Models:
SU5KRT3UHV, SU5KRT3UHVP, SU5KRT3UX, SU5KRT3UG, SU5KRT3UHW,
SU6KRT3UHV, SU6KRT3UHVP, SU6KRT3UX, SU6KRT3UG, SU6KRT3UHW
(Series Number: AG-0358)
1
Owner’s Manual
SmartOnline
®
Single-Phase Rack-Mount Online UPS
with Built-in LCD Monitoring & Control Screen
Not suitable for mobile applications.
1. Overview 2
Parts List 2
Additional Accessory Options 2
2. Important Safety Instructions 2
3. UPS Circuit Block Diagram 5
4. Installation 6
Internal Battery Rotation 6
Rack Mounting 8
Tower Mounting 9
Hardwire Input and Output 10
Wiring Instructions
(Optional with Select Models)
UPS Input and Output Overview 11
5. Features 11
Front Panel Controls, LEDs and 11
LCD Screen
Rear Panel Features 12
6. Operations 14
LCD Front Panel Display and Controls 14
LED Front Panel Indicators 14
Front Panel Button Functions 15
Home Screen Layout 15
Basic Connection and Start-Up 16
Power Strategy Selection Options 19
Front Panel LCD Selection and 21
Configuration Options
Configuring External Battery Packs 24
7. Optional Connections 25
8. Troubleshooting and Event Log 28
9. Internal Battery Replacement 30
10. Fan Replacement 32
11. Storage and Service 33
12. Warranty and Product Registration 33
Español 35
Français 69
Русский
103
NOTE: External battery pack options require configuration using front panel LCD interface or via Tripp Lite’s EXTERNAL BATTERY CONFIGURATION software.
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2022 Tripp Lite. All rights reserved. SmartOnline
®
is a trademark of Tripp Lite. For latest updates, please visit tripplite.com
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
