Dishwasher
User manual
LDV02284
Dishwasher
User manual
LDV02284
Explanation of symbols
Throughout this User Manual the following symbols are used:
C
Important information or
useful hints about usage.
A
Warning for hazardous
situations with regard to life
and property.
B
Warning for electric shock.
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations.
Do not dispose of the packaging materials together with the domeic or other
waes. Take them to the packaging material collection points designated by the
local authorities.
Dear Cuomer,
We hope that you get the be results from your product which has been
manufactured with high quality and ate-of-the-art technology. Therefore,
please read this entire user manual and all other accompanying documents
carefully before using the product and keep it as a reference for future use. If
you handover the product to someone else, give the user manual as well. Follow
all warnings and information in the user manual.
Remember that this user manual is also applicable for several other models.
Dierences between models will be identied in the manual.
CONTENTS
1 INSTRUCTIONS
FOR SAFETY AND
ENVIRONMENT 4
General safety ...........................................4
Intended use .............................................. 5
Children’s safety ........................................5
Disposing of packaging material................5
Transportation of the product ....................5
Compliance with WEEE Directive and
Disposing of the Wae Product ................6
Compliance with RoHS Directive...............6
Package information .................................. 6
2 DISHWASHER 7
Overview....................................................7
Fan drying syem .....................................8
Technical specications .............................8
3 INSTALLATION 9
Appropriate inallation location ................. 9
Connecting water supply ...........................9
aquAvoid™ plus .....................................10
Connection to the drain ...........................10
Adjuing the feet .....................................10
Electrical connection................................11
This appliance mu be earthed ..............11
Fitting a dierent plug ..............................12
Initial use .................................................12
4 PREPARATION 13
Tips for energy saving .............................13
Water softening syem ...........................13
Adjuing the water softening syem ......13
Adding salt ............................................... 15
Detergent ................................................. 16
Tablet detergents .....................................17
Rinse aid..................................................18
Items not suitable for washing in the
dishwasher ..............................................18
Placing the dishes into the dishwasher ...19
Adjuing the height of the upper basket .21
Upper basket rack ...................................22
Ceiling cutlery basket ..............................22
Collapsible upper basket wires ................ 22
Collapsible lower basket tines .................23
Cutlery basket .........................................23
5 OPERATING THE
PRODUCT 24
Keys.........................................................25
Function keys ..........................................25
Preparing the machine ............................25
Programme selection...............................25
Auxiliary functions....................................27
Scheduling the washing time ................... 28
Starting the programme ........................... 29
Cancelling the programme ......................29
Adjuing the amount of rinse aid ............30
Salt indicator (
) ...................................30
Rinse Aid indicator ( ) ...........................30
End of programme ................................... 30
Water cut-o warning ...............................31
Overowing warning ................................31
ProCare ...................................................31
6 MAINTENANCE AND
CLEANING 32
Cleaning the outer surface of the product 32
Cleaning the interior of the machine ........ 32
Cleaning the lters ................................... 32
Cleaning the hose lter ............................33
Cleaning the impellers .............................34
Lower impeller .........................................34
Upper impeller ........................................34
7 TROUBLESHOOTING 35
8 GUARANTEE 40
Guarantee Details....................................40
4
Dishwasher / User manual
/44 EN
1
This section contains safety
inructions that will help to
give protection from risk of
personal injury or property
damage. Failure to follow
these inructions shall void all
warranties.
• Never place the product
on a carpet-covered oor;
otherwise, lack of airow
beneath the product will
cause electrical parts
to overheat. This will
cause problems with your
product.
• Do not operate the product
if the power cable / plug
is damaged! Call the
Authorised Service Agent.
• Connect the product to a
grounded outlet protected
by a fuse complying with
the values in the “Technical
specications” table. Do
not neglect to have the
grounding inallation
made by a qualied
electrician. Our company
shall not be liable for any
damages that will arise
when the product is used
without grounding in
accordance with the local
regulations.
• The water supply and
draining hoses mu be
securely faened and
remain undamaged.
• Unplug the product when
not in use.
• Never wash the product by
spreading or pouring water
onto it! There is the risk of
electric shock!
• Never touch the plug with
wet hands! Never unplug
by pulling on the cable,
always pull out by grabbing
the plug.
• The product mu
be unplugged during
inallation, maintenance,
cleaning and repairing
procedures.
• Always have the repair
procedures carried out by
the Authorised Service
Agent. Manufacturer
shall not be held liable for
damages that may arise
from procedures carried
out by unauthorised
persons.
• Never use chemical
solvents in the product.
They bring forth the risk of
explosion.
• When you pull the upper
and lower baskets out
completely, the door of
the product will bear all
the weight of the baskets.
Do not put other loads on
the door; otherwise, the
product may tilt.
• Never leave the door of
the product open apart
from loading and unloading
procedures.
• Do not to open the door
of the product when it is
running unless necessary.
Be careful for the rush of
hot eam when you need
to open the door.
Dishwasher / User manual
5 / 44
EN
Inructions for safety and envIronment
Intended use
• This product has been
designed for domeic use.
• It mu be used to do the
domeic type dishes only.
• This appliance is intended
to be used in household
and similar applications
such as:
- Sta kitchen areas in shops,
oces and other working
environments.
• Only dishwasher safe
detergents, rinse aids and
additives mu be used.
• The manufacturer waives
any responsibility arisen
from incorrect usage or
transportation.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical,sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
inruction concerning use
of the appliance in a safe
way and underand the
hazards involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall
not be made by children
without supervision.
• Electrical products are
dangerous for the children.
Keep children away from
the product when it is in
use. Do not let them to
tamper with the product.
• Do not forget to close the
door of the product when
leaving the room where it
is located.
• Store all detergents and
additives in a safe place
away from the reach of the
children.
Packaging materials are
dangerous to children. Keep
packaging materials in a safe
place away from reach of the
children.
Packaging materials of the
product are manufactured
from recyclable materials.
Dispose of them properly
and sort in accordance with
recycled wae inructions.
Do not dispose of them with
normal domeic wae.
A
If you need to move
the product, do it
in upright position
and hold from the
rear side. Tilting the
product onto its front
side may cause the
electronic parts in it
get wet and damaged.
6
Dishwasher / User manual
/44 EN
Inructions for safety and envIronment
1. Unplug the product before
transporting it.
2. Remove water drainage
and water supply
connections.
3. Drain the remaining water
in the product completely.
This product complies
with EU WEEE Directive
(2012/19/EU). This
product bears a
classication symbol for wae
electrical and electronic
equipment (WEEE).This
product has been
manufactured with high quality
parts and materials which can
be reused and are suitable for
recycling. Do not dispose of
the wae product with normal
domeic and other waes at
the end of its service life. Take
it to the collection center for
the recycling of electrical and
electronic equipment. Please
consult your local authorities to
learn about these collection
centers.
The product you have
purchased complies with EU
RoHS Directive (2011/65/EU).
It does not contain harmful and
prohibited materials specied
in the Directive.
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domeic or other waes.
Take them to the packaging
material collection points
designated by the local
authorities.
Dishwasher / User manual
7 / 44
EN
Dishwasher
2
15
1. Upper basket
2. Upper impeller
3. Lower impeller
4. Silverware basket
5. Door
6. Rating Label
7. Control panel
8. Detergent dispenser
9. Lower basket
10. Filters
11. Salt reservoir lid
12. Upper basket rail
13. Upper cutlery basket (depends on model)
14. Tabletop (depends on model)
15. Fan drying syem (depends on model)
8
Dishwasher / User manual
/44 EN
Dishwasher
This product complies with the following EU directives;
Development, production and sales ages of this product comply with the
safety rules included in all pertaining European Community regulations.
