5KFP1335
5KFP1325
English ................................................................................ 5
Deutsch ............................................................................ 35
Français ............................................................................65
Italiano .............................................................................. 95
Nederlands .................................................................... 125
Español ........................................................................... 155
Português ....................................................................... 185
Ελληνικά .........................................................................215
Svenska .......................................................................... 245
Norsk .............................................................................. 275
Suomi .............................................................................. 305
Dansk .............................................................................. 335
Íslenska ........................................................................... 365
Русский .......................................................................... 395
Polski ............................................................................... 425
Český .............................................................................. 455
............................................................................. 485
4
5
English
FOOD PROCESSOR SAFETY
Important safeguards ................................................................................................. 6
Electrical requirements ............................................................................................. 8
Electrical equipment waste disposal .......................................................................... 8
PARTS AND FEATURES
Parts and accessories ................................................................................................. 9
Important food processor features ......................................................................... 10
ACCESSORIES
Included accessories ................................................................................................ 11
Disc assembly overview .......................................................................................... 12
Accessories selection guide ..................................................................................... 13
PREPARING THE FOOD PROCESSOR FOR FIRST USE
Beforerstuse ........................................................................................................ 14
Removing the work bowl cover from the work bowl .............................................14
SETTING UP YOUR FOOD PROCESSOR
Attaching the work bowl ......................................................................................... 15
Attaching the work bowl cover ............................................................................... 16
Installing the adjustable slicing disc .......................................................................... 17
Adjusting the slicing thickness.................................................................................. 18
Installing the shredding disc ..................................................................................... 19
Installing the multipurpose blade or dough blade* .................................................. 20
Installing the mini-bowl* and mini-blade*................................................................ 21
Installing the egg whip* ............................................................................................ 22
Using the 3-in-1 feed tube ....................................................................................... 23
USING YOUR FOOD PROCESSOR
Before use ............................................................................................................... 24
Using the speed1/speed 2 control ........................................................................... 25
Using the pulse control ............................................................................................ 25
Removing processed foods ......................................................................................26
CARE AND CLEANING .............................................................................................. 27
TIPS FOR GREAT RESULTS
Using the multipurpose blade .................................................................................. 28
Using a slicing or shredding disc .............................................................................. 29
Using the dough blade* ........................................................................................... 30
Helpful hints ............................................................................................................ 30
TROUBLESHOOTING ................................................................................................ 32
WARRANTY AND SERVICE ...................................................................................... 33
FOOD PROCESSOR INSTRUCTIONS
TABLE OF CONTENTS
* Included only in model 5KFP1335
6
FOOD PROCESSOR SAFETY
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including
the following:
1. Read all instructions. Misuse of appliance may
result in personal injury.
2. To protect against risk of electrical shock, do not
put Food Processor in water or other liquid.
3. This appliance is not intended for use by persons
with reduced physical sensory or mental capabilities,
or lack of experience and knowledge, unless they
have been given supervision or instructions concerning
use of the appliance in a safe way and understand
the hazards involved.
4. Children should be supervised to insure they do
not play with the appliance. The appliance is not
to be used by children. The appliance and cord
should be out of reach of children. Children shall
not clean or perform user maintenance on the
appliance without supervision.
7
English
FOOD PROCESSOR SAFETY
5. Unplug from the outlet when not in use, before putting
on or taking off parts, and before cleaning.
6. Avoid contacting moving parts.
7. Do not operate any appliance with a damaged cord or
plug, or after the appliance malfunctions, or is dropped
or damaged in any manner. Return appliance to the
nearest Authorized Service Facility for examination,
repair, or electrical or mechanical adjustment.
8. The use of attachments not recommended or sold by
KitchenAid may cause re, electric shock, or injury.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter.
11. Keep hands and utensils away from moving blades
or discs while processing food to reduce the risk
of severe injury to persons or damage to the Food
Processor. A scraper may be used but must be used
only when the Food Processor is not running.
12. Blades are sharp. Care should be taken when
handling the sharp cutting blades, emptying the
bowl and during cleaning.
13. To reduce the risk of injury, never place cutting blade
or discs on base without rst putting bowl properly
in place.
