OPERATION
DRYING
CHANGING THE PROGRAMME SEQUENCE
Before commissioning the tumble
dryer for the first time, make sure it has
been installed correctly. Connect it
correctly.
Please read the separate operating
instructions supplied with the appliance.
Risk of damage due to incorrect use
or operation.
This tumble dryer contains a refrigerant
that is flammable and explosive.
It is essential to read the separate
operating instructions.
Damage caused by switching the
appliance on too soon.
The heat pump can be damaged.
After setting up the tumble dryer, wait for
at least one hour before starting a drying
programme.
Switching on the tumble dryer
Turn the programme selector to a
programme.
The welcome tone will sound and the
welcome screen will light up.
The display will guide you step by step
through the initial commissioning process.
For further information, please refer to the
separate operating instructions.
Operating the sensors
The sensors react to fingertip contact. If a
sensor is illuminated, it can be selected.
If a sensor is brightly lit, this means it is
currently selected.
If a sensor is dimly lit, this means that
selection is possible.
a
Control panel
The control panel consists of a display
and various sensors.
b
Sensors for the Extras
You can supplement the drying
programmes with Extras.
c
Display
Various values are displayed and/or
selected in the display.
d
sensors
The values in the display can be
changed with the sensors.
e
OK sensor
Confirm selected values with the OK
sensor.
f
sensor
The sensor starts the Delay start
function.
g
sensor
You can use the sensor to call up an
energy consumption forecast for the
selected drying programme.
h
Start/Add laundry sensor
Touching the Start/Add laundry sensor
starts the selected programme. The
current programme can be interrupted
to add laundry. The programme can be
started as soon as the sensor is
flashing on and off. The sensor lights up
constantly once the programme has
started.
i
PerfectDry indicator
The PerfectDry system measures the
residual moisture present in the laundry
in programmes with selectable drying
levels and provides a more precise
drying result.
The indicator flashes at the beginning of
the programme and lights up towards
the end of the programme.
j
Optical interface
For service technicians.
k
Programme selector
For selecting programmes and for
switching the appliance off.
– MobileStart and Wash2Dry
for an alternative programme
selection. Prerequisite: the tumble
dryer is connected to the network
– Further programmes/
for
additional programmes and options
for changing settings.
Energy savings
There are various steps you can take to
avoid unnecessarily long drying times and
high energy consumption:
- Make sure your laundry is spun at the
maximum spin speed before drying.
- Load according to the optimum amount
of laundry recommended for the drying
programme. This will mean that the
energy consumption for the amount of
laundry is the most economical.
- Make sure the room temperature is not
too high.
If there are other heat producing
appliances in the room in which the
tumble dryer is located, make sure the
room is well ventilated and switch the
other appliances off if possible.
- Clean the fluff filters after every drying
cycle.
Preparing the laundry
Damage due to foreign objects which were not
removed from the laundry.
Foreign objects can melt, burn, or explode.
Remove foreign objects (e.g. detergent dispenser, loose
bra hangers, lighter and all objects) from the laundry.
Fasten duvet covers and pillow cases to prevent small
items from being rolled up inside them.
Loading the tumble dryer
Do not overload the drum. Overloading can give a
disappointing drying result and cause unnecessary wear
and tear to the laundry. It can also cause more creasing.
Loosen the laundry.
Open the tumble dryer door.
Check that the drum is empty.
Load the laundry in the drum.
Insert the fragrance flacon.
If you are drying without a
fragrance capsule, close both
sockets. Slide the tab of each
slider downwards (arrows).
Shut the door with a gentle
swing.
Risk of damage to laundry.
When closing the door, make
sure that laundry does not get
trapped in the door opening.
1
Condensed water container
2
Door
3
Control panel
4
Plinth filter access panel
5
Cold air intake grille
1. Selecting a programme
Turn the programme selector. The interior
drum lighting will come on.
There are 4 possible ways to select a
programme:
Useful tip: The condensed water container
must be filled to use certain programmes.
1. Selecting standard programmes via the
programme selector
Turn the programme selector to the required
programme.
The selected programme will be shown in the display. This
will then be replaced by the standard display.
2. Selection of further programmes via Further
programmes/ and the display
Turn the programme selector to the Further
programmes/
position.
Touch the sensors until the programme you want
appears in the display.
Confirm the programme with the OK sensor.
3. Selection via MobileStart
Turn the programme selector to the MobileStart
position.
Follow the instructions in the display.
Touch the Start/Add laundrysensor.
The tumble dryer can now be operated via a mobile device
together with the Miele App.