2014/35/EU, 2014/30/EU, 93/68/EC, IEC 60436/DIN 44990, EN 50242
Power input 220-240 V, 50 Hz (see rating label)
Total power consumption 1800-2100 W (see rating label)
Heater power consumption 1800 W (see rating label)
Total current (depends on the model) 10 A (see rating label)
Drain pump power consumption 30 W (see rating label)
Water pressure 0.3 –10 bar (= 3 – 100 N/cm² = 0.01-1.0
Mpa)
C
Technical specications may be changed without prior notice to improve
the quality of the product.
C
Figures in this manual are schematic and may not match the product
exactly.
C
Values ated on the markings of the product or in the printed documents
accompanying the product are obtained in the laboratory on basis of
the relevant andards. Depending on operational and environmental
conditions of the product, these values may vary.
Data required for performance tes shall be provided upon reque. Reques can
be e-mailed to the following address:
Do not forget to provide the code, ock and serial numbers of the product to be
teed in your reque e-mail along with your contact information. Code, ock and
serial numbers of the product may be found on the type label attached to the side
wall of the door.
(depends on model)
Fan drying syem ensures ecient drying of your dishes.
It is normal to hear a dierent sound than that of washing cycle during fan
operation.
Dishwasher / User manual
9 / 44
EN
3
To make the product ready for use,
make sure that the electricity, tap
water supply and water drainage
syems are appropriate before calling
the Authorised Service Agent. If they
are not, call a qualied technician
and plumber to have any necessary
arrangements carried out.
C
Preparation of the location
and electrical, tap water and
wae water inallations
at the place of inallation
is under cuomer's
responsibility.
B
Manufacturer shall not
be held responsible for
damages arising from
processes carried out by
unauthorised persons.
A
Prior to inallation, visually
check if the product has any
defects on it. If so, do not
have it inalled. Damaged
products cause risks for your
safety.
C
Make sure that the water
inlet and discharge hoses
are not folded, pinched or
crushed while pushing the
product into its place after
inallation or cleaning
procedures.
When placing the product, pay attention
not to damage the oor, walls, piping,
etc. Do not hold the product from its
door or panel to move it.
• Place the product on a solid and
at oor that has sucient load
carrying capacity! The product
mu be inalled on a at surface
in order for the door to be closed
comfortably and securely.
• Do not inall the product at places
where temperature may fall below
0ºC.
• Place the product on a rigid oor.
Do not place it on a long pile rug or
similar surfaces.
B
Ensure the power cable does
not get trapped under the
product.
• Make sure that you select a
location that will allow you to load
and unload the dishes in a fa and
comfortable manner.
• Inall the product in a place close
to the tap and the drain. Select the
inallation location by considering
that it will not be changed after the
connections are made.
• Do not use old or used water inlet
hose on the new product. Use the
new water inlet hose supplied with
the product.
• Connect the water inlet hose
directly to the cold water tap.
Permitted water temperature up
to 25°C. Pressure coming from
the tap should be minimum 0.3
and maximum 10 bars. If the
water pressure exceeds 10 bars,
a pressure relief valve should be
inalled in between.
• Open the tap completely after
making the connections to check
for water leaks.
10
Dishwasher / User manual
/44 EN
Inallation
A
For your safety, close the
water inlet tap completely
after the washing programme
is over.
Water discharge hose can directly be
connected to the drain hole or sink’s
drainage. The length of this connection
mu be min. 50 cm and max. 100 cm
from the oor. A discharge hose longer
than 4 meters will cause washing
performance to be aected.Attach the
water discharge hose to the drainpipe
without bending it. Tightly x the water
discharge hose to the drainpipe in order
to prevent any dislocation of the water
discharge hose during operation of the
product.
min
300
min
120
max 1000
min 500
(depends on model)
The aquAvoid™ plus syem protects
again water leaks that may occur
at the hose inlet.Water contact with
the valve box of the syem mu be
avoided to prevent damage to the
electrical syem. If the aquAvoid™ plus
syem is damaged, unplug the product
and call the Authorised Service Agent.
A
As the hose set contains
electrical connections and
assemblies, never shorten
or lengthen the hose with
extension hoses.
If the door of the product cannot
be closed properly or if the product
wobbles when you push it slightly,
then you need to adju the feet of the
product. Adju the feet of the product
as illurated in the relevant section.
A
Diswashers door mu be
aligned properly otherwise
hot eam can escape!
Danger of serious burns,
other injury or may damage
furniture.
C
Drainpipe mu be connected
to the foul water syem and
it should not be connected to
any surface water drain.
Dishwasher / User manual
11 / 44
EN
Inallation
A
be earthed
If the tted moulded plug is
not suitable for your socket,
then the plug should be cut
o and an appropriate plug
tted.
Deroy the old plug, which
is cut o as a plug with a
bared cord could cause a
shock hazard if inserted into
a socket elsewhere in the
house.
The moulded plug on this
appliance incorporates a
13A fuse. Should the fuse
need to be replaced an ASTA
approved BS1362 fuse of
the same rating mu be
used. Do not forget to ret
the fuse cover. In the event
of losing the fuse cover, the
plug mu not be used until
a replacement fuse cover
has been tted. Colour of
the replacement fuse cover
mu be the same colour as
that visible on the pin face
of the plug. Fuse covers
are available from any good
electrical ore.
Before you insert the plug into the wall
socket make sure that the voltage and
the frequency shown in the rating label
corresponds to your electricity supply.
We recommend that this appliance be
connected to the mains supply via a
suitable switched and fused socket in a
readily accessible position.
If the supply cord or the mains lead
is damaged please do not replace it
yourself. The supply cord or the mains
lead mu be replaced by a Authorised
Service Agent or a similarly qualied
person.
12
Dishwasher / User manual
/44 EN
Inallation
As the colours of the wires in the
mains lead of this appliance may not
correspond with the coloured markings
identifying the terminals on your plug,
proceed as follows:
1. Connect the green - yellow or
green (earth) wire to the terminal
in the plug marked ‘E’ or with the
symbol
or coloured green
and yellow or green.
2. Connect the blue (neutral) wire to
the terminal in the plug marked ‘N’
or coloured black.
3. Connect the brown (live) wire to the
terminal in the plug marked ‘L’ or
coloured red.
With the alternative plugs a 13A fuse
mu be tted either in the plug or
adaptor or in the main fuse box. If in
doubt contact a qualied electrician.
Before arting to use the product, make
sure that all preparations are made
in accordance with the inructions in
sections “Important safety inructions”
and “Inallation”.
• Before using the product, ll the
salt reservoir with 1 litre of water,
add salt (see next page) and ir
to dissolve. Run the Dishwasher
without dishes on a short
programme with a small amount of
detergent.
A
There might be a small
amount of water left in the
product after factory quality
control tes. This causes no
harm to the product.
Dishwasher / User manual
13 / 44
EN
4
Following information will help you use
the product in an ecological and energy-
ecient manner.
Wipe away any coarse food remnants
on the dishes before putting them in the
product.
Operate the product after lling it
completely.
When selecting a programme, consider
the table of "Programme data and
average consumption values".
Do not put more detergent than
suggeed on the detergent package.
The product is equipped with a water
softening syem which reduces the
hardness of incoming water. This
syem softens the supply water to a
level that will allow washing the dishes
with the required quality.
