EN FRENCH DOOR BOTTOM
FREEZER/REFRIGERATOR
FR RÉFRIGÉRATEUR À PORTES
FRANÇAISES/CONGÉLATEUR EN BAS
ES REFRIGERADOR CON CONGELA-
DOR INFERIOR DE PUERTA DOBLE
A05963204 June 2018
USE AND CARE GUIDE
GUIDE D’UTILISATION ET D’ENTRETIEN
GUIA DE USO Y CUIDADO
2
Finding Information
Please read and save
this guide
Thank you for choosing Electrolux, our
new premium brand in home appliances.
This Use & Care Guide is part of our
commitment to customer satisfaction and
product quality throughout the service life
of your new appliance.
Purchase date
Electrolux model number
Electrolux serial number
Keep a record for quick
reference
Table of contents
Questions?
For toll-free telephone support in the U.S.
and Canada: 1-877-4ELECTROLUX
(1-877-435-3287)
For online support and product information
visit http://www.electroluxicon.com
NOTE
Registering your product with Electrolux
enhances our ability to serve you. You
can register online at
www.electroluxappliances.com or by
sending your Product Registration Card
in the mail.
Doors
Handles are secure and tight
Door seals completely to cabinet on
all sides
Leveling
Refrigerator is level side-to-side and
slightly elevated in front to assist with
door and drawer closing (front should
be higher than back)
Toe grille is properly attached to
refrigerator
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to
refrigerator
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser operates
correctly
Final Checks
Shipping material removed
Fresh food and freezer temperatures
set
Crisper humidity controls set
Registration card sent in
Installation Checklist
Finding Information ................................. 2
Safety ..................................................... 3
Feature Overview .................................... 5
Installation .............................................. 6
Removing the Doors ............................. 11
Installing Door Handles ......................... 15
Connecting the Water Supply ............... 16
Controls ................................................ 18
Automatic Ice Maker & Water Dispenser ... 23
Automatic Ice Maker - Freezer .............. 25
Storage Features .................................. 27
Storing Food and Saving Energy .......... 32
Normal Operating Sounds .................... 33
Changing The Water and Air Filters ....... 34
Care and Cleaning ................................ 36
Solutions to Common Problems ........... 38
Warranty ............................................... 43
3
Safety
Important safety instructions
General Safety
Safety Precautions
Do not attempt to install or operate your unit
until you have read the safety precautions
in this manual. Safety items throughout this
manual are labeled with a Danger, Warning,
or Caution based on the risk type.
Definitions
This is the safety alert symbol. It is
used to alert you to potential personal injury
hazards. Obey all safety messages that follow
this symbol to avoid possible injury or death.
• Do not store or use gasoline or other
flammable liquids near this or any
other appliance. Read product labels
for warnings regarding flammability
and other hazards.
• Do not operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts
of the automatic ice maker.
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
IMPORTANT
Indicates installation, operation, or
maintenance information which is
important but not hazard-related.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
WARNING
Please read all safety instructions before
using your new refrigerator.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
• Remove all staples from the carton to
avoid injury. Staples can also damage
finishes if they come in contact with
other appliances or furniture.
Child Safety
Packing Materials:
• Packing cartons covered with rugs,
bedspreads, plastic sheets, or stretch
wrap may become airtight chambers
and can quickly cause suffocation.
• Destroy or recycle the product’s carton,
plastic bags, and any other exterior
wrapping material immediately after
the refrigerator is unpacked. Children
should never play with these items.
Child Entrapment and Suffocation:
• These problems are not limited to the
past. Whether junked, abandoned,
or temporarily stored (even for a few
hours), unattended refrigerators and
freezers are dangerous. Please take
the precautions listed below.
Proper Disposal of
Refrigerators/Freezers
We strongly encourage responsible
appliance recycling/disposal methods.
Check with your utility company or visit
www.energystar.gov/recycle for more
information on recycling your old refrigerator.
Before you recycle or dispose of your old
refrigerator/freezer:
• Remove the doors.
• Leave the shelves and baskets in place
so children may not easily climb inside.
• Have refrigerant and compressor oil
removed by a qualified service technician.
4
• The refrigerator must be plugged into
its own dedicated 115 Volt, 60 Hz,
AC-only non-GFCI electric outlet.
The power cord of the appliance
is equipped with a three-prong
grounding plug for your protection
against electrical shock hazards.
It must be plugged directly into
a properly grounded three-prong
receptacle. The receptacle must be
installed in accordance with local
codes and ordinances. Consult a
qualified electrician. Do not use an
extension cord or adapter plug.
• If the power cord is damaged,
it should be replaced by the
manufacturer, service technician, or a
qualified person.
• Never unplug the refrigerator by pulling
on the power cord. Always grip the
plug firmly and pull straight out from
the receptacle to prevent damaging
the power cord.
• To avoid electrical shock, unplug the
refrigerator before cleaning and before
replacing a light bulb or LED light.
• Performance may be affected if
the voltage varies by 10% or more.
Operating the refrigerator with
insufficient power can damage the
compressor. Such damage is not
covered under your warranty.
• Do not plug the unit into an outlet
controlled by a wall switch or pull cord
to prevent the refrigerator from being
turned off accidentally.
Electrical information
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Safety
WARNING
You must follow these guidelines to
ensure that your refrigerator’s safety
mechanisms are operating correctly.
IMPORTANT
To turn off power to your refrigerator,
unplug the power cord from the wall
outlet.
5
Feature Overview
Understanding features and terms
Your Electrolux refrigerator is designed for optimal convenience and storage flexibility.
The illustration below is provided to assist you with familiarizing yourself with product
features and terminology.
NOTE
*Features may vary according to model. Model is shown without freezer drawer cover.
IMPORTANT
Features not included with your
refrigerator can be purchased at
www.electroluxicon.com or by calling
1-877-435-3287.
*Luxury-Design
®
Glass Shelves
*Removable
Ice Bin
Freezer Baskets
with organizers
Toe Grille
Tilt Can Bin
Flipper Mullion
Air Filter
LED
Light
Flipper
Guide
*Ice
Maker
*Ice Bin
*Freezer Ice
Maker
Water
Filter
Luxury-Glide
®
Crisper Drawers
Luxury-Glide
®
Crisper Drawers
*Luxury-Design
®
Glass Shelves
*Custom Temp
TM
Drawer
(CTD) or Deli Drawer
(with humidity slides)
*Special
Items Rack
(inside CTD)
*Wire Shelf
(inside freezer drawer)
6
Installation
This Use & Care Guide provides general
installation and operating instructions
for your model. We recommend using a
service or kitchen contracting professional
to install your refrigerator. Use the
refrigerator only as instructed in this Use &
Care Guide. Before starting the refrigerator,
follow these important first steps.
Top Hinge
Cover Front
Screw
Top Hinge
Cover Rear
Screw
Lower
Hinge
Screw
Top
Hinge
Screw
Components Provided:
Required Tools
You will need the following tools:
CAUTION
DO NOT install the refrigerator where
the temperature will drop below 55°F
(13°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside the
refrigerator.
DO NOT block the toe grille on the lower
front of your refrigerator. Sufficient air
circulation is essential for the proper
operation of your refrigerator.
Tools Necessary:
Phillips Head
or
Quadrex Head
Screwdriver
(OR)
OR
⅜" and ¼"
Socket
Wrench
Adjustable
Wrench
OR
⅜"
Fixed
Wrench
ANDAND
6mm
Allen Wrench
Location
• Choose a place that is near a
grounded, non-GFCI, electrical outlet.
Do Not use an extension cord or an
adapter plug.
• If possible, place the refrigerator out
of direct sunlight and away from the
range, dishwasher, or other heat
sources.
• The refrigerator must be installed on a
floor that is level and strong enough to
support a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic
ice maker.
7
Installation
Installation
• Allow the following clearances for ease
of installation, proper air circulation,
and plumbing and electrical
connections:
Sides & Top 3/8 inch (9.5 mm)
Back 1 inch (25.4 mm)
Your refrigerator should be positioned
to allow easy access to a counter when
removing food. For best use of refrigerator
drawers and freezer baskets, the
refrigerator should be in a position where
both can be fully opened.
NOTE
If your refrigerator is placed with the
door hinge against a wall, you may have
to allow additional space so the door
can be opened wider.
NOTE
The refrigerator doors are designed to
shut by themselves within a 45 degree
opening.
Cabinet Leveling &
Refrigerator Door Align-
ment (if necessary)
Guidelines for final positioning of your
refrigerator:
• All four corners of the cabinet must
rest firmly on the floor.
• The front should be slightly elevated
to ensure that doors close and seal
properly.
• Doors should align with each other
and be level.
Most of these conditions can be met by
raising or lowering the adjustable front
rollers.
To level the cabinet using the front rollers:
1 Slightly open freezer drawer if the toe
grill is installed. Lift the toe grille and
gently pull forward.
