EASY POUR WAFFLE MAKER
Model Number: WM 43981
UPC: 848052005143
Customer Assistance
1-855-451-2897 (US)
Please consider the option to recycle the packaging material.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 1 6/8/18 11:40
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
2
When using electrical appliances, basic safety precautions should always
be followed, including the following:
• Read all instructions before use.
• Do not touch hot surfaces. Use handles or knobs.
• WARNING - to protect against electric shock, fire and personal injury:
- do not immerse cord, plug or appliance in water or other liquids;
- do not immerse the appliance or any electrical components in water or
any other liquids;
- always switch off and unplug the appliance before cleaning.
• Close supervision is necessary when any appliance is used by or near
children.
• Unplug from wall outlet when not in use and before cleaning. Allow
to cool before putting on or taking o parts, and before cleaning the
appliance.
• Do not operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been damaged in any manner. Call our
toll-free customer assistance number for information on examination,
repair, or adjustment.
• The use of accessory attachments not recommended by the appliance
manufacturer may result in re, electric shock or injuries to persons.
• Do not use outdoors or in a damp area.
• Do not place the appliance close to the edge of the countertop.
• Do not let power cord hang over edge of table or counter, or touch hot
surfaces.
• Do not place on or near a hot gas or electric burner or in a heated oven.
• Extreme caution must be used when moving an appliance containing
hot oil or other hot liquids. A re may occur if the appliance is covered
or touches ammable material, including curtains, draperies, walls, and
the like, when in operation. Do not store any item on top of the appliance
when in operation.
• When using this appliance, provide 6 - 8 inches of air space above, behind
and on both sides for air circulation.
• It is recommended that you use a heat-resistant mat underneath the
appliance to avoid any heat damage to your counter or furniture.
• Do not use the appliance with open wae plates.
• To disconnect, turn the control knob (3) to MIN and then remove the
plug from the wall outlet.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 2 6/8/18 11:40
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
3
• Never pull on the power cord to disconnect the appliance from the wall
outlet; instead, grasp the plug and pull on the plug.
• Do not use appliance for other than intended use.
• Do not clean with metal scouring pads. Pieces can break o the pad and
touch electrical parts involving a risk of electric shock.
• Let the appliance cool completely before putting away or storing.
• Never leave the appliance unattended during use.
ADDITIONAL SAFEGUARDS
This appliance is for HOUSEHOLD USE ONLY.
WARNING:
- DO NOT OPERATE THIS APPLIANCE, IF THE POWER CORD SHOWS
DAMAGE OR IF APPLIANCE WORKS INTERMITTENTLY OR STOPS
WORKING ENTIRELY.
• A short power-supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord.
• Longer extension cords are available and may be used if care is exercised
in their use.
• If an extension cord is used:
- The marked electrical rating of the extension cord should be at least as
great as the electrical rating of the appliance.
- The longer cord should be arranged so that it does not drape over
the countertop or table top where it can be pulled on by children or
tripped over unintentionally.
Polarized plug
• This appliance has a polarized plug (one blade is wider than the other).
To reduce the risk of electric shock, this plug is intended to t into a
polarized outlet only one way. If the plug does not t fully in the outlet,
reverse the plug. If it still does not t, contact a qualied electrician. Do
not attempt to modify the plug in any way.
• Do not let children handle or put the electrical cord into their mouths.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 3 6/8/18 11:40
PARTS
4
PARTS
MIN MAX
3
4
5
6
10
7
8
9
2
1
1. Locking latch
2. Pour spout
3. Control knob (browning level:
MIN (light) to MAX (dark))
4. Power cord with plug
5. Power indicator (blue)
6. Ready indicator (green)
7. Lid
8. Wae plate
9. Stand
10. Measuring cup
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 4 6/8/18 11:40
ILLUSTRATIONS
5
ILLUSTRATIONS
MIN
MAX
MIN
MAX
a b
6-8 inches
6-8 inches
6-8 inches
MIN MAX
c
MIN
MAX
d
MIN
MAX
+-
e
MIN MAX
MIN
MAX
MIN
MAX
f
g
MIN
MAX
h
MIN
MAX
i
MIN
MAX
j
185
ML
150
170
k
MIN
MAX
l
MIN
MAX
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 5 6/8/18 11:40
6
OPERATION
m
MIN
MAX
MIN
MAX
n
o
MIN
MAX
WARNING:
- Always use an oven mitt to protect your hand when handling the appliance.