C
The mains water hardness
mu be softened if it is
over 7°dH. Otherwise,
hardness ions will accumulate
on the dishes that are
washed and may aect the
washing, rinsing and drying
performances of the machine.
Cleaning, rinsing and drying
performance of your dishwasher will
increase when water softening syem
is adjued properly.
Adju the new water hardness level
according to the Water hardness level
inruction in this booklet.
Use the te rip supplied with the
product according to the eps given
below to determine hardness level of
your supply water.
14
Dishwasher / User manual
/44 EN
Inallation
Remove the test
strip from the
packet.
Turn on the tap and
let the water run for
about a minute.
Hold the test strip in
the water for about
a second.
Remove the test
strip from the water
and shake it.
Wait for 1 minute. The test strip shows
you the hardness
level.
After determining hardness level of the supply water:
1. Turn on the machine, press Time Delay and P+/P keys simultaneously. After the
countdown (3,2,1) is displayed keep the keys pressed for a while.
2. Press P+/P key to activate the (r..) position.
3. Using Time Delay key, adju water hardness level according to the hardness of
the supply water. See “Water hardness level adjument table” for correct setting.
4. Press On / O key to save the setting.
Hardness
Level
English Water
Hardness °dE
German Water
Hardness °dH
French Water
Hardness °dF
Water Hardness Level Indicator
0th Level
0-5 0-4 0-8
Press the Time Delay key to switch the water hardness level
to position 1. (r1)
1st Level
6-9 5-7 9-13
2nd Level
10-15 8-12 14-22
Press the Time Delay key to switch the water hardness level
to position 2. (r2)
3rd Level
16-19 13-15 23-27
Press the Time Delay key to switch the water hardness level
to position 3. (r3)
4th Level
20-24 16-19 28-34
Press the Time Delay key to switch the water hardness level
to position 4. (r4)
5th Level
25-62 20-50 35-90
Press the Time Delay key to switch the water hardness level
to position 5. (r5)
If the hardness level of the supply water is above 90 °dF or if you are using well
water, then it is recommended to use water purication devices and special lters.
If the hardness level of the supply water is below 13°dF, there is no need to use salt
in your dishwasher. If this is the case, “No Salt Warning Indicator” (if any) illuminates
continuously on the panel of your machine.
If the water hardness level adjument is set to level 1, the “No salt warning
indicator” will illuminate continuously although it is not necessary to use salt. If you
use salt under this condition, salt will not be consumed and the Salt indicator will not
illuminate.
Dishwasher / User manual
15 / 44
EN
Preparation
C
If you move your house,
it is necessary to readju
water hardness level of your
machine by considering the
information given above
according to the hardness
level of the supply water
in your new location. Your
machine will display the
mo recently adjued water
hardness level.
Water softening syem needs to be
regenerated in order for the product
operates with the same performance
continuously. Dishwasher salt is used
for this purpose.
C
Use only special softening
salts produced particularly
for the dishwashers in your
machine.
C
It is recommended to
use granule- or powder-
formed softening salts in
the water softening syem.
Do not use salts that do
not completely dissolve in
water such as table salt or
rock salt. Otherwise the
performance of the syem
may deteriorate in time.
C
Salt reservoir will be lled
with water when you art
the product. For this reason,
add salt before operating the
machine.
1. Firstly, take the lower basket out to
add softening salt.
2. Turn the salt reservoir lid counter-
clockwise to open it (A).
3. Add 1 litre of water to salt reservoir
of your machine only in initial use.
4. Fill the salt reservoir with salt by
using the salt funnel (D). To speed
up dissolution rate of salt in water,
stir it with a spoon.
C
You can put about 2 kg of
softening salt into the salt
reservoir.
5. Replace the lid and tighten it when
the reservoir is full.
C
You need to add salt right
before arting the machine.
Thus, the overowing
salty water will be ushed
immediately, preventing the
risk of corrosion in machine.
In cases where you would not
art washing immediately,
run your machine empty in
the shorte program.
16
Dishwasher / User manual
/44 EN
Preparation
1. Push the latch to right to open the
detergent dispenser lid (A).
2. Put suggested amount of powder,
liquid/gel or tablet detergent in the
reservoir.
C
Inside the detergent
dispenser there are level
markings that help you
use appropriate amount of
powder detergent. When
brimful, detergent dispenser
will contain 45 cm³ of
detergent. Fill detergent up to
15 cm³ or 25 cm³ level marks
in the detergent dispenser
according to fullness of
the machine and/or soiling
degree of the dishes. One
tablet is enough if you are
using detergent tablets.
3. Push the lid of the detergent
dispenser to close it. A "click" will be
heard when the lid is closed.
C
Since dierent salt brands
in the market have dierent
particle sizes and since the
water hardness may vary,
dissolution of the salt in water
may take a couple of hours.
Therefore, Salt Indicator
remains on for a while after
adding salt into the machine.
You can use powder, liquid/gel or tablet
detergents in the machine.
A
Only use in the machine
the detergents produced
particularly for use
with dishwashers. We
recommend you not use
detergents that contain
chlorine and phosphate
as they are harmful for the
environment.
C
Pay attention to the warnings
on the detergent packaging
to get better washing and
drying results. Contact the
manufacturer of the detergent
for further queions.
A
Do not put solvents into the
detergent dispenser. There is
the risk of explosion!
Put the detergent into the detergent
dispenser ju before operating the
machine as illurated below.
Dishwasher / User manual
17 / 44
EN
Preparation
C
The be washing
performance in dishwashers
is obtained by using
detergent, rinse aid and water
softening salt individually.
C
Observe the inructions of
the detergent manufacturer
on the package when using
tablet detergents.
C
Contact the detergent
manufacturer if your dishes
are wet and/or if you notice
limescale spots particularly
on your glasses after the
washing programme is
over when using a tablet
detergent.
1. Make sure that salt and rinse aid
reservoirs are full.
2. Set the water hardness to the
highest level and perform an empty
run.
3. After the empty washing cycle,
review the user manual and
readjust the water hardness level so
as to suit the water supply.
4. Make the appropriate rinse aid
settings.
1
2
3
C
Use powder or liquid/
gel detergent in short
programmes without
prewash since the solubility
of the tablet detergent
changes depending on the
temperature and time.
In addition to the conventional tablet
detergents, there are also commercially
available detergent tablets that show
water softening salt and/or rinse aid
eect. Some types of these detergents
contain special-purpose components
such as glass and ainless eel
protectors. These tablets show their
eects up to a certain water hardness
level (21°dH). Water softening salt and
rinse aid mu also be used together
with the detergent if the water hardness
level is above the mentioned level.
18
Dishwasher / User manual
/44 EN
Preparation
4. If there are stains on tableware
items after washing, level must be
increased and if there is a blue trace
after wiping them by hand, it must
be decreased. This is set to position
3 as factory default.
C
The rinse aid adjument is
described under "Adjuing
the amount of rinse aid" in
the section for operating the
machine.
C
Wipe clean any spilled
rinse aid outside the
reservoir. Rinse aid that
spilled accidentally will
cause foaming and it will
eventually decrease washing
performance.
• Never wash dishes soiled by
cigarette ash, candle remnants,
polish, dyeu, chemicals, etc. in
your dishwasher.
• Do not wash silverware and cutlery
with wooden or bone ems, glued
pieces, or pieces that are not
resiant to heat, as well as copper
and tin-plated containers in the
dishwasher.
