Table of contents
Safety...............................................4
General information..........................4
Intended use.....................................4
Restriction on user group.................4
Safe installation ................................4
Safe use ...........................................6
Damaged appliance .........................7
Risk to children ................................8
Safety systems .................................9
Preventing material damage ........10
Safe installation ..............................10
Safe use .........................................10
Childproof lock
1
............................11
Door lock........................................11
Environmental protection and
saving energy................................11
Disposing of packaging .................11
Saving energy.................................11
AquaSensor
1
...................................11
Installation and connection..........11
Scope of supply .............................11
Installing and connecting the ap-
pliance ............................................12
Drainage connection ......................12
Drinking water connection .............12
Electrical connection ......................13
Familiarising yourself with
your appliance...............................14
Appliance .......................................14
Controls ..........................................15
Programmes ..................................17
Information for test institutes ..........18
Additional functions
1
....................19
Features.........................................19
Basket ............................................19
Cutlery basket ................................20
Folding prongs ...............................20
Height of tableware ........................20
Before using for the first time ......20
Performing the initial configura-
tion..................................................20
Water softening system................21
Overview of water hardness set-
tings................................................21
Setting water softening system ......21
Special salt .....................................22
Switching off water softening
system ............................................22
Regeneration of the water
softening system ............................23
Rinse aid system...........................24
Rinse aid ........................................24
Setting the amount of rinse aid......24
Switching rinse aid system off .......24
Detergent .......................................25
Suitable detergents ........................25
Unsuitable detergents ....................26
Information on detergents ..............26
Adding detergent ...........................26
Tableware ......................................27
Damage to glass and tableware ....27
Arrange tableware ..........................28
Removing tableware.......................28
Basic operation .............................29
Opening appliance door ................29
Switching on the appliance ............29
Setting a programme .....................29
Setting additional functions ............29
Setting timer programming
1
...........29
1
Depending on the appliance specifications
en
3
Starting the programme .................30
Interrupting programme .................30
Terminate programme....................30
Switching off appliance ..................30
Basic settings................................31
Overview of basic settings .............31
Cleaning and servicing.................31
Cleaning the tub .............................31
Self-cleaning interior
1
......................32
Cleaning products ..........................32
Tips on appliance care...................32
Filter system ...................................32
Cleaning the spray arm..................33
Troubleshooting............................34
Appliance safety.............................34
Error code / Fault display / Sig-
nal...................................................34
Washing results..............................36
Information on display panel..........43
Malfunctions ...................................43
Mechanical damage.......................44
Noise ..............................................44
Clean wastewater pump.................46
Transportation, storage and
disposal .........................................46
Removing the appliance ................46
Protect appliance from frost...........47
Transporting the appliance ............47
Disposing of old appliance ............47
Customer Service..........................47
Product number (E-Nr.) and pro-
duction number (FD) ......................48
Technical specifications...............48
1
Depending on the appliance specifications
en Safety
4
Safety
Observe the following safety instructions.
General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.
Intended use
Only use this appliance:
¡ For cleaning household tableware.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of 4000 m above sea level.
Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
Safe installation
WARNING‒Risk of injury!
Improper installation may cause injury.
▶
When installing and connecting the appliance, follow the in-
structions in the manual and installation instructions.
Safety en
5
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
▶
Connect and operate the appliance only in accordance with
the specifications on the rating plate.
▶
Always use the supplied power cable for the new appliance.
▶
Connect the appliance to a power supply with alternating
current only via a properly installed socket with earthing.
▶
The protective conductor system of the domestic electrical
installation must be properly installed.
▶
Never equip the appliance with an external switching
device, e.g. a timer or remote control.
▶
When the appliance is installed, the mains plug of the
power cord must be freely accessible. If free access is not
possible, an all-pole isolating switch must be installed in the
permanent electrical installation according to the installation
regulations.
▶
When installing the appliance, check that the power cable is
not trapped or damaged.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-ap-
proved adapters.
▶
Do not use extension cables or multiple socket strips.
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer.
WARNING‒Risk of burns!
If the appliance is not installed properly, this may result in
burns.
▶
With free-standing appliances, ensure that they are installed
with the back panel against a wall.
en Safety
6
Safe use
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for
use on packagings of detergent and rinse aid products may
cause serious harm to health.
▶
Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
WARNING‒Risk of explosion!
¡ Adding solvents to the interior of the appliance may cause ex-
plosions.
▶
Never add solvents to the interior of the appliance.
¡ Highly caustic alkaline or highly acidic cleaning agents in con-
junction with aluminium parts in the interior of the appliance
may cause explosions.
▶
Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, in
conjunction with aluminium parts (e.g. grease filters of ex-
tractor hoods or aluminium pans), e.g. for the Machine Care
programme.
WARNING‒Risk of injury!
¡ Leaving the appliance door open may result in injury.
▶
Only open the appliance door to load or unload tableware
in order to prevent accidents, e.g. through tripping.
▶
Do not sit or stand on the appliance door when open.
¡ Knives and utensils with sharp points can cause injuries.
▶
Arrange knives and utensils with sharp points in the cutlery
basket with the points downwards, on the knife shelf or in
the cutlery drawer.
WARNING‒Risk of scalding!
If you open the appliance door while the programme is run-
ning, hot water may splash out of the appliance.
▶
Open the appliance door carefully if the programme is still
running.
Safety en
7
WARNING‒Risk of tipping!
Overfilling the Baskets may cause the appliance to tip up.
▶
Never overfill the Baskets with free-standing appliances.
WARNING‒Risk of electric shock!
¡ An ingress of moisture can cause an electric shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat or humidity.
▶
Do not use steam- or high-pressure cleaners to clean the
appliance.
¡ If the insulation of the power cord is damaged, this is danger-
ous.
▶
Never let the power cord come into contact with hot appli-
ance parts or heat sources.
▶
Never let the power cord come into contact with sharp
points or edges.
▶
Never kink, crush or modify the power cord.
Damaged appliance
WARNING‒Risk of electric shock!
¡ If the appliance or the power cord is damaged, this is danger-
ous.
▶
Never operate a damaged appliance.
▶
Never operate an appliance with a cracked or fractured sur-
face.
▶
Never pull on the power cord to unplug the appliance. Al-
ways unplug the appliance at the mains.
▶
If the appliance or the power cord is damaged, immediately
unplug the power cord or switch off the fuse in the fuse box
and turn off the water tap.
▶
"Call customer services." →Page47
¡ Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by
trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
en Safety
8
▶
If the power cord of this appliance is damaged, it must be
replaced with a special connection cable, which is available
from the manufacturer or his Customer Service.
Risk to children
WARNING‒Risk of suffocation!
¡ Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
¡ Children may breathe in or swallow small parts, causing them
to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
¡ Children may become trapped in the appliance and suffocate.
▶
Use the childproof lock if fitted.
▶
Never let children play with or operate the appliance.
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
▶
With redundant appliances, unplug the power cord. Then
cut through the cord and damage the lock on the appliance
door beyond repair so that the appliance door will no longer
close.
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
▶
Keep an eye on children when opening and closing the ap-
pliance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the
mouth, throat and eyes.
▶
Keep children away from detergent and rinse aid products.
Safety en
9
▶
Keep children away from the appliance when open. The wa-
ter in the interior of the dishwasher is not drinking water. It
may contain residues of detergents and rinse aid.
Safety systems
Protect children from possible hazards resulting from the appli-
ance.
Depending on the features of the model, the appliance comes
with a
→"Childproof lock", Page11.
en Preventing material damage
10
Preventing material damage
Preventing material dam-
age
Preventing material damage
Safe installation
ATTENTION!
¡ Improper installation of the appli-
ance may cause damage.
▶
If the dishwasher is installed
above or below other domestic
appliances, follow the informa-
tion on installation in combina-
tion with a dishwasher in the in-
stallation instructions for the in-
dividual appliances.
