PX360-ES-1A
EN/ES
Safety Precautions
Before trying to use the Digital Piano, be sure to
read the separate “Safety Precautions”.
Precauciones de seguridad
Antes de intentar usar el piano digital, asegúrese
de leer las “Precauciones de seguridad” separadas.
USER’S GUIDE
GUÍA DEL USUARIO
Please keep all information for future reference.
Guarde toda información para tener como referencia futura.
EnglishEspañol
PX
-
360M
This recycle mark indicates that the packaging conforms to
the environmental protection legislation in Germany.
Esta marca de reciclaje indica que el empaquetado se
ajusta a la legislación de protección ambiental en Alemania.
MA1504-A Printed in China
C
PX360-ES-1A.indd 1 2015/04/24 12:46:39
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important!
Please note the following important information before using this product.
• Before using the AD-A12150LW Adaptor to power the product, be sure to check the AC Adaptor for any damage first. Carefully check the
power cord for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is seriously damaged.
• The product is not intended for children under 3 years.
• Use only the CASIO AD-A12150LW adaptor.
• The AC adaptor is not a toy.
• Be sure to disconnect the AC adaptor before cleaning the product.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
The P (POWER) indicator being unlit does not mean the apparatus is completely disconnected from the MAINS.
When you need to have the apparatus completely disconnected from the MAINS, you must unplug the power cord. For that purpose, locate
the apparatus in a way that secures easy access to the power cord.
Declaration of Conformity
Model Number: PX-360M
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
Casio Europe GmbH
Casio-Platz 1, 22848 Norderstedt, Germany
www.casio-europe.com
Declaration of Conformity According to EU Directive
EN-1
PX360-ES-1A.indd 3 2015/04/24 12:46:39
EN-2
Contents
General Guide EN-4
Installing the Music Stand . . . . . . . . . . . . . . . . . EN-5
Saving Settings and Using Panel Lock . . . . . . . EN-6
Returning the Digital Piano to Its Factory
Default Settings . . . . . . . . . . . . . . . . . . . . . . . EN-6
Power Outlet EN-7
Using an AC Adaptor . . . . . . . . . . . . . . . . . . . . EN-7
Turning Power On or Off. . . . . . . . . . . . . . . . . . EN-7
Connections EN-8
Connecting Headphones. . . . . . . . . . . . . . . . . . EN-8
Connecting a Pedal. . . . . . . . . . . . . . . . . . . . . . EN-8
Connecting Audio Equipment or an Amplifier . . EN-9
Bundled and Optional Accessories . . . . . . . . . EN-10
Operations Common to All Modes EN-11
Using the Display Screen . . . . . . . . . . . . . . . . EN-11
Performing Operations . . . . . . . . . . . . . . . . . . EN-12
Playing with Different Tones EN-14
Selecting and Playing a Tone . . . . . . . . . . . . . EN-14
Splitting the Keyboard between Two Tones . . EN-15
Layering Two Tones . . . . . . . . . . . . . . . . . . . . EN-16
Splitting the Keyboard for Duet Play . . . . . . . . EN-16
Adjusting the Keyboard Volume Balance . . . . EN-17
Using the Metronome . . . . . . . . . . . . . . . . . . . EN-18
Changing the Tempo Setting . . . . . . . . . . . . . EN-18
Using the Pitch Bend Wheel . . . . . . . . . . . . . . EN-19
Shifting the Pitch of the Digital Piano in
Semitone Units (Transpose) . . . . . . . . . . . . EN-19
Using Auto Accompaniment EN-20
Playing an Auto Accompaniment . . . . . . . . . . EN-20
Using Recommended Tones and Tempos
(One-Touch Presets) . . . . . . . . . . . . . . . . . . EN-23
Adding Harmony to Melody Notes
(Auto Harmonize). . . . . . . . . . . . . . . . . . . . . EN-24
Creating Your Own Original Rhythm by
Editing a Built-in Auto Accompaniment
(Rhythm Edit) . . . . . . . . . . . . . . . . . . . . . . . . EN-24
Deleting a User Rhythm . . . . . . . . . . . . . . . . . EN-26
Demo Song EN-27
Playing the Demo Tunes. . . . . . . . . . . . . . . . . EN-27
Music Presets EN-28
Recalling Preset Data . . . . . . . . . . . . . . . . . . . EN-28
Creating an Original User Preset
(User Presets) . . . . . . . . . . . . . . . . . . . . . . . EN-29
Deleting a User Preset . . . . . . . . . . . . . . . . . . EN-33
Registering Tone and
Rhythm Setups EN-34
Recording and Playback EN-36
Recording to Digital Piano Memory
(MIDI Recorder) . . . . . . . . . . . . . . . . . . . . . . EN-38
Recording to a USB Flash Drive
(Audio Recorder) . . . . . . . . . . . . . . . . . . . . . EN-45
Configuring Digital Piano Settings EN-48
Configuring Digital Piano Settings. . . . . . . . . . EN-48
USB Flash Drive EN-56
Connecting a USB Flash Drive to and
Detaching It from the Digital Piano. . . . . . . . EN-57
Formatting a USB Flash Drive . . . . . . . . . . . . EN-57
Saving Standard Song Data to a
USB Flash Drive. . . . . . . . . . . . . . . . . . . . . . EN-57
Saving Digital Piano Data to a
USB Flash Drive. . . . . . . . . . . . . . . . . . . . . . EN-58
Loading Data from a USB Flash Drive to
Digital Piano Memory. . . . . . . . . . . . . . . . . . EN-58
Deleting Data from a USB Flash Drive . . . . . . EN-59
Connecting to a Computer EN-60
Minimum Computer System Requirements . . EN-60
Using MIDI . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-61
Reference EN-62
Error Messages. . . . . . . . . . . . . . . . . . . . . . . . EN-62
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . EN-63
Product Specifications. . . . . . . . . . . . . . . . . . . EN-65
Operating Precautions . . . . . . . . . . . . . . . . . . EN-67
PX360-ES-1A.indd 4 2015/04/24 12:46:39
Contents
EN-3
English
Appendix A-1
Tone List ..............................................................A-1
Drum Assignment List ..........................................A-6
Rhythm List ..........................................................A-8
Music Preset List................................................A-10
Fingering Guide..................................................A-12
Parameter List....................................................A-14
Chord Example List............................................A-15
Part and MIDI Channel Assignments.................A-17
MIDI Implementation Chart
Company and product names used in this
manual may be registered trademarks of others.
PX360-ES-1A.indd 5 2015/04/24 12:46:39
EN-4
General Guide
co cp cq cr cs ct
bt ck cm cn
br
dk
2
bo
bp
bq
7 8 9 bk bl bm
bs
531 4
bndl
∗
6
cl
Bottom
Back
PHONES jacks
Front
AUDIO VOLUME controller
LINE OUT R, L/MONO jacks
Pedal connector
MIDI OUT/THRU, IN
terminals
USB port
DAMPER, ASSIGNABLE PEDAL jacks
AUDIO IN jacks
DC 12V terminal
LINE IN R, L/MONO jacks
PX360-ES-1A.indd 6 2015/04/24 12:46:40
General Guide
EN-5
English
• This manual uses the numbers and names below to refer to buttons and controllers.
Insert the bottom of the music stand into the
groove on the top of the Digital Piano’s
console.
* Installing the Music Stand
1P (Power) button
2VOLUME controller
3REC MODE button
4MIDI a button
5AUDIO a button
6TRANSPOSE w, q button
7INTRO button
8NORMAL/FILL-IN button
9VARIATION/FILL-IN button
bkSYNCHRO/ENDING button
bla button
bmACCOMP ON/OFF button
bnDisplay
boMENU
bpMAIN
bqEXIT
brDial
bsw/NO, q/YES buttons
btTONE button
ckRHYTHM button
clTEMPO buttons
cmMETRONOME button
cnGRAND PIANO button
coBANK button
cpREGISTRATION 1 button
cqREGISTRATION 2 button
crREGISTRATION 3 button
csREGISTRATION 4 button
ctSTORE button
dkUSB flash drive port
dlPITCH BEND wheel
PX360-ES-1A.indd 7 2015/04/24 12:46:40
EN-6
General Guide
Your Digital Piano lets you save its current settings,
and lock its buttons to protect against operation errors.
For details, see “Auto Resume” (page EN-53) and
“Operation Lock” (page EN-52).
Perform the following procedure when you want to
return the Digital Piano’s stored data and settings to
their initial factory defaults.
1.
Turn off the Digital Piano.
2.
While holding down the cl TEMPO w, q
buttons, press the 1 P button.
• The Digital Piano will turn on and initialize its
internal system. You will be able to use the Digital
Piano in a short while.
• See “Turning Power On or Off” (page EN-7) for
information about turning power on and off.
Saving Settings and Using
Panel Lock
Returning the Digital Piano to
Its Factory Default Settings
PX360-ES-1A.indd 8 2015/04/24 12:46:40
EN-7
English
Power Outlet
Your Digital Piano runs on standard household power.
Be sure to turn off power whenever you are not using
the Digital Piano.
Use only the AC adaptor (JEITA Standard, with unified
polarity plug) that comes with this Digital Piano. Use
of a different type of AC adaptor can cause
malfunction of the Digital Piano.
Specified AC Adaptor: AD-A12150LW
• Use the supplied power cord to connect the AC
adaptor as shown in the illustration below.
Note the following important precautions to avoid
damage to the power cord.
During Use
• Never pull on the cord with excessive force.
• Never repeatedly pull on the cord.
• Never twist the cord at the base of the plug or
connector.
During Movement
• Before moving the Digital Piano, be sure to unplug
the AC adaptor from the power outlet.
During Storage
• Loop and bundle the power cord, but never wind it
around the AC adaptor.
• Never connect the AC adaptor (JEITA Standard,
with unified polarity plug) that comes with this Digital
Piano to any other device besides this Digital Piano.
Doing so creates the risk of malfunction.
• Make sure the Digital Piano is turned off before
plugging in or unplugging the AC adaptor.
• The AC adaptor will become warm to the touch after
very long use. This is normal and does not indicate
malfunction.
• Use the AC adaptor so its label surface is pointed
downwards. The AC adaptor becomes prone to
emitting electromagnetic waves when the label
surface is facing upwards.
1.
Press the 1 P button to turn on power.
• Do not touch the keyboard, pedals, or buttons while
the startup screen is on the display. Doing so will
cause malfunction.
• Use the Digital Piano’s VOLUME controller (2) to
adjust the volume.
2.
To turn off the Digital Piano, hold down the
1 P button until the Digital Piano’s display
goes blank.
• Pressing the 1 P button to turn off power actually
puts the Digital Piano into a standby state. Minute
amounts of current continue to flow within the
Digital Piano in the standby state. If you do not plan
to use the Digital Piano for a long time or if there is a
lightning storm in your area, be sure to unplug the
AC adaptor from the power outlet.
This Digital Piano is designed to turn off automatically
to avoid wasting power after no operation is
performed for a preset amount of time. The Auto
Power Off trigger time is about four hours.
• You can disable Auto Power Off, if you want. For
details, see “Auto Power Off” under “SYSTEM
SETTING Screen” (page EN-52).
Using an AC Adaptor
Household power outlet
Power cord
DC 12V terminal AC adaptor
• Configuration and type depends
on your geographic location.
Turning Power On or Off
Auto Power Off
PX360-ES-1A.indd 9 2015/04/24 12:46:40
EN-8
Connections
• Before connecting headphones, be sure to use the
Digital Piano’s 2 VOLUME controller to turn the
volume down to a low level. After connecting, you
can adjust the volume to the level you want.
• While sound output from the speakers is disabled,*
the Digital Piano automatically optimizes sound for
headphones and LINE OUT listening. During
speaker output, it automatically switches to
optimization for listening with speakers.
* Plug inserted into the PHONES jack or “Speaker”
SYSTEM SETTING Screen (page EN-52) turned
off.
Front
Connect commercially available headphones to the
PHONES jacks. Connecting headphones to either of
the PHONES jacks cuts off output to the speakers,
which means you can practice even late at night
without bothering others. To protect your hearing,
make sure that you do not set the volume level too high
when using headphones.
• Be sure to push the headphones plug into the
PHONES jacks as far as it will go. If you don’t, you
may hear sound from only one side of the
headphones.
• If the plug of the headphones you are using does not
match the PHONES jacks, use the applicable
commercially available adaptor plug.
• If you are using headphones that require an adaptor
plug, make sure you do not leave the adaptor
plugged in when you unplug the headphones. If you
do, nothing will sound from the speakers when you
play.
The back of the Digital Piano has two pedal jacks, one
for a damper pedal and one for a soft/sostenuto pedal.
Depending on the type of operation you want the
pedal (SP-3) to perform, connect the pedal’s cable
either to the Digital Piano’s DAMPER PEDAL jack or
ASSIGNABLE PEDAL jack. If you want to use both
operations (jacks) at the same time, you need to
purchase another optionally available pedal.
Back
Pedal Functions
z Damper Pedal
Pressing the damper pedal while playing will cause the
notes you play to reverberate.
• Whenever a piano tone is selected, pressing this
pedal will activate the Digital Piano’s Damper
Resonance effect, which causes notes to resonate in
the same way they do when the damper pedal on an
acoustic piano is pressed.
z
Soft Pedal
Pressing this pedal suppresses notes played on the
keyboard after the pedal was pressed, and makes them
sound softer.
z
Sostenuto Pedal
Only the notes of the keys that are depressed when this
pedal is pressed are sustained, even if the keyboard
keys are released, until the pedal is released.
Connecting Headphones
PHONES jacks
Commercially available
headphones
Connecting a Pedal
To connect to the pedal jack
PEDAL jacks
SP-3
PX360-ES-1A.indd 10 2015/04/24 12:46:40
Connections
EN-9
English
You can connect the optionally available 3-Pedal Unit
(SP-33) to the pedal connector on the bottom of the
Digital Piano. You can then use the pedals for
expression that is similar to that available on an
acoustic piano.
• The optionally available CS-67P special stand is
required in order to use the SP-33 Pedal Unit.
You can connect audio equipment or a music amplifier
to the Digital Piano and then play through external
speakers for more powerful volume and better sound
quality.
• While sound output from the speakers is disabled,*
the Digital Piano automatically optimizes sound for
headphones and LINE OUT listening. During
speaker output, it automatically switches to
optimization for listening with speakers.
* Plug inserted into the PHONES jack or “Speaker”
SYSTEM SETTING Screen (page EN-52) turned
off.
• Whenever connecting a device to the Digital Piano,
first use the VOLUME controller to set the volume to
a low level. After connecting, you can adjust the
volume to the level you want.
• Whenever you connect any device to the Digital
Piano, be sure to read the user documentation that
comes with the device.
Pedal Connector
Pedal connector
Bottom
Connecting Audio Equipment
or an Amplifier
INPUT 1
INPUT 2
4
1
3
2
Guitar amplifier
Keyboard amplifier, etc.
Standard plug
Standard
jack
LEFT (White)
RIGHT (Red)
MIDI sound source, etc.
Pin plug
Audio amplifier
AUX IN jack, etc.
Smartphone, etc.
Stereo mini plug
PX360-ES-1A.indd 11 2015/04/24 12:46:41
EN-10
Connections
An external source connected to LINE IN R (right) is
output from the Digital Piano’s right speaker, while a
source connected to LINE IN L/MONO is output from
the left speaker. Use commercially available connection
cords that match the equipment being connected to.
When an external source is connected to LINE IN L/
MONO only, the input is output from both speakers.
You can connect a smartphone or other music player to
AUDIO IN.
Use the AUDIO VOLUME knob to adjust the volume
level from the music player.
• Digital Piano built-in effects (reverb, chorus, DSP)
are also applied to LINE IN terminal input. LINE IN
input can be recorded with the Audio Recorder.
• Digital Piano built-in effects (reverb, chorus, DSP)
are not applied to AUDIO IN terminal input.
AUDIO IN input cannot be recorded with the
Audio Recorder.
Use commercially available cables to connect the
external audio equipment to the Digital Piano’s
LINE OUT jacks as shown in Figure
2
. LINE OUT R
jack output is right channel sound, while LINE OUT
L/MONO jack output is left channel sound. It is up to
you to purchase connecting cables like the ones shown
in the illustration for connection of audio equipment.
Normally in this configuration you must set the audio
equipment’s input selector to the setting that specifies
the terminal (such as AUX IN) to which the Digital
Piano is connected. Use the Digital Piano’s VOLUME
controller to adjust the volume level.
Use commercially available cables to connect the
amplifier to the Digital Piano’s LINE OUT jacks as
shown in Figure
3
. LINE OUT R jack output is right
channel sound, while LINE OUT L/MONO jack
output is left channel sound. Connecting to the
LINE OUT L/MONO jack only outputs a mixture of
both channels. It is up to you to purchase a connecting
cable like the one shown in the illustration for
connection of the amplifier. Use the Digital Piano’s
VOLUME controller to adjust the volume level.
• When using the LINE OUT jacks, also connect
headphones to the PHONES jacks. This will switch
the LINE OUT output to appropriate sound quality.
Use only accessories that are specified for use with this
Digital Piano.
Use of unauthorized accessories creates the risk of fire,
electric shock, and personal injury.
• You can get information about accessories that are
sold separately for this product from the CASIO
catalog available from your retailer, and from the
CASIO website at the following URL.
http://world.casio.com/
Using the Digital Piano to Produce
Sounds from an External Source
(Figures
1
and
4
)
Connecting to Audio Equipment
(Figure
2
)
Connecting to a Musical Instrument
Amplifier (Figure
3
)
Bundled and Optional
Accessories
PX360-ES-1A.indd 12 2015/04/24 12:46:41
EN-11
English
Operations Common to All Modes
When you turn on the Digital Piano, a MENU screen
and a MAIN screen (which shows the current setup)
appear on the display. You can use these screens to
configure a variety of different functions. A quick
palette of navigation icons along the right side of the
display are for navigating between screens.
■ MENU screen
Touching a menu icon displays a screen for configuring
tone, rhythm, and other settings.
■ MAIN screen
The MAIN screen is for checking and modifying main
settings. Current settings are shown along the bottom
of the screen.
1
USB flash drive mounted
2
Speakers off
3
Chord
4
Tempo
5
Measure
6
Beat
7
Transpose
8
Split point
9
Registration bank
■ Quick Palette
The Quick Palette is always displayed along the right
side of the screen. Touch the Quick Palette icons to
navigate between screens.
You can tell the currently selected items and operation
enabled icons by their colors;
Red: Currently selected or turned on
Blue: Operation enabled
Example: “Soft Rock” selected in the Rock group.
Using the Display Screen
Display Screen Layout
Displays the MAIN
screen.
Returns to the
previous screen.
Quick Palette
3 4 5 6 7 8 9
Displays the
MENU screen.
Quick Palette
21
Screen Contents
bo MENU: Displays the MENU screen.
bp MAIN: Displays the MAIN screen.
bq EXIT: Returns to a previous screen.
Goes to the next group.
Goes to the previous or next page.
PX360-ES-1A.indd 13 2015/04/24 12:46:41
EN-12
Operations Common to All Modes
Your Digital Piano has a touch panel. You can use the
touch panel to configure a variety of different
functions.
• Do not perform touch panel operations with a sharp
or hard pointed object. Doing so can damage the
LCD.
Touch
Press the display lightly with your finger.
Swipe
Swipe the display from left to right with your finger.
Swiping a MENU screen changes to another page of
menu items.
You can touch the keys of an on-screen touch keyboard
to input data file names. The Digital Piano supports
input of alpha characters and symbols.
1
Shows the letters you input.
2
Selects the character type.
3
Moves the cursor forward and back.
4
Deletes the letter to the left at the cursor.
5
Input letters at the cursor position.
6
Inputs a space at the cursor position.
Performing Operations
To use the touch panel
To input text characters
1 3 4
65
2
PX360-ES-1A.indd 14 2015/04/24 12:46:41
Operations Common to All Modes
EN-13
English
An item that can be selected using a list is indicated by
the “X” icon.
1.
Touch the item whose setting you want to
change.
2.
On the list that appears, touch the item to
which you want to change.
A setting value that can be changed is indicated by a
“ ” icon.
1.
Touch the item whose setting you want to
change.
2.
Use the br Dial or the bs w, q buttons to
change setting value.
• Holding down either of the bs w, q buttons
scrolls through values at high speed.
To toggle a function between on or off, touch its item or
icon.
To select an item in a list To change a setting value
To toggle a function on or off
PX360-ES-1A.indd 15 2015/04/24 12:46:41
EN-14
Playing with Different Tones
Your Digital Piano has 550 tones. Tones are divided
into 12 groups.
• For more information, see the “Tone List” (page
A-1).
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Touch the “Upper 1” tone.
This displays the TONE SELECT screen.
3.
Touch the group that contains the tone you
want to use.
• You can navigate between groups by touching “UU“
or “II”.
4.
Touch the tone you want to use.
• You can navigate between tone list pages by touching
“ ” or “ ”.
5.
On the screen, touch bp MAIN to return to
the MAIN screen.
• Touching the Upper 1 icon to turn it off will deselect
the keyboard tone so nothing will sound on the
keyboard.
• Pressing the cn GRAND PIANO button will switch
to the grand piano tone and reconfigure Digital
Piano settings so they are optimized for grand piano
play. For details about these settings, see “Parameter
List” (page A-14).
bp
cn
bs
cmcl6
Selecting and Playing a Tone
Upper 1
PX360-ES-1A.indd 16 2015/04/24 12:46:41
Playing with Different Tones
EN-15
English
You can split the keyboard so the left side (lower
range) plays one tone and the right side (upper range)
plays a different tone.
• On a split keyboard, a tone assigned to the low range
is called a “split tone” (Lower 1).
Example: When “GM Slap Bass 1” is selected as the split
tone
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Select the main tone.
3.
On the MAIN screen, touch “Split”.
This turns on split.
4.
Touch “Lower 1”.
This displays the TONE SELECT screen.
5.
Touch the group that contains the tone you
want to use as the split tone.
6.
Touch the tone you want to use as the split
tone.
7.
On the screen, touch bp MAIN to return to
the MAIN screen.
8.
To unsplit the keyboard and return it to a
single tone, touch “Split” on the MAIN screen.
This unsplits the keyboard.
• You can layer both the main tone and the split tone
with another by turning on layer (page EN-16). You
can also configure the layer setting after turning on
the split.
• Turning off Upper 1, Upper 2, Lower 1, or Lower 2
by touching its icon will mute the applicable tone.
• When tones with DSP are assigned as both the main
tone and the split tone, the effect of one of the tones
becomes disabled.
You can use the procedure below to specify the
location on the keyboard where it splits between the
left side and the right side. That location is called the
“split point”.
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Touch “Split Point”.
3.
Use the bs w, q buttons to specify the
split point, which is the leftmost key of the
upper range.
• You can also specify the split point by touching and
holding “Split Point” as you press the desired
keyboard key.
Splitting the Keyboard
between Two Tones
Lower 1
Lower 2
Upper 1
Upper 2
Split tone:
GM Slap Bass 1
Main tone:
Grand Piano Concert
Red
To move the keyboard split point
Low Range High Range
Split Point
Red
PX360-ES-1A.indd 17 2015/04/24 12:46:42
EN-16
Playing with Different Tones
You can layer two different tones so they play at the
same time when you press a keyboard key.
• The Upper 1 tone is called the “main tone”, while
the Upper 2 tone is called the “layered tone”.
