DCE040 ENGLISH
DeWALT CONNECTOR FOR USE WITH 20V MAX* TOOLS
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk of
personal injury or propertydamage.
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.
(Used without word) Indicates a safety relatedmessage.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.
WARNING: To reduce the risk of injury, read the instructionmanual.
If you have any questions or comments about this or any
DeWALT tool, call us toll free at: 1-800-4-DeWALT
(1-800-433-9258).
GENERAL SAFETY WARNINGS
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE
1 . This device contains a factory-installed coin cell battery. It cannot be removed or replaced.
2 . Chemical burn hazard. Keep out of reach of children.
3 . Do not use in extreme hot or cold conditions. Keep between -10° C to 40° C (14 F° to 104° F).
4 . Do not force open the device as the coin cell battery can cause severe internal burns and lead to death in as little as 2hours
if swallowed or otherwise enters the body. If the device is damaged in any way, stop using the device and keep it away from
children. If you think batteries may have been swallowed or entered the body, seek immediate medical attention.
5 . If coin cell battery contents come into contact with the skin, immediately wash area with mild soap and water. If coin cell
battery liquid gets into the eye, rinse water over the open eye for 15 minutes or until irritation ceases. If medical attention is
needed, the battery electrolyte is composed of an organic solvent and lithium salts.
6 . Do not incinerate or dismantle this device.
7 . Under abusive conditions, liquid may be ejected from the device. Avoid contact. If contact accidentally occurs, flush with water.
If liquid contacts eyes, additionally seek medical help. Liquid ejected from the battery may cause irritation or burns.
8 . DO NOT dispose of device together with household waste material! Appliance that has reached the end of its life must be
collected separately and returned to an environmentally compatible recycling facility.
9 . Do not expose device to moisture.
10 . Follow all warnings and instructions for tool and battery pack with which the device will be used.
The label on your tool may include the following symbols. The symbols and their definitions are asfollows:
V ......................... volts
Hz .......................hertz
min ..................... minutes
or DC ......direct current
...................... Class I Construction (grounded)
…/min ..............per minute
BPM .................... beats per minute
IPM ..................... impacts per minute
RPM .................... revolutions per minute
sfpm ................... surface feet per minute
SPM .................... strokes per minute
A ......................... amperes
W ........................watts
or AC ...........alternating current
or AC/DC .... alternating or direct current
...................... Class II Construction (double insulated)
n
o
.......................no load speed
n .........................rated speed
......................earthing terminal
.....................safety alert symbol
.....................visible radiation
..................... wear respiratory protection
..................... wear eye protection
..................... wear hearing protection
..................... read all documentation
...................... Tool Connect™ home
...................... permanent tool attachment
Storage Recommendations
The best storage place is one that is cool and dry, away from direct sunlight and excess heat or cold.
Wireless Certifications and Safety Information
• This device is CAN ICES-3(B)/NMB-3(B)compliant.
• This device complies with Part 15 of the FCC rules and Industry Canada License-exempt RSS standard(s). Operation is subject to
the following two conditions:
ʵ This device may not cause harmful interference, and
ʵ This device must accept any interference received, including interference that may cause undesiredoperation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
followingmeasures:
ʵ Reorient or relocate the receivingantenna.
ʵ Increase the separation between the equipment andadaptor.
ʵ Connect the equipment into an outlet on a circuit different from that to which the adaptor isconnected.
ʵ Consult the dealer or an experienced radio/TV technician forhelp.
• Changes or modifications to this equipment not expressly approved by the manufacturer could void the user’s authority to
operate the device. This Class B digital apparatus complies with Canadian ICES-003.
• Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary
for successfulcommunication.
• To comply with FCC and Industry Canada RF radiation exposure limits for general population, the antenna used for this device
must not be co-located or operating in conjunction with any other antenna ortransmitter.
For Bluetooth® Products
• When traveling on airlines, be sure to comply with the airline restrictions on usage of personal electronic devices and
Bluetooth®.
• The out of range alert feature has been designed to act as an aid to warn against products getting misplaced or stolen. It is not
a securitysystem.
• The connectivity range is up to 100 feet (30.5 meters) depending on environment andlocation.
• The shortwave radio frequency signals of a Bluetooth® device may impair the operation of other electronic and medical devices
(such as pacemakers or hearing aids).
NOTE: The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth®, SIG, Inc. and any use of such
marks by
DeWALT is under license. Other trademarks and trade names are those of their respectiveowners.
INTENDED USE
When installed, this DEWALT Connector enables DEWALT cordless power tools with Bluetooth® connectivity. The power tool
can now be located, enabled and disabled via the Tool Connect™ App. Power tool features cannot be customised as they can
on DEWALT Bluetooth® power tools. Enable/Disable does not function with lighting products.
DeWALT Tool Connect™
This DeWALT Connector is capable of connecting with mobile devices that support Bluetooth® Smart (or Bluetooth® 4.0)
technology. (To see if your mobile device is compatible, visit: http://www.bluetooth.com/Pages/Bluetooth-Smart-Devices-List.
aspx)
DeWALT Tool Connect™ is an application for your smart device (such as a smart phone or tablet) that can connect and control
your DeWALT Connector.
