T27032 All Colour Variants
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
SANDWICH | PANINI | WAFFLE
DEEP FILL SNACK MAKER
3-IN-1
YEAR
GUARANTEE
2
This box contains:
Instruction Manual
2 Slice Deep Snack Maker
3 x Sets Non-stick plates:
(Waffle Plates)
(Panini Plates)
(Sandwich Plates)
1. Power light
2. Ready light
3. Upper Cooking plates release
buttons (under lid)
4. Non-stick cooking plates
(3 options)
5. Lower Cooking plates release
buttons (under lid)
6. Locking latch
7. Cool touch handle
Specifications:
1 2
6 5 7 4
3
Description: Deep Fill Snack Maker
Model: T27032 All Colour Variants
Rated Voltage: 220-240V~
Frequency: 50/60Hz
Power Consumption: 900W
Technical Data:
3
Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals in
your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must
be connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the same
rating already fitted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualified electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead and
should the fuse need replacing, you must use an
ASTA approved one (conforming to BS 1362 of
the same rating).
If in doubt, consult a qualified electrician who
will be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
4
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualified person.
• Do not let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• Do not carry the appliance
by the power cord.
• Do not use any extension
cord with this appliance.
• Do not pull the plug out
by the cord as this may
damage the plug and/or
the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or before
cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved.
• Cleaning and user
maintenance should not
be undertaken by children
without supervision.
• Take care when any
appliance is used near
pets.
• Do not use this product
for anything other than its
intended use.
• This appliance is for
household use only.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• Do not immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:
5
• Do not use the appliance
outdoors.
• High temperatures are
present during operation.
• Only touch the handles
on the unit.
• This appliance can
produce steam as part
of the cooking process.
Avoid contact with
steam escaping from the
appliance.
• The appliance is not
intended to be operated
by means of an external
timer or separate remote
control system.
• Extreme caution must be
used when moving an
appliance that produces
hot oil or other hot liquids
from the cooking process.
• Bread, oil, and other foods
may burn. Don’t use the
Sandwich Maker near or
below curtains or other
combustible materials,
and watch it while in use.
• Don’t wrap food in plastic
film, polythene bags, or
metal foil. You’ll damage
the Sandwich Maker,
and you may cause a fire
hazard.
• Keep the Sandwich Maker
and the cable away from
hotplates, hobs or burners.
• Don’t use the Sandwich
Maker for any purpose
other than toasting
sandwiches/making
toasties.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
+44 (0) 333 220 6066
6
Before First Use:
Read all instructions and safety information carefully before first use. Please retain this information
for future reference.
1. Carefully unpack the appliance. Remove all packaging materials.
2. Place the appliance on a flat, level surface. Open the snack maker lid.
3. Wipe the cooking plates with a damp cloth so that they are clean.
Note: Use a small amount of cooking oil to season the cooking plates, and wipe off any excess with a
dry cloth. This only needs to be done once.
4. Wipe the outside of the housing with a soft damp cloth. NEVER immerse the power cord and
plug in water or any other liquid.
5. Close the appliance.
6. Plug into the wall outlet and pre-heat. The appliance is ready for use once the green indicator
goes out. This will take approximately 5 minutes.
Note: During this initial phase some smoke may be emitted from the snack maker. This is normal.
Preparing sandwiches:
1. Butter the bread on the outer surfaces and place desired fillings within.
2. Lift safety catch and open the snack maker. Place sandwiches on the heating plates.
3. Close the casing to ensure that the sandwich is placed evenly.
4. Lock the safety catch.
5. Normal cooking times will be 3-6 minutes for each sandwich. The red light will turn on and off,
as the thermostat keeps the snack maker at the proper baking temperature.
CAUTION! The appliance is not to be operated in the open position.
CAUTION! The cooking surface is hot; handle with care.
Serving your sandwiches:
1. Remove the sandwiches from the heating plates with a plastic or wooden spatula.
2. Be careful with your sandwiches, the fillings will be quite hot.
3. Allow to cool for a few minutes before enjoying.
Heating a Panini:
1. Place the panini plates onto the snack maker and turn on the unit. Once the green light goes
out the appliance is ready to cook.
2. Prepare your Panini with your chosen ingredients and turn on the unit. Close the lid while the
plates heat.
