Outdoor Gas Fire Pit Table
SLFPX69
50,000 BTU Square Gas Fire Pit with Stainless Steel Lid
and Stainless Steel Legs
www.SereneLifeHome.com
2
DANGER
FIRE OR EXPLOSION HAZARD
If you smell gas:
• Shut o gas to the appliance.
• Extinguish any open ame.
• If odor continues, leave the area immediately.
• After leaving the area, call your gas supplier or re department.
Failure to follow these instructions could result in re or explosion, which
could cause property damage, personal injury, or death.
WARNING:
Do not store or use gasoline or other ammable vapors and liquids in the vicinity
of this or any other appliance. An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
WARNING:
If the information in this manual is not followed exactly, a re or explosion may
result causing property damage, personal injury, or loss of life.
WARNING:
For outdoor use only. Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
WARNING:
Improper installation, adjustment, alteration, service or maintenance can cause
injury or property damage. Refer to the owner's information manual provided
with this appliance. For assistance or additional information consult a qualied
installer, services agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
www.SereneLifeHome.com
3
SAFETY INFORMATION
Before you assemble or operate this unit, please carefully read this entire
manual. Failure to do so may result in a re, explosion, injury or death.
WARNING
•
The installation of this unit must adhere to local codes or Propane Storage and
Handling Code, CSA B149.2.
• THIS UNIT IS INTENDED FOR OUTDOOR USE ONLY! This product shall be used
outdoors, in a ventilated space and shall not be used in any enclosed area.
• This unit is to be used with propane gas only! (sold separately)
• Do not attach a remote gas supply to this unit.
• Only use propane gas for this unit.
• Solid fuels shall not be burned in this appliance.
• When igniting this unit, stay away from the burner as the ame will light up and
may cause injury.
• LP GAS WARNING: Do not use any more than 1/4 in depth lava rocks/pumice
stones/LavaGlass® above the burner holes. Doing so will suocate the ame.
• If the propane gas tank is leaking gas, you may hear, see, or smell a hiss.
Do the following:
1. Disconnect the propane gas tank.
2. Do not attempt to x the problem yourself.
3. Contact your gas supplier or re department for help.
• Applying too much propane may result in gas pooling and will not burn.
Allow fresh air into the unit so that the remaining gas may escape.
• Do not use a ame to check for gas leaks.
• Manifold pressure: 11 inch w.c. (2.74kPa).
• Use LP propane tanks with the following dimensions: diameter 12 in, height 18
in - capacity 20 lbs.
• You must use a propane tank that has a collar to protect the gas valve.
• DO NOT ll tank over 80 percent full.
• The tank system must be set up for vapor withdrawal.
• Discontinue use if any part of the propane tank is damaged. Rust and dents may
be hazardous and should be inspected by a gas supplier.
• Do not burn anything other than the provided materials for this re table.
• Keep away from the unit for the rst 20 minutes after igniting your unit for the
rst time, as lava rocks/pumice stones/LavaGlass could pop out and cause injury.
Should any rocks pop out, discard them.
www.SereneLifeHome.com
4
• Always ensure that lava rocks/pumice stones/LavaGlass are completely dry before
use. Failure to do so will cause them to crack or pop.
• Do not operate unit until all parts are fully assembled.
• Do not paint or color any part of this heating unit.
• Unit may be hot while in use, do not attempt to move it while in use.
• Never leave this heating unit unattended while in use.
• This unit is not intended for cooking.
• Keep any ammable items away and do not use any other replace cover for this
unit.
• Keep a safe distance to avoid burning skin or clothing.
• Do not sit or rest hands or feet on this heating unit.
• Never place hands or ngers on upper portion of this unit while in use.
• Keep all electrical cords and fuel supply hose away from heated surfaces.
• Combustible material should not be within 60 inches of the top of the unit, or
within 48 inches around the entire unit.
• Keep the appliance area clear and free from combustible material, gasoline, and
other ammable vapors and liquids.
• If the ame goes out while burning, turn the gas valve o. Wait 5 minutes before
repeating the initial lighting procedure. Once you have a ame started, hold
down the control knob for 1 minute.
• Do not add water into the unit.