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Select the main tone.
3.
Touch the Upper 2 icon.
This turns on layer and layers the two tones.
4.
Touch the “Upper 2” tone.
This displays the TONE SELECT screen.
5.
Touch the group that contains the tone you
want to use as the layer tone.
6.
Touch the tone you want to use as the layer
tone.
7.
On the screen, touch bp MAIN to return to
the MAIN screen.
8.
To unlayer the keyboard and return to a
single tone, touch the Upper 2 icon on the
MAIN screen.
This unlayers the tones.
• You can adjust the balance between the main tone
and layered tone.
See “Adjusting the Keyboard Volume Balance”
(page EN-17).
• Touching the Upper 1 or Upper 2 icon will turn off
the applicable tone so it does not sound.
• When tones with DSP are assigned as both the main
tone and the layered tone, the effect of one of the
tones becomes disabled.
You can split the keyboard in the center for duet play
so the left and right sides have the same ranges. The
left outer pedal operates as the left side damper pedal,
while the right outer pedal is the right side damper
pedal.
The duet play can be used with the teacher showing
how to play on the left side as the student plays the
same melody on the right side.
Pedals
z Using the Optional SP-33 Pedal Unit
z
Using the Provided SP-3 Pedal Unit
For use as the right keyboard damper pedal, connect to
the DAMPER PEDAL terminal.
For use as the left keyboard damper pedal, connect to
the ASSIGNABLE PEDAL terminal.
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
Layering Two Tones
Red
Splitting the Keyboard for
Duet Play
C4 C4
Right keyboardLeft keyboard
(Middle C)(Middle C)
Left and right side damper pedal
Left keyboard
damper pedal
Right side damper pedal
(Half-pedal operation
supported)
PX360-ES-1A.indd 18 2015/04/24 12:46:42
Playing with Different Tones
EN-17
English
2.
Touch “Duet”.
This turns on duet play.
• Touch “Pan” to turn on Duet Pan. While Duet Pan is
enabled (on), the left side keyboard tone is output
from the left speaker, while the right side keyboard
tone is output from the right speaker. The effects
below are not applied.
– Acoustic Simulator (except for Hammer Response)
– Reverb
– Delay
– Chorus
– DSP
3.
To turn off duet play, touch “Duet” again.
The returns to the state in effect before you turned on
duet play.
You can use the following procedure to change the
octave of the left and right Duet Mode keyboards.
1.
Perform steps 1 and 2 of the procedure under
“Splitting the Keyboard for Duet Play”.
2.
Touch “Left Octave” and then use the bs w,
q buttons to change the octave of the left
keyboard.
Example: The illustration below shows how changing
the left octave shift setting to “+1” affects the
left keyboard octave.
3.
Touch “Right Octave” and then use the bs
w, q buttons to change the octave of the
right keyboard.
• Turning off duet play clears octave shift settings and
returns the keyboard to its initial default octave
settings.
Use this procedure to adjust the volume balance
between the main tone and the layered tone.
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Touch “BALANCE”.
3.
Touch the tone you want to adjust and then
use the bs w, q buttons to adjust volume.
Upper 1: Main tone
Upper 2: Layered tone
Lower 1: Split (main) tone
Lower 2: Split (layered) tone
4.
On the screen, touch bp MAIN to return to
the MAIN screen.
• For other BALANCE screen settings, see
“BALANCE Screen” under “Configuring Digital
Piano Settings” (pages EN-48 through EN-55).
To change the octave of a Duet Mode
keyboard (Duet Octave Shift)
Red
Adjusting the Keyboard
Volume Balance
C4 C5 C6 C7 C3 C4 C5 C6
1 octave higher than initial setting Unchanged
Leftmost C key
PX360-ES-1A.indd 19 2015/04/24 12:46:42
EN-18
Playing with Different Tones
1.
Press the cm METRONOME button.
This starts the metronome.
2.
Press the cm METRONOME button again to
stop the metronome.
This stops the metronome.
You can specify from 0 to nine beats per measure for
the metronome.
Specifying 0 will cause each beat to be indicated by the
same sound. This setting lets you practice with a steady
beat.
1.
On the MENU screen, touch “SYSTEM
SETTING”.
2.
Touch “Metronome Count”.
3.
Use the bs w, q buttons to select a beats
per measure value.
4.
On the screen, touch bp MAIN.
This returns to the MAIN screen.
You can use the following procedure to adjust the
volume level of the metronome, without affecting the
volume of keyboard output.
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Touch “BALANCE”.
3.
Touch “Metronome Volume”.
4.
Use the bs w, q buttons to adjust the
metronome volume setting (0 to 127).
5.
On the screen, touch bp MAIN.
This returns to the MAIN screen.
There are two different methods you can use to change
the tempo setting: using the cl TEMPO w, q
buttons for gradual change, or by tapping a beat with
the cl TEMPO TAP button (tap input).
■ Method 1:
To adjust the tempo setting using the
cl
TEMPO w, q buttons
1.
Use the cl TEMPO w, q buttons to adjust
the tempo setting.
Each press of a button increases or decreases the tempo
value (beats per minute) by one.
• Holding down either button changes the value at
high speed.
• You can specify a tempo value in the range of 20 to
255.
■ Method 2:
To adjust the tempo by tapping a beat (tap
input)
1.
Tap the cl TEMPO TAP button a number of
times at the tempo you want to set.
• The tempo setting will change in accordance with
your tapping.
• After you use this method to specify the approximate
tempo, you can then use the procedure under “To
adjust the tempo setting using the cl TEMPO w,
q buttons” to adjust the setting to a more exact
value.
Using the Metronome
To change the beats per measure
Adjusting the Balance between
Metronome and Keyboard Volume
(Metronome Volume)
Flashes in time with the beat.
Changing the Tempo Setting
Tap two or more times.
PX360-ES-1A.indd 20 2015/04/24 12:46:42
Playing with Different Tones
EN-19
English
You can use the pitch bend wheel to slide the pitch of
notes smoothly upwards and downwards. This
capability makes it possible to reproduce saxophone
and electric guitar choking effects.
1.
While playing a note on the
keyboard, rotate the pitch bend
wheel on the left of the keyboard
upwards or downwards.
The amount the note bends depends on
how much you rotate the pitch bend
wheel.
• Do not touch the pitch bend wheel as
you turn on the Digital Piano.
• You also can configure pitch bend wheel operation
by specifying the amount of pitch change at
maximum rotation in either direction. See
“CONTROLLER Screen” (page EN-53) for more
information.
The transpose feature lets you raise or lower the overall
pitch of the Digital Piano in semitone steps. You can
use this feature to adjust keyboard tuning to a key that
better matches a vocalist, another musical instrument,
etc.
1.
Use the 6 TRANSPOSE w, q buttons to
change the setting value.
• You can change the tuning of the keyboard within the
range of –12 to 00 to +12.
• Pressing the 6 TRANSPOSE w, q buttons at the
same time changes the setting to 0.
• The current transpose setting is shown on the MAIN
screen.
Using the Pitch Bend Wheel
Shifting the Pitch of the Digital
Piano in Semitone Units
(Transpose)
PX360-ES-1A.indd 21 2015/04/24 12:46:42
EN-20
Using Auto Accompaniment
With Auto Accompaniment, simply select the
accompaniment rhythm you want and the matching
accompaniment (drums, guitar, etc.) will play
automatically when you play a chord with your left
hand. It’s like having your own personal backup group
along with you wherever you go.
This Digital Piano has 200 built-in Auto
Accompaniment patterns, which are divided into 13
groups. You can edit built-in rhythms to create your
own original rhythms (called “user rhythms”), which
you can save in a 14th group. For more information, see
the “Rhythm List” (page A-8).
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Touch the “Rhythm” rhythm name.
3.
Touch the group that contains the rhythm you
want to use.
• You can navigate between groups by touching “UU“
or “II”.
4.
Touch the rhythm you want to use.
• You can navigate between rhythm list pages by
touching “ ” or “ ”.
5.
Use the cl TEMPO w, q buttons to adjust
the tempo setting.
• For information about the tempo adjustment method,
see “Changing the Tempo Setting” (page EN-18).
• To return a rhythm to its recommended tempo
setting, press the cl TEMPO w, q buttons at the
same time.
bp
cl
bmbk7 9 bl8
ck
bo bsbq
Playing an Auto
Accompaniment
PX360-ES-1A.indd 22 2015/04/24 12:46:43
Using Auto Accompaniment
EN-21
English
6.
Press the bm ACCOMP ON/OFF button so its
lamp is lit.
This turns ACCOMP on, so all accompaniment parts
sound.
• Turning ACCOMP off so the ACCOMP lamp is unlit
causes only the percussion instrument parts (Drums,
Percussion) to sound.
• Each press of the button toggles ACCOMP between
on and off.
7.
Press the bk SYNCHRO/ENDING button.
This puts Auto Accompaniment into “synchro
standby”. Playing a chord during synchro standby will
cause Auto Accompaniment to start to play
automatically.
• Pressing the 7 INTRO button while Auto
Accompaniment is in synchro standby will enter
intro standby. Pressing the 9 VARIATION button
will enter variation standby. For details about intro
and variation patterns, see “Modifying Auto
Accompaniment Patterns” (page EN-23).
8.
Play the chord you want on the chord
keyboard (left keyboard keys).
Auto Accompaniment will start playing when you play
the chord.
• To start percussion part play without playing a
chord, press the bl a button.
Example: To play a C chord
9.
Play other chords with your left hand as you
play the melody with your right hand.
• You can use “CASIO Chord” or other simplified
chord fingering modes to play chords. For details, see
“To select a chord fingering mode” in the following
section.
• You can use the 8 NORMAL and 9 VARIATION
buttons to modify accompaniment patterns. For
details, see “Modifying Auto Accompaniment
Patterns” (page EN-23).
10.
When you are finished, press the bl a
button again to stop Auto Accompaniment.
• Pressing the bk SYNCHRO/ENDING button instead
of the bl a button will play an ending pattern
before stopping Auto Accompaniment play. For
details about ending patterns, see “Modifying Auto
Accompaniment Patterns” (page EN-23).
• You can adjust the volume level of the Auto
Accompaniment, without affecting the volume of
Digital Piano output. For details, see “BALANCE
Screen” (page EN-50).
• You can change the size of the chord keyboard by
using the split feature to move the split point (page
EN-15). The keyboard keys to the left of the split
point make up the chord keyboard.
Lit
Flashing
Chord keyboard Melody keyboard
PX360-ES-1A.indd 23 2015/04/24 12:46:43
EN-22
Using Auto Accompaniment
You can select from among the following five chord
fingering modes.
Fingered 1
Fingered 2
Fingered 3
CASIO Chord
Full Range
1.
On the MENU screen, touch “RHYTHM”.
2.
Touch “Chord Input Type”.
3.
Touch the chord input method you want to
use.
This changes to the selected chord input method.
■ Fingered 1, 2, 3
With these three chord fingering modes, you play
chords on the chord keyboard using their normal
chord fingerings. Some chord forms are abbreviated,
and can be fingered with one or two keys.
For information about the types of chords you can
finger and their fingerings, see the “Fingering Guide”
(page A-12).
■ CASIO CHORD
With “CASIO Chord”, you can use simplified
fingerings to play the four types of chords described
below.
When pressing more than one chord keyboard key,
makes no difference whether the additional keys are
white or black.
■ FULL RANGE CHORD
With this chord fingering mode, you can use the full
range of the keyboard to play chords and the melody.
For information about the types of chords you can
finger and their fingerings, see the “Fingering Guide”
(page A-12).
To select a chord fingering mode
Fingered 1: Play the component notes of the chord on the
keyboard.
Fingered 2: Unlike Fingered 1, 6th input is not possible with
this mode.
Fingered 3: Unlike Fingered 1, this mode allows input of
fraction chords with the lowest keyboard note as
the bass note.
Chord keyboard
Chord Type Example
Major Chords
Press one key, whose note
corresponds to the chord
name.
• To play C Major, press any
C key in the chord
keyboard. The octave of the
note does not matter.
C (C Major)
Minor Chords
Press the chord keyboard key
that corresponds to the major
chord, while also pressing one
other chord keyboard key to
the right.
Cm (C minor)
Seventh Chords
Press the chord keyboard key
that corresponds to the major
chord, while also pressing
two other chord keyboard
keys to the right.
C7 (C seventh)
Minor Seventh Chords
Press the chord keyboard key
that corresponds to the major
chord, while also pressing
three other chord keyboard
keys to the right.
Cm7 (C minor seventh)
Chord keyboard
C
C
DE F
#
b
E
F
#
G
A
b
A
B
B
b
C
C
DE F
E
#
b
Note name
C
C
DE F
#
b
E
F
#
G
A
b
A
B
B
b
C
C
DE F
E
#
b
C
C
DE F
#
b
E
F
#
G
A
b
A
B
B
b
C
C
DE F
E
#
b
C
C
DE F
#
b
E
F
#
G
A
b
A
B
B
b
C
C
DE F
E
#
b
Melody keyboard
Chord keyboard
PX360-ES-1A.indd 24 2015/04/24 12:46:43
Using Auto Accompaniment
EN-23
English
There are six different Auto Accompaniment patterns,
shown below. You can switch between patterns during
accompaniment play and even modify patterns. Use
buttons 7 through bk to select the pattern you want.
*1 Press at the beginning of a song.
Accompaniment play proceeds with the normal
pattern after the intro pattern is complete. Pressing
the 9 VARIATION/FILL-IN button before the
intro pattern is finished will proceed with the
variation pattern after the intro pattern is complete.
*2 Press while a normal pattern is playing to insert a
fill-in pattern.
*3 Press while a variation pattern is playing to insert a
fill-in variation pattern.
*4 Press at the end of a song.
This will play an ending pattern and then stop Auto
Accompaniment.
One-Touch Preset gives you one-touch access to tone
and tempo settings that go well with the currently
selected Auto Accompaniment rhythm pattern.
1.
On the MENU screen, touch “RHYTHM”.
This displays the RHYTHM screen.
• You can also display the RHYTHM screen by
pressing the ck RHYTHM button.
2.
Touch “One Touch”.
This configures tone, tempo, and other settings to
match the currently selected rhythm pattern.
At this time, Auto Accompaniment play also will go
into synchro standby, which means that Auto
Accompaniment will start to play automatically when
you finger a chord.
3.
Play a chord on the keyboard.
This will start Auto Accompaniment play.
• One-Touch Presets are not supported for user
rhythms (001 through 010 of the user group).
Modifying Auto Accompaniment Patterns
Intro *
1
Normal Variation Ending *
4
7 8 9 bk
Normal fill-in *
2
Variation fill-in *
3
Using Recommended Tones
and Tempos (One-Touch
Presets)
PX360-ES-1A.indd 25 2015/04/24 12:46:43
EN-24
Using Auto Accompaniment
Auto Harmonize lets you add harmony to melody
notes you play with your right hand for more melodic
depth. You can select any one of 12 Auto Harmonize
types.
1.
On the screen, touch bp MAIN.
This displays the MAIN screen.
2.
Touch “Auto Harmonize” to turn it on.
3.
Touch bo MENU.
4.
On the MENU screen, touch “RHYTHM”.
5.
Touch “Auto Harmonize Type”.
6.
Touch the Auto Harmonize type you want to
use.
7.
Play chords and the melody on the keyboard.
Harmony will be added to your melody notes based on
the chords you play.
You can use the rhythm editor to modify a built-in
Auto Accompaniment and create an original “user
rhythm” of your own.
You can select a part (Drums, Bass, etc.) of a normal,
intro, or other pattern (page EN-23) and turn it on or
off, adjust its volume level, and perform other
operations.
1.
Perform steps 1 through 4 under “Playing an
Auto Accompaniment” (page EN-20) to select
the rhythm you want to edit.
2.
On the MENU screen, touch “RHYTHM”.
3.
Touch “Edit”.
4.
Touch “Edit”.
5.
Use buttons 7 through bk to select the
accompaniment pattern you want to edit.
The button you press will light, indicating that the
pattern is being edited.
• Each press of the 8 toggles between NORMAL and
FILL-IN, and each press of 9 toggles between
VARIATION and FILL-IN. The applicable button
flashes while the fill-in pattern is selected.
Example: When intro is selected
Adding Harmony to Melody
Notes (Auto Harmonize)
Type Name Description
Duet 1 Adds close (separated by two to four
degrees) 1-note harmony below the
melody note.
Duet 2 Adds open (separated by more than 4 to 6
degrees) 1-note harmony below the
melody note.
Country Adds country style harmony.
Octave Adds the note from the next lower octave.
5th Adds the fifth degree note.
3-Way Open Adds 2-note open harmony, for a total of
three notes.
3-Way Close Adds 2-note close harmony, for a total of
three notes.
Strings Adds harmony that is optimal for strings.
4-Way Open Adds 3-note open harmony, for a total of
four notes.
4-Way Close Adds 3-note close harmony, for a total of
four notes.
Block Adds block chord notes.
Big Band Adds big band style harmony.
Red
Creating Your Own Original
Rhythm by Editing a Built-in
Auto Accompaniment (Rhythm
Edit)
789bk
Lit
PX360-ES-1A.indd 26 2015/04/24 12:46:44
Using Auto Accompaniment
EN-25
English
6.
Touch the display item for the instrument part
you want to edit.
Rhythm, tone: Touch the display item and then select
from the list that appears.
To change the settings of items other than those above,
use the bs w, q buttons to change the displayed
value.
• Rhythm patterns are made up of the eight parts
below.
Drums, Percussion, Bass, Chord 1, Chord 2, Chord 3,
Chord 4, Chord 5
• Pressing the bl a button during an editing
operation will sound the accompaniment pattern
with the edits you have made up to that point.
Touching “Solo” will sound only the instrument part
you are editing.
• The table below describes the parameters you can
edit.
7.
After editing is complete, adjust the tempo of
the rhythm as desired.
• The tempo you set here becomes the initial default
tempo.
8.
On the screen, touch bq EXIT.
9.
Touch “Write”.
This displays a screen for specifying the destination
user rhythm number and rhythm name.
• If you want to exit the editing operation without
saving, touch bq EXIT.
10.
Touch “Rename”.
11.
Input a name for the rhythm.
12.
After inputting the rhythm name, touch
“Enter”.
13.
Touch the destination user rhythm number.
• If the rhythm number already has data assigned to it,
there will be an asterisk (*) next to it.
14.
Touch “Execute”.
If the selected rhythm number does not have any data
assigned to it, the message “Sure?” will appear. If it
does have data assigned to it, the message “Replace?”
will appear.
15.
Touch “Yes”.
This stores the data.
• To return to the screen in step 4 without saving, touch
“No”.
• Saving user rhythm data to a user rhythm number
that already has data will cause the existing data to
be replaced by the new data.
• If the size of the accompaniment pattern or
instrument part data is too large to be edited, a
memory full message (Memory Full) will appear on
the display. If that happens, select a different
accompaniment pattern or instrument part for
editing.
Item Description Setting
Rhythm Replaces the part
accompaniment data with
that of the specified rhythm
number. *
1
Rhythm
number *
2
Part Toggles each part on or off. White:
Part is muted.
Red:
Part sounds.
Tone Changes the tone
(instrument) for part play.
Tone name *
3
Volume Controls the volume level of
each part.
000 to 127
Pan Controls whether the sound
of the part can be heard from
the left side or right side.
–64 to 0 to 63 *
4
Reverb
Send
Specifies how much reverb
(page EN-51) is applied to
each part.
000 to 127
Chorus
Send
Specifies how much chorus
(page EN-51) is applied to
each part.
000 to 127
Delay
Send
Specifies how much delay
(page EN-51) is applied to
each part.
000 to 127
*1 Replacing part accompaniment data clears all edits made
up to that point.
*2 For an intro, the same rhythm number is applied to all of
the eight instrument parts. For example, if you assign
rhythm 003 to Chord 1, rhythm 003 is automatically
assign to the other seven instrument parts as well. If you
later change Chord 2 to rhythm 004, the Chord 1 rhythm
also changes to 004.
Like the intro, all of the eight parts of an ending also are
the same rhythm number.
*3 Only drum set tones can be selected for Drums and
Percussion parts.
Drum set sounds cannot be selected for the Bass and the
Chord 1 through Chord 5 parts.
*4 A smaller value shifts the pan position to the left while a
larger value shifts to the right. A value of zero specifies
center.
Destination user rhythm number
PX360-ES-1A.indd 27 2015/04/24 12:46:44
EN-26
Using Auto Accompaniment
1.
On the MENU screen, touch “RHYTHM”.
2.
Touch “Edit”.
3.
Touch “Clear”.
4.
Touch the user rhythm you want to delete and
then touch “Execute”.
5.
Touch “Yes”.
This deletes the selected user rhythm.
• To cancel the delete operation, touch “No”.
Deleting a User Rhythm
PX360-ES-1A.indd 28 2015/04/24 12:46:44
EN-27
English
Demo Song
1.
While holding down the bm ACCOMP ON/
OFF button, press the bl a button.
This will start sequential playback of the demo songs,
starting from song 1.
• You can use the bs w, q buttons to change to
another demo song.
2.
Press the bl a button.
This stops demo song playback.
Playback of the demo songs will continue in an endless
loop until you press the bl a button to stop it.
• Only the operations described above can be
performed while demo song playback is in progress.
bsbl bm
Playing the Demo Tunes
PX360-ES-1A.indd 29 2015/04/24 12:46:44
EN-28
Music Presets
Music Presets provide you with one-touch tone,
rhythm, chord, and other settings that are optimized
for specific musical genres and songs.
In addition to built-in presets, you can create your own
original Music Presets (user presets).
There is a total of 305 built-in music presets, which are
divided into nine groups. A tenth group is provided
for user presets.
• For more information, see the “Music Preset List”
(page A-10).
1.
On the MENU screen, touch “MUSIC
PRESET”.
This displays the MUSIC PRESET screen and turns on
Auto Chord.
2.
Touch the preset name.
3.
Touch the group that contains the preset you
want to use and then touch the preset name.
This configures the Digital Piano with the settings
(tone, rhythm, etc.) of the selected preset.
4.
Press the bl a button to start Auto
Accompaniment with the preset chord
progression. Play the melody on the
keyboard.
• The preset chord progression repeats until you stop it
by pressing the bl a button again.
• Touching “Auto Chord” to turn it off turns off the
preset chord progression, which enables play of the
normal Auto Accompaniment pattern.
• To change the key of a preset chord progression,
touch “Key Shift” and then use the bs w, q
buttons to make the change.
• To turn off Auto Chord, press the bm ACCOMP
button.
• For details about the settings for a recalled preset,
see “Music Preset List” (page A-10).
bl bsbm bq
Recalling Preset Data
Flashing
PX360-ES-1A.indd 30 2015/04/24 12:46:44
Music Presets
EN-29
English
A music preset editor is provided to allow you to create
your own original music presets (user presets). Up to
50 user presets can be stored in the user group.
1.
Perform step 1 through 3 in the procedure
under “Recalling Preset Data” (page EN-28)
to select the preset you want to use as the
basis for your user preset.
2.
Touch “Edit”.
3.
Edit the music preset parameters.
4.
After editing everything you want, touch
“Write”.
5.
Touch “Rename”.
6.
Input a name for the preset.
7.
After inputting the preset name, touch “Enter”.
8.
Touch the destination preset number.
• If the preset number already has data assigned to it,
there will be an asterisk (*) next to it.
9.
Touch “Execute”.
