Washing Machine
WM7
2 - EN
1 Warnings
General Safety
• Neverplaceyourmachineonacarpet
coveredfloor.Otherwise,lackofairflow
frombelowofyourmachinemaycause
electricalpartstooverheat.Thismaycause
problemswithyourwashingmachine.
• Ifthepowercableormainsplugis
damagedyoumustcallAuthorizedService
forrepair.
• Fitthedrainhoseintothedischarge
housingsecurelytopreventanywater
leakageandtoallowmachinetotakein
anddischargewaterasrequired.Itisvery
importantthatthewaterintakeanddrain
hosesarenotfolded,squeezed,orbroken
whentheapplianceispushedintoplace
afteritisinstalledorcleaned.
• Yourwashingmachineisdesignedto
continueoperatingwhenthepower
restoresafterapowerinterruption.The
machinewillresumeitsprogramwhenthe
powerrestores.Pressthe“Start/Pause/
Cancel”buttonfor3secondstocancelthe
program(See,CancelingaProgram)
• Theremaybesomewaterinyourmachine
whenyoureceiveit.Thisisfromthequality
controlprocessandisnormal.Itisnot
harmfultoyourmachine.
• Someproblemsyoumayencountermay
becausedbytheinfrastructure.Press
“Start/Pause/Cancel”buttonfor3seconds
tocanceltheprogramsetinyourmachine
beforecallingtheauthorizedservice.
First Use
• Carryoutyourfirstwashingprocess
withoutloadingyourmachineandwith
detergentunder“Cottons90°C”program.
• Ensurethatthecoldandhotwater
connectionsaremadecorrectlywhen
installingyourmachine.
• Ifthecurrentfuseorcircuitbreakerisless
than16Amperes,pleasehaveaqualified
electricianinstalla16Amperefuseor
circuitbreaker.
• Whileusingwithorwithoutatransformer,
donotneglecttohavethegrounding
installationlaidbyaqualifiedelectrician.
Ourcompanyshallnotbeliableforany
damagesthatmayarisewhenthemachine
isusedonalinewithoutgrounding.
• Keepthepackagingmaterialsoutofreach
ofchildrenordisposethembyclassifying
accordingtowastedirectives.
Intended use
• Thisproducthasbeendesignedforhome
use.
• Theappliancemayonlybeusedfor
washingandrinsingoftextilesthatare
markedaccordingly.
Safety instructions
• Thisappliancemustbeconnectedto
anearthedoutletprotectedbyafuseof
suitablecapacity.
• Thesupplyanddraininghosesmust
alwaysbesecurelyfastenedandremainin
anundamagedstate.
• Fitthedraininghosetoawashbasinor
bathtubsecurelybeforestartingupyour
machine.Theremaybeariskofbeing
scaldedduetohighwashingtemperatures!
• Neveropentheloadingdoororremovethe
filterwhilethereisstillwaterinthedrum.
• Unplugthemachinewhenitisnotinuse.
• Neverwashdowntheappliancewitha
waterhose!Thereistheriskofelectric
shock!
• Nevertouchtheplugwithwethands.Do
notoperatethemachineifthepowercord
orplugisdamaged.
• Formalfunctionsthatcannotbesolvedby
informationintheoperatingmanual:
• Turnoffthemachine,unplugit,turnoff
thewatertapandcontactanauthorized
serviceagent.Youmayrefertoyourlocal
agentorsolidwastecollectioncenterin
yourmunicipalitytolearnhowtodisposeof
yourmachine.
If there are children in your
house...
• Keepchildrenawayfromthemachine
whenitisoperating.Donotletthem
tamperwiththemachine.
• Closetheloadingdoorwhenyouleavethe
areawherethemachineislocated.
3 - EN
2 Installation
Removing packaging
reinforcement
Tilt the machine to remove the packaging
reinforcement. Remove the packaging
reinforcement by pulling the ribbon.
Opening the transportation locks
A
Transportationsafetyboltsmustbe
removedbeforeoperatingthewashing
machine!Otherwise,themachinewillbe
damaged!
1. Loosenalltheboltswithaspanneruntil
theyrotatefreely(“C”)
2. Removetransportationsafetyboltsby
turningthemgently.
3. Fitthecovers(suppliedinthebagwiththe
OperationManual)intotheholesonthe
rearpanel.(“P”)
C
Keepthetransportationsafetyboltsin
asafeplacetoreusewhenthewashing
machineneedstobemovedagaininthe
future.
C
Nevermovetheappliancewithoutthe
transportationsafetyboltsproperlyfixedin
place!
Adjusting the feet
A
Donotuseanytoolstoloosenthelock
nuts.Otherwise,theycanbedamaged.
1. Manually(byhand)loosenthelocknutson
thefeet.
2. Adjustthemuntilthemachinestandslevel
andfirmly.
3. Important:Tightenalllocknutsupagain.
Connecting to the water supply.
Important:
• Thewatersupplypressurerequiredtorun
themachinemustbe1-10bar(0,1–1
MPa).
• Connectthespecialhosessuppliedwith
themachinetothewaterintakevalveson
themachine.
• Ifyouaregoingtouseyourdoublewater-
inletmachineasasingle(cold)water-inlet
unit,youmustinstallthestopper*,supplied
withyourmachinetothehotwatervalve.
• Ifyouwanttousebothwaterinletsofthe
product,youcanconnectthehotwater
hoseafterremovingthestopperand
gasketgroupfromthehotwatervalve.
* Applies for the products supplied with a blind
stopper group.
• Modelswithasinglewaterinletshouldnot
beconnectedtothehotwatertap.
When returning the appliance to its place after
maintenance or cleaning, care should be taken
not to fold, squeeze or block the hoses.