▶
If there is no information or if the
installation instructions do not in-
clude the relevant information,
contact the manufacturer of
these appliances to check that
the dishwasher can be installed
above or below these appli-
ances.
▶
If no information is available
from the manufacturer, the dish-
washer should not be installed
above or below such appli-
ances.
▶
To ensure the safe operation of
all domestic appliances, con-
tinue following the installation in-
structions for the dishwasher.
▶
Only install the dishwasher be-
low a hob after taking into con-
sideration the specified safety
clearances.
▶
Do not install the dishwasher
near heat sources, e.g. radiat-
ors, heat storage tanks, ovens
or other appliances that gener-
ate heat.
¡ Modified or damaged water hoses
may result in material damage and
damage to the appliance.
▶
Never kink, crush, modify or cut
through water hoses.
▶
Only use the water hoses sup-
plied with the appliance or genu-
ine spare hoses.
▶
Never re-use water hoses that
have been used before.
¡ If the water pressure is too high or
too low, the appliance may not be
able to operate properly.
▶
Make sure that the water pres-
sure in the water supply system
is min. 50kPa (0.5bar) and
max. 1000kPa (10bar).
▶
If the water pressure exceeds
the maximum value specified, a
pressure-reducing valve must be
installed between the drinking
water connection and the hose
set of the appliance.
Safe use
ATTENTION!
¡ Escaping water vapour can dam-
age fitted units.
▶
When the programme ends,
leave the appliance to cool
down for a while before opening
the door.
¡ Special salt for dishwashers can
damage the tub due to corrosion.
▶
To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro-
gramme starts.
¡ Detergent may damage the water
softening system.
▶
Only fill the dispenser of the wa-
ter softening system with special
dishwasher salt.
¡ Unsuitable cleaning agents may
damage the appliance.
▶
Do not use a steam cleaner.
▶
So as not to scratch the finish
on the appliance, do not use
sponges with a rough surface or
abrasive cleaning agents.
Childproof lock en
11
▶
To prevent corrosion, do not use
sponge cloths on dishwashers
with a stainless steel front or
rinse such cloths thoroughly
several times before using them
for the first time.
Childproof lock
Childproof lock
1
Childproof lock
The childproof lock lets you protect
children from possible hazards result-
ing from the appliance.
Depending on the features of the
model, the appliance comes with a
door lock.
Door lock
The door lock is a mechanical safety
system and makes it more difficult to
open the appliance door.
→"Opening appliance door",
Page29
Environmental protection and saving energy
Environmental protection
and saving energy
Environmental protection and saving energy
Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶
Sort the individual components by
type and dispose of them separ-
ately.
Saving energy
If you follow these instructions, your
appliance will use less electricity and
less water.
Use the Eco50° programme.
The Eco50° programme is en-
ergy-efficient and environmentally
friendly.
AquaSensor
1
The AquaSensor is an optical meas-
uring device (light barrier) which
measures the turbidity of the washing
water. You can save water with the
AquaSensor.
Use of the AquaSensor depends on
the programme. If the soiling level is
low, the washing water is used in the
next wash cycle, allowing water con-
sumption to be reduced by 2-4 litres.
If the soiling level is higher, the wash-
ing water is drained off and replaced
with fresh water. In the automatic pro-
grammes the temperature and run-
ning time are additionally adjusted to
the level of soiling.
Installation and connection
Installation and connec-
tion
Installation and connection
Scope of supply
After unpacking all parts, check for
any damage in transit and complete-
ness of the delivery.
If you have any complaints, contact
the dealer who sold you the appli-
ance or our Customer Service.
1
Depending on the appliance specifications
en Installation and connection
12
Note:The appliance has been tested
at the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.
The delivery consists of the following:
¡ Dishwasher
¡ User manual
¡ Installation Instructions
¡ Warranty
1
¡ Installation material
¡ Steam guard plate
1
¡ Rubber apron
1
¡ Mains cable
¡ Quick reference guide
1
Installing and connecting the
appliance
You can position your appliance in a
fitted kitchen between wooden and
plastic walls.
1. "Follow the safety instructions."
→Page4
2. "Follow the instructions for elec-
trical connection." →Page13
3. Check the "Scope of supply"
→Page11 and the condition of
the appliance.
4. Consult the installation instructions
for the installation dimensions re-
quired.
5. Set the appliance up so it is level.
Make sure that the appliance is
standing on the floor securely.
6. "Install the drainage connection."
→Page12
7. "Install the drinking water connec-
tion." →Page12
8. Connect the appliance to the
power supply.
Drainage connection
Connect your appliance to drainage
connection so dirty water is dis-
charged via the wash cycle.
Installing the drainage connection
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the wastewater hose to
the outlet connection of the siphon
using the enclosed parts.
3. When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
4. Also check that there is no cover
in the drainage system preventing
the wastewater from being dis-
charged.
Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water
connection
Note
¡ If you are replacing the appliance,
you must use a new water supply
hose.
1. Consult the installation instructions
supplied for the steps required
here.
2. Connect the appliance to the drink-
ing water connection using the en-
closed parts.
Observe the "Technical data"
→Page48.
3. When doing so, check that the
drinking water connection is not
kinked, crushed or twisted.
1
Depending on the appliance specifications
Installation and connection en
13
Electrical connection
Connect your appliance to the power
supply.
Connecting the appliance to the
electricity supply
Notes
¡ Please follow the "Safety instruc-
tions" →Page4.
¡ Connect the appliance to alternat-
ing current only, in the range of
220 - 240V and 50Hz or 60Hz.
¡ Please note that the water safety
system is only functional if there is
a power supply.
1. Insert the non-heating appliance
plug of the power cable into the
appliance.
2. Insert the mains plug of the appli-
ance into a nearby socket.
The connection data for the appli-
ance can be found on the rating
plate.
3. Check that the mains plug is inser-
ted properly.
en Familiarising yourself with your appliance
14
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Familiarising yourself with your appliance
Appliance
You can find an overview of the parts of your appliance here.
1
2
3
8
7
6
4
5
1
Rating plate Rating plate with "E number and FD number"
→Page48.
The data you need for "Customer Service"
→Page47.
1
Depending on the appliance specifications
Familiarising yourself with your appliance en
15
2
Detergent dispenser "Detergent" →Page25 is added to the detergent
dispenser.
3
Cutlery basket
1
"Cutlery basket" →Page20
4
Dispenser for special salt Add special salt to the dispenser for special salt.
→"Water softening system", Page21
5
Spray arm The spray arm washes the tableware in the basket.
If the tableware has not been washed properly, clean
the spray arm.
→"Cleaning the spray arm", Page33
6
Filter system "Filter system" →Page32
7
Basket "Basket" →Page19
8
Dispenser for rinse aid Add rinse aid to the dispenser for rinse aid.
→"Rinse aid system", Page24
1
Depending on the appliance specifications
Controls
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
With some buttons you can perform different functions.
2 4 5 6
789
1 3
1
ON/OFF button "Switching on the appliance" →Page29
"Switching off the appliance" →Page30
2
Programme selector "Programmes" →Page17
1
Depending on the appliance specifications
en Familiarising yourself with your appliance
16
3
Start button and reset button "Starting the programme" →Page30
"Terminating the programme" →Page30
4
Programme sequence display The programme sequence display shows the cur-
rent cycle of the appliance, e.g. washing or dry-
ing.
5
Timer programming
1
"Setting timer programming" →Page29
6
Additional functions
1
"Additional functions" →Page19
7
Rinse aid refill indicator "Rinse aid system" →Page24
8
Special salt refill indicator "Water softening system" →Page21
9
Water supply display Display for water supply
1
Depending on the appliance specifications
Programmes en
17
Programmes
Programmes
Programmes
You can find an overview of the pro-
grammes that can be selected here.