2 Make initial cabinet adjustments by
using the front roller height adjusting
screws. Use a 3/8 inch socket
wrench to turn the adjustment
screws (1 per side).
To raise: turn adjustment screw
clockwise.
To lower: turn adjustment screw
counterclockwise.
DO NOT
Loosen
or
Remove
These 3
Hex
Screws
CAUTION
Do Not loosen or remove these 3 hex screws.
Raise
Lower
Anti-tip
Leg
Door opening
8
Installation
Screw
Flipper
Mullion
Hinge
Flipper
Mullion
Adjusting Flipper Mullion Screw
To adjust the flipper mullion:
1 Loosen the screw located on the
flipper mullion hinge.
2 Adjust flipper mullion height. For
proper connection with the flipper
mullion guide, there should be a
separation about the thickness of
a coin (0.060 inches, or 1.5 mm)
between the guide and flipper
mullion.
3 Re-tighten screw.
Flipper
Mullion
Mullion
Guide
Thickness
of a Coin
Adjusting Flipper Mullion Height
Installing Shelves (select
models)
Your refrigerator was shipped with the
shelf hanger and glass shelves in a
shipping pack. Below are the instructions
to install and remove the shelves in your
desired locations.
1 Place top hooks of the hanger into
the desired slot, and lower straight
down until lower hooks rest on the
ladder.
Raise
1. Open freezer drawer to make lower
hinge visible.
2. Insert 6mm Allen wrench into the
shaft of the lower hinge.
3. Adjust the height by turning clockwise
or counterclockwise. Turning
clockwise will lower the door. Turning
counterclockwise will raise the door.
Default setting is to the lowest height
when you receive your appliance.
To make final door height adjustments:
Toe Grille Must
Fit in Slot on
Anti-tip Bracket
Screw/Washer
Assembly
(2) Retaining Clips
3 Ensure both doors are bind-free with
their seals touching the cabinet on all
four sides and that cabinet is stable.
4 After unit is leveled, lower anti-tip leg
using a 3/8 inch socket wrench until
it firmly contacts the floor.
5 Install the toe grille by fitting into place.
Door
Door
9
Installation
3 While holding shelf at a 45-degree
angle with the gray handle facing
you, push the shelf into the back of
the hanger.
CAUTION
Shelves must be removed prior to
moving the refrigerator.
4 Gently set the shelf onto the hanger
once the back is secured by the hanger.
5 Remove shelf from its locked position
by pulling the slide mechanism
toward you.
6 Lift the hanger directly upwards and pull
toward you to remove it from the ladder.
Reposition the Air Seal
(select models)
1 Remove air seal by pushing seal
straight back.
2 Position the air seal towards the
outside edge of the shelf to avoid the
air tower when shelf is pushed back
into place.
3 Install seal by sliding the open
channel end of the seal onto back
edge of shelf until seal sits snug on
back of shelf and flap sits at about a
10 degree angle from shelf surface.
Air Seal
Air Seal
2 Relock shelf by pushing the slide
mechanism away from you.
10
Reposition the Air Seal
(select models)
Your refrigerator includes glass shelves that are
designed to catch and hold accidental spills.
You can easily adjust shelf positions in
the fresh food compartments to suit
your needs. The shelves have mounting
brackets that attach to slotted supports at
the rear of each compartment.
To change the position of a shelf:
1 Before adjusting a shelf, remove all food.
2 Lift the front edge up and pull the shelf out.
3 Replace by inserting the mounting bracket
hooks into the desired support slots.
4 Lower the shelf and lock into position.
CAUTION
To avoid injury from breakage, handle
tempered glass shelves carefully.
NOTE
Features may vary according to model.
Shelf features (select models)
Full Luxury-Design
TM
Shelf (varies by model)
For slide-out shelves:
1 Remove air seal by pushing down on
the flap with a downward rotation.
2 Position the air seal towards the outside
end of the shelf to avoid the air tower
when shelf is pushed back into place.
3 Install seal by sliding lower tab of seal
up into bottom rear slot of shelf with
seal at a downward angle then pulling
up on seal flap until seal sits snug on
back of shelf and flap sits at about a
10 degree angle from shelf surface.
Installation
11
Removing the Doors
2 Disconnect the harness by grasping
both sides of the connector firmly,
depress the latch and pull apart.
Getting through narrow
spaces
If your refrigerator will not fit through an
entrance area, you can remove the doors.
Check first by measuring the entrance.
To prepare for removing the doors:
1 Make sure the electrical power cord
is unplugged from the wall outlet.
2 Open the freezer drawer and remove
the toe grille (see Installation section).
3 Remove any food from the door
shelves and close the doors.
To remove the top hinge covers:
1 Remove the two screws from each
cover over the top door hinges.
2 Lift inside edge of hinge cover and tilt
back.
Rear
Cover
Screw
Ground
Screw
Top
Hinge
Top Hinge
Cover
Hinge
Screws
Multi-wire
Cables
Leave
Hinge
With
Door
Front
Cover Screw
Water
Line
Left Door
Rear
Cover
Screw
Top
Hinge
Ground
Screw
Front
Cover Screw
Top Hinge
Cover
Hinge
Screws
Leave
Hinge
With
Door
Right Door
To remove the refrigerator doors
NOTE
DO NOT remove the ground screw from
hinge.
WARNING
Make sure the electrical power cord is
unplugged from the wall outlet.
1 Remove top hinge covers. Trace
lightly around the door’s top
hinges with a pencil. This makes
reinstallation easier.
12
Removing the Doors
4 Open the refrigerator doors to a 90
degree angle and remove the two
screws from the top hinge. Lift and
remove door from lower hinge.
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury, or damage to the
doors or handles.
5 Unscrew the three lower hinge
screws and remove the hinge.
IMPORTANT
Open the refrigerator doors to a 90
degree angle before lifting the doors
off the bottom hinges and setting them
aside.
Lower Hinge Removal
Water
Line
Water
Line
Press
Press
3 Detach the water tube from the
connector located behind the
refrigerator, the connector releases
when you press inward on the
connector’s outer sleeve. Pull the
water tube out toward the front of the
unit.
NOTE
Use care while pulling the water tube
from the unit to be sure that you do not
kink the tube.
NOTE
You will be pulling approximately five
feet of water tube from the back of the
refrigerator.
90˚
Top View
Cabinet
Left Door
Right Door
Top View
of
Cabinet
13Removing the Doors
NOTE
When reinserting the water tube and
replacing the top hinge cover, use care
to be sure you do not kink the tube.
NOTE
Upon replacement, the tube needs to be
fully inserted up to the marking line.
To reinstall the refrigerator
doors:
Water
Line
Water
Line
Insert
tube up
to the
marking
line
Press
Press
Bottom of the Doors
For
RIGHT DOOR,
turn pin 90˚
counter-
clockwise
For
LEFT DOOR,
turn pin 90˚
clockwise
IMPORTANT
When replacing the doors on the lower
hinge, they must be installed at a 90
degree angle.
1 Replace the lower hinge screws.
2 Holding the door at a 90 degree
angle, drop the pin down into the
center hinge opening. Rotate it
slightly in either direction until the
door falls down into place.
5 Reconnect the harnesses.
6 Replace the top hinge covers.
7 Reconnect electrical power cord to
the wall outlet.
To reset door pin:
If doors are removed at less than a 40
degree angle, the pin returns to the home
position. It can be reset by turning the
door upside and using a 5/32” Allen
wrench to rotate the left hand pin 90
degrees clockwise and the right hand pin
90 degrees counterclockwise.
Pin
Mechanism
Bottom
Hinge
Opening
Doors
at 90º
(Door Bottom)
3 Reinstall top hinge.
4 Insert the water line in the top left
tunnel pushing from the front to the
back of the unit.
Once the door pins are reset, follow the
steps “To reinstall the refrigerator doors”.
14
Removing the Doors
CAUTION
Drawer is heavy. Use caution when
lifting.
Removing Freezer Drawer
Remove
Hex Head
Drawer Screw
DO NOT
Remove
Other
Screws
DO NOT
Loosen
or
Remove
These 3
Hex
Screws
Replacing Freezer Drawer
1 Extend the Freezer slides from the
unit.
2 Carefully align support pin with hooks
on end of freezer slides and then
lower freezer door onto slides.
3 Replace the 4 hex head screws that
secure the slides to the door (2 on
each side) and tighten.
1 Remove 4 hex head drawer screws.
2 Lift up drawer to remove.
Pin
Hook
NOTE
To locate the pin, look inside the drawer
and the pin is next to the door liner and
the slides. Not all parts are shown in the
illustration.
15
Installing Door Handles
Door Handle Mounting Instructions
End
Cap
End
Cap
End
Cap
End
Cap
Mounting
Refrigerator
Handles
End
Cap
End
Cap
Mounting
Freezer
Handle
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
NOTE
An Allen wrench is supplied in the handle packaging. When using the Allen wrench to tighten the
Allen set screws (C), it is imperative that force be applied to the longer arm of the Allen wrench to
ensure that the set screws are completely tightened so that handles are flush with doors/drawer.