Connecting to the drain
The water discharge hose can be attached to
the edge of a washbasin or bathtub. The drain
hose should be firmly fitted into the drain as to
not get out of its housing.
Important:
• Theendofthedrainhosemustbedirectly
connectedtothewastewaterdrainorto
thewashbasin.
• Thehoseshouldbeattachedtoaheightof
atleast40cm,and90cmatmost.
• Incasethehoseiselevatedafterlayingit
onthefloorlevelorclosetotheground
(lessthan40cmabovetheground),water
dischargebecomesmoredifficultandthe
laundrymaycomeoutwet.
• Thehoseshouldbepushedintothe
drainageformorethan15cm.Ifitistoo
longyoumayhaveitshortened.
• Themaximumlengthofthecombined
hosesmustnotbelongerthan3.2m.
90
4 - EN
Electrical connection
Connect the machine to an earthed outlet
protected by a fuse of suitable capacity.
Important:
• Connectionshouldcomplywithnational
regulations.
• Thevoltageandtheallowedfuse
protectionarespecifiedinthesection
“TechnicalSpecifications”.
• Thespecifiedvoltagemustbeequalto
yourmainsvoltage.
• Connectionviaextensioncordsormulti-
plugsshouldnotbemade.
B
Adamagedpowercablemustbereplaced
byaqualifiedelectrician.
B
Theappliancemustnotbeoperatedunless
itisrepaired!Thereistheriskofelectric
shock!
3 Initial preparations for
washing
Preparing clothes for washing
Laundry items with metal attachments such
as, bras, belt buckles and metal buttons
will damage the machine. Remove metal
attachments or place the items in a clothing
bag, pillow case, or something similar.
• Sortthelaundryaccordingtotypeoffabric,
color,anddegreeofsoilingandpermissible
watertemperature.Alwaysfollowthe
adviceonthegarmentlabels.
• Placesmallitemslikeinfants’socksand
nylonstockings,etc.inalaundrybag,
pillowcaseorsomethingsimilar.Thiswill
alsosaveyourlaundryfromgettinglost.
• Wash“machinewashable”or“hand
washable”labeledproductsonlywithan
appropriateprogram.
• Donotwashcolorsandwhitestogether.
New,darkcoloredcottonsmayreleasea
lotofdye.Washthemseparately.
• Useonlydyes/colorchangersandlime
removerssuitableformachinewash.
Alwaysfollowtheinstructionsonthe
packaging.
• Washtrousersanddelicateclothesturned
insideout.
Correct load capacity
C
Pleasefollowtheinformationinthe
"ProgramSelectionTable".Washing
resultswilldegradewhenthemachineis
overloaded.
Loading door
The door locks during program operation and
the Door Locked Symbol lights up. The door
can be opened when the symbol fades out.
Detergents and softeners
Detergent Drawer
The detergent dra wer is composed of three
compartments:
The detergent dispenser may be in two
different types according to the model of your
machine.
– (I) for prewash
– (II) for main wash
- (III) siphon
– (
) for softener
Detergent, softener and other cleaning
agents
Add detergent and softener before starting the
washing program.
Never open the detergent dispenser drawer
while the washing program is running!
When using a program without pre-wash, no
detergent should be put into the pre-wash
compartment (Compartment no. I).
Detergent quantity
The amount of washing detergent to be used
depends on the amount of laundry, the degree
of soiling and water hardness.
• Donotuseamountsexceedingthe
quantitiesrecommendedonthepackage
toavoidproblemsofexcessivefoam,
poorrinsing,financialsavingsandfinally,
environmentalprotection.
• Neverexceedthe(>max<)levelmarking;
otherwise,thesoftenerwillbewasted
withoutbeingused.
• Donotuseliquiddetergentifyouwantto
washusingthetimedelayfeature.
5 - EN
Figure 2
4 Selecting a Program and Operating Your Machine
1 - Spin Speed Adjustment Button
2 - Time Delaying Button (+/-)
3 - Temperature Adjustment Button
4 - Start/Pause/Cancel Button
Control panel
Figure 1
7.a - Spin Speed Indicator
7.b - Temperature Indicator
7.c - Spin Symbol
7.d - Temperature Symbol
7.e - Remaining Time and Delaying Time
Indicator
7.f - Programme Indicator Symbols (pre-
wash/main wash/rinse/softener/spin)
7.g - Economy Symbol
7.h - Time Delaying Symbol
7.i - Door Locked Symbol
7.j - Start Symbol
7.k - Standby Symbol
7.l - Auxiliary Function Symbols
7.m - Water cut-off Symbol (According to
your machine’s model)
Display symbols
Turning the machine on
Plug in your machine. Turn the tap on
completely. Check if the hoses are connected
tightly. Place the laundry in the machine. Add
detergent and softener. Press the “On/Off”
button.
Program selection
Turn the Programme Selection Knob to the
program mode that you wish to wash your
laundry.
The recommended temperature and spin
speed for the selected program appear. Press
“Start/Pause/Cancel” button to start the
program.
C
Sortthelaundryaccordingtotypeoffabric,
color,degreeofsoilingandpermissible
watertemperaturewhenchoosinga
program.
Main programs
Depending on the type of textile, the following
main programs are available:
F1
F2
F3
F4
5 - Auxiliary Function Keys
6 - Program Selection Knob
7 - Display
8 - On/Off Button
1 7
2
3
6
5 4
8
6 - EN
• Cotton
You can wash normally soiled durable cotton
clothes with this program. Your laundry will be
washed with vigorous washing movements
during a longer washing cycle.
• Synthetics
You can wash your less durable clothes on
this program. Lighter washing movements
and shorter washing cycle is used compared
to “Cottons” program. It is recommended for
your synthetic clothes (such as shirts, blouses,
synthetic/cotton blended garments, etc.). For
curtains and lace, the “Synthetic 40” program
with pre-wash and anti-creasing functions
selected is recommended.
