P/N 216961200 (Mar 2004)
READ AND SAVE THESE INSTRUCTIONS
Use & Care Manual
Refrigerator
Record Serial/Model Numbers 2
2-3
4
3-4
4
4-5
5
6
7-8
Safety Instructions
First Steps
Energy Saving Tips
Setting
the Temperature Control
Refrigerator Features
Care and Cleaning
Warranty
Troubleshooting Guide
2
SERIAL / MODEL NUMBERS
READ ALL INSTRUCTIONS BEFORE USING
THIS REFRIGERATOR.
FOR YOUR SAFETY
Do not store or use gasoline, or other flammable vapors and
liquids in the vicinity of this or any other appliance. Read
product labels for flammability and other warnings.
CHILD SAFETY
• Destroy carton, plastic bags, and any exterior wrapping
material immediately after the refrigerator is unpacked.
Children should never use these items to play. Cartons
covered with rugs, bedspreads, plastic sheets or
stretch wrap may become airtight chambers, and can
quickly cause suffocation.
• Remove all staples from the carton. Staples can cause
severe cuts, and destroy finishes if they come in
contact with other appliances or furniture.
• An empty, discarded ice box, refrigerator, or freezer is a
very dangerous attraction to children.
• Remove and discard any spacers used to secure the
shelves during shipping. Small objects are a choke
hazard to children.
READ AND SAVE THESE INSTRUCTIONS
This Owner’s Guide provides specific operating instructions
for your model. Use your refrigerator only as instructed in
this guide. These instructions are not meant to cover every
possible condition and situation that may occur. Common
sense and caution must be practiced when installing,
operating, and maintaining any appliance.
Record Your Model and Serial Numbers
Record the model and serial numbers in the space provided
below. The serial plate is located on the upper left wall
inside the refrigerator.
Model Number:
Serial Number:
Purchase Date:
Versión en español
Si desea obtener una copia en español de este Manual del
Usuario, sívase escribir a la dirección que se incluye a
continuación. Solicite la P/N 216961300.
Spanish Owner’s Guides
Electrolux Home Products
P.O. Box 212378
Augusta, GA 30917
IMPORTANT SAFETY INSTRUCTIONS
Remove the door(s) of any appliance that is not in use,
even if it is being discarded.
ELECTRICAL INFORMATION
These guidelines must be followed to ensure that safety
mechanisms in the design of this refrigerator will
operate properly.
• Refrigerator must be plugged into its own 115 Volt,
60 Hz., AC only electric outlet. The power cord of the
appliance is equipped with a three-prong grounding
plug for your protection against shock hazards. It must
be plugged directly into a properly grounded three-
prong receptacle. The receptacle must be installed in
accordance with local codes and ordinances. Consult a
qualified electrician. Do not use an extension cord or
adapter plug.
Proper Disposal of Your
Refrigerator/Freezer
Risk of child entrapment.
Child entrapment and suffocation are not
problems of the past. Junked or
abandoned refrigerators or freezers are
still dangerous — even if they will sit for
"just a few days." If you are getting rid of
your old refrigerator or freezer, please
follow the instructions below to help
prevent accidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
• Remove doors.
• Leave shelves in place
so children may not
easily climb inside.
3
Avoid fire hazard or
electric shock. Do not use an extension
cord or an adapter plug. Do not remove
any prong from the power cord.
• If voltage varies by 10% or more, performance of your
refrigerator may be affected. Operating refrigerator with
insufficient power can damage the compressor.
• To prevent the refrigerator from being turned off
accidentically, do not plug unit into an outlet controlled
by a wall switch or pull cord.
• Do not pinch, knot, or bend the cord in any manner.
OTHER PRECAUTIONS
• Never unplug the refrigerator by pulling on the cord.
Always grip the plug firmly, and pull straight out from
the receptacle.
• To avoid electrical shock, unplug the refrigerator before
cleaning and before replacing a light bulb.
NOTE: Turning the temperature control to OFF turns off the
compressor, but does not disconnect the power to the light
bulb or other electrical components.
• Do not operate refrigerator in the presence of explosive
fumes.
This Owner’s Guide provides specific operating instructions
for your model. Use the refrigerator only as instructed in this
Owner’s Guide. Before starting the refrigerator, follow
these important first steps.
INSTALLATION
• Choose a place that is near a grounded electrical outlet.
