HHF250
TWO POSITION HEATER
Owner’s Manual
If you have any questions about the operation of this
product, please call us toll-free at 1-800-477-0457,
e-mail us at [email protected],
or visit our website at: www.HoneywellPluggedIn.com
2
WARNING – READ AND SAVE THESE OPERATING
AND SAFETY INSTRUCTIONS BEFORE USING THIS
HEATER. IF YOU DO NOT UNDERSTAND THESE
INSTRUCTIONS OR PRODUCT LABELS PLEASE
CALL OUR CUSTOMER REPRESENTATIVES AT
18004770457 FOR ASSISTANCE BEFORE
USING THIS PRODUCT.
WARNING – Failure to follow any of these safety
instructions could result in fire, injury, or death.
YOUR RESPONSIBILITIES
Electrical appliances may expose people to hazards
that can cause severe injury as well as death. The use
of electrical products may create hazards that include,
but are not limited to, injury, fire, electric shock and
electrical system damage. These instructions are
intended to provide you with the information you need
to use the product correctly and to avoid such hazards.
When using electrical appliances, basic precautions
should always be followed to reduce risk of fire,
electric shock, and injury to persons including the
following:
1. WARNING – Read all instructions before using
this heater.
2. WARNING – NEVER leave an operating
unit unattended.
3. WARNING – This heater is hot when in use. To
avoid burns, DO NOT let bare skin touch hot
surfaces. Use handles when moving this heater.
Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at
least 3 feet (0.9m) from the front of the heater
and keep them away from all sides of the heater.
4. WARNING – Extreme caution is necessary when
any heater is used by or near children or invalids.
5. WARNING – ALWAYS unplug heater when not
in use.
6. WARNING – DO NOT operate any heater
with a damaged cord or plug, any heater that
malfunctions, or any heater that has been
dropped or damaged in any manner. Discard
heater or return heater to authorized service
facility for examination and/or repair.
7. WARNING – For residential use only.
8. WARNING – DO NOT use outdoors.
9. WARNING – This heater is not intended for use
in bathrooms, laundry areas and similar indoor
locations. DO NOT locate heater where it may
fall into a bathtub or other water container.
10. WARNING – DO NOT run cord under carpeting.
DO NOT cover cord with throw rugs, runners,
or similar coverings. DO NOT route cord under
furniture or appliances. Arrange cord away
from traffic areas and where it will not be a
tripping hazard.
11. WARNING – This appliance has a polarized plug
(one blade is wider than the other). To reduce
the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug
does not fit fully in the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety feature.
12. WARNING – This heater draws 9.17 amps during
operation. To prevent overloading a circuit,
DO NOT plug the heater into a circuit that already
has other appliances working.
13. WARNING – It is normal for the plug to feel
warm to the touch; however, a loose fit between
the AC outlet (receptacle) and plug may cause
overheating and distortion of the plug. Contact a
qualified electrician to replace loose or worn outlet.
14. WARNING – To disconnect the heater, first turn
off the product, then grip the plug body and pull it
from the wall outlet. NEVER pull by the cord.
15. WARNING – DO NOT insert or allow foreign objects
to enter any ventilation or exhaust opening as
this may cause electric shock, fire, or damage
to the heater.
16. WARNING – To prevent a possible fire, DO NOT
block air intakes or exhaust in any manner.
DO NOT use on soft surfaces, like a bed, or where
openings may become blocked.
17. WARNING – A heater has hot and arcing or
sparking parts inside. DO NOT use it in areas
where gasoline, paint or flammable liquids are
used or stored.
18. WARNING – Use this heater only as described in
this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, or
injury to persons.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE SAFETY INSTRUCTIONS BEFORE
USING THIS HEATER
3
19. WARNING – ALWAYS plug heater directly into
a wall outlet/receptacle. DO NOT use with an
extension cord or relocatable power tap
(outlet/power strip).
