P/N YRD256-MNL-0003 Rev G
1
YaleAssure Lock
®
®
SL
Key Free Touchscreen Deadbolt
Installation and Programming Instructions
(YRD26)5
This manual will walk you through all the required steps to add your new
Yale Assure Lock SL to your door.
• Remove existing deadbolt
• Double check door measurements
• Install your Assure Lock SL
• Program your Assure Lock SL
• Add your Assure Lock SL to your smart home system or Yale
Access app if purchased with Yale Smart Module or Yale Access
Upgrade Kit
Failure to follow these instructions could result in damage to the product, voiding the factory warranty and could lead to failure of the product to provide access.
Before you begin
Using the app on your smart
phone, scan this QR for step-by
-step installation instructions & to
register your lock
DOWNLOAD
THE BILT APP
Tools Needed
Standard
Phillips Head
Screwdriver
Tools Needed For New
Doors Or Adjusting Existing Door
Utility
Knife
Drill
Wood
Mortise
Chisel
Pencil
Tape
Measure
Level