Different programmes, which can be
found on the control panel of your
appliance, are available depending
on the appliance configuration.
The running time may vary depend-
ing on the programme selected. The
running time depends on the water
temperature, the quantity of table-
ware, the level of soiling and the ad-
ditional function selected. The run-
ning time will change if the rinse aid
system is switched off or rinse aid
needs to be added.
The consumption values can be
found in the quick reference guide.
The consumption values relate to
normal conditions and a water hard-
ness of 9-20°E. Different influen-
cing factors such as water temperat-
ure or pipe pressure may result in
deviations.
Programme Use Programme se-
quence
Additional functions
Intensive 70°
Dishes:
¡ Washing pots and
pans, non-fragile
tableware and cut-
lery.
Level of soiling:
¡ Removing stubborn
burned or dried-on
food remnants con-
taining starch and
protein.
When using powder de-
tergent, you can also
apply a little to the in-
side of the appliance
door.
Intensive:
¡ Pre-rinse
¡ Cleaning 70°C
¡ Intermediate rinse
¡ Final rinse 69°C
¡ Drying
All
→"Additional func-
tions", Page19
Mix 65°
Dishes:
¡ Cleaning mixed
dishes and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants normally to
firmly dried-on.
Intensive:
¡ Pre-rinse
¡ Cleaning 65°C
¡ Intermediate rinse
¡ Final rinse 69°C
¡ Drying
All
→"Additional func-
tions", Page19
en Programmes
18
Programme Use Programme se-
quence
Additional functions
Eco 50°
Dishes:
¡ Cleaning mixed
dishes and cutlery.
Level of soiling:
¡ Removing common
household food rem-
nants lightly dried-
on.
Most economical:
¡ Pre-rinse
¡ Cleaning 50°C
¡ Intermediate rinse
¡ Final rinse 66°C
¡ Drying
All
→"Additional func-
tions", Page19
Glass 40°
Dishes:
¡ Cleaning delicate
tableware, cutlery,
temperature-sensit-
ive plastics, glasses
and stemware in the
stemware basket.
Level of soiling:
¡ Removing lightly ad-
hering fresh food
remnants.
Particularly gentle:
¡ Pre-rinse
¡ Cleaning 40°C
¡ Intermediate rinse
¡ Final rinse 60°C
¡ Drying
ExtraDry
→"Additional func-
tions", Page19
Quick 45°
Dishes:
¡ Cleaning delicate
tableware, cutlery,
temperature-sensit-
ive plastics and
glasses.
Level of soiling:
¡ Removing lightly ad-
hering fresh food
remnants.
Time-optimised:
¡ Cleaning 45°C
¡ Intermediate rinse
¡ Final rinse 55°C
ExtraDry
→"Additional func-
tions", Page19
PreRinse
Dishes:
¡ Cleaning all types of
dishes.
Level of soiling:
¡ Cold rinsing, inter-
mediate cleaning.
Cold rinse suitable:
¡ Pre-rinse
None
Information for test institutes
Test institutes are provided with in-
formation for comparability tests, e.g.
according to EN60436.
These are the conditions for conduct-
ing the tests, however they are not
the results or consumption values.
E-mail enquiries to: dishwasher@test-
appliances.com
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rat-
ing plate on the appliance door.
Additional functions en
19
Additional functions
Additional functions
1
Additional functions
You can find an overview of the addi-
tional functions that can be selected
here. Different additional functions,
which can be found on the control
panel of your appliance, are available
depending on the appliance configur-
ation.
Additional function Use
Hygiene
¡ To ensure a higher
hygiene status for
the appliance and
dishes, the temper-
ature is raised and
maintained for an
extra-long period.
¡ Especially suitable
for cleaning chop-
ping boards or
baby bottles.
¡ Continuous use of
this function in-
creases the hy-
giene status.
¡ This will increase
the running time
and energy con-
sumption.
ExtraDry
¡ For a better drying
result the final
rinse temperature
is increased and
the drying phase
extended.
¡ Especially suitable
for drying plastic
parts.
¡ There is a slight in-
crease in energy
consumption and
the running time is
extended.
Additional function Use
SpeedPerfect
¡ The running time is
shortened by 20%
to 50% depending
on the washing
programme.
¡ Energy and water
consumption are
increased.
Features
Features
Features
You can find an overview of the pos-
sible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.
Basket
Arrange the tableware in the basket.
1
Depending on the appliance specifications
en Before using for the first time
20
Cutlery basket
Arrange cutlery in the cutlery basket,
always without sorting it and with the
sharp points downwards.
Folding prongs
Use the folding prongs to position
tableware securely, e.g. plates.
You can fold the prongs down to po-
sition pans, bowls and glasses
better.
1
Folding down prongs
1
If you do not need the prongs, fold
them down.
1. Push the lever forwards and fold
down the prongs .
1
2
2. To use the prongs again, fold them
back up.
a The prongs audibly click into posi-
tion.
Height of tableware
You can place tableware with a max-
imum height of 28cm in the basket.
Before using for the first time
Before using for the
first time
Before using for the first time
Performing the initial config-
uration
On initial start-up or after a reset to
the factory settings, you will need to
make settings.
Requirement:"The appliance has
been installed and connected."
→Page11
1.
"Add special salt." →Page22
2.
"Add rinse aid." →Page24
3. "Switch on the appliance."
→Page29
4. "Setting the water softening sys-
tem." →Page21
1
Depending on the appliance specifications
Water softening system en
21
5. "Set the amount of rinse aid to be
dispensed." →Page24
6.
"Add detergent" →Page25.
7. Start the Programme with the
highest cleaning temperature
without tableware.
To remove any marks from water
or other residues, we recommend
you operate the appliance without
tableware before using it for the
first time.
Tip:You can change these settings
and other "Basic settings"
→Page31 at any time.
Water softening system
Water softening system
Water softening system
Hard water leaves limescale on the
tub and tableware and parts of the
appliance may become blocked.
To ensure good dishwashing results,
you can treat the water with special
salt and the water softening system.
To avoid damage to the appliance,
water with a hardness above 9 °E
must be softened.
Overview of water hardness settings
You can find an overview of the water hardness values that can be selected
here.
You can find out how hard your water is from your local water company or by
using a water hardness tester.
Water hard-
ness value
°E
Hardness
range
mmol/l Level LED LED LED
0 - 8 Soft 0 - 1.1 0
9 - 20 Medium 1.2 - 2.9 1
21 - 26 Hard 3.0 - 3.7 2
27 - 44 Hard 3.8 - 6.2 3
Note:Set the water hardness determ-
ined on your appliance.
With a water hardness of 0 - 8°E
you can dispense with special salt
and switch off the water softening
system.
Setting water softening sys-
tem
Set the water hardness on your appli-
ance.
1. Determine the water hardness and
the appropriate setting value.
2. Press .
3. Press and hold .
4. Turn the programme selector until
flashes.
5. Release the button.
6. Turn the programme selector until
the required level has been set.
0, 1, 2 or 3 LEDs will light up ac-
cordingly.
→"Overview of water hardness set-
tings", Page21
The factory setting is level 1 (LED
).
7. Press to save the setting.
a The LEDs go out.
en Water softening system
22
Special salt
You can use special salt to soften
water.
Adding special salt
If the special salt refill indicator lights
up, add special salt to the dispenser
for special salt just before the pro-
gramme starts. The amount of spe-
cial salt required depends on the wa-
ter hardness: the higher the water
hardness, the greater the amount of
special salt required.
ATTENTION!
¡ Detergent may damage the water
softening system.
▶
Only fill the dispenser of the wa-
ter softening system with special
dishwasher salt.
¡ Special salt can damage the tub
due to corrosion.