20. WARNING – NEVER tamper with this product
or attempt to fix it. Any tampering with, or
modification of this product can result in serious
injury, death, or fire. DO NOT open. Risk of electric
shock. There are no user serviceable parts inside.
21. WARNING – DO NOT remove product labels
that contain warnings or safety instruction.
22. CAUTION – The output of this heater may vary
and its temperature may become intense enough
to burn exposed skin. Use of this heater is not
recommended for persons with reduced sensitivity
to heat or an inability to react to avoid burns.
23. CAUTION – Before cleaning, or storage, or when
not in use, turn the product’s controls to the OFF
position and unplug the heater from the electrical
outlet and allow to cool.
24. CAUTION – Place the heater on a firm, level, open
surface free from obstructions and at least 3 feet
(0.9m) away from any combustible materials.
DO NOT use on an unstable surface such as
bedding or deep carpeting. Be sure the heater is
not in a position where it may be a tripping hazard.
25. CAUTION – If your home has aluminum wiring
have a licensed electrician check your receptacle’s
connections. When using a 1100 watt heater,
aluminum wire connections can cause a safety issue.
26.
SAVE THESE INSTRUCTIONS
Place the heater on a firm, level, open surface free from obstructions and at least 3 feet (0.9 m) away from
any wall or combustible material. DO NOT use on an unstable surface such as bedding or deep carpeting.
BE SURE THE HEATER IS NOT IN A POSITION WHERE IT MAY BE A TRIPPING HAZARD.
SET-UP
Turn off the heater.
Allow it to cool for ten minutes.
Unplug heater and move it to the desired location. This heater is equipped with a Cool Touch Handle for
your convenience.
MOVING THE HEATER
4
SAFETY FEATURES
This heater is equipped with several devices and features for added protection:
• A high temperature safety sensor prevents overheating. If activated, unplug the device and wait at least
10 minutes or allow the unit to cool completely. Make sure the operating conditions are safe and then
plug the heater back in and follow the OPERATION instructions.
• A thermal cut-off fuse that will permanently shut down the heater should it operate at a higher than
normal temperature.
• A high temperature plastic and a cool to touch housing and handle.
• Thermal insulated wiring for heat resistance and reinforced wire connections to help protect against
loose connections.
OPERATION
• With the Power Knob in the OFF ( ) position, plug
the heater into a polarized 120V outlet.
DO NOT FORCE THE POLARIZED PLUG INTO THE OUTLET;
it will only fit one way
• The Power Knob is equipped with three (3) settings: Fan Only
(
), Low ( ) and High ( ). The Low ( ) heat setting uses 550
watts of power and the High (
) heat setting uses 1100 Watts of
power. The Fan only (
) setting uses very low power and does not
provide heat. You can select the proper setting to accommodate your
comfort level with the Power Knob. When you choose any setting the
red Power Light will come on. Because the Low (
) heat setting does
not require as much electricity to operate, it is more energy efficient
and may be a better option if you are concerned about the amperage
draw on a circuit when the heater is on the High setting.
• Turn the Thermostat Control fully clockwise to the highest setting.
• When the room reaches a comfortable temperature, slowly turn the
Thermostat Control counter-clockwise until the heating element
goes off (the red Power Light will not be shut off). This is the point at
which the Thermostat setting equals the room temperature. At this
setting, the Thermostat will automatically turn the heater on and off
to maintain the selected temperature.
• Turn the Power Knob to OFF (
) and unplug the heater when
you are finished using it. Unplug the heater when you are finished
using it.
NOTE: NEVER LEAVE AN OPERATING HEATER UNATTENDED
This heater can be operated in the upright position
or on its side.
5
CLEANING
We recommend that your heater be cleaned at least once a month and before off-season storage.
• Turn the heater OFF (
) and unplug it. Allow it to cool.
• Use a dry cloth only to clean the external surfaces of the heater. DO NOT USE WATER, WAXES, POLISHES
OR ANY CHEMICAL SOLUTION.
