EN
CTS100-E-2B
USER’S GUIDE
CT
-
S100
Preparing a Power Supply Turning Power On or Off Connecting Headphones
(Sold Separately)
Selecting a Musical
Instrument Tone
Changing the Pitch in
Semitone Steps
(TRANSPOSE)
Fine Tuning (Tuning) Enabling and Disabling
Sustain (SUSTAIN)
Saving and Loading
Instrument Settings
(MY SETUP)
Playing a Built-in Song Playing with a Rhythm
Backing
Configuring Function Settings
Cove
r
EN-1
About Music Score data
You can download music score data as a PDF file from the CASIO website, which you can access using the URL or QR code
below. You will then be able to view music scores on your smart device. You can jump from the PDF file table of contents directly
to the music score you want, and you can print out scores as needed.
https://support.casio.com/global/en/emi/manual/CT-S100/
Included and Optional Accessories
Use only accessories that are specified for use with this Digital Keyboard.
Use of unauthorized accessories creates the risk of fire, electric shock, and personal injury.
• You can get information about accessories that are sold separately for this product from the CASIO catalog available from
your retailer, and from the CASIO website at the URL or QR code below.
https://support.casio.com/global/en/emi/manual/CT-S100/
• Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal
use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
• IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION,
DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE
USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
• The contents of this manual are subject to change without notice.
• The actual appearance of the product may be different from that shown in the illustrations in this User’s Guide.
• Company and product names used in this manual may be registered trademarks of others.
EN-2
General Guide EN-3
Getting Ready to Play EN-4
Preparing a Power Supply . . . . . . . . . . . . . . . . . . . EN-4
Preparing the Music Stand . . . . . . . . . . . . . . . . . . . EN-5
Connecting Headphones (Sold Separately) . . . . . . EN-5
Playing on the Keyboard EN-6
Turning Power On or Off. . . . . . . . . . . . . . . . . . . . . EN-6
Adjusting the Volume Level. . . . . . . . . . . . . . . . . . . EN-7
Using the Metronome . . . . . . . . . . . . . . . . . . . . . . . EN-7
Listening to Demo Play . . . . . . . . . . . . . . . . . . . . . . EN-8
Controlling the Sound of a Performance EN-9
Selecting a Musical Instrument Tone . . . . . . . . . . . EN-9
Enabling and Disabling Sustain (SUSTAIN) . . . . . EN-10
Adding Reverb to Notes (REVERB) . . . . . . . . . . . EN-10
Changing the Pitch in Semitone Steps
(TRANSPOSE) . . . . . . . . . . . . . . . . . . . . . . . . . EN-10
Fine Tuning (Tuning). . . . . . . . . . . . . . . . . . . . . . . EN-11
Saving and Loading Instrument Settings
(MY SETUP) EN-11
Saving to MY SETUP . . . . . . . . . . . . . . . . . . . . . . EN-11
Recalling From MY SETUP. . . . . . . . . . . . . . . . . . EN-12
Playing a Built-in Song EN-12
Songs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-12
Selecting a Song to Play. . . . . . . . . . . . . . . . . . . . EN-12
Practicing a Song Part . . . . . . . . . . . . . . . . . . . . . EN-14
Sounding a Count in Time with a Song. . . . . . . . . EN-14
Playing with a Rhythm Backing EN-15
Rhythm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-15
Playing a Rhythm . . . . . . . . . . . . . . . . . . . . . . . . . EN-15
Inserting a Fill-in Phrase . . . . . . . . . . . . . . . . . . . . EN-16
Fingering a Chord to Play a Rhythm
Accompaniment . . . . . . . . . . . . . . . . . . . . . . . . . EN-17
Connecting with External Devices EN-19
Connecting to a computer and Using MIDI . . . . . . EN-19
Connecting with Audio Equipment . . . . . . . . . . . . EN-20
Configuring Function Settings EN-21
Configuring Settings . . . . . . . . . . . . . . . . . . . . . . . EN-21
Keyboard Keys Used for Configuring Settings . . . EN-22
Setting Item List . . . . . . . . . . . . . . . . . . . . . . . . . . EN-23
Reference EN-26
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-26
Product Specifications . . . . . . . . . . . . . . . . . . . . . .EN-28
Tone List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-30
Drum Assignment List. . . . . . . . . . . . . . . . . . . . . . .EN-32
Song List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-33
Rhythm List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-34
Fingering Guide . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-35
Chord Example List . . . . . . . . . . . . . . . . . . . . . . . .EN-36
MIDI Implementation Chart
Contents
EN-3
■ Front Panel
■ Back
• The numbers to the right of the ☞ symbol are reference page numbers.
General Guide
P(Power) button ☞EN-6
VOLUME buttons ☞EN-7
Main tone buttons ☞EN-9
TONE button ☞EN-9, 16
RHYTHM/SONG button ☞EN-7, 8, 12, 15
FILL-IN/PART button ☞EN-14, 16
a (Start/Stop) button ☞EN-7, 12, 15
MY SETUP button ☞EN-11
FUNCTION button ☞EN-21
DC 9.5V terminal ☞EN-4
PHONES/OUTPUT jack ☞EN-5, 20 USB port ☞EN-19
Function setting item list ☞EN-21
EN-4
Though either an AC adaptor or batteries can be used for
power, use of AC adaptor power is normally recommended.
Use only the AC adaptor (JEITA Standard with unified polarity
plug) specified for this Digital Keyboard. Use of a different
type of AC adaptor can cause malfunction.
• Be sure to turn off Digital Keyboard power before
connecting or disconnecting the AC adaptor.
• The AC adaptor becomes warm to the touch after very
long use. This is normal and does not indicate
malfunction.
• To prevent breaking of the wire, take care to avoid
putting any type of load on the power cord.
• Never insert metal, pencils, or any other objects into
the DC 9.5V terminal. Doing so creates the risk of
accident.
• Be sure to turn off power before loading batteries.
• Use commercially available AA-size alkaline batteries
or AA-size rechargeable nickel metal hydride batteries.
• Low battery power can cause abnormal operation. If
this happens, replace batteries with new ones. If you
are using rechargeable batteries, charge them.
■ Batteries
Note the precautions below when using rechargeable
batteries.
• Use Panasonic Group AA-size eneloop rechargeable
batteries. Do not use any other type of batteries.
• Use only the specified charger to charge batteries.
• Rechargeable batteries must be removed from the product
for charging.
• For information about using eneloop batteries or their
specified charger, be sure to read the user documentation
and precautions that come with each item, and use them
only as directed.
Be sure to replace batteries at least once a year, even if there
is no indication of low battery power. Dead rechargeable
batteries (eneloop) in particular may deteriorate if they are left
in the product. Remove rechargeable batteries from the
product as soon as possible after they go dead.
1.
Open the battery cover on the back of the
Digital Keyboard.
2.
Load six AA-size batteries into the battery
compartment.
Load batteries with their positive (+) and negative (–)
ends facing correctly.
3.
Insert the tabs of the battery cover into the
holes, and close the cover.
• Configure the setting below to specify the type of
batteries you loaded.
Getting Ready to Play
Preparing a Power Supply
Using the AC Adaptor
AC Adaptor Type: AD-E95100L
(JEITA Standard plug)
No twisting No pulling No wrapping
AC adaptor DC 9.5V terminal
Household power outlet
Using Batteries for Power
Tab
Getting Ready to Play
EN-5
■ Configuring the Battery Type Setting
1.
While holding down FUNCTION, press the C{2
keyboard key.
• Each press of the C{2 keyboard key sounds a tone
that lets you know what setting (alkaline batteries or
nickel metal hydride batteries) was selected.
One tone: Alkaline batteries
Two tones: Rechargeable nickel metal hydride
batteries
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
■ Low Battery Indication
Flashing TONE LEDs indicate low battery power. When this
happens, replace the batteries with new ones.
• Continued use with low batteries may cause power to
turn off suddenly. This can cause stored data to be
corrupted or lost.
Insert the music stand into the handle of the Digital Keyboard.
Plugging in headphones cuts off output from the built-in
speakers, which means you can practice playing even late at
night without disturbing others.
• Be sure to turn down the Digital Keyboard volume level
before connecting headphones.
• Headphones do not come with the Digital Keyboard.
• Use separately sold or commercially available headphones.
• Do not listen to output over headphones at very high
volume levels for long periods. Doing so creates the
risk of hearing damage.