▶
To make sure that any special
salt that escapes is washed out
of the tub, add the special salt
to the dispenser for special salt
immediately before the pro-
gramme starts.
1. Unscrew the lid of the dispenser
for special salt and remove.
2. On initial start-up: Fill the dispenser
right up with water.
3. Note:Only use special salt for
dishwashers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dis-
penser.
a
Funnel
1
Fill the dispenser right up with spe-
cial salt. The water in the dis-
penser is displaced and forced
out.
4. Place the lid back on the dis-
penser and turn to close.
Switching off water softening
system
If you find the special salt refill indic-
ator irritating, e.g. when using com-
bined detergents with salt replace-
ment substances, you can switch the
salt refill indicator off.
Note
To avoid damage to the appliance, only
switch off the water softening system in
the following cases:
¡ The water hardness is max. 26°E
and you are using combined deter-
gents with salt replacement sub-
stances. According to manufactur-
ers, combined detergents with salt
replacement substances can gen-
1
Depending on the appliance specifications
Water softening system en
23
erally only be used up to a water
hardness of 26°E without adding
special salt.
¡ The water hardness is 0 - 8°E.
You do not need to use special
salt.
1. Press .
2. Press and hold .
3. Turn the programme selector until
flashes.
4. Release the button.
5. Turn the programme selector until
no LED lights up (level 0).
→"Overview of water hardness set-
tings", Page21
6. Press to save the setting.
a The LEDs go out.
a The water softening system is
switched off and the salt refill indic-
ator is deactivated.
Regeneration of the water
softening system
In order to obtain fault-free function of
the water softening system, the appli-
ance performs reheating of the water
softening system at regular intervals.
Regeneration of the water softening
system takes place before the end of
the main rinse cycle in all pro-
grammes. It will increase the run time
and consumption values, e.g. water
and electricity.
Overview of consumption values with regeneration the water softening
system
Here you can find an overview of the maximum additional running time and
consumption values during regeneration of the water softening system.
You can find the column applicable to your model in the quick reference guide
according to its water consumption in the Eco50° programme.
Water consump-
tion in litres (de-
pending on
model)
Regeneration of
the water soften-
ing system after
x rinse cycles
Additional run-
ning time in
minutes
Additional water
consumption in
litres
Additional power
consumption in
kWh
8 5 4 2.5 0.03
9 4 4 2.5 0.03
The consumption values specified
are laboratory measurements determ-
ined in accordance with the currently
applicable standard and using the
Eco 50° programme and the factory
value of the water hardness is set to
9 - 20°E.
en Rinse aid system
24
Rinse aid system
Rinse aid system
Rinse aid system
You can use the rinse aid system
and rinse aid to get tableware and
glasses rinsed perfectly without
marks.
Rinse aid
For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dish-
washers.
Adding rinse aid
If the rinse aid refill indicator lights
up, top up with rinse aid. Only use
rinse aid for domestic dishwashers.
1. Press the catch on the lid of the
dispenser for rinse aid and lift
.
1
2
2. Add rinse aid up to the max mark.
max
3. If rinse aid spills out, remove it
from the tub.
Spilled rinse aid can cause ex-
cessive frothing during the wash
cycle.
4. Close the lid of the dispenser for
rinse aid.
a The lid clicks into position.
Setting the amount of rinse
aid
If there are streaks or water marks on
tableware, change the amount of
rinse aid.
1. Press .
2. Press and hold .
3. Turn the programme selector until
flashes.
4. Release the button.
5. Turn the programme selector until
the right amount of rinse aid has
been set.
0, 1, 2 or 3 LEDs will light up ac-
cordingly.
The factory setting is level 2 (LED
and LED ).
– A low setting adds less rinse aid
during the wash cycle and re-
duces streaking on tableware.
– A higher setting adds more
rinse aid during the wash cycle,
reduces water marks and im-
proves the drying result.
6. Press to save the setting.
a The LEDs go out.
Switching rinse aid system off
If you find the rinse aid refill indicator
irritating, e.g. when using combined
detergents with a rinse aid compon-
ent, you can switch the rinse aid sys-
tem off.
Tip:The function of rinse aid is lim-
ited with combined detergents. You
will generally get better results using
rinse aid.
Detergent en
25
1. Press .
2. Press and hold .
3. Turn the programme selector until
flashes.
4. Release the button.
5. Turn the programme selector until
no LED lights up (level 0).
6. Press to save the setting.
a The LEDs go out.
a The rinse aid system is switched
off and the rinse aid refill indicator
is deactivated.
Detergent
Detergent
Detergent
Suitable detergents
Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying res-
ults, use separate detergent, adding
"Special salt" →Page22 and "Rinse
aid" →Page24 separately.
Modern, powerful detergents mainly
use a low-alkaline formulation with
enzymes. Enzymes break down
starch and remove protein. Oxygen-
based bleaching agents are generally
used to remove coloured marks, e.g.
tea or ketchup.
Note:Follow the manufacturer's in-
structions for each detergent.
Detergent Description
Tabs Tabs are suitable for all
cleaning functions and do
not need to be measured
out.
With shorter Programmes
tabs sometimes do not dis-
solve entirely and leave
residues of detergent. This
may impair the cleaning ef-
fect.
Detergent Description
Powder deter-
gent
Powder detergent is re-
commended for shorter
Programmes.
The dosage can be adjus-
ted to the level of soiling.
Liquid detergent Liquid detergent works
faster and is recommen-
ded for shorter Pro-
grammes without PreR-
inse.
Sometimes liquid deter-
gent may leak out despite
the detergent dispenser
being closed. This is not a
fault and is non-critical if
you remember the follow-
ing:
¡ Only choose a pro-
gramme without PreR-
inse.
¡ Do not select timer pro-
gramming for starting
the programme.
The dosage can be adjus-
ted to the level of soiling.
Tip:Suitable detergents are available
online via our website or from "Cus-
tomer Service" →Page47.
Separate detergents
Separate detergents are products
that do not contain components other
than detergent, e.g. powder deter-
gent or liquid detergent.
With powder and liquid detergent the
dosage can be individually adjusted
to the level of soiling of the table-
ware.
For better washing and drying results
and to avoid damage to the appli-
ance, please additionally use "Spe-
cial salt" →Page22 and "Rinse aid"
→Page24.
en Detergent
26
Combined detergent
Besides conventional separate deter-
gents, a number of products are
available with additional functions.
These products contain not only de-
tergent but also rinse aid and salt re-
placement substances (3in1) and,
depending on the combination (4in1,
5in1,...), additional components such
as glass protection or stainless steel
cleaner.
According to manufacturers, com-
bined detergents generally only func-
tion up to a water hardness of 26°E.
With a water hardness above 26°E
you will need to add special salt and
rinse aid. For the best washing and
drying results we recommend using
special salt and rinse aid from a wa-
ter hardness of 17°E. If you are us-
ing combined detergent, the washing
programme is adjusted automatically
to ensure the best possible washing
and drying result.
Unsuitable detergents
Do not use detergent which could
cause damage to the appliance or
present a risk to health.
Detergent Description
Hand washing-up
liquid
Hand washing-up liquid
can cause increased froth-
ing and damage the appli-
ance.
Detergent con-
taining chlorine
Chlorine residue on table-
ware may present a risk to
health.
Information on detergents
Follow the instructions on detergents
in everyday use.
¡ Detergents marked as "organic" or
"ecological" (environmentally
friendly) generally contain lower
levels of active agents or com-
pletely dispense with certain sub-
stances. The cleaning effect may
be restricted here.
¡ Set the rinse aid and the water
softening system to the separate
detergent or combined detergent
in use.
¡ According to manufacturers, com-
bined detergents with salt replace-
ment substances can only be used
up to a certain water hardness,
usually 26°E, without adding spe-
cial salt. For the best washing and
drying results we recommend us-
ing special salt from a water hard-
ness of 17°E.
