Durable Indoor Table Tennis Table
SLPPTB22
Designed with MDF Table Top for Optimal Bounce
www.SereneLifeHome.com2
IMPORTANT SAFETY NOTICE
For your safety and benet, read this manual carefully before starting assembly and using this product.
Failure to follow the instructions and safety precautions in this manual can result in serious injury or damage
to equipment.
SAFETY INFORMATION:
• DO NOT allow children to open table. ADULTS ONLY
should open, close, adjust, or move table.
• DO NOT leave children unattended with table.
• DO NOT climb, sit, jump, lean, or stand on table.
Table is not intended to be weight bearing and serious
injury may result.
• Table should only be placed on a at, level surface to
ensure stability.
CARE AND MAINTENACE:
• This table is intended for indoor use only.
• Examine your table regularly for wear and tear.
Discontinue use immediately if any defect or damaged
parts are found.
• When not in use, store table in a dry, indoor space.
Condensation and moisture can cause damage to
table top.
• ALWAYS ensure wheel locks are properly engaged
when stored to secure table.
GENERAL ASSEMBLY WARNINGS:
• ADULTS ONLY should assemble table. At least two (2)
to three (3) adults are required for full assembly.
Tables are HEAVY and SHOULD NOT be lifted or
assembled alone.
• ALWAYS wear appropriate safety equipment during
assembly, especially if operating power tools.
• Assembly area should be clear of children and pets.
• To avoid damage to table top surface, assemble on a
dry, at, and clear area.
• DO NOT tighten hardware until instructed. Only hand
tighten at appropriate steps to secure lock nuts.
• Power drills can be useful, but ensure equipment is set
to low torque before use. If over-tightened, screws can
be stripped.
www.SereneLifeHome.com 3
HARDWARE LIST PAGE
Accessory Holder 3.PCSSupport Tube 4.PCS Strut Tube 4.PCS
Net 1.PCS
Net Clipper 2.PCS
Table Tennis Table Top 2.PCS
Caster Beams 2.PCS
Middle Plate 1.PCS
P1
P3
P6P5
P8
P4
P7
Phillips Head
Screwdriver 5/16" Wrench (x2) 1/4" Wrench (x2)
1
/
4
5
/
16
Bolt M10x110MM 4.PCS Bolt M10x75MM 8.PCS Bolt M8x90MM 4.PCS
H1 H2 H3
P2
TOOLS REQUIRED FOR ASSEMBLY (NOT INCLUDED)
M6 Plastic Spacer 4.PCSM8 Plastic Washer 4.PCS
M10 Plastic Washer
8.PCS
M10 Plastic Spacer
4.PCS
M8 Lock nut 8.PCS M6 Lock nut 6.PCS
M10 Washer 24.PCS
3.0x12MM Screw
4.PCS
M8 Washer 16.PCS M6 Washer 8.PCS
Triangle Support Plates
4.PCS
Stop Spool 8.PCS
H7
H8
H9
H10 H11 H12
H13 H14 H15
H16 H17 H18
M6x15mm Phillips Head Machine Bolt 2.PCS
H19
Bolt M8x60MM 4.PCS Bolt M6x45MM 4.PCS M10 Lock nut 12.PCS
H4 H5 H6
www.SereneLifeHome.com4
STEP 1
Hardware Needed:
• Before beginning, ensure you have cleared an area large enough for the table
to be assembled.
• Align Triangle Support Plate with Caster Beam to line up holes. Thread the bolt
in the following order: Bolt (H2) through a Washer (H13), the Caster Beam (P2),
a Stop Spool (H17), the Triangle Support Plate (H18), another Washer (H13),
and Lock Nut (H6).
• Hand tighten only. DO NOT tighten completely, as nuts/bolts will be adjusted
in a later step.
• NOTE: For easiest set up, try to attach both bolts at the same time on each end.
• Repeat steps for all four sections (x4).
P2
H2
H6
H13
H17
H18
M10 Washer 16.PCS
Caster Beams 2.PCS
Bolt M10x75MM 8.PCS
M10 Lock nut 8.PCS
Triangle Support Plates 4.PCS
Stop Spool 8.PCS
WARNING:
Clear area of small children
and pets
www.SereneLifeHome.com 5
STEP 2
Hardware Needed:
• Attach Middle Plate (P3) to Caster Beams (P2) as shown in the above image.
• Thread the Bolt (H4) through the Washer (H14), both Steel Frames, another
Washer (H14) and secure with Lock Nut (H7).
• Repeat for both Caster Beams then tighten completely.
H4
P3
H7
H14
P2
M8 Lock nut 4.PCS
Bolt M8x60MM 4.PCS
M10 Lock nut 8.PCS
Caster Beams 2.PCS
M8 Washer 8.PCS
www.SereneLifeHome.com6
STEP 3
Hardware Needed:
IMPORTANT NOTE:
• The Gray Support Tube should have the longer end attached to the Caster Beam,
bending up and out.
