NEC Direct View LED – Intelligent display solutions for a brighter world
The NEC Q Series II Indoor DvLED is designed to provide high-bright, quality imaging
for indoor settings. With pixel spacing options of 2.8mm & 3.9mm the optimum display
resolution can be achieved regardless of viewing distance. The Q Series Indoor dvLED
is engineered to deliver vivid content visualization, even in harsh indoor settings. The
square, modular design can be scaled to any size and allows for creative installations
to be realized. The front and rear serviceable design helps to minimize downtime by
providing easy access and quick maintenance. The Q series indoor dvLED is the ideal
solution for live event venues, DOOH, airports, train and bus stations, and more. NEC
offers full design & planning services plus post installation service plans, ensuring you
get a custom-tailored solution allowing you to focus on what’s most important – your
business.
BENEFITS
Durable Construction ensures reliable operation even in the harshest conditions
Unmatched Brightness for clear and vivid imagery even in the brightest indoor
settings
Strong, Light-weight Modules with quick lock devices to enable rental applications
Easy Front/Rear Access for quick and easy maintenance when needed, minimizing
downtime
NEC Direct View LED-Q039i2
(3.9mm Q Series II Indoor)
DISPLAY
Panel Technology Direct View LED
Pixel Configuration 3-1 SMD (Black)
Panel Resolution 128 x 128
Pixel Pitch 3.91mm
Brightness (typical/maximum) 1200/1320 cd/m²
Lifetime 100,000 hours
Contrast Ratio(typical) 7000:1
Viewing Angle 80/80 horizontal / 75/75 vertical
Dimming Capability 256 levels
Color Processing Up to 16 bit
Displayable Colors 281Trillion
Refresh Rate(Hz) Up to 3840Hz
Connectivity
Input Terminals
Digital: DVI-D Dual Link in/out or HDMI External
Control: RS232 / USB
External Control 1x GenLock; 1x LAN
PowerConsumption(typical)
On 200Watts/sqm
Max 480Watts/Sqm
Physical Specifications
Dimensions (W x H x D) [mm] 500 x 500 x 70mm
Weight 18.3lbs / 8.3kg
Environmental Conditions
Operating Temperature -4° to 104°F / -20° to 40°C
Operating Humidity 10% to 80%
Storage Temperature -4° to 131°F / -20° to 55°C
Servicability
Front & Rear Service
IP Level
IP20
NEC Direct View LED-Q039i2 (3.9mm Q Series II Indoor) - Technical Specification
All other brand or product names are trademarks or registered trademarks of their respective holders.
Product specifications subject to change.
©2022 Sharp NEC Display Solutions of America, Inc. | All rights reserved.
Cat.No. 25.NEC.80.GL.UN.362 | Rev. 08.16.2022