• If the plug of the headphones does not match the
PHONES/OUTPUT jack, use a commercially available
adapter plug.
• If you are using headphones that require an adapter
plug, make sure you do not leave the adapter plugged
in when removing the headphones.
Preparing the Music Stand
C2 C3 C4 C5 C6 C7
C
{
2
Music stand
Connecting Headphones (Sold
Separately)
PHONES/OUTPUT jack
(3.5mm stereo mini jack)
Stereo mini plug
EN-6
1.
Press P (Power).
This turns on power.
• To turn off power, long-press P (Power) until the LED
goes out.
2.
Play something on the keyboard.
• Turning off power normally causes the tone and
rhythm number and other settings to return to their
initial defaults. However, the settings below are
remembered.
− MIDI Out Channel
− MIDI Out Octave Shift
− MIDI Out Velocity
− Startup volume level
− MY SETUP Startup
− Auto Power Off
− Battery type
While Auto Power Off is enabled, Digital Keyboard power will
turn off automatically after about 30 minutes of non-operation.
• Auto Power Off is disabled while a song is playing.
■ Disabling Auto Power Off
You can disable Auto Power Off to ensure that power does
not turn off automatically during a concert, etc.
1.
While holding down FUNCTION, press the B}4
keyboard key.
• Each press of the B}4 keyboard key sounds a tone
that lets you know what setting (on or off) was
selected.
High tone: On (enabled)
Low tone: Off (disabled)
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
After disabling Auto Power Off, release
FUNCTION.
Playing on the Keyboard
Turning Power On or Off
Long-press
Auto Power Off
C2 C3 C4 C5 C6 C7
B
}
4
Playing on the Keyboard
EN-7
1.
Use the VOLUME + and – buttons to adjust the
volume level.
• The setting range is 0 to 10.
• Holding down either button scrolls the setting value.
You can use the procedure below to specify the volume level
that is applied when the Digital Keyboard is turned on.
1.
While holding down FUNCTION, press the C{4
or E}4 keyboard key to adjust the volume level
setting.
• You can change the volume value within a range of 1
to 10.
• Pressing the C{4 keyboard key lowers the volume
level, while pressing E}4 raises it.
• To return the setting to its initial default, press the C{4
and E}4 keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
The metronome lets you play and practice along with a steady
beat to help keep you on tempo. You can also set a tempo
that is suitable for your practice.
1.
Press RHYTHM/SONG a number of times until
the LED goes out.
2.
Press a.
This starts the metronome.
3.
Press a again to stop the metronome.
Use the procedure below to change the tempo of the
metronome.
1.
Start the metronome.
2.
While holding down FUNCTION, use the
TEMPO keyboard keys to specify a tempo
value.
• You can specify a tempo value in the range of 20 to
255.
• Each press of the – or + keyboard key raises or lowers
the tempo by 1. Holding down either button scrolls the
setting value.
• You can also use the TEMPO value input keys (0 to 9)
to enter a specific tempo value.
• Input three digits as the tempo value.
Example: To set a tempo of 20, input “03230”.
• To return the setting to its initial default, press the –
and + keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
3.
Release FUNCTION to exit the setting
operation.
Adjusting the Volume Level
Specifying the Power On Volume Level
C2 C3 C4 C5 C6 C7
C
{
4 E
}
4
Using the Metronome
Start/Stop
Changing the Metronome Tempo
Playing on the Keyboard
EN-8
You can use the procedure below to configure a setting that
sounds a chime on the first beat of each measure, and a click
for the remaining beats.
• Available settings are Off, or a value of 1 to 16 beats.
1.
Start the metronome.
2.
While holding down FUNCTION, use the
METRONOME BEAT – and + keyboard keys to
change the beat.
• Selecting Off (0) disables the chime. Use this setting
when you want to practice without worrying about the
first beat of each measure.
• To return the setting to its initial default, press the –
and + keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
3.
Release FUNCTION to exit the setting
operation.
1.
Start the metronome.
2.
While holding down FUNCTION, use the
METRONOME VOLUME – and + keyboard keys
to change the volume level.
• You can specify a volume value from 0 to 10.
• To return the setting to its initial default, press the –
and + keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
3.
Release FUNCTION to exit the setting
operation.
You can use Demo Play to play built-in songs in sequence.
1.
While holding down FUNCTION, press the B}6
keyboard key.
This starts song number “1”.
• This causes the SONG LED to light.
• For information about how to change the demo song,
see the “Selecting a Demo Song” (page EN-8).
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION.
3.
To exit Demo Play, hold down FUNCTION as
you press the B}6 keyboard key again, or
press a.
You can use the procedure below to change the song played
by Demo Play.
1.
While holding down RHYTHM/SONG, press
one of the keyboard keys.
This starts Demo Play of the song you selected.
• Each of the keyboard keys has a song assigned to it.
For a list of song titles, see the “Song List” (page
EN-33).
• The keyboard input LED is lit while RHYTHM/SONG
is depressed.
2.
Release RHYTHM/SONG to exit the setting
operation.
Specifying the Metronome Sound and Beats
Per Measure
Changing the Metronome Sound Volume
Level
Listening to Demo Play
Selecting a Demo Song
C2 C3 C4 C5 C6 C7
B
}
6
EN-9
Your Digital Keyboard lets you select tones for a wide variety
of musical instrument sounds, including violin, flute, orchestra,
and more. Dedicated buttons give you instant access to the
main tones (piano, organ, etc.) Even the same song sounds
different when the instrument type is changed.
1.
Press one of the main tone buttons: PIANO,
E.PIANO, ORGAN, HARPSICHORD, STRINGS.
• This causes the TONE 1 LED to light.
2.
To toggle between tone variations, press
TONE.
• Each press of TONE toggles between TONE 1
(TONE 1 LED lit, TONE 2 LED unlit) and TONE 2
(TONE 2 LED lit, TONE 1 LED unlit).
1.
Press TONE to select the tone group you want.
• Each press of TONE toggles between Group 1
(TONE 1 LED lit, TONE 2 LED unlit) and Group 2
(TONE 2 LED lit, TONE 1 LED unlit).
• When you select a group, keep TONE depressed as
you continue with step 2, below.
2.
While holding down TONE, press one of the
keyboard keys.
This sounds the selected tone.
• Each of the keyboard keys has a tone assigned to it.
For tone information, see the “Tone List” (page
EN-30).
3.
Release TONE to exit the setting operation.
• Selecting a drum set tone causes various percussion
instruments to be assigned to keyboard keys.
■ Tone Groups
Tones are divided into two groups: Group 1 and Group 2.
After selecting the group that includes the tone you want to
use, use the keyboard keys to select the tone.
Controlling the Sound of a
Performance
Selecting a Musical Instrument
Tone
Selecting One of the Main Tones
Selecting a Tone
Controlling the Sound of a Performance
EN-10
While sustain is enabled, notes are sustained longer when
keyboard keys are released.
1.
While holding down FUNCTION, press the
SUSTAIN keyboard key.
This turns on sustain.
• Each press of the SUSTAIN keyboard key sounds a
tone that lets you know what setting (on or off) was
selected.
High tone: On (enabled)
Low tone: Off (disabled)
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
You can use the procedure below to add reverb to the notes
you play.
1.
While holding down FUNCTION, press the
REVERB keyboard key to select a reverb type.
• You can specify a reverb value in the range of 1 to 4.
• Each press of the REVERB keyboard key sounds a
tone that lets you know what setting was selected.
One low tone: Off (disabled)
One high tone: 1
Two high tones: 2
Three high tones: 3
Four high tones: 4
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
Transpose lets you raise or lower the overall pitch in semitone
steps. You can use this feature to raise or lower the key to
make it easier to play a piece written in a difficult key, or to
adjust to a key that better matches a vocalist, another musical
instrument, etc.
1.
While holding down FUNCTION, use the
TRANSPOSE keyboard keys to change the
transpose setting.
• The setting range is one octave up (+12 semitones)
and down (–12 semitones).
• Pressing the – keyboard key lowers the pitch in
semitone units, while pressing the + key raises the
pitch in semitone units.
• To return the setting to its initial default, press the –
and + keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
Enabling and Disabling Sustain
(SUSTAIN)
Adding Reverb to Notes
(REVERB)
Changing the Pitch in Semitone
Steps (TRANSPOSE)
EN-11
You can use the procedure below to adjust the overall pitch by
changing the frequency of A4. (0.1Hz units)
1.