¡ To prevent sticking, only touch de-
tergents in a water-soluble pouch
with dry hands and only ever place
them in a dry detergent dispenser.
¡ Even if the rinse aid and special
salt refill indicators light up, wash-
ing programmes will run properly
with combined detergents.
¡ The function of rinse aid is limited
with combined detergents. You will
generally get better results using
rinse aid.
¡ Use tablets with a special drying
performance.
Adding detergent
1. To open the detergent dispenser,
press the locking latch.
Tableware en
27
2. Add the detergent to the dry deter-
gent dispenser.
15 ml
25 ml
50 ml
If you are using tablets, one is
enough. Insert the tablets in a hori-
zontal position.
If you are using powder or liquid
detergent, follow the manufac-
turer's instructions and quantities
for dosage in the detergent dis-
penser.
3. Close the lid of the detergent dis-
penser.
a The lid clicks into position.
a The detergent dispenser will open
automatically at the optimum time
during the programme. Powder or
liquid detergent will spread around
the washing tank and dissolve
there. Tablets will fall into the appli-
ance and dissolve.
Tip:If you use powder detergent and
select a program with pre-rinse, you
can also add a little detergent to the
interior door of the appliance.
Tableware
Tableware
Tableware
Only clean tableware that is suitable
for dishwashers.
Note:Decorated glassware and parts
made of aluminium or silver may
fade or discolour with dishwashing.
Delicate types of glass may turn
cloudy after a few washing cycles.
Damage to glass and table-
ware
Only put glasses and china in the
dishwasher if it is marked as dish-
washer-safe by the manufacturer.
Avoid damage to glass and table-
ware.
Cause Recommendation
The following table-
ware is not dish-
washer-safe:
¡ Items of cutlery
and tableware
made from wood
¡ Decorated glass-
ware, antique and
hand-crafted table-
ware
¡ Plastic parts not
resistant to heat
¡ Tableware made
from copper or tin
¡ Tableware soiled
with ash, wax, lub-
ricating grease or
paint
¡ Very small items of
tableware
Only put tableware in
the dishwasher if it is
marked as dish-
washer-safe by the
manufacturer.
The chemical com-
position of detergent
causes damage.
Use a detergent
marked by the manu-
facturer as gentle on
tableware.
en Tableware
28
Cause Recommendation
Highly caustic alkaline
or highly acidic clean-
ing solutions, in partic-
ular commercial or in-
dustrial cleaners, are
not safe to use in the
dishwasher with alu-
minium.
If you are using highly
caustic alkaline or
highly acidic cleaning
agents, in particular
commercial or indus-
trial cleaning agents,
do not put aluminium
parts in the dish-
washer interior.
The water temperat-
ure of the programme
is too high.
Select a programme
with lower temperat-
ures.
After the programme
has ended, take glass-
ware and cutlery out
of the appliance
without delay.
Arrange tableware
Arrange tableware correctly to optim-
ise the dishwashing result and pre-
vent damage to both the appliance
and tableware.
Tips
¡ Using the appliance allows you to
save energy and water compared
to washing-up by hand.
¡ See our website for examples of
how to load your appliance effi-
ciently, free of charge.
¡ To save energy and water, load
the machine with the number of
place settings specified (standard
load with tableware and cutlery).
→"Technical specifications",
Page48
¡ For better washing and drying res-
ults, position items with curves or
recesses at an angle so water can
run off.
1. Remove large remnants of food
from tableware.
To save resources, do not pre-
rinse tableware under running wa-
ter.
2. Observe the following when arran-
ging tableware:
– To prevent damage to table-
ware, arrange it so it is stable
and cannot tip over.
– To prevent injury, arrange cut-
lery with the points and sharp
edges facing down.
– Position containers with the
openings facing down so no wa-
ter can collect in them.
– Do not block the spray arm so it
can still turn.
Removing tableware
WARNING
Risk of injury!
Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
to shock, may crack and can result in
injury.
▶
When the programme has ended,
do not empty the appliance until
the tableware has cooled down for
a while.
Basic operation en
29
▶
Check the washing tank and ac-
cessories for soiling and clean if
necessary.
→"Cleaning and servicing",
Page31
Basic operation
Basic operation
Basic operation
Opening appliance door
1. If the childproof lock
1
is not activ-
ated, open the appliance door.
2. If the childproof lock
1
is activated,
press the catch of the lock to the
right and open the appliance
door .
1
2
Switching on the appliance
▶
Press .
The Eco 50° programme is set by
default.
The Eco 50° programme is an es-
pecially environmentally friendly
programme and ideal for normally
soiled tableware. It is the most effi-
cient programme for the combina-
tion of energy/water consumption
for this type of tableware and evid-
ences conformity with the EU Eco-
design Directive.
If you do not perform any actions
on the appliance for 15 minutes,
the appliance will automatically
switch off.
Setting a programme
To adjust the wash cycle to the soil-
ing level of the tableware, select a
suitable programme.
▶
Turn the programme selector until
the right programme has been se-
lected.
a The programme is set and the LED
flashes.
Setting additional functions
You can set additional functions to
complete the washing programme
selected.
Note:The additional functions which
can be used depend on the pro-
gramme selected.
▶
Press the button for the relevant
additional function.
a The additional function is set and
the additional function button
flashes.
Setting timer programming
1
You can delay the start of the pro-
gramme by 3, 6 or 9 hours.
1. Press repeatedly until the relev-
ant display lights up.
2. To activate timer programming,
press .
Note:To deactivate timer program-
ming, press repeatedly until none
of the displays 3h, 6h or 9h light up.
1
Depending on the appliance specifications
en Basic operation
30
Starting the programme
▶
Press .
a The programme has ended when
no indicators on the controls light
up.
Notes
¡ You can only change a pro-
gramme when running if you can-
cel it.
→"Terminate programme",
Page30
¡ The appliance switches off auto-
matically 1minute after the end of
the programme to save energy. If
you open the appliance door im-
mediately after the programme has
ended, the appliance will switch off
after 4 seconds.
Interrupting programme
Note:When you open the appliance
door once the appliance has heated
up, leave the door slightly ajar for a
few minutes and then close it. This
will help prevent excess pressure
building up in the appliance and stop
the appliance door bursting open.
1. Press .
a The programme is saved and the
appliance switches off.
2. Press to resume the pro-
gramme.
Terminate programme
To end a programme early or to
switch from a programme that has
already started, you will need to can-
cel it first.
▶
Press for approx.
3seconds.
a The programme is cancelled and
ends after approx. 1minute.
Switching off appliance
1. Please note the information on
"Safe use" →Page10.
2. Press .
3. To prevent damage from dripping
water, turn the water tap off tight
(not applicable to appliances with
Aqua-Stop).
Tip:If you press during the wash
cycle, the programme currently run-
ning will be interrupted. When you
switch the appliance back on, the
programme continues automatically.
Basic settings en
31
Basic settings
Basic settings
Basic settings
You can configure the basic settings for your appliance to meet your needs.
Overview of basic settings
The basic settings depend on the features of your appliance.
Basic setting Selection Description
Water hardness Scale with 4 levels Set the water hardness.
→"Setting water softening sys-
tem", Page21
Rinse aid disp. Scale with 4 levels Set the amount of rinse aid to
be dispensed or switch off.
→"Setting the amount of rinse
aid", Page24
Extra Dry On
Off
1
Switch ExtraDry on or off for
each operation.
For a better drying result the
temperature in the final rinse is
increased. This may increase
the run time slightly.
Note:Please take care with del-
icate tableware.
→"Setting Intensive drying",
Page31
1
Factory setting (may vary according to model)
Setting Intensive drying
1. Press .
2. Press and hold .
3. Turn the programme selector until
flashes.