14. Be certain cover is securely locked in place before
operating appliance.
15. Never feed food by hand. Always use the food pusher.
16. Do not attempt to defeat the cover interlock
mechanism.
8
Voltage: 220-240 Volts
Frequency: 50/60 Hertz
Wattage: 300 Watts
NOTE: Iftheplugdoesnottintheoutlet,
contactaqualiedelectrician.Donotmodify
the plug in any way.
Electrical requirements
Electrical equipment waste disposal
FOOD PROCESSOR SAFETY
SAVE THESE INSTRUCTIONS
17. This appliance is intended to be used in household
and similar applications such as:
- staff kitchen areas in shops, ofces or other
working environments.
- farm houses.
- by clients in hotels, motels and other residential
type environments.
- bed and breakfast type environments.
18. Be careful if hot liquid is poured into the Food
Processor as it can be ejected out of the appliance
due to a sudden steaming.
Disposal of packing material
The packing material is 100% recyclable
and is marked with the recycle symbol .
The various parts of the packing must
therefore be disposed of responsibly
and in full compliance with local authority
regulations governing waste disposal.
Scrapping the product
- This appliance is marked in compliance
withEuropeanDirective2012/19/EU,Waste
Electrical and Electronic Equipment (WEEE).
- By ensuring this product is disposed of
correctly,youwillhelppreventpotential
negative consequences for the environment
andhumanhealth,whichcouldotherwise
be caused by inappropriate waste handling
of this product.
- The symbol
on the product or on the
accompanying documentation indicates
that it should not be treated as domestic
waste but must be taken to an appropriate
collection center for the recycling of
electrical and electronic equipment.
For more detailed information about
treatment,recoveryandrecyclingofthis
product,pleasecontactyourlocalcityofce,
your household waste disposal service or the
shop where you purchased the product.
9
English
PARTS AND FEATURES
Parts and accessories
Reversible (2 mm and 4 mm)
shredding disc
Externally adjustable slicing
disc (thin to thick)
Stainless steel
multipurpose blade
Dough blade*
Disc
adapter
Slicing
adapter
Drive
adapter
950 mL (4-cup)
Mini-bowl* and mini-blade*
Base
3.1 L (13-cup)
work bowl
Work bowl cover
with 3-in-1
feed tube
3-Piece food
pusher
Accessory case*
Externally
adjustable
slicing control
Egg whip*
* Included only in model 5KFP1335
10
PARTS AND FEATURES
Important Food Processor features
Externally adjustable slicing control
KitchenAid’s exclusive externally adjustable
slicing disc allows you to adjust slicing
thicknessfromthintothick,withouthaving
to remove the blade assembly. With the
slicingdiscinstalled,simplyslidetheSlicing
Thickness Control to the desired setting - no
need to remove the cover or even turn off
the Food Processor!
Speed 1/ speed 2 /pulse control
Two speeds and Pulse provide precise
control to give great results with most
any food.
Work bowl cover with 3-in-1 feed tube
The 3-in-1 feed tube accommodates large
items–liketomatoes,cucumbers,and
potatoes – with a minimum of sectioning
or slicing.
3-Piece food pusher
Three pushers are nested inside of each
other. Remove the medium pusher from
the large pusher to reveal a medium-size
feed tube for continuous processing.
For continuous processing of smaller items
(likeherbs,nuts,singlecarrots,andcelery),
remove the narrow pusher and use the
narrow feed tube.
A small hole in the bottom of the narrow
pusher makes it easy to drizzle oil into
ingredients–justllwiththedesired
amount of oil or other liquid ingredient.
Heavy-duty base
Theheavy,slip-resistantbasehelps
provide improved stability and reduced
vibration during tough food processing jobs.
11
English
Included accessories
ACCESSORIES
3.1 L (13-Cup) Work bowl
Thedurable,largeworkbowlprovides
capacity for large jobs.
950 mL (4-Cup) Mini-bowl*
and mini-blade*
Mini-bowl and stainless steel mini-blade are
perfect for small chopping and mixing jobs.
Externally adjustable slicing disc
Disc is adjustable from approximately
1 to 6 mm (1/16 to 1/4 inch) for slicing
most foods.