4. Selecting the Wash2Dry function
After the programme has finished in the washing machine,
the tumble dryer display will show the most appropriate
drying programme for the laundry.
Load the tumble dryer.
Touch the Start/Add laundrysensor.
2. Selecting programme settings
Selecting the drying level
Drying levels can be selected for certain programmes as
per the “Programme chart”.
Touch the or sensor to select a drying level.
Useful Tip: HygieneDry: Reduce laundry loads by half.
Selecting the programme duration
You can select a programme duration for the programmes
Cool air, Warm air, Basket programme.
Touch the or sensor to select a programme
duration.
Selecting an Extra
Extras can be selected according to the
"Programme chart", but are not available for
all drying levels.
Touch the sensor for the Extra you want.
It then lights up brightly.
DryFresh
Refreshing without steam.
Tip: use the DryFresh fragrance flacon,
reduce the load size.
DryCare40
Gentle temperature for all fabrics that are
free of wool and are washable at
temperatures of 40°C and above. It is also
suitable for fabrics with the symbol on
the care label.
Tip: reduce the amount of laundry for the
load.
PowerFresh
Refresh using steam.
Tip: use the DryFresh fragrance flacon,
reduce the load size.
Buzzer
A buzzer sounds at the end of the
programme.
Delay start/SmartStart
Delay start
With Delay start you can delay the start of a
programme. The start of the programme
can be delayed from 15 minutes up to a
maximum of 24 hours.
SmartStart
The SmartStart function (only available in
selected countries) lets you define a time
period during which your tumble dryer will
start automatically. The machine will start
on receipt of a signal, e.g. from your energy
supplier, that indicates that the electricity
rate is particularly economical.
EcoFeedback
You can use the sensor to call up an
energy consumption forecast for the
selected drying programme.
Touch the sensor.
The estimated energy consumption will be
displayed as a bar chart.
3. Starting the programme
Touch the flashing Start/Add laundry
sensor.
The Start/Add laundrysensor lights up and
the programme starts. When Delay start is
being used, the programme duration will
appear after the Delay start time has
elapsed.
Adding or removing laundry
You have forgotten an item of laundry, but
the programme has already started.
Touch the Start/Add laundry sensor.
Door can be opened lights up in the
display.*
Open the tumble dryer door.
Add or remove laundry.
Close the door.
Touch the Start/Load laundry sensor to
start the programme.
*Exceptions
In some cases – for example, during the
cooling phase or the Proofingprogramme –
it is not possible to add laundry items.
HygieneDry drying level: the HygieneDry
drying process starts at the end of the
normal drying process and must not be
interrupted.
Cancelling the current programme
You cannot change to another programme
once a programme has started. This
prevents the appliance being operated
unintentionally.
If you adjust the programme selector,
Cannot be changed will light up in the
display. This indicator goes out when you
select the original programme.
Turn the programme selector to the
position.
The programme is cancelled. You can now
select a new programme.
At the end of the programme
The programme is finished when Finish/
Anti-crease or Finish appears in the display.
The Start/Add laundrysensor goes out.
- 10minutes after the end of the
programme the Start/Add laundrysensor
will begin to flash slowly and the display
will go out.
- The tumble dryer switches off
automatically.
Do not open the tumble dryer door before
the end of the programme.
Open the door.
Remove the laundry.
Items left in the dryer could be damaged
by overdrying when the dryer is used the
next time.
Always remove all items from the drum.
If the dryer is switched on and the door is
opened, the drum lighting will come on. The
drum lighting will go out after a few minutes
to save energy.
Turn the programme selector to .
Clean the fluff filters.
Close the drum door.
Empty the condensed water container.
Emptying the condensed water
container
Empty the condensed water container
after every drying programme.
Empty container. See will appear in
the display if the maximum level of the
condensed water container is reached.
Open and close the door to deactivate
this message.
Pull out the
condensed water
container.
To prevent water running out, hold the
condensed water container by the front
panel and at the back to keep it in a
horizontal position.
Empty the
container.
Replace the
container in the
dryer.
Filling the condensed water
container
For some programme applications, the
condensed water container must be filled
to at least the -min- mark.
With the condensed water draining
externally, the condensed water container is
empty. Only fill with commercially available
condensed water.
Fill through the
rings of the
pouring spout.
To stop the spray jet becoming calcified,
only fill with tap water in exceptional
circumstances.
Useful tip: This tumble dryer has 2
sockets for inserting fragrance flacons.
You can use one or both sockets to give
your laundry a pleasant fragrance.
Close the unused socket.