If the selected preset number does not have any data
assigned to it, the message “Sure?” will appear. If it
does have data assigned to it, the message “Replace?”
will appear.
10.
Touch “Yes”.
This stores the data.
• To return to the screen in step 8 without saving, touch
“No”.
1.
On the editing operation selection screen
(page EN-29), touch “Chord Edit” to display
the chord progression editing screen shown
below.
Step (timing and chord)
The timing of a chord progression is expressed as
a series of three values (such as 001:1:00)
indicating measure
*1
(001), beat (1), and tick
(00)
*2
. This series of three values is referred to
collectively as a “step”.
*1 Up to 999 measures
*2 There are 12 ticks per beat, as shown below.
2.
Edit the step as desired.
• You can playback and check the edited progression
by pressing the bl a button. Chord progression
editing cannot be performed while chord progression
playback is in progress.
Creating an Original User
Preset (User Presets)
3-1. To edit the chord progression
Touch “Chord Edit” to display the chord
progression editing screen.
Next, perform the editing operation described
under “To edit a chord progression” (page
EN-29). After you are finished, touch bq EXIT to
return to the screen above.
3-2. To change how an Auto Accompaniment is
played
Touch “Parameter Edit” to display the parameter
editing screen.
Next, perform the editing operation described
under “To change how an Auto Accompaniment
is played” (page EN-31). After you are finished,
touch bq EXIT to return to the screen above.
To edit a chord progression
Step (timing and chord)
01 02 09 10 1100
Chord progression
Measure 1
Beat 1 Beat 2 Beat 3 Beat 4 Beat 1 Beat 2
Tick
001:1:00
002:1:00
For the sample display
above, the chord change
from C to Am7 occurs
here.
Measure 2
PX360-ES-1A.indd 31 2015/04/24 12:46:44
EN-30
Music Presets
3.
After you are finished, touch bq EXIT to
return to the editing type selection screen
(page EN-29).
• Up to approximately 999 measures can be contained
in a single preset.
If your edits cause this limit to be exceeded, the
message “Measure Limit” will appear on the screen
and further editing will become impossible.
■ To edit preset chord information
1.
Use the on-screen “e” and “r” icons to
select the step you want to change.
2.
Input timing information or a chord.
• To change the timing, touch the current “Measure”,
“Beat”, or “Tick” value, and then use the bs w, q
buttons to change the timing value.
• To change a chord, touch it and then play the desired
chord on the keyboard.
• The timing of the first step (001:1:00) is fixed and
cannot be changed. Also, the final step is always one
measure, regardless of the resolution.
■ To insert a new chord
1.
Use the on-screen “e” and “r” icons to
select the step that comes immediately
before the location where you want to insert a
new chord.
2.
Touch “Insert” and then play the desired
chord on the keyboard.
■ To insert a sequential series of steps
1.
Use the on-screen “e” and “r” icons to
select the step that comes immediately
before the location where you want to insert
the step.
2.
Touch “Step Rec”.
3.
Touch the note icon.
4.
Touch the note you want to use.
5.
Play a chord on the keyboard.
This inputs a step of the length you specified in step 4
above, and then advances to input of the next step.
• Touching “Tie” without inputting a chord will
specify a tie.
• Touching “Rest” without inputting a chord will
result in no chord being played during that step.
6.
After you are finished inserting steps, touch
“Step Rec” again to exit data editing.
■ To delete a step
1.
Use the on-screen “e” and “r” icons to
select the step you want to delete.
2.
Touch “Delete”.
• You cannot delete the first step or the last step.
PX360-ES-1A.indd 32 2015/04/24 12:46:45
Music Presets
EN-31
English
1.
On the editing type selection screen (page EN-29), touch “Parameter Edit” to display the auto
accompaniment play editing screen shown below.
2.
Touch the parameter whose setting you want to change, and then use the bs w, q buttons to
change the setting value.
3.
After you are finished, touch bq EXIT to return to the editing type selection screen (page EN-29).
To change how an Auto Accompaniment is played
Parameter Description Setting
Synchro Type:
Synchro type
Selects the synchro standby status and type when
the music preset is selected.
Off (no standby)
Normal: From standby to normal pattern
Variation: From standby to variation pattern
Intro: From standby to intro pattern
Intro Chord:
Intro chord
Selects from among major (12 keys) and minor (12
keys) for the intro chords.
C to B: Major (C to B)
Cm to Bm: Minor (Cm to Bm)
Ending Chord:
Ending chord
Selects from among major (12 keys) and minor (12
keys) for the ending chords.
C to B: Major (C to B)
Cm to Bm: Minor (Cm to Bm)
Auto Fill-In:
Auto fill-in on/off
Specifies whether or not a fill-in should be
inserted into the final measure of a chord
progression.
Off: Fill-in not inserted
On: Fill-in inserted
Timing Set:
Chord progression
variation
This parameter lets you add different variations to
the timing of the chord progression being edited.
You can use it to match the chord progression to
the beat of a specific rhythm.
For information about differences in playback for
each setting value, see “Timing Setting and Chord
Progression Playback” (page EN-32).
Normal, Half, Double, 3/4, 3/2
Parameter Setting
PX360-ES-1A.indd 33 2015/04/24 12:46:45
EN-32
Music Presets
■ Timing Setting and Chord Progression Playback
This section explains how chord progressions are played in accordance with the “Timing Set” settings in step 2
under “To change how an Auto Accompaniment is played” (page EN-31). Note that this setting affects playback
only. It does not change the chord progression data.
z Normal
Plays chords at the same timing as the recording.
z Half
Plays chords measure-by-measure at a timing that is half that of the recording.
Example:
The following shows what happens when the “Half” setting is used to play back a user preset that was created
based on a music preset whose rhythm is a 4/4 time.
Half Playback when a 4/4 time rhythm is assigned to the user preset
Half Playback when a 2/4 time rhythm is assigned to the user preset
z Double
Plays chords measure-by-measure at a timing that is double that of the recording.
Playing back a chord progression like that shown for “Half” above while “Double” is specified results in the
progression shown below.
Double Playback when a 4/4 time rhythm is assigned to the user preset
Double Playback when an 8/4 time rhythm is assigned to the user preset
1 2 3 4
Dm A7
1
1 2 3 4
Dm G7
2
1 2 3 4
C Em
3
1 2 3 4
Am C7
4
Measure
Beat
Chord progression
1 2 3 4
Dm A7
1
1 2 3 4
Dm G7
2
1 2 3 4
C Em
3
1 2 3 4
Am C7
4
Measure
Beat
Chord progression
1 2 1 2
Dm A7
1
1 2 1 2
C EmDm G7 Am C7
324
Measure
Beat
Chord progression
1 2 3 4
Dm
1
1 2 3 4
Dm
2
1 2 3 4
C
3
1 2 3 4
Am
4
Measure
Beat
Chord progression
1 2 3 4
Dm
1
5 6 7 8
A7
1 2 3 4
Dm
2
5 6 7 8
G7
1 2
C
3
Measure
Beat
Chord progression
PX360-ES-1A.indd 34 2015/04/24 12:46:45
Music Presets
EN-33
English
z 3/4
Plays chords measure-by-measure at a timing that is 3/4 times that of the recording. This setting is best for use
with a 6/8 time rhythm.
Playing back a chord progression like that shown for “Half” above while “3/4” is specified results in the
progression shown below.
3/4 Playback when a 4/4 time rhythm is assigned to the user preset
3/4 Playback when a 6/8 time rhythm is assigned to the user preset
z 3/2
Plays chords measure-by-measure at a timing that is 3/2 times that of the recording. This setting is best for use
with a 6/4 time rhythm.
Playing back a chord progression like that shown for “Half” above while “3/2” is specified results in the
progression shown below.
3/2 Playback when a 4/4 time rhythm is assigned to the user preset
3/2 Playback when a 6/4 time rhythm is assigned to the user preset
• When “Double” or “3/2” is selected, chord timing is shifted to a later timing. Any chords that do not fit within a
measure are not played.
1.
On the MENU screen, touch “MUSIC PRESET”.
2.
Touch “Edit”.
3.
Touch “Clear”.
4.
Touch the user preset you want to delete and then touch “Execute”.
5.
Touch “Yes”.
This deletes the selected user preset.
• To cancel the delete operation, touch “No”.
Deleting a User Preset
1 2 3 4
Dm A7
1
1 2 3 4
Dm G7
2
1 2 3 4
C Em
3
1 2 3 4
Am C7
4
Measure
Beat
Chord progression
1 2 3 4
Dm A7 Dm G7 C Em Am
1
5 6 1 2
2
3 4 5 6
3
1 2 3 4 5 6 1 2
4
Measure
Beat
Chord progression
1 2 3 4
Dm A7
1
1 2 3 4
Dm G7
2
1 2 3 4
C Em
3
1 2 3 4
Am C7
4
Measure
Beat
Chord progression
1 2 3 4
Dm A7 Dm G7 C Em Am
1
5 6 1 2
2
3 4 5 6
3
1 2 3 4 5 6 1 2
4
Measure
Beat
Chord progression
PX360-ES-1A.indd 35 2015/04/24 12:46:45
EN-34
Registering Tone and Rhythm Setups
Registration memory lets you store Digital Piano
setups (tone, rhythm, etc.) for instant recall whenever
you need them. Registration memory simplifies
performance of complex pieces that require successive
tone and rhythm changes.
You can have up to 96 setups in Registration memory
at one time. To select a setup, use the co BANK button
and REGISTRATION buttons cp through cs.
• Press the co BANK button and then use the bs w,
q buttons to change the bank number.
• Pressing a REGISTRATION button (cp through
cs) selects the corresponding area in the currently
selected bank.
• For details about these settings, see “Parameter List”
(page A-14).
1.
Configure the Digital Piano with the tone,
rhythm, and other settings you want to save.
2.
While holding down the ct STORE button,
perform the operation below.
Use the bs w, q buttons to select the bank where
you want to store the data, and then press a
REGISTRATION button (cp through cs) to specify an
area.
The data will be saved to the bank and area you specify.
Example: Bank 4, Area 1
cr csco cp cqbs ct
Area 1 Area 2 Area 3 Area 4
Bank 1 Setup 1-1 Setup 1-2 Setup 1-3 Setup 1-4
Bank 2 Setup 2-1 Setup 2-2 Setup 2-3 Setup 2-4
.
.
.
.
.
.
.
.
.
.
Bank 24 Setup 24-1 Setup 24-2 Setup 24-3 Setup 24-4
co cp cq cr cs
To save registration data
ctcp cq cr cs
Bank
Lit
PX360-ES-1A.indd 36 2015/04/24 12:46:46
Registering Tone and Rhythm Setups
EN-35
English
1.
Press the co BANK button to select the bank
that contains the setup you want to recall.
• The currently selected bank and area numbers are
shown on the MAIN screen and button lamps.
2.
Use the REGISTRATION buttons (cp
through cs) to select the area whose setup
you want to recall.
This recalls the registration memory setup and
automatically configure the Digital Piano settings
accordingly.
Example: When recalling the registration data in Bank 4,
Area 1
• You can use Accomp Freeze to specify
accompaniment settings that should be left
unchanged whenever a registration setup is applied.
For details, see “SYSTEM SETTING Screen” under
“Configuring Digital Piano Settings” (pages EN-48
through EN-55).
■ Saving Setup Registration Data to an
External Device
See “Connecting to a Computer” (page EN-60).
To recall a registration setup
Lit
PX360-ES-1A.indd 37 2015/04/24 12:46:46
EN-36
Recording and Playback
Your Digital Piano can record what you play on the keyboard and play it back when you want. The Digital Piano
has two recording functions: a MIDI Recorder and an Audio Recorder. Select the function that suits the needs for the
type of recording you want to make.
• CASIO COMPUTER CO., LTD. takes no responsibility for any damages, lost profits, or claims by third parties
arising from the deletion of recorded data due to malfunction, repair, or for any other reason.
■ Recording Features
MIDI Recorder Audio Recorder
Keyboard performance information is recorded as MIDI data*
to a system track or 16 tracks (storage areas for keyboard
performance data) in Digital Piano memory.
Keyboard performance information is recorded to a USB flash
drive as audio data.
• Keyboard performance information (keyboard keys press/
release, touch pressure, etc.) is recorded as MIDI data.
• The size of MIDI data is much smaller when compared with
audio data, making it easier to edit later on a computer, etc.
• Supported recording capacity: 100 songs approximately
50,000 notes per song (total of all tracks)
• Like a portable music player or tape recorder, notes are
recorded as audio data.
• Audio data files are much larger compared to MIDI data
files. The advantage of audio data files is that they can be
easily played back on a computer, portable music player,
etc.
• Supported recording capacity: Up to 100 files, each file up to
a maximum length of 74 minutes
3 4
bs
5
MIDI
USB
PX360-ES-1A.indd 38 2015/04/24 12:46:47
Recording and Playback
EN-37
English
■ Playback Features
* MIDI
MIDI is short for “Musical Instrument Digital Interface”. It is a universal standard that makes it possible for
musical instruments, computers, and other devices to exchange performance information (keyboard key press/
release, touch pressure, etc.) regardless of manufacturer. Performance data in this case is called “MIDI data”.
MIDI Recorder Audio Recorder
Playback plays the system track and tracks 1 through 16.
• With the MIDI Recorder, the Digital Piano automatically
performs playback using its internal sound source in
accordance with the performance information recorded as
MIDI data.
You can play back audio data from a USB flash drive.
• The Audio Recorder plays back the waveform of sound
recorded as audio data.
MIDI Recorder Audio Recorder
What you can do...
Record to one track while playing back from the other track
System Track
Keyboard play
3
While playing
back...
Track 1
Keyboard play
·
·
·
What you can do...
Record performance while playing back a song recorded
with the MIDI Recorder
MIDI Recorder
song playback
+
Keyboard play 3 Record
Record input of an external device connected to the LINE
IN terminal along with Digital Piano performance and
playback
• AUDIO IN terminal input is not recorded.
What you can do...
Play on the keyboard along with playback of tracks
System Track 3 While playing back...
Track 1 3 While playing back...
Keyboard play
What you can do...
You can play along on the keyboard while the audio data is
playing.
Playback of a song on a
USB flash drive
+
Keyboard play
PX360-ES-1A.indd 39 2015/04/24 12:46:47
EN-38
Recording and Playback
Perform the steps below to record your keyboard play
to Digital Piano Memory.
1.
Configure the tone, rhythm, and other
settings you want to use.
• The settings you configure here will be included as
part of the recorded MIDI data.
• For details about what is included in the recorded
MIDI data, see “System Track” (page EN-39).
2.
On the MENU screen, touch “MIDI
RECORDER”.
3.
Touch “0”.
This turns on the recorder and enters record mode.
• Each touch of “0” cycles through modes as shown
below
Playback mode
Recording mode
4.
Touch “New Data”.
This enables recording of new data to the system track.
5.
Play something on the keyboard.
Recording starts as soon as you play something.
• You can also start recording by touching “X”.
• You also can configure the piano so Auto
Accompaniment is included in the recorded data.
• The 4 MIDI a button is lit while recording is in
progress.
6.
After you finish recording, touch “Y”.
This causes the 3 REC MODE button and 4 MIDI
a button lamps to become unlit, and enters the
playback mode.
• You can also enter the recording mode by pressing
the 3 REC MODE button and then touching
“MIDI RECORDER”. This method can be used to
enter the recording mode only for making a new
recording.
• Recording memory capacity is approximately 50,000
notes per song. When remaining capacity is 100 or
fewer notes, the 4 MIDI a button lamp will
flash at high speed. Recording will stop
automatically when the allowable limit is reached.
• The Digital Piano has memory for 100 songs.
• If power to the Digital Piano is cut off while recording
is in progress, everything you recorded up to that
point will be lost. Take care so power is not turned
off accidentally during recording operations.
Recording to Digital Piano
Memory (MIDI Recorder)
Unlit
Lit Flashing
Unlit: Playback mode
PX360-ES-1A.indd 40 2015/04/24 12:46:47
Recording and Playback
EN-39
English
You can record specific instruments, the left hand and
right hand, or other parts of a song individually, and
then combine them into a final song.
■ What is a track?
A “track” is a separate recorded part of a song. The
MIDI Recorder of this Digital Piano has a total of 17
tracks, one of which is a system track as described
below.
z System Track
In addition to notes you play on the keyboard and
other performance operation data, the system track
also includes a wide range of setup information for
the song, including layer on/off, split on/off, tempo,
Auto Accompaniment settings, reverb type, etc.
When you record a single-track song to recorder
memory, as shown under “Recording to Digital
Piano Memory (MIDI Recorder)” (page EN-38)
everything is recorded to the system track.
z
Tracks 01 through 16
These tracks can be used to record notes, as well as
pitch bend wheel and pedal operations, and the
keyboard tone setting. These tracks can be combined
with the system track and each other to create the
final song.
■ Supported Track Data
The following describes the data that can be recorded
to each type of track.
System Track, Tracks 01 through 16
Keyboard performance*
1
, the keyboard tone setting*
1
,
pedal and pitch bend wheel operation, mixer settings
(except for part on/off)
System Track only
Rhythm, balance setting, effect setting (reverb, chorus,
delay), tempo, Auto Accompaniment performance/
setting, one-touch preset, music preset performance*
2
,
registration*
2, 3
1.
Record the first part to the system track.
• Use the procedure under “Recording to Digital Piano
Memory (MIDI Recorder)” (page EN-38) to record to
the system track.
2.
Next, select the tone of the part you want to
play and record.
3.
On the MENU screen, touch “MIDI
RECORDER”.
4.
Touch “0” to enter the recording mode.
5.
Touch the track name.
6.
Touch the track (Solo Track 1 through Solo
Track 16) you want to record.
7.
Start playing something on the keyboard.
This starts recording along with playback of what you
recorded to the system track, so you can play along
with system track.
To record to a specific track (Part)
*1 Upper 1 only for Tracks 1 through 16
*2 Recall only
*3 The Auto Accompaniment volume level and
transpose setting of the recalled data is not included
in the recording.
PX360-ES-1A.indd 41 2015/04/24 12:46:47
EN-40
Recording and Playback
8.
After you are finished playing, touch “Y”.
This enters the playback mode. Touch “X“ to play back
what you recorded up to this point. To stop playback,
touch “Y”.
• You can use the following procedure to turn specific
tracks on (play enabled) and off (play disabled). This
allows you to listen only to the track(s) you want
when recording a new track.
You can mute specific recorded tracks so they do not
play as you record a new track.
9.
Repeat steps 2 through 8 above as required
to record all of the parts you need to complete
your song.
• You can re-record the currently selected track
without changing any settings. Simply touch “Rec
Type” on the screen that is displayed in the
recording mode, and then select “Re-Recording”.
You can use punch-in recording to re-record a specific
part of recorder song that you want to improve or
correct.
1.
Enter the MIDI recorder recording mode and
then select the track where you want to
perform punch-in recording.
• For information about how to select a track, see steps
4 and 5 under “To record to a specific track (Part)”
(page EN-39).
2.
Touch “Rec Type”.
3.
Touch “Punch In Sync”.
• If you want to delete all of the data in the track
following the section you recorded with punch-in
recording, touch “Punch Out Erase”.
4.
Touch “X”.
This will start playback of the selected track.
5.
When playback reaches the point you want to
re-record, play the desired note(s) on the
keyboard.
This starts punch-in recording, so continue to play.
• Performing a pedal or pitch bend wheel operation
also will start punch-in recording.
• Besides keyboard play, you can also start punch-in
recording by performing the operation below.
Touch “Punch In”*
1
, change the tone, change the
rhythm*
2
, change the tempo*
2
.
*1 Used when you want to start punch-in recording
without modifying play or settings.
*2 System track only
• During punch-in playback, you can touch “s” to
skip back or “d” to skip forward. This lets you
jump more quickly to the location you want to
record. You can also pause playback by touching
“k”.
6.
After you are finished punch-in recording,
touch “Y”.
Anything in the track following the point where you
touched “Y” will be retained as-is.
• If you want to cancel punch-in recording part way
through and retain the original track data, touch
“Cancel Punch”.
(1) Touch “Monitor”.
This displays the MIDI Recorder playback
properties screen.
(2) You can select “Mute” or “Solo” for each of the
tracks.
Mute: Track is not played.
Solo: Selected track is played alone.
To re-record part of a recorder song
(Punch-in Recording)
Mistake
Playback
Use punch-in
recording to re-record
only this part.
PX360-ES-1A.indd 42 2015/04/24 12:46:47
Recording and Playback
EN-41
English
You can use the following procedure to specify a
particular range for punch-in recording.
1.
Enter the MIDI recorder recording mode and
then select the song that contains the section
you want to re-record.
2.
Use “s” and “d” to display the first
measure of the section you want to record
and then touch “Set A”.
3.
Use “s” and “d” to display the last
measure and then touch “Set B”.
4.
Touch “
Y
W” to return to the beginning of the
song, or use “
s” and “d” to adjust the
position to start playback.
5.
Touch “0”.
This enters record standby.
6.
Touch “Rec Type”.
7.
Touch “Punch In A-B”.
8.
Touch “X”.
• Punch in recording will start from the start measure
and stop with the end measure automatically.
■ To re-record an area smaller than one
measure
Use the procedure below to specify a punch-in
recording area that includes a part of a measure.
Example: To re-record from beat 3 of measure 2 up to beat
1 of measure 4
1.
Use the MIDI Recorder to start playback of
the song that contains the section you want to
re-record.
2.
When playback reaches the point where you
want to start punch-in recording, touch “Set
A”.
• After touching “Measure”, “Beat”, or “Tick” for Point
A, you can then use the bs w, q buttons to make
fine adjustments to the start point.
3.
When playback reaches the point where you
want to end punch-in recording, touch “Set
B”.
• After touching “Measure”, “Beat”, or “Tick” for Point
B, you can then use the bs w, q buttons to make
fine adjustments to the end point.
4.
Touch “Y” to stop play back.
To re-record a specific range
(Auto Punch-in Recording)
Start measure End measure
Punch-in recording range
To re-record this section
PX360-ES-1A.indd 43 2015/04/24 12:46:48
EN-42
Recording and Playback
5.
Touch “
Y
W” to return to the beginning of the
song, or use “
s” and “d” to adjust the
position to start playback.
6.
Touch “0” to enter the recording mode and
select the track where you want to perform
punch-in recording.
• For information about how to select a track, see steps
4 and 5 under “To record to a specific track (Part)”
(page EN-39).
7.
Touch “Rec Type”.
8.
Touch “Punch In A-B”.
9.
Touch “X”.
• Punch-in recording automatically starts when
playback reaches the start point and ends when it
reaches the end point you specified in step 3.
You can use the procedure below to perform auto play
of MIDI data (MIDI recording data or SMF files) stored
in Digital Piano memory or on a USB flash drive, and
practice along on the keyboard.
• For information about loading a USB flash drive on
the Digital Piano and importing MIDI data to Digital
Piano memory, see “Loading Data from a USB Flash
Drive to Digital Piano Memory” (page EN-58).
1.
On the MENU screen, touch “MIDI
RECORDER”.
This displays a MIDI RECORDER screen.
2.
Touch the file name.
3.
Touch the “User” tab to play back MIDI data
stored in Digital Piano memory or the “Media”
tab to play back from a USB flash drive.
4.
Touch the MIDI data you want to play.
5.
Touch “X”.
This starts playback.
• You can also start playback by pressing the 4 MIDI
a button.
