MAIN FEATURES
PARTS AND FUNCTIONS
•
Powerful ush: Improved pressurized T-type 3 way ush
ow creates high-speed, full bowl rinsing.
Two ush types available
1. Push button ush: Connect the water inlet of the toilet to
a water supply system if available.
Flush the toilet by pressing the orange ush button.
2. Manual piston pump ush: Each of our cassette toilet has
a built-in 17L ush tank. Through the water ll cap, you can
add clean water into the ush tank. To ush the toilet, just
move the piston pump up and down several times.
•
Scratch-resistant plastic inlay. High gloss nish, easy to clean.
•
Removable wheeled waste water tank with level indicator,
vent button and emptying spout.
www.SereneLifeHome.com
A. Seat & lid.
B. Flush valve.
C. Flush water tank.
D. Toilet base
E. Flush piston pump: the toilet ushes when the piston pump is moved up and down
(water from the self-contained ush tank, capacity: 17L).
F. Removable waste water tank, capacity: 24L
G. Water inlet (can connect to a water supply system when available)
H. Manual ush button when the toilet is connected to water supply system.
I. Cap of ush water tank.
J. Rotating emptying spout: ensures that the waste tank can be easily and hygienically emptied.
K. Level indicator: when it turns red, the waste tank requires emptying.
L. Vent button: Always press the vent button to release air pressure inside the waste holding tank to avoid
waste spills before opening the ush valve. When emptying the waste tank, press the vent button to
prevent splashing.
INTRODUCTION
Cassette toilet is made up of two parts: a permanently toilet frame and a waste holding tank that is
removeable from the back side. The removable waste tank is located under the toilet and can be pulled
out for emptying and cleaning.
PREPARING FOR USE
1. Fill the ush tank with clean water or connect the water inlet at the rear of the toilet to a water supply
system. (Fig 1)
2. Press the vent button to release air pressure inside the waste holding tank to avoid waste spills before
opening the ush valve. (Fig 2)
3. Pull out the ush valve. Drop 1 toilet treatment pod & add 1 liter water into the waste holding tank
through the opening. (Fig 3)
•
Any brand of RV toilet treatment pod is working. It helps to break down waste, avoid unpleasant smells
in the waste tank and keeps the inside of the waste tank clean*
1 2
3
www.SereneLifeHome.com
A. Seat & lid.
B. Flush valve.
C. Flush water tank.
D. Toilet base
E. Flush piston pump: the toilet ushes when the piston pump is moved up and down
(water from the self-contained ush tank, capacity: 17L).
F. Removable waste water tank, capacity: 24L
G. Water inlet (can connect to a water supply system when available)
H. Manual ush button when the toilet is connected to water supply system.
I. Cap of ush water tank.
J. Rotating emptying spout: ensures that the waste tank can be easily and hygienically emptied.
K. Level indicator: when it turns red, the waste tank requires emptying.
L. Vent button: Always press the vent button to release air pressure inside the waste holding tank to avoid
waste spills before opening the ush valve. When emptying the waste tank, press the vent button to
prevent splashing.
INTRODUCTION
Cassette toilet is made up of two parts: a permanently toilet frame and a waste holding tank that is
removeable from the back side. The removable waste tank is located under the toilet and can be pulled
out for emptying and cleaning.
PREPARING FOR USE
1. Fill the ush tank with clean water or connect the water inlet at the rear of the toilet to a water supply
system. (Fig 1)
2. Press the vent button to release air pressure inside the waste holding tank to avoid waste spills before
opening the ush valve. (Fig 2)
3. Pull out the ush valve. Drop 1 toilet treatment pod & add 1 liter water into the waste holding tank
through the opening. (Fig 3)
•
Any brand of RV toilet treatment pod is working. It helps to break down waste, avoid unpleasant smells
in the waste tank and keeps the inside of the waste tank clean*
USE
1. Pull out the ush valve to use the toilet. (Fig 4)
2. After use, ush the toilet by moving the piston pump up and down or by pressing the orange ush
button for seconds when water supply is connected. (Fig 5)
3. Close the ush valve after ushing. (Fig 6)
EMPTYING
The waste holding tank must be emptied when the indicator turns red. It is advisable to empty the
waste holding tank earlier.
Note!
Do not allow the waste holding tank to become too full.
1. Make sure that the ush valve is closed. Pull the waste tank out from the toilet. (Fig 7)
2. Carry the holding tank to a normal toilet or to a legal waste disposal site.
3. Remove the emptying spout cap. Empty the waste. (Fig 8)
4. After emptying, ush the waste holding tank and clean the ush valve thoroughly with water.
Slide the waste tank back into the toilet. (Fig 9)
4
5
6
7 8 9
www.SereneLifeHome.com
MAINTENANCE
The ush valve seal must be cleaned regularly.
Lubricate the seal periodically with silicone spray or paste lubricant.
WINTER USE AND STORAGE
You can continue to use the cassette toilet in cold weather, as long as the toilet is situated in a heated
location. If not, there is a risk of freezing. In this case we advise that the toilet is drained by the follow-
ing procedures.
1. Empty the ush water tank by moving the ush piston pump up and down or by pressing the ush
button. Flush the tank until it is empty and no more water is being pumped out.
2. Empty the waste holding tank. To allow the tank to dry, do not place the cap back on the emptying
spout of the waste tank.
FEATURES:
•
Compact, Portable & Comfortable
•
Home-like Comfort: Ergonomic Toilet Seat
•
Water-Saving T-type Water Outlet for Full-bowl Flush Coverage
•
Flushes and Rinses Bowl with Fresh Water Reserve
•
Extra Large Detachable Waste Water Tank with Level Indication & Air Release Vent Button
•
Rugged & Durable Construction
•
Corrosion-Resistant & Easy-to-Clean
•
Button-Styled Pump Flusher with A Water Supply System to Flush
•
Water Tank Capacity for Up to 120+ Flushes
•
Easy Access Waste Tank for Quick Disposal
•
Double-Sealed Drain Valve Protects Against Leaks & Odors
WHAT'S IN THE BOX:
•
Cassette Toilet
TECHNICAL SPECS:
•
Waste Holding Tank Capacity: 6.3 Gallon
•
Fresh Water Tank Capacity: 4.5 Gallon
•
Flush Pump Type I: Piston Pump with Fresh Water Reserve
•
Flush Pump Type II: Button-Styled Pump Flusher
with A Water Supply System
•
Empty Type: Rotating No-Splash Pour Spout
•
Construction Material: High-Density Polyethylene
•
Product Dimensions (L x W x H): 20.8’’ x 15.6’’ x 18.9’’ -inches
USE
1. Pull out the ush valve to use the toilet. (Fig 4)
2. After use, ush the toilet by moving the piston pump up and down or by pressing the orange ush
button for seconds when water supply is connected. (Fig 5)
3. Close the ush valve after ushing. (Fig 6)
EMPTYING
The waste holding tank must be emptied when the indicator turns red. It is advisable to empty the
waste holding tank earlier.
Note!
Do not allow the waste holding tank to become too full.
1. Make sure that the ush valve is closed. Pull the waste tank out from the toilet. (Fig 7)
2. Carry the holding tank to a normal toilet or to a legal waste disposal site.
3. Remove the emptying spout cap. Empty the waste. (Fig 8)
4. After emptying, ush the waste holding tank and clean the ush valve thoroughly with water.
Slide the waste tank back into the toilet. (Fig 9)
