GB
Quick Guide
CONTROL PANEL
1. ON/OFF button
2. START/PAUSE button and indicator light
3. TEMPERATURE button
4. DISPLAY
5. CHILD LOCK button
6. OPTION button
7. DELAYED START button
8. SPIN button
9. WASH CYCLE SELECTOR KNOB
10. PUSH & GO button
WASH CYCLE TABLE
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
DETERGENT DISPENSER DRAWER
1
9
2 3
5
6
78
10
4
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
Compartment 1:
Do not insert detergent in this compartment.
Compartment 2: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage.
If powder detergent is used, insert the partition
into slot B.
Compartment 3: Additives (fabric softener, etc.)
The fabric softener must never exceed the “max”
level indicated on the central pin.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
! To remove the drawer, press lever C and pull the drawer outwards.
C
* By selecting the 16 cycle and excluding the spin cycle, the washing machine will drain only.
** The duration of the wash cycles can be checked on the display.
*** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
**** The display will show the suggested spin speed as default value.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected. The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60
-
Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.
The most ecient programme in terms of energy and water consumption for washing
normally soiled cotton laundry.
Note: spin speed values shown on the display can slightly diers from the values stated in the table.
For all testing institutes:
2) Long cotton cycle: set cycle 6 at a temperature of 40°C.
3) Long synthetics cycle: set cycle 7 at a temperature of 40°C.
Maximum load 10 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(***)
Energy
consumption
kWh
Total water l
Laundry
temperature °C
Wash cycle
Temperature
Maxim
spin
(r.p.m.)
Max.
load
(kg)
Duration
(h : m)
Wash
Fabric
softener
Powder
Liquid
Setting Range
2 3
1 Cotton 30°C
– 30°C 1200 5 **
–
– – – –
2 Synthetics 30°C
– 30°C 1000 5 **
–
– – – –
3 Colours 30°C
– 30°C 1000 5 **
–
– – – –
4 Delicates 30°C
– 30°C 600 (****) 1 **
–
– – – –
5 Rapid 30min 30°C
– 30°C 1200 (****) 5.5 0:30
–
71 0.21 50 27
6 Cotton (2) 40°C
– 60°C 1600 10 3:55
49 1.14 107 45
7 Synthetics (3) 40°C
– 60°C 1200 5.5 2:55
35 0.83 80 43
8 Mixed 40°C
– 40°C 1600 10 **
–
- - - –
9 Eco 40-60 (1) 40°C 40°C
1551 10 3:59
44 0.89 64 30
1551 5 3:00
44 0.57 61 28
1551 2.5 2:30
44 0.40 40 22
10 White 60°C
– 90°C 1600 10 2:40
54 1.90 100 55
11 Rapid 20°C
– 20°C 800 2.5 **
–
– – – –
11 Rapid 40°C
– 40°C 1200 5.5 **
–
– – – –
11 Rapid 60°C
– 60°C 1000 10 **
– – – –
12 Duvet 30°C
– 30°C 1000 3.5 **
–
– – – –
13 Wool 40°C
– 40°C 800 2.5 **
–
– – – –
14 20°C
20°C
– 20°C
1600 10
1:50
–
55 0.20 95 22
15 Rinse + Spin – – 1600 10 ** –
– – – – – –
16 Spin + Drain * – – 1600 10 ** – – – – – – – –
Required dosage Optional dosage