• Do not operate unit if any part has been under water. Immediately call a qualied
service technician to inspect the appliance and replace any part of the control
system and any gas control that has been under water.
• Do not disconnect any part while unit is in use.
• Do not store a spare propane tank on or near this unit.
• If the heating unit is indoors, detach the propane tank and leave outdoors.
• Always remove protective cover before operating (if applicable).
• Do not set the protective cover over the unit until it is turned o and completely
cooled down.
• Check for leaks after not using the unit for long periods of time.
• Children should never operate this unit. Children must be supervised while
near this unit.
• Keep gas tank at least 5 feet away from unit when lit. (if external tank)
• Maximum gas supply: 250 psi; Min. gas supply: 10 psi.
www.SereneLifeHome.com
5
• All installation and repair should be done by a qualied professional.
This unit should be inspected annually and cleaned regularly.
• Inspect all elements of this heating unit before each use. If there is damage, the
burner must be replaced.
• Keep the hose out from any pathways to eliminate any accidental damage.
(if external tank).
• Be aware of the hazards of high temperatures and stay away from the unit to
avoid any burns or injury.
• The gas supply tank should be constructed and marked with specications for
the LP gas tanks of the U.S. Department of Transportation or the National
Standard of Canada CAN/CSA-B339, LP gas tanks, spheres and tubes for
Transportation of Dangerous Goods; and Commission.
• The LP gas tank must have a listed overlling prevention device and a QCCI or
Type I, (CGA791) LP gas tank connection.
• This heating appliance appliance should not be used on plastic or articial wood
decks.
• Children and adults should be alerted to the hazards of high surface
temperatures and should stay away to avoid burns or clothing ignition.
• Young children should be carefully supervised when they are in the area of
the appliance.
• Clothing or other ammable materials should not be hung from the
appliance or placed on or near the appliance.
• Any guard or other protective device removed for servicing the appliance
shall be replaced prior to operating the appliance.
• Installation and repair should be done by a qualied service person.
The appliance should be inspected before use and at least annually by a
qualied service person. More frequent cleaning may be required as
necessary. It is imperative that the control compartment, burners and
circulating airways of the appliance are kept clean.
www.SereneLifeHome.com
6
IF APPLICABLE:
• Allow heating item to cool completely before placing on lid.
• DO NOT use heating item while lid is installed. Always remove the lid while
heating item is in use.
SAFETY INFORMATION
Only use the regulator and hose assembly provided with this unit. Replacement
parts must be supplied directly by us.
Inspect the burner before use of this unit. If the burner shows any kind of damage,
do not operate the appliance. For assistance with repair or replacement of the
burner or any other parts, contact to us.
NOTE: You must follow all steps to properly assemble this heating item.
Make sure the gas valve is turned “OFF” before assembling. Do NOT attempt to
assemble without proper tools.
Min. Clearance
60 in. (152.4 cm)
Min. Clearance
48 in (121.9 cm)
Min. Clearance
48 in (121.9 cm)
Combustible materials should not be
within 60 inches of the top of the unit, or
within 48 inches around the entire unit.
www.SereneLifeHome.com
7
HARDWARE
ITEM
DESCRIPTION
AA M6 x 12 Screw
BB M6 x 15 Screw
QTY
8
22
Before beginning assembly of this product, be sure all parts are present.
Compare parts with package contents list and hardware contents list. If any part
appears to be missing or damaged do not begin assembly of this product and call
customer service immediately.
Estimated assembly time: 30 minutes
CONTENTS
AA BB
L
M
B
P
O
N
Q
R
A
D
C
K
F
E
J
I
H
G
S
www.SereneLifeHome.com
8
ITEM DESCRIPTION Qty
A Lid 1
B Table Top 1
C
Panel
1
D Panel 1
E Panel
1
F
Door
1
H
I 1
J
K
L
M
N
O
P
G Leg
Metal Stand
1
1
1
Protective Cover
Control Knob (preassembled)
Guard (preassembled)
Firebowl (preassembled)
Burner (preassembled)
Regulator Hose (preassembled)
1
1
1
1
1
Glass Rocks
1 box
R
1
1
Leg
Leg
Leg
Metal support
S
2
www.SereneLifeHome.com
9
ASSEMBLY INSTRUCTIONS
1. Attach the panel (C/D/E) to the legs
(G/H/I/J)using screws (BB).