Fig. A
NOTE: The Tool Connect™ App is governed by separate terms and conditions available for viewing through the
mobileapplication.
Activating the DeWALT Connector (Fig. A)
IMPORTANT: ACTIVATE AND TEST THE CONNECTOR WITH THE TOOL CONNECT™ APP BEFORE IT IS ATTACHED TO
THE TOOL. ONCE THE DEWALT CONNECTOR IS INSTALLED IN THE TOOL, IT CANNOT BE REMOVED BY THE USER. Take
the connector and the tool to a DeWALT service center for removal.
Download the
DeWALT Tool Connect™ applicationat:
• Install a fully charged 20V Max* battery pack into the DeWALT Connector as you normally would install a battery pack into
the tool. Refer to tool instruction manual.
• Follow the instructions in the app to create your Tool Connect™ account.
• On the Home screen of the app, select "+ Tool" to begin the process of adding your connector to the app.
• To pair your connector with the
DeWALT Tool Connect™ app, at the appropriate screen, press the button
1
on the front
of the connector until the blue LED begins to blink. The connector can only be connected to one Tool Connect™ account
at atime.
• Once the connector has been connected, you can confirm that you would like to register the product.
For more information on
DeWALT Tool Connect™ functionality and features, please call 1–800–4-DeWALT (1–800–433–9258),
visit www.DeWALT.com or view the FAQ page and help screens located inside the mobileapplication.
Installing the DeWALT Connector into Tool (Fig. A)
IMPORTANT: ONCE THE DEWALT CONNECTOR IS INSTALLED IN THE TOOL, IT CANNOT BE REMOVED BY THE USER.
Take the connector and the tool to a DeWALT service center for removal.
IMPORTANT: BEFORE INSTALLING THE DEWALT CONNECTOR INTO YOUR TOOL, RECORD THE TOOL'S SERIAL
NUMBER AND DATE CODE THAT WILL BE PERMANENTLY COVERED UP BY THE CONNECTOR ONCE INSTALLED.
Record below for future reference:
Tool Type: _______________________________________________________
Tool Cat Number: _________________________________________________
Tool Serial Number: ________________________________________________
Tool's Date Code: __________________________________________________
1. Remove the tearoff label from the Connector.
2. Align the
DeWALT Connector with the rails inside the tool's handle.
3. Slide the connector into the handle until it is firmly seated in the tool (you will hear a click) and ensure that it does not
disengage.
4. If you have not already done so, install a 20V Max* battery pack into the
DeWALT Connector as you normally would install
a battery pack into the tool. Refer to tool instuction manual.
Internal Coin Cell
The connector is equipped with an internal coin cell so that it can be located when it is not on a 20V Max* battery. When
the coin cell is fully charged, it can last for 90 days before it needs to be recharged. It will take 10 hours to fully charge a
completely drained coin cell.
Please call customer service for any additional questions on blink patterns.
LED Indicator
LED Blink Pattern Status
Blinking
— — — —
Ready to pair
Solid on then off Already paired to an account
Solid on Needs to be recharged**
**To recharge the coin cell, insert a 20V Max* battery for a total of 10 hours for full charge.
Specifications
DCE040
Voltage V
DC
20
Weight 0.12 kg/4.0 oz
MAINTENANCE
Cleaning
WARNING: Never use solvents or other harsh chemicals for cleaning the connector. These chemicals may weaken the
plastic materials used in these parts. Use a cloth dampened only with water and mild soap. Never let any liquid get inside
the connector; never immerse into aliquid.
Repairs
The connector is notserviceable.
WARNING: To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment (including brush inspection
and replacement, when applicable) should be performed by a DeWALT factory service center or a DeWALT authorized
service center. Always use identical replacementparts.
Register Online
Thank you for your purchase. Register your product nowfor:
• WARRANTY SERVICE: Registering your product will help you obtain more efficient warranty service in case there is a
problem with yourproduct.
• CONFIRMATION OF OWNERSHIP: In case of an insurance loss, such as fire, flood or theft, your registration of ownership
will serve as your proof ofpurchase.
• FOR YOUR SAFETY: Registering your product will allow us to contact you in the unlikely event a safety notification is
required under the Federal Consumer SafetyAct.
Register online at www.dewalt.com/register.
3 YEAR FREE SERVICE
DeWALT will replace any defective connector any time within 3 years after purchase.
FREE WARNING LABEL REPLACEMENT: If your warning labels become illegible or are missing, call 1-800-4-
DeWALT
(1-800-433-9258) for a freereplacement.
* Maximum initial battery voltage (measured without a workload) is 20, 60 or 120 volts. Nominal voltage is 18, 54 or 108.
(120V Max* is based on using 2 D
eWALT 60V Max* lithium-ion batteries combined.)
1
IMPORTANT: CONNECTOR
ATTACHMENT IS PERMANENT!
IMPORTANT: L’INSTALLATION DE
CE CONNECTEUR EST PERMANENTE!
IMPORTANTE: ¡EL ACCESORIO
CONECTOR ES PERMANENTE!