Escaping steam can burn and the appliance housing is hot.
Before rst use
• Remove all packaging materials and/or other transportation means.
• Check package content to verify it is complete and undamaged. Do not operate
the appliance if the content is incomplete or appears damaged. Return it
immediately to Walmart.
Danger of suocation!
- Packaging materials are not toys. Always keep plastic bags, foils and foam parts
away from babies and children. Packaging material could block airways and
prevent breathing.
NOTE:
- The appliance may produce an odor and / or emit smoke when switched on for
the first time, as residues from the production process are eliminated. This is
normal and does not indicate a defect or hazard.
• Clean your appliance and all accessories thoroughly before using for the first time
( Cleaning and Maintenance).
• When using the appliance for the first time, it is recommended to operate it
for at least 10 minutes without any foodstuff on the waffle plates ( Using
the Appliance), until no odor or smoke is present. During use, ensure ample
ventilation.
• Let the appliance cool completely.
• Clean the appliance ( Cleaning and Maintenance).
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 6 6/8/18 11:40
USING THE APPLIANCE
7
This appliance is designed for making waes and is not intended for any other use.
NOTE:
- The appliance has a rated power of 800W. Before plugging it into the wall
outlet, ensure that the electrical circuit is not overloaded with other appliances.
This appliance should always be operated on a separate 120V ~ 60Hz wall
outlet.
- Make sure the lid (7) is closed and the locking latch (1) is locked in place before
connecting the appliance into the wall outlet.
- Do not operate the appliance in the horizontal position.
• Fully unfold the stand (9) and place the appliance on a clean, at and heat
resistant surface (ill.
a
).
• Ensure a minimum distance around the appliance of at least 6 - 8 inches to other
objects, cupboards and walls (ill.
b
).
• Connect the plug (4) into a wall outlet (ill.
c
). The blue power indicator (5) will
turn on.
• Turn the control knob (3) to the desired browning level (ill.
d
), between
MIN and MAX. The appliance will heat up to operating temperature of the set
browning level.
• Once the operating temperature has been reached, the green ready indicator (6)
will turn on. The heat-up time will take about 3 - 5 minutes.
NOTE:
- Leave the lid (1) closed to reduce heat-up time.
Danger of burns!
- Do not touch the waffle plates (8) and/or the lid surface (ill.
e
).
WARNING:
- Never let the power cord (4) come in contact with the lid (7) during use (ill.
f
).
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 7 6/8/18 11:40
USING THE APPLIANCE
8
BAKING WAFFLES
Danger of burns!
- Always use an oven mitt to protect your hand when handling the appliance.
Escaping steam can burn and the appliance housing is hot.
- Do not touch the waffle plates (8) and/or the lid surface.
• Disengage the locking latch (1) and carefully open the lid (7) (ill.
g
).
• Apply cooking spray or spray butter on the waffle plates (8) (ill.
h
).
• Close the lid (7) and engage the locking latch (1) (ill.
i
).
• Pour the batter into the measuring cup (10) until 185 ml (ill.
j
).
• Hold the measuring cup 3 - 5 inches above the pour spout (2) and pour the batter
slowly and steadily into the pour spout (ill.
k
).
NOTE:
- Turn the control knob (3) to adjust the browning level if necessary.
- Use a thinner wae batter rather than a thick one for best results.
- During the cooking process, the green ready indicator (6) will turn on and o
several times to ensure a constant temperature.
- Waes take about 3 - 6 minutes, depending on recipe, or once no more steam
is being emitted.
- Do not open the lid (7) within the rst few minutes, as this may cause the
wae to tear.
• Disengage the locking latch (1), open the lid (7) and remove the waffles using a
plastic or wooden utensil (ill.
l
).
NOTE:
- Never use metal utensils, as these will damage the non-stick coating.
- You may need to adapt the cooking time based on the result of your rst
batches of waes.
• After removing the waffles, keep the lid (7) closed.
• Wait for the green ready indicator (6) to light up again, indicating the operating
temperature of the set browning level has been reached, before repeating the
previous steps to bake more waffles.
• Once you have finished using the appliance, turn the control knob (3) to MIN and
disconnect the plug (4) from the wall outlet (ill.
m
). Both indicators will switch
off.