Reversible shredding disc
Shreddingdiscisreversibletoallowcoarse
ornelyshreddedcheeseorvegetables.
Drive adapter
The drive adapter is used with the
appropriate adapter to connect the slicing/
shredding discs and mini-blade* to the
power shaft on the base.
Slicing adapter
Adaptertsoverthedriveadapterandinto
the bottom of the adjustable slicing disc.
Disc adapter
Adaptertsoverthedriveadapterand
into the bottom of the shredding disc.
Stainless steel multipurpose blade
Versatilebladechops,minces,blends,mixes,
andemulsiesinamatterofseconds.
Dough blade*
The dough blade is specially designed for
mixing and kneading yeast dough.
Egg whip*
The egg whip will quickly whip egg whites
formeringues,m
ousses,soufés,and
desserts.
Accessory case*
Stylishanddurablecaseorganizes and protects
blades,discs,andaccessories.
Spatula/cleaning tool*(not shown)
Specialshapefacilitatesfoodremovalfrom
bowls,discs,andblades.
* Included only in model 5KFP1335
12
ACCESSORIES
Disc assembly overview
There are two different disc adapters included with the food processor. One is used
exclusivelywiththeadjustableslicingdisc.TheotherisusedwiththeReversibleShredding
Disc and all other optional discs.
Adjustable
slicing disc
Reversible
shredding disc
Slicing
adapter
Disc
adapter
Drive
adapter
Drive
adapter
Properly
assembled
13
English
Accessories selection guide
Cheese
Chocolate
Fruit
Fresh Herbs
Nuts
Tofu
Vegetables
Meat
PastaSauce
Pesto
Salsa
Sauces
Cake Batter
Pie Dough
Eggs
Yeast Dough
Potatoes
Vegetables (soft)
Cabbage
Cheese
Chocolate
Fruit (hard)
Vegetables (hard)
Fruit (soft)
Potatoes
Tomatoes
Vegetables (soft)
Cheese
Chocolate
Fruit (hard)
Vegetables (hard)
Slice
thick
Slice
thin
Shred
medium
Shred
ne
Whip
Action Setting Food Accessory
ChopMince Puree
Mix
Knead
Or
Multipurpose stainless steel blade
Adjustable slicing disc
Reversible shredding disc
Plastic dough blade*
Egg whip*
Mini-bowl* and mini multipurpose
Stainless steel blade*
ACCESSORIES
* Included only in model 5KFP1335
14
Removing the work bowl cover from the work bowl
Before rst use
PREPARING THE FOOD PROCESSOR FOR FIRST USE
YourFoodProcessorisshippedwiththeworkbowlcoverinstalledontheworkbowl,withthe
mini-bowl* inside the work bowl.
To remove the work bowl cover from the work bowl for initial cleaning:
BeforeusingyourFoodProcessorforthersttime,washtheworkbowl,workbowlcover,
mini-bowl*,feedtubepushers,discs,andbladeseitherbyhandorinthedishwasher(see
“Cleaning the Food Processor”).
1
Grasp the feed tube on the work bowl
cover and turn it clockwise to remove it
from the work bowl.
2
Lift out the mini-bowl*.
Oncewashed,disassembleddiscs,shafts,
and blades should be stored in the provided
storagecase*,inalocationoutofthereach
of children. The mini-bowl* can nest inside
the work bowl for convenient storage.
* Included only in model 5KFP1335
15
English
SETTING UP YOUR FOOD PROCESSOR
Attaching the work bowl
NOTE:Selecttheaccessoryyouwouldliketouseandinstallitaccordingtothe
instructions on the following pages.
Power Shaft
1
PlacetheFoodProcessoronadry,level
countertop with the controls facing
forward. Do not plug in the Food
Processor until it is completely assembled.
2
Placetheworkbowlonthebase,
aligning the raised portion with the
indentation on the base. The center
holeshouldtoverthepowershaft.
3
Grasp the work bowl handle and
turn the bowl counterclockwise
to lock it on the base.
16
Attaching the work bowl cover
SETTING UP YOUR FOOD PROCESSOR
Food
pusher
1
Place the work bowl cover on the
work bowl with the feed tube just to
the left of the work bowl handle. Grasp
the feed tube and turn the cover to the
right until it locks into place.
