USER INSTRUCTIONS
The Security+ ®remote control works only with door
openers and light controls having an orange "Learn"
button and yellow indicator light,
Programming instructions are described and illustrated
below. The additional push buttons can also activate other
garage door openers and/or light controls. (Instructions for
programming light products are included with
those accessories.)
Remote Coding Instructions
1. Press and release the "learn" button
on the motor unit. The learn indicator
light will glow steadily for 30 seconds.
2. Within 30 seconds, press and hold the
button on the hand-held remote.
Model 139.53681 B
Security+ ®3-Function Remote Control
Model 139.53680
Security+ ®Compact 3-Function Remote Control
To prevent possible SERIOUSINJURYor DEATHfrom a
moving gate or garagedoor:
• ALWAYSkeepremote controls out of reachof children.
NEVERpermit children to operate,or playwith remote
control transmitters.
• Activate gateor door ONLYwhen it can be seenclearly, is
properly adjusted, and there are no obstructions to
door travel.
• ALWAYSkeepgateor garage door in sight until completely
closed. NEVERpermit anyoneto cross path of moving gate or
door.
To Control the Motor Unit Lights (Premium
Consoles Only)
With Security+ ®transmitters, a remote push button can be
programmed to operate the motor unit lights without
opening the door.
1. With the door closed, press and hold the remote button
that you want to control the light.
2. Press and hold the Light button on the door control.
3. Press and hold the Lock button on the door control.
4. After the motor unit lights flash, release all buttons.
Test by pressing the remote push button. The motor unit
lights should turn on or off but the door should not move.
The Remote Control Batteries
3. Release the button when the motor unit
light blinks. It has learned the code. If
light bulbs are not installed, two clicks will
be heard.
/
I
To Erase All Codes From Motor Unit
Memory __
To deactivate any unwanted remote, first
erase all codes.
Press and hold the "learn" button on motor
unit until the "learn" indicator light goes out (approximately
6 seconds). All previous codes are now erased.
Reprogram each remote or keyless entry you wish to use.
Replacement parts:
Security+ ®3-Function remote control
housing only (No circuit board) .............. 41A5032
Security+ ®Compact 3-Function remote control
housing only (No circuit board) .............. 41A5062
3V2032 Lithium battery:
(Models 139.53681B and 139.53680) ........... 10A20
3V2016 Lithium battery: (Model 139.53681) ...... 10A19
Visor clip: ................................ 29B134
114A2110D
Toprevent possible SERIOUSINJURYor DEATH:
• NEVERallow small children near batteries.
• If battery is swallowed, immediately notify doctor.
The lithium battery should produce 3-FUNCTION
Open this end _-_
power for up to 5 years. To replace t_rStc_aok,_g__t°avoi_
battery, use the visor clip or hoo
screwdriver blade to pry open the s_,_o_-_/f
case as shown. Insert battery
matching polarity instructions COMPACT_
Twist here
inside the remote cover or on the toopen _--v_
printed cirucuit board.
Dispose of old battery properly.
NOTICE:Tocomply with FOCand or Industry Canada(IO)rules, adjustment or modificationsof
this receiverand/or transmitter are prohibited,exceptfor changingthe codesetting or replacing
the battery.THEREARENOOTHERUSERSERVICEABLEPARTS.
I Testedto Complywith FCCStandardsFORHOMEOROFFICEUSE.Operationis snbjecttothe
following two conditions: (1) this device mat not causeharmful interference,and (2)this device
must acceptany interferencereceived,including interferencethat may causeu desired operation.
To order replacement parts call...
1-800-4-MY-HOME ® (1-800-469-4663)
© 2006, Sears, Roebuck and Co,/® Registered Trademark / TMTrademark /
sMService Mark of Sears, Roebuck and Co,
® Marca Registrada / TMMarca de Fabrica / sMMarca de Servicio de Sears,
Roebuck and Co.