4. Release the button.
5. Turn the programme selector until
the right level has been set.
– If the LED lights up, Intensive
drying is switched on.
– If the LED does not light up,
Intensive drying is switched off.
6. Press to save the setting.
a The LEDs go out.
Cleaning and servicing
Cleaning and servicing
Cleaning and servicing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
Cleaning the tub
WARNING
Risk of harm to health!
Using detergents containing chlorine
may result in harm to health.
▶
Never use detergents containing
chlorine.
1. Remove any coarse soiling in the
interior with a damp cloth.
en Cleaning and servicing
32
2. Add detergent to the detergent dis-
penser.
3. Select the programme with the
highest temperature.
4. "Start the programme without
tableware." →Page30
Self-cleaning interior
1
To remove deposits, the appliance
self-cleans the interior at regular inter-
vals.
The programme sequence is auto-
matically adjusted for self-cleaning,
e.g. the cleaning temperature is
briefly increased. Consumption val-
ues, e.g. water and electricity, may
also increase.
If the interior is no longer self-cleaned
adequately and deposits occur, see
this information:
→"Cleaning the tub", Page31.
Cleaning products
Only use suitable cleaning products
to clean your appliance.
→"Safe use", Page10
Tips on appliance care
Follow the tips on appliance care to
make sure your appliance functions
properly at all times.
Action Benefit
Wipe the door seals,
the front of the dish-
washer and the con-
trol panel regularly us-
ing a damp cloth and
washing-up liquid.
This ensures the parts
of the appliance will
remain clean and hy-
gienic.
If the appliance is not
going to be used for a
while, leave the door
slightly ajar.
This will prevent un-
pleasant odours.
Filter system
The filter system removes coarse
soiling from the dishwashing cycle.
1
2
3
1
Micro filter
2
Fine filter
3
Coarse filter
Cleaning filters
Soiling in the dishwashing water may
block the filters.
1. After each wash check the filters
for residue.
2. Turn the coarse filter anticlockwise
and remove the filter system .
‒ Check that no foreign objects
fall into the sump.
2
1
1
Depending on the appliance specifications
Cleaning and servicing en
33
3. Pull down the micro filter to re-
move.
4. Press the locking catches to-
gether and lift the coarse filter out
.
1
2
5. Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine fil-
ter.
6. Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into posi-
tion.
7. Insert the filter system into the ap-
pliance and turn the coarse filter
clockwise.
Make sure that the arrow markings
match up.
Cleaning the spray arm
Limescale and soiling in the dish-
washing water may block the nozzles
and bearing of the spray arm. Clean
the spray arm regularly.
1. Pull up the spray arm to remove.
2. Check the outlet nozzles on the
spray arm for blockages under
running water and remove any for-
eign objects.
3. Insert the spray arm.
a The spray arm clicks into position.
en Troubleshooting
34
Troubleshooting
Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained specialist
staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced with a
special connection cable, which is available from the manufacturer or his
Customer Service.
Appliance safety
Fault Cause Troubleshooting
Appliance door will not open
or cannot be opened easily.
Childproof lock is activated.
▶
"Open the appliance door."
→Page29
Error code / Fault display / Signal
Fault Cause Troubleshooting
Display for water supply
lights up
Supply hose is kinked.
▶
Install the supply hose without
kinks.
Water tap is turned off.
▶
Turn on the water tap.
Water tap is jammed or
furred up.
▶
Turn on the water tap.
The filters in the water con-
nection of the supply or
AquaStop hose are blocked.
1. Switch off the appliance.
2. Pull out the mains plug.
3. Turn off the water tap.
4. Unscrew the water connection.
Troubleshooting en
35
Fault Cause Troubleshooting
Display for water supply
lights up
5. Remove the filter from the supply
hose
6. Clean the filter.
7. Re-insert the filter in the supply
hose.
8. Screw the water connection back
on.
9. Check the water connection for
leaks.
10. Restore the power supply.
11. Switch the appliance on.
Filters are soiled or blocked.
▶
Clean the filters.
→"Cleaning filters", Page32
Wastewater hose is blocked
or kinked.
1. Reposition the wastewater hose
without kinks.
2. Remove residues.
Siphon connection is still
sealed.
▶
Check the connection to the siphon
and open if necessary.
Cover of the wastewater
pump is loose.
▶
Secure the cover of the "Wastewa-
ter pump " →Page46 so it clicks
into position.
en Troubleshooting
36
Fault Cause Troubleshooting
Display "Check water sup-
ply" flashes
A technical fault is present. 1. Press .
2. Unplug the appliance or switch off
the fuse.
3. Wait at least 2minutes.
4. Insert the mains plug of the appli-
ance in a socket or switch on the
fuse.
5. Switch the appliance on.
6. If the problem occurs again:
‒ Press .
‒ Turn off the water tap.
‒ Pull out the mains plug.
‒ Contact "Customer Service"
→Page47 and give the er-
ror code.
Displays flash Appliance door is not closed
properly.
▶
Close the appliance door.
‒ Arrange the tableware so
that no parts project beyond
the basket and prevent the
appliance door from closing
properly.
Washing results
Fault Cause Troubleshooting
Tableware is not dry. No rinse aid used or dosage
set too low.
1. Add "Rinse aid" →Page24.
2. Set the amount of rinse aid to be
dispensed.
Programme or programme
option has no drying phase,
or the drying phase is too
brief.
▶
Select a programme with drying,
e.g. intensive, strong or ECO pro-
gramme.
Some option buttons decrease the
drying result, e.g varioSpeed.
Troubleshooting en
37
Fault Cause Troubleshooting
Tableware is not dry. Water collects in recesses of
the tableware or cutlery.
▶
Position tableware at an angle
where possible.
The combined detergent
used has a poor drying per-
formance.
1. Use rinse aid to improve drying per-
formance.
2. Use a different combined detergent
with a better drying performance.
Extra Dry not activated to im-
prove drying performance.
▶
Activate Extra Dry.
Tableware removed too
early or drying process not
yet ended.
1. Wait until the programme ends.
2. Only remove tableware 30minutes
after the programme has ended.
Rinse aid used has a limited
drying performance.
▶
Use a name-brand rinse aid.
Eco products may have limited ef-
fectiveness.
Plastic tableware is not dry. Not a fault. As plastic does
not store heat so well, it also
does not dry as well.
▶
No remedial action possible.
Cutlery is not dry. Cutlery not arranged prop-
erly in the cutlery basket or
cutlery drawer.
Droplets can form on the cutlery con-
tact points.
1. "Arrange cutlery individually where
possible." →Page28
2. Avoid points of contact.
Appliance interior still wet
after wash cycle.
Not a fault. The condensa-
tion drying principle causes
water droplets in the tub –
they are indeed desirable
here. The moisture in the air
condenses on the inside
walls, runs off and is
pumped out.
No action required.
en Troubleshooting
38
Fault Cause Troubleshooting
Remnants of food on table-
ware.
Tableware is placed too
close together or basket is
overfilled.
1. Arrange tableware with sufficient
space in between.
The spray jets must reach the sur-
faces of the tableware.
2. Avoid points of contact.
Spray arm rotation is
blocked.
▶
Arrange tableware so that it does
not obstruct spray arm rotation.
Spray arm nozzles are
blocked.
▶
Clean the Spray arms.
Filters are soiled.
▶
Clean the filters.
→"Cleaning filters", Page32
Filters are inserted incor-
rectly and/or not engaged.
1. Insert the filters properly.
→"Filter system", Page32
2. Engage the filters.
Washing programme selec-
ted too weak.
▶
Select a more intensive washing
programme.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
Tall narrow receptacles in
corner areas are not rinsed
adequately.
▶
Do not position tall narrow recept-
acles at too great an angle or in
corner areas.
Top baskets on right and left
are not set to same height.