1. Remove handles from protective packaging.
2. Position fresh food handle end caps (A) over upper and lower pre-installed shoulder
bolts (B) that are fastened into door, ensuring the holes for the set screws are facing
towards the opposite door.
3. While holding handle firmly against door, fasten upper and lower Allen set screws
(C) with supplied Allen wrench.
4. Repeat steps 2 and 3 to install opposite handle. Ensure the holes for the set screws
are facing towards the first door.
5. Position freezer handle end caps over left and right pre-installed shoulder bolts (B) that
are fastened to the drawer, ensuring the holes for the set screws are facing down.
6. While holding handle firmly against drawer, fasten left and right Allen set screws (C)
with supplied Allen wrench.
16
Connecting the Water Supply
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the refrigerator from
electrical power before connecting a
water supply line to the refrigerator.
IMPORTANT
Ensure that your water supply line
connections comply with all local
plumbing codes.
CAUTION
To Avoid Property Damage:
• Copper or Stainless Steel braided
tubing is recommended for the
water supply line. Water supply
tubing made of ¼ inch plastic is
not recommended to be used.
Plastic tubing greatly increases the
potential for water leaks, and the
manufacturer will not be responsible
for any damage if plastic tubing is
used for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
softener can damage the ice maker.
If the ice maker is connected to soft
water, ensure that the softener is
maintained and working properly.
NOTE
Check with your local building authority
for recommendations on water lines and
associated materials prior to installing
your new refrigerator. Depending
on your local/state building codes,
Electrolux recommends for homes
with existing valves its Smart Choice®
water line kit 5305513409 with a 6
ft. (1.8 meters) Stainless Steel Water
Line and for homes without an existing
valve, Electrolux recommends its Smart
Choice® water line kit 5305510264 with
a 20 ft. (6 meters) Copper Water Line
with self-tapping saddle valve). Please
refer to www.electroluxappliances.com
for more information.
Before installing the water supply line,
you will need:
1. Basic Tools: adjustable wrench,
flat-blade screwdriver, and Phillips
TM
screwdriver
2. Access to a household cold water
line with water pressure between 30
and 100 psi.
3. A water supply line made of ¼ inch
(6.4 mm) OD, copper or stainless
steel tubing. To determine the length
of tubing needed, measure the
distance from the ice maker inlet
valve at the back of the refrigerator
to your cold water pipe. Then add
approximately 7 feet (2.1 meters), so
the refrigerator can be moved out for
cleaning.
4. A shutoff valve to connect the water
supply line to your household water
system.
5. Do NOT reuse compression fitting or
use thread seal tape.
6. A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the ice maker
inlet valve.
17
To connect water supply line to ice
maker inlet valve:
1. Disconnect refrigerator from electric
power source.
2. Place end of water supply line into
sink or bucket. Turn ON water supply
and flush supply line until water
is clear. Turn OFF water supply at
shutoff valve.
3. Remove plastic cap from water valve
inlet and discard cap.
4. If you use copper tubing - Slide brass
compression nut, then ferrule (sleeve)
onto water supply line. Push water
supply line into water valve inlet as far
as it will go (¼ inch / 6.4 mm). Slide
ferrule (sleeve) into valve inlet and
finger tighten compression nut onto
valve. Tighten another half turn with
a wrench; DO NOT over tighten. See
Figure 1.
If you use braided flexible stainless
steel tubing - The nut is already
assembled on the tubing. Slide nut
onto valve inlet and finger tighten nut
onto valve. Tighten another half turn
with a wrench; DO NOT over tighten.
See Figure 2.
5. With steel clamp and screw, secure
water supply line (copper tubing only)
to rear panel of refrigerator as shown.
6. Coil excess water supply line (copper
tubing only), about 2½ turns, behind
refrigerator as shown and arrange
coils so they do not vibrate or wear
against any other surface.
7. Turn ON water supply at shutoff valve
and tighten any connections that
leak.
8. Reconnect refrigerator to electrical
power source.
9. To turn ice maker on, lower wire
signal arm (freezer ice maker) or use
the digital control setting to turn the
ice maker’s On/Off switch to the On
position (fresh food ice maker).
Figure 1
Plastic Water Tubing
to Ice Maker
Fill Tube
Steel
Clamp
Brass
Compression
Nut
Ferrule
(Sleeve)
Copper
water line
Water Valve
Bracket
Valve Inlet
Water Valve
Copper water line
from household
water supply
(Include enough tubing in loop to allow
moving refrigerator out for cleaning)
Figure 2
Steel
Clamp
Braided
Flexible
Stainless
Steel
Water Line
Water Valve
Bracket
Valve Inlet
Water Valve
6 ft (1.8 Meters) Braided flexible
stainless steel water line from
household water supply.
Plastic Water Tubing
to Ice Maker
Fill Tube
(Include enough tubing in loop to allow
moving refrigerator out for cleaning.)
Connecting the Water Supply
18
Controls
Wave-Touch
TM
Your refrigerator is equipped with a Wave-
Touch
TM
control panel display. It is only
necessary to gently touch the glass. There
are three levels of display.
1st Level: Sleep Mode
Sleep Mode displays only the water,
cubes and crushed options. Touch an icon
to activate the desired dispenser mode.
The active dispenser mode is more brightly
illuminated.
2nd Level: Awakened Display Mode
IMPORTANT
When the ice maker is turned off, the ice
in the bucket should be transferred to the
freezer or discarded to prevent it from melting.
The control panel is awakened by touching
anywhere on the glass where there is an
indicator. Black space will not awaken the
display. After 10 seconds of inactivity, the
control panel will return to the Sleep mode.
NOTE
The recommended settings for a product
installed in a kitchen is 37˚F for the fresh
food compartment and 0˚F for the freezer.
IMPORTANT
If your product has food freezing in the
fresh food compartment, increase the
temperature setting 1 or 2 degrees.
IMPORTANT
If you place food within 1 inch in front of
the air ports, there may be the chance
of freezing food.
The following dispenser options are illuminated:
i ce o Press and hold for three seconds to
turn the ice maker “ON” or “OFF”.
express freeze Activates a faster rat e for fr eezing food.
dispenser light On / O
contro l lock Press and hold for three seconds to
activate and deactivate. This restricts
undesired changes to the refrigera-
tor’s settings and prevents use of the
ice and water dispenser.
19
Controls
3rd Level: User Variable Options
Touching the options icon displays the
following options:
vacation mode Conserves energy by increas-
ing the time between automatic
defrost. This feature is automati-
cally activated during long periods
between door openings. Vacation
mode is manually activated when
the red indicator is lit.
wa t e r l t e r Touch to display lter condition
status. Press and hold for three
seconds to reset after filter change .
air lter Touch to display lter status. Press
and hold for three seconds t o r eset
after lter change.
temp display When active, it allows the display
of the freezer and fridge temp
settings during “Sleep Mode”. The
temperature is displa yed when the
red indicator is lit.
temp mode Touch to toggle display from
Fahrenheit to Celsius.
mut e s ou nd s Tones emitted by each keypress
can be turned o based on user
prefer ence . The sounds are muted
when the red indicator is lit. Warn-
ing signals will stay active.
factory default Resets all refrigerator settings such
as temp, temp display, and alar m
tones to their factory default settings.
on o Press and hold for three seconds
to turn o the cooling system to
clean the refrigerator. It also turns
o the ice maker, all dispenser
functions, and the Custom Temp
TM
drawer (select models). The
temperature displa y will r ead OFF.
IMPORTANT
Pressing the system on/off icon does not
turn off power to your refrigerator. You must
unplug the power cord from the wall outlet.
Alarms
Door Ajar If the door has been left open for an
extended period of time, an alarm will
sound and the door ajar indicator will
display on the center of the display. The
alarm is turned o by closing the door.
The alarm o key will blink to prompt the
reset of any pending alarms. Press this
key to reset any system Alarms.
High Tem p In the event of a high temperature
condition, the temperatur e display will blink
and display “HI”. Af ter 20 minutes, the
high temp alert will be displayed and the
alarm o icon will illuminate until pressed ,
acknowledging the alarm, at which time
the highest temperature r eached will be
displayed and the refrigera tor will r esume
normal operation. All other modes are
turned off until the alarm is acknowledged.
Power Fail In the event of a power failure, the power
fail alert will be displayed and the alarm
o key will blink until the alarm o icon is
pressed, acknowledging the alarm. Other
modes may be turned o until the alarm is
acknowledged. When the po wer fail alert
is turned o, the refrigerator will resume
normal operation. The high temp alarm
may also be illuminated until a saf e operat-
ing range temperature has been reached .
