Please read before using equipment.
Required tools (not included):
pencil
Be sure the mounting surface is
between 3/8” (9.5mm) and 1 1/4”
(31mm) thick, with at least a 2 3/4”
(69mm) clearance behind the
mounting surface, so that no wall
studs or other objects block the
back of the speaker.
If you choose to paint the frame and
grille, we recommend using spray paint.
Make sure to let the paint dry before
connecting the speaker wire or
mounting the speaker.
To remove the grille for painting, use the
grille remover or insert a paper clip into one
of the grille openings and then pull up.
Or, you can carefully twist the plastic frame
back and forth until the grille edge becomes
exposed. Then lift out the grille.
The red (+) terminal on the speaker
should connect to a (+) channel on
your audio equipment and the
black (-) terminal on the speaker should
connect to the same channel (-) terminal
on your audio equipment.
Remove the grille to expose the
Turn the four screws to tighten the
over-tighten the screws.
14 - 18 gauge speaker wire
speaker from the audio equipment.
Separate about 4” (101mm) of speaker
wire at each end.
1/4” (6mm) of insulation from each wire.
INSTALLATION INSTRUCTIONS
Do not nail or staple through speaker wire.
recommend you spray paint the grille so paint
PREPARING THE LOCATION
PREPARING THE SPEAKER
entering the speaker, remove the grille
paint mask and replace the grille.
prevent the loss of the mounting tabs.
2-Way Wall Speaker