• Allow the appliance to cool down completely before handling again.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 8 6/8/18 11:40
USING THE APPLIANCE
9
RECIPES
Golden waes
1 ¾ c all-purpose our
2 tsp baking powder
1 tsp baking soda
½ tsp salt
⁄ c bakers sugar
1 c milk
1 c water
3 eggs
1 tbsp vanilla extract
½ tsp almond extract
½ c vegetable oil
• Start with all ingredients at room temperature.
• Sift together flour, baking powder, baking soda, salt and sugar.
• In separate bowl whisk together milk, water, eggs, vanilla extract, almond extract
and oil.
• Add wet ingredients to dry and whisk until batter is smooth. Allow batter to rest
for 5 minutes, stir again. Use the measuring cup to pour batter into the pour
spout when green ready light is illuminated.
• Pour batter slowly and steadily holding the measuring cup 3 - 5 inches above the
pour spout. This helps to prevent clogging of the pour spout. Cook for 4 minutes
with the control knob on MAX level.
• Serves 6. Serve with fresh berries and powdered sugar.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 9 6/8/18 11:40
10
RECIPES
Pumpkin wae
2 c all-purpose our
2 tsp baking powder
1 tsp baking soda
1 tsp salt
1 ½ c milk
½ c water
½ c pureed pumpkin
½ c vegetable oil
3 eggs
⁄ c brown sugar
1 tbsp maple syrup
1 tsp vanilla extract
1 ½ tsp cinnamon
1 tsp ground ginger
½ tsp nutmeg
¼ tsp ground clove
• Sift together flour, baking powder, baking soda and salt.
• In a separate bowl beat together milk, water, pumpkin, oil, eggs, brown sugar,
maple syrup, vanilla extract, cinnamon, ginger, nutmeg and clove.
• Add wet ingredients to dry ingredients and blend together until the batter is
smooth. Allow to rest for 5 minutes, stir again. Use the measuring cup to pour
batter into the pour spout when green ready light is illuminated.
• Pour batter slowly and steadily holding the measuring cup 3 - 5 inches above the
pour spout. This helps prevent clogging of the pour spout. Cook for 4 minutes
with the control knob on MAX level.
• Serves 6. Serve with whipped cream and cinnamon sugar sprinkles.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 10 6/8/18 11:40
11
RECIPES
Cinnamon wae with mascarpone maple honey icing
2 c all-purpose our
2 tsp baking powder
1 tsp baking soda
1 tsp salt
1 tsp cinnamon
2 c buttermilk
½ c vegetable oil
½ c water
2 eggs
⁄ c brown sugar packed rm
1 tsp vanilla extract
• Start with buttermilk, eggs and water at room temperature.
• Sift together flour, baking powder, baking soda, salt and cinnamon.
• In a separate bowl blend together with a hand mixer buttermilk, vegetable oil,
water, eggs, brown sugar and vanilla extract.
• Add wet ingredients to dry and blend until batter is smooth. Allow batter to rest
for 5 minutes, blend again. Use the measuring cup to pour batter into the pour
spout when green ready light is illuminated.
• Pour batter slowly and steadily holding the measuring cup 3 - 5 inches above the
pour spout. This helps prevent clogging of the pour spout. Cook for 3 - 4 minutes
with the control knob on MAX level.
• Serves 6. Serve with: 1 cup mascarpone, ⁄ cup maple syrup and 1 tbsp. honey
blended together, drizzle icing.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 11 6/8/18 11:40
12
RECIPES
Peanut butter wae
1 ¾ c all-purpose our
2 tsp baking powder
1 tsp baking soda
1 tsp salt
⁄ c bakers sugar
1 c milk
1 c water
3 eggs
1 tbsp vanilla extract
½ c creamy peanut butter
½ c vegetable oil
• Sift together flour, baking powder, baking soda, salt and sugar.
• In a separate bowl whisk together milk, water, eggs and vanilla extract.
• In separate bowl blend peanut butter and oil, with hand mixer or blender. Add to
milk mixture and blend until smooth.
• Add wet ingredients to dry and blend until batter is smooth. Allow to rest for 5
minutes, stir again. Use the measuring cup to pour batter into waffle maker when
green ready light is illuminated.