2
Fit the food pusher into the 3-in-1
feedtube.See“Usingthe3-in-1
Feed Tube” for details on working with
different sized foods.
NOTE: Be sure to install the desired
accessory before attaching the work
bowl cover.
NOTE: Your Food Processor will not operate unless the work bowl and work bowl cover are
properlylockedonthebase,andthelargepusherisinsertedtothemaximumlllineonthe
feed tube (approximately halfway down).
17
English
SETTING UP YOUR FOOD PROCESSOR
Installing the adjustable slicing disc
1
Withtheworkbowlinstalled,place
the drive adapter on the power shaft
of the base.
2
Holding the adjustable slicing disc by
the2ngergrips,alignthepinsonto
the adjustable slicing disc adapter into
theL-slotsonthedisc.Slidethedisc
down onto the adapter and turn to
engage the pins in the L-slot.
3
Lower the slicing blade and slicing
adapter onto the drive adapter.
4
Installtheworkbowlcover,beingsure
it locks into place.
IMPORTANT: The adjustable slicing disc can only be installed in one direction.
TIP: You may need to turn the disc/drive adapter until it drops down into place.
18
SETTING UP YOUR FOOD PROCESSOR
Adjusting the slicing thickness
Thicker
Thinner
Setthedesiredslicingthicknessbymoving
the lever to the left for thinner slices or to
the right for thicker slices.
NOTE: The lever only works with the
adjustable slicing disc. Changing thickness
settings with other discs or blades installed
will have no effect on operation.
19
English
SETTING UP YOUR FOOD PROCESSOR
Installing the shredding disc
3
Withtheworkbowlinstalled,slidethe
drive adapter onto the power shaft.
2
Slidethedriveadapterintothedisc
adapterasfarasitwillgo,untilit
clicks into place.
1
Holdingthediscbythe2ngergrips,
insert the disc adapter into the hole in
the bottom of the disc.
4
Installtheworkbowlcover,beingsure
it locks into place.
IMPORTANT:Whenusingthereversibleshreddingdisc,havethedesiredside
(medium/ne)facingUP.
TIP: You may need to turn the disc/drive adapter until it drops down into place.
20
SETTING UP YOUR FOOD PROCESSOR
Installing the multipurpose blade or dough blade*
1
Place the blade on the power shaft.
Rotate the blade so it falls into place
on the power shaft.
2
Pushtolock.Pressdownrmlyonthe
multipurpose blade until it is down as
far as it will go. The multipurpose blade
featuresaninternalsealthattstightly
over the center of the work bowl.
Installtheworkbowlcover,being
sure it locks into place.
* Included only in model 5KFP1335
IMPORTANT: The multipurpose blade and dough blade* can only be used with the work bowl.
21
English
SETTING UP YOUR FOOD PROCESSOR
Installing the mini-bowl* and mini-blade*
3
Installtheworkbowlcover,beingsure
it locks into place.
2
Insert the drive adapter into the
mini-blade,andplaceonthepower
shaft. It may be necessary to rotate the
blade until it falls into place. Press down
rmlytolockitintoplace.
1
Place the mini-bowl inside the work
bowl over the power shaft. Rotate the
mini-bowl until the tabs on the top
edge of the bowl drops into the indents
on the top of the work bowl.
4
To remove the mini-bowl after
processing,removethemini-blade
by pulling straight up on the cap. Then
liftthebowlstraightupandout,using
thetwongergripslocatedalongthe
top edge of the bowl.
* Included only in model 5KFP1335
22
SETTING UP YOUR FOOD PROCESSOR
Installing the egg whip*
2
With the work bowl in place on the
base,placetheeggwhiponthepower
shaft. Rotate the egg whip so it falls into
place on the power shaft.
1
Be sure the egg whip is properly
assembled. If the two pieces have been
disassembledforcleaning,alignthepin
on the egg whip adapter with the slot
ontheeggwhip,androtatetolockinto
place.
3
Installtheworkbowlcover,beingsure
it locks into place.
IMPORTANT: The egg whip can only be used with the work bowl.
