TFHV8 Series
8" High Velocity Turbo Fan
Save These Instructions
3 Speed
Wind
Adjustable
Tilt Up/Down
Wall
Mountable
Quiet &
Efficient
Safety
Grill
Safety
Plug
2
2
INTENDED USE:
This product is intended for indoor residential and ofce use only,
not for industrial or other commercial applications. Use only with
electrical wiring that is in good working order and that meets
applicable codes and ordinances. If you have any questions
whether your wiring is adequate, consult a qualied electrician.
While using your fan, you should follow the IMPORTANT
INSTRUCTIONS listed below. As part of those instructions, we
have used the word "WARNING" to indicate the level of hazard:
WARNING indicates a hazard which, if not avoided, could result
in injury or death.
IMPORTANT INSTRUCTIONS:
As with all electrical appliances, basic safety precautions should
always be followed to reduce the risk of electric shock, re, or
injury to persons, including the following precautions:
• Read all the instructions before using this fan.
• Use this fan only as described in this manual. Any other use not
recommended by the manufacturer may cause electrical shock,
re or injury to persons.
• Do not operate the fan with a damaged power cord or after the
fan malfunctions or has been dropped in any manner.
• Use of extreme caution is necessary when any fan is used by or
near children, disabled persons or pets and whenever the fan is
left operating unattended.
• Do not place the fan on a small, unlevel, uneven or any surface
which might allow fan to tip or fall.
• For proper operation, fan should be placed on a smooth,
non-combustible, level surface.
• Always unplug fan when not in use, when moving from place
to place, when assembling or disassembling parts, and before
cleaning.
• The use of attachments, not recommended or sold by the
manufacturer, may cause hazards.
• Do not use outdoors.
• Do not use fan in window. Rain may cause electrical hazard
(for non-window models).
• Do not operate the fan with blade guards or any safety device
removed.
• Avoid the use of extension cords due to risk of re. If an
extension cord must be used, the cord must be minimum
14 AWG and rated not less then 1875 watts.
• Do not run power cord under carpeting. Do not cover cord with
throw rugs, runners or the like. Arrange cord away from trafc
area where it will not be tripped over.
• Do not insert or allow any object to enter any openings on the
fan. Doing so may cause electric shock and/or re hazard.
Avoid contact with moving parts.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
WARNING: SHOCK HAZARD
Use your fan only in dry environments. This fan is not intended
for use in a bathroom, laundry area, or similar locations, or near
sinks, washing machines, swimming pools or other sources of
water. Never locate fan where it may fall into a bathtub or other
water receptacle. Do not use in damp environments such as
READ & SAVE THESE
INSTRUCTIONS!
ooded basements.
WARNING: HOT SURFACES
Do not touch fan motor when in use. This motor is hot when in
use, to avoid burns, do not let bare skin touch hot surfaces.
WARNING: FIRE HAZARD
Fans have arcing or sparking parts inside. Do not use near
combustible materials or ammable gases or sources of heat. Do
not use in areas where gasoline, paint or ammable materials are
used or stored. To prevent a possible re, do not block air intakes
or exhaust in any manner. Do not insert or allow foreign objects
to enter any ventilation or exhaust opening as this may cause an
electric shock, re, or damage the fan.
WARNING: ELECTRICAL SHOCK HAZARD
Do not use with damaged cord or plug. Use with adequate
electrical system that is up to code.
CAUTION: TO PREVENT ELECTRIC SHOCK,
this product has a polarized two prong plug (one blade is wider
than the other) that must be fully inserted in to a matching
properly grounded outlet. This plug is designed to t a polarized
outlet only one way. If the plug does not t fully into the outlet,
reverse the plug. If the plug still does not t, contact a qualied
electrician. Do not attempt to defeat this safety feature.
CAUTION: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, do not use this product with any
solid-state speed control device.
DO NOT run power cord under carpeting. Do not cover cord
with throw rugs, runners or the like. Arrange cord away from
trafc area where it will not be tripped over. Avoid the use of
extension cords due to risk of re. If an extension cord must
be used, the cord must be minimum 14 AWG and rated not
less then 1875 watts. Do not use an extension cord unless the
plug can be completely inserted into its receptacle. Unplug
the fan when not in use. Do not operate fan with its ventilation
DO NOT operate any fan with a damaged cord or plug or after
fan malfunctions, has been dropped or damaged in any manner.
Do not operate fan with a broken blade, safety cage or any visual
imperfections. Disconnect power before servicing. For repairs
covered under warranty, see warranty statement. For all other
repairs contact
Customer Service by telephone or
mail for
information and assistance.
obstructed.
3
3
USAGE:
Fan Operation: Always operate the fan in the upright position
following all instructions and recommendations listed in this
manual.
Fan Location: Place the fan in the area of the room that will
provide proper fan cooling.
