SmartPro LCD 120V 1000VA 500W Line-Interactive
UPS, AVR, Tower, USB, TEL/DSL/Coax Protection, 8
Outlets
MODEL NUMBER: SMART1000LCD
Description
The SMART1000LCD SmartPro LCD 120V, 1000VA/500W Line-Interactive Uninterruptible Power Supply provides battery backup and AC power protection
against blackouts, brownouts, power surges and line noise that can damage electronics or destroy data. Ideal for backing up your desktop computer or
audio/visual components, this line-interactive UPS switches to battery backup mode in milliseconds to keep your connected equipment running long enough to
save files and shut down safely with no data loss.
While all eight NEMA 5-15R outlets protect against surges, four outlets also provide up to 3 hours of UPS battery support for a DVR component, 60 minutes of
support for a basic desktop PC and LCD monitor, and 10 minutes of support at half load (250W).
Automatic voltage regulation (AVR) corrects undervoltages as low as 89V without using any battery power. EMI/RFI noise filtering improves your equipment’s
performance and prevents damage. A 1038-joule surge suppression rating protects your equipment from harmful power surges.
Space-saving NEMA 5-15P plug with 6-foot cord connects to any NEMA 5-15R socket and allows furniture to be placed flush against the wall. Large rotatable
LCD screen with dimmer shows real-time input voltage, overload, AVR and battery statuses at a glance. With Tripp Lite’s free PowerAlert software (available
via free web download), the SMART1000LCD enables safe unattended system shutdown and file saves in case of a prolonged power failure.
Features
Reliable Battery Backup
Provides 1000VA/500W high-performance power protection for desktop computers, audio/video components, media centers and other electronics
Supports basic desktop computer and LCD monitor up to 60 minutes or single DVR components up to 3 hours during power outage
Supports 50% load (250W) up to 10 minutes and full load (500W) up to 3 minutes
97% full-load efficiency rating saves money in energy costs
Audible alarm indicates loss of utility power or low battery
Optimized Outlets
Highlights
Supports a basic desktop PC up
to 60 min. during power outage
Features 8 protected outlets—4
battery-protected, 4 surge-only
Offers automatic voltage
regulation (AVR)
LCD screen reports real-time
UPS and power status
Plugs into any NEMA 5-15R
socket
Package Includes
SMART1000LCD SmartPro LCD
120V 1000VA/500W
Line-Interactive UPS
USB cable
Telephone cord
Owner’s Manual
1 / 5
4 NEMA 5-15R outlets deliver battery backup for devices that require constant power
All 8 outlets protect against surges or spikes that can harm equipment or data
Automatic Voltage Regulation (AVR)
Corrects undervoltages as low as 89V with a 14% boost without drawing battery backup power
Rotatable LCD Status Screen
Large LCD screen shows real-time input voltage, overload, AVR and battery statuses
Rotates for easy viewing in both horizontal and vertical installations
Dimmer switch controls brightness level
AC Line, Coaxial and Tel/DSL Surge Suppression
Surge suppression rating of 1038 joules protects connected equipment and data from harmful power surges
Tel/DSL RJ11 jacks and included cord protect standard dialup/DSL phone connection
2.2 Hz coaxial jacks protect CATV, broadband cable internet, satellite or broadcast antenna connections
EMI/RFI Line Noise Filtering
Removes electromagnetic and radio frequency interference that can disrupt or damage your equipment’s performance
USB Communication Port and Free PowerAlert Software
HID-compliant USB port integrates with built-in power management and auto-shutdown of Windows and Mac OS X
Works with Tripp Lite PowerAlert software available as free web download from www.tripplite.com/poweralert, to enable safe, unattended system
shutdown and file saves during prolonged power failure
Flexible Installation Options
Space-saving NEMA 5-15P right-angle plug with 6-foot cord connects to any NEMA 5-15R socket
Adapts to vertical or horizontal installation without special hardware
Specifications
OUTPUT
Output Volt Amp Capacity (VA) 1000
Output kVA Capacity (kVA) 1