* Included only in model 5KFP1335
23
English
SETTING UP YOUR FOOD PROCESSOR
Using the 3-in-1 feed tube
The 3-in-1 feed tube features a 3-piece
food pusher. Use the entire food pusher
toprocesslargeitems,orusetheinner
portions to create medium-sized or small
feed tubes to process smaller items.
Tosliceorshredsmallitems,insertthe
3-piecefoodpusherintothefeedtube,then
lift out the small pusher to remove. Use the
small feed tube and pusher to process small
orslenderitems,likesinglecarrotsorcelery
stalks.Whennotusingthesmallfeedtube,
be sure to lock the small pusher into place.
To slowly drizzle oil or other liquid
ingredientsintotheworkbowl,justllthe
small pusher with the desired amount of
liquid. A small hole in the bottom of the
pusher will drizzle the liquid ingredient
at a constant rate.
24
USING YOUR FOOD PROCESSOR
Before use
BeforeoperatingtheFoodProcessor,
besuretheworkbowl,blades,andwork
bowl cover are properly assembled on the
FoodProcessorbase(see“SettingUpYour
Food Processor”).
This line on the work bowl indicates
the maximum level of liquid that can be
processed by the Food Processor.
25
English
Using the pulse control
USING YOUR FOOD PROCESSOR
The pulse control allows precise control of
the duration and frequency of processing.
It’s great for jobs which require a light touch.
JustpressandholdthePULSEButtonto
startprocessingathighspeed,andrelease
it to stop.
Using the speed 1/speed 2 control
IMPORTANT: Wait until the blade or disc comes to a complete stop before removing the
work bowl cover. Be sure to turn off the Food Processor before removing the work bowl
cover,orbeforeunpluggingtheFoodProcessor.
NOTE:IftheFoodProcessorfailstooperate,makesuretheworkbowlandcoverare
properlylockedonthebase(see“SettingUpYourFoodProcessor”).
2
TostoptheFoodProcessor,pressthe
O (OFF) button. The indicator light will
go out and the blade or disc will stop
within a few seconds.
1
ToturnontheFoodProcessor,press
theSpeed1button(lowspeed,for
softfood)ortheSpeed2button
(highspeed,forhardfood).TheFood
Processor will run continuously and the
indicator light will glow.
26
USING YOUR FOOD PROCESSOR
4
Ifusingthemini-bowl*,graspand
removethebowlusingthengergrips
located along the top edge of the bowl.
Removing processed foods
3
Ifusingadisc,removeitbefore
removing the bowl. Holding the
discbythe2ngergrips,liftit
straight up. Remove the adapter.
2
Turn the work bowl cover to the
left and remove.
1
Press the O (OFF) button. Unplug the
Food Processor before disassembling.
* Included only in model 5KFP1335
27
English
USING YOUR FOOD PROCESSOR
CARE AND CLEANING
5
Turn the work bowl to the left to
unlock it from the base. Lift to remove.
6
The multipurpose blade can be removed
from the work bowl before the contents
are emptied. You may also leave the
blade locked in place. Then remove food
from the bowl and blade with a spatula.
1. Press the O (OFF) button.
2. Unplug the Food Processor
before cleaning.
3. Wipethebaseandcordwithawarm,
sudsycloth,andwipecleanwithadamp
cloth. Dry with a soft cloth. Do not use
abrasive cleansers or scouring pads.
4. Please note these BPA-free bowls require
special handling. If you choose to use
adishwasherinsteadofhandwashing,
please follow these guidelines.
- All parts are top rack dishwasher safe.
- Avoid laying the bowl on its side.
- Avoid using high temperature settings
such as sanitize or steam settings.
5. If washing the Food Processor parts by
hand,avoidtheuseofabrasivecleansers
or scouring pads. They may scratch or
cloud the work bowl and cover.
Thoroughly dry all parts after washing.
6. To prevent damage to the locking
system,alwaysstoretheworkbowl
and work bowl cover in the unlocked
position when not in use.
7. Wrap the power cord around the work
bowl.Securetheplugbyclippingitto
the cord.