• The operations below are supported while MIDI data
is playing back, during playback standby, or while
playback is paused.
6.
To stop playback, touch “Y”.
• You can also stop playback by pressing the 4 MIDI
a button.
To play MIDI data
This icon: Does this:
Performs repeat play.
Y
W Returns to the beginning of a song.
s Rewinds. A single touch rewinds one
measure, holding down performs
continuous rewind.
d Fast forwards. A single touch fast
forwards one measure, holding down
performs continuous fast forward.
k Pauses or resumes the currently playing
MIDI data.
The icon flashes while playback is
paused.
a Starts playback MIDI data or stops
playback.
0 Toggles between the recording mode and
playback mode.
PX360-ES-1A.indd 44 2015/04/24 12:46:48
Recording and Playback
EN-43
English
You can change the volume level of the MIDI data auto
play only, without affecting the volume of the
keyboard. For details, see “BALANCE Screen” under
“Configuring Digital Piano Settings” (pages EN-48
through EN-55).
You can configure the piano to repeat the section of a
song you want to practice. You could, for example,
specify repeat play from measure 5 to measure 8.
1.
Touch “X”.
This starts auto play.
2.
When play reaches the beginning of the
section you want to repeat, touch “Set A”.
This makes the measure where you touched “Set A” the
“start measure”.
• You can also make fine adjustments to the start point.
After touching “Measure”, “Beat”, or “Tick” for Point
A, you can then use the bs w, q buttons to adjust.
3.
When play reaches the end of the section you
want to repeat, touch “Set B”.
This makes the measure where you touched “Set B” the
“end measure”.
• You can also make fine adjustments to the end point.
After touching “Measure”, “Beat”, or “Tick” for Point
B, you can then use the bs w, q buttons to adjust.
4.
Touch “A-B Repeat” to enable repeat
playback.
This starts repeat playback of the specified section.
5.
To disable repeat playback, touch “A-B
Repeat” again, which will return to normal
playback.
• To clear the start measure and end measure settings,
touch “Reset A-B”.
To adjust the Balance between Playback
and Keyboard Volume (MIDI Volume)
To repeat playback of a specific section
(Repeat)
Beginning End
Repeated measures
PX360-ES-1A.indd 45 2015/04/24 12:46:48
EN-44
Recording and Playback
1.
On the MENU screen, touch “MIDI
RECORDER”.
2.
Touch the data name.
3.
Touch “User Data Edit”.
4.
Touch “Rename”.
5.
Touch the data you want to rename.
6.
Input the new name.
7.
After you are finished inputting the name,
touch “Enter”.
8.
Touch “Yes”.
• To cancel the rename operation, touch “No”.
1.
On the MENU screen, touch “MIDI
RECORDER”.
2.
Touch the data name.
3.
Touch “User Data Edit”.
4.
Touch “Copy”.
5.
Touch the data you want to copy.
6.
Touch “Execute”.
7.
Touch “Yes”.
• To cancel the copy operation, touch “No”.
1.
On the MENU screen, touch “MIDI
RECORDER”.
2.
Touch the data name.
3.
Touch “User Data Edit”.
4.
Touch “Delete”.
5.
Touch the data you want to delete.
6.
Touch “Execute”.
7.
Touch “Yes”.
This deletes the MIDI data you selected.
• To cancel the delete operation, touch “No”.
1.
On the MENU screen, touch “MIDI
RECORDER”.
2.
Touch “Monitor”.
3.
Touch “Edit”.
4.
Touch “Rename”.
5.
Touch the track you want to rename.
6.
Input the new name.
7.
After you are finished inputting the name,
touch “Execute”.
8.
Touch “Yes”.
• To cancel the rename operation, touch “No”.
To rename recorded MIDI data
To copy recorded MIDI data
To delete recorded data
To rename a track
PX360-ES-1A.indd 46 2015/04/24 12:46:48
Recording and Playback
EN-45
English
1.
On the MENU screen, touch “MIDI
RECORDER”.
2.
Touch “Monitor”.
3.
Touch “Edit”.
4.
Touch “Copy”.
5.
In the “Source” list, touch the track you want
to copy.
6.
In the “Destination” list, touch the destination
track.
7.
Touch “Execute”.
8.
Touch “Yes”.
• To cancel the copy operation, touch “No”.
1.
On the MENU screen, touch “MIDI
RECORDER”.
2.
Touch “Monitor”.
3.
Touch “Edit”.
4.
Touch “Clear”.
5.
Touch the track you want to clear.
6.
Touch “Execute”.
7.
Touch “Yes”.
• To cancel the delete operation, touch “No”.
Anything played on the Digital Piano is recorded to the
USB flash drive as audio data (WAV files*). If you play
along on the Digital Piano as you play back data stored
in Digital Piano memory, the memory playback and
your keyboard play are both recorded to USB flash
drive.
* Linear PCM, 16bit, 44.1 kHz, Stereo
• Each new recording of audio data to a USB flash
drive is automatically assigned a new file name, so
existing data is not overwritten.
• Never remove the USB flash drive while Audio
Recorder recording or playback is in progress. Doing
so can corrupt the data on the USB flash drive and
damage the USB flash drive port.
PREPARATION
• Be sure to format the USB flash drive on the Digital
Piano before using it. See “USB Flash Drive” on page
EN-56 for more information.
1.
Insert the USB flash drive into the Digital
Piano’s USB flash drive port.
• When you perform a USB flash drive operation or
turn on the Digital Piano while a USB flash drive is
plugged in, the Digital Piano initially needs to
perform a “mounting” sequence to prepare for data
exchange with the USB flash drive. Digital Piano
operations may be momentarily disabled while a
mounting sequence is being performed. While the
mounting process is in progress, the message “Media
Mounting” will be displayed on the display. It may
take up to 10 or 20 seconds or even longer for a USB
flash drive to be mounted. Do not attempt to perform
any operation on the Digital Piano while a mounting
sequence is in progress. A USB flash drive needs to be
mounted each time it is connected to the Digital
Piano.
2.
On the MENU screen, touch “AUDIO
RECORDER”.
To copy one track to another
To clear a track
Recording to a USB Flash
Drive (Audio Recorder)
To record keyboard play to a USB flash
drive
PX360-ES-1A.indd 47 2015/04/24 12:46:48
EN-46
Recording and Playback
3.
Touch “0”.
This turns on the recorder and enters recording mode.
• Each touch of “0“ cycles through modes as shown
below.
Playback mode
Recording mode
4.
Start playing something on the keyboard.
This will cause recording to the USB flash drive to start.
• You can also start recording by touching “X”.
• The 5 AUDIO a button is lit while recording is
in progress.
• Do not remove the USB flash drive from the USB
flash drive port while the 5 AUDIO a button
lamp is lit or flashing. Doing so will interrupt
recording and may corrupt data.
5.
To stop recording, touch “Y”.
• You can also enter the recording mode by pressing
the 3 REC MODE button and then touching
“AUDIO RECORDER”.
1.
On the MENU screen, touch “AUDIO
RECORDER”.
2.
Touch “0” to enter the recording mode.
3.
Touch “X”.
4.
Press the 4 MIDI a button.
• This starts playback of the Digital Piano’s memory
contents. Play along on the keyboard.
5.
To stop recording, touch “Y”.
Unlit
Lit Flashing
To record keyboard play with playback
from Digital Piano memory
Lit Flashing
PX360-ES-1A.indd 48 2015/04/24 12:46:49
Recording and Playback
EN-47
English
1.
On the MENU screen, touch “AUDIO
RECORDER”.
• The above step is not necessary if you are playing
back recorded data immediately after recording it
(while the AUDIO RECORDER screen is displayed).
2.
Touch the file name.
This displays the audio file selection screen.
3.
Touch the song you want to play.
4.
Touch “X”.
This starts playback of the selected song.
• You can also start playback by pressing the 5
AUDIO a button.
• The 5 AUDIO a button is flashing while
playback is in progress.
• The operations below are supported while audio data
is playing back, during playback standby, or while
playback is paused.
Note that rewind (s) and fast forward (d)
operations are supported only during playback.
5.
To stop the song, touch “Y”.
• You can also stop playback by pressing the 5
AUDIO a button.
Files can be deleted one at time.
• The procedure below deletes all of the data of the
selected song. Note that the delete operation cannot
be undone. Check to make sure you really do not
need the data in Digital Piano memory before you
perform the following steps.
1.
On the MENU screen, touch “AUDIO
RECORDER”.
2.
Touch the file name.
3.
Touch “Delete”.
4.
Touch the data you want to delete.
5.
Touch “Execute”.
6.
Touch “Yes”.
This deletes the audio data you selected.
• To cancel the delete operation, touch “No”.
To play along with data recorded on a
USB flash drive
This icon: Does this:
Prev Plays the previous audio data.
Next Plays the next audio data.
Y
W Returns to the beginning of a song.
s Rewinds. A single touch rewinds one
second, holding down performs
continuous rewind.
d Fast forwards. A single touch fast
forwards one second, holding down
performs continuous fast forward.
k Pauses or resumes the currently playing
audio data.
The icon flashes while playback is
paused.
a Starts playback from the beginning of
audio data or stops playback.
0 Toggles between the recording mode and
playback mode.
To delete an audio file from a USB flash
drive
PX360-ES-1A.indd 49 2015/04/24 12:46:49
EN-48
Configuring Digital Piano Settings
On the MENU screen, you can change the selected tone
and rhythm, and also change the keyboard key and
touch settings, pedal and MIDI settings, and more. This
means you can tailor Digital Piano operation to suit
your particular needs.
1.
On the MENU screen, touch the menu for the
settings you want to configure.
2.
Touch the item whose setting you want to
change.
3.
Use the br Dial or the bs w, q buttons to
change the setting.
br
bs
bt
Configuring Digital Piano
Settings
PX360-ES-1A.indd 50 2015/04/24 12:46:49
Configuring Digital Piano Settings
EN-49
English
■ TONE Screen
Use this screen to configure tone and other keyboard settings.
• You can also display the TONE screen by pressing the bt TONE button.
■ RHYTHM Screen
Use this screen to configure Auto Accompaniment settings. See “Using Auto Accompaniment” (page EN-20) for
more information.
Item Description Setting
Upper 1, Upper 2,
Lower 1, Lower 2
Turns each part on or off, and specifies its tone. Off, On
Octave Change the range of each part in octave units. –2 to 0 to 2
Auto Harmonize See page EN-24. Off, On
Duet See page EN-16. Off, On
Split See page EN-15. Off, On
PX360-ES-1A.indd 51 2015/04/24 12:46:49
EN-50
Configuring Digital Piano Settings
■ BALANCE Screen
Use this screen to adjust volume settings for the keyboard, Auto Accompaniment, etc.
Item Description Setting
Upper 1 Volume See page EN-17. 0 to 127
Upper 2 Volume See page EN-17. 0 to 127
Lower 1 Volume See page EN-17. 0 to 127
Lower 2 Volume See page EN-17. 0 to 127
Keyboard Volume Adjusts the volume levels of all parts that are controlled by the keyboard. 0 to 127
Accomp Volume Adjusts the volume level of the Auto Accompaniment without changing the
keyboard tone volume level.
0 to 127
MIDI Volume Adjusts the volume level of the MIDI data without changing the keyboard
tone volume level.
0 to 127
Audio Volume Adjusts the volume level of audio data stored on a USB flash drive. 0 to 127
Line In Volume Adjusts the volume of LINE IN terminal input. 0 to 127
Metronome Volume See page EN-18. 0 to 127
PX360-ES-1A.indd 52 2015/04/24 12:46:49
Configuring Digital Piano Settings
EN-51
English
■ EFFECT Screen
Use this screen to apply variety of acoustic effects to notes.
■ MIDI RECORDER Screen
Use this screen to record a performance to Digital Piano memory and to play back recordings. For more
information, see “Recording to Digital Piano Memory (MIDI Recorder)” (page EN-38).
■ AUDIO RECORDER Screen
Use this screen to record a performance on a commercially available USB flash drive, and to play back recorded
audio data on the Digital Piano. For more information, see “Recording to a USB Flash Drive (Audio Recorder)”
(page EN-45).
■ MUSIC PRESET Screen
Music presets provide you with one-touch tone, rhythm, chord, and other settings that are optimized for specific
musical genres and songs. In addition to built-in presets, you can create your own original music presets (user
presets). For more information, see “Music Presets” (page EN-28).
Item Description Setting
Brilliance Controls the brilliance of the tone. –3 to 0 to +3
Reverb Type Specifies the type of reverb to be
applied.
Room1, Room2, Room3, Hall1, Hall2, Hall3, Plate1, Plate2,
Plate3, Delay, Pan Delay, Large Room1, Large Room2,
Stadium1, Stadium2, Long Delay1, Long Delay2
Chorus Type Specifies the type of chorus to be
applied.
Chorus1, Chorus2, Chorus3, Chorus4, FB Chorus, Flanger1,
Flanger2, Flanger3, Flanger4, Short Delay1, Short Delay2,
Short Delay3, Short Delay4, Soft Chorus, Bright Chorus,
Deep Chorus
Delay Type Selects the delay type. Short 1, Short 2, Echo, Short Tempo, Mid Tempo, Long Tempo
Hammer Response Controls the time deviation
between when a key is pressed
and the note actually sounds.
1 to 4: A greater value produces slower timing.
String Resonance Adjusts the string resonance that
is characteristic of an acoustic
piano.
1 to 4: A larger value increases the resonance level.
PX360-ES-1A.indd 53 2015/04/24 12:46:50
EN-52
Configuring Digital Piano Settings
■ SYSTEM SETTING Screen
Use this screen to configure global Digital Piano settings.
Item Description Setting
Speaker Specifies whether sound should be output from the Digital Piano
speakers (On) or muted (Off).
Off, On
Touch Response Adjusts keyboard touch Off: Disabled
Light: Strong sound even
with light pressure
Normal: Normal key
touch
Heavy: Normal sound
even with strong pressure
Touch Off Velocity Specifies the velocity value when the Touch Response setting is Off. 0 to 127
Metronome Beat Specifies the number of metronome beats per measure. 0 to 9
Accomp Freeze You can use Accomp Freeze to specify accompaniment settings that
should be left unchanged whenever a registration setup is applied.
For details, see “Parameter List” (page A-14).
Off, On
Tuning Raises or lowers the overall pitch of the Digital Piano from the
standard pitch of A4 = 440 Hz in 0.1Hz units.
415.5Hz to 440.0Hz to
465.9Hz
Temperament Changes the temperament of the keyboard and Auto
Accompaniment from the standard equal temperament to another
tuning more suitable for playing classics, Arabian music, etc.
Equal, Pure Major,
Pure Minor, Pythagorean,
Kirnberger 3,
Werckmeister,
Mean-Tone, Rast, Bayati,
Hijaz, Saba, Dashti,
Chahargah, Segah,
Gurjari Todi,
Chandrakauns,
Charukeshi
Temperament Base Note Pressing a keyboard key makes the pressed key the root of the
temperament.
C to B (12 types)
Acmp Temperament Turn this setting off to play Auto Accompaniment using standard
equal temperament, regardless of the current scale setting selected
with the Temperament Base Note parameter above.
Off, On
Stretch Tuning Sharpens high notes and flattens low notes to achieve stretch tuning.
This type of tuning is called “stretch tuning”.
Turn off this setting to play with normal (non-stretch) tuning.
Off, On
Brightness Use this item to adjust display brightness. 1 to 13
N. Gate Thresh Cuts LINE IN terminal input sound that is below a preset level,
which reduces noise. A larger setting value raises the sound cutoff
level.
1, 2, 3
Operation Lock When this setting is turned on, the Digital Piano’s buttons (except
for the 1 P button and buttons required for unlock) are locked, so
no operation can be performed. Turn on operation lock when you
want to protect against unintentional button and control panel
operations.
Off, On
PX360-ES-1A.indd 54 2015/04/24 12:46:50
Configuring Digital Piano Settings
EN-53
English
■ CONTROLLER Screen
Use this to configure pedal and pitch bend wheel settings.
Auto Resume When “On” is selected for this setting, the Digital Piano will
remember its settings whenever it is turned off, and restore them
when it is turned on again.
When “Off” is selected, settings are reset to their initial defaults
whenever the Digital Piano is turned on.
Off, On
Auto Power Off Specifies if Auto Power Off (page EN-7) is enabled (On) or disabled
(Off).
Off, On
Factory Reset Use this screen to return the piano’s stored data and settings to their
initial factory defaults.
–
Item Description Setting
Pedal Assign Specifies whether the pedal connected to the ASSIGNABLE PEDAL jack is a
soft pedal or a sostenuto pedal.
• See page EN-8 for details about the two pedal types.
Sostenuto, Soft
Upper1 Pedal Turn on to apply the pedal effect to the main tone when the pedal is
depressed.
Off, On
Upper2 Pedal Turn on to apply the pedal effect to the layered tone when the pedal is
depressed.
Off, On
Lower1 Pedal Turn on to apply the pedal effect to the split (main) tone when the pedal is
depressed.
Off, On
Lower2 Pedal Turn on to apply the pedal effect to the split (layered) tone when the pedal is
depressed.
Off, On
Bend Range Specifies (in semitone units) how much the pitch of the keyboard
performance parts (Port A parts 1 through 5) changes when the pitch bend
wheel is rotated all the way upwards or downwards.
00 to 24
Item Description Setting
PX360-ES-1A.indd 55 2015/04/24 12:46:50
EN-54
Configuring Digital Piano Settings
■ MIXER Screen
Use this screen to change the tone of each part, and to adjust its volume and reverb.
Item Meaning Setting
Part A part that is turned on is sounded. Turn off parts you do not want to sound. Off, On
Tone Changes the tone. 550
Volume Adjusts the volume. The volume level of each part is shown by an on-screen
level meter.
0 to 127
Pan Specifies the stereo pan position of the sound output by the Digital Piano. 0
indicates the center, while a smaller values shifts to the left and a larger value
shifts to the right.
–64 to 0 to +63
Coarse Tune Specifies, in semitone steps, the pitch of the notes of each part. –24 to 0 to +24
Fine Tune Specifies, in cent steps, the pitch of the notes of each part. –99 to 0 to +99
Bend Range Adjusts, in semitone steps, the bend range of each part. 0 to 24
Reverb Send Specifies how much reverb is applied to each part.
No reverb is applied at all when this setting is 0, while maximum reverb is
applied when it is 127.
0 to 127
Chorus Send Specifies how much chorus is applied to each part.
No chorus is applied at all when this setting is 0, while maximum chorus is
applied when it is 127.
0 to 127
Delay Send Specifies how much delay is applied to each part.
No delay is applied at all when this setting is 0, while maximum delay is
applied when it is 127.
0 to 127
Port Specifies the port. For information about MIDI channels assigned to each
port, see “Part and MIDI Channel Assignments” (page A-17).
Port A, Port B,
Port C
Level meter
PX360-ES-1A.indd 56 2015/04/24 12:46:50
Configuring Digital Piano Settings
EN-55
English
■ MIDI Screen
Use this screen to configure MIDI settings.
For information about MIDI channels assigned to each port, see “Part and MIDI Channel Assignments” (page A-17).
■ MEDIA Screen
Use this screen to save data to a USB flash drive inserted in the Digital Piano and to import data from a USB flash
drive to Digital Piano memory. For more information, see “USB Flash Drive” (page EN-56).
Item Description Setting
Keyboard Channel Selects the channel for sending keyboard play MIDI data to an external
device (keyboard channel).
01 to 16
Accomp Out Turn on this setting to send MIDI data corresponding to Auto
Accompaniment to an external device.
Off, On
Chord Judge Select whether Chord input should be performed when a MIDI note on
message to the Auto Accompaniment chord keyboard is received.
Off, On
Hi-Res Vel Out Turns high-resolution velocity MIDI out on or off. Off, On
Local Control Selecting “Off” for Local Control cuts off the Digital Piano’s sound source, so
no sound is produced by the Digital Piano when keys are pressed.
Off, On
MIDI Out/Thru Specifies either Out or Thru as the MIDI OUT terminal function. Out, Thru
MIDI In Port Select the port to be used for input from the MIDI In. A, B, C
PX360-ES-1A.indd 57 2015/04/24 12:46:50
EN-56
USB Flash Drive
Your Digital Piano supports the following USB flash
drive operations.
z USB flash drive formatting
z Data storage to a USB flash drive
z USB flash drive data loading to Digital Piano
memory
z Delete data from a USB flash drive
z Easy play back of song data from a USB flash drive
■ Types of Data
* Your Digital Piano also supports import of rhythm
data created on another device. Supported file name
extensions are: ac7, z00, and ckf.
• Be sure to observe the precautions provided in the
documentation that comes with the USB flash drive.
• Avoid using a USB flash drive under the following
conditions. Such conditions can corrupt data stored
on the USB flash drive.
• Areas subjected to high temperature, high
humidity, or corrosive gas
• Areas subjected to strong electrostatic charge and
digital noise
• Never remove the USB flash drive while data is
being written to or loaded from it. Doing so can
corrupt the data on the USB flash drive and damage
the USB flash drive port.
• Never insert anything besides a USB flash drive into
the USB flash drive port. Doing so creates the risk of
malfunction.
• A USB flash drive can become warm after very long
use. This is normal and does not indicate
malfunction.
• Static electricity conducted to the USB flash drive
port from your hand or from a USB flash drive can
cause malfunction of the Digital Piano. If this
happens, turn the Digital Piano off and then back on
again.
• Song data recorded with the Digital Piano’s MIDI
recorder is stored on a USB flash drive as-is or
stored as a MIDI file (SMF format 0).
• Standard audio data from a computer (WAV files)
can also be stored on a USB flash drive and
played back on the Digital Piano.
• Digital Piano play can be recorded directly to a
USB flash drive.
For details, see “Recording to a USB Flash Drive
(Audio Recorder)” (page EN-45).
• Storage of edited Auto Accompaniment data on a
USB flash drive
• MIDI files and CASIO format files stored on a
USB flash drive can be loaded into the Digital
Piano memory (page EN-42).
Data Type
Description
(File Name Extension)
Supported
Operations
Save to
USB
Flash
Drive
Load
from USB
Flash
Drive
User
rhythms*
(page EN-24)
Auto Accompaniment
data edited with this
Digital Piano (AC7)
OO
User MIDI
data (pages
EN-42,
EN-36)
One of the following
two types of music data
1. Standard MIDI files
(MID)
SMF Format 0 or
Format 1
2. MIDI data recorded
on this Digital Piano
(ZMF)
OO
User Music
Presets (page
EN-29)
Music Preset data edited
on this Digital Piano
(ZMP)
OO
Registration
(page EN-34)
Tone and rhythm setup
settings (ZRM)
OO
USB Flash Drive and USB Flash Drive Port
Handling Precautions
Copyrights
You are allowed to use recordings for your own
personal use. Any reproduction of an audio or music
format file, without the permission of its copyright
holder, is strictly prohibited under copyright laws
and international treaties. Also, making such files
available on the Internet or distributing them to third
parties, regardless of whether such activities are
conducted with or without compensation, is strictly
prohibited under copyright laws and international
treaties. CASIO COMPUTER CO., LTD. shall not be
held in any way liable for any use of this Digital
Piano that is illegal under copyright laws.
PX360-ES-1A.indd 58 2015/04/24 12:46:50
USB Flash Drive
EN-57
English
• Never plug any other device besides a USB flash
drive into the USB flash drive port.
