INSTALLATION AND USER INSTRUCTION GUIDE
820-174
Please read all instructions carefully andretain for future reference
IMPORTANT INSTRUCTIONS
PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS HEATER.
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND PERSONAL
INJURY, INCLUDING THE FOLLOWING:
When switching on the appliance for the first time, allow it to run at full power for
about two hours to get rid of the unpleasant smell. Make sure that the room in which
the appliance is located is well ventilated during this operation. It is normal for the
appliance to emit small cracking sounds when you turn it on if the first time.
Security Advice
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces.
Use handle when moving the unit. Keep flammable materials such as furniture,
pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front
and top of the heater and keep them away from the sides and rear of the heater. Keep
the rear grille away from walls or drapes so as not to block the air intake.
3. Extreme caution and supervision is necessary when any heater is used near children
or invalids and whenever the heater is left operating and unattended.
4. Always unplug heater when not in use.
5. Do not use any heater with a damaged cord or plug or after the heater malfunctions or
has been dropped or damaged in any manner. Discard heater or return to an
authorized service facility for examination and/or repair.
6. Do not use outdoors.
7. This heater is not intended for use in bathrooms, laundry areas or other similar indoor
locations. Never locate heater where it may fall into a bathtub or other water
container.
8. Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or appliances. Arrange cord away from
traffic areas and place it where it will not be tripped over.
9. To disconnect heater, turn controls to off, then remove plug from outlet.
10. This appliance has a polarized plug (one blade is wider than the other). This plug is
intended to fit a polarized outlet only one way. If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit, consult a qualified electrician. Do not connect
the heater to extension cords, surge protectors, timers, direct breakers, or an outlet
with other appliances connected to the same outlet. Risk of fire, overheat,
malfunction, property damage, injury, or even death may result if not adhered
to!
11. Connect to properly polarized outlets only.
12. Do not insert or allow foreign objects to enter ventilation or exhaust openings, as this
may cause an electric shock or fire, or damage the heater.
13. To prevent a possible fire, do not block air intakes or exhaust in any manner. Do not
use on soft surfaces, like a bed, where openings may become blocked.
14. A heater has hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or flammable liquids are used or stored.
15. Use this heater only as described in this manual. Any other use not recommended by
the manufacturer may cause fire, electric shock, injury to persons or other damage to
property.
16.This heater must be plugged into a 120V, 15 amp (or more) circuit of its own. Nothing
else can be plugged into the same circuit. If unsure if you home meets this
specification, consult a certified electrician prior to use. Risk of fire, overheat,
malfunction, property damage, injury, or even death may result if not adhered
to!
17.To prevent overload and blown fuses, be sure that no other appliance is plugged into
the same outlet or into another outlet wired into the same circuit.
18.It is normal for the heater's plug and cord to feel warm to the touch. A plug or cord that
becomes hot to the touch or becomes distorted in shape may be a result of a worn
electrical outlet. Worn outlets or receptacles should be replaced prior to further use
of the heater. Plugging heater into a worn outlet/receptacle may result in overheating
of the power cord or fire.
19.Ensure the heater is on a stable, secure surface to eliminate the potential of tipping
over.
20. Always plug heaters directly into a wall outlet/receptacle. Never use with an 21. Be
sure that the plug is fully inserted into appropriate receptacle. Please remember that
receptacles also deteriorate due to aging and continuous use: check periodically for
signs of overheating or deformations evidenced by the plug. Do not use the
receptacle and CALL your electrician.
21.Be sure that the plug is fully inserted into appropriate receptacle. Please remember
that receptacles also deteriorate due to aging and continuous use: check periodically
for signs of overheating or deformations evidenced by the plug. Do not use the
receptacle and CALL your electrician.
22.Check that neither the appliance nor the power cable has been damaged in any way
during transportation.
23.Make sure that no pieces of polystyrene or other packaging material have been left
between elements of the appliance. It may be necessary to pass over the appliance
with a vacuum cleaner.
24.This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be supervised to ensure that they
do not play with the appliance.
CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.
ATTACHING THE LEGS
1. Turn product on its side to start attaching legs.
2. Place a leg on each corner and use 3 screws for each leg.
3. Tighten the screws clockwise until tight on each leg.
4. Turn the unit back up to standing position making sure it is stable.
5. Place the unit in the required location and plug in, it is now ready for use.
NOTE: The drawing below is for illustration purposes only, your product may be slightly
different in looks but the operations are the same.
Parts List:
Electric heater*1
User manual*1
Legs*4
Screws*12
1. Thermostat control knob (TEMPERATURE SETTING)-Adjust to maintain room
temperature
2. Flame switch - Switches flame effect and power on/off
3. Heating setting: please press “ ” for 750W
4. Heating setting : please press “ ” and “ ” at the same time for 1500W(can not operate
without first press “ ”)
5. Flame dimmer control - Adjust to set flame intensity
User Guide:
Location of Controls
Overheating safe device
If the heater stops working, turn the heater off and inspect the blockage of inlet or outlet.
Disconnect the plug and wait at least 10 minutes for the protection system to reset
before attempting to restart the heater. If the safe device still switches the heater off and
makes the heater fail to operate, take the heater to your nearest service center for
examination or repair.
Attention: before restarting the heater, the plug must be disconnected for at least 10
minutes
Cleaning
1. Always disconnect the appliance from the main supply before cleaning.
2. Clean the outside of the heater by wiping with a damp or dry cloth.
3. Do not use petroleum, any other detergent or chemical solvent to clean the heater.
4. When the heater is not used for a long time, it should be protected from dust and stored
in a clean dry place.
Disposal
Environmental Protection
Waste electrical production should not be disposed of with household waste.
Please recycle where facilities exist. Check with your Local Authority or
retailer for recycling advice.
Fireplace Heaters
Model Voltage Frequency Power
YH-20-1A 120V 60Hz 1500W
