IMPORTANT SAFETY INSTRUCTIONS
• Review all instructions before assembling the cart.
• Improper assembly can cause personal injury and/or property damage.
• Do not overload cart. See specifications for load capacity (distributed evenly).
• Do not step into or on the cart, or use it as a toy.
Assembly
#141011 (Model PUC-3819)
Flat Top Heavy-Duty Utility Cart
5
Tools required: cross-point
screwdriver, and rubber or wood
mallet.
Use the mallet to tap down the parts
to ensure they are seated properly
before fastening them with screws.
2
1
3
4
WARNING: This product can expose you to chemicals including lead which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more information go to http://www.p65warnings.ca. gov.
2
Parts Breakdown
Index
no.
Part no.
Description
Qty.
1
PUC3819-01
Upper Platform 97 x 48 in
1
2
PUC3819-02
Bottom Platform
1
3
PUC3819-03
Cross Head Screw M6x25
4
4
PUC3819-04
Leg Screw 6x18mm
4
5
PUC3819-05
Leg Square Nut M4
4
6
PUC3819-06
Leg
4
7
PUC4325-SCA
Swivel Caster Assembly 5in.
2
8
PUC4325-FCA
Fixed Caster Assembly 5in.
2
9
TS-2361081
Spring Washer 8mm
16
10
TS-1540061
Hex Nut M8
16
11
GB82786-2-5
Carriage Bolt M8x57mm
16
Specifications
Stock number
141011
Model number
PUC-3819
Load capacity
550 lb (250 kg)
Upper platform size,
including handle (L x W)
38 x 19 in. (97 x 48 cm)
Height between platforms
22-1/4 in. (56.5 cm)
Upper platform height from floor
32-1/4 in. (82 cm)
Caster size (OD x W)
5 x 1 in. (12.5 x 2.6 cm)
Overall dimensions (L x W x H)
38 x 19 x 32-1/4 in.
(97 x 48 x 82 cm)
Net weight (approx.)
37.4 lb (17 kg)
Shipping weight (approx.)
40.8 lb (18.5 kg)
Cart material
Polypropylene
To order parts visit www.store.jettools.com, or call 1-800-274-
6848 Monday through Friday, 8:00 a.m. to 5:00 p.m. CST. Having
the Model Number and Serial Number of your unit available when
you call will allow us to serve you quickly and accurately.
Non-proprietary parts, such as fasteners, can be found at local
hardware stores, or may be ordered from JET.
Some parts are shown for reference only, and may not be
available individually.
