BH72 & BH72 Lite
Bluetooth Headset
Quick Start Guide
V1.0
English /
简体中文
Package List
Note: We recommend that you use the included accessories, and other accessories may have
compatibility issues that prevent them from working properly.
BH72 BH72 Lite
USB 2.0 Cable
(USB-A to USB-C)
Storage Bag
Quick Start Guide
BT51-A Dongle or
BT51-C Dongle
BHC76 Wireless
Charging Stand
Power Adapter
Optional
Q
u
i
c
k
S
t
a
r
t
G
u
i
d
e
or
L
Charging
USB Charging
Wireless Charging (optional)
LED Indicator Status
Note: It takes two hours for USB charging and three hours for wireless charging to be fully
charged.
Note:
• Werecommendtofullychargetheheadsetwhenusingitforthe�rsttime.BH72Litedoes
not support wireless charging.
• The BHC76 is compatible with devices that support QI wireless charging, such as wireless
charging mobile phones and headsets.
Red
Charging
Green
Fully Charged
Green
Align
Power on/off
"power on,
remaining talk
time XX hours"
"power off"
Red
Green
Hold 2s
Power on
Power off
LED Indicator
Yealink BH72
Note: If your desk phone/PC does not have built-in Bluetooth, you need to use the BT51 dongle
to pair the headset. When the BT51 dongle is plugged into the desk phone/PC and the headset
is power on, the desk phone/PC and BT51 dongle will automatically connect.
Pairing and Connecting Device
Step1: Enter Pairing Mode
"pairing mode"
Power off State
Power on State
Step2: Select the Headset from Your Bluetooth Device
Hold 5s
"power on,
remaining talk
time XX hours.
pairing mode"
Hold
3s
ON
"mobile one
connected"
Flashing Red and Green Alternately
Flashing Red and Green Alternately
Flash Red
Trying to Connect to
Teams
Connect to Teams
Successfully
Solid Red
Flash Purple
Solid Purple
Talking
Incoming Call
Busylight
Call Controls and Busylight
Press
1X
Accept
End
Reject
or
Push
Mute
or
Note: Only the Teams edition can connect to Teams.
Pull
Multi-function Button
Press
1X
Press
2X
Press
1X
Multi-function
Button
Music Controls
Customers Button
Hold
Press
1X
"remaining talk
time XX hours.
PC connected,mobile
one connected"
1.5s
Hold
1.5s
Press
1X
Press
1X
OpenTeamsNoti�cation
Hold
2s
Siri, Google assistant...,
depending on mobile phone.
Press
1X
Activate Voice Assistant
Check the Battery and
Device Connection Status
Press
1X
Yealink USB Connect
(
PC
Yealink Connect App (Mobile
Download it from the Yealink website https://www.yealink.com/product/yuc.
Apple and the Apple logo are trademarks of Apple Inc.
Download the Yealink Connect App from IOS App Store or Android App Store.
Replace Ear Cushions
Software Management
1. Pleaseusethe power adapter providedbyYealink togetamore ef�cient charging
experience.
2. Please do not place any metal and magnetic cards on the charging board to avoid
abnormalities and damage to the charger.
3. Please do not charge too far away from the charging sign to get a more efficient
charging experience.
4. Duringuse,ifyou�ndthechargingboardorthechargeddeviceisoverheatedandthe
charging stops(theindicatorlightkeepsashing),youneedtoremovethecharged
device until it cools down, and then try charging again.
5. Theindicatorlightofthe chargingstandkeepsashing, anditmaybe thefollowing
three situations:
• The location of the charged device is not placed correctly. You need to replace the it.
After calibrating the charging position, you can charge the device normally until the
indicator light is always on.
• The charging stand has an overheating alarm. After the mobile phone or the charging
stand coolsdown,itwillstop ashingautomaticallyand enter thenormalcharging
state.
• Metal or magnetic cards may be placed on the charging board, and please remove
them.
Notes for BHC76 (optional)
Safety Guide for BHC76 (optional)
1. Donotdisassembletheproductbyyourselforbringitnear�reandwatertoavoid
short circuit leakage or damage to the product.
2. Do not use the product in high temperature, humidity, and corrosive environment to
avoid damaging the circuit and causing failure to charge or other failures.
3. Do not expose the product to corrosive liquids. Otherwise, it will cause severe damage.
4. Do not disassemble or re-equip the product for any reason to avoid secondary failure
and burnout.
5. Do not place the product below -10°C or above 60°C.
6. Do not knock, throw or shake the product because rough methods will damage the
internal circuit board structure.
About Yealink
Yealink (Stock Code: 300628) is a global brand that specializes in video conferencing,
voice communications and collaboration solutions with best-in-class quality, innovative
technology and user-friendly experience. As one of the best providers in more than
140 countries and regions, Yealink ranks No.1 in the global market share of SIP phone
shipments (Global IP Desktop Phone Growth Excellence Leadership Award Report, Frost
& Sullivan, 2019).
Copyright
Copyright © 2021 YEALINK(XIAMEN) NETWORK TECHNOLOGY CO., LTD.
All rights reserved. No parts of this publication may be reproduced or transmitted in any
form or by any means, electronic or mechanical, photocopying, recording, or otherwise,
for any purpose, without the express written permission of Yealink(Xiamen) Network
Technology CO., LTD.
Technical Support
Visit Yealink WIKI (http://support.yealink.com/) for firmware downloads, pr oduct
documents, FAQ, and more. For better service, we sincerely recommend you to use
Yealink Ticketing system (https://ticket.yealink.com) to submit all your technical issues.
YEALINK(XIAMEN) NETWORK TECHNOLOGY CO.,LTD.
Web: www.yealink.com
Addr: No.1 Ling-Xia North Road, High Tech Park,
Huli District, Xiamen, Fujian, P.R.C
Copyright©2021 Yealink Inc. All rights reserved.