• Pour batter slowly and steadily holding the measuring cup 3 - 5 inches above the
pour spout. This helps prevent clogging of the pour spout. Cook for 3 - 4 minutes
with the control knob on MAX level.
• Serves 6. Serve with jelly or with bacon and banana.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 12 6/8/18 11:40
13
RECIPES
Cheddar jack cheese & chive wae
1 ¾ c all-purpose our
2 tsp baking powder
1 tsp baking soda
1 tsp salt
¼ c bakers sugar
1 tsp herbs de Provence
½ tsp granulated garlic
½ tsp granulated onion
2 c water
3 eggs
½ tsp vanilla extract
½ c vegetable oil
2 tbsp nely chopped fresh chive
⁄ c fancy shredded cheddar & Monterey Jack cheeses
¼ c fancy shredded Parmesan cheese
• Sift together flour, baking powder, baking soda, salt, sugar and spices.
• In separate bowl whisk together water, eggs, vanilla extract, oil and chives.
• Add wet ingredients to dry and whisk until batter is smooth. Mix in shredded
cheeses. Allow batter to rest for 5 minutes, stir again. Use the measuring cup to
pour batter into the pour spout when green ready light is illuminated.
• Pour batter slowly and steadily holding the measuring cup 3 - 5 inches above the
pour spout. This helps prevent clogging of the pour spout. Cook for 4 minutes
with the control knob on MAX level.
• Serves 6. Serve for breakfast with poached egg and sliced avocado or for lunch
with fried chicken and honey.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 13 6/8/18 11:40
CLEANING AND MAINTENANCE
14
HINTS AND TIPS
• The appliance is designed to create a delicious Belgium style waffle without holes,
empty spaces or messy overflow. The waffle plates channel the batter down on a
45% angle to produce a complete waffle with a crisp finish and a tender center.
The batter expands during the cooking process and the overflow is contained in
the pour spout.
• Use the recipes or, if using a boxed waffle mix, follow the instructions and then
thin the waffle mix with water (2 tbsp. to ⁄ cup depending on batch size) for a
smooth pourable batter. Use the measuring cup (10) to pour batter into the pour
spout when green ready indicator is illuminated.
• Pour batter slowly and steadily holding the measuring cup 3 - 5 inches above
the pour spout. This helps to prevent clogging of the pour spout. Cook for 4
minutes with the control knob on MAX level. Disengage the latch, open the lid
and remove the waffle to serve. We recommend using tongs or a fork specially
designed for Belgian Waffles.
• Most waffle batter can be poured directly onto the non-stick waffle plates (8).
Use a cooking spray for dessert waffles or any recipe with a lot of sugar. If your
waffles start to stick, the waffle plates (8) may need to be scrubbed with a nylon
brush to remove any cooked-on food particles.
• Most waffles can be made ahead of time and kept warm in a 200°F (90°C) oven.
• To store waffles, let them cool and then pack into an airtight container. Store in
a refrigerator or freezer. Waffles can be reheated in a microwave oven or regular
oven.
• Most waffles are done in about 3 - 6 minutes. Recipes made from scratch may
take longer. Check if waffles are done after 3 - 6 minutes or once no more steam
is being emitted. If the appliance does not open easily, allow waffles to cook for
another minute before checking again.
• It is recommended to clean all accessories after each use.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 14 6/8/18 11:40
CLEANING AND MAINTENANCE
15
Proper maintenance will ensure many years of service from your appliance. Clean
the appliance after every use. The appliance contains no user serviceable parts and
requires little maintenance. Leave any servicing or repairs to qualied personnel.
WARNING:
- Always disconnect the plug (4) from the wall outlet before cleaning. Allow all
parts of the appliance to cool down completely.
NOTE:
- Do not immerse the power cord with plug (4) or appliance into water or any
other liquids (ill.
n
).
- Do not use abrasive cleaners, steel wool or scouring pads (ill.
o
). Dry all parts
thoroughly after cleaning, before using or storing the appliance. Ensure that no
water enters the appliance housing.
• Wipe the appliance housing, lid (7) and waffle plates (8) with a damp cloth. Rinse
cloth and wipe all parts again.
NOTE:
- Dry all parts and surfaces thoroughly before use. Make sure that all parts and
surfaces are completely dry before connecting the appliance to a wall outlet.