Do Not use an extension cord or an adapter plug.
• For the most efficient operation, the refrigerator should
be located where surrounding temperatures will not drop
below 10° F (-12° C) or exceed 110° F (43° C). The
Freeze Control Feature is designed to automatically
maintain the selected interior refrigerator temperature
within these boundaries.
•
Allow space around the unit for good air circulation.
Leave a 3 inch (75 mm) space on all sides of the
refrigerator for adequate circulation.
FIRST STEPS
NOTE: The exterior walls of the refrigerator may become
quite warm as the compressor works to transfer heat from
the inside. Temperatures as much as 30° F warmer than
room temperature can be expected. For this reason it is
particularly important in hotter climates to allow enough
space for air circulation around your refrigerator.
LEVELING
The refrigerator must have all bottom corners resting firmly
on a solid floor. The floor must be strong enough to support
a fully loaded refrigerator. NOTE: It is Very Important for
your refrigerator to be level in order to function properly. If
the refrigerator is not leveled during installation, the door
may be misaligned and not close or seal properly, causing
cooling, frost, or moisture problems.
To Level Your Refrigerator:
After discarding crating screws and wood base, use a
carpenter’s level to level the refrigerator from front-to-back.
Adjust the plastic leveling feet in front, ½ bubble higher, so
that the door closes easily when left halfway open.
Installation
Unpacking and Leveling
4
CLEANING
• Wash any removable parts of the refrigerator interior, and
exterior with mild detergent and warm water. Wipe dry.
Do not use harsh cleaners on these surfaces.
• Do not use razor blades or other sharp instruments,
which can scratch the appliance surface when removing
adhesive labels. Any glue left from the tape can be
removed with a mixture of warm water and mild deter-
gent, or touch the residue with the sticky side of tape
already removed. Do not remove the serial plate.
DOOR REMOVAL
If door must be removed :
1. Gently lay refrigerator on its back, on a rug or blanket.
2. Remove two base screws and base panel. Remove wire
clips on bottom of cabinet.
3. Remove bottom hinge screws.
4. Remove plastic top hinge cover.
5. Remove screws from top hinge.
6. Remove top hinge from cabinet.
7. Remove door and bottom hinge from cabinet.
8. To replace door, reverse the above order and securely
tighten all screws to prevent hinge slippage.
• Install the refrigerator in the coolest
part of the room, out of direct sunlight
and away from heating ducts or
registers. Do not place the refrigerator
next to heat- producing appliances
such as a range, oven or dishwasher.
• Level the refrigerator so the door
close tightly.
• Do not overcrowd the refrigerator or block cold air
vents. Doing so causes the refrigerator to run longer
and use more energy. Shelves should not be lined with
aluminum foil, wax paper or paper toweling. Liners
interfere with cold air circulation, making the refrigerator
less efficient, which could cause food spoilage.
COOL DOWN PERIOD
For safe food storage, allow 4 hours for the refrigerator to
cool down completely. The refrigerator will run continuously
for the first several hours.
TEMPERATURE CONTROL
The temperature control is located inside the refrigerator. The
temperature is factory preset to provide satisfactory food
storage temperatures. However, the temperature control is
adjustable to provide a range of temperatures for your
personal satisfaction. If a colder temperature is desired, turn
the temperature control knob toward COLDEST and allow
several hours for temperatures to stabilize between adjustments.
SETTING THE TEMPERATURE CONTROL
ENERGY SAVING TIPS
REFRIGERATOR FEATURES
TILT-OUT SHELF
This shelf is located inside on the refrigerator door and
provides additional storage space. To access an item, tilt
top of “basket” shelf down.
• Cover foods and wipe containers dry before placing
them in the refrigerator. This cuts down on moisture
build-up inside the unit.
• Organize the refrigerator to reduce door openings.
Remove as many items as needed at one time and
close the door as soon as possible.
Cold Control
5
ADJUSTABLE INTERIOR SHELVES
Multi-position adjustable interior shelves can be moved to
any position for larger or smaller packages. The shipping
spacers that stabilize the shelves for shipping should be
removed and discarded.
Adjustable Interior Shelves
SLIDE-OUT BASKET
A Slide-Out Basket (some models) located at the bottom of
the refrigerator, provides separate storage space for items
that are difficult to store on refrigerator shelves. To remove
the basket, pull out and lift up.