While holding down FUNCTION, use the
TUNING keyboard keys below to adjust tuning.
440: Sets the A4 frequency to 440.0 Hz.
–1: Lowers the A4 frequency 1.0Hz.
+1: Raises the A4 frequency 1.0Hz.
–0.1: Lowers the A4 frequency 0.1Hz.
+0.1: Raises the A4 frequency 0.1Hz.
• You can specify a frequency in the range of 415.5 to
465.9 Hz.
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
You can use MY SETUP to save the setup (tone, rhythm, and
other settings) of the Digital Keyboard. You can recall a saved
setup when you need it to perform a particular song, etc.
1.
Long-press MY SETUP.
Your setup is saved when you hear an operation
complete tone.
You can use MY SETUP to save the items below.
• The function you are using (Tone, Rhythm, Song)
• Tempo
• Tone number
• Metronome beat
• Metronome volume level
•Sustain
• Rhythm number
• Song number
• Practice part
• Count
• Transpose
• Reverb
• Pedal
• Chord fingering mode
• Rhythm volume level
• Song volume level
• Tuning
Fine Tuning (Tuning)
Saving and Loading
Instrument Settings (MY
SETUP)
Saving to MY SETUP
Savable Settings
Long-press
EN-12
1.
Press MY SETUP.
Your setup is saved when you hear an input tone.
Use the procedure below to enable MY SETUP power on,
which causes the MY SETUP settings to be applied whenever
power is turned on.
1.
While holding down FUNCTION, press the F{4
keyboard key to enable MY SETUP power on.
• Each press of the F{4 keyboard key sounds a tone
that lets you know what setting (on or off) was
selected.
High tone: On (enabled)
Low tone: Off (disabled)
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
With this Digital Keyboard, the term “song” is used to refer to a
musical piece. You can listen to the built-in songs for your
own enjoyment, or you can play along with them for practice.
1.
Press RHYTHM/SONG a number of times until
the SONG LED is lit.
2.
While holding down RHYTHM/SONG, press
one of the keyboard keys.
This starts playback of the song you selected.
• Each keyboard key has a song assigned to it. For a list
of songs, see the “Song List” (page EN-33).
• The keyboard input LED is lit while RHYTHM/SONG
is depressed.
3.
Release RHYTHM/SONG.
4.
Press a to stop the song.
5.
To resume the previously playing song, press
a again.
• Starting to use the Song Function while the metronome is
sounding or a rhythm is playing will cause the ongoing
operation to stop.
Recalling From MY SETUP
Enabling MY SETUP Power On
C2 C3 C4 C5 C6 C7
F
{
4
Playing a Built-in Song
Songs
Selecting a Song to Play
Starting or Stopping Song Play
Playing a Built-in Song
EN-13
You can use the procedure below to change the tempo
(speed) and slow down playback to practice difficult
passages, etc.
1.
Select the song whose tempo you want to
change with the Song Function.
2.
While holding down FUNCTION, use the
TEMPO keyboard keys to specify a tempo
value.
• You can specify a tempo value in the range of 20 to
255.
• Each press of the – or + keyboard key raises or lowers
the tempo by 1. Holding down either button scrolls the
setting value.
• You can also use the TEMPO value input keys (0 to 9)
to enter a specific tempo value.
• Input three digits as the tempo value.
Example: To set a tempo of 20, input “03230”.
• To return to the recommended setting for the current
song, press the – and + keyboard keys at the same
time.
• Changing the song number returns the song to its
recommended tempo.
• The keyboard input LED is lit while FUNCTION is
depressed.
3.
Release FUNCTION to exit the setting
operation.
Use the procedure below to adjust the balance between the
volume levels of song play and what you play on the
keyboard.
1.
While holding down FUNCTION, use the SONG
VOLUME – and + keyboard keys to adjust the
volume level.
• You can change the volume value within a range of 1
to 10.
• To return the setting to its initial default, press the –
and + keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
Changing a Song’s Tempo (Speed) Adjusting the Song Volume Level
Playing a Built-in Song
EN-14
You can turn off the right-hand part or the left-hand part of a
song you are playing and practice along with the remaining
part. Use this when you feel that a song is initially too difficult
for you to play with both hands at the same time.
1.
While a song is playing or stopped, press
FILL-IN/PART.
Each press of FILL-IN/PART cycles through the
settings shown below.
• A tone sounds to let you know which playback part is
selected.
One low tone: Off (all parts sound)
One high tone: Right-hand part off
Two high tones: Left-hand part off
Three high tones: Both-hand parts off
You can configure count settings to sound a count in time with
a song and to sound a pre-count before a song starts.
1.
While song play is stopped, hold down
FUNCTION as you press the SONG COUNT
keyboard key to specify a count setting.
• Each press of the SONG COUNT keyboard key
sounds a tone that lets you know what setting was
selected.
One low tone: Off (disabled)
One high tone: Count
Two high tones: Pre-count
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION.
3.
Press a to start playback.
• Playback starts in accordance with the count type you
selected.
Count: A count sounds throughout song playback.
Pre-count: A count sound at the beginning of the song,
before actual playback starts.
• To turn off a count, stop the song and repeat step 1 of
this procedure until you hear one low tone.
Practicing a Song Part
Normal Playback (Initial Default Setting)
Right-hand Part Off
Left-Hand Part Off
Both-hand Parts Off
Sounding a Count in Time with a
Song
Configuring Count Settings
EN-15
You can use the procedures in this section to select the
rhythm you want, and then automatically play
accompaniments to suit it simply by playing chords with your
left hand. It’s like having a personal backup group along with
you wherever you go.
• Auto Accompaniments are made up of the parts
(instruments) below.
– Rhythm (percussion)
– Bass (bass instruments)
– Harmony (other instruments)
You can have only the rhythm part play, or you can have all
three parts play at the same time.
The rhythm part is the foundation of each Auto
Accompaniment. Your Digital Keyboard comes with a variety
of built-in rhythms, including 8-beat and waltz. Use the
procedure below to play the basic rhythm part.
1.
Press RHYTHM/SONG a number of times until
the RHYTHM LED is lit.
2.
While holding down RHYTHM/SONG, press
one of the keyboard keys.
This starts playback of the rhythm you selected.
• Each of the keyboard keys has a rhythm assigned to it.
For information about rhythms, see the “Rhythm List”
(page EN-34).
• The keyboard input LED is lit while RHYTHM/SONG
is depressed.
3.
Release RHYTHM/SONG.
4.
To stop playback, press a.
5.
To resume the previously playing rhythm,
press a again.
Use the procedure below to change tempo to a speed that
suits you.
1.
Select the rhythm whose tempo you want to
change with the Rhythm Function.
2.
While holding down FUNCTION, use the
TEMPO keyboard keys to specify a tempo
value.
• You can specify a tempo value in the range of 20 to
255.
• Each press of the – or + keyboard key raises or lowers
the tempo by 1. Holding down either button scrolls the
setting value.
• You can also use the TEMPO value input keys (0 to 9)
to enter a specific tempo value.
• Input three digits as the tempo value.
Example: To set a tempo of 20, input “03230”.
• To return to the recommended value, press the – and
+ keyboard keys at the same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
3.
Release FUNCTION to exit the setting
operation.
Playing with a Rhythm
Backing
Rhythm
Playing a Rhythm
Changing the Tempo of a Rhythm
Playing with a Rhythm Backing
EN-16
Use the procedure below to adjust the balance between the
volume levels of keyboard play and the rhythm.
1.
While holding down FUNCTION, use the
RHYTHM VOLUME – and + keyboard keys to
adjust the volume level.
• You can change the volume value within a range of 1
to 10.
• To return the setting to its initial default, press the
RHYTHM VOLUME – and + keyboard keys at the
same time.
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
1.
While a rhythm is playing, use TONE to select
the tone group you want.
• Each press of TONE toggles between Group 1
(TONE 1 LED lit, TONE 2 LED unlit) and Group 2
(TONE 2 LED lit, TONE 1 LED unlit).
• When you select a group, keep TONE depressed as
you continue with step 2, below.
2.
While holding down TONE, press one of the
keyboard keys.
This sounds the selected tone.
• Each of the keyboard keys has a tone assigned to it.
For tone information, see the “Tone List” (page
EN-30).
3.
Release TONE to exit the setting operation.
