05
06
01
02
03
04
1、Insert the casters into the base leg 2、Insert the cylinder into the middle of
the base
6、Fasten the tilt mechanism and seat
cushion with screw A like the picture
show
7、 Fasten the arm with screw A 8、Insert the assembled cylinder into
the base hole
4、 Put the backrest like picture show
and fasten the it with screw A
9、Assemble the lumbar pillow as the
picture show
1
3
6
7
4
5
2
Screws Ax16
Base
Armrest
Casters
gas lift cover
headrest
Lumbar pillow
Cylinder
Screws Bx2
A
B
C
Allen wrench Cx1
HDJY001BMJ/CB
HDJY001BM/CB
HDJY001WM/CB
HDJY001GM/CB
A
B
C
1
3
6
7
4
5
2
8
9
10
11
10
Backrest
9
8
Tilt mechanism
Cover of the recliner adjuster
11
Seat cushion
3、Put on the cylinder cover as the
picture show
5、Put the cover of the recline adjuster
as the picture show, fasten it with
screw B
HDJY001GMJ/CB
Height adjust
Pull up the first lever in your right when the chair is empty.
then the chair will be raised up.
Pull down the same lever when you are in the chair. it will
be lowered down.
Rocking Style
Pull out the lever to start rock, push the same lever in to
stop it.
Recline function
When you are sitting in the chair, recline forward and pull
the right lever under the seat cushion. Then you can
recline. When it reclines to the proper angle, stop pulling
the lever, the angle will be locked. If you need to re-set
the chair to 90° angle, continue pull up the same lever
and sit straight, the chair back will back to 90°.
User manual