• The Black Strut Tube should have the longer end attached to the Caster Beam,
bending up and out.
• If needed, loosen the Lock Nuts assembled in step 1.
• Thread the bolt in the following order: Bolt (H1) through Washer (H13), Gray
Support Tube (P4), Plastic Spacer (H9), Caster Beam (P2), Plastic Washer (H10),
Black Strut Tube (P5), Plastic Washer (H10), Triangle Support Plate (H18), Washer
(H13), securing with Lock Nut (H6).
• Repeat steps for all four sections.
• Ensure all nuts are securely tightened before moving onto the next step.
LONG END
SHORT END
H18
H1
H13
H6
H9
H10
M10 Lock nut 4.PCS
Triangle Support Plates 4.PCS
Bolt M10x110MM 4.PCS
M10 Washer 8.PCS
M10 Plastic Washer 8.PCS
M10 Plastic Spacer 4.PCS
P5
P4
P2
Strut Tube 4.PCS
Support Tube 4.PCS
Caster Beams 2.PCS
CAUTION:
DO NOT overtighten the nuts,
as this will apply too much pressure
to the spacers and may cause them
to crack.
www.SereneLifeHome.com 7
STEP 4
• Place the Strut Tubes (P5) in a upward position and lay the Gray Support Tubes
(P4) down in front to avoid interference while attaching the Table Top.
WARNING:
Gray support tubes will
protrude into assembly area,
posing a potential tripping
hazard. Exercise caution
when completing the
remaining assembly steps.
www.SereneLifeHome.com8
STEP 5
Hardware Needed:
• With at least one adult on each side of the table, align the table top U-Beam
with the Black Strut Tubes on the Table Base. In an even and controlled
manner, lower the Table Top to avoid misalignment while attaching to
the Table Base.
• Make sure the pre-drilled holes on the U-Beam line up with the pre-drilled
holes on the Black Support Beam. This is important for a later step.
• Continue on to next step. Once complete with Step 8, you will repeat
steps 5-8 for the other table top
Table Tennis Table Top 2.PCS
P1
WARNING:
• At least (2) to three (3) adults are
required for the following steps.
• DO NOT attempt to assemble alone,
as this may lead to serious injury.
• DO NOT open the table to playing
position until all support beams and
hinges are attached to table frame.
• DO NOT leave table unattended in
standing position. Table could be
knocked over, causing serious injury
or property damage.
ASSEMBLY TIP: if there are three
(3) assemblers, have two lift the
table with one guiding the table
onto the tubes.
www.SereneLifeHome.com 9
STEP 6
Hardware Needed:
H3
P4
H7
H11
H14
M8 Lock nut 4.PCS
Bolt M8x60MM 4.PCS
Support Tube 4.PCS
M8 Washer 8.PCS
M8 Plastic Washer 4.PCS
Support Attachment
• Attach Gray Support Tube (P4) to the outside of the Table Leg.
Thread the bolt in the following order: Bolt (H3) through Washer
(H14), through Gray Support Tube (P4), through Plastic Spacer
(H11), through Table Leg, Washer (H14), securing with Lock Nut (H7).
• Secure tightly and repeat step for other Gray Support Tube.
WARNING:
• DO NOT open the table to playing position
until all support beams and hinges are
attached to table frame.
• DO NOT leave table unattented in the
upright position. Table is not secure yet
and can be knocked over causing bodily
injury or property damage
H7
H14
H14
H14
H14
H3
H3
H7
H11
H11
P4
CAUTION:
DO NOT overtighten the nuts,
as this will apply too much
pressure to the spacers and
may cause them to crack.
www.SereneLifeHome.com10
STEP 7
Hardware Needed:
• Install screws (H16) into the pre-drilled holes on the Black Strut Tubes (P5).
3.0x12MM Screw 4.PCS
H16
WARNING:
• DO NOT open the table to playing
position until all support beams
and hinges are attached to table
frame.
• DO NOT leave table unattented in
the upright position. Table is not
secure yet and can be knocked
over causing bodily injury or
property damage
H16
H16
www.SereneLifeHome.com 11
STEP 8
Hardware Needed:
H5
P5
H8
H12
H15
M6 Lock nut 4.PCS
Bolt M6x45MM 4.PCS
Strut Tube 4.PCS
M6 Washer 8.PCS
M6 Plastic Spacer 4.PCS
Hinge Attachment
• Ensure the hinge is bent with the elbow on the bottom making, a
“V” shape. WARNING: It is very important the hinge is assembled
correctly or there could be damage to the table.
• Thread the bolt in the following order: Bolt (H5) Washer (H15),
Hinge, Spacer (H12), Strut Tube (P5), Washer (H15), then Lock nut
(H8).