C
The rinse aid used in
dishwashers is a special
combination that aims to
increase drying eciency and
prevent water or lime ains
on the washed items. For this
reason, care mu be paid
to have rinse aid in the rinse
aid reservoir and to use rinse
aids produced specially for
dishwashers only.
1. Open the lid of the rinse aid
reservoir with the help of the latch.
2. Fill the reservoir until “MAX” level.
3. Slightly press the point (B) of the
reservoir lid to close it.
Dishwasher / User manual
19 / 44
EN
Preparation
C
Decorative prints of
chinaware as well as
aluminium and silver items
may get discoloured or
tarnished after washing in
the dishwasher ju as it
happens in handwashing as
well. Some delicate glass
types and cryals may
become dull in time. We
rongly recommend you
to check if the tableware
you are going to purchase
is suitable for washing
especially in the dishwasher.
You can use your dishwasher in the
optimum way with respect to energy
consumption and washing and drying
performance only if you place the
dishes in an orderly way.
• Wipe away any coarse food
remnants (bones, seeds, etc.) on
the dishes before placing them in
the dishwasher.
• Place thin, narrow pieces in the
middle sections of baskets if
possible.
• Place the heavily soiled and bigger
items in the lower basket and
smaller, delicate and light items in
the upper basket.
• Place the hollowed dishes such as
bowls, glasses and pans upside
down in the dishwasher. Thus,
accumulation of water in deep
hollows is prevented.
A
To prevent possible injuries,
always place the sharp and
pointed dishes such as
service fork, bread knife,
etc. upside down so as their
pointed ends will face down
or they will lie horizontally in
the dish basket.
Unload dishes in the lower basket r
and then the dishes in the upper basket.
20
Dishwasher / User manual
/44 EN
Preparation
Suggestions for loading the dishwasher
Lower basket
Upper basket
Improper Loading Of Dishware
Dishwasher / User manual
21 / 44
EN
Preparation
(depends on model)
The upper basket height adjument
mechanism has been designed for
you to create large spaces in the lower
or upper sections of your machine
depending on your needs by adjuing
the height in the upper or lower direction
while your basket is empty or loaded.
Thanks to this mechanism, you can use
your basket in three dierent positions,
namely lower, middle and upper
positions (1, 2, 3).
1. To raise your basket, hold the upper
basket wires with both hands while
the basket is in the lowermost
position and pull them up (A).
2. You will hear a "Click" from the right
and left mechanisms, indicating that
the basket has reached the next
level. Release the basket.
Repeat the process if the height is not
sucient.
1
2
3
To lower the basket, while it is in the
uppermo position;
1. Hold the upper basket wires with
both hands, slightly lift up the basket
and simultaneously push and
release the latches shown in the
figure (B).
2. Lower the basket from its current
position to the lower one.
3. Release the basket after it has
reached one level down.
Repeat the process if the height is not
sucient.
C
The movement mechanism
may not function properly
if the upper basket is
overloaded or if the weight
diribution is not balanced.
In heavier conditions, there
is the risk of falling one level
down.
C
Make sure that the
adjument mechanism has
the same positions on the
right and left sides of the
upper basket.
22
Dishwasher / User manual
/44 EN
Preparation
(depends on model)
You can use collapsible wires when you
need a larger space for your dishes in
the upper basket of your machine.
To bring the collapsible wires into
horizontal position, grab the wire from
the middle position and push them
in the direction of arrow in the gure.
Place your larger dishes into the area
created. To bring the wires back to
vertical position, ju lift them up.
(depends on model)
(depends on model)
Ceiling cutlery basket is designed
to wash your cutlery items such as
forks, spoons and etc. by placing them
between the bars on the basket.
C
Bringing the wires to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore,
hold the wires from their
ems while bringing them
to the horizontal or vertical
positions.
Dishwasher / User manual
23 / 44
EN
Preparation
(depends on model)
Foldable tines (A) located at the lower
basket of the machine are designed
for an easier placement of large pieces
such as pans, bowls, etc. You can
create larger spaces by folding each
tines individually or all of them at once.
To bring the collapsible tines into
horizontal position, grab the tines from
mid position and push them in the
directions of arrows (B). To bring the
tines back to vertical position, ju lift
them up. Collapsible tines will click into
the latch again (C).
C
Bringing the tines to the
horizontal position by holding
them from the tips may cause
them to bend. Therefore, it
will be appropriate to bring
the tines in the middle to
horizontal or vertical position
by holding them from their
ems and pushing in the
direction of arrow.
(depends on model)
Cutlery basket is designed to wash your
dishes such as knife, fork, spoon, etc. in
an ecient manner.
Since the cutlery basket can be moved
(A, B), you can create more space while
placing your dishes in the lower basket
and free up space for your dishes of
dierent sizes.
24
Dishwasher / User manual
/44 EN
5
1. On/Off key
2. Programme Selection / Programme Cancel (3 seconds) key
3. Function keys
F1
F2
F3
F4
4. Programme indicator
5. Salt indicator
6.
7. Start / Cancel indicator
8. Time Delay / Programme Time indicator
9. Time Delay key
10. Time Delay indicator
11. End of Programme indicator
12.
13. Rinse Aid indicator
1
10
2 4 5 6 7 8 3 9
111213
3
Not in use
Not in use
Half Load function
Rapid Clean Function
Extra Drying Function
PowerWash Function
Dishwasher / User manual
25 / 44
EN
Operating the product
When you press On / O key, indicator
lights illuminate on the display for ON
position. The lights turn o in OFF
position.
Press this key until the desired
programme appears in the programme
indicator.
To cancel the running programme open
the door of the product. Press and hold
the Programme Selection / Programme
Cancel keys for 3 seconds. After the
3 - 2 - 1 countdown, 0:01 is displayed,
close the door of the product and wait
for the draining process complete.
Draining is completed in 2 minutes and
the machine gives an audible warning
when it is completed.
If you press any of the Function keys
during programme selection or time
delay selection, an armative key
signal will be heard provided that the
relevant function is supported by the
selected programme. Function will be
deemed selected when the indicator of
the selected function is lit.
To cancel the selected function, keep
the function key pressed until the
function indicator disappears.
1. Open the door of the dishwasher.
2. Place the dishes in accordance with
the instructions in the user manual.
3. Make sure that the upper and lower
impellers rotate freely.
4. Put adequate amount of detergent
into the detergent dispenser.
1. Press the On/Off button to turn on
your machine.
2. Check the Salt and Rinse Aid
indicators and add salt and/or rinse
aid if needed.
3. Refer to the table of “Programme
data and average consumption
values” to determine a washing
programme suitable for your dishes.
4. Selected programme will start when
you close the door of your machine.
26
Dishwasher / User manual
/44 EN
Operating the product
012345678
ProClean Eco * Auto MixWash+ Intensive ExpressDry Glass Care Mini Prewash
-
50 ºC 45-65 ºC - 70 ºC 60 ºC 40 ºC 35 ºC -
This programme is
recommended to be
operated on every 1-
2
months for machine
cleaning and
necessary hygiene.
The programme
should be operated
while the machine is
empty.
In order to achieve
an efficient result
use together with
special machine
cleaning agents
Most economical
washing programme
for the medium
soiled daily dishes
that are kept waiting.
Determines the
soiling degree of the
dishes and sets the
temperature and
amount of the
washing water as
well as the washing
time automatically.
Suitable for all types
of dishes.
It is the most
suitable washing
programme for daily
mixed dishes
including plastic
items. While
delicate glass items
are washed in the
upper basket, pans
and trays can be
washed in the lower
basket.