• When you perform a USB flash drive operation or
turn on the Digital Piano while a USB flash drive is
plugged in, the Digital Piano initially needs to
perform a “mounting” sequence to prepare for data
exchange with the USB flash drive. Digital Piano
operations may be momentarily disabled while a
mounting sequence is being performed. While the
mounting process is in progress, the message
“Media Mounting” will be displayed. It may take up to
10 or 20 seconds or even longer for a USB flash
drive to be mounted. Do not attempt to perform any
operation on the Digital Piano while a mounting
sequence is in progress. A USB flash drive needs to
be mounted each time it is connected to the Digital
Piano.
■ To insert a USB flash drive
1.
As shown in the illustration below, insert the
USB flash drive into the Digital Piano’s USB
flash drive port.
• Carefully push the USB flash drive in as far as it will
go. Do not use undue force when inserting the USB
flash drive.
■ To remove a USB flash drive
1.
Check to confirm that there is no data
exchange operation being performed, and
then pull the USB flash drive straight out.
• Be sure to format a USB flash drive on the Digital
Piano before using it for the first time.
• Before formatting a USB flash drive, make sure it
does not have any valuable data stored on it.
• The format operation performed by this Digital Piano
is a “quick format”. If you want to completely delete
all of the data in USB flash drive, format it on your
computer or some other device.
Supported USB Flash Drives
This Digital Piano supports USB flash drives formatted
to FAT32. If your USB flash drive is formatted to a
different file system, use the Windows format function
to reformat it to FAT32. Do not use quick format.
1.
Insert the USB flash drive to be formatted into
the Digital Piano’s USB flash drive port.
2.
On the MENU screen, touch “MEDIA”.
3.
Touch “FORMAT”.
This displays a confirmation message (“Sure?”).
4.
Touch “Yes”.
• The message “Please Wait” remains on the display
while the operation is being performed. Do not
perform any operation while this message is on the
display. “Complete” appears on the display after
formatting is complete.
• To cancel the format operation, touch “No”.
Even when the file format is WAV (general audio data)
or SMF (standard MIDI file), the procedure below can
be used to save data to USB flash drive and play it back
on the Digital Piano.
1.
Connect the USB flash drive to your
computer.
2.
Move the song data file you want to play back
to the MUSICDAT folder on the USB flash
drive.
• For information about playback see “To play along
with data recorded on a USB flash drive” (page
EN-47).
Connecting a USB Flash Drive
to and Detaching It from the
Digital Piano
USB flash drive
USB flash drive port
Formatting a USB Flash Drive
Saving Standard Song Data to
a USB Flash Drive
PX360-ES-1A.indd 59 2015/04/24 12:46:51
EN-58
USB Flash Drive
Digital Piano memory data (MIDI recorder songs) can
be saved to a USB flash drive.
• MIDI Recorder songs can be converted to standard
MIDI (SMF) files and stored on the USB flash drive.
• During recording of an Audio Recorder song, the
data is stored directly to the USB flash drive, so the
operation below is not required.
1.
Insert the USB flash drive into the Digital
Piano’s USB flash drive port.
2.
On the MENU screen, touch “MEDIA”.
3.
Touch “Save”.
4.
Touch the data type you want to save.
5.
Touch the data you want to save.
6.
Rename the file as required.
7.
After renaming the file, touch “Enter”.
This displays a confirmation message (“Sure?”). If there
already a file with the same name on the USB flash
drive, a confirmation message (“Replace?”) will appear
asking if you want to overwrite it with the new data.
8.
Touch “Yes”.
• The message “Please Wait” remains on the display
while the operation is being performed. Do not
perform any operation while this message is on the
display. “Complete” appears on the display after
data save is complete.
• To cancel the save operation, touch “No”.
You can use the procedure below to load data from a
USB flash drive into Digital Piano memory.
• Place the data (file) you want to load into the
MUSICDAT folder on the USB flash drive.
1.
Insert the USB flash drive into the Digital
Piano’s USB flash drive port.
2.
On the MENU screen, touch “MEDIA”.
3.
Touch “Load”.
4.
Touch the data type of the data you want to
import.
5.
On the “USB” list, touch the data you want to
import.
6.
On the “User Area” list, touch the import
destination you want.
• If you are importing MIDI data, you will not be able
to specify an import destination.
7.
Touch “Execute”.
This displays an import confirmation message
(“Sure?”). If there is already data in the import
destination in Digital Piano memory, a message
(“Replace?”) will appear asking if you want to replace it
with the new data.
8.
Touch “Yes”.
• The message “Please Wait” remains on the display
while the operation is being performed. Do not
perform any operation while this message is on the
display. “Complete” appears on the display after
data import is complete.
• To cancel the import operation, touch “No”.
Saving Digital Piano Data to a
USB Flash Drive
Loading Data from a USB
Flash Drive to Digital Piano
Memory
PX360-ES-1A.indd 60 2015/04/24 12:46:51
USB Flash Drive
EN-59
English
Use the following procedure to delete USB flash drive
data (files).
1.
Insert the USB flash drive into the Digital
Piano’s USB flash drive port.
2.
On the MENU screen, touch “MEDIA”.
3.
Touch “Delete”.
4.
Touch the data type of the data you want to
delete.
5.
Touch the data you want to delete.
6.
Touch “Execute”.
This displays a delete confirmation message (“Sure?”).
7.
Touch “Yes”.
• The message “Please Wait” remains on the display
while the operation is being performed. Do not
perform any operation while this message is on the
display. “Complete” appears on the display after
data delete is complete.
• To cancel the delete operation, touch “No”.
Deleting Data from a USB
Flash Drive
PX360-ES-1A.indd 61 2015/04/24 12:46:51
EN-60
Connecting to a Computer
You can connect the Digital Piano to a computer and
exchange MIDI data between them. You can send play
data from the Digital Piano to commercially available
music software running on your computer, or you can
send MIDI data from your computer to the Digital
Piano for playback.
The following shows the minimum computer system
requirements for sending and receiving MIDI data.
Check to make sure that your computer complies with
these requirements before connecting the Digital Piano
to it.
z
Operating System
Windows Vista
®
*1
Windows
®
7
*2
Windows
®
8
*3
Windows
®
8.1
*4
Mac OS
®
X (10.3.9, 10.4.11, 10.5.X, 10.6.X, 10.7.X, 10.8.X,
10.9.X)
z
USB port
• Never connect to a computer that does not conform
to the above requirements. Doing so can cause
problems with your computer.
• For the latest news about supported operating
systems, visit the website at the URL below.
http://world.casio.com/
• Make sure you follow the steps of the procedure
below exactly. Connecting incorrectly can make data
send and receive impossible.
1.
Turn off the Digital Piano and then start up
your computer.
• Do not start up the music software on your computer
yet!
2.
After starting up your computer, use a
commercially available USB cable to connect
it to the Digital Piano.
3.
Turn on the Digital Piano.
• If this is the first time you are connecting the Digital
Piano to your computer, the driver software required
to send and receive data will be installed on your
computer automatically.
4.
Start up commercially available music
software on your computer.
5.
Configure the music software settings to
select “CASIO USB-MIDI” as the MIDI device.
• For information about how to select the MIDI device,
see the user documentation that comes with the
music software you are using.
• Be sure to turn on the Digital Piano first before
starting up your computer’s music software.
Minimum Computer System
Requirements
*1: Windows Vista (32-bit)
*2: Windows 7 (32-bit, 64-bit)
*3: Windows 8 (32-bit, 64-bit)
*4: Windows 8.1 (32-bit, 64-bit)
To connect the Digital Piano to your
computer
Computer USB port
A connector
B connector
Digital Piano USB port
USB cable
(A-B type)
PX360-ES-1A.indd 62 2015/04/24 12:46:51
Connecting to a Computer
EN-61
English
• Once you are able to connect successfully, there is no
problem with leaving the USB cable connected when
you turn off your computer and/or Digital Piano.
• This Digital Piano conforms to General MIDI Level 1
(GM).
• For detailed specifications and connections that
apply to MIDI data send and receive by this Digital
Piano, see the latest support information provided
by the website at the following URL.
http://world.casio.com/
The letters MIDI stand for Musical Instrument Digital
Interface, which is the name of a worldwide standard
for digital signals and connectors that makes it possible
to exchange musical data between musical instruments
and computers (machines) produced by different
manufacturers.
For details about the MIDI specifications of this Digital
Piano, see the “MIDI Implementation” document at the
website located at the URL below.
http://world.casio.com/
• You can alter the Digital Piano’s MIDI setup by
changing the MIDI data send channel or other
settings. For details, see “MIDI Screen” (page
EN-55).
• Use a separately available or commercially available
MIDI cable to connect the MIDI terminals of your
Digital Piano and another electronic musical
instrument for exchange of MIDI data.
• MIDI terminals are disabled while the Digital Piano
is connected to a computer via the USB port.
Using MIDI
What is MIDI?
PX360-ES-1A.indd 63 2015/04/24 12:46:51
EN-62
Reference
One of the error messages below appears on the display when a problem occurs.
• To clear an error message and return to the normal display, touch bq EXIT on the display.
Error Messages
Display Message Cause Action
No Media 1. The USB flash drive is not connected to the
Digital Piano’s USB flash drive port.
1. Correctly plug the USB flash drive into the USB
flash drive port.
2. The USB flash drive was removed while some
operation was in progress.
2. Do not remove the USB flash drive while any
operation is in progress.
3. The USB flash drive is write-protected. 3. Unprotect the USB flash drive.
4. The USB flash drive has anti-virus software. 4. Use a USB flash drive that does not have anti-
virus software.
No File There is no loadable file or no playable file in the
“MUSICDAT” folder.
Move the file you want to load or play into the
appropriate location (pages EN-57, EN-58) in the
“MUSICDAT” folder.
No Data You are attempting to save user data (user preset,
user rhythm, MIDI data, etc.) when there is no data
to save.
Select a user data item for which there is data to
save.
Read Only A read-only file with the same name you are trying
to use is already stored on USB flash drive.
• Change the name and then save the new data.
• Remove the read-only attribute from the existing
USB flash drive file and overwrite it with the new
data.
• Use a different USB flash drive.
Media Full There is not enough space available on the USB flash
drive.
Delete some of the files on the USB flash drive to
make room for new data (page EN-59) or use a
different USB flash drive.
Too Many Files 1. There are too many files on the USB flash drive. 1. Delete some of the files on the USB flash drive to
make room for new data.
2. There is a file named TAKE99.WAV in the
“MUSICDAT” folder.
2. Delete the WAV file in the “MUSICDAT” folder.
Not SMF01 You are attempting to play back SMF Format 2 song
data.
This Digital Piano supports playback of SMF Format
0 or Format 1 only.
Size Over 1. The MIDI recording data on the USB flash drive
cannot be played because it is too big.
1. The Digital Piano supports playback of MIDI
recording data up to approximately 700KB.
2. The SMF file on the USB flash drive cannot be
played because it is too big.
2. The Digital Piano supports playback of SMF files
up to 320 KB.
3. The data you are trying to import cannot be
imported because it is too big.
3. The Digital Piano supports import of data (per
item) up to the maximum sizes shown below.
User Rhythms: Approximately 32 KB
User Presets: Approximately 6 KB
Wrong Data 1. The USB flash drive data is corrupted. —
2. USB flash drive contains data that is not
supported by this Digital Piano.
Memory Full 1. There is not enough Digital Piano memory
available to convert a MIDI recorder song to SMF
data and store it on the USB flash drive.
1. Reduce the size of the song data.
Example:
Delete any tracks that are not required.
2. There is not enough memory remaining for
rhythm editing operations.
2. Select a different accompaniment pattern.
3. Remaining memory became too low during
music preset editing.
3. The Digital Piano supports input of
approximately 1,000 chords.
Format Error 1. The USB flash drive format is not compatible
with this Digital Piano.
1. Format the USB flash drive on the Digital Piano.
2. The USB flash drive is corrupted. 2. Use a different USB flash drive.
Media Error The USB flash drive is corrupted. Use a different USB flash drive.
Measure Limit Attempting to input MIDI recording data or music
preset that has more than 999 measures.
The Digital Piano supports input of up to 999
measures.
Data Full Attempting to store data that exceeds the maximum
allowable number of data items.
Delete unneeded data.
PX360-ES-1A.indd 64 2015/04/24 12:46:51
Reference
EN-63
English
Troubleshooting
Problem Cause Action
See
Page
No sound is produced when I
press a keyboard key.
1. The VOLUME controller is set to
“MIN”.
1. Rotate the VOLUME controller more
towards “MAX”.
) EN-7
2. Headphones or an adaptor plug is
plugged into one of the PHONES
jacks.
2. Disconnect whatever is connected to the
PHONES jack.
) EN-8
3. Upper 1 icon is off. 3. Touch the Upper 1 icon to turn it on. ) EN-14
4. The “Speaker” SYSTEM
SETTING is off.
4. Turn on the “Speaker” SYSTEM
SETTING.
) EN-52
The pitch of the Digital Piano
is off.
1. Digital Piano tuning is incorrect. 1. Adjust Digital Piano tuning, or turn the
Digital Piano off and then back on again.
) EN-19
2. The Digital Piano’s key setting is
something other than “440.0 Hz”.
2. Change the key setting to “440.0 Hz”, or
turn Digital Piano power off and then
back on again.
) EN-52
3. A non-standard temperament
setting is being used.
3. Change the temperament setting to
“Equal”, which is the standard modern
tuning.
) EN-52
4. Octave shift is enabled. 4. Change the octave shift setting to 0. ) EN-49
Tones and/or effects sound
strange. Turning power off
and then back on again does
not eliminate the problem.
Example:
Note intensity does
not change even though I alter
key pressure.
The “Auto Resume” feature is turned
on.
Turn off “Auto Resume”. Next, turn power
off and then back on again.
) EN-53
I cannot transfer data after
connecting the Digital Piano
to a computer.
— 1. Check to make sure that the USB cable
is connected to the Digital Piano and
computer, and that the correct device is
selected with your computer’s music
software.
) EN-60
2. Turn off the Digital Piano and then exit
the music software on your computer.
Next, turn the Digital Piano back on and
then restart the music software on your
computer.
I cannot record chord
accompaniment data on my
computer.
“Accomp Out” is turned off. Turn on “Accomp Out”. ) EN-55
I cannot store data to a USB
flash drive or load data from a
USB flash drive.
— See “Error Messages”. ) EN-62
Playback stops part way
through while transferring
song data from my computer.
Digital noise from the USB cable or
power cord caused data
communication between your
computer and Digital Piano to be
interrupted.
Stop song playback, disconnect the USB
cable from the Digital Piano, and then
reconnect it. Next, try playing back the song
again.
If this does not solve the problem, quit the
MIDI software you are using, disconnect the
USB cable from the Digital Piano, and then
reconnect it. Next, restart the MIDI software
and then try playing back the song again.
) EN-60
A tone’s quality and volume
sounds slightly different
depending where it is played
on the keyboard.
This is an unavoidable result of the digital sampling process,
*
and does not indicate
malfunction.
* Multiple digital samples are taken for the low range, middle range, and high range of the
original musical instrument. Because of this, there may be a very slight difference in tonal
quality and volume between sample ranges.
PX360-ES-1A.indd 65 2015/04/24 12:46:52
EN-64
Reference
When I press a button, the
note that is sounding cuts out
momentarily or there is a
slight change in how effects
are applied.
Performing a button operation while playing with the Duet Mode, Auto Accompaniment, the
recorder, or other functions can cause such phenomena when the Digital Piano switches
internal tone effects. It does not indicate malfunction.
Even though I play on
different ranges of the
keyboard, the notes do not
change octaves.
The ranges of certain tones are limited, which means that octaves change normally up to a
certain low note or high note. With such a tone, the notes of the lowest octave will be
repeated to the left of the lowest possible note, and the highest octave will be repeated to the
right of the highest possible note. This is due do limitations in the range of the original musical
instrument for each tone, and does not indicate malfunction of the Digital Piano.
Problem Cause Action
See
Page
PX360-ES-1A.indd 66 2015/04/24 12:46:52
Reference
EN-65
English
Product Specifications
Model PX-360MBK
Keyboard Ebony/ivory feel piano keyboard, 88-key piano keyboard
• Velocity resolution: 16,256 maximum
• Layer, Split
• Duet: 4 octaves (–2 to 0 to +2)
• Transpose: 2 octaves (–12 to 0 to +12)
• Octave shift: 4 octaves (–2 to 0 to +2)
Sound Source • Number of Tones: 550
• Maximum polyphony: 128 tones
• Touch Response (3 sensitivity levels, Off)
• Tuning: 415.5 Hz to 440.0 Hz to 465.9 Hz (0.1 Hz units)
• Temperament: Equal temperaments plus 16 other types
• Stretch Tuning: On, Off
Display 5.3-inch touch panel (5.0-inch 528 × 320-dot TFT color LCD)
Acoustic Simulator Linear Morphing, Damper Resonance, Hammer response, String resonance
Effects Reverb (17 types), Chorus (16 types), Delay (6 types), DSP
Auto Accompaniment Data items: 200 preset, 10 user
Music Preset Data items: 305 preset, 50 user
Demo Song 6
MIDI Recorder • Functions: Real-time recording, playback
• Number of Song: 100
• Number of Tracks: 17
• Capacity: Up to approximately 50,000 notes per song
• Recorded Data Protection: Built-in flash memory
• MIDI Recorder Volume Level: Adjustable
Audio Recorder • Real-time recording and playback to USB flash drive*
* Linear PCM, 16bit, 44.1 kHz, stereo .WAV format
• Songs: 100 files
• Approximately 74 minutes maximum recording per file.
• Audio Recorder Volume Level: Adjustable
Registration 96 (4 setups × 24 banks)
Metronome • Beats: 0 to 9
• Tempo Range: 20 to 255
• Metronome Volume Level: Adjustable
Pedals Damper (with half-pedal operation), Soft, Sostenuto
Other Functions • Dedicated piano tone buttons
• Balance adjustment
• Setting backup
• Operation Lock
MIDI 16-channel multi-timbre receive
Pitch Bend Wheel Pitch Bend Range: 00 to 24 semitones
USB Flash Drive • Capacity: 32GB or less recommended
• SMF direct playback, data storage, data loading, USB flash drive format,
audio data playback and storage
Inputs/Outputs • PHONES jacks: Stereo mini jacks × 2
• Pedal Jacks: Standard jacks × 2
• Power: 12V DC
• MIDI OUT/IN terminals
• LINE IN R, L/MONO jacks: Standard jacks × 2
Input impedance: 9.0K
Ω
Input voltage: 200mV
• LINE OUT R, L/MONO jacks: Standard jacks × 2
Output impedance: 2.3KΩ
Output voltage: 1.8V (RMS) MAX
• Audio In: Stereo mini jack
Input impedance: 9.0KΩ
Input voltage: 200mV
• USB port: Type B
• USB flash drive port: Type A
• Pedal connector (for optional SP-33 only)
PX360-ES-1A.indd 67 2015/04/24 12:46:52
EN-66
Reference
• Specifications and designs are subject to change without notice.
Speakers
φ
12cm × 2 +
φ
5cm × 2 (Output 8W + 8W)
Power Requirements AC Adaptor: AD-A12150LW
• Auto Power Off: Approximately 4 hours after last operation. Auto Power Off can be disabled.
Power Consumption 12V = 10W
Dimensions 132.2 (W) × 29.3 (D) × 13.9 (H) cm (52
1
/
16
× 11
9
/
16
× 5
1
/
2
inch)
Weight approximately 11.9kg (26.2 lbs)
PX360-ES-1A.indd 68 2015/04/24 12:46:52
Reference
EN-67
English
Be sure to read and observe the following operating
precautions.
• With a model that has a recording function or other
data storage function, be sure to back up any data
you want to maintain to another medium before
submitting this product for servicing or repair.
Stored data may be accessed or even deleted as part
of servicing or repair procedures.
■ Location
Avoid the following locations for this product.
• Areas exposed to direct sunlight and high humidity
• Areas subjected to temperature extremes
• Near a radio, TV, video deck, or tuner
• The above devices will not cause malfunction of the
product, but the product can cause interference in
the audio or video of a nearby device.
■ User Maintenance
• Never use benzine, alcohol, thinner, or other
chemical agents to clean the product.
• To clean the product or its keyboard, wipe with a
soft cloth moistened in a weak solution of water and
a mild neutral detergent. Wring all excess moisture
from the cloth before wiping.
■ Included and Optional Accessories
Use only accessories that are specified for use with this
product. Use of unauthorized accessories creates the
risk of fire, electric shock, and personal injury.
■ Weld Lines
Lines may be visible on the exterior of the product.
These are “weld lines” that result from the plastic
molding process. They are not cracks or scratches.
■ Musical Instrument Etiquette
Always be aware of others around you whenever using
this product. Be especially careful when playing late at
night to keep the volume at levels that do not disturb
others. Other steps you can take when playing late at
night are closing windows and using headphones.
• Any reproduction of the contents of this manual,
either in part or its entirety, is prohibited. Except for
your own, personal use, any other use of the
contents of this manual without the consent of
CASIO is prohibited under copyright laws.
• IN NO EVENT SHALL CASIO BE LIABLE FOR
ANY DAMAGES WHATSOEVER (INCLUDING,
WITHOUT LIMITATION, DAMAGES FOR LOSS
OF PROFITS, BUSINESS INTERRUPTION, LOSS
OF INFORMATION) ARISING OUT OF THE USE
OF OR INABILITY TO USE THIS MANUAL OR
PRODUCT, EVEN IF CASIO HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
• The contents of this manual are subject to change
without notice.
■ AC Adaptor Handling Precautions
• Use a power outlet that is easily accessible so you
can unplug the AC adaptor when a malfunction
occurs or whenever else you need to do so.
• The AC adaptor is intended for indoor use only. Do
not use it where it might be exposed to splashing or
moisture. Do not place any container, such as a
flower vase, that contains liquid on the AC adaptor.
• Store the AC adaptor in a dry place.
• Use the AC adaptor in an open, well-ventilated area.
• Never cover the AC adaptor with newspaper, a table
cloth, a curtain, or any other similar item.
• Unplug the AC adaptor from the power outlet if you
do not plan to use the Digital Piano for a long time.
• Never try to repair the AC adaptor or modify it in
any way.
• AC adaptor operating environment
Temperature: 0 to 40°C
Humidity: 10% to 90% RH
Output polarity:&
Operating Precautions
PX360-ES-1A.indd 69 2015/04/24 12:46:52
EN-68
Reference
AC Adaptor Handling Precautions
Model: AD-A12150LW
1. Read these instructions.
2. Keep these instructions on hand.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not install near radiators, heat registers, stoves, or any other source of heat (including amplifiers).
8. Use only attachments and accessories specified by the manufacturer.
9. Refer all servicing to qualified service personnel. Servicing is required after any of the following occurs:
when the product is damaged, when the power supply cord or plug is damaged, when liquid is spilled into
the product, when a foreign object falls into the product, when the product is exposed to rain or moisture,
when the product does not operate normally, when the product is dropped.
10. Do not allow the product to be exposed to dripping or splashing liquid. Do not place any object containing
liquid on the product.
11. Do not allow the electrical load output to exceed the label rating.
12. Make sure the surrounding area is dry before plugging into a power source.
13. Make sure the product is oriented correctly.
14. Unplug the product during lightning storms or when you do not plan to use it for a long time.
15. Do not allow product ventilation openings to become blocked. Install the product in accordance with the
manufacturer’s instructions.
