Owner’s Manual
SmartRack
®
NEMA-3R
Wall-Mount Heavy Duty
Cabinet
General-Use Industrial Control
Models: SRN3RG12UHD, SRN3RG18UHD
(Series Number: AG-0606)
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2021 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
Table of Contents
1. Important Safety Instructions 2
2. Overview 2
3. Feature Identification 3
4. Enclosure Installation 4
4.1 Preparation 4
4.2 Unpacking 4
4.3 Ground Connection 5
5. Enclosure Configuration 5
5.1 Door Locks 5
5.2 Cable Access and Management 5
5.3 Mounting Rails 6
5.4 Adjusting Mounting Rail Depth 6
6. Wall Mounting the Enclosure 7
7. Equipment Installation 9
8. Specifications 9
8.1 Unit Dimensions 9
8.2 Package Dimensions 9
9. Storage and Service 10
10. Warranty and Product Registration 10
Español 11
Francais 21