Suitable for heavily
soiled dishes, pots
and pans.
Daily washing
programme for
normally soiled
dishes in the fastest
way.
Special programme
for gentle cleaning
of delicate
glassware.
Suitable for lightly
soiled daily dishes
that are scraped or
pre-cleaned.
Suitable for
removing the
remnants on the
soiled dishes that
will be kept waiting
in the machine for a
few days, and thus,
for preventing the
bad odour buildup.
- Medium Medium to high Medium High Medium Low Low -
-++++- +-+
-+++++++-
-++++++- -
75 239 92-173 206 164 58 120 30 15
14,4 8,7 12,6-17,0 16,4 15,2 10,6 12,6 10 3,4
0,70 0,73 0,90-1,20 1,30 1,25 1,12 0,93 0,74 -
Degree of Soiling
Energy (kWh)
Prewash
Wash
Dry
Duration (min)
Water (I)
Programme Table
The consumption values shown in the table were determined under standard conditions. Differences may therefore occur under practical conditions. * Reference programme for
testing institutes. The tests in accordance with EN 50242 must be carried out with a full water softener salt dispenser and a full rinse aid reservoir, and using the test programme.
Programme number
Programme name
Cleaning temperature
Sensitivity: Public
Dishwasher / User manual
27 / 44
EN
Operating the product
Washing programmes of your
dishwasher are designed to obtain the
be cleaning eect, considering the
type of the soiling, soiling degree and
properties of the dishes to be washed.
Auxiliary functions allow you save from
time, water and power.
C
Auxiliary functions may cause
changes in the programme
duration.
C
Auxiliary functions are not
suitable for all washing
programs. Indicator of the
auxiliary function that is
not compatible with the
programme will not be active.
It is used to operate the machine
without loading it completely.
1. Load your dishes in the machine as
you like.
2. Turn the machine on with On/Off
key.
3. Select the desired programme and
press the Half Load key.
While the function is enabled, the Half
Load indicator will become on in the
function selection indicator and on the
display.
4. Close the door of the machine to
start the programme.
C
With the Half Load function
you can save both water and
power while using the lower
and upper baskets of the
machine.
It shortens the time of the washing
cycle selected and decreases water
consumption by enabling washing
under higher pressure.
It provides superior drying performance.
PowerWash
impeller located
under the lower
impeller helps
washing your
heavily soiled
dishes places in the right side of the
lower basket. It will give better results to
place the mo soiled dish to the right
front side.
C
Do not try to remove the
PowerWash impeller!
Auto Tablet is a feature which detects
the use of combined tablet detergents
automatically.
C
Drying performance of
these type of detergents
is improved by adjuing
temperature and duration
accordingly.
Owing to this feature, there is no need
to press any button in case of a tablet
detergent use.
Feature can be activated if automatic
detection is desired.
1. After turning on the machine,
press Time Delay and P keys
simultaneously. Keep them pressed
until the countdown 3, 2, 1 is
completed on the display.
28
Dishwasher / User manual
/44 EN
Operating the product
(Depends on the model)
Some models have interior lighting to
illuminate the interior when the door is
opened.
1. After turning on the machine,
press Time Delay and P+ keys
simultaneously. Continue to press
until the countdown 3, 2, 1 is
completed on the display.
2. Press P+ key to activate the L:
option. The interior lighting is turned
off at "L:0" option and turned on at
"L:1" option. Set the desired option
with the Time Delay key.
3. Turn off the machine with On/Off
key to save the changes.
(depends on the model)
Your machine reects a light to the oor
during the washing process. This light
turns o after the washing process is
complete.
C
Floor illumination is activated
automatically when the
washing programme arts
and remains lit until the end
of the programme.
1. After switching your machine on,
press Time Delay and P / P+ keys
simultaneously. Keep them pressed
until the countdown 3, 2, 1 is
completed on the display.
2. Press P / P+ key to activate the S:
position on the display.
3. Each pressing on the Time Delay
key will change the warning sound
volume as "S:0" off, "S:1" medium
and "S:2" high.
4. Turn off the machine with the On/Off
key to save the changes.
C
Your machine is set to
“S:2” as factory default.
2. Press P key to activate the a:
option. Automatic detergent
detection feature is disabled at “a:0”
option and enabled at “a:1” option.
Set the desired option by pressing
the Time Delay key.
3. Turn off the machine with On/Off
key to save the changes.
C
Floor illumination cannot be
cancelled by the user.
If an economical electricity tari is
applied in your region, you can use
the Time Delay function to wash your
dishes during appropriate hours.
You can delay the art of the selected
programme until 24 hours.
1. Press the Time Delay function
key after selecting the washing
programme and other auxiliary
functions.
2. Once you press the Time Delay key,
Display Information Line will show
"0:30" and Time Delay indicator will
start flashing.
3. Set the desired time by pressing the
Time Delay key. Time will increase
with increments of 30 minutes up
to 6 hours and after that in 1 hour
Dishwasher / User manual
29 / 44
EN
Operating the product
C
Your machine performs water
softening depending on the
hardness level of the supply
water. Washing time can
change while the programme
is running depending on the
ambient temperature where
your machine is inalled,
temperature of the supply
water and amount of the
dishes.
C
Pay attention not to open the
door of the machine when
it is running. There may
be a rush of vapour when
you open the door of your
machine; be careful.
C
The machine will remain
silent in pause mode for
some time in order to remove
the water from the machine
and on the dishes completely
and to have the water
softener cleaned, and then it
will resume running in drying
mode.
Open the door of the product Press
and hold the Programme Selection /
Programme Cancel keys for 3 seconds.
After the 3 - 2 - 1 countdown, 0:01 is
displayed, close the door of the product
and wait for the draining process
complete. Draining is completed in
2 minutes and the machine gives an
audible warning when it is completed.
increments up to 24 hours every
time you press the key.
4. Close the door of your machine
after setting the Delayed Start.
Once the delay time is over, the
selected programme will start
automatically.
While the Time Delay function is
activated, you cannot make changes
in the washing programme, auxiliary
functions or the duration of delay time.
C
Programme and auxiliary
functions cannot be set/
changed after the programme
has arted.
Open the door of the product Press
and hold the Programme Selection /
Programme Cancel keys for 3 seconds.
After the 3 - 2 - 1 countdown, 0:01 is
displayed, close the door of the product
and wait for the draining process
complete. Draining is completed in
2 minutes and the machine gives an
audible warning when it is completed.
C
You can select and art a
new programme following the
cancellation of Time Delay
function.
C
Time Delay function cannot
be set after the programme
arts.
Close the door of your machine to art
it after selecting the programme and
auxiliary functions.
30
Dishwasher / User manual
/44 EN
Operating the product
C
There might be residues of
detergent or rinse aid in the
machine and/or on the pieces
being washed depending on
the ep the programme you
have cancelled was in.
)
Please check the salt indicator on
the display to see whether there is
adequate amount of softening salt in
the dishwasher or not. You need to rell
the salt reservoir with salt whenever salt
indicator appears on the display of your
machine.
C
Adjuing the water hardness
level is explained in Water
Softening Syem section.
)
Please check the rinse aid indicator
on the display to see whether there is
adequate amount of rinse aid in the
dishwasher or not. You need to rell
the rinse aid reservoir with rinse aid
whenever rinse aid indicator appears on
the display of your machine.
1. After turning on the machine,
press Time Delay and P+ keys
simultaneously. After the countdown
(3, 2, 1) is displayed keep the keys
pressed for a while.
2. Press P+ to move to position (P) on
the display.