8. Disassembleddiscs,shafts,andblades
should be stored in the provided storage
case*,andinalocationoutofthereach
of children.
* Included only in model 5KFP1335
28
TIPS FOR GREAT RESULTS
To chop fresh fruits
or vegetables:
Peel,core,and/orremove
seeds. Cut food in 1 to
2.5-4 cm (1
1
/2-inch) pieces. Process food
todesiredsize,usingshortpulses,1to
2secondseachtime.Scrapesidesofbowl,
if necessary.
To puree cooked fruits and vegetables
(except potatoes):
Add 60 mL (1/4 cup) liquid from recipe per
235mL(1cup)offood.Processfood,using
shortpulses,untilnelychopped.Then
process continuously until reaching desired
texture.Scrapesidesofbowl,ifnecessary.
To prepare mashed potatoes:
Shredhotcookedpotatoesusingthe
shredding disc. Exchange shredding disc
formultipurposeblade.Addsoftenedbutter,
milk,andseasonings.Pulse3to4times,
2to3secondseachtime,untilsmoothand
milk is absorbed. Do not over process.
To chop dried (or sticky) fruits:
The food should be cold. Add 60 mL
(1/4cup)ourfromrecipeper120mL
(1/2cup)driedfruit.Processfruit,using
shortpulses,untilreachingdesiredtexture.
To nely chop citrus peel:
Withsharpknife,peelcoloredportion
(without white membrane) from citrus.
Cut peel in small strips. Process until
nelychopped.
To mince garlic or to chop fresh herbs
or small quantities of vegetables:
Withprocessorrunning,addfoodthrough
the feed tube. Process until chopped. For
bestresults,makesureworkbowland
herbs are very dry before chopping.
To chop nuts or make nut butters:
Process up to 710 mL (3 cups) of nuts to
desiredtexture,usingshortpulses,1to2
secondseachtime.Foracoarsertexture,
processsmallerbatches,pulsing1or2
times,1to2secondseachtime.Pulse
moreoftenfornertexture.Fornut
butters,processcontinuouslyuntil
smooth.Storeinrefrigerator.
To chop cooked or raw meat,
poultry or seafood:
The food should be very cold. Cut in
2.5 cm (1-inch) pieces. Process up to
455g(1pound)atatimetodesiredsize,
usingshortpulses,1to2secondseachtime.
Scrapesidesofbowl,ifnecessary.
To make bread, cookie,
or cracker crumbs:
Break food into 3.5-5.0 cm (1
1
/2 to 2-inch)
pieces.Processuntilne.Forlargerpieces,
pulse2to3times,1to2secondseachtime.
Thenprocessuntilne.
To melt chocolate in a recipe:
Combine chocolate and sugar from recipe
inworkbowl.Processuntilnelychopped.
Heat liquid from recipe. With processor
running,pourhotliquidthroughthefeed
tube. Process until smooth.
To grate hard cheeses,
such as Parmesan and Romano:
Never attempt to process cheese that
cannot be pierced with the tip of a sharp
knife. You can use the multi-purpose blade
to grate hard cheeses. Cut cheese in 2.5 cm
(1-inch)pieces.Placeinworkbowl.Process,
usingshortpulses,untilcoarselychopped.
Processcontinuouslyuntilnelygrated.Pieces
of cheese can also be added through the feed
tube while the processor is running.
Using the multipurpose blade
NOTE:Processingnutsandotherhardfoodsmayscratchthesurfacenishontheinsideofthebowl.
29
English
TIPS FOR GREAT RESULTS
Cutfoodtotfeedtubeverticallyor
horizontally,andpackfeedtubesecurely
to keep food positioned properly. Process
using even pressure.
Or use the small feed tube in the two-piece
food pusher. Position food vertically in
the tube and use the small food pusher
to process food.
To slice or shred fruits
or
vegetables that are
long and relatively small
in diameter, such as celery, carrots, and
bananas:
To shred rm and soft
cheeses:
Firm cheese should be
verycold.Forbestresultswithsoftcheeses,
suchasmozzarella,freeze10to15minutes
beforeprocessing.Cuttotfeedtube.
Process using even pressure.