A “fill-in” is a short phrase played where you want to change
the mood of a piece. A fill-in pattern can be used to create a
link between two melodies or as an accent.
1.
While a rhythm is playing, press FILL-IN/
PART.
This inserts a fill-in phrase that plays to the end of the
measure. The RHYTHM LED flashes while the fill-in
phrase is sounding.
• To continue play of the fill-in phrase through the
following measure, keep FILL-IN/PART depressed.
• If you press FILL-IN/PART while a rhythm is stopped,
the fill-in phrase will be put into standby and played
when the rhythm is started.
In this case, you can cancel fill-in phrase standby by
pressing the FILL-IN/PART button again before
starting the rhythm.
Changing the Volume Level of a Rhythm
Changing the Keyboard Tone While a
Rhythm is Playing
Inserting a Fill-in Phrase
Playing with a Rhythm Backing
EN-17
Playing a chord with your left hand automatically adds bass
and harmony accompaniment parts to the currently selected
rhythm. It is just like having your own personal back up group
on call.
1.
Start the rhythm.
2.
Play something on the accompaniment
keyboard.
This starts the accompaniment, sounding the bass,
harmony, and other non-rhythm instruments.
• Playing a chord while rhythm play is stopped will cause
rhythm and accompaniment to start at the same time.
3.
Play other chords with your left hand as you
play the melody with your right hand.
4.
To stop the rhythm, press a.
You can select from among the six chord fingering modes
below.
• CASIO CHORD
•FINGERED1
•FINGERED2
• FINGERED ON BASS
• FINGERED ASSIST
• FULL RANGE CHORD
1.
While holding down FUNCTION, use the
CHORD MODE keyboard keys to specify a
chord fingering mode.
• Each press of the CHORD MODE keyboard key
sounds a tone that lets you know what setting was
selected.
One low tone: Off
One high tone: CASIO CHORD
Two high tones: FINGERED 1
Three high tones: FINGERED 2
Four high tones: FINGERED ON BASS
Five high tones: FINGERED ASSIST
Six high tones: FULL RANGE CHORD
• The keyboard input LED is lit while FUNCTION is
depressed.
2.
Release FUNCTION to exit the setting
operation.
Fingering a Chord to Play a
Rhythm Accompaniment
Accompaniment keyboard
Selecting a Chord Fingering Mode
Playing with a Rhythm Backing
EN-18
■ CASIO CHORD
With CASIO CHORD, you can use simplified fingerings to
play the four types of chords described below.
• When playing a minor, seventh, or minor seventh chord on
the accompaniment keyboard, it makes no difference
whether the additional keys you press are black or white.
■ FINGERED
With this chord fingering mode, you play chords on the
accompaniment keyboard using their normal chord fingerings.
Note that some chords can also be formed using abbreviated
fingerings of one or two keys. For information about the types
of chords you can finger and their fingerings, see the
“Fingering Guide” (page EN-35).
● FINGERED 1
Play the component notes of the chord on the keyboard.
● FINGERED 2
Unlike FINGERED 1, 6th input is not possible with this mode.
● FINGERED ON BASS
Play the component notes of the chord on the keyboard. This
mode allows input of fraction chords with the lowest keyboard
note as the base note.
● FINGERED ASSIST
In addition to FINGERED 1 input, you can also use the
fingerings below to play the three chord types.
■ FULL RANGE CHORD
With this chord fingering mode, you can use the full range of
the keyboard to play chords and the melody.
Chord Type Example
Major Chords
Letters above the accompaniment
keyboard indicate the name of the
chord assigned to each key.
Accompaniment keyboard keys
marked with the same chord name
play exactly the same chord.
C (C Major)
Minor Chords
Press the key that corresponds to the
major chord, while also pressing one
other accompaniment area key to the
right.
Cm (C Minor)
Seventh Chords
Press the key that corresponds to the
major chord, while also pressing two
other accompaniment area keys to
the right.
C7 (C Seventh)
Minor Seventh Chords
Press the key that corresponds to the
major chord, while also pressing
three other accompaniment area
keys to the right.
Cm7
(C Minor Seventh)
Accompaniment keyboard
A
C
C
DE F F
#
b
E
#
G
b
AB
B
b
C
C
DE F
E
#
b
A
C
C
DE F F
#
b
E
#
G
b
AB
B
b
C
C
DE F
E
#
b
A
C
C
DE F F
#
b
E
#
G
b
AB
B
b
C
C
DE F
E
#
b
A
C
C
DE F F
#
b
E
#
G
b
AB
B
b
C
C
DE F
E
#
b
Minor Chords
(Cm)
One keyboard key for the base note and
the nearest black key to the left.
Seventh Chords
(C7)
One keyboard key for the base note and
the nearest white key to the left.
Minor Seventh
Chords (Cm7)
One keyboard key for the base note and
the nearest black key and white key to
the left.
Accompaniment keyboard
Accompaniment Keyboard/Melody Keyboard
EN-19
You can connect the Digital Keyboard to a computer and
exchange MIDI data between them. You can record Digital
Keyboard play using computer music software, and use the
Digital Keyboard to play data sent to it from the computer.
■ Minimum Computer System Requirements
The following shows the minimum computer system
requirements for sending and receiving MIDI data. Check to
make sure that your computer complies with these
requirements before connecting the Digital Keyboard to it.
● Supported Operating Systems
Windows 7*
1
Windows 8.1*
2
Windows 10*
3
macOS (OS X / Mac OS X) 10.7, 10.8, 10.9, 10.10, 10.11,
10.12, 10.13, 10.14, 10.15
*1 Windows 7 (32-bit, 64-bit)
*2 Windows 8.1 (32-bit, 64-bit)
*3 Windows 10 (32-bit, 64-bit)
● USB Port
• Never connect the Digital Keyboard to a computer
running an operating system that is not one of those
above. Doing so can cause malfunction of the
computer.
• For the latest news about supported operating systems,
visit the website at the URL or QR code below.
https://support.casio.com/global/en/emi/manual/CT-S100/
■ Connecting to a Computer
• Incorrect connections can make data exchange
impossible. Be sure to follow the steps of the
procedure below.
1.
Turn off the Digital Keyboard and then start up
your computer.
• Do not start up the music software on your computer
yet!
2.
Use a commercially available USB cable to
connect the Digital Keyboard to your
computer.
• Use a USB 2.0 or 1.1 A-MicroB connector type USB
cable that supports data communication.
3.
Turn on the Digital Keyboard.
• If this is the first time you are connecting, the driver
required to transfer data will automatically be installed
on your computer.
4.
Start up commercially available music software
on your computer.
5.
Use the settings of your computer’s
commercially available music software to
select “CASIO USB-MIDI” as the MIDI device.
• For information about how to select the MIDI device,
refer to the user documentation that comes with the
music software you are using.
• Be sure to turn on the Digital Keyboard before starting
up your computer’s music software.
• Data send/receive cannot be performed while a song is
playing (page EN-12).
Connecting with External
Devices
Connecting to a computer and
Using MIDI
Digital Keyboard USB port (Micro-B)
Micro-B connector
Computer, smartphone, etc.
B
Connecting with External Devices
EN-20
• Once you are able to connect successfully, you can leave
the USB cable connected when you turn off your computer
and/or Digital Keyboard.
• For detailed specifications and connections that apply to
MIDI data communication by this Digital Keyboard, see the
latest support information provided on the website at the
URL or QR code below.
https://support.casio.com/global/en/emi/manual/CT-S100/
■ Configuring MIDI Settings
For information about the MIDI settings below, refer to the
“Setting Item List” (page EN-23).
• MIDI Out Channel
• MIDI Out Octave Shift
• MIDI Out Velocity
• Local Control
You can connect the Digital Keyboard to a commercially
available stereo system or amplifier, or to a recording device.
You can also use the Digital Keyboard to sound output from a
portable audio player or another device, and use that as
backing for your keyboard play.
■ Sounding Digital Keyboard Output on an
External Device
Connection requires commercially available connecting cords,
supplied by you.
• The connecting cord should have a stereo mini plug on one
end and a plug that matches the configuration of the input
jack of the external device on the other end.
• Turn off the external device and the Digital Keyboard
before connecting them. Before turning power on or
off, turn down the volume level of the Digital Keyboard
and external devices.
• After connecting, turn on the Digital Keyboard first and
then the external device.
• If Digital Keyboard notes are distorted when they are
sounded on an external audio device, lower the Digital
Keyboard’s volume level.
