User Manual
01
IMPORTANT SAFETY INSTRUCTIONS
BEFORE USING THIS APPLIANCE, READ ALL INSTRUCTIONS AND CAUTIONARY
MARKINGS IN YOUR USER MANUAL AND ON THE APPLIANCE.
WARNING
The hair dryer, filter and attachements contain magnets, keep away from implanted medical
devices such as pacemakers and defibrillators as they may be afffected by strong magnetic fileds.
Do not use the hair dryer on babies.
Do not allow children to use the hair dryer without the supervision of adults.
Do not use the hair dryer for any other purpose than drying hair.
Do not use the hair dryer near flammable and explosive materials.
Do not use the hair dryer or touch the plug with wet hands.
Do not submerge the hair dryer into any liquid.
Do not use the hair dryer in high humidity or high temperature environments.
Do not use the hair dryer near bathtubs, showers, basins or other vessels containing water.
Laifen hair dryer has overheat protection. if the device overheats, it will automatically turn off.
Please unplug the device and leave it for cooling down.
Do not obstruct the air inlet, this may cause overheating and may present a fire hazard.
The air outlet and attachements are hot during usage, do not touch them before they cool down.
Do not use the hair dryer if the plug or wire is damaged.
Do not wrap the wire around the hair dryer.
Do not stretch the wire.
Do not unplug the hair dryer by pulling on the wire.
Please keep the wire away from hot surfaces.
After using or before cleaning the hair dryer, please unplug it.
Do not use any detergents, lubricants, air freshers or polishes on the hair dryer or attachments.
Do not disassemble, repair or replace any part of the hair dryer by yourself.
Do not use the hair dryer if it has been dropped in water or damaged.
When the hair dryer is used in the bathroom, unplug it after using. It is also recommended to
install a Residual Current Device(RCD)/GFCI, with a residual operating current not exceeding
30mA, in the electrical circuit supplying the bathroom.
02
The instruction photo, accessories and user’s interface are for
reference. Your product may appear differently. Please refer
to the actual product for further information.
Product Features
Laifen Digital Motor
The Laifen digital motor spins up to 105000 rpm, propelling the airflow up to 21m/s fast drying.
Smart Thermo-control System
The smart thermo-control system measures airflow temperature over 50 times per second to protect
your hair from extreme heat damage.
Hair-caring Ionic Technology
The ionic generator produces 200 million/cm3 of ionic to neutralize static electricity for smooth and
glossy hair.
Hot-Cold Air Circulation Mode
Press the tempareture control button for 1 second to start the hot-cold air circulation mode. Hot air
and cold air alternates every 2 seconds.
Noise-reducing Technology
Modulate the frequency of motor noise to a range
that human ears cannot perceive. Only the sound
of wind will be heard.
*(1): 21m/s is the speed of hot airflow near the air outlet
Functions Instruction
Airflow outlet
Power/Air flow control
Temperature Control
Laifen LOGO
Air inlet/Removable
filter cage
RED Hot
Yellow Warm
Blue Cold
LED temperature
indicator
03
Parameters
Laifen SE High speed hair dryer
Product Name: Hair Dryer
Model: SE
Rated Voltage: 110V (refer to dryer body)
Rated Frequency: 50-60Hz(refer to dryer body)
Rated Power: 1400W(110V)
Product Dimension: 270*70*89mm
Product Name: Hair Dryer
Model: SE
Rated Voltage: 220V (refer to dryer body)
Rated Frequency: 50Hz (refer to dryer body)
Rated Power: 1500W(220V)
Product Dimension: 270*70*89mm
Move up and down this button to shift the airflow speed.
Ensure the Power button is set at OFF before connecting to power.
This package doesn’t include a nozzle. You can purchase a
right nozzle by need.
How to attach the nozzle on the hair dryer?
Bring the nozzle close to the air outlet of the device, the
magnetic rings will easily clip on each other, then the nozzle
could be rotated to any position.
Speed Settings
Accessories (purchase optionally)
Power off (o) Low Speed (－) High Speed (＝)
Smooth nozzle :
59mm
61mm
61mm
04
Diuser nozzle :
for styling curly hair during drying.