STORAGE
Clean your heater using the above-mentioned steps. Wrap the cord around the unit. Place in its original box and
store it in a cool, dry place.
TROUBLESHOOTING
If your heater shuts off unexpectedly or fails to operate, one of your heater safety features may have been
activated to prevent overheating.
• Be sure it is plugged in and that the electrical outlet is working.
• Check your Thermostat Control setting. The unit may simply be off because you have reached your desired
heat setting.
• Check for any obstructions. If you find an obstruction, turn the heater OFF (
) and unplug it. Allow the
heater to cool completely, then remove the obstruction. Wait at least 10 minutes, then plug the heater back
in and follow the OPERATION instructions.
PRODUCT SPECIFICATIONS
Model HHF250
Unit dims 5.4” L x 9.8” W x 11.3” H
Amps 9.17
Unit Voltage 120V, 60Hz
Max Watts 1100 Watts
Max BTUs 3753
Operation Cost* To estimate the cost to operate this heater, multiply the watts used by 0.001 to convert
into kilowatts then multiply by your local kilowatt electric rate for however long you run the heater.
For example, if your electric rate is $0.1284** per kilowatt hour and you ran this heater in constant high mode
(1100 Watts) for 4 hours, it would cost you $0.56 cents to run the heater (1100 Watts x 4 hours x 0.001) x
0.1284kwp = $0.56 cents.
NOTE: Because the Low setting does not require as much electricity to operate, it is more energy efficient and
may be a better option if you are concerned about the higher power consumption when the heater is on the
High setting.
* Calculation (Total Wattage x .001 x hours used) x Cost per Kilowatt Hour = Cost to operate
** Average Retail Price of Electricity to Ultimate Customer by EndUse, US Energy Information Administration,
October 2019.
6
3 YEAR LIMITED WARRANTY
YOU SHOULD FIRST READ ALL INSTRUCTIONS
BEFORE ATTEMPTING TO USE THIS PRODUCT.
A. This 3 year limited warranty applies to repair
or replacement of product found to be
defective in material or workmanship. This
warranty does not apply to damage resulting
from commercial, abusive, unreasonable use
or supplemental damage. Defects that are
the result of normal wear and tear will not be
considered manufacturing defects under this
warranty. KAZ IS NOT LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY
NATURE, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT
IS LIMITED IN DURATION TO THE DURATION
OF THIS WARRANTY. Some jurisdictions do not
allow the exclusion or limitation of incidental or
consequential damages or limitations on how
long an implied warranty lasts, so the above
limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and
you also may have other rights which vary from
jurisdiction to jurisdiction. This warranty applies
only to the original purchaser of this product
from the original date of purchase.
B. At its option, Kaz will repair or replace this
product if it is found to be defective in material or
workmanship.
C. This warranty does not cover damage resulting
from any unauthorized attempts to repair or from
any use not in accordance with the instruction
manual.
CONSUMER RELATIONS
Call us toll-free at: 18004770457
E-mail: ConsumerRelations@HelenofTroy.com
Or visit our website at:
www.HoneywellPluggedIn.com
Please be sure to specify a model number.
NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST OR SEE YOUR
WARRANTY. DO NOT RETURN THE PRODUCT TO THE ORIGINAL PLACE OF PURCHASE. DO NOT ATTEMPT
TO OPEN THE MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR WARRANTY AND CAUSE
DAMAGE TO THE PRODUCT OR PERSONAL INJURY.
7
8
For responsible recycling, please visit:
www.RecycleNation.com
© 2020 All rights reserved.
Kaz USA, Inc., a Helen of Troy Company
Marlborough, MA 01752
www.HoneywellPluggedIn.com
ConsumerRelations@HelenOfTroy.com
Honeywell is a trademark of Honeywell International Inc.,
used under license by Helen of Troy Limited.
Honeywell International Inc., makes no representation or
warranties with respect to this product.
A004702R0
10MAR20