16. Take care the power cord is located where it will not be stepped upon or bent severely, particularly in
locations close to plugs and convenience receptacles, and in locations where it exits from the product.
17. The AC adaptor should be plugged into a power outlet as close to the product as possible to allow
immediate disconnection of the plug in case of emergency.
The symbol below is an alert indicating un-insulated hazardous voltage inside the product’s enclosure, which
may be sufficient to constitute the risk of electric shock to users.
’
The symbol below is an alert indicating the presence of important operating and maintenance (servicing)
instructions in the documentation that accompanies the product.
*
PX360-ES-1A.indd 70 2015/04/24 12:46:52
Reference
EN-69
English
STLport
Copyright 1994 Hewlett-Packard Company
Copyright 1996,97 Silicon Graphics Computer Systems, Inc.
Copyright 1997 Moscow Center for SPARC Technology.
Permission to use, copy, modify, distribute and sell this software and
its documentation for any purpose is hereby granted without fee,
provided that the above copyright notice appear in all copies and that
both that copyright notice and this permission notice appear in
supporting documentation. Hewlett-Packard Company makes no
representations about the suitability of this software for any
purpose. It is provided "as is" without express or implied warranty.
Permission to use, copy, modify, distribute and sell this software and
its documentation for any purpose is hereby granted without fee,
provided that the above copyright notice appear in all copies and that
both that copyright notice and this permission notice appear in
supporting documentation. Silicon Graphics makes no representations
about the suitability of this software for any purpose. It is provided
"as is" without express or implied warranty.
Permission to use, copy, modify, distribute and sell this software and
its documentation for any purpose is hereby granted without fee,
provided that the above copyright notice appear in all copies and that
both that copyright notice and this permission notice appear in
supporting documentation. Moscow Center for SPARC Technology makes no
representations about the suitability of this software for any
purpose. It is provided "as is" without express or implied warranty.
PX360-ES-1A.indd 71 2015/04/24 12:46:52
A-1
Appendix/Apéndice
Tone List/Lista de tonos
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
Piano
001 GRAND PIANO CONCERT 0 2
002 GRAND PIANO BRIGHT 1 2
003 GRAND PIANO STUDIO 0 3 O
004 GRAND PIANO MODERN 0 4 O
005 ROCK PIANO 1 3 O
006 LA PIANO 1 4 O
007 DANCE PIANO 1 1 5
008 DANCE PIANO 2 1 6 O
009 GRAND PIANO MELLOW 0 5 O
010 MONO PIANO 1 0 6
011 MONO PIANO 2 0 7 O
012 TACK PIANO 0 8 O
013 GRAND PIANO CLASSIC 0 9
014 GRAND PIANO DOLCE 0 10 O
015 HONKY-TONK 3 2
016 OCTAVE PIANO 3 3
017 STRINGS PIANO 0 11 O
018 SYNTH-STR.PIANO 0 12
019 PIANO PAD 0 13
020 CHOIR PIANO 0 14
021 PIANO CHIME 0 15
022 ELEC.GRAND PIANO 2 2
023 MODERN E.G.PIANO 2 3
024 CHORUS E.G.PIANO 2 4 O
025 OFF VELO.HARPSICHORD 6 2 O
026 HARPSICHORD 6 3
027 COUPLED HARPSICHORD 6 4 O
028 HARPSICHORD & STRINGS 6 5
Elec.Piano
001 AiR ELEC.PIANO 1 4 2
002 AiR ELEC.PIANO 2 4 3
003 AiR ELEC.PIANO 3 4 4
004 AiR ELEC.PIANO 4 4 5 O
005 AiR ELEC.PIANO 5 4 6 O
006 AiR 60'S E.PIANO 1 4 7
007 AiR 60'S E.PIANO 2 4 8
008 AiR 60'S E.PIANO 3 4 9 O
009 AiR 60'S E.PIANO 4 4 10 O
010 ELEC.PIANO 1 4 11
011 ELEC.PIANO 2 4 12
012 ELEC.PIANO 3 4 13
013 ELEC.PIANO 4 4 14
014 ELEC.PIANO 5 4 15
015 DIGITAL E.PIANO 1 5 2
016 DIGITAL E.PIANO 2 5 3
017 DIGITAL E.PIANO 3 5 4
018 DIGITAL E.PIANO 4 5 5
019 DIGITAL E.PIANO 5 5 6
020 DIGITAL E.PIANO 6 5 7
021 DIGITAL E.PIANO 7 5 8
022 DIGITAL E.PIANO 8 5 9
023 DIGITAL E.PIANO 9 5 10
024 DYNO ELEC.PIANO 1 4 16
025 DYNO ELEC.PIANO 2 4 17 O
026 60'S ELEC.PIANO 1 4 18 O
027 60'S ELEC.PIANO 2 4 19 O
028 CHORUS E.PIANO 1 4 20
029 CHORUS E.PIANO 2 4 21
030 PHASER E.PIANO 1 4 22 O
031 PHASER E.PIANO 2 4 23 O
032 AMP E.PIANO 1 4 24 O
033 AMP E.PIANO 2 4 25 O
034 CRUNCH E.PIANO 4 26 O
035 DIZZY E.PIANO 4 27 O
036 ANALOG E.PIANO 1 5 11 O
037 ANALOG E.PIANO 2 5 12 O
038 OFF VELO.CLAVI 1 7 2
039 OFF VELO.CLAVI 2 7 3
040 CLAVI 1 7 4
041 CLAVI 2 7 5
042 CLAVI 3 7 6
043 CLAVI 4 7 7
044 WAH CLAVI 1 7 8 O
045 WAH CLAVI 2 7 9 O
046 CRUNCH CLAVI 7 10 O
047 VIBRAPHONE 1 11 2 O
048 VIBRAPHONE 2 11 3
049 MARIMBA 12 2
050 CELESTA 8 2
051 BRIGHT CELESTA 8 3 O
052 GLOCKENSPIEL 9 2
053 MUSIC BOX 1 10 2
054 MUSIC BOX 2 10 3 O
055 XYLOPHONE 13 2
056 TUBULAR BELL 14 2
057 DULCIMER 15 2
Organ
001 DRAWBAR ORGAN 1 16 2 O
002 DRAWBAR ORGAN 2 16 3
003 DRAWBAR ORGAN 3 16 4
004 DRAWBAR ORGAN 4 16 5
005 JAZZ ORGAN 1 17 2
006 JAZZ ORGAN 2 17 3 O
007 JAZZ ORGAN 3 17 4
008 PERC.ORGAN 1 17 5 O
009 PERC.ORGAN 2 17 6 O
010 PERC.ORGAN 3 17 7 O
011 ROCK ORGAN 1 18 2 O
012 ROCK ORGAN 2 18 3
013 ROCK ORGAN 3 18 4
014 ELEC.ORGAN 1 16 6 O
015 ELEC.ORGAN 2 16 7 O
016 ELEC.ORGAN 3 16 8
017 70'S ORGAN 17 8 O
018 OVERDRIVE ORGAN 1 16 9 O
019 OVERDRIVE ORGAN 2 16 10 O
020 TREMOLO ORGAN 16 11 O
021 FULL DRAWBAR 16 12
022 ROTARY ORGAN 17 9
023 CLICK ORGAN 17 10 O
024 SEQUENCE ORGAN 17 11
025 GOSPEL ORGAN 17 12 O
026 PIPE ORGAN 1 19 2
027 PIPE ORGAN 2 19 3
028 CHAPEL ORGAN 19 4
029 THEATER ORGAN 16 13
030 REED ORGAN 20 2
031 ACCORDION 1 21 2
032 ACCORDION 2 21 3
033 ACCORDION 3 21 4
034 BANDONEON SOLO 23 4
035 BANDONEON 1 23 2
036 BANDONEON 2 23 3
037 HARMONICA 1 22 2
038 HARMONICA 2 22 3
Guitar
001 NYLON STR.GUITAR 1 24 2
002 NYLON STR.GUITAR 2 24 3
003 NYLON STR.GUITAR 3 24 4 O
004 STEEL STR.GUITAR 1 25 2
005 STEEL STR.GUITAR 2 25 3
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
PX360-ES-1A.indd 142 2015/04/24 12:47:09
Appendix/Apéndice
A-2
006 STEEL STR.GUITAR 3 25 4
007 12 STR.GUITAR 25 5
008 STEEL GT HARMONICS 31 2
009 JAZZ GUITAR 26 2 O
010 OCT JAZZ GUITAR 26 3
011 CLEAN GUITAR 1 27 2 O
012 CLEAN GUITAR 2 27 3 O
013 CLEAN GUITAR 3 27 4 O
014 CLEAN GUITAR 4 27 5
015 CHORUS CLEAN GUITAR 1 27 6 O
016 CHORUS CLEAN GUITAR 2 27 7 O
017 CRUNCH ELEC.GUITAR 1 27 8 O
018 CRUNCH ELEC.GUITAR 2 27 9 O
019 CRUNCH ELEC.GUITAR 3 27 10 O
020 CHORUS CRUNCH GUITAR 27 11 O
021 MUTE GUITAR 1 28 2
022 MUTE GUITAR 2 28 3
023 MUTE DIST.GUITAR 28 4 O
024 OVERDRIVE GUITAR 1 29 2 O
025 OVERDRIVE GUITAR 2 29 3 O
026 DISTORTION GT 1 30 2 O
027 DISTORTION GT 2 30 3 O
028 DISTORTION GT 3 30 4 O
029 DISTORTION GT 4 30 5 O
030 STEEL GT + STRUM.NOISE M 1 25 32
031 STEEL GT + STRUM.NOISE M 2 25 33
032 STEEL GT + STRUM.NOISE M 3 25 34
033 CLEAN GUITAR M 27 32
034 CRUNCH E.GUITAR M 1 27 33
035 CRUNCH E.GUITAR M 2 27 34
036 DISTORTION GT M 30 32
037 OVERDRIVE GT M 1 29 32
038 OVERDRIVE GT M 2 29 33
039 MUTE OVERDRIVE GT M 1 28 32
040 MUTE OVERDRIVE GT M 2 28 33
Bass
001 ACOUSTIC BASS 1 32 2
002 ACOUSTIC BASS 2 32 3 O
003 RIDE BASS 32 4
004 FINGERED BASS 1 33 2
005 FINGERED BASS 2 33 3 O
006 FINGERED BASS 3 33 4
007 FINGERED BASS 4 33 5
008 PICKED BASS 1 34 2
009 PICKED BASS 2 34 3
010 SYNTH-BASS 1 38 2
011 SYNTH-BASS 2 38 3 O
012 SYNTH-BASS 3 38 4 O
013 SYNTH-BASS 4 39 2
014 SYNTH-BASS 5 39 3 O
015 SYNTH-BASS 6 39 4 O
016 TRANCE BASS 38 5
017 ORGAN BASS 39 5
018 FINGERED BASS M 1 33 32
019 FINGERED BASS M 2 33 33
020 SAW SYNTH-BASS M 39 32
021 SYNTH-BASS M 1 38 32
022 SYNTH-BASS M 2 38 33
Strings
001 STEREO STRINGS 1 49 2
002 STEREO STRINGS 2 48 2
003 STEREO STRINGS 3 48 3
004 WIDE STRINGS 48 4
005 STRINGS 48 5
006 STRING ENSEMBLE 1 48 6
007 STRING ENSEMBLE 2 48 7
008 SLOW STRINGS 49 3
009 BRIGHT STRINGS 48 8 O
010 WARM STRINGS 48 9
011 PIZZICATO STRINGS 45 2
012 CHAMBER 48 10
013 OCTAVE STRINGS 48 11
014 ORCHESTRA PAD 48 12
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
015 SYNTH-STRINGS 1 50 2 O
016 SYNTH-STRINGS 2 50 3
017 SYNTH-STRINGS 3 51 2
018 70'S SYNTH-STR. 50 4
019 80'S SYNTH-STR. 50 5
020 FAST SYNTH-STRINGS 50 6
021 SLOW SYNTH-STRINGS 50 7
022 PHASER SYNTH-STRINGS 50 8 O
023 OCTAVE SYNTH-STRINGS 51 3
024 VIOLIN 40 2
025 SLOW VIOLIN 40 3
026 VIOLA 41 2
027 CELLO 42 2
028 SLOW CELLO 42 3
029 CONTRABASS 43 2
030 HARP 46 2
031 VIOLIN SECTION 48 13
032 HARP & STRINGS 49 4
033 CHOIR AAHS 52 2
034 CHOIR STRINGS 52 3
035 STRINGS VOICE 52 4
036 SLOW CHOIR 52 5
037 WAH CHOIR 52 6 O
038 VOICE DOO 53 2
039 SYNTH-VOICE 1 54 2
040 SYNTH-VOICE 2 54 3
041 VOICE ENSEMBLE 54 4
042 SYNTH-VOICE PAD 54 5
043 CHORUS SYNTH-VOICE 54 6 O
044 ORCHESTRA HIT 1 55 2
045 ORCHESTRA HIT 2 55 3 O
Brass
001 STEREO BRASS 61 2 O
002 BRASS 61 3
003 BRASS SECTION 1 61 4
004 BRASS SECTION 2 61 5
005 HARD BRASS 61 6
006 BRASS SFZ 61 7
007 BRASS & SAX 61 8
008 SYNTH-BRASS 1 62 2
009 SYNTH-BRASS 2 63 2
010 SYNTH-BRASS 3 62 3
011 WARM SYNTH-BRASS 62 4
012 ANALOG SYNTH-BRASS 62 5
013 80'S SYNTH-BRASS 62 6
014 TRANCE BRASS 63 3
015 CHORUS SYNTH-BRASS 62 7 O
016 SYNTH-BRASS PAD 63 4
017 TRUMPET 1 56 2 O
018 TRUMPET 2 56 3
019 MELLOW TRUMPET 56 4
020 VELO.TRUMPET 56 5
021 MUTE TRUMPET 59 2
022 TROMBONE 57 2
023 VELO.TROMBONE 57 3
024 JAZZ TROMBONE 57 4
025 FRENCH HORN 60 2
026 FRENCH HORN SECTION 60 3
027 TUBA 58 2
Reed
001 ALTO SAX 65 2 O
002 BREATHY ALTO SAX 65 3 O
003 TENOR SAX 66 2 O
004 BREATHY TENOR SAX 66 3 O
005 SOPRANO SAX 64 2
006 BREATHY S.SAX 64 3
007 BARITONE SAX 67 2
008 HARD A.SAX 65 4
009 SOFT T.SAX 66 4
010 T.SAXYS 66 5
011 CLARINET 71 2
012 VELO.CLARINET 71 3
013 OBOE 68 2
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
PX360-ES-1A.indd 143 2015/04/24 12:47:10
A-3
Appendix/Apéndice
014 ENGLISH HORN 69 2
015 BASSOON 70 2
016 FLUTE 1 73 2 O
017 FLUTE 2 73 3
018 JAZZ FLUTE 73 4
019 PICCOLO 72 2
020 RECORDER 74 2
021 PAN FLUTE 75 2
022 BOTTLE BLOW 76 2
023 WHISTLE 78 2
024 OCARINA 79 2
025 SHAKUHACHI 77 2
Synth
001 SAW LEAD 1 81 2
002 SAW LEAD 2 81 3 O
003 SAW LEAD 3 81 4
004 MELLOW SAW LEAD 81 5
005 SLOW SAW LEAD 81 6
006 PULSE SAW LEAD 81 7
007 TRANCE LEAD 81 8
008 SS LEAD 81 9
009 SQUARE LEAD 1 80 2
010 SQUARE LEAD 2 80 3
011 SQUARE LEAD 3 80 4 O
012 SLOW SQUARE LEAD 80 5
013 PHASER SQUARE LEAD 80 6 O
014 PULSE LEAD 1 80 7
015 PULSE LEAD 2 80 8
016 SINE LEAD 80 9
017 VELO.SINE LEAD 80 10
018 SQUARE PULSE LEAD 80 11
019 VA SYNTH 1 80 12
020 VA SYNTH 2 80 13
021 VA SYNTH 3 80 14
022 VA SYNTH 4 80 15
023 VA SYNTH 5 80 16
024 VA SYNTH SEQ-BASS 1 81 10
025 VA SYNTH SEQ-BASS 2 81 11 O
026 SEQUENCE SAW 81 12
027 SAW ARPEGGIO 81 13
028 CALLIOPE 82 2
029 VENT LEAD 82 3
030 PIPE LEAD 82 4
031 CHIFF LEAD 83 2
032 VOICE LEAD 85 2
033 VOX LEAD 85 3
034 CHARANG 84 2
035 PLUCK LEAD 84 3
036 GT SYNTH-LEAD 84 4
037 CHURCH LEAD 85 4
038 DOUBLE VOICE LEAD 85 5
039 SYNTH-VOICE LEAD 85 6
040 FIFTH LEAD 86 2
041 FIFTH SAW LEAD 86 3
042 FIFTH SQUARE LEAD 86 4
043 FOURTH LEAD 86 5
044 SEVENTH SEQUENCE 86 6
045 BASS+LEAD 87 2
046 SYNTH-BASS+LEAD 87 3
047 REED LEAD 87 4
048 FANTASY 1 88 2
049 FANTASY 2 88 3 O
050 NEW AGE 88 4
051 WARM VOX 89 2
052 WARM PAD 89 3
053 HORN PAD 89 4
054 POLYSYNTH 90 2
055 POLYSYNTH PAD 90 3 O
056 SYNTH-PAD 90 4
057 VA SYNTH-PAD 1 90 6 O
058 VA SYNTH-PAD 2 90 7 O
059 VA SYNTH-PAD 3 90 8 O
060 POLY SAW 90 9
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
061 BRIGHT SAW PAD 1 90 10
062 BRIGHT SAW PAD 2 90 11
063 SPACE CHOIR 91 2
064 STAR VOICE 91 3 O
065 GLASS PAD 92 2
066 BOTTLE PAD 92 3
067 ETHNIC PAD 93 2
068 METAL PAD 93 3
069 HALO PAD 94 2
070 SWEEP PAD 95 2
071 RAIN DROP 96 2
072 WOOD PAD 96 3
073 SOUND TRACK 97 2
074 CRYSTAL 98 2
075 VIBRAPHONE BELL 98 3
076 ATMOSPHERE 99 2
077 ATMOSPHERE PAD 99 3
078 STEEL PAD 99 4
079 BRIGHTNESS 100 2
080 ECHO VOICE 102 2
081 ECHO PAD 102 3
082 POLY DROP 102 4
083 STAR THEME 103 2
084 SPACE PAD 103 3
Ethnic
001 SITAR 1 104 2
002 SITAR 2 104 3
003 TANPURA 1 104 4
004 TANPURA 2 104 5
005 HARMONIUM 1 20 3
006 HARMONIUM 2 20 4
007 SAROD 105 4
008 SHANAI 111 3
009 TABLA 116 16
010 ER HU 1 110 16
011 ER HU 2 110 17
012 ER HU 3 110 18
013 YANG QIN 1 15 3
014 YANG QIN 2 15 4
015 PI PA 1 105 5
016 PI PA 2 105 6
017 DI ZI 1 72 3
018 DI ZI 2 72 4
019 ZHENG 1 107 3
020 ZHENG 2 107 4
021 XIAO 77 5
022 SHENG 109 3
023 SUO NA 111 4
024 CHINESE HARP 46 3
025 OUD 1 105 7
026 OUD 2 105 8
027 NEY 72 5
028 ARABIC ORGAN 16 14
029 ARABIC STRINGS 48 14
030 SAZ 15 5
031 KANUN 15 6
032 BANJO 105 2
033 MUTE BANJO 105 3
034 THUMB PIANO 108 2
035 STEEL DRUMS 114 2
036 RABAB 105 9
037 SHAMISEN 106 2
038 KOTO 107 2
GM
001 GM PIANO 1 0 0
002 GM PIANO 2 1 0
003 GM ELEC.GRAND PIANO 2 0
004 GM HONKY-TONK 3 0
005 GM E.PIANO 1 4 0
006 GM E.PIANO 2 5 0
007 GM HARPSICHORD 6 0
008 GM CLAVI 7 0
009 GM CELESTA 8 0
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
PX360-ES-1A.indd 144 2015/04/24 12:47:11
Appendix/Apéndice
A-4
010 GM GLOCKENSPIEL 9 0
011 GM MUSIC BOX 10 0
012 GM VIBRAPHONE 11 0
013 GM MARIMBA 12 0
014 GM XYLOPHONE 13 0
015 GM TUBULAR BELL 14 0
016 GM DULCIMER 15 0
017 GM ORGAN 1 16 0
018 GM ORGAN 2 17 0
019 GM ORGAN 3 18 0
020 GM PIPE ORGAN 19 0
021 GM REED ORGAN 20 0
022 GM ACCORDION 21 0
023 GM HARMONICA 22 0
024 GM BANDONEON 23 0
025 GM NYLON STR.GUITAR 24 0
026 GM STEEL STR.GUITAR 25 0
027 GM JAZZ GUITAR 26 0
028 GM CLEAN GUITAR 27 0
029 GM MUTE GUITAR 28 0
030 GM OVERDRIVE GT 29 0
031 GM DISTORTION GT 30 0
032 GM GT HARMONICS 31 0
033 GM ACOUSTIC BASS 32 0
034 GM FINGERED BASS 33 0
035 GM PICKED BASS 34 0
036 GM FRETLESS BASS 35 0
037 GM SLAP BASS 1 36 0
038 GM SLAP BASS 2 37 0
039 GM SYNTH-BASS 1 38 0
040 GM SYNTH-BASS 2 39 0
041 GM VIOLIN 40 0
042 GM VIOLA 41 0
043 GM CELLO 42 0
044 GM CONTRABASS 43 0
045 GM TREMOLO STRINGS 44 0
046 GM PIZZICATO 45 0
047 GM HARP 46 0
048 GM TIMPANI 47 0
049 GM STRINGS 1 48 0
050 GM STRINGS 2 49 0
051 GM SYNTH-STRINGS 1 50 0
052 GM SYNTH-STRINGS 2 51 0
053 GM CHOIR AAHS 52 0
054 GM VOICE DOO 53 0
055 GM SYNTH-VOICE 54 0
056 GM ORCHESTRA HIT 55 0
057 GM TRUMPET 56 0
058 GM TROMBONE 57 0
059 GM TUBA 58 0
060 GM MUTE TRUMPET 59 0
061 GM FRENCH HORN 60 0
062 GM BRASS 61 0
063 GM SYNTH-BRASS 1 62 0
064 GM SYNTH-BRASS 2 63 0
065 GM SOPRANO SAX 64 0
066 GM ALTO SAX 65 0
067 GM TENOR SAX 66 0
068 GM BARITONE SAX 67 0
069 GM OBOE 68 0
070 GM ENGLISH HORN 69 0
071 GM BASSOON 70 0
072 GM CLARINET 71 0
073 GM PICCOLO 72 0
074 GM FLUTE 73 0
075 GM RECORDER 74 0
076 GM PAN FLUTE 75 0
077 GM BOTTLE BLOW 76 0
078 GM SHAKUHACHI 77 0
079 GM WHISTLE 78 0
080 GM OCARINA 79 0
081 GM SQUARE LEAD 80 0
082 GM SAW LEAD 81 0
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
083 GM CALLIOPE 82 0
084 GM CHIFF LEAD 83 0
085 GM CHARANG 84 0
086 GM VOICE LEAD 85 0
087 GM FIFTH LEAD 86 0
088 GM BASS+LEAD 87 0
089 GM FANTASY 88 0
090 GM WARM PAD 89 0
091 GM POLYSYNTH 90 0
092 GM SPACE CHOIR 91 0
093 GM BOWED GLASS 92 0
094 GM METAL PAD 93 0
095 GM HALO PAD 94 0
096 GM SWEEP PAD 95 0
097 GM RAIN DROP 96 0
098 GM SOUND TRACK 97 0
099 GM CRYSTAL 98 0
100 GM ATMOSPHERE 99 0
101 GM BRIGHTNESS 100 0
102 GM GOBLINS 101 0
103 GM ECHOES 102 0
104 GM SF 103 0
105 GM SITAR 104 0
106 GM BANJO 105 0
107 GM SHAMISEN 106 0
108 GM KOTO 107 0
109 GM THUMB PIANO 108 0
110 GM BAGPIPE 109 0
111 GM FIDDLE 110 0
112 GM SHANAI 111 0
113 GM TINKLE BELL 112 0
114 GM AGOGO 113 0
115 GM STEEL DRUMS 114 0
116 GM WOOD BLOCK 115 0
117 GM TAIKO 116 0
118 GM MELODIC TOM 117 0
119 GM SYNTH-DRUM 118 0
120 GM REVERSE CYMBAL 119 0
121 GM GT FRET NOISE 120 0
122 GM BREATH NOISE 121 0
123 GM SEASHORE 122 0
124 GM BIRD 123 0
125 GM TELEPHONE 124 0
126 GM HELICOPTER 125 0
127 GM APPLAUSE 126 0
128 GM GUNSHOT 127 0
Drums
001 STANDARD SET 1 0 120
002 STANDARD SET 2 1 120
003 STANDARD SET 3 2 120
004 STANDARD SET 4 3 120
005 DANCE SET 29 120
006 TRANCE SET 31 120
007 HIP-HOP SET 9 120
008 ROOM SET 8 120
009 POWER SET 16 120
010 ROCK SET 17 120
011 ELECTRONIC SET 24 120
012 SYNTH SET 1 25 120
013 SYNTH SET 2 30 120
014 JAZZ SET 32 120
015 BRUSH SET 40 120
016 ORCHESTRA SET 48 120
017 ETHNIC SET 1 49 120
018 ETHNIC SET 2 50 120
Group
Number/
Número
de grupo
Tone Name/
Nombre del tono
Program
Change/
Cambio
de
programa
Bank
Select
MSB/
MSB de
selección
de banco
DSP
PX360-ES-1A.indd 145 2015/04/24 12:47:11
A-5
Appendix/Apéndice
• With some guitar tones, playing in the lowest range
(far left) or highest range (far right) may result in
strum noise, harmonics, or other characteristic
playing sounds being included with the notes.