Styling nozzle (concentrator) :
for styling straight hair during drying.
79mm
70mm
61mm
135mm
63mm
05
Filter should be cleaned and maintained regularly to avoid damages, ensuring that the air inlet is always clean
and clear of blockage.
Never wash the filter with water or any other liquid.
Ensure to turn off the hair dryer and unplug it before cleaning the filter cover.
Clean the outter filter cage and inner filter with dry cloth or soft brush.
After cleaning, mount the filter cage back to the filter, until a soft click noise is heard.
The Air inlet filter cover is held in place by a magnet. In order to remove it, hold the handle firmly and
gently pull the filter cover downward.
Maintenance
Click
06
The table is complied in accordance to SJ/T 11364 standard
O: Indicates that this hazardous substance contained in all of the homogeneous materials used for this
part is within the limit requirement in GB/T26572
X: Indicate that this hazardous substance contained in at least one of the homogeneous materials used
for this part exceed the limit requirement in GB/T26572
(1): Hazardous substance contained is exempted under EU RoHS directives exemption list(2011/65/EU)
Meaning within 10 years of use, this product could be considered environmental friendly.
Hazardous Materials
Component
Lead
(Pb)
Mercury
(Hg)
Cadmium
Cd
Hexavalent
chromium
(Cr(VI))
Polybrominated
biphenyl
(PBB)
Polybrominated
diphenyl ethers
(PBDE)
Plas�c part O O O O O O
Metal part O O O O O O
Heater Matrix
×
(1)
O O O O O
Motor Assembly
×
(1)
O O O O O
Circuit Controller
Component
×
(1)
O O O O O
Wire&Cable O O O O O O
Assessories O O O O O O
07
Troubleshooting
Errors Diagnostics Solutions
Blue light ring flicker warning
Inner components
overheat
Turn off and restart after 1
min,if it does not work,
send back for repair
Yellow light ring flicker warning
Inner components
damaged
Send back for repair
Red light ring flicker warning
Air inlet or outlet blocked Clean air inlet and outlet
Protection programme
is started
Do not turn on and off
continuously or repeatedly
Input Voltage Error
Check the electricity supply
voltage
No lig
ht indication
Power not connected Check wire and plug
Function
when turn on
Light ring PCB damaged
Send back for repair
No reaction when pressing
hot wind button
Hot air button damaged
Heater gets red Controller PCB damaged
Wire or plug overheat
wire damaged or
plug loose
Smelled burnt when working
Inner components
damaged
Does not function
when turn on
08
30-Day Unconditional Return Service
Laifen offers 30 days unconditional return service. Within 30 days since the date of purchase, you can
contact us to return your hair dryer and to be refunded.
To be eligible for a refund, you must:
Return the hair dryer with all accessories and gifts.
Return them in their original packaging.
Provide valid proof of purchase.
Ensure the hair dryer and accessories are resalable.
Returns shipping costs：
Returns for reason of product quality issue, Laifen will carry the shipping costs.
Returns for any reason other than product quality issue, the buyer should carry the shipping costs.
Returns for any reason other than product quality issue, buyers should assume responsiblity for any damage or
loss incurred in transport.
Return Policy
09
This appliance is for household use and is not intended for business purposes.
Using this appliance for professional or commercial purposes, or outside of “normal use” will invalidate
the guarantee.
Outside of “normal use” means more than two hours per day.
Note:
Laifen 2-year guarantee
Laifen provides 2-year guarantee for your hair dryer. In 2 years since the date of purchase, if your hair
dryer cannot work due to the defects of materials or workmanship, we will repair or replace it for you.
Following situations are not covered:
Purchase from unauthorized resellers.
Warranty period is expired.
Without proof of purchase.
The hair dryer has been modified, altered or repaired unofficially.
Use the hair dryer for any other purpose than drying hair.
Damage caused by operations which are not in accordance with Laifen user manual.
Damage caused by any misuse or accident.
Damage caused by excessive usage considered as normal wear and tear.
Warranty