Setting cooling
temperatures
1 Touch
the glass
panel to
illuminate
the 2
nd
level of
display.
2 Select the options icon. Plus (+) and
minus (-) indicators will appear on either
side of the displayed temperatures.
3 Press the + or – indicator to adjust the
temperature to the desired setting.
The temperature display will begin
to blink with the first touch. After five
seconds of inactivity, the display will
beep to accept the new temperature.
After 10 seconds, the display times
out and returns to the basic display.
20 Controls
The Sabbath Mode is a feature that
disables portions of the refrigerator and its
controls in accordance with observance of
the weekly Sabbath and religious holidays
within the Orthodox Jewish community.
Wave-Touch
TM
“Sabbath
Mode”
Sabbath Mode is turned ON and OFF
by pressing and holding both the freezer
“-” and refrigerator “+” indicators for five
seconds. The display shows “Sb” while in
Sabbath mode.
In the Sabbath Mode, the High Temp alarm
is active for health reasons. For example,
if the door is left ajar the High Temp alarm
is activated. The refrigerator will function
normally once the door is closed, without
any violation of the Sabbath/Holidays.
The High Temp alarm is permitted when
cabinet temperature is outside the safe
zone for 20 minutes. The alarm silences
itself after 10 minutes while the High Temp
icon stays lit until the Sabbath mode is
exited.
For further assistance, guidelines for
proper usage and a complete
list of models with the Sabbath
feature, please visit the web at
http:\\www.star-k.org.
NOTE
While in Sabbath Mode, neither the
lights, dispenser, nor the control panel will
work until Sabbath Mode is deactivated.
Refrigerator stays in Sabbath Mode after
power failure recovery. It must be deactivated
with the buttons on the control panel.
NOTE
While in Sabbath Mode, the Wave-
Touch
TM
model will only illuminate the -/+
keys used to turn the Sabbath Mode Off.
NOTE
Although you have entered the Sabbath
Mode, the ice maker will complete the
cycle it had already initiated. The ice
cube compartment will remain cold
and new ice cubes can be made with
standard trays.
Sabbath Mode and the Custom
Temp
TM
Drawer
The Custom Temp
TM
Drawer should be
turned off for the Sabbath/Holidays. Before
putting the refrigerator into the Sabbath
mode, turn the Custom Temp
TM
Drawer off
by pressing the drawer on/off button. The
display will show “OFF” and the drawer
will turn off. Then enter the Sabbath mode
function on the main refrigerator display.
See Wave-Touch
TM
“Sabbath Mode”
section. When in Sabbath mode, the
display will not illuminate and the drawer
will remain off. The drawer can still be used
as a non-temp controlled drawer in this
mode. When the refrigerator is taken out
of Sabbath mode, the Custom Temp
TM
Drawer will have to be turned back on.
NOTE
If the Custom Temp
TM
Drawer is not
turned off prior to putting the unit into
Sabbath Mode, it will continue to adjust
itself to maintain the set point even if the
display does not illuminate to show that
it is still on.
NOTE
During Sabbath Mode, the freezer
ice maker (if present) will continue to
work and must be manually turned
off to be compliant with the Sabbath
observances.
21
Controls
IQ-Touch
TM
A red indicator light will be illuminated above most active features.
Touch the icon to activate the options below.
fast freeze Activates a faster rate for freezing food.
fast ice Increases the production of ice
energy saver Keep this switch set on energy saver (light on) for lo w est energy
usage. If moisture appears on the cabinet between the doors,
pressing this button will turn the light o and enable an electric
heater used to r educe moisture on the cabinet between the doors .
water lter Press and hold for three seconds to reset after lter change.
air lter Filt er c ondition status is alw a y s displayed when door is open.
Press and hold for three seconds to reset after lter change.
temp mode Touch to toggle display from Fahrenheit to Celsius.
mute sounds T ones emitted by each key pr ess can be turned off based on
user prefer ence . The sounds are muted when the red indicator
is lit. Warning signals will stay active.
default settings Resets all refrigerator settings such as temp , temp display and
tones to their factory default settings.
on o Press and hold for three seconds to turn o the cooling
system to clean the refrigera tor. The tempera ture displa y s will
read OFF.
Setting cooling temperatures
Press the + or – indicator to adjust the temperature to the
desired setting.
The temperature display will begin to blink with the first touch. The
display will time out after 10 seconds and return to the basic display.
Alarms
Door Ajar If the door has been left open for an extended period of time , an
alarm will sound and the door ajar indicator will display on the b ot-
tom display of the con trol panel . The al arm is turned off by closing
the door . The mute sounds key will blink to prompt the reset of an y
active alarms. Press this key to reset any system alarms.
High Temp In the event of a high temperature condition, the tempera ture
display will blink and display “HI”. After 20 minutes, the alarm
will sound and the high temp indicator will be red on the bottom
of the control panel. The mute sounds icon will illuminate until
pressed, acknowledging the alarm, at which time the highest
temperature r eached will be display ed and the refrigerat or will
resume normal operation. In case the high temp alarm is not
acknowledged at the first alarm sound time out, when the door
is rst opened, the alarm sound will be repeated.
Power Fail In the event of a power failure, the power fail alert will be
displayed and the tempera ture display will blink un til the mute
sounds icon is pressed, acknowledging the alarm. Other modes
may be turned o until the alarm is acknowledged. The power
fail alert is turned o and the refrigerator will resume normal
operation. The high temp alarm may also be illuminated until a
safe operating range temperature has been reached.
IMPORTANT
Pressing the system on/off icon does not turn off power to your
refrigerator. You must unplug the power cord from the wall outlet.
22 Controls
IQ-Touch
TM
“Sabbath Mode”
The Sabbath Mode is a feature that
disables portions of the refrigerator and
its controls for IQ-Touch
TM
, in accordance
with observance of the weekly Sabbath
and religious holidays within the Orthodox
Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding the
freezer temp “-” and the refrigerator temp
“+” indicators for five seconds. The display
shows “Sb” while in Sabbath mode.
In the Sabbath Mode, the High Temp alarm
is active for health reasons. For example,
if the door is left ajar the High Temp alarm
is activated. The refrigerator will function
normally once the door is closed, without
any violation of the Sabbath/Holidays.
The High Temp alarm is permitted when
cabinet temperature is outside the safe
zone for 20 minutes. The alarm silences
itself after 10 minutes while the High Temp
icon stays lit until the Sabbath mode is
exited.
For further assistance, guidelines for
proper usage and a complete list of
models with the Sabbath feature,
please visit the web at
http:\\www.star-k.org.
NOTE
While in Sabbath Mode, neither the
lights nor the control panel will work until
Sabbath Mode is deactivated.
Refrigerator stays in Sabbath Mode
after power failure recovery. It must be
deactivated with the buttons on the
control panel.
NOTE
During Sabbath Mode, the automatic ice
maker will continue to work and must be
manually turned off to be compliant with
the Sabbath observances.
Sabbath Mode and the Custom
Temp
TM
Drawer
The Custom Temp
TM
Drawer should be
turned off for the Sabbath/Holidays. Before
putting the refrigerator into the Sabbath
mode, turn the Custom Temp
TM
Drawer off
by pressing the drawer on/off button. The
display will show “OFF” and the drawer
will turn off. Then enter the Sabbath mode
function on the main refrigerator display.
See the IQ-Touch
TM
“Sabbath Mode”
section. When in Sabbath mode, the
display will not illuminate and the drawer
will remain off. The drawer can still be used
as a non-temp controlled drawer in this
mode. When the refrigerator is taken out
of Sabbath mode, the Custom Temp
TM
Drawer will have to be turned back on.
NOTE
If the Custom Temp
TM
Drawer is not
turned off prior to putting the unit into
Sabbath Mode, it will continue to adjust
itself to maintain the set point even if the
display does not illuminate to show that
it is still on.
23
Automatic Ice Maker & Water Dispenser
Priming the water sup-
ply system
1 Begin filling the tank by pressing and
holding a drinking glass against the
water dispenser paddle.
2 Keep the glass in this position until
water comes out of the dispenser. It
may take about 1½ minutes.
3 Continue dispensing water for about
two minutes to flush the system
and plumbing connections of any
impurities (stopping to empty the
glass as necessary).
Ice maker operation &
care
After the refrigerator is installed properly
and has cooled for several hours, the ice
IMPORTANT
Your ice maker is turned on at the
factory so it can work as soon as you
install your refrigerator. If you cannot
connect a water supply, set the ice
maker’s On/Off icon to Off and turn off
the water supply valve; otherwise, the
ice maker’s fill valve may make a loud
chattering noise when it attempts to
operate without water.
CAUTION
For proper dispenser operation,
recommended water supply pressure
should fall between 30 psi and 100 psi.
Excessive pressure may cause water
filter to malfunction.
NOTE
The water dispenser has a built-in device that
shuts off the water flow after two minutes of
continuous use. To reset this shutoff device,
simply release the dispenser paddle.