Output Watt Capacity (Watts) 500
Nominal Output Voltage(s)
Supported
110V; 115V; 120V
Nominal Voltage Details 115v nominal output in battery mode
Frequency Compatibility 60 Hz
Output Voltage Regulation (Battery
Mode)
+/- 5%
Output Receptacles (8) 5-15R
2 / 5
UPS Output Receptacles (Surge
Suppression Only)
4 UPS outlets, 4 surge-only outlets
Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)
Output AC Waveform (AC Mode) Sine wave
Output AC Waveform (Battery Mode) PWM sine wave
INPUT
Rated input current (Maximum Load) 12A
Nominal Input Voltage(s) Supported 120V AC
UPS Input Connection Type 5-15P; Right-Angled
UPS Input Cord Length (ft.) 6
UPS Input Cord Length (m) 1.8
Recommended Electrical Service 15A 120V
Input Phase Single-Phase
BATTERY
Full Load Runtime (min.) 3 min. (500w)
Half Load Runtime (min.) 10 min. (250w)
DC System Voltage (VDC) 12
Battery Recharge Rate (Included
Batteries)
Less than 16 hours from 10% to 90%
Internal UPS Replacement Battery
Cartridge
RBC51
Battery Access Battery access door
Battery Replacement Description Hot-swappable, user replaceable batteries
Expandable Runtime No
VOLTAGE REGULATION
Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with input voltage as low as 89
Undervoltage Correction Input voltages between 89 and 104 are boosted by 14%
USER INTERFACE, ALERTS & CONTROLS
Front Panel LCD Display
Backlighted LCD screen indicates input voltage, 5-bar battery charge level, overload, AVR, on battery and replace
battery status; LCD screen rotates for rack/tower viewing
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; dimmer switch controls LCD brightness
Alarm Cancel Operation
Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate
low-battery status
Audible Alarm Audible alarm indicates power-failure and low-battery status; alarm can be disabled using PowerAlert software
LED Indicators Front panel LCD display
3 / 5
SURGE / NOISE SUPPRESSION
UPS AC Suppression Joule Rating 1038
UPS AC Suppression Response
Time
Instantaneous
UPS Dataline Suppression 1 line TEL/DSL (1 in / 1 out); Coax jacks (1 set)
EMI / RFI AC Noise Suppression Yes
PHYSICAL
Installation Form Factors Supported
with Included Accessories
Tower
Primary Form Factor Tower
UPS Power Module Dimensions
(hwd, in.)
11.84 x 3.66 x 7.24
UPS Power Module Dimensions
(hwd, cm)
30.1 x 9.3 x 18.4
UPS Power Module Weight (lbs.) 15.55
UPS Power Module Weight (kg) 7.05
UPS Shipping Dimensions (hwd / in.) 10.43 x 15.55 x 4.8
UPS Shipping Dimensions (hwd /
cm)
26.5 x 39.5 x 12.2
Shipping Weight (lbs.) 16.2
Shipping Weight (kg) 7.4
UPS Housing Material ABS
Primary UPS Height (mm) 301
Primary UPS Width (mm) 93
Primary UPS Depth (mm) 184
Shipping Height (mm) 265
Shipping Width (mm) 395
Shipping Depth (mm) 122
ENVIRONMENTAL
Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC Mode BTU / Hr. (Full Load) 61
Battery Mode BTU / Hr. (Full Load) 510
AC Mode Efficiency Rating (100%
Load)
97%
4 / 5
COMMUNICATIONS
Communications Interface USB (HID enabled)
PowerAlert Software
For local monitoring via the UPS’s built-in USB port, download PowerAlert Local software at
http://www.tripplite.com/poweralert
Communications Cable USB cable included
WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
Network UPS Tools Compatibility
NUT compatible. See the full list of Tripp Lite NUT compatible UPS systems at
http://www.networkupstools.org/stable-hcl.html?manufacturer=Tripp Lite
LINE / BATTERY TRANSFER
Transfer Time 3 milliseconds
Low Voltage Transfer to Battery
Power (Setpoint)
89
High Voltage Transfer to Battery
Power (Setpoint)
139
SPECIAL FEATURES
Cold Start (Startup in Battery Mode
During a Power Failure)
Cold-start operation supported
Green Energy-Saving Features Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category B (EMI)
WARRANTY
Product Warranty Period (U.S. &
Canada)
3-year limited warranty
Product Warranty Period (Latin
America)
3-year limited warranty
Product Warranty Period
(International)
2-year limited warranty
Product Warranty Period (Mexico) 3-year limited warranty
Connected Equipment Insurance
(U.S., Canada & Puerto Rico)
$250,000
Ultimate Lifetime Insurance