AUTOMATIC FREEZE CONTROL
The Freeze Control Feature will maintain proper interior
refrigerator temperature even when the refrigerator is
placed in an area where the surrounding temperature drops
down to 10° F (-12° C).
INTERIOR LIGHT
The light comes on automatically when the door is opened.
To replace the light bulb, turn the temperature control to
OFF and unplug the electrical cord. Replace the old bulb
with a bulb of the same wattage.
Adjustable Interior Shelves
and Slide-Out Basket
CLEANING THE INSIDE
Wash inside surfaces of the refrigerator with a solution of
two tablespoons of baking soda in one quart (1.136 litres)
warm water. Rinse and dry. Wring excess water out of the
sponge or cloth when cleaning in the area of the controls, or
any electrical parts.
Wash the removable parts with the baking soda solution
mentioned above, or mild detergent and warm water. Rinse
and dry. Never use metallic scouring pads, brushes,
abrasive cleaners, or alkaline solutions on any surface. Do
not wash removable parts in a dishwasher.
CLEANING THE OUTSIDE
Wash the cabinet with warm water and mild liquid deter-
gent. Rinse well and wipe dry with a clean soft cloth.
Replace parts and food.
VACATION AND MOVING TIPS
Vacations:
If the refrigerator will not be used for several months:
• Remove all food and unplug the power cord.
• Clean and dry the interior thoroughly.
• Leave the refrigerator door open slightly, blocking it open
if necessary, to prevent odor and mold growth.
Moving: When moving the refrigerator, follow these guide-
lines to prevent damage:
• Disconnect the power cord plug from the wall outlet.
• Remove foods and clean the refrigerator.
• Secure all loose items by taping them securely in place
to prevent damage.
• In the moving vehicle, secure refrigerator in an upright
position to prevent movement. Also protect outside of
refrigerator with a blanket, or similar item.
CARE AND CLEANING
If leaving the refrigerator
door open while on vacation, make
certain that children cannot get into the
refrigerator and become entrapped.
WARNING
6
REFRIGERATOR WARRANTY
Your refrigerator is protected by this warranty
WARRANTY
PERIOD
THROUGH OUR AUTHORIZED SERVICERS,
WE WILL:
THE CONSUMER WILL BE RESPONSIBLE FOR:
FULL ONE-YEAR
WARRANTY
One year from original
purchase date
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship. Excludes original and replacement Ice
& Water filter cartridges (if equipped). Original and
replacement cartridges are warranted for 30 days
(parts only).
Costs of service calls that are listed under
NORMAL
RESPONSIBILITIES OF THE CONSUMER. *
LIMITED 2
ND
-5
TH
YEAR WARRANTY
(Cabinet Liner and
Sealed System)
Second through fifth
years from original
purchase date
Repair or replace any parts in the cabinet liner or
Sealed Refrigeration System (compressor, condenser,
evaporator, drier and tubing) which prove to be
defective in materials or workmanship.
Costs for pick up and delivery of the appliance required because
of service. Costs for labor, parts and transportation other than
with respect to the cabinet liner or Sealed Refrigeration System.
LIMITED
WARRANTY
(Applicable to the
State of Alaska)
Time periods listed
above.
All of the provisions of the full warranties above and
the exclusions listed below apply.
Costs of the technician's travel to the home and any costs for
pick up and delivery of the appliance required because of
service.
In the U.S.A., your appliance is warranted by Electrolux Home Products, Inc. We authorize no person to change or add to any of our obligations
under this warranty. Our obligations for service and parts under this warranty must be performed by us or an authorized Electrolux Home Products,
Inc. servicer. In Canada, your appliance is warranted by Electrolux Canada Corp.
This warranty applies only to products in ordinary household use, and the consumer is responsible for the
items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves,etc.,
which are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
NOTE:
Some states do not allow the exclusion or limitation of incidental or consequential damages, so this
limitation or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in
ordinary household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Electrolux Home Products, Inc. or its authorized
servicers; use of parts other than genuine Electrolux Home Products, Inc. parts; obtained from persons other
than such servicers; or external causes such as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the
warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all
receipts. This written warranty gives you specific legal rights. You may also have other rights that vary from state to
state. Service under this warranty must be obtained by contacting Electrolux Home Products, Inc.:
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
USA
800•944•9044
Electrolux Home Products, Inc.