NOTE
The ice maker also has a built-in plastic
signal bale arm that automatically stops
ice production when the ice bin is full.
This signal arm should not be used to
manually stop the ice maker.
Turning the ice maker on and off
Ice production is controlled by the ice
maker’s On/Off icon on the control panel.
Press and hold the “Ice Off” icon for three
seconds to turn the ice maker “ON” or
“OFF”. When the ice maker is “OFF” the
red LED above the icon will be illuminated.
NOTE
Dispensed water is not chilled. For
colder water, add ice to cup or container
before dispensing water.
Using the ice maker after
installation
Before making ice for the first time, be
sure to prime the water supply system.
Air in new plumbing lines can result in
two or three empty ice maker cycles.
Furthermore, if the system is not flushed,
the first ice cubes may be discolored or
have an odd flavor.
maker can produce ice within 24 hours.
The ice maker will fill the ice bin from the
rear. You must dispense some ice to force
the ice forward in the bin. This will allow
the bin to fill completely.
Full bin should be expected after 48 to 60
hours with no ice usage. Ice rate is 2.0 to
2.5 lbs. per day. For extra capacity you
can add an ice maker kit for the freezer.
24
Automatic Ice Maker & Water Dispenser
Ice maker/dispenser tips
• If your refrigerator is not connected to
a water supply or the water supply is
turned off, turn off the ice maker by
holding the On/Off soft-touch icon for
three seconds.
• The following sounds are normal when
the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• If you need a large quantity of ice
at one time, it is best to get cubes
directly from the ice bin.
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
bin as explained below.
• When dispensing cubed ice, it is
normal to have a small quantity of little
pieces along with the whole cubes.
Removing Ice Bin
Cleaning the ice maker
Clean the ice maker and ice bin at regular
intervals, especially prior to vacation or
moving.
1 Turn off
the ice
maker.
2 Remove
the ice
bin by
pulling
straight
out.
3 Empty
and
carefully
clean the ice bin with mild detergent.
Do not use harsh or abrasive
cleaners. Rinse with clear water.
4 Allow the ice bin to dry completely
before replacing.
5 Replace the ice bin. Turn the ice
maker on.
Adjusting Ice Bin Auger
Auger
Remove and empty the ice bin if:
• An extended power failure (one hour
or longer) causes ice cubes in the
ice bin to melt and freeze together,
jamming the dispenser mechanism.
• You do not use the ice dispenser
frequently. Ice cubes will freeze
together in the bin, jamming the
dispenser mechanism.
Remove the ice bin and shake to loosen
the cubes or clean as explained above.
IMPORTANT
When removing or replacing the ice bin,
DO NOT rotate the auger in the ice bin.
If the auger is accidentally rotated, you
must realign the auger by turning it in 45
degree turns (see below) until the ice bin
fits into place with the drive mechanism.
If the auger is not properly aligned when
replacing the ice bin, the refrigerator will
not dispense ice. The fresh food door
also may not close properly causing
warm air to leak into the fresh food
compartment.
CAUTION
If the water supply to your refrigerator
is softened, be sure the softener is
properly maintained. Chemicals from
a water softener can damage the ice
maker.
NOTE
Dispenser models allow for an additional
freezer ice maker to be installed. Call
1-877-435-3287 for more information.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
25Automatic Ice Maker - Freezer
Ice maker operation &
care (select models)
After the refrigerator is installed properly,
the ice maker can produce ice within 24
hours. It can completely fill an ice bin in
about three days.
When using the ice maker for the first
time and in order for the ice maker to
work properly, it is necessary to clear air
from water filter tubing. Once ice maker
begins making ice, allow the bucket to
fill completely, then discard the first TWO
FULL buckets of ice. It will take at least
two days to completely fill the bucket on
regular ice making mode or 1½ days on
fast ice mode.
The ice maker produces approximately
2.0 to 2.5 pounds of ice every 24 hours
depending on usage conditions. In a
Standard Depth model, the ice bin will
hold about 12 pounds of ice. In a Counter
Depth model, the ice bin will hold about 7
pounds of ice.
Turning the ice maker on and off
Ice production is controlled by lifting/
lowering the ice maker’s wire signal arm.
To gain access to the ice maker, pull the
freezer drawer out. Lift the wire signal arm
to turn the ice maker OFF and lower the
wire signal arm to turn it ON.
Ice maker tips
• If your refrigerator is not connected to
a water supply or the water supply is
turned off, turn off the ice maker by
lifting wire signal arm.
• The following sounds are normal when
the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
bin as explained below.
Fast Ice Function
Your refrigerator is equipped with a
“Smart” Fast Ice Function that will, if
activated, allow an increase in freezer ice
production. After time the refrigerator will
return to normal ice production.
Wire
Signal Arm
OFF
ON
IMPORTANT
Your ice maker is turned on at the
factory so it can work as soon as you
install your refrigerator. If you cannot
connect a water supply, lift the ice
maker’s wire signal arm to turn it off.
Otherwise, the ice maker’s fill valve may
make a loud chattering noise when it
attempts to operate without water.
CAUTION
If the water supply to your refrigerator
is softened, be sure the softener is
properly maintained. Chemicals from
a water softener can damage the ice
maker.
NOTE
During the Sabbath Mode, the
automatic ice maker will continue to
work and must be manually turned
off to be compliant with the Sabbath
observance.
26
Cleaning the ice maker
Clean the ice maker and ice bin at regular
intervals, especially prior to vacation or
moving.
1 Turn off the ice maker.
2 Remove the ice bin.
3 Empty and carefully clean the ice bin
with mild detergent. Do not use harsh
or abrasive cleaners. Rinse with clean
water.
4 Allow the ice bin to dry completely
before replacing in the freezer.
5 Replace the ice bin. Turn the ice
maker on.
Remove and empty the ice bin if:
• An extended power failure (one hour
or longer) causes ice cubes in the ice
bin to melt and freeze together.
Remove the ice bin and shake to loosen
the cubes or clean as explained above.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
Automatic Ice Maker - Freezer
27
Storage Features
Special items rack (select models)
The innovative design of the special items
rack allows you to store four bottles of
wine or soft drink bottles.
Removing Crisper Drawer
To remove the Crisper Drawer for cleaning:
1 Pull the drawer out until it stops.
2 Lift the front slightly and remove the
drawer.
Special Items
Rack
Cool Zone (select models)
Some models are equipped with a meat
keeper drawer for short-term storage of bulk
meat items. This drawer includes sliding
controls for adjusting the humidity inside.
Any meat to be kept longer than two days
should be frozen. If you store fruits or vegetables
in this drawer, set it to a higher humidity.
Opening Crisper Drawer
Adjusting Crisper Humidity
(varies by model)
Higher
Humidity
Lower
Humidity
Humidity Control
Drawers
Your refrigerator includes a variety of
storage drawers.
Crispers
Crisper drawers are designed for storing
fruits, vegetables, and other fresh produce.
They feature a smooth-glide, ball-bearing
system and soft-close functionality so as
not to bruise your fruits and vegetables.
Crisper humidity control
Crisper drawers include a sliding control
for adjusting the humidity inside the
crisper. Leafy vegetables keep best when
stored with the Humidity Control set on
Higher Humidity. Fresh fruits keep best
when stored with the Humidity Control set
on Lower Humidity.
28
Storage Features
The Custom Temp
TM
Drawer is designed to
keep food items at a precise temperature
whether cooler, warmer, or the same as
the fresh food section of the refrigerator.
The thaw setting holds a temperature for
thawing frozen foods for 12 hours. At the
end of that time, it then switches to the
snacks setting to store the thawed food.
Custom Temp
TM
Drawer (select models)
To operate:
1 To turn on and off, press the drawer’s
On/Off button. The numeric display will
show a temperature between “28°F and
38°F” when on and “OFF” when off.
2 Press F/C if you prefer to display
Fahrenheit “F,” or Celsius “C”.
3 Press either the up (^) or down (v) scroll
buttons to illuminate the desired item.
4 Once an option is selected, the
drawer will adjust and maintain the
temperature for the setting selected.
5 When turned off, the Custom Temp
TM
Drawer functions as a standard
meat pan. The Custom Temp
TM
Drawer is best used for packaged
food products. Leafy vegetables and
unpackaged fruits are best kept in
one of the crisper drawers.
6 The three favorite selections
provide flexibility to set and store
personal temperature selections.
The temperature is adjusted up
by pressing the + or – buttons.
The drawer will store the selected
temperature setting until it is changed.
7 The control buttons can be locked
to prevent accidental changes by
pressing the control lock button
for three seconds. Deactivate by
pressing for three seconds again.
Opening the Drawer
IMPORTANT
DO NOT clean the display area of the
Custom Temp
TM
Drawer with abrasive
or caustic cleaners. Wipe clean with a
moist sponge.