2. Attach the door (F) to the Metal
Stand (K) using screws (BB).
3. Attach the Metal support (S) to the
Metal Stand(K) and door using
screws (BB).
H
I
J
www.SereneLifeHome.com
10
4. Attach metal stand (K) to the panel
(C/E) using screws (BB).
5. Attach metal base to the bottom
part of the table top (B) using screws
(AA).
6. Put the lid.
K
E
C
B
www.SereneLifeHome.com
11
7. Place propane gas tank (not included)
into the metal stand (K). Make sure
the gas tank sits on the metal stand
(K) completely. Turn the preassembled
wing screw on the outer part of metal
stand (K) clockwise to secure the
propane gas tank tightly.
8. Turn the cylinder valve on the tank
clockwise to close the propane tank.
Attach the preassembled regulator
from the table top (B) to the cylinder
valve by turning the regulator
coupling nut clockwise.
Make sure it is fastened securely and
tighten connections by hand only.
9. Pour the box of glass rocks (L) into
the rebowl.
CYLINDER VALVE
PRESSURE
RELIEF VALVE
BLEED-OFF
VALVE
BLACK COUPLING NUT
REGULATOR
turn clockwise to connect
turn clockwise
to reseal
L
CAUTION
To ensure proper function, the guard
on this burner should be free of glass
rocks at all times.
www.SereneLifeHome.com
12
ASSEMBLY INSTRUCTIONS
•
Please keep this owner’s manual for future reference.
• Do not exceed 1/4” depth of small Lava rock/Glass rocks directly above burner
holes. Applying too many lava rocks may result in unburned gas pooling in the
re bowl. Ventilation is required to allow fresh air in and any residual gas to escape.
• Do not use if lava rocks are wet. Be sure Lava rock/Glass rocks are dry before
lighting as intense heat could cause the rocks to crack.
Carefully remove all items from the carton. Be sure all packaging, both under
the re pit and around the re bowl, is removed before using.
1. Check each part before using the product.
Make sure the gas supply system is turned
“OFF” before assembling. See Figure A.
2. Locate the battery and remove from plastic.
Unscrew the rubber cap of the electric igniter
and place AA battery into the battery case.
Make sure the positive pole "
+" is towards
the cap. Screw the cap back onto the battery
case tightly. See Figure B.
3. Place the Lava rock/Glass rocks evenly in the
re bowl. See Figure C.
WARNING
DO NOT COVER THE IGNITION SCREEN when placing the Lava rock/Glass rocks
into the re bowl. Always keep the ignition screen visible.
A
C
B
SCREEN
CORRECT INCORRECT
www.SereneLifeHome.com
13
WARNING
CAUTION: This heating item should not be used on plastic composite or articial
wood.
WARNING
When you turn the cylinder, the gas hose needs to be straightened during use.
otherwise the hose may melt and cause a re.
1 Assembling the Glass
Unsc rew all pressem bled screws on the glass clamps, Then, assemble one glass
panel to the other panel. Then, assemble the two glass panel pleces together with
the nal glass clamps as show below.
www.SereneLifeHome.com
14
2 Inserting the Glass
Insert the glass assembly made in step 1 into the ridge on the top of the re
table mantel.
OPERATION
Before performing a leak test, be sure that no sparks can occur and you are in a
spacious outdoor area. Connect the propane gas tank to the regulator and turn
the valve on the unit to the “o” position. Brush a soap and water mixture on all
connections. Turn the gas supply on; if bubbles occur on any connection there
may be a leak. If you smell gas or a leak is discovered turn the gas valve o,
disconnect propane gas tank and do not use the appliance until the leak is
repaired.
Do not use the heating unit without inspecting the gas hose. If there are signs of
wear or abrasion you must replace the hose (if applicable). Pumice stones/lava
rocks/LavaGlass could pop up and strike somebody’s face during the process of
lighting this unit; stand away from the unit for the rst 20 minutes after igniting.
Flame height should be a yellow/blue color between 2 - 10 inches in height.