▶
Set the top baskets on the left and
right to the same level.
Detergent residue in the ap-
pliance
Lid of the detergent dis-
penser is blocked by items
of tableware parts and will
not open.
1. Arrange tableware in the top basket
tableware so the tab collecting tray
is not obstructed by tableware.
→"Arrange tableware", Page28
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fra-
grance dispensers in the tablet col-
lecting tray.
The lid of the detergent dis-
penser is blocked by the tab
and will not open.
▶
Position the tab in the detergent dis-
penser crosswise, not vertically.
Troubleshooting en
39
Fault Cause Troubleshooting
Detergent residue in the ap-
pliance
Tabs are used in the quick
or short programme. Dissolv-
ing time of the tab is not at-
tained.
▶
Select a more intensive Programme
or use "Powder detergent"
→Page25.
Washing effect and dissolv-
ing performance are re-
duced after a prolonged
storage time or detergent is
very lumpy.
▶
Change your "detergent"
→Page25.
Water marks on plastic
parts.
Due to laws of physics
droplet formation on plastic
surfaces is unavoidable.
After drying water marks are
visible.
▶
Select a more intensive pro-
gramme.
▶
Position tableware at an angle.
→"Arrange tableware", Page28
▶
Use rinse aid.
→"Rinse aid", Page24
▶
Set the water softening system
higher.
Wipeable or water-soluble
coatings are present inside
the appliance or on the door.
Detergent substances are
deposited there. These coat-
ings cannot generally be re-
moved with chemicals.
▶
Change your "detergent"
→Page25.
▶
Clean the appliance mechanically.
White coating is deposited in
the appliance interior.
1. Set the water softening system cor-
rectly.
In most cases you will need to in-
crease the setting.
2. Change your detergent if required.
Special salt dispenser is not
screwed tight.
▶
Screw the special salt dispenser
tight.
Stubborn white coatings are
present on tableware, inside
the appliance or the door.
Detergent substances are
deposited there. These coat-
ings cannot generally be re-
moved with chemicals.
▶
Change your "detergent"
→Page25.
▶
Clean the appliance mechanically.
The hardness range is set in-
correctly or the water hard-
ness is greater than 44°E
(6,2mmol/l).
▶
Set the "Water softening system"
→Page21 to the water hardness
or add special salt.
3in1/organic/eco detergent
is not effective enough.
▶
Set the "Water softening system"
→Page21 to the water hardness
and use separate detergents (pro-
prietary detergent, special salt,
rinse aid).
en Troubleshooting
40
Fault Cause Troubleshooting
Stubborn white coatings are
present on tableware, inside
the appliance or the door.
Too little detergent is being
used.
▶
Increase the amount of detergent
used or change "Detergent "
→Page25.
Washing programme selec-
ted too weak.
▶
Select a more intensive washing
programme.
Tea residue or lipstick marks
on tableware.
Washing temperature is too
low.
▶
Select a programme with a higher
washing temperature.
Too little detergent is being
used or is unsuitable.
▶
Use a suitable "Detergent "
→Page25 and follow the manufac-
turer's instructions for the amount
to be used.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
Coloured coatings (blue, yel-
low, brown) that are difficult
or impossible to remove are
present inside the appliance
or on stainless steel table-
ware.
The formation of films is due
to substances contained in
vegetables (cabbage, celery,
potatoes, noodles, etc.) or
tap water (manganese).
▶
Clean the appliance.
You can remove deposits with
"Mechanical cleaning" →Page31
or a machine cleaning product. It
may not always be possible to com-
pletely remove deposits but they
are harmless to health.
The formation of films is due
to metal components on sil-
ver or aluminium tableware.
▶
Clean the appliance.
You can remove deposits with
"Mechanical cleaning" →Page31
or a machine cleaning product. It
may not always be possible to com-
pletely remove deposits but they
are harmless to health.
Coloured deposits (yellow,
orange, brown) that are easy
to remove are present inside
the appliance (mainly at the
bottom).
The formation of films is due
to ingredients of food rem-
nants and tap water (limes-
cale) "soaplike".
1. Check the setting of the water
softening system.
2. Add special salt.
→"Adding special salt", Page22
3. If you are using combined deter-
gents (tabs), activate the water
softening system.
Follow the information about deter-
gents.
→"Information on detergents",
Page26
Troubleshooting en
41
Fault Cause Troubleshooting
Plastic parts inside the appli-
ance are discoloured.
Plastic parts inside the appli-
ance may become discol-
oured during the life of the
dishwasher.
▶
Discolouration can come about and
will not impair functioning of the ap-
pliance.
Plastic parts are discol-
oured.
Washing temperature is too
low.
▶
Select a programme with a higher
washing temperature.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
Removable streaks are
present on glasses, glass-
ware with a metallic appear-
ance and cutlery.
Amount of rinse aid to be
dispensed is set too high.
▶
Set the rinse aid system to a lower
setting.
No rinse aid has been ad-
ded.
▶
→"Adding rinse aid", Page24
Detergent residue is present
in the final rinse. Lid of the
detergent dispenser is
blocked by tableware items
and will not open fully.
1. Arrange tableware in the top basket
tableware so the tab collecting tray
is not obstructed by tableware.
→"Arrange tableware", Page28
Items of tableware are blocking the
dispenser lid.
2. Do not place tableware or fra-
grance dispensers in the tablet col-
lecting tray.
Tableware has been pre-
cleaned too intensely. The
sensors chose a weaker pro-
gramme. Stubborn soiling
cannot be entirely removed.
▶
Only remove large remnants of food
and do not prerinse tableware.
en Troubleshooting
42
Fault Cause Troubleshooting
Irreversible clouding of
glassware.
Glasses are not dishwasher-
proof, only suitable for dish-
washers.
▶
Use dishwasher-proof glasses.
Glasses are usually only suitable for
use in a dishwasher, i.e. long-term
wear or long-term changes must be
expected.
▶
Avoid a lengthy steam phase
(standing time after wash cycle
ends).
▶
Use a programme with a lower tem-
perature.
▶
Set the softening system to the wa-
ter hardness.
▶
Use detergent with a glass protec-
tion component.
Rust spots on cutlery. Cutlery is not sufficiently
rust-resistant. Knife blades
are often more severely af-
fected.
▶
Use rust-resistant tableware.
Cutlery may also rust if
washed together with rust-
ing items.
▶
Do not wash rusting items.
Salt content in washing wa-
ter is too high.
1. Remove any spilled special salt
from the tub.
2. Screw the cap of the special salt
dispenser on tight.
Detergent residue is present
in the detergent dispenser
or the tablet collecting tray.
Spray arms were blocked by
tableware so detergent was
not rinsed out.
▶
Check that the spray arms are not
blocked and can rotate freely.
Detergent dispenser was
damp when detergent was
added.
▶
Only add detergent to a detergent
dispenser when dry.
Excessive formation of foam
occurs.
Hand washing-up liquid is
present in dispenser for
rinse aid.
▶
Immediately add rinse aid to the
dispenser.
→"Adding rinse aid", Page24
Rinse aid has been spilled.
▶
Remove the rinse aid with a cloth.
Detergent or appliance care
product used causes excess-
ive foaming.
▶
Change the brand of detergent.
Troubleshooting en
43
Information on display panel
Fault Cause Troubleshooting
Special salt refill indicator
lights up.
Insufficient special salt.
▶
Add "Special salt" →Page22.
Sensor does not detect spe-
cial salt tablets.
▶
Do not use special salt tablets.
Refill indicator for special
salt does not light up.
Water softening system is
switched off.
▶
"Setting the water softening sys-
tem" →Page21
Refill indicator for rinse aid
lights up.
Insufficient rinse aid. 1. Add "Rinse aid" →Page24.
2. Set the amount of rinse aid to be
dispensed.