Storage
• Before storage, always make sure the appliance is completely cool, clean and dry.
• It is recommended to store the appliance in a dry place.
• Store the appliance on a stable shelf or in a cupboard. To avoid accidents, ensure
that both the appliance and its power cord are beyond reach of children or pets.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 15 6/8/18 11:40
CLEANING AND MAINTENANCE
16
TROUBLESHOOTING
Problem Cause Solution
The appliance is
not working
Appliance not plugged in Insert the plug into the wall outlet
Wall outlet not energized Check fuses and circuit breaker
Malfunctioning appliance Disconnect the appliance from the
wall outlet and contact qualied
personnel to check and repair the
appliance
Overheated appliance Disconnect the appliance from the
wall outlet and allow to cool down
before using it again
The blue power
indicator is
on but the
appliance does
not heat up
Preheat time too short Let the appliance preheat for a
longer time
Malfunctioning appliance Disconnect the appliance from the
wall outlet and contact qualied
personnel to check and repair the
appliance
The appliance
heats up but
the blue power
indicator is o
Malfunctioning appliance Disconnect the appliance from the
wall outlet and contact qualied
personnel to check and repair the
appliance
Batter is spilling
over
Wae plates overlled Reduce amount of batter used per
serving
Wae batter too liquid Add some our to the batter
Wae is not
fully cooked
Cooking time too short Allow wae to cook for longer
If additional assistance is needed, please contact our Customer Assistance at
1-855-451-2897 (US).
TECHNICAL DATA
Rated voltage: 120V ~ 60Hz Rated power input: 800W
Rated current: 6.7A
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 16 6/8/18 11:40
© 2018 Farberware Licensing Company, LLC. All Rights Reserved.
Copyrights and Trademarks of Farberware Licensing Company,
LLC, including FARBERWARE®, are used under license from
Farberware Licensing Company, LLC.
CUSTOMER ASSISTANCE
If you have a claim under this warranty, please call our Customer Assistance
Number. For faster service, please have the model number and product name ready
for the operator to assist you. This number can be found on the bottom of your
appliance and on the front page of this manual.
Model Number: __________________ Product Name: __________________
Customer Assistance Number 1-855-451-2897
Keep these numbers for future reference!
Two-year limited warranty
What does your warranty cover?
• Anydefectinmaterialorworkmanship.
For how long after the original purchase?
• Twoyears.
What will we do?
• Provideyouwithanewone.
• Forthoseitemsstillunderwarrantybutno
longer available, WAL-MART reserves the
right to replace with a similar FARBERWARE
branded product of equal or greater value.
How do you make a warranty claim?
• Save your receipt.
• Properlypackyourunit.Werecommend
using the original carton and packing
materials.
• Returntheproducttoyournearest
Walmart store or call Customer Assistance
at 1-855-451-2897.
What does your warranty not cover?
• Parts subject to wear, including, without
limitation, glass parts, glass containers,
cutter/strainer, blades, seals, gaskets,
clutches, motor brushes, and/or agitators,
etc.
• Commercialuseoranyotherusenotfound
in printed directions.
• Damagefrommisuse,abuse,orneglect,
including failure to clean product regularly
in accordance with manufacturer's
instructions.
How does state law relate to this
warranty?
• This warranty gives you specic legal
rights, and you may also have other rights
which vary from state to state or province
to province.
• Thiswarrantyisinlieuofanyother
warranty or condition, whether express or
implied, written or oral, including, without
limitation, any statutory warranty or
condition of merchantability or tness for a
particular purpose.
• WAL-MART,FARBERWAREandtheproduct
manufacturer expressly disclaim all
responsibility for special, incidental, and
consequential damages or losses caused
by use of this appliance. Any liability is
expressly limited to an amount equal to
the purchase price paid whether a claim,
however instituted, is based on contract,
indemnity, warranty, tort (including
negligence), strict liability, or otherwise.
Some states or provinces do not allow
this exclusion or limitation of incidental
or consequential losses, so the foregoing
disclaimer may not apply to you.
What if you encounter a problem with this
product while using it outside the country
of purchase?
• Thewarrantyisvalidonlyinthecountry
of purchase and if you follow the warranty
claim procedure as noted.
Waffle Maker_43981_Farberware_IM_US_V3_180608.indd 17 6/8/18 11:40