Fan Connection: Plug fan directly into 120 volt A.C., 60 Hz
wall outlet. Be sure plug ts tightly in outlet. A loose connection
may cause overheating and damage to the plug or fan.
Note: To prevent overloading a circuit, do not plug the fan into
a circuit that is servicing other electrical needs.
Turning Fan On/Off: To start the fan, rotate Control Dial from
OFF position to desired fan speed (LOW, MEDIUM or HIGH).
Rotate dial to OFF to discontinue use. Unplug fan when not
in use.
WALL MOUNTING:
(Select models only)
This fan comes with an optional wall mounting bracket (packed
separately).
1. Use the wall mounting bracket as a template to mark your
mounting location before you attach the bracket to the fan.
Note: Fan should be level when mounted and at least one of
the two mounting screw locations should be a wall stud.
2. Place wall mounting bracket on the bottom of the fan and
attach it to the fan using the three enclosed screws as shown
in Fig. 1.
3. Place appropriate fastener into wall. Fasteners can be
purchased at your local hardware store or home center. The
fastener head must t properly into mounting holes located
on wall mounting bracket. Please leave about 3/8" of space
between the fastener head and the wall surface for the
fastener to properly slot into the wall mounting bracket holes.
4. Mount fan with attached wall mounting bracket to fasteners on
the wall. Check to be sure that the fan is secure on the wall as
shown in Fig. 2.
Fig 1
Fig 2
4
4
LIMITED WARRANTY
This unit is guaranteed to the original retail purchaser
against defects in quality or workmanship for a period of
one year from the date of original purchase. If this unit fails
because of a manufacturing defect within 30 days of
purchase, return the unit, with your receipt, to the retailer.
After 30 days, but within the warranty period, if the unit
was purchased within the continental United States, return
it, freight prepaid, to Albatross Industry.INC for repair or
replacement. If the unit was purchased outside the
continental United States, return the unit to the place of
purchase. This warranty does not cover damage caused
by misuse, abuse, overheating or alteration. Repairs made
by anyone other than Albatross Industry.INC are not
covered in this warranty. Albatross Industry.INC will not be
held liable for any losses due to neglectful operation. All
implied warranties, including the warranties of
merchantability and of fitness of purpose, if applicable, are
hereby limited in duration to the period of one
year from the date of original retail purchase. Some states
do not allow limitations on how long an implied warranty
lasts, so the above limitations may not apply to you.
Incidental or consequential damages arising from a breach
of either express or implied warranties are hereby
disclaimed and excluded. Some states do not allow the
exclusion of limitation of incidental or consequential
damages,so this limitation or exclusion may not apply to
you. Upon the expiration of this warranty all such liability
will terminate. No other warranties are expressed or
implied.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state. No
informal dispute settlement mechanisms are available. This
limited warranty is given in lieu of all other warranties.
Manufactured for:
Albatross Industry, Inc.
5818 Sycamore Glen Road, Greensboro, NC 27405
www.albatrossindustry.com
Fig 1
Slide Cover to Open
Fig 2 Fig 3
CARE AND MAINTENANCE:
Cleaning: CAUTION-Before cleaning the fan be sure to
disconnect power cord from the plug. Clean the grille surface
with a clean damp cloth. Do not use harsh chemical or abrasive
cleaners. DO NOT IMMERSE THE FAN OR ANY WIRES IN
WATER. Allow fan to dry completely before use. Periodic grille
cleaning with a vacuum will prevent dust build up. The motor is
sealed and does not require any interior maintenance, cleaning
or lubrication.
Maintenance: The Internal motor bearings are permanently
lubricated at the factory and do not require any additional
lubrication.
Repair: DO NOT OPERATE THE FAN WITHOUT THE GRILLE IN
PLACE. DO NOT USE THE FAN IF IT HAS MALFUNCTIONED OR
BECOME DAMAGED IN ANY WAY.
Storage: Keep original carton for storage of the fan. Coil and tie
the power cord to avoid damage during storage.
Note: Some models come with a plug where you can replace
a fuse. If your model has this, please read and follow the below
instructions to replace the fuse.
This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the
user servicing instructions (follow product marking for proper
fuse rating) and check the product. If the replacement fuse
blows, a short-circuit may be present and the product should
be discarded or returned to an authorized service facility for
examination and/or repair.
Fuse Replacement:
1. Grasp plug and remove from the receptacle or other
outlet device. Do not unplug by pulling on cord.
2. Open fuse cover by sliding open fuse access cover on
top of attachment plug towards blades. See Fig. 2
3. Remove fuse carefully. Use a small tool to pry the end
of the fuse from holder cavity. Be careful not to break
glass window.
4. Replace fuse.
WARNING: Risk of re. Replace fuse only with identical
2.5 or 5.0 Amp, 125 Volt fuse (3.6mm x 10mm). Be sure
fuse is properly seated within its cavity.
5. Close fuse cover by sliding it back to its original closed
position.
