the InFizz
™
Fusion
BCA800
EN
Safety Guide
2
SAFETY
GUIDELINES
Keep clean and store
the bottle with the lid o.
WARNING
Never attempt
to carbonate
an empty bottle.
Never use a bottle
that’s deformed,
discoloured, or scratched.
Never put the bottle
in the freezer.
Don’t transport
the InFizz
™
Fusion with
the gas Canister installed.
Do not carbonate milk
based products.
Do not put ice
in the bottle.
BREVILLE
®
RECOMMENDS
SAFETY FIRST
At Breville
®
we are very
safety conscious.
We design and manufacture
consumer products with
the safety of you, our valued
customer, foremost in mind.
In addition, we ask that you
exercise a degree of care
when using any appliance
and adhere to the following
precautions.
CONTENTS
02 - Limited product warranty
02 - Breville
®
recommends safety rst
02 - Safety guidelines
04 - Components & Accessories
05 - Before rst use - Care & Cleaning
06 - Gas canister placement
07 - Carbonating water
08 - Carbonating non-water drinks
10 - Troubleshooting
Breville’s warranty for this product covers the repair
or replacement if it’s found to be defective due
to faulty materials, workmanship, or function within
the warranty period.
All legal warranty rights under applicable national
legislation will be respected and will not be impaired
by our warranty. For details on length of warranty,
to obtain a printed copy or to read full terms and
conditions please scan the QR code or visit
www.breville.com
2 YEAR LIMITED
LIMITED PRODUCT
WARRANTY
QR149
Alternatively, call the Breville
Service Centre (see back
cover for contact details)
3
EN
Use InFizz
™
Fusion
compatible carbonating
bottles ONLY.
Never clean the bottle
in the dishwasher.
Do not leave the InFizz
™
Fusion and/or the bottle
in direct sunlight or too
close to a window.
Do not place the InFizz
™
Fusion next to a heat
source.
Do not place the InFizz
™
Fusion close to open
ames of any sort.
Do not use the InFizz
™
Fusion and/or the bottle
in extreme temperatures.
Do not use the bottle
after its expiration date.
The symbol shown
indicates that this
appliance should not be
disposed of in normal
household waste. It should be
taken to a local authority waste
collection center designated for
this purpose or to a dealer
providing this service. For more
information, please contact your
local council oce.
CARBON DIOXIDE CO
2
CANISTER
To reduce the risk of a CO
2
leak,
personal injury and property
damage:
• In the event of a CO
2
leak,
ventilate the area, breathe fresh
air and if feeling unwell seek
immediate medical attention.
• Do not insert a CO
2
Canister
into the InFizz
™
Fusion when
a bottle is installed.
• Do not remove a CO
2
Canister
from the InFizz
™
Fusion when
it is being operated.
• Do not remove bottle during
carbonation.
• Do not handle or remove
a CO
2
Canister while it is
discharging CO
2
.
• Do not use if damaged.
Inspect the CO
2
Canister and
CO
2
Canister valve prior to use
for dents, punctures, or other
damage. If damaged, contact
an authorised service
representative.
• Do not tamper with the CO
2
Canister in any way, including
puncturing, incinerating or
removing the valve.
• Do not expose the CO
2
Canister to heat above 120°F
/ 50°C. Protect from sunlight.
Store in a well-ventilated area.
SAVE THESE INSTRUCTIONS FOR HOUSEHOLD USE ONLY
4
A. Carbonating lever
B. Tilt head with ring pull
C. Gas cylinder compartment
D. Flat surface safety switch
to ensure a at surface is used
E. Removable drip tray cover (hand wash only)
F. Drip tray
COMPONENTS
A
B
E
F
D
C
ACCESSORIES
1. FusionCap
™
(hand wash only)
2. 1 L bottle (hand wash only)
3. Sieve
4. Funnel
5. Bottle brush
6. FusionCap
™
brush
3
1
5
2
6
4
NOTE
0.6 L Bottle -
Sold separately
5
1.1
1.7 1.8
MAX
1.51.41.2
XX/XXXX
1.6
BEFORE FIRST USE
CARE & CLEANING
1.
1.3
1.9
Keep clean and store
the bottle with the lid off.
6
CO
2
CO
2
2.1
Screw
Type
Quick
Connect
Type
2.2 2.3
Gently turn the canister
in a clockwise motion
until screwed in.
2.
GAS CANISTER
PLACEMENT
7
3.83.7
3.9
3.2
MIN
MAX
3.1
1°C - 8°C
3.3
3.5 3.6
3.4
3.
CARBONATING
WATER
x 2
x 4
x 6
1sec
PSSSH
PTSSSSS
8
4.1
1°C - 8°C
MIN
MAX
1°C - 8°C
OR
4.2
4.4
4.3
4.5
4.6
4.
CARBONATING
NON-WATER
DRINKS
x 2
x 4
x 6
1sec
PSSSH
9
4.7
Move the
switch to the
center position
to slowly
release gas.
Move the switch
all the way to the
right when
the sound of the
gas releasing is
no longer heard.
4.8
Turn the switch
back to the left
if the foam rises
up too quickly.
PTSSSSS
PTSSSSS
PTSSSSS
10
PROBLEM POSSIBLE CAUSES EASY SOLUTIONS
Small pieces of
ice in the bottle.
Small pieces of ice may appear and quickly melt
in the bottle while carbonating.
• Shorten each press so the eciency
of carbonation is not aected.
Little or no
carbonation.
CO₂ canister may be near empty or empty.
NOTE: Cold water also maximises carbonation.
• Replace the canister with a full one.
• Check the CO₂ canister is properly screwed
into place.
Bottle cannot be
removed from the
FusionCap
™
.
Excess CO₂ has not been fully released. • Turn the red switch on the FusionCap
™
all
the way to the right to release all of the
pressure.
Juice or other
non-water liquids
foam up too
quickly.
Non-water liquids should not be lled passed the
MIN line on the bottle. Varying amounts of sugar
in drinks causes them to react and carbonate
dierently, so short presses on the lever will
minimise over foaming.
• Turn the red switch on the FusionCap
™
back
to the left to slow down the pressure release.
Once foam has subsided, slowly turn
the switch to the center position before
turning all the way to the right.
TROUBLESHOOTING
5.
MAX
30d
Soak the FusionCap
™
every 30 days in max 40°C water for 5 mins
TIP
11
6.
For more information on:
• Cleaning • Troubleshooting
• Useful Tips and Warranty
Check out the website, visit www.breville.com
Scan for
Troubleshooting
BCA800 ANZ SG1_B23
Breville Service Center
Australian Customers
Phone: 1300 139 798
Web: www.breville.com
New Zealand Customers
Phone: 0800 273 845
Web: www.breville.com
Breville, the Breville Logo, is a trademark of Breville Pty Ltd (“Breville”)
and Breville’s products are distributed in Australia and New Zealand under license.
Copyright Breville Pty. Ltd. 2023.
Due to continued product improvement, the products illustrated/photographed
in this brochure may vary slightly from the actual product.
