Ilnstallat!on
nstruct=ons
Built-In Wall Oven
27" (68.6 cm) models
JKS10, JKP30, JKP35, JKP55, JKP70, JKP75,
PK916, PK956, ZEK938, ZEK958
30" (76.2 cm) models
JTP30, JTP35, JTP55, JTP70, JTP75, PT916,
PT920, PT956, PT960, ZET938, ZET958
If you have questions, call 1.800.GE.CARES or visit our website at:
ge.com
Before You Begin
Read these instructions carefully and completely.
• IMPORTANT-save these
instructions for local inspector's use.
•IMPORTANT-observe all
governing codes and ordinances.
•Note to Installer--Be sure to leave these
instructions with the consumer.
•Note to Consumer--Keep these
instructions for future reference.
•Proper installation is the responsibility
of the installer and product failure due
to improper installation is NOT covered
under warranty.
•NOTE--This appliance must be properly
grounded.
•ATTENTION INSTALLER
All electric wall ovens must be hard wired
(direct wired) into an approved junction
box. A plug and receptacle is NOT permitted
on these products.
Parts Included
(Appearance will vary)
Screws For Installation
(8-18 x .750 flat head
Phillips wood screws)
WB07T10578 - Black
WB07T10579 - SS
Optional 27" (68.6 cm)
Metal Bottom Trim Assembly
(on some models or can be
purchased separately)
27" (68.6 cm)
Metal Bottom Trim
30" (76.2 cm)
Metal Bottom Trim
Assembly
Materials Needed
Strain Relief Clamp Junction
for 1/2" conduit Box
Wire Nuts
36" (91 cm)
of String
Tools Needed
1/8" (3 mm) Drill Bit and
Electric or Hand Drill Phillips
Screwdriver
31-10647-3 11-07JR
