OWNER’S MANUAL

This is the main product document for model HVP-20SS-MF.

The file format is pdf, 4 pages, you can download this manual here .

background
20″HIGHVELOCITY
PEDESTALFAN(2‐IN‐1)
MODELHVP‐20SS-MF
OWNER’SMANUAL
READANDSAVETHESEINSTRUCTIONS.
621-1759
background
2
CAUTION:
ReadandfollowallinstructionsbeforeoperatingFan.
Donotusefanifanypartisdamagedormissing.
WARNING:
To
reducetheriskoffireorelectricalshock,donotexposetowaterorrain.
Toreducetheriskoffireorelectricalshock,donotusethisfanwithanysolidstatespeedcontrol
device.
RULESFORSAFEOPERATION:
Neverinsertfingersoranyotherobjectsthroughthegrilleguardwhenfanisinoperation.
Disconnectthefanwhenmovingfromonelocationtoanother.
Disconnectthefanwhenremovingguardsforcleaning.
Besurefanisonastable,flatsurfacewheninoperation.
DONOTusefaninwindows.Rainandmoisturemaycreateelectrical
hazard.
CAUTION:DonotaltertheFan’sassembly.
WARNING:BesureFRONTandREARGUARDscrews
are
completely screweddowninlockingpositionbeforeoperation.
INSTALLINGASSTANDFAN
STANDASSEMBLY:
1. AttachOUTERTUBEtotheBASEwith4screwsasshown.
2. LoosenPLASTICNUTonOUTERTUBEandextendINNERTUBEto
desiredheight.
3. SlideCOVERRINGdowntheOUTERTUBEtorestontopoftheBASE.
CAUTION:Theplasticnutmustbefullytightenedbefore
assemblingthefanmotortotheinnertube.
COLUMN/MOTORASSEMBLYINSTRUCTIONS:
InsertthefanattopoftheINNERTUBE.
Thenfirmlytightenthescrews
attheholeofthefan
holder.
INSTALLINGASFLOORFAN
1. AttachSHORTERPOLEtotheBASEwiththe4screwsasshown.
2. InsertthefanatthetopoftheSHORTERPOLE.
3. Thenfirmlytightenthescrews
attheholeofthefanholder.
HIGHVELOCITYFLOORFANOPERATINGINSTRUCTIONS
background
3
OPERATINGINSTRUCTIONS
TOADJUSTAIRFLOWUPWARDORDOWNWARD: Tiltfanheadtothedesiredangle.Thishigh
velocityfancanbeusedaloneorinconjunctionwithairconditioning.Rotatingthefanheadupward
servestopullairfromthefloorandcirculateitthroughouttheentireroom.
HowToAdjustTilt
1. Loosenknobbyturningcounter‐
clockwise.
2. Adjustfanheadtotileyouwant.
3. Tightenedtheknobbyturningclockwise.
SPEEDCONTROL:RotateSWITCHto(0),(4),(3),(2),(1)
speedsforrespectiveairvelocity.Itisnormalforthemotortofeelwarmtotouchaftercontinuous
operation.Thisfanfeaturesathermalcutoffthatwillautomaticallyshutoffshoulditoverheatforany
reason.Ifthishappens,immediatelyunplugthefanfromtheoutlet.
CLEANING
WARNING:Unplugfromelectricalsupplysourcebeforecleaning:
Usesoftdampclothtoclean.Thenwipewithdrycloth.
Donotuseacleaningsolutionthat
isharmfultopaintsorplastics.
Donotbendtheblades.
Themotorbearingsarepermanentlysealedanddonotrequireadditionallubrication.
WARNING:
Th
isproductisnotintendedforusebypersons(includingchildren)withreducedphysical,sensoryor
mentalcapabilities,orlackofexperienceandknowledge,unlesstheyhavebeengivensupervisionor
instructionconcerninguseoftheproductbyapersonresponsiblefortheirsafety.Childrenshouldbe
supervisedtoensurethattheydonotplaywiththeproduct.
KNOB
3-YEAR LIMITED WARRANTY
The manufacturer warrants this product to be free from manufacturing defects in material and
workmanship under normal use for a period of three (3) years after the date of purchase by the
original purchaser. To obtain warranty service, you must present a copy of the receipt as proof of
purchase. This warranty does not cover transit damages. This warranty does not apply to damages
from accident, faulty installation, misuse, abuse, alteration of any kind of fan or where the
connected voltage is more than 5%above the nameplate voltage. This warranty does not apply to
the finish on any portion of the product. Servicing performed by unauthorized persons shall render
the warranty invalid.
Some states do not allow the limitation or exclusion of certain damages. Therefore, these
limitations and exclusions may not apply to you. This warranty gives the consumer specific
legal rights. You may have other rights that vary from state to state.
For warranty service contact Customer Service at
1-888-372-8518, 7:00 a.m.- 4:00 p.m., PST, Monday-Friday.
background
4
No. PartName No. PartName
1
KNOB
11
REARGRILLE
2
SWITCHBOX
12
METALSHROUD
3
CAPACITOR
13 BLADE
4
ON/OFFSWITCH
14
FRONTGRILLE
5
SWITCHBOX
15
UBAR
6
MOTOR
16 POLE
7
SCREW
17
PLASTICRING
8
WASHER
18
SCREW
9
NUT
19 BASE
10
KNOB
For Reference
S
hould youhaveanyoperationquestionS
,
contactustoll‐freeat1‐888‐372‐8518
Monday-Friday 7am-4pm PST
ore‐mail[email protected]
