1
Wall Button Wire
Photocell wire
Power Pack
Aladdin Connect™
Control Wire
Quick Set-up Guide
DCM
(Door Control Module)
DPS
(Door Position Sensor)
Hardware Bag
Power Pack
Wire Spool
Insulated
Staple x30
Included Components
Recommended Tools
Drill & 3/32 Bit
Small Common
Screwdriver
Phillips Head
Screwdriver
Wire Cutters/
Strippers
Hammer
5/16 Wrench or
Nut Driver
For a video of this installation, visit www.GenieCompany.com/AladdinConnect/InstallationVideo
Need help or have questions? Contact Aladdin Connect™ Customer Service at 1-866-599-4995
Typical Installation shown.
Installations may vary
Scan for the
Aladdin Connect™
installation video
Scan here for additional
Aladdin Connect™
information
39386503197 03/16
