PLCMTR‐CommercialGradeCameraSystem
www.pyleaudio.com
Pleasereadinstructionscarefullybeforeinstallationanduse.Installationshouldbeperformedbyaprofessionalinstaller.
Toensureyoursafety,thedrivershouldnotwatchvideosoroperatefeaturesonthemonitorwhiledriving.Thereareno
serviceablepartsinthisunit,donotdisassembleortrytorepairthisunit.Ifunitmalfunctionspleasereturntoyourvendor
orsendtoaPylerepairfacility.
Pleaseobserveandobeythelocallawsandregulationswheninstallingtheunit.Upon
Installation,pleasemakesureastonottointerferewithanyofthevehicle'ssafetyfeatures,wiring,components,etc.We
arenotresponsibleforanydamages,injury,malfunctionsorotherwisenotedduetofaultyornon‐professional
installation.
Connection/Installation:
Thecamerahastheabilitytoconnectupto4cameras(2wiredand2wireless‐thewiredcamerascanbeconnectedviathe
includedpowerandwiringharness,having2connectorjacksfeaturing4‐pinstyledconnectors.Ifyoudesi retotake
advantageofthis
optionalfeature,andconnectadditionalcameras,pleasebesuretousecompatiblecam eraswiththreaded
locking4‐pinconnectors.
*Pleasevisitwww.pyleaudio.comtolearnmoreaboutsystemco mpatibilityandoptionalcompatibleparts.
Camera&Monitorfeaturebuilt‐intransmittersandreceivers,theincludedantennasneedtobeconnectedtothe
camera
andmonitortosend&receivethewirelessvideosignals.Wirelesssignaltransmissionrangeupto300'feet.
Thissystemincludesonecamerawithbuilt‐in2.4Gwirelesstransmitter.Thecameracanbeusedasareversecamera
(placedintherearofyourvehicle)ornormalsafetydrivingcamera
todisplaythepictureasviewedthroughthelens(when
placedonthesidesorfacingthefrontofyourvehicle).Ifusedasareversecamera,besuretowirethe'ReverseTrigger
(Green)'cableaccordingly.
Userswillhavealsohavetheabilitytoflipthecamerapictureas
displayedontheLCDscreendisplay.Thebuttoncontrolson
themonitorpanelallowthepicturetobeflippedhorizontally(Left/Right)forbackuprearviewcameravi ewing.Notflipping
thepicturewilloutthecamerapicturetothemonitordisplaysthecamerapictureasseenthroughthecameralens.This
typeofdisplayoutputisusedforanycamerafacingthefrontofyourvehicle.
PLCMTR‐CommercialGradeCameraSystem
www.pyleaudio.com
Wiring & Connection
Usethewiringchartabovetoconnectyourcamerasystemaccordingly.Ifmultiplecamerasareusedthecoloredtrigger
wiresserveasautomaticcameraanddisplayactivationconnections.
Channels1&2arereservedforwirelesscameraconnection.
Channels3&4arereservedforwiredcamera,astheincludedpowerandpowerharnesshas2additionalinputconnectors
forcompatible4‐pincameras.Theseoptionsareavailableforuserswhowishtoconnectadditionalcamerastothesystem.
Pleasenote,systeminstallationincludesoptionalmethodsofcamerasetupasuserscanchoosetoincorporateadditional
camerasourcestothecameraandvideosystem.
*Pleasevisitwww.pyleaudio.comtolearnmoreaboutsystemco mpatibilityandoptionalcompatibleparts.
2.4GAntennas
Channel1‐2370MHz
Channel2‐2510MHz
PLCMTR‐CommercialGradeCameraSystem
www.pyleaudio.com
Monitor Stand Mounting
Pleasenote,incoldweatherandtempe r atures,the
display monitor may require some time to 'warm
up'toclearlydisplayapictureonscreen.
7''DisplayMonitor
B Menu
C VideoInput1‐Ch.1
D VideoInput2‐Ch.2
E Power
F VideoInput3‐Ch.3
G VideoInput4‐Ch.4
H Mode
I RemoteControlReceiver
J RemoteControlReceiver
K LCDDisplayScreen
L WirelessAntenna
M SunShade
N AngleAdjustmentKnob
O DisplayMountingBracket
PLCMTR‐CommercialGradeCameraSystem
www.pyleaudio.com
TheU‐shapedmountstandbracketseparatesfromtheLCDdisplayhousingforattachment/fixture.TheU‐shapedbracket
attachestothedesiredlocationvia3screwholeslocated atthebaseofthebracket.PleaseremovetheLCDdisplaymonitor
fromthebracketbeforeattemptingtosecurethe
brackettoyourdesiredlocation.
Oncescrewedintothedesiredlocation,attachtheLCDdisplaymonitorhousingandtightenwiththetighteningknobtothe
sideofthehousing.Adjusttheangle/tiltoftheLCDdisplaybeforetighteningthesideknob.
Model:PLCMTR82WIR
WirelessWeatherproofRearviewBackupCamera
&MonitorVideoSystem,CommercialGrade,NightVisionCamera,7''
Display,DualDC12‐24VforBus,Truck,Trailer,Van
Camera&MonitorVehicleSafetyVideoSystem
Wireless2.4GSignalTransmitter&Receiver
WirelessRange:Over300'Feet
DesignedforCar/Truckuse12/24VoltSystems
IncludesAllNecessaryCables&
Wiring
Monitor:
7inchTFTLCDDisplay
WirelessReceiverBuilt‐intoDisplay
AspectRatio:16:9Widescreen
System:PAL/NTSCAutoSwitching
AntiGlareSunShade
UniversalStandMount
Resolution:800x480Pixels
Brightness:350cd/m2
OSDMenuwithFrontPanelButtonControls
Brightness,Color,ContrastAdjustable
4‐PinSystemConnectivity
Jacks
AbilitytoConnectupto4Cameras(2Wireless,2Wired)
DCReverse12‐24VoltTriggerwithAutoActivation
Dimensions:(LxWxH):7.1''x2.9''x4.7''
SystemIncludes:
MonitorwithBuilt‐inReceiver
CamerawithBuilt‐inTransmitter
Power&WiringHarness
CameraDCPowerCable
(2)2.4GWirelessAntennas
Camera:
WeatherproofRearviewCameraSystem
WirelessTransmitterBuilt‐intoCamera
WeatherproofMarineGradeConstruction
IP68RatingWater&FogResistance
LEDLightswithIRNightVisionIllumination
LowLuxLightPerformance
ImageSensor:SHARPColor1/4''CMD
System:PAL/NTSCAutoSwitching
VideoOutput1.0Vpp‐75Ohm
LensAngle:170Degree
Min.Illumination:0.2Lux
AutoImageAdjustment
CameraDimensions(WxHxD):3.18"x2.95"x2.17"