CAUTION
The Custom Temp
TM
Drawer and cover
can be removed for cleaning but the
control unit, attached to the right side of
the fridge, cannot be removed. Do not
immerse the Custom Temp
TM
Drawer
cover in water or put it in a dishwasher.
Clean with a damp cloth or sponge.
To remove the Custom Temp
TM
Drawer
for cleaning:
1 Pull the drawer out until it stops.
2 Lift the front slightly and remove the drawer.
Removing the Drawer
NOTE
When the refrigerator is turned off by pressing
the main Wave-Touch
TM
or IQ-Touch
TM
on/off
button, the Custom Temp
TM
Drawer will also
be turned off. When the refrigerator is turned
back on, the Custom Temp
TM
Drawer will
resume operations at the temp setting that
was set before the refrigerator was turned off.
29
Storage Features
Doors
Storage bins
The doors to your fresh food compartment
use a system of modular storage bins. All of
these bins are removable for easy cleaning.
Some of them have fixed positions, while
others can be adjusted to your needs.
Door bins are ideal for storing jars, bottles,
cans, and large drink containers. They also
enable quick selection of frequently used items.
To change the position of an adjustable
door bin:
1 Before adjusting a bin, remove all food.
2 Grip the bin firmly with both hands
and lift it upward.
3 Remove the bin.
4 Place the bin just above desired position.
5 Lower the bin onto supports until
locked in place.
Adjustable Door Bin
Accessories (varies by model)
Tall bottle retainer
The tall bottle retainer keeps tall containers
in the bin from falling forward when opening
or closing the refrigerator door. To install,
insert the ends of the retainer into the holes.
Tilt can bins
The can bins allow you to efficiently and
securely store up to eight 12-ounce
canned beverages.
Tall
Bottle
Retainer
Tilt Can Bin
Dairy compartment
Use the dairy compartment, at the top
of the fresh food compartment door, for
short-term storage of cheese, spreads, or
butter. The dairy compartment is designed
to be warmer than the open area and
includes a lift-up cover that may be locked
and a dairy divider (select models).
Dairy Compartment
Lock
30
Storage Features
Freezer Features (varies
by model)
To Remove Upper Freezer
Basket
1 Find the side where the basket frame
is aligned to the clip opening. The
basket frame should be aligned to
both front and rear clips on the same
side (either left or right side).
2 If the basket frame is not aligned to
the left or right side, push the basket
sideways (to either side) until it is aligned.
3 By grabbing the basket wire frame
close to the frontal clip, pull up to
take the basket frame out.
4 Grab the basket frame close to the
rear clip and pull up until it comes out
of the clip.
5 Once one side of the basket is off
the clips or retainers, slide the basket
sideways until the other side of the
frame is aligned with the clip openings
on the opposite side of the freezer.
6 In the same way, pull up the basket
frame from the frontal and rear clips
until it is out of the clips.
7 Remove the basket.
Reverse the steps to reinstall the basket.
Freezer Baskets
Clip
Stabilizer
Bar
NOTE
If basket is not resting on stabilizer bar retainer
clips, the drawer will not close properly.
Pull to Remove
Push to Replace
Removing Freezer Basket
Instructions
1 Locate the basket clips in the rear
corners of the basket and pull them
out to remove.
2 Open fresh food doors completely.
3 Lift the basket up and remove.
Replacing Freezer Basket
Instructions
1 Place freezer basket back inside the
freezer drawer.
2 Replace clips by sliding them back
into the slots.
Location of
basket clip.
One each side.
31
Storage Features
Dividers Removal
Lift up on the front of the upper divider and
pull out.
Squeeze handle and lift up in the center
of the divider to move it side-to-side. (The
divider cannot be removed.)
Upper Basket Divider
Upper Basket
Divider
Retainers
Stabilizer
Bar
Plastic Lower Basket Divider
Lower Basket
Divider
Tilt Wire Shelf
The freezer tilt wire shelf (located on
the inside of the freezer drawer) is not
designed to be removed.
32
Ideas for storing foods
Fresh food storage
• Keep the fresh food compartment
between 34° F and 40° F with an
optimum temperature of 37° F.
• Avoid overcrowding the refrigerator
shelves, which reduces air circulation
and causes uneven cooling.
Fruits and vegetables
• Store fruits and vegetables in crisper
drawers, where trapped moisture
helps preserve food quality for longer
time periods.
• Wash items and remove excess water.
• Wrap any items that have strong
odors or high moisture content.
Meat
• Wrap raw meat and poultry separately
and securely to prevent leaks and
contamination of other foods or
surfaces.
• Use the deli drawer or Custom Temp
TM
drawer and set to meat/poultry setting
for short-term storage. Any meat to
be kept longer than two days should
be frozen.
Frozen food storage
• Keep the freezer compartment at 0° F
or lower.
• A freezer operates most efficiently
when it is at least 2/3 full.
Packaging foods for freezing
• To minimize food dehydration and
quality deterioration, use aluminum foil,
freezer wrap, freezer bags, or airtight
containers. Force as much air out of
the packages as possible and seal
them tightly. Trapped air can cause
food to dry out, change color, and
develop an off-flavor (freezer burn).
• Wrap fresh meats and poultry with
suitable freezer wrap prior to freezing.
• Do not refreeze meat that has
completely thawed.
Loading the freezer
• Prior to grocery shopping, activate
“express freeze” so that on your return
you can ensure your newly purchased
food designated for the freezer will be
preserved as quickly as possible.
Storing Food and Saving Energy
• Activating “express freeze” also will
help your freezer more efficiently
maintain the selected temperature
after placing new purchases with pre-
existing frozen foods.
• Avoid adding too much warm food to
the freezer at one time. This overloads
the freezer, slows the rate of freezing,
and can raise the temperature of
frozen foods.
• Leave a space between packages, so
cold air can circulate freely, allowing
food to freeze as quickly as possible.
Ideas for saving energy
Installation
• Locate the refrigerator in the coolest
part of the room, out of direct sunlight,
and away from heating ducts or
registers.
• Do not place the refrigerator next to
heat-producing appliances such as a
range, oven, or dishwasher. If this is
not possible, a section of cabinetry or
an added layer of insulation between
the two appliances will help the
refrigerator operate more efficiently.
• Level the refrigerator so that the doors
close tightly.
Temperature settings
• Refer to the “Controls” section for
procedures on temperature settings.
Food storage
• Avoid overcrowding the refrigerator
or blocking cold air vents. Doing so
causes the refrigerator to run longer
and use more energy.
• Cover foods and wipe containers dry
before placing them in the refrigerator.
This cuts down on moisture build-up
inside the unit.
• Organize the refrigerator to reduce
door openings. Remove as many
items as needed at one time and close
the door as soon as possible.
• Do not place a hot container directly
on a cold shelf. Remember, such an
extreme temperature change may
damage the glass.
33
Normal Operating Sounds
Understanding the
sounds you may hear
Your new, high-efficiency refrigerator
may introduce unfamiliar sounds. These
sounds normally indicate your refrigerator
is operating correctly. Some surfaces on
floors, walls, and kitchen cabinets may
make these sounds more noticeable.
The following is a list of major components
in your refrigerator and the sounds they
can cause:
A Evaporator Refrigerant through the
evaporator may create a boiling or
gurgling sound.
B Evaporator fan You may hear air
being forced through the refrigerator
by the evaporator fan.
C Defrost heater During defrost
cycles, water dripping onto the
defrost heater may cause a hissing
or sizzling sound. After defrosting, a
popping sound may occur.
D Automatic ice maker When ice
has been produced, you will hear
ice cubes falling into the ice bin. Ice
maker fan, water valve activation,
and refrigerant gas fluid may create
sounds from its operation.
E Electronic control & automatic
defrost control These parts can
produce a snapping or clicking sound
when turning the cooling system on
and off.
F Condenser fan You may hear air
being forced through the condenser.
G Compressor Modern, high-efficiency
compressors run much faster than
older models. The compressor may
have a high-pitched hum or pulsating
sound.
H Water valve Makes a buzzing sound
each time it opens to fill the ice
maker.
I Drain pan (not removable) You
may hear water dripping into the
drain pan during the defrost cycle.
J Condenser May create minimal
sounds from forced air.
K Motorized Custom Temp
TM
drawer damper May produce a light
humming during operation.
NOTE
During automatic defrost cycle, a red
glow in the back wall vents of your
freezer compartment is normal.
NOTE
Energy efficient foam in your refrigerator
is not a sound insulator.
L Ice dispensing paddle When
dispensing ice, you will hear a
snapping, clicking, or popping sound
when the solenoid opens and closes
the ice chute.
M Motorized damper May produce a
light humming during operation.
N Custom Temp
TM
drawer fan Turns
off when door opens or Custom
Temp
TM
drawer is turned off.
34
Changing The Water and Air Filters
Locating the Filters
Your refrigerator is equipped with water
filtering system. The water filter system
filters all dispensed drinking water, as well
as the water used to produce ice.
