Countertop Stainless-Steel
Faucet Filtration System
WD-FC-06
OWNER'S MANUAL
About the System
Thanks for choosing Stainless-Steel Faucet Water Filtration System.
This faucet filtration system uses activated carbon block to give you clean and healthy
water.The system is made of 304 food-grade stainless steel to ensure guaranteed
quality and durability. Each filter can provide you with 320 gallons of clean water.
NOTE: There may be a small amount of black water during the first use.This is a normal
phenomenon because of the activated carbon.Feel free to use the water after it
becomes clear.
Use Method
1. Switch the lever to the downward direction to get tap water. [Fiqure 1.3]
2. Switch the lever to the level direction to get pure water. [Figure 1.4]
NOTE:
1.Before the first use, run cold water for 3 minutes in the "pure water" position.Do not
run water at a temperature higher than 100˚F/38˚C.There may be a small amount of
black water and the sound of water pushing air out of the filter during the first use.This
is a normal phenomenon because of the active carbon.Feel free to use the water after
it becomes clear.
2. Check for water leakage.In the event of leakage, refer to the FAQ or contact customer
service.
Installation Instructions
1. Take out the filter (A) and remove the package.
2. Take out the system and adapters (A3/A5) and twist off the filter base (D) anticlock-
wise.Keep the water outlet hole of the filter downward and put the filter on the filter
base (D). Twist on the filter base (D) clockwise.
[Figure 1.1]
How to Choose the Right Adapter
(1). For external threaded faucets, please connect the Outlet valve(C) to the
faucets.
(2). For internal threaded faucets, select the appropriate adapter (A3/A5)
according to the thread size.Use a coin to connect it to the Outlet valve(C).Then
connect the adapter to the faucet.
If you still cannot connect it properly, please contact customer service to get
another adapter.
3. Remove the aerator of the faucet and choose the right adapter to match your faucet
threading.Make sure the washer between the faucet and the system is installed firmly.
Parts List
Figure 1.1
Figure 1.2
Figure 1.3 Figure 1.4
4. Switch the lever to the level position and run water to
the system slightly. Flush it for 3 minutes during the first
use.
[Figure 1.2]
Tips: If there is water leakage at the connecting position
between the faucet and the system, it is recommended to
use a wrench to assist in tightening the nut on (C), or use
the Teflon tape inside the instruction package to avoid
leakage.
System Specifications
To achieve optimal performance, it is recommended to use the system within the
system specifications.
System Model No. -------------------------------------------------------------------------- WD-FC-06
Replacement Model No. ---------------------------------------------------------------- WD-FF-03A
Rated Capacity ----------------------------------------------------------- 3 months or 320 gallons
Rated Flow ----------------------------------------------------------------------------- 0.5 gpm/2 lpm
Operating Temperature-----------------------------------------------------------41-100˚F/5-38˚C
Operating Working Pressure-------------------------------------------15-100 psi/100-689 kPa
NOTE: Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after the system.
A
B
C
D
E
F
G
A3 A5
(A) Activated carbon block filter
(B) Filter top cover
(C) Outlet Valve
(D) Filter base
(E) Connector
(F) Sealing ring
(G) A3 adapter ( 15/16-27)
A5 adapter (M18.5)
Tap Water
Pure Water
Three Minutes
Filter Cartridge Replacement
For optimum performance, it is highly recommended you use genuine Waterdrop
faucet replacement water filter. And it is also advisable to change your filter every 3
months or 320 gallons to keep water fresh, whichever comes first. This will vary based
on water usage and water quality.
1. Twist off the filter base (D) and
remove the expired filter.
3. Twist the filter base (D) with
the filter top cover (B).
4. Switch the lever to the level position
and flush for 3 minutes.
2. Take out the new filter and press
the new filter into the filter base (D)
Ensure that the sealing ring under
the filter is in place.
Warnings
1.Do not use with water above 100˚F/38˚C.
2.Flush the system for 5-10s before use.If the system has not been used for over 24
hours, run water for 30s before use.
3.Flush the system for 3 minutes before the first use.There may be a small amount of
black water during the first use.This is a normal phenomenon because of the active
carbon.Feel free to use the water after it becomes clear.
4.Avoid water entering the filtration system from the outlet or touching the outlet of
the system.
5.Protect the filter system from freezing temperatures, frost, snow, sleet, and ice.
6.Clean the exterior of the system with a soft cloth to maintain its appearance and
service life.
7.Replace the filter every 3 months or 320 gallons for best filtration performance.
Frequently Asked Questions
Q: Why does the filtered water run slowly?
A: The water pressure is too low or the filter is clogged.Please check on whether the
water pressure of the pipeline is normal.
Q: Why does the TDS value not lower after filtration?
A: TDS stands for total dissolved solids.It is composed of inorganic salts and a small
amount of organic matter.This filter cannot lower the TDS value because it removes
harmful substances while keeping beneficial trace elements, which can increase the
TDS value.
Q: Why does water leak between the mounting base and the faucet?
A: Remove the filtration system from the faucet and check on whether the sealing
gasket at the connection is placed correctly.Ensure that the thread between the faucet
and the filtration system is screwed in firmly so that the sealing gasket can work.
Q: Why can't the filtration system connect to the kitchen faucet?
A: There are three connection methods (including two additional adapters).If the
system still cannot be connected properly, contact customer service to get another
adapter.
Limited Warranty
The Waterdrop Activated Carbon Block Faucet Filtration System ( Model No.: WD-FC-06)
offers 1-year warranty, which covers defects in materials and workmanshop from
original date of purchase. If the products proves to be defective within 1 year from the
date of purchase, please call our technical support hotline.
During the warranty period, we will replace or repair any part which is deemed to be
defective, if product has not been subjected to tampering, alteration or improper use
after delivery, and has not been repaired by the manufacturer. The product is not
warranted against misuse, use in abbormal operation temperature conditions,
conditions outside listed operating parameter, sue in commercial operations or any
other manner outside the “System Specifications” set forth in the owner’s manual. Our
obligation does not include the cost of transportation. We are not responsible for
damage in transit, and claims for such damage should be presented to the carrier by
the customer.
NOTE: It does NOT apply to any filter cartridge, which has a life expectancy that varies
based on incoming water quality.
Made in China V010
Manufacturer Technical Support:
Qingdao Ecopure Filter Co., Ltd.
1-888-352-3558 (U.S.) Mon-Fri 8:00AM-5:00PM (PST)
If you encounter any problem with our product, please contact us
to get support via the purchase channel.
