LIMITED WARRANTY
PERFORMANCE TOOL extends only the following warranties, and only to original retail purchasers. These warranties give spe-
cific legal rights. Except where prohibited by local law, the law of the State of Washington governs all warranties and all exclusions
and limitations of warranties and remedies. There may be other rights which vary from state to state.
PERFORMANCE TOOL warrants the product to be free from defects in materials and workmanship under normal use and service.
A defective product may be returned for a free replacement within 90 days from the date of purchase, provided that product is
returned to place of purchase immediately after discovery of defect. After 90 days and up to 1 year from date of purchase,
PERFORMANCE TOOL will replace at no charge any parts which our examination shall disclose to be defective and under war-
ranty. These warranties shall be valid only when a sales receipt showing the date of purchase accompanies the defective product
or defective part(s) being returned. For part(s) after 90 days, please remit your request, postage prepaid to: PERFORMANCE
TOOL, P.O. Box 88259 Tukwila, WA 98138
These warranties exclude blades, bits, punches, dies, bulbs, fuses, and other consumables which must be replaced under normal
use and service. These warranties shall not apply to any product or part which is used for a purpose for which it is not designed,
or which has been repaired or altered in any way so as to affect adversely its performance or reliability, nor shall these warranties
apply to any product or part which has been subject to misuse, neglect, accident or wear and tear incident to normal use and
service.
PERFORMANCE TOOL does not authorize any other person to make any warranty or to assume any liability in connection with
its products.
Except for warranties of title and the limited express warranties set forth above, PERFORMANCE TOOL makes no express or
implied warranties of any kind with respect to its products. In particular, PERFORMANCE TOOL makes no implied warranty of
merchantability and no implied warranty of fitness for any particular purpose, except that for goods purchased primarily for per-
sonal, family or household use and not for commercial or business use, PERFORMANCE TOOL makes an implied warranty of
merchantability (and, if otherwise applicable, an implied warranty of fitness for a particular purpose), but only for the particular
qualities or characteristics, and for the duration, expressly warranted above. The laws on limitation of implied warranties may differ
from state to state, so the above limitations may not apply in all cases.
PERFORMANCE TOOL shall not be liable for consequential, incidental or special damages resulting from or in any manner
related to any product, or to the design, use, or any inability to use the product. The sole and exclusive remedy for a defective
product or part shall be the repair, or replacement thereof as provided above. The laws on limitation of remedies or on consequen-
tial, incidental or special damages may vary from state to state, so the above limitations may not apply in all cases.
Copyright © 2008 PERFORMANCE TOOL – All rights reserved
OPERATION
Before using your jack:
Place pump handle over release valve and turn counter-clockwise to
open. Pump jack about 6 full strokes to ensure complete distribution
of hydraulic fluid. (See Figure 1)
To raise:
Refer to vehicle owner’s manual for
proper jacking procedures. Lift only on areas of vehicle as specified
by manufacturer. Make certain that load is centered on saddle. Place
pump handle over release valve and turn clockwise to close. Insert
handle into handle socket and
pump to raise load to desired
height. ALWAYS support load
with jack stands. (See figure
2)
To lower:
Raise load enough to remove jack stands. SLOWLY turn release
valve counter-clockwise just enough to allow controlled descent.
(Never turn more than 3 full turns)
Open
Close
Release
Valve
1. When jack is not in use, ram and pump piston should be in fully down
position to keep their machined surfaces free from corrosion.
2. Keep jack clean and well lubricated at points illustrated in figure 3.
3. For best results, use only hydraulic fluid with a rating of SAE 10 for
refills. Check fluid level with jack in fully down position. Fluid level
should be up to bottom of oil fill port. (See figure 5)
4. Regularly check for loose, worn or damaged parts. Any jack that
appears damaged in any way must
be removed from service.
5. Replace worn or damaged parts with
Performance Tool replacement parts.
Be sure that only qualified personnel
perform repairs.
CARE & MAINTENANCE
1
2
3
4
Figure 3
Figure 2
Jack Stands
Figure 1
50 Ton
Hydraulic Bottle Jack
OWNER'S MANUAL
Stock Number W1637
FOR YOUR SAFETY,
please read these instructions carefully and retain them for future use.