• Woollens
You can wash your machine-washable woolen
garments on this program. Wash by selecting
the proper temperature according to the labels
of your clothes. It is recommended to use
appropriate detergents for woolens.
Additional programs
For special cases, there are also extra
programs available:
C
Additionalprogramsmaydifferaccording
tothemodelofyourmachine.
• Babycare
Increased hygiene is provided by a longer
heating period and an additional rinse cycle. It
is recommended for baby clothes and clothes
worn by allergic people.
• Cotton Eco
You can wash normally soiled durable cotton
clothes by saving more energy and water with
this program. Your laundry will be washed with
vigorous washing movements and wash time
is longer than “Cotton” programme.
• Mix 40
This program washes for a longer period
at 40°C and gives the same result as the
“Cottons 60°C” program, thus it saves energy.
It is suitable for clothes for which you cannot
use the “Cottons 60°C” program.
• Delicate
You can wash your delicate clothes on this
program. It has more sensitive washing
movements and does not make intermediate
spinning compared to “Synthetic” program.
• Hand wash
You can wash your woolen/delicate clothes
that bear “not machine- washable” labels for
which hand wash is recommended on this
program. It washes the laundry with very
tender washing movements without damaging
your clothes.
• Daily Xpress
This program is used to wash lightly soiled and
unstained cotton garments in a short time.
• Xpress Super Short
You can use this program to quickly wash a
small number of lightly soiled and unstained
cotton garments. E.g.: bathrobes, duvet
covers, sport wear, daily clothes and etc. used
only once.
• Darkcare
Use this programme to wash your dark
coloured laundry, or the coloured laundry
that you do not want them get faded. This
programme washes your laundry with
low mechanical movements and at low
temperature. We recommend you to use
liquid detergent or woolen shampoo for dark
coloured laundry.
Economy Symbol
Shows energy saving programs and
temperature selections.
As “Intensive” and “Baby” programs are long
programs with higher temperature selections
to ensure hygiene, “Economy” Symbol will not
light up.
Special programs
For specific applications, you can select any of
the following programs:
• Rinse
This program is used when you want to rinse
or starch separately.
• Spin+Drain
This program spins with maximum possible
rpm in the default setting after the water drains
from the machine.
C
Usealowerspinspeedfordelicate
laundries.
Temperature selection
Whenever a new program is selected, the
temperature anticipated for that program
appears on the temperature indicator.
To change the temperature, press the
“Temperature” button. Temperature decreases
in 10° increments.
Cold selection is shown with “-” symbol.
90˚C
Heavily soiled, white cottons and
linens.
60˚C
Normally soiled, fade proof colored
linens, cottons or synthetic clothes
and lightly soiled white linens
40˚C
30°C
Cold
Blended clothes including synthetics
and woolens as well as delicates.
Spin Speed selection
Whenever a new program is selected, the
maximum spin speed of the selected program
is displayed on the spin speed indicator.
To decrease the spin speed, press the “Spin”
button. Spin speed decreases gradually. Then,
7 - EN
rinse hold and no spin options are shown
respectively.
Rinse hold is shown with “
” and no spin is
shown with “ ” symbols.
If you do not want to unload your clothes
immediately after the program, you may use
the rinse hold function in order to prevent your
clothes become wrinkled in an anhydrous
condition. With this function, your laundry is
kept in the final rinsing water. If you want to
spin your laundry after the rinse hold function:
- Adjustthespinspeed.
- Press“Start/Pause/Cancel”button.
Programresumes.Yourmachinedrainsthe
waterandspinsyourlaundry.
You can use no spin function in order to drain
the water without spinning at the end of the
program.
• Selectable
* Automatically selected, not cancelable.
*** If maximum spin speed of your machine is lower, selection may be made until maximum spin
speed.
Water and power consumption and programme duration may differ from the table shown,
subject to changes in water pressure, water hardness and temperature, ambient temperature,
type and amount of laundry, selection of auxiliary functions, and fluctuations in the supply
voltage.
C
Theauxiliaryfunctionsinthetablemaydifferaccordingtothemodelofyourmachine.
C
Programmedurationwillbedisplayedonthescreenofyourmachineaccordingtoyour
selection.
Program selection and consumption table
EN
2
Auxiliaryfunctions Temperature
Max.Load(kg)
Water
Consumption(l)
Energy
Consumption
(kWh)
SpinSpeed
(rpm)***
Prewash
QuickWash
RinsePlus
Anti-Creasing
RinseHold
Selectable
temperaturerange
°C
Cotton 90 7 62 2.20 1600 • • • • • 90-Cold
Cotton 60 7 60 1.50 1600 • • • • • 90-Cold
Cotton 40 7 60 0.85 1600 • • • • • 90-Cold
CottonEco 60** 7 60 1.06 1600 • 60
Babycare 90 7 65 2.20 1600 * • 90-30
Synthetics 60 3 50 1.00 1000 • • • • • 60-Cold
Synthetics 40 3 45 0.50 1000 • • • • • 60-Cold
Mix 40 3.5 45 0.55 1000 • • • • • 40-Cold
Darkcare 40 3 80 0.50 1000 * • 40-Cold
Woollen 40 1.5 40 0.30 1000 • • 40-Cold
Handwash 30 1 30 0.20 1000 30-Cold
XpressSuperShort 30 2 30 0.10 1400 • • 30-Cold
DailyXpress 90 7 60 2.00 1400 • • 90-Cold
DailyXpress 60 7 60 1.20 1400 • • 90-Cold
DailyXpress 30 7 70 0.25 1400 • • 90-Cold
** Energy & Water labelling test programme according to AS/NZS 2040.1
8 - EN
Auxiliary functions
Auxiliary Function Selection Buttons
C
Selecttherequiredauxiliaryfunctions
beforestartingtheprogram.