• Secure tightly and repeat step for each Hinge.
• Once complete, repeat steps 5-8 for the other Table Top (P1).
WARNING:
• DO NOT open the table to playing position
until all support beams and hinges are
attached to table frame.
• DO NOT leave table unattented in the
upright position. Table is not secure yet
and can be knocked over causing bodily
injury or property damage
H5
H5
P5
P5
H15
H15
H15
H15
H8
H8
H12
H12
www.SereneLifeHome.com12
STEP 9
Hardware Needed:
Accessory Holder 3.PCS
P6
M6 Lock nut 2.PCS
H8
M6x15mm Phillips Head Machine Bolt 2.PCS
H16
Accessory Holder
• Assemble Accessory Holder by positioning one of the plastic pieces over one of the pre-drilled holes on the H frame.
• Screw into the frame with a bolt (H19).
• Secure the middle metal piece by tightly tting it between the two plastic pieces.
• Finish the assembly by screwing in the other plastic piece with a bolt (H19).
• If assembled correctly, the metal holder should t snug between the two plastic holders.
P6
H19
H8
H19
www.SereneLifeHome.com 13
STEP 10
WARNING:
• Area should be clear of children, pets, and any other obstacles when moving the table in different position.
• DO NOT allow children to climb between, under or over any part of the table.
• Adults only should move or open/close the table.
• NEVER leave table unattended in standing position without properly stored. Table could be knocked over, causing
serious injury or property damage.
• NEVER leave table partially opened or not fully secure.
• Before moving on to the next steps, ensure all support tubes and hinges are assembled correctly and appropriately.
• DO NOT grasp metal legs, support pieces, linkage, or hinges. These parts can move and entrapment and/or pinching
of ngers or hands can occur.
Figure 3 Figure 4
Figure 2Figure 1
www.SereneLifeHome.com14
Putting the Table Play-Back and Play Mode
• After correctly assembling both Table Tops, your table can safely be moved from storage mode (Figure 1) to the
play-back (Figure 3) or normal (Figure 4) play position.
• Grab the center of the top edge with both hands. WITH CAUTION, gently pull the table outward until you feel the
legs rest on the oor as shown.
• Secure table by locking the hinges on both sides of the tabletop. Hinges will lock by pushing up on the elbow.
• Repeat steps for the other Table Top.
Putting the Table in Storage Mode
• Before moving the table tops, ensure hinges have been unlocked
• Grab from the center of the top edge, pulling up and out, do not let go until the table comfortably sits on its own.
• Repeat for the other side of the table.
• Once table is secure, you can safely unlock the wheels and move it about.
• For your safety, lock wheels once you have reached the desired storage or play area. Keep wheels locked until you
move the table again. To properly install net, the table will need to be moved into playing position as shown in Fig. 4.
www.SereneLifeHome.com 15
STEP 11
Hardware Needed:
P7
P8
• Now that your table is in play position, you are ready to assemble the net.
• Secure the Net Clipper (P7) to your Table Top (P1) by clipping it near the center of the two Table Tops.
NOTE: If you plan on putting the Table in storage mode, you will want to clip it to only one Table Top surface as
close to the center as possible. The Net Clipper can be moved back once the table is in play position again.
• With white part facing up, attach the Net (P8) to the Net Clipper (P7) by sliding one Net Sleeve into a Net Clipper,
then stretching the Net across the table to slide the sleeve into the other Net Clipper.
• Tighten the Net by pulling the cord down and hooking the chain at the bottom of the Net Clipper.
• To adjust the Net height, crank the wheel underneath the Net Clipper.
Net 1.PCS
Net Clipper 2.PCS
www.SereneLifeHome.com16
Features:
• Box Steel Apron for Durability
• Comes with 50% Pre-assembled
• Easy Set-up by Two People in just 40 minutes
• Includes Net and Clip Set
• For Indoor Use Only
• DSG Exclusive
• Swivel Wheels with Locking Casters for Safe Transport
• Matte Grey Finish
• 4/5"x2” Box Steel Apron
• Foldable Design and Simple & Fast Assembly
• Integrated Paddle and Ball Storage
• Leg Levelers and Bumper Corners for Stability and Protection
What's in the Box:
• Table tennis table • Net and clip set • Instruction book
Technical Specs:
• Wheel diameter: 3" -inches
• Construction Material: MDF+STEEL
• Table Top Thickness: 7/10'' -inches
• Lockable Casters Length: 3'' -inches
• Net Length: 66-1/5'' -inches
• Playback Position Dimensions (L x W x H): 107-9/10'' x 60'' x 7/10'' -inches
• Storage Position Dimensions (L x W x H): 63'' x 57'' x 5-7/10'' -inches
• Table Dimensions (L x W x H): 107-9/10'' x 60'' x 29-9/10'' -inches
www.SereneLifeHome.com 17
