INSTALLATION INSTRUCTIONS
69-2518-03
HE220, HE260 Humidifier
Installation Kit
WELCOME
To the comfortable world of humidified air. When you use
your Honeywell humidifier, you notice that your skin is not
as dry, and that your scratchy throat and irritated nasal
passages that aggravate allergies and asthma are
steadily improving.
You have also taken the first step in reducing the zapping
you create when you walk on your carpet and then touch
your TV, computer, metal door knob or your pet. Your
furniture and woodwork are also benefitting from the
difference that humidified air makes.
Congratulations! You have just made a great investment
in improving the comfort of your home.
APPLICATION
This installation kit contains all the parts necessary to
install your new Honeywell HE220 or HE260 Humidifier.
INSTALLATION
Preparing for the Installation
Be sure to identify all the required (Table 1) accessories
(included) and make sure the appropriate tools are
available before beginning the installation.
Required Accessories (Included)
Table 1. Required Accessories.
Quantity Accessory
Humidifier Parts and Accessories
3 ft
(0.93 m)
Bypass ducting including:
6 in. (155 mm) diameter flexible duct
Starter collar
Summer shut-off damper
Duct tape
20 ft
(6.2m)
18 gauge, two-strand thermostat wire
20 ft
(6.2m)
1/4 in. (6.35 mm) OD feed water tubing
10 ft
(3.1m)
1/2 in (12.7 mm) ID drain tubing
1 bag Connecting and mounting hardware:
Wire nuts (4)
No. 8 sheet metal screws (18)
Drain tube clamps (2 sizes)
Feed tube mounting clamps (6)
Brass inserts (2)
Plastic compression rings (2)
1 Plug-in transformer