C
Somecombinationscannotbeselected
together.(Ex.:Pre-wash)(Figure1-5a)and
QuickWash(Figure1-5b).
Auxiliary function selection
If an auxiliary function that should not be
selected together with a previously selected
function is chosen, the first selected function
will be cancelled and the last auxiliary function
selection will remain active.
(Ex.: If you want to select pre-wash first and
then quick wash, pre-wash will be cancelled
and quick wash will remain active.
Auxiliary function that is not compatible
with the program cannot be selected. (see,
“Program Selection Table”)
• Prewash
When you select this function (5a), the display
will indicate “1” symbol. A pre-wash is only
worthwhile for heavily soiled laundry. Without
pre-wash you save energy, water, detergent
and time. Pre-wash without detergent is
recommended for lace and curtains.
• Quick Wash
With this function (5b), the wash time is
shortened. The “2” symbol will light up on the
display. Use this function for smaller amounts
or slightly soiled laundries.
• Rinse Plus
This function (5c) allows your machine to
perform an extra rinsing in addition to the
rinsing cycles performed by your machine after
main washing cycle. Thus, the risk for sensitive
skins (babies, allergic skins and etc.) to be
effected by the minimal detergent remnants on
the laundry is reduced. “3” symbol will light up
on the display.
• Anti-Creasing
With this function (5d), drum movement will
be lessened to prevent creasing and spinning
speed is limited. In addition, washing is carried
out at a higher water level. The “4” symbol will
light up on the display.
C
Wheneveryouselectthisauxiliaryfunction,
loadyourmachinewithhalfofthe
maximumlaundryspecifiedintheprogram
table.
Time display
The display shows the time remaining for
the program to complete while a program is
running. Program duration may differ from the
values in the consumption table subject to the
changes in the water pressure, water hardness
and temperature, ambient temperature, type
and amount of laundry, auxiliary functions
selected, and changes in the supply voltage.
Time delay
With the “Time delay” function you can delay
the program start up to 24 hours. Setting can
be made in intervals of 30 minutes.
1. Press“Timedelaying”buttons“+”and“-”
tosetyourdesiredtimedelay.
2. Press“Start/Pause/Cancel”button.Then
thetimedelaystartstocountdown.
C
Morelaundrymaybeloadedortakenout
duringthetimedelayperiod.
Changing the delay time
If you want to change the time during the
countdown:
1. Press“Start/Pause/Cancel”button.
2. Press“Timedelaying”buttons“+”or“-”to
setthedesiredtimedelay.
3. Press“Start/Pause/Cancel”button.
Canceling the time delay
If you want to cancel the time delay
countdown and start the program immediately:
1. Press“Start/Pause/Cancel”button.
2. Pres“TimeDelaying”“-”buttonto
decreasethetimedelay.Programduration
after30minutesshallbedisplayed.
3. Press“Start/Pause/Cancel”buttontostart
theprogram.
Starting the Program
1. Press“Start/Pause/Cancel”buttontostart
theprogram.
2. Thestartsymbol(Figure2-7j)which
indicatesthattheprogramhasstartedwill
lightup.
3. Thedoorlocksandthedoorlocked
symbol(Figure2-7i)willlightup.
4. TheSymboloftherelevantstep(prewash,
mainwash,rinse,softenerandspin)that
theprogramhasstartedfromwilllightup
(Figure2-7f).
C
Ifthemachineisnotspinning,the
programmaybeinrinseholdmodeorthe
automaticspincorrectionsystemhasbeen
activatedduetoanexcessiveunbalanced
distributionoflaundryinthemachine.
Changing the selections after the
program has started
The selected spin speed and program
temperature fade out. An empty frame
appears.
When the “Program selection” button is
brought to the appropriate position, rpm and
temperature data reappear.
9 - EN
Switching the machine to standby
mode
Press “Start/Pause/Cancel” button
momentarily to switch your machine to the
standby mode. Auxiliary functions can be
cancelled or selected in accordance with
the step the program is at. The door can be
opened if the water level is suitable. Laundry
may be added / taken out by opening the
door.
Door lock
The Door Locked Symbol (Figure 2-7i) lights
up when the loading door is locked. This
symbol will flash until the door is allowed to
open. Do not force the door at this stage. You
may open the door after the symbol fades out.
Child-proof lock
This function protects the appliance from
being tampered by children. In this case, all of
the buttons are inactive except On/Off button;
by On/Off button you can whether stop or
resume (while child-lock on) the program of
your machine.
The machine is switched to child-lock by
pressing the 2nd and 4th auxiliary functions
for 3 sec. “C:on” (Child lock is activated) label
appears on the screen. The same symbol
will also be displayed whenever any button is
pressed while the machine is child-locked.
To deactivate the child-proof lock, press the
2nd and 4th auxiliary function buttons for 3
sec. “C:OFF” (Child lock is deactivated) label
appears on the screen.
Ending the program through
canceling
“Start/Pause/Cancel” button is pressed for 3
seconds to cancel the program. Start symbol
(Figure 2-7j) will flash during cancellation. After
cancellation, the symbol of the corresponding
step at which the cancellation was made will
remain lit and “End” will appear on the screen.
End of program
When the program is finished, the symbols
of the relevant steps will remain lit up and
the auxiliary function, spin and temperature
data selected at the start-up of the program
will remain selected. “End” will appear on the
display.
5 Maintenance and cleaning
Detergent Drawer
Remove any powder residue buildup in the
drawer. To do this;
1. Pressthedottedpointonthesiphoninthe
softenercompartmentandpulltowards
youuntilthecompartmentisremovedfrom
themachine.
