Thank you for choosing SYNCO product.
Please read this manual carefully before use and follow all instructions mentioned herein.
Microphone P2T
User Manual
Caring For Your SYNCO Product
Package List
Product Instruction
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
TX Transmitter x2
RX Receiver (Type-C
Connector) x1
Wireless Charging Case x1
Charging Cable x1
Type-C to 3.5mm Adapter x1
TX Transmitter RX Receiver Wireless Charging Case
① Power
② Working Indicators
③ Built-in Mic
④ Contacts
⑤ Pocket Clip
① Vocal Eects/ Mono/Stereo
② Type-C Port
③ Working Indicators
④ Connector
⑤ Contacts
① Pairing/ Power Prompt
② Type-C Port
③ Working Indicators
④ Contacts
Indicator — Transmitter (Double press the Power button to turn o light eect)
System unpaired
Charging, and then turns o when fully charge
System paired, normal working
Low battery
Flash concurrently
Single light keeps on (light eect o)
Single light keeps on (in the case)
Illuminate sequentially(light eect on)
Single light ashes
Working
Indicators(White
Light)
Working
Indicators(Red Light)
TX Transmitter RX Receiver Wireless Charging Case
Indicator — Receiver
Indicator — Wireless Charging Case
Pairing
System unpaired
Stereo mode (Only original is supported)
System paired
Mono mode-Original sound
Mono mode-Vocal eects on
Illuminate sequentially
Flash concurrently
Single light keeps on & Illuminate sequentially
Single light keeps on & Illuminate sequentially
two-way
Illuminate sequentially
Single light ashes twice & Illuminate sequentially
Working
Indicators(White Light)
Working
Indicators
(White
Light)
Operations
1. Usage
2. Pairing
3. Charging
① Tap on the right side of charging case to pop out the drawer
② Take the TX and RX out
③ TX should boot automatically as it leaved the case, and switch itself o automatically
when returning to the case.
(Forcible switch: Long press the Power button on TX for 3 seconds)
④ RX should boot automatically as it is plugged into smartphone
① Place the TX and RX in the case with their contacts are connected with the case’s
② Long press the Pairing button on the case for 3 seconds with the drawer open
③ The indicators on the TX and RX should light up and illuminate sequentially when
pairing is successful
Note: The transmitter will automatically switch o if it is unpaired or disconnected for 5
minutes.
Charge the TX: Place the TX in the case with contacts connected with the case’s.
Charge the case: Connect the case with power supply via the charging cable.
Long press for 3 seconds
4. Check the power
5. Use vocal eects
TX: Short press the Power button, the indicators will light up according to remain power
for 5 seconds
Charging Case: Short press the Power Prompt button, the indicators will light up
according to remain power for 5 seconds
Short press the Vocal Eects button on the receiver to switch sound eects: Original >> Studio FX >> KTV FX >> Voice
Amplication >> EDM (Electronic Dance Music) >> Baby FX >> Male to Female >> Female to Male >> Monster FX.
Default eect: Original.
Note: The vocal eect will apply to both transmitters. In Stereo mode, only original is supported. Other vocal eects are
unavailable.
6. Mono/ Stereo
Mono-Original
Mono-Other vocal eects
Mono-Original
Long press the Mono/Stereo button on the RX once
Long press the Mono/Stereo button on the RX once
Long press the Mono/Stereo button on the RX once
Stereo