Connecting with Audio
Equipment
Digital Keyboard PHONES/OUTPUT jack (3.5mm stereo mini jack)
Stereo mini plug
Audio equipment, amplifier,
etc.
EN-21
You can use FUNCTION in combination with keyboard keys to configure various settings.
1.
Find the item whose setting you want to change in the table under “Setting Item List” (pages EN-23 and
24) and note its details.
2.
Use the information under “Keyboard Keys Used for Configuring Settings” on page EN-22 to find the
location of the keyboard keys for configuring the setting you want.
3.
While holding down FUNCTION, use the keyboard key or keys you looked up in step 2 of this procedure
to configure the setting you want.
• The keyboard input LED is lit while FUNCTION is depressed.
• A tone will sound after the setting is configured.
Example: To lower the song volume by pressing the SONG VOLUME – keyboard key
4.
Release FUNCTION to exit the setting operation.
• You can configure a setting to disable the tone that sounds in step 3 of this procedure.
For more information, see “
Operation Tone” in the table under “Setting Item List” (pages EN-23 and 24).
Configuring Function Settings
Configuring Settings
SONG VOLUME – Keyboard Key
Configuring Function Settings
EN-22
• The circled numbers (
through
) correspond to the numbers in the table under “Setting Item List” (pages EN-23 and 24).
Keyboard Keys Used for Configuring Settings
(C2) (C3) (C4)
(C5) (C6) (C7)
− + − +
−+ −+−+ −+
− + − +− +
Left keyboard
Overall
Right keyboard
Chord fingering mode
Song count
Song volume
Rhythm volume
Tempo
MIDI Out Velocity
MIDI Out Channel
Battery type
MIDI Out Octave Shift
Startup volume level
MY SETUP Startup
Local control
Auto Power Off
Off/On Off/On Off/On
Off/On
Initialize
Operation tone
Off/OnPreparation Execute
Demo
Tuning
Off/On
Metronome beat
Sustain
Transpose
Reverb
Metronome volume level
Configuring Function Settings
EN-23
Setting Item List
Item Setting Options Description Remarks
Battery type Alkaline, Nickel metal
hydride
Specifies the type of batteries
being used.
• Each press of the keyboard key sounds a
tone that lets you know what setting was
selected.
One tone: Alkaline
Two tones: Nickel metal hydride
MIDI Out
Channel
1 to 16 Specifies the channel to output
MIDI messages.
• To return the setting to its initial default,
press – and + at the same time.
MIDI Out
Octave shift
–3 to 0 to +3 Specifies, in octave units, the note
message key number for MIDI
Out.
• To return the setting to its initial default,
press – and + at the same time.
MIDI Out
Velocity
Off, 1 to 127 Specifies the velocity of the note
on message for MIDI Out.
Startup volume
level
1 to 10 Specifies the power on volume
level.
• To return the setting to its initial default,
press – and + at the same time.
MY SETUP
Startup
Off, On Enables/disables configuration of
MY SETUP settings when power
is turned on.
Local control Off, On Mutes (Off)/unmutes (On) the
Digital Keyboard sound output of
your keyboard play.
Auto Power Off Off, On Enables/disables Auto Power Off. • Each press of the keyboard key sounds a
tone that lets you know what setting was
selected.
High tone: On (enabled)
Low tone: Off (disabled)
Chord fingering
mode
Off,
CASIO CHORD,
FINGERED 1,
FINGERED 2,
FINGERED ON BASS,
FINGERED ASSIST,
FULL RANGE CHORD
Specifies the chord fingering
mode.
• Each press of the keyboard key sounds a
tone that lets you know what setting was
selected.
One low tone: Off
One high tone: CASIO CHORD
Two high tones: FINGERED 1
Three high tones: FINGERED 2
Four high tones: FINGERED ON BASS
Five high tones: FINGERED ASSIST
Six high tones: FULL RANGE CHORD
Rhythm volume 0 to 10 Adjusts the rhythm volume level. • To return the setting to its initial default,
press – and + at the same time.
Song count Off, Count, Pre-count Can be used to sound a count in
time with song playback.
• Each press of the keyboard key sounds a
tone that lets you know what setting was
selected.
One low tone: Off (disabled)
One high tone: Count
Two high tones: Pre-count
Song volume 0 to 10 Adjusts the song volume level. • To return the setting to its initial default,
press – and + at the same time.
Tempo 20 to 255 Changes the tempo. • To return the setting to its initial default or
recommended setting, press – and + at
the same time.
Initialize Returns all settings to their factory
defaults.
Configuring Function Settings
EN-24
• Turning power off and back on again returns tone and other settings to their initial defaults (page EN-6).
• The settings below are retained even when power is turned off.
− MIDI Out Channel
− MIDI Out Octave Shift
− MIDI Out Velocity
− Startup volume level
− MY SETUP Startup
− Auto Power Off
− Battery type
Operation tone Off, On When this setting is disabled (Off),
a tone does not sound when a
keyboard key is pressed while
FUNCTION is depressed.
Demo Plays the Demo Song.
Metronome beat Off, 1 to 16 Changes the metronome beat. • To return the setting to its initial default,
press – and + at the same time.
Metronome
volume level
0 to 10 Changes the metronome volume
level.
• To return the setting to its initial default,
press – and + at the same time.
Sustain Off, On When enabled, sustains notes to
produce rich resonance.
• Each press of the keyboard key sounds a
tone that lets you know what setting was
selected.
High tone: On (enabled)
Low tone: Off (disabled)
Reverb Off, 1 to 4 Specifies the type of reverb to be
applied.
• Each press of the keyboard key sounds a
tone that lets you know what setting was
selected.
One low tone: Off (disabled)
One high tone: 1
Two high tones: 2
Three high tones: 3
Four high tones: 4
Transpose –12 to 0 to +12 The transpose feature raises or
lowers the overall pitch in
semitone steps.
You can use this feature to raise
or lower the key to make it easier
to play a piece written in a difficult
key, or to adjust to a key that
better matches a vocalist, another
musical instrument, etc.
• To return the setting to its initial default,
press – and + at the same time.
Tuning 415.5Hz to 440.0Hz to
465.9Hz
Fine tunes the overall pitch by
changing the frequency of A4 in
0.1Hz units.
Item Setting Options Description Remarks
Configuring Function Settings
EN-25
1.
While holding down FUNCTION, press the C{5 keyboard key.
A tone will sound to indicate that initialization is about to be performed. Keep FUNCTION depressed at this time.
2.
Keeping FUNCTION depressed, press the E}5 keyboard key to start initialization.
A tone will sound when initialization is complete. The Digital Keyboard will be turned off and then back on again.
• The keyboard input LED is lit while FUNCTION is depressed.
3.
Release FUNCTION to exit the operation.
Returning Settings to Their Initial Factory Defaults
C2 C3 C4 C5 C6 C7
C
{
5
C2 C3 C4 C5 C6 C7
E
}
5
EN-26
Reference
Troubleshooting
Symptom Required Action
Included Accessories
I can’t find included items during unpacking. Carefully check inside all of the packing materials.
Power Requirements
Power does not turn on. • Check the AC adaptor or make sure that the batteries are facing correctly
(page EN-4).
• Replace the batteries with new ones. Or use AC adaptor power (page
EN-4).
The Digital Keyboard suddenly turns off after
outputting a loud sound.
Replace the batteries with new ones. Or use AC adaptor power (page EN-4).
The Digital Keyboard suddenly powers down
after about 30 minutes.
Disable Auto Power Off (page EN-6).
Sound
Nothing happens when I press a keyboard
key.
• Adjust the volume level (page EN-7).
• Check if something is plugged into the PHONES/OUTPUT jack on the
back of the Digital Keyboard.
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
Nothing happens or notes do not play
normally when I play on the accompaniment
(left-side) keyboard.
Select “Off” for the Chord Mode setting (page EN-17) to disable chord input
with the accompaniment keyboard.
Nothing happens when I start an Auto
Accompaniment.
• Check and adjust the rhythm volume level (page EN-16).
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
Nothing happens when I start playing a
song’s Auto Accompaniment.
• It takes a little time after you press the button until the song starts to play.
Wait for the song to start.
• Check and adjust the song volume level (page EN-13).
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
The metronome does not sound. • Check and adjust the metronome volume level (page EN-8).
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
Notes keep sounding, without stopping. • Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
• Replace the batteries with new ones. Or use AC adaptor power (page
EN-4).