C
Ifmorethananormalamountofwater
andsoftenermixturestartstogatherinthe
softenercompartment,thesiphonmustbe
cleaned.
2. Washthedispenserdrawerandthe
siphonwithplentyoflukewarmwaterina
washbasin.
3. Replacethedrawerintoitshousingafter
cleaning.Checkifthesiphonisinits
originallocation.
Inlet water filters
There is a filter at the end of each water intake
valve at the back side of the machine and also
at the end of each water intake hose where
they are connected to the tap. These filters
prevent the foreign substances and dirt in the
water to enter into the machine. Filters should
be cleaned as they get dirty.
• Closethetaps.
• Removethenutsofthewaterintakehoses
tocleanthesurfacesofthefiltersonthe
waterintakevalveswithanappropriate
brush.
• Ifthefiltersareverydirty,youcanpullthem
outbymeansofpliersandcleanthem.
• Takeoutthefiltersontheflatendsof
thewaterintakehosestogetherwith
thegasketsandcleanthoroughlyunder
streamingwater.
• Replacethegasketsandfilterscarefullyto
theirplacesandtightenthehosenutsby
hand.
10 - EN
bypullingouttheplugattheendofthe
hose.Iftheamountofwatertobedrained
offisgreaterthanthevolumeofthe
container,replacetheplug,pourthewater
out,thenresumethedrainingprocess.
• Afterdrainingprocessiscompleted,
replacetheplugintotheendofthehose
andfitthehosebackintoitsplace.
If your product is not supplied with an
emergency drain hose, do the following as
shown in the figure below:
• Placealargecontainerinfrontofthefilter
toreceivewaterflowingfromthefilter.
• Loosenpumpfilter(anticlockwise)until
waterstartstoflowoutofit.Directthe
flowingwaterintothecontaineryouhave
placedinfrontofthefilter.Youcanusea
pieceofclothtoabsorbanyspilledwater.
• Whenthereisnowaterleft,turnthepump
filteruntilitiscompletelylooseandremove
it.
• Cleananyresiduesinsidethefilteras
wellasfibers,ifany,aroundthepropeller
region.
• Ifyourproducthasawaterjetfeature,be
suretofitthefilterintoitshousinginthe
pump.Neverforcethefilterwhilereplacing
itintoitshousing.Fitthefilterfullyintoits
housing;otherwise,watermayleakfrom
thefiltercap.
4- Close the filter cap.
Close the two-piece filter cap of your product
by pushing the tab on it.
Close the one-piece filter cap of your product
by fitting the tabs on the bottom into their
positions and pushing the upper part of it.
Draining any remaining water and
cleaning the pump filter
Your product is equipped with a filter system
which ensures a cleaner water discharge that
extends pump life by preventing solid items
such as buttons, coins and fabric fibers from
clogging the pump propeller during discharge
of the washing water.
• Ifyourmachinefailstodrainthewater,
thepumpfiltermaybeclogged.Youmay
havetocleanitevery2yearsorwhenever
itisplugged.Watermustbedrainedoffto
cleanthepumpfilter.
In addition, water may have to be drained off
completely in the following cases:
• beforetransportingthemachine(e.g.when
movinghouse)
• whenthereisthedangeroffrost
In order to clean the dirty filter and discharge
the water;
1- Unplug the machine to cut off the supply
power.
A
Theremaybewaterat90°Cinthe
machine.Therefore,thefiltermustbe
cleanedonlyaftertheinsidewateris
cooleddowntoavoidhazardofscalding.
2- Open the filter cap. The filter cap may be
composed of one or two pieces according to
the model of your machine.
If it is composed of two pieces, press the tab
on the filter cap downwards and pull the piece
out towards yourself.
If it is composed of one piece, hold it from
both sides and open it by pulling out.
3- An emergency drain hose is supplied with
some of our models. Others are not supplied
with this item.
If your product is supplied with an emergency
drain hose, do the following as shown in the
figure below:
• Pulloutthepumpoutlethosefromits
housing.
• Placealargecontainerattheendofthe
hose.Drainthewateroffintothecontainer
11 - EN
8 Solution suggestions for problems
Cause Explanation / Suggestion
Programmecannotbestartedorselected.
Machinemayhaveswitchedtoselfprotection
modeduetoaninfrastructureproblem(suchas
linevoltage,waterpressure,etc.).
Bringyourmachinetofactorysettingsbyturning
theProgrammeselectionknob.(see,Endingthe
ProgrammethroughCancelling)
Waterinthemachine.
Theremaybesomewaterinyourmachine
whenyoureceiveit.Thisisfromthequality
controlprocessandisnormal.
Itisnotharmfultoyourmachine.
Thereiswatercomingfromthebottomofthemachine.
Theremightbeproblemswithhosesorthe
pumpfilter.
-Makesurethatthesealsofthewaterinlethosesare
securelyfitted.
-Tightlyattachthedrainhosetothetap.
-Makesurethatthepumpfilteriscompletelyclosed.
Machinedoesnotfillwithwater
-Tapmaybeturnedoff.
-Waterinlethosemightbebent.
-Waterinletfiltermightbeclogged.
-Theloadingdoormaybeajar.
-Opentheinletwatertapsfully.
-Flattenthewaterintakehose.
-Cleanthewaterintakefilter.
-Closetheloadingdoor.
Machinedoesnotdischargewater.
-Wateroutlethosemightbecloggedor
twisted.
-Pumpfiltermaybeclogged.
-Cleanorflattenthehose.
-Cleanthepumpfilter.
Machinevibratesorshakes.
-Machinefeetmightnotbeadjusted.
-Transportationsafetyboltsmighthavenot
beenremoved.