Water Filter
The water filter is located at the top right
side of the fresh food compartment.
Replacing the Water Filter
In general, you should change the water
filter every six months to ensure the
highest possible water quality. Water Filter
Status on the user interface prompts
you to replace the filter after a standard
amount of water (125 gallons/473 liters for
PureAdvantage Ultra
TM
) has flowed through
the system.
If your refrigerator has not been used for a
period of time (during moving for example),
change the filter before reinstalling the
refrigerator.
Do not use with water that is
microbiologically unsafe or of unknown
quality without adequate disinfection before
or after the system. Systems certified for
cyst reduction may be used on disinfected
waters that may contain filterable cysts.
Test & certification results:
• Rated Capacity - 125 gallons/473 liters for
PureAdvantage Ultra
TM
ice and water filter
• Rated service flow - .65 gallons per minute
• Operating Temp: Min. 33°F, Max. 100°F
• Maximum Rated Pressure -
100pounds per square inch
• Recommended Minimum Operating
Pressure: 30pounds per square inch
To replace your PureAdvantage Ultra
TM
water filter:
It is not necessary to turn the water supply
off to change the filter. Be ready to wipe
up any small amounts of water released
during the filter replacement.
1 Turn Off the ice maker power switch.
2 Remove the old filter by rotating it
counter-clockwise (to the left) 90
degrees to release it.
3 Slide the old filter cartridge straight
out of the housing and discard it.
4 Unpackage the new filter cartridge.
Slide it into the filter housing as far as
it will go with the grip end horizontal.
5 Push lightly inward on the filter while
rotating it clockwise (to the right). The
filter will then pull itself inward as it is
rotated. Rotate the filter 90 degrees
until it stops and the grip end is
vertical. You may be able to feel a very
light click as the filter locks into place.
6 Press a drinking glass against the water
dispenser while checking for any leaks at
the filter housing. Any spurts and sputters
that occur as the system purges air out of
the dispenser system are normal.
7 Continue dispensing water for 3-4
minutes or until 1.5 gallons of water
has flowed through the system. You
will likely need to empty and refill your
glass several times.
8 Turn On the ice maker.
9 Press and hold the Water Filter reset
button on the control panel for three
seconds. When the display changes from
Red to Green, the status has been reset.
The PureAdvantage Ultra
TM
ice and water filter system is
tested and certified to NSF/ANSI
Standards 43, 53 and 401 for
the reduction of claims specified
on the performance data sheet.
More about your Advanced
Water Filter
Filter Cartridge
NOTE
When ordering your replacement filter,
please reorder the same filter type that is
currently in your refrigerator.
35
Changing The Water and Air Filters
Ordering replacement
filters
To order your replacement filters, please
visit our online store at
www.electroluxappliances.com, by calling
toll-free at 800-599-7569, or by visiting
the dealer where you purchased your
refrigerator. Electrolux recommends that
you order extra filters when you first install
your refrigerator, and that you replace your
filters at least once every six months.
Here is the product number to request
when ordering:
Water Filter
PureAdvantage Ultra
TM
Replacement
Cartridge #EWF02
Air Filter
Replacement cartridge, part #EAFCBF
Air filter
The air filter is located under the utility bin
and/or on the inside of the left door above
the ice maker chute.
Replacing your PureAdvantage
TM
air filter
To ensure optimal filtering of refrigerator
odors, you should change the air filter
every six months (the filter status light on
the Touch Panel prompts you to replace
the filter after six months).
1 Open the air filter door.
2 Remove the old filter and discard it.
3 Unpack the new filter and slide it into
the housing.
4 To close the air filter door, push the
top and bottom to lock the door
closed.
5 Press and hold the Air Filter Reset
button on the control panel for three
seconds. When the display changes
from Replace to Good, the status has
been reset.
Filter located under the utility bin
36
Care and Cleaning
Protecting your investment
Keeping your refrigerator clean maintains its appearance and prevents odor build-up.
Wipe up any spills immediately and clean the freezer and fresh food compartments at
least twice a year.
• Remove adhesive labels by hand. Do not use razor blades or other sharp
instruments which can scratch the appliance surface.
• Do not remove the serial plate. Removal of your serial plate voids your warranty.
• Before moving your refrigerator, raise the anti-tip brackets so the rollers will work
correctly. This will prevent the floor from being damaged.
• Never use metallic scouring pads, brushes, abrasive cleaners, or strong alkaline
solutions on any surface.
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
• Always unplug the electrical power cord from the wall outlet before cleaning.
IMPORTANT
If you store or move your refrigerator in freezing temperatures, be sure to completely
drain the water supply system. Failure to do so could result in water leaks when the
refrigerator is put back into service. Contact a service representative to perform this
operation.
CAUTION
• Pull the refrigerator straight out to move it. Shifting it from side to side may
damage flooring. Be careful not to move the refrigerator beyond the plumbing
connections.
• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces with
wet or damp hands.
• Sudden temperature changes can cause glass breakage.
NOTE
If you set your temperature controls to turn off cooling, power to lights and other
electrical components will continue until you unplug the power cord from the wall
outlet.
NOTE
Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable
fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing
petroleum products on plastic parts, interior doors, gaskets, or cabinet liners. Do not
use paper towels, scouring pads, or other abrasive cleaning materials.
37
Care and Cleaning
Care and cleaning tips
Part Cleaning Agents Tips and Precautions
Interior &
Door Liners
• Soap and water
• Baking soda and
water
• Use two tablespoons of baking soda in one
quart of warm water.
• Be sure to wring excess water out of sponge or
cloth before cleaning around controls, LED light
or any electrical part.
Door Gaskets • Soap and water • Wipe gaskets with a clean soft cloth.
Drawers &
Bins
• Soap and water • Use a soft cloth to clean drawer runners and tracks.
• Do not wash any removable items (bins,
drawers, etc.) in dishwasher.
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid sprays
• Allow glass to warm to room temperature before
immersing in warm water.
Toe Grille • Soap and water
• Mild liquid sprays
• Vacuum
• Remove toe grille (see Installation Instructions).
• Vacuum both sides and wipe with sudsy cloth or
sponge. Rinse and dry.
Exterior &
Handles
• Soap and water
• Non abrasive glass
cleaner
• Do not use commercial household cleaners
containing ammonia, bleach or alcohol to clean
handles.
• Use a soft cloth to clean smooth handles.
• Do not use a dry cloth to clean smooth doors.
Exterior &
Handles
(Stainless
Steel Models
Only)
• Soap and water
• Stainless steel
cleaners
• Never use CHLORIDE or cleaners with bleach to
clean stainless steel.
• Clean stainless steel front and handles with non-
abrasive soapy water and a dishcloth. Rinse with
clean water and a soft cloth.
• Use a non-abrasive stainless steel cleaner.
These cleaners can be purchased at most home
improvement or major department stores. Always
follow manufacturer’s instruction. Do not use
household cleaners containing ammonia or bleach.
• NOTE: Always clean, wipe and dry with grain to
prevent scratching.
• Wash the rest of the cabinet with warm water
and mild liquid detergent. Rinse well and wipe
dry with a clean soft cloth.
Vacation and moving tips
Refer to the guide on the next page for details on caring and cleaning specific areas of
your refrigerator.
Occasion Tips
Short Vacations • Leave refrigerator operating during vacations of three weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn automatic ice maker off and empty ice bucket, even if you
will only be gone a few days.
Long Vacations • Remove all food and ice if you will be gone one month or more.
• Turn the cooling system off (see “Controls” section for location
of On/Off button) and disconnect power cord.
• Turn water supply valve to closed position.
• Clean interior thoroughly.
• Leave both doors open to prevent odors and mold build-up.
Block doors open if necessary.
Moving • Remove all food and ice.
• If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching surface.
38
Solutions to Common Problems
Before you call...
If you experience a problem with your refrigerator or notice a product behavior or
condition that you do not understand, you can usually avoid a call to your service
representative by referring to this section for an answer. Beginning with the following
table, this information includes common problems, causes, and suggested solutions.
Concern Potential Cause Common Solution
Automatic Ice Maker
Ice maker is
not making
any ice.
• Ice maker is turned off.
• Refrigerator is not
connected to water line or
water valve is not open.
• The water supply line is
kinked.
• The water filter is not
seated properly.
• The water filter may be
clogged with foreign
material.
• Freezer ice maker wire
signal arm is being held
up by an item not allowing
it to go in the on or down
position.
• Turn on ice maker. For the fresh food
ice maker, press ice maker on-off
once. For the freezer ice maker,
lower the arm to turn the ice maker
on, or raise it and snap it in its upper
position to turn the ice maker off.
• Connect the unit to the household
water supply and ensure the water
valve is open.
• Ensure that the supply line does not
kink when the refrigerator is pushed
into place against the wall.
• Remove and re-install the water
filter. Be sure to rotate it fully into the
locked position.