Some notes are cut off while they are
playing.
Notes are cut off whenever the number of notes being sounded exceeds the
maximum polyphony value of 32 (16 for some tones). This does not indicate
malfunction.
The volume level or tone setting I configured
has changed.
• Adjust the volume level (page EN-7).
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
• Replace the batteries with new ones. Or use AC adaptor power (page
EN-4).
With certain volume levels and tones, the
sound of notes played in one keyboard
range will sound different from those played
in another keyboard range.
This is due to system limitations and does not indicate malfunction.
With some tones, octaves do not change at
the far ends of the keyboard.
This is due to system limitations and does not indicate malfunction.
Reference
EN-27
The pitch of the notes does not match other
accompanying instruments or notes sound
strange when played along with other
instruments.
• Check and adjust the transpose setting (page EN-10) and tuning setting
(page EN-11).
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
The reverb of notes seems to change
suddenly.
• Check and adjust the reverb setting (page EN-10).
• Try turning the Digital Keyboard off and then back on again (page EN-6) to
initialize settings.
Connecting to a computer
I can’t perform MIDI data transfers. • Check to make sure that the USB cable is connected to the Digital
Keyboard and computer, and that the correct device is selected with your
computer’s music software (page EN-19).
• Turn off the Digital Keyboard and then exit the music software on your
computer. Next, turn the Digital Keyboard back on and then restart the
music software on your computer.
Symptom Required Action
Reference
EN-28
* Measured values while using eneloop batteries.
eneloop is a trademark of Panasonic Corporation.
• Specifications and designs are subject to change without notice.
Product Specifications
Model CT-S100
Keyboard 61 keys
Maximum Polyphony 32 notes
Tones
Preset Tones 122 preset tones, Main tone buttons
Effects Reverb (4 types, Off)
Metronome
Beat Off, 1 to 16 beats
Tempo 20 to 255
Song Bank
Preset Songs 60 songs
Part Off Left hand, right hand, both hands
Auto Accompaniment
Preset Rhythms 61 types, chord input mode switching
Demo Play Looped play of all built-in Song Bank songs (60 songs)
Function Volume Adjustment Metronome, Rhythm, Song
Other Functions
Transpose ±1 octave (–12 to 0 to +12 semitones)
Tuning A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
MIDI 16 multi-timbre received, GM Level 1 standard
Jacks
USB Port Micro-B
PHONES/OUTPUT jack Stereo mini jack (3.5mm)
AC adaptor terminal 9.5V DC
Power Requirements 2-Way Power
Batteries 6 AA-size alkaline batteries or AA-size rechargeable nickel metal hydride batteries
Continuous operation Approximately 16 hours (alkaline batteries), approximately 13 hours (rechargeable nickel
metal hydride batteries)*
Actual battery life may be shorter depending on battery type, performance style, or operation
environment.
AC Adaptor AD-E95100L (JEITA Standard, with unified polarity plug)
Auto Power Off After approximately 30 minutes of non-operation, Can be disabled.
Speakers 13cm × 6cm (oval) × 2 (Output: 2.0W + 2.0W)
Power Consumption 9.5V = 5.5W
Dimensions 93.0 (W) × 25.6 (D) × 7.3 (H) cm (36 5/8 × 10 1/16 × 2 7/8 inch)
Weight Approximately 3.3kg (7.3 lbs) (Excluding batteries)
Reference
EN-29
AC Adaptor Handling Precautions
Model: AD-E95100L
1. Read these instructions.
2. Keep these instructions on hand.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this product near water.
6. Clean only with a dry cloth.
7. Do not install near radiators, heat registers, stoves, or any other source of heat (including amplifiers).
8. Use only attachments and accessories specified by the manufacturer.
9. Refer all servicing to qualified service personnel. Servicing is required after any of the following occurs: when the product
is damaged, when the power supply cord or plug is damaged, when liquid is spilled into the product, when a foreign
object falls into the product, when the product is exposed to rain or moisture, when the product does not operate
normally, when the product is dropped.
10. Do not allow the product to be exposed to dripping or splashing liquid. Do not place any object containing liquid on the
product.
11. Do not allow the electrical load output to exceed the label rating.
12. Make sure the surrounding area is dry before plugging into a power source.
13. Make sure the product is oriented correctly.
14. Unplug the product during lightning storms or when you do not plan to use it for a long time.
15. Do not allow product ventilation openings to become blocked. Install the product in accordance with the manufacturer’s
instructions.
16. Take care the power cord is located where it will not be stepped upon or bent severely, particularly in locations close to
plugs and convenience receptacles, and in locations where it exits from the product.
17. The AC adaptor should be plugged into a power outlet as close to the product as possible to allow immediate
disconnection of the plug in case of emergency.
The symbol below is an alert indicating un-insulated hazardous voltage inside the product’s enclosure, which may be
sufficient to constitute the risk of electric shock to users.
’
The symbol below is an alert indicating the presence of important operating and maintenance (servicing) instructions in the
documentation that accompanies the product.
*
Reference
EN-30
*1 Keyboard Key Note Name
