6. Installing the Display
INSTALLATION MANUAL
LCD Ceiling Mount
PCTVM15
42"
MAX
75x75 100x100
200x100/200x200
/
30kg
(66lbs)
RATED
30kg
(66lbs)
RATED
7. Adjustment
Use the tilt adjusting knob to adjust your display to the desired angle then tighten it.
Maintenance
• Check that the bracket is secure and safe to use at regular intervals(at least every three months).
• Please contact your dealer if you have any questions.
Tighten all screws but do not over tighten.
Lift the display and match the holes on your display with the holes on the mount. Secure your display to
the mount by tightening screws.
Note: Choose the appropriate screws, washers and spacers (if necessary) according to the type of screen.
TV
TV
TVTV
7
CAU T ION: DO NOT EXCEED
RATED LISTED WEIGHT. SERIOUS
INJURY OR PROPERTY DAMAGE
MAY OCCUR!