To slice uncooked meat or poultry,
such as stir-fry meats:
Cutorrollfoodtotfeedtube.Wrap
andfreezefooduntilhardtothetouch,30
minutesto2hours,dependingonthickness
of food. Check to be sure you can still pierce
foodwiththetipofasharpknife.Ifnot,allow
tothawslightly.Process,usingevenpressure.
To slice cooked meat or poultry,
including salami, pepperoni, etc.:
Food should be very cold. Cut in pieces to
tfeedtube.Processfoodusingrm,even
pressure.
To shred spinach and other leaves:
Stackleaves.Rollupandstandupinfeed
tube. Process using even pressure.
Using a slicing or shredding disc
To slice or shred fruits and vegetables
that are round, such as onions, apples,
and green peppers:
Peel,core,andremoveseeds.Cutinhalves
orquarterstotfeedtube.Positioninfeed
tube. Process using even pressure.
To slice or shred fruits and vegetables
that are small, such as strawberries,
mushrooms, and radishes:
Position food vertically or horizontally in
layers within the feed tube. Fill feed tube
in order to keep food positioned properly.
Process,usingevenpressure.Orusethe
small feed tube in the two-piece food pusher.
Position food vertically in the tube and use
the small food pusher to process food.
30
TIPS FOR GREAT RESULTS
• To capitalize on the speed of the
processor,dropingredientstobechopped
through the feed tube while the processor
is running.
• Different foods require varying degrees
of pressure for best shredding and slicing
results.Ingeneral,uselightpressure
forsoft,delicatefoods(strawberries,
tomatoes,etc.),moderatepressurefor
mediumfoods(zucchini,potatoes,etc.),
andrmerpressureforharderfoods
(carrots,apples,hardcheeses,partially
frozenmeats,etc.).
• Softandmedium-hardcheesemayspread
out or roll up on the shredding disc. To
avoidthis,shredonlywell-chilledcheese.
• Sometimesslenderfoods,suchas
carrotsorcelery,falloverinthefeed
tube,resultinginanunevenslice.To
minimizethis,cutfoodinseveralpieces
and pack the feed tube with the food.
Forprocessingsmallorslenderitems,
the small feed tube in the two piece food
pusher will prove especially convenient.
The dough blade is specially
designed for mixing and
kneading yeast dough
quicklyandthoroughly.Forthebestresults,
do not knead recipes which use more than
350g(3cups)ofour.
• Toavoiddamagetothebladeormotor,do
notprocessfoodthatissohardorrmly
frozen that it cannot be pierced with the
tipofasharpknife.Ifapieceofhardfood,
suchasacarrot,becomeswedgedor
stuckontheblade,stoptheprocessorand
remove the blade. Gently remove food
from the blade.
• Donotoverllworkbowlormini-bowl*.
Forthinmixtures,llworkbowlupto
1/2to2/3full.Forthickermixtures,ll
workbowlupto3/4full.Forliquids,ll
up to the maximum level as described
in the section “Using Your Food
Processor - Maximum Liquid Level”.
Whenchopping,theworkbowlshould
be no more than 1/3 to 1/2 full. Use the
mini-bowl
*
for up to 235 mL (1 cup) of
liquid or 120 mL (1/2 cup) solids.
• Position slicing discs so the cutting surface
is just to the right of the feed tube. This
allows the blade a full rotation before
contacting the food.
Using the dough blade*
Helpful hints
* Included only in model 5KFP1335
31
English
TIPS FOR GREAT RESULTS
• Whenpreparingacakeorcookiebatter,
use the multipurpose blade to cream
fatandsugarrst.Adddryingredients
last.Placenutsandfruitontopofour
mixture to prevent overchopping. Process
nutsandfruits,usingshortpulses,until
blended with other ingredients. Do not
overprocess.
• When shredded or sliced food piles
upononesideofthebowl,stopthe
processor and redistribute the food
using a spatula.
• When food quantity reaches the bottom
ofaslicingorshreddingdisc,remove
the food.
• A few larger pieces of food may
remain on top of the disc after slicing
orshredding.Ifdesired,cuttheseby
hand and add to mixture.
• Organize processing tasks to minimize
bowlcleanup.Processdryorrm
ingredients before liquid ingredients.