• See the “Drum Assignment List” on page A-6 for
information about the percussion instruments
assigned to each keyboard key when a drum set is
selected.
• Con algunos tonos de guitarra, si toca en el rango
más bajo (extremo izquierdo) o más alto (extremo
derecho), podrían escucharse sonidos de rasgueo, de
armónicos, u otros sonidos de ejecución
característicos incluidos en las notas.
• Consulte “Lista de asignación de batería” de la
página A-6 para obtener información acerca de los
instrumentos de percusión asignados a cada tecla
cuando se selecciona un ajuste de batería.
PX360-ES-1A.indd 146 2015/04/24 12:47:12
Appendix/Apéndice
A-6
Drum Assignment List/Lista de asignación de batería
Tabla Ge
Tabla Ka
Tabla Te
Tabla Na
Tabla Tun
Dholak Ge
Dholak Ke
Dholak Ta 1
Dholak Ta 2
Dholak Na
Dholak Ta 3
Dholak Ring
Mridangam Tha
Mridangam Dhom
Mridangam Dhi
Mridangam Dhin
Mridangam Num
High Q
Slap
Scratch Push
Scratch Pull
Sticks
Square Click
Metronome Click
Metronome Bell
Standard1 Kick 2
Standard1 Kick 1
Side Stick
Standard1 Snare 1
Hand Clap
Standard1 Snare 2
Low Tom 2
Closed Hi-Hat
Low Tom 1
Pedal Hi-Hat
Mid Tom 2
Open Hi-Hat
Mid Tom 1
High Tom 2
Crash Cymbal 1
High Tom 1
Ride Cymbal 1
Chinese Cymbal
Ride Bell
Tam bourine
Splash Cymbal
Cowbell
Crash Cymbal 2
Vibraslap
Ride Cymbal 2
High Bongo
Low Bongo
Mute High Conga
Open High Conga
Open Low Conga
High Timbale
Low Timbale
High Agogo
Low Agogo
Cabasa
Maracas
Short High Whistle
Long Low W
histle
Short Guiro
Long Guiro
Claves
High Wood Block
Low Wood Block
Mute Cuica
Open Cuica
Mute Triangle
Open Triangle
Shaker
Jingle Bell
Standard2 Kick 2
Standard2 Kick 1
Standard2 Snare 1
Standard2 Snare 2
Standard2 Low Tom 2
Standard2 Closed Hi-Hat
Standard2 Low Tom 1
Standard2 Pedal Hi-Hat
Standard2 Mid Tom 2
Standard2 Open Hi-Hat
Standard2 Mid Tom 1
Standard2 High Tom 2
Standard2 Crash Cymbal 1
Standard2 High Tom 1
Standard2 Ride Cymbal 1
Standard2 Chinese Cymbal
Standard2 Ride Bell
Standard2 Splash Cymbal
Standard2 Crash Cymbal 2
Standard2 Ride Cymbal 2
Standard3 Kick 2
Standard3 Kick 1
Standard3 Snare 1
Standard3 Snare 2
Standard3 Closed Hi-Hat
Standard3 Pedal Hi-Hat
Standard3 Open Hi-Hat
Dance Kick 1
Dance Kick 2
Dance Kick 3
Dance Kick 4
Dance Kick 5
Dance Snare 1
Dance Snare 2
Dance Snare 3
Dance Snare 4
Dance Snare 5
Dance Snare 6
Dance Snare 7
Dance Snare 8
Dance Snare 9
Dance Tambourine
Hip-Hop Snare 4
Hip-Hop Snare 3
Techno Snare
Hip-Hop Rim Shot
Hip-Hop Snare 3 Rev.
Synth2 Kick 1 Rev.
Reverse Cymbal Gate
Hip-Hop Snare 4 Gate
Hip-Hop Snare 3 Gate
Techno Snare Gate
Hip-Hop Side Stick Gate
Hand Clap 2 Gate
Hip-Hop Scratch 1
Hip-Hop Scratch 2
Synth2 Kick 2
Synth2 Kick 1
Synth2 Snare 1
Synth2 Snare 2
Synth2 Low Tom 2
Synth2 Closed Hi-Hat 1
Synth2 Low Tom 1
Synth2 Closed Hi-Hat 2
Synth2 Mid Tom 2
Synth2 Open Hi-Hat
Synth2 Mid Tom 1
Synth2 Hi Tom 2
Synth2 Hi Tom 1
Synth2 Cymbal 2
Synth1 Kick 2
Synth1 Kick 1
Synth1 Rim Shot
Synth1 Snare 1
Synth1 Hand Clap
Synth1 Snare 2
Synth1 Low Tom 2
Synth1 Chh
Synth1 Low Tom 1
Synth1 Phh
Synth1 Mid Tom 2
Synth1 Ohh
Synth1 Mid Tom 1
Synth1 Hi Tom 2
Synth1 Cymbal
Synth1 Hi Tom 1
Synth1 Ride
Chinese Cymbal
Ride Bell
Synth 1 Tambourine
Splash Cymbal
Synth 1 Cowbell
Crash Cymbal 2
Vibraslap
Synth1 Kick 3
Trance Kick 2
Trance Kick 1
Trance Side Stick
Trance Snare 1
Trance Hand Clap
Trance Snare 2
Trance Closed Hi-Hat
Trance Open Hi-Hat 1
Trance Open Hi-Hat 2
Trance Tambourine
Hip-Hop Kick 2
Hip-Hop Kick 1
Hip-Hop Side Stick
Hip-Hop Snare 1
Hip-Hop Hand Clap
Hip-Hop Snare 2
Hip-Hop Closed Hi-Hat
Hip-Hop Pedal Hi-Hat
Hip-Hop Open Hi-Hat
Room Kick 2
Room Kick 1
Room Snare 1
Room Snare 2
Room Low Tom 2
Room Low Tom 1
Room Mid Tom 2
Room Mid Tom 1
Room High Tom 2
Room High Tom 1
Power Kick 2
Power Kick 1
Power Snare 1
Power Snare 2
Room Low Tom 2
Room Low Tom 1
Room Mid Tom 2
Room Mid Tom 1
Room High Tom 2
Room High Tom 1
Rock Kick 2
Rock Kick 1
Rock Side Stick
Rock Snare 1
Rock Snare 2
Rock Closed Hi-Hat
Rock Pedal Hi-Hat
Rock Open Hi-Hat
Rock Crash Cymbal
Rock Ride Cymbal
Rock Splash Cymbal
Elec. Kick 2
Elec. Kick 1
Elec. Snare 1
Elec. Snare 2
Elec. Low Tom 2
Elec. Low Tom 1
Elec. Mid Tom 2
Elec. Mid Tom 1
Elec. High Tom 2
Elec. High Tom 1
Reverse Cymbal
Synth1 Kick 2
Synth1 Kick 1
Synth1 Rim Shot
Synth1 Snare 1
Synth1 Hand Clap
Synth1 Snare 2
Synth1 Low Tom 2
Synth1 Closed Hi-Hat 1
Synth1 Low Tom 1
Synth1 Closed Hi-Hat 2
Synth1 Mid Tom 2
Synth1 Open Hi-Hat
Synth1 Mid Tom 1
Synth1 High Tom 2
Synth1 Crash Cymbal
Synth1 High Tom 1
Synth1 Ride Cymbal
Synth1 Tambourine
Synth1 Cowbell
Synth1 High Bongo
Synth1 Low Bongo
Synth1 Mute Hi Conga
Synth1 Open Hi Conga
Synth1 Open Low Conga
Synth1 Maracas
Synth1 Claves
Synth2 Kick 2
Synth2 Kick 1
Synth1 Rim Shot
Synth2 Snare 1
Synth2 Snare 2
Synth2 Low Tom 2
Synth2 Closed Hi-Hat 1
Synth2 Low Tom 1
Synth2 Closed Hi-Hat 2
Synth2 Mid Tom 2
Synth2 Open Hi-Hat
Synth2 Mid Tom 1
Synth2 High Tom 2
Synth2 High Tom 1
Synth1 Cowbell
Synth1 Maracas
Synth1 Claves
Jazz Kick 2
Jazz Kick 1
Jazz Snare 1
Jazz Snare 2
Jazz Kick 2
Brush Kick
Brush Side Stick
Brush Snare 1
Brush Slap
Brush Snare 2
Brush Crash Cymbal 1
Brush Ride Cymbal 1
Brush Ride Bell
Brush Tambourine
Brush Splash Cymbal
Brush Crash Cymbal 2
Brush Ride Cymbal 2
Closed Hi-Hat
Pedal Hi-Hat
Open Hi-Hat
Ride Cymbal 1
Jazz Kick 1
Concert BD
Concert SD
Castanets
Concert SD
Timpani F
Timpani F#
Timpani G
Timpani G#
Timpani A
Timpani A#
Timpani B
Timpani c
Timpani c#
Timpani d
Timpani d#
Timpani e
Timpani f
Concert Cymbal 2
Concert Cymbal 1
Tabla Ge
Tabla Ka
Tabla Te
Tabla Na
Tabla Tun
Dholak Ge
Dholak Ke
Dholak Ta 1
Dholak Ta 2
Dholak Na
Dholak Ta 3
Dholak Ring
Mridangam Tha
Tablah 1
Tablah 2
Tablah 3
Daf 1
Daf 2
Riq 1
Riq 2
Riq 3
Davul 1
Davul 2
Zill 1
Zill 2
Ban Gu
Hu Yin Luo
Xiao Luo
STANDARD
SET 1
STANDARD
SET 2
STANDARD
SET 3
Standard3 Kick 2
Standard3 Kick 1
Standard3 Snare 1
Standard3 Snare 2
STANDARD
SET 4
DANCE SET TRANCE SET HIP-HOP SET ROOM SET POWER SET ROCK SET
ELECTRONIC
SET
SYNTH SET 1 SYNTH SET 2 JAZZ SET BRUSH SET
ORCHESTRA
SET
ETHNIC SET 1 ETHNIC SET 2
C-1
D-1
E-1
F-1
G-1
A-1
B-1
C0
D0
E0
F0
G0
A0
B0
C1
D1
E1
F1
G1
A1
B1
C2
D2
E2
F2
G2
A2
B2
C3
D3
E3
F3
G3
A3
B3
C4
D4
E4
F4
G4
A4
B4
C5
D5
E5
F5
G5
A5
B5
1
3
5
6
8
10
12
13
15
17
18
20
22
24
25
27
29
30
32
34
36
37
39
41
42
44
46
48
49
51
53
54
56
58
60
61
63
65
66
68
70
72
73
75
77
78
80
82
84
2
4
7
9
11
14
16
19
21
23
26
28
31
33
35
38
40
43
45
47
50
52
55
57
59
62
64
67
69
71
74
76
79
81
83
C
-1
E
-1
F
-1
A
-1
B
-1
C
0
E
0
F
0
A
0
B
0
C
1
E
1
F
1
A
1
B
1
C
2
E
2
F
2
A
2
B
2
C
3
E
3
F
3
A
3
B
3
C
4
E
4
F
4
A
4
B
4
C
5
E
5
F
5
A
5
B
5
Key/Note Number
Número de clave/
nota
PX360-ES-1A.indd 147 2015/04/24 12:47:14
A-7
Appendix/Apéndice
Bell Tree
Castanets
Mute Surdo
Open Surdo
Applause 1
Applause 2
Tablah 1
Tablah 2
Tablah 3
Daf 1
Daf 2
Riq 1
Riq 2
Riq 3
Davul 1
Davul 2
Zill 1
Zill 2
Ban Gu
Hu Yin Luo
Xiao Luo
Xiao Bo
Low Tang Gu
Mid Tang Gu
High Tang Gu
Hip-Hop Kick 3
Dance Kick 6
Dance Snare 10
Hand Clap 3
Dance Snare 11
Elec Low Tom 2
Hip-Hop Closed Hi-Hat
Elec Low Tom 1
Hip-Hop Pedal Hi-Hat
Elec Mid Tom 2
Hip-Hop Open Hi-Hat
Elec Mid Tom 1
Elec Hi Tom 2
Techno Cymbal
Elec Hi Tom 1
Techno Ride
Low Tom 2
Closed Hi-Hat
Low Tom 1
Pedal Hi-Hat
Mid Tom 2
Open Hi-Hat
Mid Tom 1
High Tom 2
Crash Cymbal 1
High Tom 1
Ride Cymbal 1
Tam bourine 2
Tam bourine 3
Cabasa 2
Maracas 2
Claves 2
Mute Triangle 2
Open Triangle 2
Shaker 2
Hand Clap
Hand Clap 2
Mridangam Dhom
Mridangam Dhi
Mridangam Dhin
Mridangam Num
Xiao Bo
Low Tang Gu
Mid Tang Gu
High Tang Gu
C6
D6
E6
F6
G6
A6
B6
C7
D7
E7
F7
G7
A7
B7
C8
D8
E8
F8
G8
A8
B8
C9
D9
E9
F9
G9
85
87
89
90
92
94
96
97
99
101
102
104
106
108
109
111
113
114
116
118
120
121
123
125
126
128
C
6
E
6
F
6
A
6
B
6
C
7
E
7
F
7
A
7
B
7
C
8
E
8
F
8
A
8
B
8
C
9
E
9
F
9
86
88
91
93
95
98
100
103
105
107
110
112
115
117
119
122
124
127
STANDARD
SET 1
STANDARD
SET 2
STANDARD
SET 3
STANDARD
SET 4
DANCE SET TRANCE SET HIP-HOP SET ROOM SET POWER SET ROCK SET
ELECTRONIC
SET
SYNTH SET 1 SYNTH SET 2 JAZZ SET BRUSH SET
ORCHESTRA
SET
ETHNIC SET 1 ETHNIC SET 2
• “»” indicates a key is assigned the same tones as it is for STANDARD SET 1.
• “
»” indica una clave asignada a los mismos tonos que para STANDARD SET 1.
Key/Note Number
Número de clave/
nota
PX360-ES-1A.indd 148 2015/04/24 12:47:15
Appendix/Apéndice
A-8
Rhythm List/Lista de ritmos
Group
Number/
Número de
grupo
Rhythm name/
Nombre del ritmo
Pops
001 POP ROCK 1
002 POP
003 ELECTROPOP
004 FUNK 8 BEAT
005 UK BEAT
006 6/8 POP
007 ACOUSTIC GUITAR POP
008 POP ROCK 2
009 SLOW SOUL
010 FAST SOUL
011 60's SOUL
012 OLDIES SOUL
013 60's POP
014 60's SHUFFLE
015 POP SHUFFLE
8 Beat
001 STRAIGHT 8 BEAT
002 MELLOW 8 BEAT
003 GUITAR 8 BEAT
004 FAST 8 BEAT
005 8 BEAT
006 OLDIES 8 BEAT
007 60's 8 BEAT
16 Beat
001 16 BEAT
002 FUNK 16 BEAT
003 16 BEAT SHUFFLE
004 FUNK SHUFFLE
005 LATIN FUSION
Rock
001 STRAIGHT ROCK
002 SHUFFLE ROCK
003 6/8 ROCK
004 SHUFFLE BLUES
005 SLOW BLUES
006 ROCK BLUES
007 6/8 BLUES
008 EP BLUES
009 R&B
010 SOFT ROCK
011 LATIN ROCK
012 ORGAN ROCK
013 70's PIANO ROCK
014 ROCK
015 60's ROCK 1
016 60's ROCK 2
017 OLDIES ROCK
018 SLOW ROCK
019 ROCK & ROLL
020 50's PIANO ROCK
021 50's ROCK
022 NEW ORLNS R&R
Dance
001 PIANO HIP-HOP
002 HIP-HOP
003 DANCE POP
004 DISCO POP
005 TECHNO POP
006 TRANCE
007 MODERN R&B
008 MODERN DANCE
009 DISCO SOUL
Jazz
001 SLOW BIG BAND
002 MIDDLE BIG BAND
003 FAST BIG BAND
004 ORCHESTRA SWING
005 SWING
006 SLOW SWING
007 JAZZ WALTZ
008 FOX TROT
009 QUICKSTEP
010 JAZZ COMBO 1
European
001 SCHLAGER
002 POLKA
003 WALTZ 1
004 WALTZ 2
005 SLOW WALTZ
006 VIENNESE WALTZ
007 FRENCH WALTZ
008 SERENADE
009 TANGO
010 MARCH 1
011 MARCH 2
Latin
001 BOSSA NOVA
002 SLOW BOSSA NOVA
003 BEGUINE
004 SAMBA 1
005 SAMBA 2
006 MAMBO
007 RHUMBA
008 CHA-CHA-CHA
009 MERENGUE
010 BOLERO
011 SALSA 1
012 SALSA 2
013 REGGAE
014 POP REGGAE
015 SKA
016 REGGAETON 1
017 REGGAETON 2
018 CUMBIA
019 CALYPSO
020 FORRO
021 PAGODE
022 BANDA
023 PASILLO
024 ARGENTINE CUMBIA
025 PUNTA
026 BACHATA
World
American
001 DIXIE
002 TEX-MEX
003 FAST GOSPEL
004 SLOW GOSPEL
005 HAWAIIAN
Group
Number/
Número de
grupo
Rhythm name/
Nombre del ritmo
PX360-ES-1A.indd 149 2015/04/24 12:47:16
A-9
Appendix/Apéndice
• The rhythms of Piano Rhythms 011 to 020 do not
sound unless a chord is being played.
• Los ritmos de Piano Rhythms 011 a 020 no suenan a
menos que se toque un acorde.