P.O. Box 212378
Augusta, GA 30917
Canada
866•213•9397
Electrolux Canada Corp.
6150 McLaughlin Road
Mississauga, Ontario
L5R 4C2
This warranty only applies in the 50 states of the U.S.A., Puerto Rico, and Canada. Product features or specifications as described or illustrated
are subject to change without notice. All warranties are made by Electrolux Home Products, Inc. In Canada, your appliance is warranted by
Electrolux Canada Corp.
01-U-FR-02 (Rev. 01/2002)
7
GNITOOHSELBUORT
EDIUG
tsilsihT.esnepxednaemituoyevasyamtI.tsilsihtweiver,ecivresrofgnillacerofeB
ropihsnamkrowevitcefedfotluserehttoneratahtsecnerucconommocsedulcni
.ecnailppasihtnislairetam
MELBORPESUACNOITCERROC
NOITAREPOROTAREGIRFER
.nurtonseodrotaregirfeR
aotnideggulpsirotaregirfeR•
tluafdnuorgasahtahttiucric
.tpurretni
ehtnisilortnocerutarepmeT•
.noitisopFFO
•rotaregirfeRdeggulpebtonyam
.esoolebyamgulpro,ni
deppirtronwolbesufesuoH•
.rekaerbtiucric
.egatuorewoP•
eva
h,teltuoehttuobaerusnuerauoyfI.tiucricrehtonaesU•
.naicinhcetdeifitrecaybdekcehcti
eeS•
lortnoCerutarepmeTehtgnitteS
.noitceS
.teltuootnidehsupylthgitsigulperusnE•
teseR.esufyaled-emitpma51ahtiwesufecalper/kcehC•
.rekaerb
tiucric
.ynapmoCcirtcelElacolllaC.sthgilesuohkcehC•
rohcumootsnurrotaregirfeR
.gnoloot
.tohsirehtaewedistuoromooR•
•rotaregirfeRneebyltnecersah
fodoireparofdetcennocsid
.emit
tohromrawfostnuomae
graL•
.yltnecerderotsneebevahdoof
yltneuqerfootdenepoerasrooD•
.gnolootro
•rotaregirfeRylthgilsebyamrood
.ne
po
oottessilortnoCerutarepmeT•
.wol
•rotaregirfeR,ytridsiteksag
.dettifylroopro,dekcarc,nrow
rehtroflamrons'
tI•rotaregirfeesehtrednuredrahkrowot
.snoitidnoc
ehtrofsruoh4sekattI•taregirfernwodloocotro
.yletelpmoc
esuac
lliwdoofmraW•rotaregirferehtlitnueromnurot
.dehcaersierutarepmetderised
ehtgniretneriamraW•rotaregirfer.ero
mnurottisesuac
.netfosselsroodnepO
eeS•
"SMELBORPROOD"
noitceS
.
•sruohlareveswollA.gnittesremrawaotbonklortnocnruT
.ezilibatsoterutarepmetehtrof
esuaclliwlaesroodehtnis
kaeL.teksagegnahcronaelC•
rotaregirferderisedniatniamotredroniregnolnurot
.erutarepmet
erutarepmetrotaregirferroiretnI
.dlocootsi
oottessilortnoCerutarepmeT•
.wol
sruohlareveswollA.gnittesremrawaotlortnocehtnruT•
.ezilibatsoterutarepm
etehtrof
erutarepmetrotaregirferroiretnI
.mrawootsi
oottessilortnoCerutarepmeT•
.mraw
sirognolootnepotpeksirooD•
.yltneuqerfootdenepo
gnitaesebtonyamrooD•
.yl
reporp
tohromrawfostnuomaegraL•
derotsneebevahyamdoof
.yltnecer
neebyltnecersahrotaregirfeR•
fodoireparofd
etcennocsid
.emit
ehtrofsruohlareveswollA.gnittesredlocaotlortnocnruT•
.ezilibatsoterutarepmet
siroodehte
mityreverotaregirferehtsretneriamraW•
.netfosselroodehtnepO.denepo
eeS•
"SMELBORPROOD"
.noitceS
stihcaerotecnahcadahsahrotaregirferehtlitnutiaW•
.erutarepmetdetceles
.yletelpmocnwodloocotsruo
h4seriuqerrotaregirfeR•
ecafruslanretxerotaregirfeR
.mrawsierutarepmet
sllawrotaregirferlanretxeehT•
remrawF°03sahcumsaebnac
.erutarepmetmoornaht
refsnartotskrowrosserpmocehtelihwlamronsisihT•
.tenibacrotaregirferehtedisnimorftaeh
ESIONDNADNUOS
revenehwsleveldnuosreduoL
.nosirotaregirfer
evahsrotaregirfernredoM•
dnayticapacegarotsdesaercni
yehT.serutarepmetelbatserom
ycneiciffehgihaeriuqer
.