Before using a fragrance flacon, please
read "Warning and Safety instructions -
Using a fragrance flacon (optional
accessory)" and "Fragrance flacon" in
the operating instructions.
Inserting a fragrance flacon
1. 2.
3. 4.
Marker must be in position .
5. 6.
Turn the outer ring clockwise a little.
Marker must be in position .
Setting the fragrance intensity
The further you
turn the outer ring
of the fragrance
flacon clockwise,
the more intense
the fragrance.
Closing the fragrance flacon
Turn the outer
ring anti-
clockwise until
marker is in
position .
Removing the fragrance flacon
Turn the outer
ring until marker
is in position
.
Remove the fragrance flacon.
To prevent any fragrance running out of
the flacon, do not lay it down on any
surface.
Only store the fragrance flacon in its
original packaging.
Using for the first time Operation Drying End of the programme FragranceDos
fold here fold here fold here fold here fold here fold here
en-AU, NZ
M.-Nr. 11 909 390
TWL 780 WP
fold here fold here fold here fold here fold here fold here
PROGRAMME CHART
CLEANING AND CARE
PROBLEM SOLVING GUIDE
Programme overview Cleaning and care Problem solving guide
Programme Load (weight
of dry
laundry)
Items
HygieneDry
Extra dry
Normal+
Normal
Hand iron
Hand iron
Machine Iron
Extras
Cottons 9 kg Cotton items such as those described under Cottons
Normal with normal residual moisture.
— — X — — — —
Cottons 9 kg Towelling, jersey wear, T-shirts, underwear, baby
clothes, workwear, covers, jackets, bathrobes, and
flannelette bed linen.
Do not use Extra dry for jersey fabrics (e.g. T-shirts,
underwear, baby clothes), as they have a tendency to
shrink.
X X X X X X X
Minimum iron 4 kg Workwear, overalls, pullovers, dresses, trousers,
leggings and table linen.
— X X X X X —
Delicates 2.5 kg Dress shirts, blouses, lingerie, appliquéd garments. — — — X X X —
Woollens handcare 2 kg Pullovers, knitted jackets, socks, stockings. — — — — — — —
Shirts 2 kg Shirts and blouses. — — X X X X —
MobileStart The Miele App is used to select programmes and operate the appliance.
Wash2Dry Automatic programme selection depending on the networked washing machine.
Bed linen 4 kg Bed linen X X X X X X X
Steam care 1 kg Cotton trousers, anoraks, shirts. — — — X X — —
Pre-ironing 1 kg Cotton trousers, anoraks, shirts. — — — X — X —
Warm air 9 kg Thick and multi-layered jackets, pillows, sleeping bags,
blankets.
— — — — — — —
Outerwear 2.5 kg For outdoor clothing. — — — X X — —
Proofing 2.5 kg Microfibre fabric, skiwear, outerwear, fine close weave
cotton garments (poplin), tablecloths.
Risk of fire! Do not use proofing agents
containing paraffin.
— — — X — — —
Express 4 kg Garments suitable for the Cottons programme. X X X X X X X
Sportswear 3 kg Sportswear. — — X X X X —
Automatic plus 5 kg Loading mix of cotton and easy care. — — X X X X —
Pillows – Pillows: 2 small 40x80cm or 1 large 80x80cm X – – X – – –
Basket programme 3.5 kg
basket load
Use dryer basket for bags, shoes, soft toys, hats,
scarves, gloves, sequined tops.
– – – – – – –
Silks handcare 1 kg Blouses, shirts. — — — — — — —
Denim 3 kg Denim garments, e.g. jackets, jeans, shirts, and skirts. — — X X X X —
Cool air 9 kg All textiles. — — — — — — —
= DryFresh, = DryCare 40, = PowerFresh, = Buzzer
Extras cannot be combined. Exception: buzzer
X = Yes, – = No
Care symbols
Drying Ironing
Normal/Higher temperature Very hot
Reduced temperature (for delicate fabrics): select Gentle tumble Hot
Do not tumble dry Warm
— — Do not treat with heat
Fluff filter
Removing visible fluff
Clean the 2 fluff filters in the door opening
at the end of every programme.
Remove the fragrance flacon.
Pull the upper fluff
filter forwards to
remove it.
Use your fingers
or a vacuum
cleaner ...
... to remove the
fluff from the
surface of the
filter.
Push the upper fluff filter back in until it
clicks into position.
Close the door.
Cleaning the fluff filters and air flow
openings thoroughly
If the drying duration has become longer
or the surface of the filters is visibly
compacted with fluff, you should carry out
the following cleaning procedure.