-Theremaybeasmallamountoflaundryinthe
machine.
-Themachinemaybeoverloadedorthe
clothesmaybedistributedunevenly.
-Theremachinemightbetouchingasolid
surface.
-Adjustthemachinefeet.
-Removethetransportationsafetybolts.
-Addmorelaundrytothemachine.
-Reducetheamountoflaundryinthemachineor
balancetheloadbyhand.
-Ensurethatnothingtouchesthemachine.
MachinestopsshortlyaftertheProgrammestarts.
Machinecanstoptemporarilyduetolow
voltage.
Itwillresumeoperatingwhenthevoltageisbackto
thenormallevel.
Thewaterbeingtakeninisdirectlydischarged.
Improperpositionofthedrainhose.
Connectthewaterdraininghoseasdescribedinthe
operationmanual.
Nowatercanbeseeninthemachineduringwashing.
Thisisnotaproblem.Thewaterlevelisnot
visiblefromtheoutsideofthemachine.
Thedoorisjammed.
-Waterlevelmightbeabovethelowerlevelof
thedoor.
-Machinemightbeheatingupthewaterorit
maybeatthespinningcycle.
-Duetoanelectricalmechanism,thedoor
canonlybeopenedafewminutesafterthe
Programmehasstopped.
-Runeitherthe“Pump”or“Spin”Programme.
-Waituntiltheprocessisover.
-Waituntiltheprocessisover.
12 - EN
Machinefillswithwaterwhenaprocessiscancelled.
Insideofmachinemaybehot.
Forsafetyreasonscoldwaterisaddedtocoolthehot
washload
Itcontinuouslyspins.Remainingtimedoesnotcountdown.(Onmodelswithdisplay)
Theremaybeanimbalanceoflaundryinthe
machine.
-Theautomaticspincorrectionsystemmighthave
beenactivatedduetotheunbalanceddistributionof
thelaundryinthedrum.
-Thelaundryinthedrummaybeclustered(bundled
laundryinabag).Laundryshouldberearrangedand
re-spun.
-Nospinningisperformedwhenthelaundryisnot
evenlydistributedinthedrumtopreventanydamage
tothemachineandtoitsenvironment.
Washingtimetakeslongerthanthetimespecifiedinthemanual
-Waterpressuremaybelow.
-Supplyvoltagemaybelow.
-Inputtemperatureofwatermaybelow.
-Theremaybeanimbalanceoflaundryinthe
machine.
-Numberofrinsesand/oramountofrinse
watermighthaveincreased.
-Themachinewillwaituntilthereissufficientamount
ofwater,whichwilllengthenthewashingtimetoavoid
poorwashingresultsduetoinsufficientwater.
-Washingtimeisextendedtoavoidpoorwashing
resultswhenthesupplyvoltageislow.
-Cycletimeisextendedtoheatupthewaterwhen
theinputwateriscold.Also,washingtimecanbe
lengthenedtoavoidpoorwashingresults.
-Theautomaticspincorrectionsystemmighthave
beenactivatedduetotheunbalanceddistributionof
thelaundryinthedrum.
-Thelaundryinthedrummaybeclustered(bundled
laundryinabag).
-Laundryshouldberearrangedandre-spun.
-Nospinningisperformedwhenthelaundryisnot
evenlydistributedinthedrumtopreventanydamage
tothemachineandtoitsenvironment.
-Wateramountisincreasedtoobtainabetterrinse
andarinsecycleisaddedwhennecessary.
Itcontinuouslywashes.Remainingtimedoesnotcountdown.
Inthecaseofapausedcountdownwhiletaking
inwater:
-Timerwillnotcountdownuntilthemachine
isfilledwiththecorrectamountofwater.(On
modelswithdisplay)
-Timemighthavegottenstuckduringheating
step.(Onmodelswithdisplay)
Inthecaseofapausedcountdownatthe
spinningstep:
Theremaybeanimbalanceoflaundryinthe
machine.(Onmodelswithdisplay)
-Themachinewillwaituntilthereissufficientamount
ofwatertoavoidpoorwashingresultsduetolackof
water.Thenthetimerwillstarttocountdown.
-Timewillnotcountdownuntiltheselected
temperaturefortheProgrammeisattained.
-Theautomaticspincorrectionsystemmighthave
beenactivatedduetotheunbalanceddistributionof
thelaundryinthedrum.
-Thelaundryinthedrummaybeclustered(bundled
laundryinabag).Laundryshouldberearrangedand
re-spun.
-Nospinningisperformedwhenthelaundryisnot
evenlydistributedinthedrumtopreventanydamage
tothemachineandtoitsenvironment.
Itdidnotspin.
-Theremaybeanimbalanceoflaundryinthe
machine.Therefore,theProgrammemighthave
beencompletedwithoutspinning.
-Themachinewillnotspinifthewaterhasnot
completelydrained.
-Theautomaticspincorrectionsystemmighthave
beenactivatedduetotheunbalanceddistributionof
thelaundryinthedrum.
-Thelaundryinthedrummaybeclustered(bundled
laundryinabag).Laundryshouldberearrangedand
re-spun.
-Nospinningisperformedwhenthelaundryisnot
evenlydistributedinthedrumtopreventanydamage
tothemachineandtoitsenvironment.
-Checkthefilter.
-Checkthedrainhose.
13 - EN
Washingperformanceispoor:Laundryturnsgrey
-Usinginsufficientamountofdetergentfora
longtime,
-Washingatlowtemperaturesforalongtime,
-Usinginsufficientamountofdetergentfor
hardwaters(soilcansticktothelaundry),
-Usingexcessiveamountofdetergent
(detergentcansticktothelaundry).