• If water dispenses slowly or not at
all, or if the filter is six months old or
older, it should be replaced.
• Move any item or frozen ice cubes
that may block the signal arm from
being in the on or down position.
Additionally, the ice bin itself may be
out of position so that it prevents the
signal arm from dropping all the way
down. Be sure the bin is pushed all
the way to the rear of the shelf. See
Automatic Ice Maker-Freezer section
in manual.
39
Solutions to Common Problems
Concern Potential Cause Common Solution
Automatic Ice Maker (Cont’d)
Ice maker is
not making
enough ice.
• Ice maker is producing
less ice than you expect.
• The water filter may be
clogged with foreign
material.
• The water supply line is
kinked.
• Saddle valve on cold
water pipe is clogged
or restricted by foreign
material.
• Heavy traffic, opening
or closing of the doors
excessively.
• Freezer control is set too
warm (freezer ice maker).
• Water pressure is
extremely low. Cut-off and
cut-on pressures are too
low (well systems only).
• Reverse osmosis system
is in regenerative phase.
• The ice maker will produce
approximately 2.0 to 2.5 pounds of
ice every 24 hours depending on
usage conditions.
• If water dispenses slower than
normal, or if the filter is six months
old or older, it should be replaced.
• Ensure that the supply line does not
kink when the refrigerator is pushed
into place against the wall.
• Turn off household water line
valve. Remove valve. Ensure that
valve is not a self-piercing saddle
valve. Clean valve. Replace valve if
necessary.
• Press Fast Freeze to temporarily
increase ice production rate. (Freezer
ice maker only.)
• Set freezer control to colder setting
to improve performance of the ice
maker (freezer ice maker). Allow 24
hours for temperature to stabilize.
• Have someone turn up the cut-off
and cut-on pressure on the water
pump system (well systems only).
• It is normal for a reverse osmosis
system to be below 20 psi during the
regenerative phase.
Freezer ice
maker will
not stop
making
ice (select
models).
• Ice maker wire signal arm
is being held down by a
package in the freezer
that has fallen against ice
maker.
• Move any item or frozen ice cubes
that may block the signal arm from
being in the off or upward position.
See Automatic Ice Maker-Freezer
section in manual.
Ice cubes
are freezing
together.
• Ice cubes are not being
used frequently enough or
interruption of power for
prolonged time.
• Ice cubes are hollow
(shells of ice with water
inside). The hollow cubes
break open in the bin
and leak their water onto
existing ice, which causes
it to freeze together.
• Remove ice container and discard
ice. The ice maker will produce fresh
supply. Ice should be used at least
twice weekly to keep the cubes
separated.
• This generally occurs when the ice
maker does not get enough water.
This is usually the result of a clogged
water filter or restricted water supply.
Replace the water filter and if the
condition still occurs check for a
Saddle Valve, water valve not turned
on all the way or kinked water supply
line.
40 Solutions to Common Problems
Concern Potential Cause Common Solution
Dispenser (Ice & Water)
Dispenser
will not
dispense
ice.
• There is no ice in the bin to
be dispensed.
• The refrigerator doors are
not completely closed.
• Dispenser paddle has
been pressed too long and
the dispenser motor has
overheated.
• See the “Ice maker is not making any
ice” section above.
• Be sure the refrigerator doors are
completely closed.
• The motor overload protector will
reset in about three minutes and then
ice can be dispensed.
Ice
dispenser is
jammed.
• Ice has melted and
frozen around auger
due to infrequent use,
temperature fluctuations,
and/or power outages.
• Ice cubes are jammed
between ice maker and
back of ice container.
• Remove ice container, thaw, and
empty the contents. Clean container,
wipe dry, and replace in proper
position. When new ice is made,
dispenser should operate.
• Remove ice cubes that are jamming
the dispenser.
Dispenser
will not
dispense
water.
• Water filter not seated
properly.
• Water filter is clogged.
• Household water line valve
is not open.
• Remove and reinstall the water filter.
For PureAdvantage Ultra, be sure to
rotate it to the right until it stops and
the grip end is vertical.
• Replace filter cartridge. Be sure to
rotate it to the right until it stops and
the grip end is vertical.
• Open household water line valve.
See CONCERN column AUTOMATIC
ICE MAKER.
Water
not cold
enough.
• The water dispensing
system is not designed to
chill water.
• Add ice to cup or container before
dispensing water.
Water has
an odd
taste and/or
odor.
• Water has not been
dispensed for an extended
period of time.
• Unit not properly
connected to cold water
line.
• Draw and discard 10-12 glasses of
water to freshen the supply.
• Connect unit to cold water line that
supplies water to the kitchen faucet.
41
Solutions to Common Problems
Concern Potential Cause Common Solution
Opening/Closing Of Doors/Drawers
Door(s) will
not close.
• Door was closed too hard,
causing other door to
open slightly.
• Refrigerator is not level. It
rocks on the floor when
moved slightly.
• Refrigerator is touching a
wall or cabinet.
• Close both doors gently.
• Ensure floor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Ensure floor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
Drawers are
difficult to
move.
• Food is touching shelf on
top of drawer.
• Track that drawers slide on
is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly installed
on track.
• Clean drawer, rollers, and track. See
Care & Cleaning.
Running of Refrigerator
Compressor
does not
run.
• Freezer control is set to
“OF”.
• Refrigerator is in defrost
cycle.
• Plug at electrical outlet is
disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• Set freezer control.
• This is normal for a fully automatic
defrost refrigerator. The defrost cycle
occurs periodically, lasting about 30
minutes.
• Ensure plug is tightly pushed into
outlet.
• Check/replace fuse with a 15 amp
time-delay fuse. Reset circuit breaker.
• Check house lights. Call local electric
company.
Refrigerator
seems to
run too
much or too
long.
• Your variable speed
compressor is designed
to run 100% of the time
except during the defrost
cycle. At times it will run
faster, such as after a
defrost cycle.
• It is normal for the compressor to run
continuously except during defrost
mode.
Digital Temperature Setting Display
Digital
temperature
displays an
error.
• Electronic control
system has detected a
performance problem.
• Call your Electrolux service
representative, who can interpret any
messages or number codes flashing
on the digital displays.
42 Solutions to Common Problems
Concern Potential Cause Common Solution
Water/Moisture/Frost Inside Refrigerator
Moisture
collects on
inside of
refrigerator
walls.
• Weather is hot and humid.
• Flipper mullion
• The rate of frost buildup and internal
sweating increases.
• Adjust flipper mullion. (See “To adjust
the flipper mullion” in the Installation
section.)
Water
collects on
bottom side
of drawer
cover.
• Vegetables contain and
give off moisture.
• It is not unusual to have moisture on
the bottom side of the cover.
• Move humidity control (some models)
to lower setting.
Water
collects in
bottom of
drawer.
• Washed vegetables and
fruit drain while in the
drawer.
• Dry items before putting them in the
drawer. Water collecting in bottom of
drawer is normal.
Water/Moisture/Frost Outside Refrigerator
Moisture
collects on
outside of
refrigerator
or between
doors.
• Weather is humid. • This is normal in humid weather.
When humidity is lower, the moisture
should disappear.
Food in Fresh Food Compartment
Food is
freezing.
• Temperature setting is too
low.
• Temperature sensor is
covered by food (right side
of fresh food area).
• Food is covering the air
ports.
• Move the setting to a higher degree.
• Allow space for air flow to the sensor.
• Allow space between the air ports
and the food.
43
Warranty
Major Appliance Warranty Information
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase,
Electrolux will repair or replace any parts of this appliance that prove to be defective in materials or
workmanship when such appliance is installed, used, and maintained in accordance with the provided
instructions. In addition, the cabinet liner and sealed refrigeration system (compressor, condenser,
evaporator, dryer or tubing) of your appliance is covered by a two through five year limited warranty. During
the 2nd through 5th years from your original date of purchase, Electrolux will repair or replace any parts in
the cabinet liner and sealed refrigeration system which prove to be defective in materials or workmanship
when such appliance is installed, used, and maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed
outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other
consumables, or knobs, handles, or other cosmetic parts.
11. Pickup and delivery costs; your appliance is designed to be repaired in the home.
12. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry
trip charges, or mileage expense for service calls to remote areas, including the state of Alaska.
13. Damages to the finish of appliance or home incurred during transportation or installation,
including but not limited to floors, cabinets, walls, etc.
14. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
external causes such as abuse, misuse, inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE
YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES
SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF
THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES
DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA, Puerto Rico and Canada. In the USA and Puerto Rico, your
appliance is warranted by Electrolux Major Appliances North America, a division of Electrolux Home
Products, Inc. In Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes
no person to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product features or
specifications as described or illustrated are subject to change without notice.
USA
1-877-435-3287
Electrolux Major Appliances North America
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1-800-265-8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada L5V 3E4