• To clean ingredients from the
multipurposebladeeasily,justempty
theworkbowl,replacethelid,andpulse
1 to 2 seconds to spin the blade clean.
• Afterremovingtheworkbowlcover,
place it upside down on the counter.
This will help keep the counter clean.
• Use a spatula to remove ingredients from
the work bowl.
• Your Food Processor is not designed
to perform the following functions:
- Grindcoffeebeans,grains,or
hard spices
- Grind bones or other inedible
parts of food
- Liquefy raw fruits or vegetables
- Slicehard-cookedeggsorunchilled
meats.
• If any plastic parts should discolor due to
thetypesoffoodprocessed,cleanthem
with lemon juice.
32
TROUBLESHOOTING
If your Food Processor should malfunction or fail to operate, check the following:
Food Processor doesn’t run:
• Make sure that the bowl and lid are
properly aligned and locked in place and
the large food pusher is inserted in the
feed tube.
• Whenusingthelargefeedtubeopening,
make sure that food is not above the Max.
Fill line on the feed tube.
Max Fill line
on feed tube
• Press only one button at a time. The Food
Processor will not operate if more than
one button is pressed at the same time.
• Is the Food Processor plugged in?
• Is the fuse in the circuit to the Food
Processor in working order? If you
haveacircuitbreakerbox,besure
the circuit is closed.
• UnplugtheFoodProcessor,then
plug it back into the outlet.
• If the Food Processor is not at room
temperature,waituntilitreachesroom
temperature and retry.
Food Processor not shredding or slicing
properly:
• Make sure the raised-blade side of the
disc is positioned face up on the common
adapter.
• Ifusingtheadjustableslicingblade,make
sure it is set to the correct thickness.
• Make sure ingredients are suitable for
slicingorshredding.See“Tipsforgreat
results.”
If the work bowl cover won’t close when
using the disc:
• Makesurethediscisinstalledcorrectly,
withtheraisednubontop,andis
positioned properly on the drive adapter.
Nub
If the problem is not due to one of the above
items,see“Warrantyandservice”section.
33
English
WARRANTY AND SERVICE
Length of
Warranty:
KitchenAid Will Pay For: KitchenAid Will Not
Pay For:
Europe, Middle
East and Africa :
For Model
5KFP1335,
5KFP1325:
Three years Full
Warranty from
date of purchase.
The replacement parts
and repair labor costs to
correct defects in materials
or workmanship. Service
must be provided by an
Authorized KitchenAid
Service Center.
A. Repairs when Food Processor
is used for operations other
than normal household
food preparation.
B. Damage resulting from
accident, alterations,
misuse, abuse, or installation/
operation not in accordance
with local electrical codes.
KITCHENAID DOES NOT ASSUME ANY RESPONSIBILITY FOR INDIRECT
DAMAGES.
KitchenAid Food Processor warranty
In U.K. and Ireland:
Foranyquestions,ortondthenearestKitchenAidAuthorizedServiceCenter,pleasend
our contact details below.
NOTE:AllserviceshouldbehandledlocallybyanAuthorizedKitchenAidServiceCenter.
Contact number for U.K. and Northern Ireland:
Tollfree number 0800 988 1266 (calls from mobile phones are charged standard
network rate) or call 0194 260 5504.
Contact number for Ireland:
Tollfree number +44 (0) 20 8616 5148
E-mail contact for U.K. and Ireland:
Gotowww.kitchenaid.co.uk,andclickonthelink“ContactUs”atthebottomofthepage.
Address for U.K. and Ireland:
KitchenAidEuropa,Inc.
PO BOX 19
B-2018 ANTWERP 11
BELGIUM
In other countries:
Forallproductrelatedquestionsandaftersalesmatters,pleasecontactyourdealer
toobtainthenameofthenearestAuthorizedKitchenAidService/CustomerCenter.
For more information, visit our website at:
www.KitchenAid.co.uk
www.KitchenAid.eu
Customer service
© 2014. All rights reserved.
Specicationssubjecttochangewithoutnotice.
W10505785C
09/14
© 2014. All rights reserved.
Specicationssubjecttochangewithoutnotice.
