½”
PART A - BASE HALF
PART B - BASE HALF
HAMMOCK CHAIR STAND ASSEMBLY
HARDWARE INCLUDED (TOTAL OF 9) PARTS INCLUDED (TOTAL OF 4)
(2) 3⅛”
Screws
(2) Washers (2) Nuts
TOOLS INCLUDED (TOTAL OF 2)
TOOL REQUIRED
BUT NOT INCLUDED
Assembling Your Hammock Chair Stand:
TWO PEOPLE ARE REQUIRED TO SET UP THE HAMMOCK
CHAIR STAND.
(1) Align PART A - BASE HALF with PART B -
BASE HALF placing them ½” apart.
WARNING: MAKE SURE THE ENTIRE BASE
IS SECURE TO THE GROUND BEFORE
PROCEEDING.
(2) Have one person hold PART C, while placing it
via its protrusion into the circular opening between
the base halves (PART A & PART B).
(2) 1⅛”
Screws
(1) Carabiner
Hook
(1) Allen Wrench
(1) Open-End
Wrench
HAMMOCK CHAIR STAND - ASSEMBLED
PART A - BASE HALF
PART B - BASE HALF
PART C
PART D
Protrusion of
PART C
circular opening
PART A
PART B
[TOP VIEW]
[TOP VIEW]
(1) Hammer
®
BY SUNJOE
HAMMOCK CHAIR STAND ASSEMBLY
HAMMOCK CHAIR INSTALLATION
(Hammock Chair Sold Separately)
WARNING: TIPPING HAZARD
MAKE SURE THE ENTIRE BASE
IS SECURED TO THE GROUND
BEFORE USE.
(3) While holding PART C in place, the other
person will take the (2) 3⅛” Screws and thread it
through each of the holes on one side of the base.
Place a Washer and then a nut on each of the
screws. Hold the nut in place using the Open-End
Wrench while using the Allen Wrench to tighten
the screws.
(4) Use the Allen Wrench
to tighten the (2) 1⅛”
Screws to screw in PART
D into PART C.
(5b) When installing the Hammock Chair,
latch the Hammock Chair loop into the
opening of the Carabiner Hook. Use a
hammer to gently tap the top of the
Hammock Chair loop until it is securely in
place and the Carabiner Hook gate snaps
closed.
For best results, secure base using nails (or
metal stakes) with a head that is greater
than ½” and body that is less than ½”;
inserted through the holes at the ends of
the base.
PART C
[TOP VIEW]
PART D
PART C
(5a) Take the Carabiner Hook and latch it onto
the loop that is on PART D. Rotate the hook such
that the narrow end meets with the loop and pull
downward. Use a hammer to lightly tap the hook
until it is securely on the loop.
FULLY ASSEMBLED
HAMMOCK CHAIR & HAMMOCK CHAIR STAND
®
BY SUNJOE
Made in China
Max Weight Capacity: 300 LBS (136 KGS)
©Bliss Hammocks is a Registered Trademark of Snow Joe, LLC