-Usetherecommendedamountofdetergent
appropriateforwaterhardnessandthelaundry.
-Selectthepropertemperatureforthelaundrytobe
washed.
-Ifthewaterhardnessishigh,usinganinsufficient
amountofdetergentcancauselaundrytoturngrey
overtime.
-Itisdifficulttoeliminatesuchgreynessonceit
occurs.
Washingperformanceispoor:Staincouldnotberemoved,notcleaned.Laundrycouldnotbe
whitened.
-Insufficientamountofdetergentused.
-Excessivelaundryloadedintomachine
-WrongProgrammeandtemperaturemight
havebeenselected.
-Improperdetergentmayhavebeenused.
-Wrongtypeofdetergentused.
-Userecommendedamountofdetergentappropriate
forthelaundry.
-Donotloadthemachineinexcess.
-SelecttheproperProgrammeandtemperaturefor
thelaundrytobewashed.
-Putthedetergentinthecorrectcompartment.
-Donotmixdetergentwithbleachingagents.
-Washingperformanceispoor:Oilystainsappearonlaundry.
-Washingperformanceispoor:Badodour
-Oilyaccumulationsonthedrummayhave
stucktothelaundry.
-Oilyaccumulationsonthedrummayhave
stucktothelaundry.
-Suchodoursandbacterialayersareformedon
thedrumasaresultofcontinuouswashingatlower
temperaturesand/orinshortProgrammes.
-Leavethedetergentdispenserdraweraswellasthe
loadingdoorofthemachineajaraftereachwashing.
Thus,ahumidenvironmentfavorableforbacteria
cannotbecreatedinsidethemachine.
-Machinemustbeoperatedemptyeitherat60°Cor
90°CProgrammewithdetergentevery6months.
Colouroftheclothesfaded.
-Excessivelaundryloadedintomachine.
-Detergentmayhavegottendamp.
-Ahighertemperaturemighthavebeen
selected.
-Donotloadthemachineinexcess
-Storedetergentinaclosedanddrylocation.
-Donotkeepthemunderhightemperatures.
-SelecttheproperProgrammeandtemperature
accordingtothetypeandsoilingdegreeofthe
laundry.
Itdoesnotrinsewell.
-Theamount,brandandstorageconditionsof
thedetergentusedmightnotbeappropriate.
-Detergentmighthavebeenputinthewrong
compartment.
-Machinefiltermaybeclogged.
-Drainhosemaybefolded.
-Intermediatespinsmaybeskipped.
-Storedetergentinaclosedanddrylocation.Donot
keepthemunderhightemperatures.
-Ifdetergentisputintheprewashcompartment
althoughprewashcycleisnotselected,machinecan
takethisdetergentduringrinsingorsoftenerstep.
-Checkthefilter.
-Checkthedrainhose.
-Theremaybeanimbalanceoflaundryinthe
machine.
-Thelaundryinthedrummaybeclustered(bundled
laundryinabag).Laundryshouldberearrangedand
re-spun.
-Nospinningisperformedwhenthelaundryisnot
evenlydistributedinthedrumtopreventanydamage
tothemachineandtoitsenvironment.
14 - EN
Clothesstiffened.
-Insufficientamountofdetergentused.
-Thedetergentmayhavebeenplacedintothe
wrongcompartment;thedetergentmaybe
mixedwiththesoftener.
-Ifthewaterhardnessishigher,usinginsufficient
amountofdetergentcancausethelaundrytobecome
stiffintime.Useappropriateamountofdetergent
accordingtothewaterhardness.
-Ifdetergentisputintheprewashcompartment
althoughprewashcycleisnotselected,machinecan
takethisdetergentduringrinsingorsoftenerstep.
-Donotmixthesoftenerwithdetergentwhenputting
inthecompartment.
-Washandcleanthedrawerwithhotwater.
Clothesdonotsmelllikethesoftener.
-Insufficientamountofdetergentused.
-Thedetergentwasplacedintothewrong
compartment;thedetergentwasmixedwith
thesoftener.
-Ifthewaterhardnessishigher,usinginsufficient
amountofdetergentcancausethelaundrytobecome
stiffintime.Useappropriateamountofdetergent
accordingtothewaterhardness.
-Ifdetergentisputintheprewashcompartment
althoughprewashcycleisnotselected,machinecan
takethisdetergentduringrinsingorsoftenerstep.
Donotmixthesoftenerwithdetergentwhenputtingin
thecompartment.
Washandcleanthedrawerwithhotwater.
Detergentresidueinthedispensingdrawer.
-Detergentmayhavebeenputinwet
dispenserdrawer.
-Detergentmayhavegottendamp.
-Waterpressuremightbelow
-Thedetergentinthemainwashcompartment
mighthavegottenwetwhiletakinginthe
prewashwater..
-Detergentmightbemixedwiththebleaching
agent.
-Drythedetergentdrawerbeforeputtingindetergent.
-Storedetergentinaclosedanddrylocation.
-Donotkeepthemunderhightemperatures.
-Thedetergentdispenseroutlet(holes)mayhavea
problem.
-Theremightbeproblemswiththedetergent
dispenservalves.
-Donotmixthesoftenerwithdetergentwhenputting
inthecompartment.
Thereisdetergentleftonthelaundry.
-Excessivelaundryloadedintomachine.
-WrongProgrammeandtemperaturemight
havebeenselected.
-Wrongdetergentmayhavebeenused.
-Donotloadthemachineinexcess.
-SelecttheproperProgrammeandtemperaturefor
thelaundrytobewashed.
-Usewooldetergentsforwoollens.
Thereistoomuchfoam
.
-Youmaynotbeusingproperdetergentfor
automaticwashingmachines.
-Excessiveamountofdetergentmayhavebeen
used.