3. Set to the appropriate level with the
Time Delay key.
4. Press On / Off key to save the
setting.
No rinse aid dispensed in P:0 wash
position.
1 dose of rinse aid is dispensed in P:1
position.
2 doses of rinse aid are dispensed in
P:2 position.
3 doses of rinse aid are dispensed in
P:3 position.
4 doses of rinse aid are dispensed in
P:4 position.
C
When the programme you
have selected comes to an
end, an audible warning
signal will warn you to turn o
your machine. This audible
signal will warn you with
certain intervals before it
turns o.
End of Programme indicator will light up
when the washing programme is over.
1. Open the door of the machine.
2. Press On/Off key to turn off your
machine.
3. Close the tap.
4. Unplug the machine from the
socket.
C
For energy saving, the
machine is automatically
turned o following the
completion of the programme
or if the programme is not
arted.
Dishwasher / User manual
31 / 44
EN
Operating the product
This programme is recommended
to be operated on each 1-2 months
for machine cleaning and necessary
hygiene. The programme should be
operated while the machine is empty.
In order to achieve an ecient result, it
is recommended to use together with
special machine cleaning agents.
C
Do not use this programme to
clean dishes. As it operates
in high temperatures, it is
harmful for the dishes.
C
Leave your dishes in the
machine for about 15
minutes to allow them cool
down after they are washed.
Your dishes will dry in a
shorter time if you leave
the door of your machine
ajar during this period. This
process will increase the
drying eectiveness of your
machine.
If mains water is cut or water inlet tap
is turned o the machine cannot take
water in and E:02 icon will ash on the
programme indicator. As long as the
problem continues, washing programme
is paused and the water inlet is checked
regularly by the machine; when
the water is reored E:02 icon will
disappear after a while and the washing
programme resumes.
If the machine intakes too much
water or there is leakage at any of the
components then the machine will
detect this and E:01 icon will ash on
the Programme indicator. As long as the
overowing continues safety algorithm
will be active and try to discharge the
water. If overowing ops and safety
is assured, E:01 icon will disappear.
If E:01 does not disappear, there is
a permanent fault. In this case the
authorised service should be contacted.
32
Dishwasher / User manual
/44 EN
6
Service life of the product extends and
frequently faced problems decrease if it
is cleaned at regular intervals.
A
Unplug the product and turn
o the tap before attempting
any cleaning procedures.
C
Do not use abrasive
subances for cleaning.
C
Clean the lter and impellers
at lea once a week in order
for the machine operates
eciently.
Wipe the outer surface and door
gaskets of the product gently with a mild
cleaning material and damp cloth. Wipe
the "Control panel" only with a slightly
damp cloth.
• Clean the interior of the machine
and the tank by running a
programme with or without
detergent based on the degree of
soil.
• If water has remained in the
machine, drain the water by
performing the procedures under
the topic "Canceling a programme".
If the water cannot be discharged,
remove the lters as specied in
the "Cleaning the lters" section
and check if there are any leftover
deposits that have accumulated at
the bottom of the machine, blocking
the water path. Clean if necessary.
Clean the lters at lea once a week
in order for the machine operates
eciently. Check if food residues are left
on the lters. If there are food residues
on lters, take them out and clean well
under running water.
1. Turn the micro filter (1) and coarse
filter (2) assembly counter clockwise
and pull it out from its seating.
2. Pull out the metal/plastic filter (3)
from the seating.
3. Press the two pawls on the coarse
filter inwards and separate the
coarse filter from the assembly.
Dishwasher / User manual
33 / 44
EN
Maintenance and cleaning
4. Clean all three filters under tap
water by means of a brush.
5. Place the metal/plastic filter.
6. Place the coarse filter into the micro
filter. Make sure that it is properly
seated. Turn the coarse filter
clockwise until a "click" sound is
heard.
C
Do not use the dishwasher
without lter.
C
Incorrect placement of the
lters will reduce washing
eciency.
Damages on the machine that may be
caused by impurities coming from the
urban supply water or your own water
inallation (such as sand, dirt, ru,
etc.) can be prevented by means of the
lter attached to the water inlet hose.
Check the lter and the hose regularly
and clean them if necessary.
1. Turn off the tap and remove the
hose.
2. After taking out the filter, clean it
under running tap water.
3. Place the cleaned filter back to its
seat in the hose.
4. Install the hose to tap.
(depends on model)
34
Dishwasher / User manual
/44 EN
Maintenance and cleaning
Clean the impellers at lea once a
week in order for the machine operates
eciently.
Check if the holes on the lower impeller
(1) are clogged. If they are clogged,
remove and clean the impeller. You can
pull the lower impeller up to remove it.
Check if the holes on the upper impeller
(1) are clogged. If they are clogged,
remove and clean the impeller. Turn its
nut to left to remove the upper impeller.
Make sure that the nut is tightened well
when inalling the upper impeller.
Dishwasher / User manual
35 / 44
EN
7
start.
• Power cable is unplugged. >>> Check if the power cable is plugged in.
• Fuse is blown. >>> Check the fuses in your house.
• Water is cut. >>> Make sure that the water inlet tap is open.
• Door of the machine is open. >>> Make sure that you have closed the door of
the machine.
• On / Off button is not pressed. >>> Make sure that you have turned on the
machine by pressing the On / Off button.
Dishes are washed
• Dishes are not placed orderly in the machine. >>> Load the dishes as described
in the user manual.
• Selected programme is unsuitable. >>> Select a programme with a higher
temperature and cycle time.
• Impellers are stuck. >>> Prior to starting the programme, turn the lower and
upper impellers by hand to make sure that they rotate freely.
• Impeller holes are clogged. >>> Lower and upper impeller holes might be
clogged with food remnants such as lemon pips. Clean the impellers regularly
as illustrated in section “Cleaning and Care”.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter
system regularly as illustrated in section “Cleaning and Care”.
• Filters are installed incorrectly. >>> Check the filter system and make sure that
it is installed correctly.
• Baskets are overloaded. >>> Do not overload the baskets in excess of their
capacity.
• Detergent is stored under unsuitable conditions. >>> If you are using powder
detergent, do not store the detergent package in humid places. Keep it in a
closed container if possible. For ease-of-storing, we recommend you to use
tablet detergents.
• Detergent is not sufficient. >>> If you are using powder detergent, adjust
the amount of detergent according to the soiling degree of your dishes and/
or programme definitions. We recommend you to use tablet detergents for
optimum results.
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid
in the machine.
• Detergent dispenser lid is left open. >>> Make sure that the detergent dispenser
lid is closed tightly after adding detergent.
36
Dishwasher / User manual
/44 EN
Troubleshooting
Dishes are at the end
• Dishes are not placed orderly in the machine. >>> Place your dishes in a way
that no water will accumulate in them.
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid
in the machine.
• Machine is unloaded right after the programme is over. >>> Do not unload your
machine right after washing process is completed. Slightly open the door and
wait for evacuation of the steam inside for a while. Unload the dishes after the
pieces cool down to a touchable level. Start unloading process from the lower
basket. Thus, dropping of water remained on a piece at upper basket onto the
pieces at lower basket is prevented.
• Selected programme is unsuitable. >>> Since rinsing temperature is low at
programmes with short duration, drying performance will also be low. Select
programmes with longer duration for a higher drying performance.
• Surface quality of the kitchen utensils is deteriorated. >>> Desired washing
performance can not be obtained on kitchen utensils with deteriorated surfaces
and it is not suitable to use such utensils in terms of hygiene as well. Also, water
can not flow easily on deteriorated surfaces. It is not recommended to wash
such kitchen utensils in dishwasher.