Spanish/Eastern European
006 PASODOBLE
007 CAUCASIAN
008 RUSSIAN CHANSON 1
009 RUSSIAN CHANSON 2
010 POLISH WALTZ
Arabic/Oriental
011 MALFOUF
012 BALADI
013 KHALIJI
014 ADANI
015 MUS
016 SIRTAKI
Indian
017 BHANGRA
018 DADRA
019 GARBA
020 KEHARWA
021 DANDIYA
022 TEEN TAAL
023 BHAJAN
Chinese
024 GUANGDONG
025 JIANGNAN
026 BEIJING
027 DONGBEIYANGGE
028 JINGJU
029 HUANGMEIXI
030 QINQIANG
031 YUJU
032 YAOZU
033 DAIZU
034 MIAOZU
035 MENGGU
036 XINJIANG
037 ZANGZU
038 CHINESE POP
Southeast Asian
039 KRONCONG
040 DANGDUT
Japanese
041 ENKA
Country
001 MODERN COUNTRY
002 COUNTRY 8 BEAT
003 COUNTRY 16 BEAT
004 COUNTRY BALLAD
005 COUNTRY SHUFFLE 1
006 COUNTRY SHUFFLE 2
007 FINGER PICKING COUNTRY
008 COUNTRY WALTZ
009 BLUEGRASS
Various
001 CHRISTMAS SONG
002 CHRISTMAS WALTZ
003 SCREEN SWING
004 SYMPHONY
005 STR QUARTET
Ballad
001 PIANO ROCK BALLAD
002 90's BALLAD
003 MODERN BALLAD
004 ELECTRIC BALLAD
005 SLOW BALLAD 1
Group
Number/
Número de
grupo
Rhythm name/
Nombre del ritmo
006 SLOW BALLAD 2
007 R&B BALLAD
008 16 BEAT BALLAD
009 BRUSH BALLAD
010 POP BALLAD
011 PIANO WALTZ BALLAD
012 90's 6/8 BALLAD
013 6/8 BALLAD 1
014 6/8 BALLAD 2
015 EASY LISTENING BALLAD
016 UNPLUGGED BALLAD
017 ROCK BALLAD 1
018 ROCK BALLAD 2
019 6/8 ROCK BALLAD
020 OLDIES BALLAD
Piano Rhythms
001 PIANO 8 BEAT
002 PIANO BALLAD 1
003 PIANO BALLAD 2
004 EP BALLAD 1
005 EP BALLAD 2
006 BLUES BALLAD
007 JAZZ COMBO 2
008 JAZZ COMBO 3
009 RAGTIME
010 BOOGIE-WOOGIE
011 PIANO ROCK & ROLL
012 ARPEGGIO 1
013 ARPEGGIO 2
014 ARPEGGIO 3
015 PIANO MARCH 1
016 PIANO MARCH 2
017 STRIDE PIANO
018 WALTZ 3
019 WALTZ 4
020 WALTZ 5
Group
Number/
Número de
grupo
Rhythm name/
Nombre del ritmo
PX360-ES-1A.indd 150 2015/04/24 12:47:16
Appendix/Apéndice
A-10
Music Preset List/Lista de preajustes musicales
Group
Number/
Número de
grupo
Preset Name/
Nombre de preajuste
Pops
001 Soft Pop
002 Winter Pop
003 Oldies Pop
004 Alpine Flora
005 Gypsy
006 Rain Pop
007 Movie Waltz
008 Funky Pop
009 Love Pop
010 60's Pop
011 Rising Sun
012 Pop Ska
013 Weep Blues
014 Cartoon
015 Carol
016 My Life
017 Blue Love
018 Xmas Pop
019 Shuffle Pop1
020 Shuffle Pop2
021 70's Soul
022 70's Pop
023 West Coast
024 Bossa Pop
025 Radio Pop
026 Crazy Roll
027 80's Pop 1
028 80's Pop 2
029 UK Pop 1
030 UK Pop 2
031 A Feeling
032 Calling
033 80's EuroPop
034 The World
035 Mexican Pop
036 Guitar Pop
037 90's Pop
038 Wonder
039 Modern Pop 1
040 Modern Pop 2
041 MdrnPopRock
042 Basic 1
043 Basic 2
044 Basic 3
045 Basic 4
046 Basic 5
Dance
001 Funky Disco
002 Funky Clavi
003 Disco Soul
004 70's Disco
005 Disco Lady
006 Staying
007 Up&Down
008 80's Disco
009 80'sDancePop
010 Bb Girl
011 Blv Disco
012 Lady Jam
013 Into Your H
014 Euro Pop
015 Modern Dance
016 Trance
017 ShuffleDance
Rock
001 50's Rock 1
002 50's Rock 2
003 Heartache
004 EP R&R
005 Pop R&B
006 60's Rock 1
007 60's Rock 2
008 60's Rock 3
009 60's Rock 4
010 60's Rock 5
011 Get Rock
012 Honky Rock
013 Wild Rock
014 Alligator
015 Movie Rock
016 Pop Rock
017 16Bt Shuffle
018 Heat Up
019 Hard Rock
020 Grunge Rock
021 Modern Rock
022 R&R
023 Piano R&R
024 Blues
025 8 Bars Blues
026 Riff Rock 1
027 Riff Rock 2
028 Riff Rock 3
Jazz
001 My Swing
002 Your Things
003 Angel
004 Time Passes
005 Piano Trio
006 Goodbye
007 Marine Dance
008 Vine Days
009 TraneChanges
010 RhythmChange
011 Swing Mood
012 The Big Mood
013 Brown Jug
014 Jazz Club
015 All Day Long
016 Avenue
017 Big Band 1
018 Big Band 2
019 Jazz Waltz 1
020 Jazz Waltz 2
021 Jazz Waltz 3
022 Mode Jazz
023 Tea Time
024 Welcome Home
025 Jazz Opera
026 NY City
027 Soul & Jazz
028 Loneliness
029 Foggy
030 Moon Swing
031 Jazz Ballad1
032 Jazz Ballad2
033 Jazz Ballad3
034 PatheticTrip
035 Night Sky
036 Twilight
037 Blues in F
038 Blues in Bb
039 Blues in C
040 II-V
041 II-V-I
042 Minor Blues
Classic
001 Canon
002 Air G String
003 Je Te Veux
004 Adagio
005 Spring
006 Ave Maria
007 JesusBleibet
008 Symphony 25
009 Symphony 40
010 HungriaDance
011 Eine Kleine
012 Pathetique
013 Moonlight
014 PstlSymphony
015 Ode To Joy
016 Le Cygne
Group
Number/
Número de
grupo
Preset Name/
Nombre de preajuste
PX360-ES-1A.indd 151 2015/04/24 12:47:16
A-11
Appendix/Apéndice
017 Swan Lake
018 Valse Fleurs
019 Habanera
020 Nocturne
021 Etude
022 FrenchCancan
023 FantaisieImp
024 Humoresque
025 Pavane
026 Hope & Glory
027 Moldau
028 FromNewWorld
029 Reverie
030 Nutcracker
031 Liebestraume
032 Gymnopedies
033 Jupiter
034 Entertainer
035 MapleLeafRag
Trad
001 Michael Row
002 GrndpasClock
003 Troika
004 AuldLangSyne
005 Aloha Oe
006 O Sole Mio
007 Furusato
008 SzlaDziweczk
009 Battle Hymn
010 Condor
011 ScarboroFair
012 Danny Boy
013 Greensleeves
014 Annie Laurie
015 AmazingGrace
016 WeWishU Xmas
017 Silent Night
018 Joy To World
019 YankeeDoodle
020 Clarnt Polka
021 TaRaRaBoom
022 Double Eagle
023 Blauen Donau
024 Yellow Rose
025 BeautDreamer
Latin
001 Satellite
002 Rio
003 Aqua
004 Single
005 Sea Shore
006 Poor Pitch
007 Mountain
008 Heartless
009 Carnival
010 Mythology
011 Tico-Tico
012 Beguine
013 Amapola
014 La Paloma
015 Banana Boat
016 Peanut
017 A Cup Of
018 Jamaica
019 60's Movie 1
020 60's Movie 2
021 The No.5
022 Everyday
023 Kiss Me
024 El Tango
025 El Choclo
026 Reggae 1
027 Reggae 2
028 Pop Reggae 1
029 Pop Reggae 2
030 Latin Rock 1
031 Latin Rock 2
032 Modern Latin
Country
001 US Folk 1
002 US Folk 2
003 50's Country
Group
Number/
Número de
grupo
Preset Name/
Nombre de preajuste
004 70's Country
005 60's Folk
006 Tree
007 A Friend
008 Cowboy
009 Country Bld1
010 Country Bld2
011 Country Bld3
012 CountryWaltz
013 Mdrn Country
Ballad
001 Love Ballad
002 R&B Ballad
003 Soul Ballad
004 Blues Ballad
005 MovieBallad1
006 MovieBallad2
007 MovieBallad3
008 Xmas Ballad
009 Love Me
010 Oldies Bld 1
011 Oldies Bld 2
012 Oldies Bld 3
013 Oldies Bld 4
014 E World
015 Guitar Bld 1
016 Guitar Bld 2
017 Moon Waltz
018 Theme
019 Paradise
020 60's Ballad1
021 60's Ballad2
022 Baroque Bld
023 FrenchBallad
024 Everywhere
025 Wonderful
026 70's Ballad1
027 70's Ballad2
028 70's Ballad3
029 My Song
030 Peace
031 Without
032 Soundtrack
033 Soft Ballad
034 Memories
035 Minor Ballad
036 Pop Ballad 1
037 Pop Ballad 2
038 PianoBallad1
039 PianoBallad2
040 Musical Bld
041 R Ballad
042 Love Song
043 80's Ballad1
044 80's Ballad2
045 80's Ballad3
046 80's Ballad4
047 Friends
048 Rock Ballad1
049 Rock Ballad2
050 Two Flames
051 90's Ballad1
052 90's Ballad2
053 90's Ballad3
054 90's SoulBld
055 I Always
056 6/8 Ballad
057 Wind Ballad
058 90's 6/8 Bld
059 My Ballad
060 MdrnSoulBld1
061 MdrnSoulBld2
062 Mdrn Pf Bld
063 Rap Ballad
064 Dance Ballad
065 MdrnRock Bld
066 Slow Ballad
067 90's R&B Bld
Group
Number/
Número de
grupo
Preset Name/
Nombre de preajuste
PX360-ES-1A.indd 152 2015/04/24 12:47:17
Appendix/Apéndice
A-12
Fingering Guide/Guía de digitación
Fingered 1, Fingered 2 Chords/Acordes Fingered 1, Fingered 2
*1With Fingered 2, interpreted as Am7.
*2With Fingered 2, interpreted as Am7
b
5
.
*3Inverted form not supported in some cases.
*4Full Range Chord not supported.
*1Con Fingered 2, se interpreta como Am7.
*2Con Fingered 2, se interpreta como Am7
b
5
.
*3En algunos casos no se puede usar de forma invertida.
*4No es compatible con Full Range Chord.
C
Cm
Cdim
Caug
*3
C
5
Csus4
*3
Csus2
*3
C7
Cm7
*3
CM7
CmM7
Cdim7
*3
CdimM7
C7
5
*3
Cm7
5
*3
CM7
5
Caug7
CaugM7
C7sus4
C6
*1 *3
Cm6
*2 *3
Cadd9
Cmadd9
C69
*3
Cm69
*3
C7
(
9)
C7
(9)
C7
(
9)
C7
(
11)
C7
(
13)
C7
(13)
Cm7
(9)
Cm7
(11) *3
CM7
(9)
CmM7
(9)
C5
C8
(Root and 5th only) *
4
(La raíz y la 5ta. solamente) *
4
(Root only, or root plus octave) *
4
(La raíz solamente o la raíz más la
octava) *
4
PX360-ES-1A.indd 153 2015/04/24 12:47:17
A-13
Appendix/Apéndice
In addition to the chords that can be fingered with
Fingered 1 and Fingered 2, the following chords also
are recognized.
Además de los acordes que se pueden digitar con
Fingered 1 y Fingered 2, también se pueden reconocer
los siguientes acordes.
• With Fingered 3, the lowest note fingered is
interpreted as the base note. Inverted forms are not
supported.
• With Full Range Chord, when the lowest fingered is
a certain distance from the neighboring note, the
chord is interpreted as a fraction chord.
• Unlike Fingered 1, 2, and 3, Full Range Chord
requires pressing of at least three keys to form a
chord.
• Con Fingered 3, la nota más baja digitada se
interpreta como nota base. No se pueden usar
formas invertidas.
• Con Full Range Chord, cuando la nota digitada más
baja se encuentre a cierta distancia de la nota
adyacente, el acorde se interpreta como un acorde
bitonal.
• A diferencia de Fingered 1, 2, y 3, Full Range Chord
requiere la pulsación de tres teclas como mínimo
para formar un acorde.
Fingered 3, Full Range Chords/
Acordes Fingered 3, Full Range
C
#
C
D
C
F
#
C
F
C
G
C
A
b
C
A
C
Gm
C
Am
C
B
b
m
C
Ddim
C
Fdim
C
FM7
C
A
b
M7
C
F
#
m7
b
5
C
Gdim
C
Adin
C
Bdin
C
A
b
7
C
F7
C
Fm7
C
B
b
C
C
#
m
C
Dm
C
Fm
C
Bm
C
A
b
m
C
F
#
m
C
Gm7
C
A
b
add9
C
C
#
dim
C
F
#
din
C
A
b
din
C
PX360-ES-1A.indd 154 2015/04/24 12:47:17
Appendix/Apénd ice
A-14
Parameter List/Lista de parámetros
To check this setting item:/Para comprobar este elemento de ajuste:
Refer to this column in the table below:/
Vea esta columna de la siguiente tabla:
Setting items that are always saved when power is turned off/
Elementos de ajuste que se almacenan siempre al cortar la alimentación
1
When “On” is selected for the “Auto Resume” setting (page EN-53), setting items that are restored
to those in effect the last time power was turned off/
Cuando se selecciona “On” para el ajuste “Auto Resume” (página EN-53), los elementos de ajuste se
restablecen a los que estaban en efecto la última vez que se cortó la alimentación
2
Setting items stored by Registration (page EN-34)./
Elementos de ajuste que se almacenan mediante Registro (página EN-34).
3
Setting items changed by One Touch Preset (page EN-23)./
Elementos de ajuste que se modifican mediante Preajuste de un toque (página EN-23).
4
Setting items changed when a Grand Piano tone is selected (page EN-14)./
Elementos de ajuste que se modifican cuando se seleccionan tonos de piano de cola (página EN-14).
5
Setting items changed by Music Preset (page EN-28)./
Elementos de ajuste que se modifican mediante Preajuste musical (página EN-28).
6
Setting Item/
Elemento de ajuste
1 2 3 4 5 6
System Setting
Speaker O
Touch Response OO
Touch Off Velocity O O
Metronome Count O
Accomp Freeze O
Tuning O
Temperament O
Temperament Base Note O
Accomp Temperament O
Stretch Tuning O
Brightness O
N.Gate Thrash O
Auto Resume O
Auto Power Off O
Duet
On/Off OOOOO*
3
Octave O O
Duet Pan OO
Controller
Pedal Assign OO
Upper 1 Pedal O O
Upper 2 Pedal OO
Lower 1 Pedal O O
Lower 2 Pedal OO
Bend Range O O
MIDI
Keyboard Channel O
Accomp Out O
Chord Judge O
Hi-Res Vel Out O
Local Control
MIDI In Port O
MIDI Out/Thru O
Main/Tone Setting
Split Point O O
Transpose OO
Part On/Off O O O O O
Part Octave OOOOO
Mixer (Mixer setting for Part 1 to Part 5 of Port A/
Ajuste del mezclador de la Parte 1 a la Parte 5 del puerto A)
Tone OOOOO
Volume O O O O O
Pan OOOOO
Coarse Tune O O O O O
Fine Tune OOOOO
Bend Range O O O O O
Reverb Send OOOOO
Chorus Send O O O O O
Delay Send OOOOO
Part On/Off
Effect
Brilliance O O O O O
Reverb Type OOOOO
Chorus Type O O O O O
Delay Type OOOOO
Hammer Response O
String Resonance O
Rhythm
Rhythm No OO*
1
OO
Accomp On/Off O O*
1
O O
Chord input Type OO*
1
O
Synchro state O*
1
O O O
Tempo OO*
1
OOO
Accomp Part on/off O O*
1
O O
Harmonize on/off OO OO
Harmonize Type O O O O
Auto Chord OO*
1
OO
Music Preset Key Shift O O*
1
Music Preset O*
1
*
2
O*
2
Balance
Accomp Volume OO*
1
MIDI Volume O
Keyboard Volume O
Audio Volume O
Line in Volume O
Metronome Volume O
Other
Registration Bank O
*1 Not changed when Accomp Freeze is enabled.
*2 Recalls cord progression stored to the applicable number.
*3 Selecing a Music Preset exits the Duet Mode.
*1 No se modifica con “Accomp Freeze” (Acompañamiento
congelado) habilitado.
*2
Llama la progresión de acordes correspondiente al número aplicable.
*3 Si se selecciona un preajuste musical se sale del modo dúo.
Setting Item/
Elemento de ajuste
1 2 3 4 5 6
PX360-ES-1A.indd 155 2015/04/24 12:47:18
A-15
Appendix/Apéndice
Chord Example List/Lista de ejemplos de acordes
(
A
)
/B
BF
/
(
G
)
G
(
G
)
/A
AFCC
/
(
D
)
D
(
D
)
/E
E
Root
Chord
Type
M
m
dim
aug
5
sus4
sus2
7
m7
M7
mM7
dim7
dimM7
7
5
m7
5
M7
5
aug7
augM7
7sus4
PX360-ES-1A.indd 156 2015/04/24 12:47:21
Appendix/Apéndice
A-16
(
A
)
/B
BF
/
(
G
)
G
(
G
)
/A
AFCC
/
(
D
)
D
(
D
)
/E
E
Root
Chord
Type
6
m6
add9
madd9
69
m69
7
(
9
)
7
(9)
7
(
9
)
7
(
11
)
7
(
13)
7
(13)
m7
(9)
m7
(11)
M7
(9)
mM7
(9)
5
8
• Since the chord input range is limited, this model may not support some of the chords shown above.
• Debido a que el rango de entrada de acordes es limitado, es posible que este modelo no admita algunos de los acordes mostrados arriba.
PX360-ES-1A.indd 157 2015/04/24 12:47:24
A-17
Appendix/Apéndice
■ Port A: Keyboard, Auto Accompaniment
play, other/
Puerto A: Teclado, reproducción del
acompañamiento automático, otros
■ Port B: MIDI Recorder system track
playback/
Puerto B: Reproducción de la pista del
sistema del grabador MIDI
■ Port C: MIDI Recorder solo track playback/
Puerto C: Reproducción de solo pista del
grabador MIDI
Part and MIDI Channel
Assignments/
Asignaciones de las partes y
de los canales MIDI
Part No./
Nº de la
parte
MIDI Channel/
Canal MIDI *
1
Function/Función
1 In:1 Out:01 *
2
Upper1
2 In:2 Out:02 Upper2
3 In:3 Out:03 Lower1
4 In:4 Out:04 Lower2
5 In:5 Out:05 Auto Harmonize
6 In:6 –
7 In:7 –
8 In:8 Metronome
9 In:9 Out:9 Accomp Percussion *
3
10 In:10 Out:10 Accomp Drum *
3
11 In:11 Out:11 Accomp Bass *
3
12 In:12 Out:12 Accomp Chord1 *
3
13 In:13 Out:13 Accomp Chord2 *
3
14 In:14 Out:14 Accomp Chord3 *
3
15 In:15 Out:15 Accomp Chord4 *
3
16 In:16 Out:16 Accomp Chord5 *
3
Part No./
Nº de la
parte
MIDI Channel/
Canal MIDI *
1
Function/Función
1 In:1 MIDI Recorder System Track Upper1
2 In:2 MIDI Recorder System Track Upper2
3 In:3 MIDI Recorder System Track Lower1
4 In:4 MIDI Recorder System Track Lower2
5 In:5
MIDI Recorder System Track Auto
Harmonize
6 In:6 –
7 In:7 –
8 In:8 –
9 In:9 –
10 In:10 –
11 In:11 –
12 In:12 –
13 In:13 –
14 In:14 –
15 In:15 –
16 In:16 –
Part No./
Nº de la
parte
MIDI Channel/
Canal MIDI *
1
Function/Función
1 In:1 MIDI Recorder Solo Track 1
2 In:2 MIDI Recorder Solo Track 2
3 In:3 MIDI Recorder Solo Track 3
4 In:4 MIDI Recorder Solo Track 4
5 In:5 MIDI Recorder Solo Track 5
6 In:6 MIDI Recorder Solo Track 6
7 In:7 MIDI Recorder Solo Track 7
8 In:8 MIDI Recorder Solo Track 8
9 In:9 MIDI Recorder Solo Track 9
10 In:10 MIDI Recorder Solo Track 10
11 In:11 MIDI Recorder Solo Track 11
12 In:12 MIDI Recorder Solo Track 12
13 In:13 MIDI Recorder Solo Track 13
14 In:14 MIDI Recorder Solo Track 14
15 In:15 MIDI Recorder Solo Track 15
16 In:16 MIDI Recorder Solo Track 16
*1 The port that accepts MIDI In messages depends on the
MIDI In port setting.
*2 The MIDI Out channel number of Port A Part 1 depends
on the keyboard channel setting.
*3 Also used for Auto Accompaniment play by MIDI
Recorder system track playback.
*1 El puerto que acepta los mensajes de entrada MIDI
depende del ajuste del puerto de entrada MIDI.
*2 El número del canal de salida MIDI del Puerto A Parte 1
depende del ajuste del canal del teclado.
*3 También se utiliza para la ejecución del acompañamiento
automático mediante la reproducción de la pista del
sistema del grabador MIDI.
PX360-ES-1A.indd 158 2015/04/24 12:47:25
• Cut this page along the dashed line so you can have it on hand as you read the contents of the manual.
• Recorte esta página por la línea de puntos para tenerla a mano mientras continúa leyendo este manual.
PX-360M
br bt ck cm cn
cr cs ctco cp
31
72 8 9 bo bp bqbk bl bm cq
4 56 cl
bs
PX360-ES-1A.indd 159 2015/04/24 12:47:25
Function Transmitted Recognized Remarks
Basic
Channel
1 - 16
1 - 16
1 - 16
1 - 16
Default
Changed
Note
Number
0 - 127 0 - 127
0 - 127
*
1True voice
After
Touch
Control
Change
X
X
X
O
Pitch Bender
OO
Key’s
Ch’s
Velocity
O
9nH v = 1 - 127
X
8nH v = 64
O
9nH v = 1 - 127
X
9nH v = 0, 8nH v =
**
Note ON
Note OFF
Mode
Mode 3
X
Mode 3
X
Default
Messages
Altered
0,32
1
5
6, 38
7
10
11
16
17
18
19
64
65
66
Bank select
Modulation
Portamento Time
Data entry LSB, MSB
*2
Volume
Pan
Expression
DSP Parameter0
*2
DSP Parameter1
*2
DSP Parameter2
*2
DSP Parameter3
*2
Damper
Portamento Switch
Sostenuto
Sf
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
O
O
X
X
X
X
X
X
O
X
O
Model PX-360M Version : 1.0
** : no relation
** : sin relación
MIDI Implementation Chart
PX360-ES-1A.indd 162 2015/04/24 12:47:25
Function Transmitted Recognized Remarks
Basic
Channel
1 - 16
1 - 16
1 - 16
1 - 16
Default
Changed
Note
Number
0 - 127 0 - 127
0 - 127
*
1True voice
Program
Change
OO
0 - 127:True #
After
Touch
Control
Change
X
X
X
O
Pitch Bender
OO
System Exclusive
OO
Key’s
Ch’s
Velocity
O
9nH v = 1 - 127
X
8nH v = 64
O
9nH v = 1 - 127
X
9nH v = 0, 8nH v =
**
Note ON
Note OFF
Mode
Mode 3
X
Mode 3
X
Default
Messages
Altered
System
Common
X
X
X
X
X
X
: Song Pos
: Song Sel
: Tune
Aux
Messages
Remarks
O
O
X
O
X
X
O
O
X
O
O
X
: All sound off
:
Reset all controller
: Local ON/OFF
: All notes OFF
: Active Sense
: Reset
System
Real Time
O
O
X
X
: Clock
: Commands
0,32
1
5
6, 38
7
10
11
16
17
18
19
64
65
66
67
76
77
78
80
81
82
83
84
88
91
93
94
100, 101
Bank select
Modulation
Portamento Time
Data entry LSB, MSB
*2
Volume
Pan
Expression
DSP Parameter0
*2
DSP Parameter1
*2
DSP Parameter2
*2
DSP Parameter3
*2
Damper
Portamento Switch
Sostenuto
Soft pedal
Vibrato rate
Vibrato depth
Vibrato delay
DSP Parameter4
*2
DSP Parameter5
*2
DSP Parameter6
*2
DSP Parameter7
*2
Portamento Control
High resolution velocity prefix
*3
Reverb send
Chorus send
Delay send
RPN LSB, MSB
*2
Mode 1 : OMNI ON, POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON, MONO
Mode 4 : OMNI OFF, MONO
O : Yes
X : No
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
X
X
O
O
X
X
X
X
X
X
O
X
O
O
X
X
X
X
X
X
X
X
O
O
O
O
O
*2
Model PX-360M Version : 1.0
*1 : Depends on tone
*2 : For details, see MIDI Implementation at http://world.casio.com/
.
*3 : Note on only
*1 : Depende del tono
*2 : Si desea más información, vea Implementación MIDI en http://world.casio.com/
.
*3 : Nota activada solamente
PX360-ES-1A.indd 2 2015/04/24 12:46:39
PX360-ES-1A
EN/ES
Safety Precautions
Before trying to use the Digital Piano, be sure to
read the separate “Safety Precautions”.
Precauciones de seguridad
Antes de intentar usar el piano digital, asegúrese
de leer las “Precauciones de seguridad” separadas.
USER’S GUIDE
GUÍA DEL USUARIO
Please keep all information for future reference.
Guarde toda información para tener como referencia futura.
EnglishEspañol
PX
-
360M
This recycle mark indicates that the packaging conforms to
the environmental protection legislation in Germany.
Esta marca de reciclaje indica que el empaquetado se
ajusta a la legislación de protección ambiental en Alemania.
MA1504-A Printed in China
C
PX360-ES-1A.indd 1 2015/04/24 12:46:39