Wait 50 minutes after extinguishing ame prior to placing a lid (if applicable) or
protective cover on heating item.
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
www.SereneLifeHome.com
15
To Light
1. Make sure the control knob is in the "OFF" position.
2. Open the door and slowly open the valve on the propane gas tank by turning
the knob counterclockwise.
3. Close the door on the body.
4. Push the ignition control knob in fully and rotate about 1/4 turn counterclockwise
until a click is heard, it may take several attemps to light the burner. Once lit, keep
holding down the control knob for 15 seconds.
5. If ignition doesn't occur within a few seconds, release the control knob and
rotate to the "OFF" position. Wait for 5 minutes for gas to clear and then repeat
the above lighting instructions.
6. To adjust the ame, turn the control knob either clockwise or counterclockwise
depending on whether you want to lower or raise the ame.
To Extinguish
1. Turn control knob clockwise to the "HIGH" position; push and continue turning
the control knob to the "OFF" position.
2. Close the cylinder valve on the propane gas tank if you don't intend to use it for
a long time.
MAINTENANCE
• Before performing any maintenance always disconnect propane gas tank.
• Store your product indoors during winter months. Avoiding extreme cold
temperatures will prevent from exposure damage.
• Keep the heating item free and clear from combustible materials.
• Visually inspect burner for obstructions and keep tank enclosure free and clear
from debris.
• Use a soft brush to get rid of the mild stains, loose dirt and soil after the burner
and pumice stones/lava rocks/LavaGlass are completely cooled down.
Wipe down with a soft cloth.
• Harsh weather conditions may cause stubborn stains, discoloration and possibly
rust pitting.
• Permanent damage may occur if powder or solvent comes in contact with painted
or plastic components on this heating unit.
• Keep the heating unit stored away from direct sunlight.
• If storing this unit inside, disconnect the propane gas tank from the gas valve.
• Not using manufacturer approved or supplied parts/accessories may result in a
defective condition and void the warranty of this heating unit.
• Always place lid (if applicable) or protective cover on heating item when not in use.
Problem Cause Solution
Heating unit won’t
light
Igniter pin and burner are wet Dry o with a soft cloth
Igniter battery is incorrectly
inserted
Check which direction the
battery is inserted
Igniter pin is broken
Contact us for parts
replacement
Electrode wire is loose or
disconnected
Reconnect wire to the
igniter box located inside
the re pit behind the
igniter box
Electrode wire is shorting
between valve and igniter pin
Contact us for parts
replacement
Burner won’t light
while using a
match
No gas ow
Check that the gas tank
isn’t empty
Regulator isn’t connected
securely to the tank
Tighten regulator
connection to the gas tank
Gas ow is obstructed
Check all hoses for kinks
and bends
Burner ports are clogged
Turn all gas ow
connections o. Insert an
opened paperclip
(or similar item) into each
of the burner ports to clear
them out.
Heating unit emits
a lot of black
smoke
Flame is obstructed at
burner ports
Check that all burner ports
are free of any small lava
rocks/pumice stones/
LavaGlass pieces
Regulator hose is kinked
Straighten hose of all
bends or kinks
www.SereneLifeHome.com
16
TROUBLESHOOTING
Problem Cause Solution
Sudden drop in
gas ow
No gas ow
Check that the gas tank
isn’t empty
Excess ow safety valve has
been activated
Turn the control knob to
the ‘o’ position. Close the
tank valve and disconnect
propane gas tank. Turn the
control knob to ‘high“, wait
1 minute. Turn the control
knob back to the ‘o’
position. Reconnect
propane gas tank.
Light the re unit as
indicated in the ‘To Light’
section of this manual.
Flame blows out
easily
High or gusting winds Increase ame to ‘high’
No gas ow
Check that the gas tank
isn’t empty
Excess ow safety valve has
been activated
See “sudden drop in gas
ow” above
www.SereneLifeHome.com
17
TROUBLESHOOTING
This product can expose you to a chemical or group of chemicals, which may
include ”Lead and lead compounds” which is known in the state of California
to cause cancer, birth defects, or other reproductive harm. For more info, go
to https://www.p65warnings.ca.gov/.