Pull the upper fluff filter forwards to
remove it.
Turn the yellow
dial on the lower
fluff filter in the
direction of the
arrow (until you
hear it click).
Hold the dial and
pull the fluff filter
forwards to
remove it.
Use a vacuum
cleaner with a
long crevice
nozzle attached to
remove any visible
fluff from the
upper air flow
openings.
Flush the fluff filters through with warm
running water.
Shake the fluff filters thoroughly and then
dry them carefully.
Ensure the filters are dry before replacing
them. Wet filters could cause operational
faults.
Refit all of the fluff filters and close the
door.
Plinth filter
Clean the plinth filter when the
programme running time is longer than
usual or whenever Clean the plinth filter.
See lights up.
To delete the message: confirm with OK.
Press the round,
indented area on
the access panel
to open it.
Pull the plinth filter
out by the handle.
When the plinth filter is pulled out, the right
guide pin will slide out. The guide pin
prevents the flap from being closed without
the plinth filter in place.
Pull the handle out
of the plinth filter.
Clean the filter thoroughly under running
water.
Squeeze the plinth filter carefully several
times as you rinse it.
Rinse the plinth filter until all visible
residues have been removed.
Use a damp cloth
to remove any
fluff.
Refitting the plinth filter
Fit the plinth filter
back on the
handle the right
way round.
Push the plinth
filter in completely.
Insert the right guide
pin at the same time.
Close the panel.
Some of the messages in the display are more than one line long. Touch the or sensor
to read them in full.
Problem Possible cause and remedy
000
Access via a code has been activated.
You must enter the correct PIN code to use the tumble
dryer. See “Settings – Code” in the operating
instructions.
Empty container. See
lights up after a
programme has been
cancelled.
The condensed water container is full or there is a kink in
the drain hose.
Open and close the door with the tumble dryer switched
on to clear the fault, or switch the tumble dryer off and
then on again.
Empty the condensed water container.
Check the drain hose.
Clean the plinth filter. See
lights up at the end of
a programme.
There is a build-up of fluff.
To deactivate the message, confirm with OK.
See “Cleaning and care” in the operating instructions.
Clean the fluff filter.
Clean the plinth filter.
Clean the plinth filter. See
lights up after a
programme has been
cancelled.
There is a blockage due to a build-up of fluff.
See “Cleaning and care” in the operating instructions.
To deactivate the message, turn the programme selector
to the position.
Clean the fluff filter.
Clean the plinth filter.
Clean the air flow openings.
Clean the heat exchanger.
Fill condensate container
The condensed water container is empty. When certain
programmes are being used, water is taken from the
condensed water container and recycled.
To deactivate the message, confirm with OK.
Fill the condensed water container to at least the
―min―mark.
Finish/Cooling down
The laundry is cooled down at the end of the programme.
Either remove the laundry and spread it out to cool down
or leave it in the tumble dryer to cool down during the
cooling phase.
Problem Possible cause and remedy
The display is in a
different language.
A different language has been selected in "Settings –
Language ".
Set the language you want. The flag symbol serves as a
guide.
The display remains dark,
and the sensor does not
light up or flash.
There is no power to the tumble dryer.
Check whether the mains plug is plugged in and
switched on.
Check whether the circuit breaker has tripped.
The tumble dryer has switched off automatically to save
energy.
Turn the programme selector to switch the tumble dryer
on again.
The laundry is not
sufficiently dry.
The load consisted of different types of fabric.
Finish drying using the Warm air programme.
Select a more suitable programme next time.
Items made of synthetic
fibres are charged with
static electricity after
drying.
Items made of synthetic fibre can become charged with
static electricity in the tumble dryer.
Static charge can be reduced by adding fabric softener
to the final rinse in the washing programme.
There is a build-up of
fluff.
Fluff is principally the result of friction when garments are
being worn and to some extent when they are being
washed. Tumble drying hardly causes any fluff to form.
Fluff is collected by the fluff filters and the plinth filter.
See “Cleaning and care” in the operating instructions.
There are operating
noises (whirring/
humming).
This is not a fault.
The compressor (heat pump) is operating, or you have
selected a programme which sprays condensed water into
the drum.
No action is required.
Quick Start Guide
Heat pump tumble dryer
These short instructions are not a substitute for the operating instructions supplied with
the appliance. Please read the operating instructions supplied with your tumble dryer
before using it for the first time and take note of the Warning and Safety instructions, as
well as the full descriptions on how to use your appliance.
en-AU, NZ
M.-Nr. 11 909 390 / 00
fold here fold here fold here fold here fold here fold here