Tone List
Tone 1
No. *1 Tone Name
Program
Change
Bank
Select
MSB
MAIN TONE 1
1 C2 GRAND PIANO 000 000
2C{2 ELEC.PIANO 1 004 000
3 D2 DRAWBAR ORGAN 016 000
4E}2HARPSICHORD 006 000
5 E2 STRINGS 048 000
PIANO/E.PIANO
6 F2 HONKY-TONK 003 000
7F{2 ELEC.GRAND PIANO 002 000
8 G2 60’S E.PIANO 004 005
9A}2 CHORUS E.PIANO 004 009
10 A2 SYNTH-STR.E.PIANO 004 003
11 B}2 SYNTH-VOICE & E.PIANO 004 010
12 B2 CLAVI 007 000
CHROMATIC PERC.
13 C3 CELESTA 008 000
14 C{3 GLOCKENSPIEL 009 002
15 D3 MUSIC BOX 010 000
16 E}3VIBRAPHONE 011 000
17 E3 MARIMBA 012 000
18 F3 TUBULAR BELL 014 000
ORGAN
19 F{3 PERC.ORGAN 017 000
20 G3 ROCK ORGAN 018 000
21 A}3 CHAPEL ORGAN 019 008
22 A3 REED ORGAN 020 000
23 B}3 ACCORDION 021 000
24 B3 HARMONICA 022 000
25 C4 BANDONEON 023 000
GUITAR
26 C{4 NYLON STR.GUITAR 024 002
27 D4 STEEL STR.GUITAR 025 002
28 E}4 JAZZ GUITAR 026 002
29 E4 CLEAN GUITAR 027 002
30 F4 MUTE GUITAR 028 002
31 F{4 DISTORTION GUITAR 030 002
BASS
32 G4 ACOUSTIC BASS 032 002
33 A}4 FINGERED BASS 033 002
34 A4 PICKED BASS 034 002
35 B}4 FRETLESS BASS 035 002
36 B4 SAW SYNTH-BASS 038 002
37 C5 SQUARE SYNTH-BASS 039 002
STR/ORCHESTRA
38 C{5 VIOLIN 040 000
39 D5 VIOLA 041 000
40 E}5 CELLO 042 002
41 E5 CONTRABASS 043 002
42 F5 PIZZICATO STRINGS 045 000
43 F{5 HARP 046 000
44 G5 TIMPANI 047 000
ENSEMBLE
45 A}5 SYNTH-STRINGS 050 000
46 A5 CHOIR AAHS 052 000
47 B}5SYNTH-VOICE 054 000
48 B5 ORCHESTRA HIT 055 000
BRASS
49 C6 TRUMPET 056 000
50 C{6 TROMBONE 057 002
51 D6 TUBA 058 002
52 E}6 FRENCH HORN 060 000
53 E6 BRASS 061 000
54 F6 SYNTH-BRASS 062 000
REED
55 F{6 SOPRANO SAX 064 000
56 G6 ALTO SAX 065 000
57 A}6 TENOR SAX 066 001
58 A6 BARITONE SAX 067 002
59 B}6 OBOE 068 000
60 B6 CLARINET 071 000
PIPE
61 C7 PICCOLO 072 002
Tone 1
No. *1 Tone Name
Program
Change
Bank
Select
MSB
Reference
EN-31
*1 Keyboard Key Note Name
Tone 2
No. *1 Tone Name
Program
Change
Bank
Select
MSB
MAIN TONE 2
62 C2 BRIGHT PIANO 001 000
63 C{2 ELEC.PIANO 2 005 000
64 D2 PIPE ORGAN 019 000
65 E}2 HARPSICHORD & STRINGS 006 001
66 E2 SLOW STRINGS 049 000
PIPE
67 F2 FLUTE 073 000
68 F{2 RECORDER 074 000
69 G2 BOTTLE BLOW 076 000
70 A}2 WHISTLE 078 000
71 A2 OCARINA 079 000
SYNTH-LEAD
72 B}2 SQUARE LEAD 080 000
73 B2 SAW LEAD 081 000
74 C3 VOICE LEAD 085 000
75 C{3 FIFTH LEAD 086 000
76 D3 BASS+LEAD 087 000
77 E}3 DANCE SQUARE LEAD 080 048
78 E3 DANCE SYNC SQUARE LEAD 080 049
79 F3 DANCE SAW LEAD 081 048
80 F{3 DANCE SYNC SAW LEAD 081 049
81 G3 DANCE SAW BASS 087 048
SYNTH-PAD
82 A}3FANTASY 088 000
83 A3 WARM PAD 089 000
84 B}3 POLYSYNTH 090 000
85 B3 SPACE CHOIR 091 000
86 C4 METAL PAD 093 000
87 C{4 HALO PAD 094 000
88 D4 RAIN DROP 096 000
89 E}4 SOUND TRACK 097 000
90 E4 CRYSTAL 098 000
91 F4 ATMOSPHERE 099 000
92 F{4BRIGHTNESS 100 000
93 G4 SF 103 000
94 A}4 DANCE SAW PAD 090 048
95 A4 DANCE SQUARE PAD 090 049
INDIAN
96 B}4 SITAR 1 104 002
97 B4 SITAR 2 104 003
98 C5 TANPURA 1 104 032
99 C{5TANPURA 2 104 033
100 D5 HARMONIUM 1 020 032
101 E}5 HARMONIUM 2 020 033
102 E5 SHANAI 1 111 002
103 F5 SHANAI 2 111 003
104 F{5 SANTUR 1 015 003
105 G5 SANTUR 2 015 004
106 A}5 TABLA 116 016
ETHNIC
107 A5 BANJO 105 000
108 B}5SHAMISEN 106 000
109 B5 KOTO 107 000
110 C6 BAGPIPE 109 000
111 C{6 FIDDLE 110 000
VARIOUS
112 D6 TINKLE BELL 112 000
113 E}6 STEEL DRUMS 114 000
114 E6 SYNTH-DRUM 118 000
115 F6 STRINGS PIANO 000 008
116 F{6 BASS/PIANO 000 009
117 G6 SE 1 120 002
118 A}6 SE 2 122 002
DRUM SET
119 A6 STANDARD SET 000 120
120 B}6 DANCE SET 029 120
121 B6 BRUSH SET 040 120
122 C7 INDIAN SET 049 120
Tone 2
No. *1 Tone Name
Program
Change
Bank
Select
MSB
Reference
EN-32
•“” indicates a key is assigned the same tones as it is for STANDARD SET.
Drum Assignment List
STANDARD SET DANCE SET
C-1
D-1
E-1
F-1
G-1
A-1
B-1
C0
D0
E0
F0
G0
A0
B0
C1
D1
E1
F1
G1
A1
B1
C2
D2
E2
F2
G2
A2
B2
C3
D3
E3
F3
G3
A3
B3
C4
D4
E4
F4
G4
A4
B4
C5
D5
E5
F5
G5
A5
B5
C6
D6
E6
F6
G6
A6
B6
C7
D7
E7
F7
G7
A7
B7
C8
D8
E8
F8
G8
A8
B8
C9
D9
E9
F9
G9
C
-1
E
-1
F
-1
A
-1
B
-1
C
0
E
0
F
0
A
0
B
0
C
1
E
1
F
1
A
1
B
1
C
2
E
2
F
2
A
2
B
2
C
3
E
3
F
3
A
3
B
3
C
4
E
4
F
4
A
4
B
4
C
5
E
5
F
5
A
5
B
5
C
6
E
6
F
6
A
6
B
6
C
7
E
7
F
7
A
7
B
7
C
8
E
8
F
8
A
8
B
8
C
9
E
9
F
9
INDIAN SETBRUSH SET
DRUMS SET NAME
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
Standard Kick 1
Side Stick
Standard Snare 1
Standard Hand Clap
Standard Snare 2
Low Tom 2
Closed Hi-Hat
Low Tom 1
Pedal Hi-Hat
Mid Tom 2
Open Hi-Hat
Mid Tom 1
High Tom 2
Crash Cymbal 1
High Tom 1
Ride Cymbal 1
Chinese Cymbal
Ride Bell
Tambourine
Splash Cymbal
Cowbell
Crash Cymbal 2
Vibraslap
Ride Cymbal 2
High Bongo
Low Bongo
Mute High Conga
Open High Conga
Open Low Conga
High Timbale
Low Timbale
High Agogo
Low Agogo
Cabasa
Maracas
Short High Whistle
Long Low Whistle
Short Guiro
Long Guiro
Claves
High Wood Block
Low Wood Block
Mute Cuica
Open Cuica
Mute Triangle
Open Triangle
Shaker
Cheer Short
Cheer
Cheer Long
Cheer Fade Out
Explotion 1
Explotion 2
Synth Kick 1
Synth Snare 1
Synth Hand Clap
Synth Snare 2
Synth Low Tom 2
Synth Low Tom 1
Synth Mid Tom 2
Synth Mid Tom 1
Synth High Tom 2
Synth High Tom 1
Dance Kick 1
Dance Kick 2
Dance Q
Dance Snare 1
Dance Clap
Dance Snare 2
Hip-Hop Close Hat
Noise Rise
Hip-Hop Open Hat
Brush Kick 1
Brush Snare 1
Brush Slap
Brush Snare 2
Brush Low Tom 2
Brush Low Tom 1
Brush Mid Tom 2
Brush Mid Tom 1
Brush High Tom 2
Brush High Tom 1
Ta b l a G e
Ta b l a K a
Ta b l a Te
Ta b l a N a
Ta b l a Tu n
Key Note No.
Reference
EN-33
*1 Keyboard Key Note Name
Song List
No. *1 Title
PIANO/CLASSICS
1 C2 FÜR ELISE
2C{2 VALSE op.64 no.1 “PETIT CHIEN”
