3. What’s in the Box?
FOLDING
PLATFORM
TROLLEY
04692 – FRT300 ASSEMBLY INSTRUCTIONS
Read this manual in full before using this product and retain it for future use.
Always use the latest version of the manual. For the latest version of this
manual please visit drapertools.com/manuals
1. Specication
Stock No. 04692
Part No. FRT300
Max. static load: 300kg
Max. dynamic load: 200kg approx.
Wheel diameter: 127mm
Dimensions: L 910 x W 610 x H 870mmm
Net weight: 12.5kg
2. Health and Safety Information
Important: Read these instructions before attempting to assemble, use or
maintain this product. Non-compliance may result in injury or damage to the
user, the product or the load.
• Keep your work area well lit, with bystanders at a safe distance.
• Assemble this product only in the manner depicted and do not modify the
product in any way.
EN
Original Instructions
Version 1 – January 2023
• Before every use, inspect the trolley for broken or cracked parts and
loose xtures.
• Only use this product on rm, level surfaces capable of supporting both
the trolley and its load.
− DO NOT use this product on sloped or slippery surfaces.
− Where available, use ramps to mount kerbs and other raised edges.
• DO NOT ride on or allow others to ride on this product.
• DO NOT exceed the maximum rated capacities of this product.
• When in use, ensure that the load is distributed evenly and that the trolley
is not overbalanced.
− Be mindful of changes to the weight distribution when loading
and unloading.
• ALWAYS ensure that the heaviest part of the load is at against the
trolley platform.
• Ensure that the load is stable and secure before transporting it.
• Manoeuvre the product using the handle ONLY and maintain full control
of the trolley at all times.
− This product is intended to be pushed; only pull if
absolutely necessary.
• Plan your route and ensure that the castors are not obstructed before
moving the trolley.
• DO NOT leave the trolley unattended while under load.
(C)(B)
(D)
(A)
(E)
A. 1 x Trolley platform
B. 2 x Swivel castors
C. 2 x Fixed castors
D. 16 x M10 x 15mm hex bolts
E. 16 x M10 spring washers
Carefully remove the product from the packaging and examine it for any
signs of damage that may have occurred during shipment.
Before assembling the product, lay the contents out and check them against
the parts shown below. If any part is damaged or missing, do not attempt to
use the product. Please contact the Draper Helpline; contact details can be
found at the back of this manual.
Please visit drapertools.com for our full range of accessories
and consumables.
Keep the product packaging for the duration of the warranty period in
case the product needs to be returned for repair.
WARNING! Keep packaging materials out of reach of children.
Dispose of packaging correctly and responsibly and in accordance
with local regulations.
WARNING! DO NOT use this product if its structural integrity
is compromised. Tighten, replace or repair all aected parts
before use.