C
It is normal that drying complaints can be experienced with Teon
kitchen utensils. It is associated with the ructure of Teon. Since the
surface tensions of Teon and water are dierent, water droplets will
remain as beads on the Teon surface.
Tea, stains remain dishes.
• Selected programme is unsuitable. >>> Select a programme with a higher
temperature and cycle time.
• Surface quality of the kitchen utensils is deteriorated. >>> Tea and cafe
stains or other dye spots may not be cleaned in dishwasher when they have
penetrated in deteriorated surfaces. Desired washing performance can not be
obtained on kitchen utensils with deteriorated surfaces and it is not suitable to
use such utensils in terms of hygiene as well. It is not recommended to wash
such kitchen utensils in dishwasher.
• Detergent is stored under unsuitable conditions. >>> If you are using powder
detergent, do not store the detergent package in humid places. Keep it in a
closed container if possible. For ease-of-storing, we recommend you to use
tablet detergents.
Lime remain dishes and a
• Rinse aid is not sufficient. >>> Check the rinse aid indicator and add rinse aid if
necessary. Increase the rinse aid setting if there is enough amount of rinse aid
in the machine.
Dishwasher / User manual
37 / 44
EN
Troubleshooting
• Water hardness setting is low or salt level is insufficient >>> Measure the
hardness of the supply water appropriately and check the water hardness
setting.
• Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole
while adding salt. Make sure that the salt reservoir lid is tightly closed after
finishing the filling process. Run the prewash programme to remove the salt that
spilled inside the machine. Since the salt granules that will remain under the lid
will dissolve during prewash, causing the lid loosen, check the lid once again at
the end of the programme.
There is a in the
C
A new machine has a peculiar odour. It will fade out after a couple of
washes.
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter
system regularly as illustrated in section “Cleaning and Care”.
• Dirty dishes are kept in dishwasher for 2-3 days. >>> If you are not going
to start the machine right after you have put the dishes into it, remove the
remnants on the dishes and run the Prewash programme without detergent
every 2 days. In such cases, do not close the door of the machine completely
in order to avoid odour build up in machine. You can also use commercially
available odour removers or machine cleaners.
, dishes
• Salt leakage exists. >>> Salt may cause deterioration and oxidation on metal
surfaces. Pay attention not to spill salt around the salt filling hole while adding
salt. Make sure that the salt reservoir lid is tightly closed after finishing the filling
process. Run the prewash programme to remove the salt that spilled inside
the machine. Since the salt granules that will remain under the lid will dissolve
during prewash, causing the lid loosen, check the lid once again at the end of
the programme.
• Salty food remnants have remained on dishes for a long time. >>> If cutlery
soiled with such foods will be kept waiting in machine, dirt must be removed by
prewash or dishes must be washed without being kept waiting.
• Electric installation is not grounded. >>>Check if your machine is connected to
the actual grounding line. Otherwise, the static electric created in the product
causes arcs on the surfaces of metal items creating pores, removing the
protective cover on the surface and causing discoloration.
• Intensive cleansers such as bleaches are used. >>> Protective cover on metal
surfaces gets damaged and looses its efficiency in time when it gets in contact
with cleansers such as bleach. Do not wash your dishes with bleach.
• Metal items particularly knives are used for purposes other then their intended
uses. >>> Protective cover on the edges of knives may get damaged when
38
Dishwasher / User manual
/44 EN
Troubleshooting
they are used for purposes such as opening cans. Do not use metal kitchen
utensils out of their intended uses.
• Cutlery are made of low quality stainless steel. >>> Corrosion on such items is
inevitable; they should not be washed in dishwashers.
• Kitchen utensils that are already corroded are washed in dishwasher. >>> Rust
on a corroded item can migrate to other stainless steel surfaces and cause
corrosion on those surfaces as well. Such items should not be washed in
dishwashers.
remains in .
• Detergent dispenser was damp when adding detergent. >>> Make sure that the
detergent dispenser is dried well prior to filling it with detergent.
• Detergent is added long before the washing process. >>> Pay attention to add
detergent shortly before start-up of the washing.
• Opening of the detergent dispenser lid is prevented during washing. >>>
Place the dishes in a way that will not prevent the detergent dispenser lid from
opening and the water going into the machine from impellers.
• Detergent is stored under unsuitable conditions. >>> If you are using powder
detergent, do not store the detergent package in humid places. Keep it in a
closed container if possible. For ease-of-storing, we recommend you to use
tablet detergents.
• Impeller holes are clogged. >>> Lower and upper impeller holes might be
clogged with food remnants such as lemon pips. Clean the impellers regularly
as illustrated in section “Cleaning and Care”.
and utensils are erased.
C
Decorated glasses and decorated lure porcelains are not suitable
for washing in the dishwasher. Manufacturers of some glassware and
porcelain tableware items do not recommend washing such kitchen
utensils in the dishwashers either.
Dishes are .
C
Kitchen utensils that contains or are made of aluminium should not be
washed in dishwasher.
• Salt leakage exists. >>> Pay attention not to spill salt around the salt filling hole
while adding salt. Spilled salt can cause scratches. Make sure that the salt
reservoir lid is tightly closed after finishing the filling process. Run the prewash
programme to remove the salt that spilled inside the machine. Since the salt
granules that will remain under the lid will dissolve during prewash, causing the
lid loosen, check the lid once again at the end of the programme.
• Water hardness setting is low or salt level is insufficient >>> Measure the
hardness of the supply water appropriately and check the water hardness
setting.
Dishwasher / User manual
39 / 44
EN
Troubleshooting
• Dishes are not placed orderly in the machine. >>> When placing the glasses
and other glassware into the basket lean them not against other dishes but the
edges or racks of the basket or the glass support tines. Striking of the glasses
to each other or to other dishes due to the impact of water during washing can
cause breaks, or scratches on their surfaces.
A smear remains that resembles be
when hand. A bluish when
the is .
• Excessive rinse aid is used. >>>Lower rinse aid setting. Clean the spilled rinse
aid when adding rinse aid.
• Corrosion has occurred on glass due to soft water. >>> Measure the hardness
of the supply water appropriately and check the water hardness setting. If
your supply water is soft (<5 dH), do not use salt. Choose programmes that
wash in higher temperatures (e.g. 60-65°C). You can also use glass protective
detergents that are commercially available.
in the .
• Dishes are washed with hand-wash detergent by hand but not rinsed before
placing them into the machine. >>> Hand-wash detergents do not contain
antifoam. There is no need to hand-wash the dishes before placing them into
the machine. Removing the coarse soil on the dishes under tap water, with a
tissue paper or fork will be sufficient.
• Rinse aid has spilled into the machine when adding rinse aid. >>> Take care
that rinse aid is not spilled in the machine when you are filling it. Clean any
spilled rinse ait with the help of a tissue paper/towel.
• Lid of the rinse aid reservoir is left open. >>> Make sure that the lid of the rinse
aid reservoir is closed after adding rinse aid.
utensils are .
• Dishes are not placed orderly in the machine. >>> Load the dishes as described
in the user manual.
• Baskets are overloaded. >>> Do not overload the baskets in excess of their
capacity.
Water remains in the dishwasher at the end the .
• Filters are clogged. >>> Check if the filter system is clean. Clean the filter
system regularly as illustrated in section “Cleaning and Care”.
• Discharge hose is clogged/blocked. >>> Check the discharge hose. If
necessary, remove the discharge hose, clear the blockage and insert is as
illustrated in the user manual.