-Toomuchdetergentmayhavebeenusedfora
smallamountoflightlysoiledlaundry.
-Detergentmayhavebeenstoredimproperly.
-Typeofmaterialbeingwashed(laceitems
willcauseexcessivefoamduetotheirmeshed
structure).
-Detergentmighthavebeenputinthewrong
compartment.
-Softenerbeingreleasedearly.
-Useonlyautomaticwashingmachinedetergentsin
yourwashingmachine.
-Useonlysufficientamountofdetergent.
-Useonlysufficientamountofdetergent.
-Storedetergentinaclosedanddrylocation.
-Donotstoreinexcessivelyhotplaces.
-Usesmalleramountsofdetergentforlaceitems.
-Ifyouputdetergentintheprewashcompartment
althoughyouhavenotselectedaprewashcycle,the
machinecantakethisdetergentduringrinsingor
softenerstep.
-Toomuchsoftenerwasputin.
Thedetergentdispenserisproblematic.Wateris
siphoned(pullingthesoftenerintothewasherearly)
duringthefillorrinsecycles.
Valvesareproblematic.
Thereisfoamingoverthedetergentdrawer
Toomuchdetergentwasused
Mix1tablespoonfulsoftenerand½literwater
andpourintothemainwashcompartmentofthe
detergentdrawer.
15 - EN
WM7
7
84
60
54
72
220-240 V / 50Hz
10
2000-2350
1200
7 Specifications
Specifications of this appliance may change without notice to improve the quality of the product.
Figures in this manual are schematic and may not match your product exactly.
Values stated on the machine labels or in the documentation accompanying it are obtained
in laboratory in accordance with the relevant standards. Depending on operational and
environmental conditions of the appliance, values may vary.
Models
Maximumdrylaundrycapacity(kg)
Height(cm)
Width(cm)
Depth(cm)
NetWeight(±4kg)
Electricity(V/Hz.)
TotalCurrent(A)
TotalPower(W)
Spinningcycle(rpmmax.)
Thisappliance’spackagingmaterialisrecyclable.Helprecycleitandprotecttheenvironmentby
droppingitoffinthemunicipalreceptaclesprovidedforthispurpose.Yourappliancealsocontains
agreatamountofrecyclablematerial.Itismarkedwiththislabeltoindicatetheusedappliances
thatshouldnotbemixedwithotherwaste.Thisway,theappliancerecyclingorganisedbyyour
manufacturerwillbedoneunderthebestpossibleconditions,incompliancewithEuropean
Directive2002/96/EConWasteElectricalandElectronicEquipment.Contactyourtownhalloryour
retailerfortheusedappliancecollectionpointsclosesttoyourhome.Wethankyoudoingyourpart
toprotecttheenvironment.
16 - EN
17 - EN
18 - EN
ELECTRICALDISTRIBRUTORSService&CareCentrePTYLTD
ABN11051297557
1/9TERANCLOSE
WHITEBRIDGENSW2290
PH:0249209114 FAX:0249209115
EMAIL:[email protected]WEBSITE:www.euromaid.com.au
EUROMAIDWASHINGMACHINEWARRANTY
INADDITIONSTORIGHTSBYLAW
ElectricalDistributorsAustraliaPtyLtdguaranteestotheoriginalpurchaserinthefirsttwoyearsofownership
thatanypartwithdefectivematerialbereplacedfreeofcharge,providedthatallserviceworkiscarriedoutby
ElectricaldistributorsAustraliaPtyLtdorthenearestappointedserviceagent.
2YearWarrantyProducts:
FrontLoadwashingmachinesandDishwashers
1YearWarrantyProducts:
Clothesdryers
WheretheapplianceisinstalledoutsidethenormalserviceareaofElectricalDistributorsAustraliaPtyLtdorits
AppointedServiceAgentthepurchaserwillpaythetravelcostchargesfortheserviceagenttoattendtherepairor
totaketheappliancetotheservicecentre.
BuiltIn&FreeStandingAppliances:
AccessmustbegrantedwithinnormalworkinghoursandourServiceAgentsmusthaveeasyaccesstothesebuilt
inappliancesandchargeswillbetheresponsibilityofthepurchaserwheretheservicetechniciancannotobtain
easyaccesstoremovetheapplianceforinspectionpriortorepair.
ThisWarrantyisnottransferableandexcludesanyrepairorreplacementcausedbyPowerSurgesfaulty
installationabuse,PestDamages,misuse,actsofGodoraccident.
TheaboveWarrantyisforDomesticApplicationonlyandislimitedtoThree(3)MonthsinCommercial
Applications.
AUTHORISEDSERVICEAGENTS:
NSW
QUEENSLAND GOLDCOAST
ALLGENERALWHITEGOODS ENDEAVOURREFRIGERATION ROSHADAPPLIANCESERVICE
4/11HALLSTROMPLACE 167ROBERTSONSTREET 1/13LEDADRIVE
WETHERILLPARK2164NSW FORTITUDEVALLEYQLD4006 BURLEIGHQLD4220
PH:0297561511FAX:0297561091 PH:0738727444FAX:0738522465 PH:0755357044FAX:0755357407
VIC
WA
MASTERTECHSERVICES DACAPSAPPLIANCEPARTSANDSERVICE
9KIRKHAMROAD 357SEVENOAKSSTREET
DANDENONGVIC3175 CANNINGTONWA6107
PH:1300131118FAX:1300366705 PH:1800322277FAX:1800354310
TAS
FARRELECTRICALCONTRATOR
286MACQUAIRESTREET
SOUTHHOBARTTAS7004
PH:0362231010FAX0362237039
FOROUTSIDESERVICEAREAS
PLEASECONTACTOURSERVICE&CARECENTREATNEWCASTLE
0249209114