Refill indicator for rinse aid
does not light up.
Rinse aid system is switched
off.
▶
Set the amount of rinse aid to be
dispensed.
→"Setting the amount of rinse aid",
Page24
→"Setting the amount of rinse aid",
Page24
Malfunctions
Fault Cause Troubleshooting
Water is left in the appliance
at the end of the pro-
gramme.
Filter system or area under
the filters is blocked.
1. Clean the "Filters" →Page32.
2. Clean the "Wastewater pump"
→Page46.
Programme has not yet
ended.
▶
Wait until the programme ends or
cancel the programme with Reset.
▶
→"Terminate programme",
Page30
Appliance cannot be
switched on or operated.
Appliance functions have
failed.
1. Pull out the mains plug or switch off
the fuse.
2. Wait at least 2minutes.
3. Connect the appliance to the power
supply.
4. Switch the appliance on.
Appliance does not start. The mains fuse has tripped.
▶
Check the relevant fuse.
Mains cable is not inserted. 1. Check whether the socket works.
2. Check whether the mains cable is
properly inserted in the socket and
on the rear of the appliance.
Appliance door is not closed
properly.
▶
Close the appliance door.
en Troubleshooting
44
Fault Cause Troubleshooting
Programme starts automat-
ically.
You did not wait until pro-
gramme ended.
▶
→"Terminate programme",
Page30
Appliance stops during the
programme or cuts out.
Appliance door is not closed
properly.
▶
Close the appliance door.
Power and/or water supply
has been interrupted.
1. Check the power supply.
2. Check the water supply.
Top basket is pressing
against inner door and pre-
venting appliance door from
being closed securely.
▶
Check whether the rear panel of the
appliance is being pressed in by a
socket or hose holder that has not
been removed.
▶
Arrange the tableware so that no
parts project beyond the basket
and prevent the appliance door
from closing properly.
Basic settings cannot be
changed.
A programme is currently
running. Changing basic set-
tings is only possible at the
start of a programme.
Mechanical damage
Fault Cause Troubleshooting
Appliance door cannot be
closed.
Door lock has been activ-
ated.
▶
Close the appliance door with
greater force.
Door cannot be closed due
to installation method.
▶
Check whether the appliance has
been installed properly.
When closed, the appliance door,
its decor or attached parts should
not knock against adjacent cabin-
ets or the worktop.
Lid on the detergent dis-
penser cannot be closed.
Detergent dispenser or lid
are blocked by sticky deter-
gent residue.
▶
Remove detergent residue.
Noise
Fault Cause Troubleshooting
Filling valves making knock-
ing noises.
Caused by the domestic in-
stallation. No appliance fault
present. Does not affect
functioning of the appliance.
▶
Can only be remedied in the do-
mestic installation.
Troubleshooting en
45
Fault Cause Troubleshooting
Knocking or rattling noise. Spray arm is striking table-
ware.
▶
Arrange tableware so that the spray
arms do not strike tableware.
With a small load the water
jets directly strike against
the tub.
▶
Distribute the tableware evenly.
▶
Load the appliance with more table-
ware.
Light items of tableware
move about during the wash
cycle.
▶
Position light items of tableware se-
curely.
en Transportation, storage and disposal
46
Clean wastewater pump
Large remnants of food or foreign
bodies can block the waste water
pump. As soon as the rinsing water
no longer drains properly, the waste
water pump must be cleaned.
WARNING
Risk of injury!
Sharp and pointed objects or frag-
ments of glass may block the waste
water pump and cause injury.
▶
Remove any foreign bodies care-
fully.
1. Disconnect the appliance from the
power supply.
2. Remove the basket.
3. Remove the filter system.
4. Scoop out any water.
Use a sponge if necessary.
5. Loosen the screws on the pump
cover (Torx T 20).
6. Pull up and remove the pump
cover.
7. Remove any remnants of food and
foreign bodies in the interior.
8. Insert the pump cover, press down
and screw firmly in place.
9. Install the filter system.
10.Insert the basket.
Transportation, storage and disposal
Transportation, storage
and disposal
Transportation, storage and disposal
You can find out here how to prepare
your appliance for transportation and
storage. You will also find out how to
dispose of old appliances.
Removing the appliance
1. Disconnect the appliance from the
mains power supply.
2. Turn off the water tap.
3. Detach the drainage connection.
4. Detach the drinking water connec-
tion.
5. Pull the appliance out carefully,
along with the hose behind it.
Customer Service en
47
Protect appliance from frost
If there is a risk of frost where the ap-
pliance will be standing, e.g. in a holi-
day home, empty the appliance com-
pletely.
▶
Empty the appliance.
→"Transporting the appliance",
Page47
Transporting the appliance
To avoid damage to the appliance,
empty it before transporting.
Note:Always transport the dish-
washer upright to prevent residual
water getting into the machine's con-
trols and damaging the appliance.
1. Remove tableware from the appli-
ance.
2. Secure loose parts.
3. Turn on the water tap.
4. "Switch on the appliance."
→Page29
5. Select the programme with the
highest temperature.
6.
"Start the programme." →Page30
7. To drain the appliance, terminate
the programme after approx.
4minutes.
→"Terminate programme",
Page30
8. "Switch off the appliance."
→Page30
9. Turn off the water tap.
10.To empty the residual water out of
the appliance, detach the supply
hose and let the water drain out.
Disposing of old appliance
Valuable raw materials can be re-
used by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
▶
With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair
so that the appliance door will no
longer close.
1. Unplug the appliance from the
mains.
2. Cut through the power cord.
3. Dispose of the appliance in an en-
vironmentally friendly manner.
Information about current disposal
methods are available from your
specialist dealer or local authority.
This appliance is labelled in ac-
cordance with European Direct-
ive 2012/19/EU concerning
used electrical and electronic
appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the
framework for the return and re-
cycling of used appliances as
applicable throughout the EU.
Customer Service
Customer Service
Customer Service
If you have any queries, are unable to
rectify faults on the appliance your-
self or if your appliance needs to be
repaired, contact Customer Service.
Function-relevant genuine spare parts
according to the corresponding Eco-
design Order can be obtained from
Customer Service for a period of at
en Technical specifications
48
least 10 years from the date on
which your appliance was placed on
the market within the European Eco-
nomic Area.
Note:Under the terms of the manu-
facturer's warranty the use of Cus-
tomer Service is free of charge.
Detailed information on the warranty
period and terms of warranty in your
country is available from our after-
sales service, your retailer or on our
website.
If you contact Customer Service, you
will require the product number (E-
Nr.) and the production number (FD)
of your appliance.
The contact details for Customer Ser-
vice can be found in the enclosed
Customer Service directory or on our
website.
Product number (E-Nr.) and
production number (FD)
You can find the product number (E-
Nr.) and the production number (FD)
on the appliance's rating plate.
The rating plate is located inside the
appliance door.
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.
Technical specifications
Technical specifications
Technical specifications
Weight Max.: 24kg
Voltage 220 - 240V, 50Hz or
60Hz
Power rating 2000 - 2400W
Fuse 10 - 16A
Water pressure ¡ Min. 0.05MPa
(0.5bar)
¡ Max. 1MPa
(10bar)
Inlet rate Min. 10l/min
Water temperature Cold water: 25°C
Capacity 6place settings
You can find more information about
your model online at
https://eprel.ec.europa.eu/
1
. This web
address is linked to the official EU
EPREL product database. Please
then follow the instructions on
searching for the model. The model
identifier is made up of the charac-
ters before the slash in the product
number (E-Nr.) on the rating plate. Al-
ternatively, you can also find the
model identifier in the first line of the
EU energy label.
1
Only applies to countries in the European Economic Area
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service direct-
ory.
*9001483273*
9001483273 (011012) 550 EA
en
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