C
If you cannot eliminate the problem although you follow the inructions
in this section, consult your dealer or the Authorised Service Agent.
Never try to repair a nonfunctional product yourself.
40
Dishwasher / User manual
/44 EN
Your new Blomberg product is
guaranteed again faulty materials,
defective components or manufacturing
defects. The guarantee arts from the
date of original purchase of the product
for a period of three (3) years, unless
Beko plc (the “Manufacturer”) agrees
to extend the guarantee for the product
in writing. If you have any queions
about the guarantee on your product
(including how long it is valid), please
contact your retailer or our Call Centre
on 0333 207 9870.
This guarantee does not in any way
diminish or aect your atutory rights
in connection with the product. This
guarantee is in addition to your atutory
rights as a consumer. If you have any
queions about these rights, please
contact the retailer from which you
purchased the product. In certain
circumances, it is possible that your
atutory rights may oer additional
or higher levels of protection than
those oered under the terms of this
guarantee.
• Repairs to the product required as
a result of faulty materials, defective
components or manufacturing
defects.
• Functional replacement parts to
repair a product.
• The costs of a Blomberg Approved
Engineer to carry out the repair.
8
Guarantee
• Transit and delivery damage.
• Cabinet or appearance parts,
including but not limited to control
knobs, flaps and handles.
• Accessories and/or consumable
items including but not limited to
ice trays, scrapers, cutlery baskets,
filters and light bulbs.
• Repairs necessary as a direct or
indirect result of:
- Accidental damage, misuse or
abuse of a product.
- An attempted repair of a product
by anyone other than a Blomberg
Approved Engineer (the “Engineer”).
- Installation or use of a product
where such installation or use fails
to meet the requirements contained
in this guarantee or the User
Instructions Booklet.
• Repairs to a product operated at
any time on commercial or non-
residential household premises
(unless we have previously agreed
to the inallation environment).
This guarantee is limited to the co
of repairing the product. To the extent
permitted by law, Beko plc (the
“Manufacturer”) does not accept and will
not be held liable for any nancial loss
incurred in connection with the failure of
any product to operate in accordance
with the expected andards. Such
nancial loss includes but is not limited
to loss arising from:
• Time taken off work.
• Damaged food, clothing or other
items.
Dishwasher / User manual
41 / 44
EN
Guarantee
• Meals taken at restaurants or from
takeaways.
• General compensation for
inconvenience.
• Your product is designed and built
for domestic household use only.
• The guarantee will automatically
be void if the product is installed
or is used in commercial or non-
residential domestic household
premises, unless we have
previously agreed to the installation
environment.
• The product must be correctly
installed, located and operated in
accordance with the instructions
contained in the User Instructions
Booklet provided with your product.
• Professional installation by a
qualified Electrical Domestic
Appliance Installer is recommended
for all Washing Machines,
Dishwashers and Electric Cookers
(as incorrect installation may result
in you having to pay for the cost of
repairing the product).
• Gas Cookers must be professionally
installed by a Gas Safe (or Gas
Networks Ireland for Republic of
Ireland) registered gas installer.
• This guarantee is given in respect
of products purchased and used
within the United Kingdom and the
Republic of Ireland.
• This guarantee is effective from the
initial date of purchase of a new
product from an authorised retailer
and will be void if the product is
resold.
• This guarantee does not apply to
graded sales (where the product is
purchased as a “second”).
• Possession of a copy of these
terms and conditions does not
necessarily mean that a product has
the benefit of this guarantee. If you
have any questions, please call our
Call Centre on the number set out
above.
• The Manufacturer reserves the right
to terminate the guarantee if its staff
or representatives are subjected
to physical or verbal abuse in the
course of carrying out their duties.
• Optional extras, where available
(i.e. extendable feet) are supplied
on a chargeable basis only.
This is a repair-only guarantee. On
occasion the Manufacturer may at its
sole discretion, replace your product
with a new product inead of carrying
out a repair. Where a replacement
is oered, this would normally be an
identical model, but when this is not
possible, a model of similar specication
will be provided. The Manufacturer
will cover the cos and arrange for
the delivery of the new product and
for the return of the old product. Any
cos related to disconnecting the faulty
product and inalling the replacement
product will not be borne by the
Manufacturer unless previously agreed
to in writing. The original guarantee will
continue to apply to the replacement
product; the new product will not come
with a new guarantee.
42
Dishwasher / User manual
/44 EN
Guarantee
Our engineers work Monday to Friday
9.00am to 5.00pm. Appointments
outside these hours may be possible at
the sole discretion of the Manufacturer
but cannot be guaranteed. Whil our
Engineers will endeavour to minimize
inconvenience and to meet reques for
specic timed appointments, this cannot
be guaranteed. The Manufacturer
will not be liable for delays or if it is
unable to carry out a repair because
a convenient appointment cannot be
arranged.
It is your responsibility to provide
evidence to the Engineer that your
product is covered by this guarantee
with a proof of purchase. The
Manufacturer reserves the right to
charge for the reasonable co of any
service call if:
• You cannot provide evidence that
your product is covered by this
guarantee.
• Where a service call has been
made and the engineer finds that
there is no fault with your product.
• That your product has not been
installed or operated in accordance
with the User Instructions Booklet.
• That the fault was caused by
something other than faulty
materials, defective components or
manufacturing defects.
• For missed appointments.
Payment of these cos are due
immediately upon the Engineer
providing you with an invoice. If you
fail to pay the cos for the service call
in a timely manner, the Manufacturer
reserves the right to terminate the
guarantee.
If you are a resident of the United
Kingdom, this guarantee will be
governed by English law and subject to
the English Courts, save where you live
in another part of the United Kingdom,
in which case the law and courts of that
location will apply.
If you are resident in the Republic of
Ireland, this guarantee will be governed
by Irish law and the Irish courts will
have jurisdiction.
HOW TO OBTAIN SERVICE
Please keep your purchase receipt
or other proof of purchase in a safe
place; you will need to have it should
the product require attention under
guarantee.
15 9428 0100_AA_BLOMBERG_E545_EN/ 21-06-18.(11:33)
It will be useful if you complete the details below, as it will help us assi you when
requeing service. (The model number is printed on the Inruction Booklet and the
serial number is printed on the Rating Label axed to the appliance). Recording of
these details alone will not count as proof of purchase. A valid proof of purchase is
required for under guarantee service.
The area around the product mu be easily accessible to the Engineer without the
need for cabinets or furniture being removed.
It is your responsibility to ensure our Engineers have a clean and safe environment
to carry out any repairs.
………...……………………………………………………………………………………
Model No:
Serial No:
Retailer:
Date of purchase:
…………………………………………….………………………………………………..
0333 207 9870.
01 691 0160
www.blomberguk.com/regier
Before requeing service please check the troubleshooting guide in the Operating
Inructions as a charge may be levied where no fault is found even though your
product may ill be under guarantee.
If you have purchased an extended guarantee please refer to the inructions
contained within the extended guarantee agreement document, otherwise please
call the appropriate number above where service can be obtained at a charge.
Should you experience any diculty in obtaining service contact the Blomberg
Cuomer Helpline on Tel: 0333 207 9870 or e-mail: cuomerservice@support.
Blomberguk.com
……………………………………………….................................................................
This guarantee is provided by Beko plc. Beko House, 1 Greenhill Crescent,
Watford, Herts, WD18 8QU. Beko plc is regiered in England and Wales with
company regiration number 02415578.