rosserpmoc
,wolsilevelesiongnidnuorrusehtnehW.lamronsisihT•
ehtslooctielihwgninnurrosserpmocehtraehthgi
muoy
.roiretni
nehwsleveldnuosregnoL
.nosemocrosserpmoc
rehgihtasetareporotaregirfeR•
ehtfotratsehtgnirudserusserp
.elcycNO
saraeppasidroffolevellliwdnuoS.lamronsisihT•
.nurotseunitnocrotaregirfer
8
MELBORPESUACNOITCERROC
(ESIONDNADNUOS
).tnoC
moornehwsnurnaF
.F°54wolebsierutarepmet
sahtatsomrehtroiretxE•
.nafdnaretaehehtdetavitca
.lamronsisihT•
dnuosgnikcarcrognippoP
.nosemocrosserpmocnehw
noisnapxeogrednustraplateM•
retawtohnisa,noitcartnocdna
.sepip
saraeppasidroffolevellliwdnuoS.lamronsisihT•
.nurotseunitnocrotaregirfer
,dnuosgnilgrugrognilbbuB
.gniliobretawekil
loocotdesu(tnaregirfeR•
gnitalucricsi)rotaregirfer
.metsysehttuohguorht
.lamronsisihT•
.esiongnilttarrognitarbiV
skcortI.leveltonsirotaregirfeR•
devomsitinehwroolfehtno
.ylthgils
.llawehtgnihcuotsirotaregirfeR•
ehtni"gnileveL"otrefeR.tinuehtleveL•
spetStsriF
.noitceS
refeR.ylthgilsrotaregirferevomrorotaregirferehtleveleR•
ehtni"gnileveL"ot
spetStsriF
.noitceS
.dnuoSgnippanS
ehtgninrutlortnoCdloC•
.ffodnanorotaregirfer
.lamronsisihT•
ROTAREGIRFEREDISNITSORF/ERUTSIOM/RETAW
foedisninosmroferutsioM
.sllawrotaregirfer
.dimuhdnatohsirehtaeW•
gnitaesebtonyamrooD•
.ylreporp
siro,gnolootnepotpeksirooD•
.yltneuqerfootdenepo
.lamronsisihT•
"eeS•
SMELBORPROOD
.noitceS"
.netfosselroodehtnepO•
ROTAREGIRFEREDISTUOTSORF/ERUTSIOM/RETAW
foedistuonosmroferutsioM
.rotaregirfer
gnitaesebtonyamrooD•
riadlocehtgnisuac,ylreporp
otrotaregirferehtedisnimorf
morfriatsiommrawteem
.edistuo
"eeS•
SMELBORPROOD
.noitceS"
ROTAREGIRFERNIRODO
.rotaregirfernisrodO
.denaelcebotsdeenroiretnI•
nierasrodognortshtiwsdooF•
.rotaregirfereht
.adosgnikabdna,retawmraw,egnopshtiwroiretninaelC•
.ylthgitdoofehtrevoC•
SMELBORPROOD
.esolctonlliwrooD
skcortI.leveltonsirotaregirfeR•
devomsitinehwroolfehtno
.ylthgils
dnaerauqsfotuotenibacehtecrofnacnoitidnocsihT•
ehtni"gnileveL"otrefeR.roodehtngilasim
spetStsriF
.noitceS
NOTONSIBLUBTHGIL
.notonsiblubthgiL
.tuodenrubsiblubthgiL•
gnihcaersitnerruccirtceleoN•
.rotaregirfereht
ehtni"thgiLroiretnI"rednusnoitceridwolloF•
rotaregirfeR
serutaeF
.noitceS
"eeS•
NOITAREPOROTAREGIRFER
.noitceS"
