Renogy RBC20A1 12V 20A AC-to-DC LFP Portable Battery Charger

1. This charger is specially designed for lithium battery charging.

2. This is a 12V dedicated lithium battery charger, where 12V refers to the voltage platform of the battery. The 12V voltage platform has one form: the battery itself is a 12V battery, and the other is formed by connecting multiple small voltage platform batteries in parallel. For example, two 12V lithium batteries are connected in parallel can form a 12V voltage.

To sum up, this charger is designed for 12V lithium iron phosphate.

1. When the charger is in the fast high-current charging stage, it will provide a maximum charging current of 20A, and the charger's indicator light is slow flashing red, indicating that it is charging.

2. When the charger is in the constant voltage charging stage, the charging current will continue to decrease to 2A, and the charger's indicator light is slow flashing red, indicating it is charging.

3. When the charger is in the trickle phase, the charging current will be less than 1A, and the charger's indicator light will be green, indicating that it is fully charged.

1. Accessories include an alligater clip battery cable, and Blade Fuse.

2. The role of the battery cable: Provide one easy-to-operate connection methods to facilitate the user to realize the connection between the charger and the battery quickly

3. The role of the Blade Fuse: to provide the reverse connection protection of the battery. If the charger's positive and negative output terminals are accidentally reversed, it will burn only the fuse, and the AC charger will be safe, providing double protection.

The charging current of this charger is 20A. When using it, you need to make sure the maximum charging current of the battery is ≥20A. The total charging time for a 100Ah lithium battery is 3.5 hours.

Yes, this charger has a lithium battery activation function. When the lithium battery cannot be charged and discharged after triggering the BMS protection, this charger can be used to wake up the lithium battery.