3 D2 TURKISH MARCH (MOZART)
4E}2 TRÄUMEREI
5 E2 ETUDE op.10 no.3 “CHANSON DE L’ADIEU”
6 F2 LIEBESTRÄUME no.3
7 F{2 NOCTURNE op.9 no.2 (CHOPIN)
8 G2 CANON (PACHELBEL)
9 A}2 MARY HAD A LITTLE LAMB
10 A2 LE CYGNE FROM “LE CARNAVAL DES ANIMAUX”
11 B}2 AIR FROM “SUITE no.3”
12 B2 SPRING FROM “THE FOUR SEASONS”
13 C3 HUNGARIAN DANCES no.5
14 C{3 MINUET IN G MAJOR
15 D3 GAVOTTE (GOSSEC)
16 E}3 ARABESQUE (BURGMÜLLER)
17 E3 DECK THE HALL
18 F3 ODE TO JOY
19 F{3 AVE MARIA (GOUNOD)
20 G3 PRELUDE op.28 no.7 (CHOPIN)
21 A}3 GOING HOME FROM “FROM THE NEW WORLD”
22 A3 SONATA op.27 no.2 “MOONLIGHT” 1st Mov.
23 B}3 THE ENTERTAINER
24 B3 FRÖHLICHER LANDMANN
25 C4 LA CHEVALERESQUE
26 C{4 JESUS BLEIBET MEINE FREUDE
27 D4 MARCH FROM “THE NUTCRACKER”
28 E}4 CHANSON DU TOREADOR FROM “CARMEN”
29 E4 INVENTIONEN no.1
30 F4 PRAELUDIUM no.1 (J.S.BACH)
EVENT
31 F{4 SILENT NIGHT
32 G4 JINGLE BELLS
33 A}4 WE WISH YOU A MERRY CHRISTMAS
34 A4 JOY TO THE WORLD
35 B}4 O CHRISTMAS TREE
WORLD
36 B4 WHEN THE SAINTS GO MARCHING IN
37 C5 GREENSLEEVES
38 C{5 ANNIE LAURIE
39 D5 AMAZING GRACE
40 E}5 TWINKLE TWINKLE LITTLE STAR
41 E5 GRANDFATHER’S CLOCK
42 F5 ON TOP OF OLD SMOKEY
43 F{5 COME BIRDS
44 G5 DID YOU EVER SEE A LASSIE?
45 A}5 DANNY BOY
46 A5 MY BONNIE
47 B}5 HOME SWEET HOME
48 B5 AURA LEE
49 C6 ALOHA OE
50 C{6 LONDON BRIDGE
51 D6 UNDER THE SPREADING CHESTNUT TREE
52 E}6 SIPPIN’ CIDER THROUGH A STRAW
53 E6 BEAUTIFUL DREAMER
54 F6 MY DARLING CLEMENTINE
55 F{6 LITTLE BROWN JUG
56 G6 YANKEE DOODLE
57 A}6 I’VE BEEN WORKING ON THE RAILROAD
58 A6 OH! SUSANNA
59 B}6 TURKEY IN THE STRAW
60 B6 FURUSATO
No. *1 Title
Reference
EN-34
*1 Keyboard Key Note Name
Rhythm List
No. *1 Rhythm name
8 BEAT
1 C2 STRAIGHT 8 BEAT
2C{28 BEAT
16 BEAT
3 D2 16 BEAT
4 E}2 16 BEAT SHUFFLE
BALLAD
5 E2 16 BEAT BALLAD
6 F2 POP BALLAD
7 F{2 6/8 BALLAD
DANCE
8 G2 DISCO POP
9A}2 MODERN R&B
POPS
10 A2 POP
11 B}2 POP ROCK
ROCK
12 B2 STRAIGHT ROCK
13 C3 SHUFFLE ROCK
14 C{3 SLOW ROCK
15 D3 ROCK WALTZ
JAZZ
16 E}3BIG BAND
17 E3 SLOW SWING
18 F3 JAZZ WALTZ
19 F{3 FOX TROT
EUROPEAN
20 G3 POLKA
21 A}3 WALTZ 1
22 A3 VIENNESE WALTZ
23 B}3TANGO
24 B3 MARCH
LATIN
25 C4 BOSSA NOVA
26 C{4 SAMBA
27 D4 MAMBO
28 E}4 SALSA
29 E4 REGGAE
30 F4 POP REGGAE
31 F{4 SKA
32 G4 CUMBIA
INDIAN
33 A}4 BHANGRA
34 A4 DADRA
35 B}4 GARBA
36 B4 KEHARWA
37 C5 TEEN TAAL
38 C{5 DANDIYA
39 D5 BHAJAN
40 E}5 INDIAN POP 1
41 E5 INDIAN POP 2
42 F5 QAWWALI
43 F{5 KERALA
44 G5 RAJASTHANI
WORLD
AMERICAN
45 A}5 COUNTRY BALLAD
46 A5 BLUEGRASS
47 B}5 DIXIE
48 B5 TEX-MEX
49 C6 FAST GOSPEL
50 C{6 HAWAIIAN
EASTERN EUROPEAN
51 D6 RUSSIAN CHANSON
ARABIC
52 E}6 ADANI
CHINESE
53 E6 JIANGNAN
54 F6 DONGBEIYANGGE
55 F{ 6 JINGJU
56 G6 HUANGMEIXI
57 A}6 MIAOZU
58 A6 XINJIANG
VARIOUS
59 B}6 STRING QUARTET
PIANO RHYTHMS
60 B6 ARPEGGIO
61 C7 WALTZ 2
No. *1 Rhythm name
Reference
EN-35
■ FINGERED 1, FINGERED 2 Chords
*1 With FINGERED 2, interpreted as Am7.
*2 With FINGERED 2, interpreted as Am7
b
5
.
*3 Inverted form not supported in some cases.
*4 These fingerings are special fingerings for Digital
Keyboard chord input, and so they are not suitable for
normal keyboard play.
■ FINGERED ON BASS, FULL RANGE CHORD
In addition to the chords that can be fingered with
FINGERED 1 and FINGERED 2, the chords below also are
recognized.
• With FINGERED ON BASS, the lowest note fingered is
interpreted as the base note. Inverted forms are not
supported.
• With FULL RANGE CHORD, when the lowest note fingered
is a certain distance from the neighboring note, the chord is
interpreted as a fraction chord.
• Unlike FINGERED 1, 2, and FINGERED ON BASS, FULL
RANGE CHORD requires pressing of at least three keys to
form a chord.
Fingering Guide
C
Cm
Cdim
Caug
*3
C
5
Csus4
*3
Csus2
*3
C7
CmM7
Cdim7
*3
C6
*1
*3
Cm6
*2
*3
CaugM7
CdimM7
Caug7
Cm7
*3
CM7
Cm7
5
*3
CM7
5
C7sus4
C7
5
*3
*4*4*4
*4
*4
*4
*4
Cmadd9
C69
*3
Cm69
*3
Cadd9
C
C
D
C
F
C
F
C
G
C
A
C
A
C
Gm
C
Am
C
B
m
C
Ddim
C
Fdim
C
FM7
C
A
M7
C
F
m7
5
C
Gdim
C
Adim
C
Bdim
C
A
7
C
F7
C
Fm7
C
B
C
C
m
C
Dm
C
Fm
C
zzzzz zz z z z
Bm
C
zz zz zz z
A
m
C
F
m
C
zzzzz zz
Gm7
C
A
add9
C
zz z z
G7
C
zz
C
dim
C
F
dim
C
A
dim
C
Reference
EN-36
*1 Root *2 Chord Type
• Since the chord input range is limited, this model may not support some of the chords shown above.
Chord Example List
*2
*1
M
m
dim
aug
sus4
sus2
7
m7
M7
m7
5
7
5
7sus4
add9
madd9
mM7
dim7
69
6
m6
FCC
/
(
D
)
D
(
D
)
/E
E
Reference
EN-37
*1 Root *2 Chord Type
• Since the chord input range is limited, this model may not support some of the chords shown above.
*2
*1
M
m
dim
aug
sus4
sus2
7
m7
M7
m7
5
7
5
7sus4
add9
madd9
mM7
dim7
69
6
m6
(
A
)
/B
BF
/
(
G
)
G
(
G
)
/A
A
Function Transmitted Recognized Remarks
Basic
Channel
1
1 - 16
1 - 16
1 - 16
Default
Changed
Note
Number
0 - 127
0 - 127
*
1
0 - 127
True voice
After
Touch
Control
Change
X
X
X
O
Pitch Bender
OX
Key’s
Ch’s
Velocity
O
9nH v = 1 - 127
X
9nH v = 0, 8nH v =
**
O 9nH v = 1 - 127
X 8nH v = 64
Note ON
Note OFF
Mode
Mode 3
X
Mode 3
X
Default
Messages
Altered
0
1
5
6, 38
7
10
11
64
65
66
Bank select
Modulation
Portamento Time
Data entry LSB/MSB
Volume
Pan
Expression
Hold 1
Portamento Switch
Sostenuto
Model: CT-S100 Version : 1.0
O
X
X
X
X
X
X
X
X
X
O
O
O
O
O
O
O
O
O
O
*
2
MIDI Implementation Chart
**: no relation
Program
Change
True #
Exclusive
O
*
2
O
*
2
System
Common
X
X
X
X
X
X
Song Pos
Song Sel
Tune
Aux
Messages
Remarks
X
O
X
O
X
X
O
O
X
O
O
X
All sound off
Reset all controller
Local ON/OFF
All notes OFF
Active Sense
System Reset
System
Real Time
X
X
X
X
Clock
Commands
67
71
72
73
74
84
91
100, 101
Soft pedal
Filter resonance
Release time
Attack time
Brightness
Portamento Control
Reverb send level
RPN LSB/MSB
Mode 1 : OMNI ON, POLY
Mode 3 : OMNI OFF, POLY
Mode 2 : OMNI ON, MONO
Mode 4 : OMNI OFF, MONO
O : Yes
X : No
X
X
O
X
X
X
X
X
O
O
O
O
O
O
O
O
*
2
OO
0 - 127
*1: Depends on tone.
*2: For details about RPN and system exclusive messages, see MIDI Implementation at
https://support.casio.com/global/en/emi/manual/CT-S100/
MA2001-B