3. Once the green indicator goes out, open the snack maker and place the Panini into the centre.
4. Press the top down with a little pressure upon the Panini and then allow it to cook for 3-6
minutes according to your preference.
Making Waffles:
1. Place the waffle plates onto the snack maker and turn on the unit. Once the green indicator
light goes out the appliance is ready to cook.
2. Once you have prepared your favourite waffle mix and it is at the correct consistency, pour
slowly and evenly, making sure liquid doesn’t overflow, into the waffle plates.
3. Waffle cooking times will vary according to the consistency of your mix, we recommend no less
than 2 minutes, and that cooking until golden brown offers an ideal result.
4. Once cooked to your satisfaction, carefully remove with tongs and add your favourite toppings.
Tips:
• Always preheat your snack maker fully.
• Ensure the lid of the snack maker is down whilst preheating.
• Butter, margarine and olive oil can all be used to coat the outside of your bread.
• Light/Low fat versions of margarines are not recommended as they do not withstand heat.
• Fillings: Try to use canned or pre-cooked fruit as fresh fruit may give off excessive juices when
heated. Be careful when biting into toasted sandwiches containing fillings such as cheese and
tomato or jam as they retain heat and can burn if eaten too quickly.
• Processed cheeses tend to ‘run’ under higher temperatures.
• Pat moist ingredients (such as sliced tomatoes and fruits) dry before adding to your sandwich.
• Allow hot sandwiches to rest for 2-3 minutes after removing them from the snack maker. This
helps the fillings cool slightly and means they will run less.
7
Inserting and Removing the Cooking Plates:
1. Insert the cooking plate into the underside of the lid. Place the 2 wide pins into the hinge slots.
Push the locking pin at the top right of the plate in to the aligned hole in the lid, pressing to
ensure that the plate clicks into place.
2. Insert the cooking plate into the bottom of the unit. Place the 2 wide pins into the hinge slots.
Push the locking pin at the bottom left of the plate in to the aligned hole in the base, pressing
to ensure that the plate clicks into place.
3. To remove the plates, open the lid and press the corresponding plate release buttons on the
sides of the unit to release the plates.
Note: Always unplug the appliance and allow it to cool before removing cooking plates.
Troubleshooting:
Questions Answers
Do the indicator
lights show when my
sandwich is done?
No. The indicator lights only indicate power, and that the snack maker
has reached the correct temperature. Ensure you do not leave the snack
maker unattended during use.
How long will it take
to make a toasted
sandwich?
We recommend toasting your sandwiches for around five minutes.
Generally the sandwiches will be ready approximately 2-4 minutes
after adding them to the snack maker, depending on your
preference.
Why are my fillings
spilling over during
cooking?
You may have added too many fillings to your sandwiches. Ensure
that no fillings are ‘overflowing’ when you add the sandwich to the
snack maker. Fillings such as cheese and jam reach very high
temperatures when heated and can spill over.
Cleaning & Care:
• This appliance requires little maintenance. It contains no user serviceable parts. Do not try to
repair it yourself. Refer it to qualified personnel if servicing needed. Always unplug this snack
maker from power source and wait until it cool down before cleaning.
• There is no need to take your snack maker apart for cleaning. Dry with a paper towel to absorb
excess oil. Brush crumbs from the grooves, and wipe with damp cloth and mild soap.
• The cooking plates can be removed and washed in warm soapy water or placed in a
dishwasher.
• Never immerse the unit in water or any other liquid.
• Avoid using abrasive cleaners, scratching or sharp utensils, as they will damage the non-stick
surface.
• Do not use cleansers or oven cleaners on the heating plates.
• To clean handles and other parts, use a damp cloth with mild soap. Should any filling be
difficult to remove, pour a little cooking oil onto the plate and wipe off after 5 minutes, when
the filling has softened.
IMPORTANT! After cleaning, allow the appliance to dry fully before using again.
Do not use the appliance if damp. Ensure the appliance is completely clean and dry before
storing.
Storage:
To store your appliance:
1. Unplug the power cord from the power outlet and clean as above.
2. Allow the appliance to dry fully.
3. Store on a flat, dry, level surface, preferably in its original packaging, and out of reach of
children.
8
Check these charts for basic imperial to metric conversions of
weights.
Food Allergies
Important Note: Some of the recipes contained in this document may contain nuts and/or other
allergens. Please be careful when making any of our sample recipes that you ARE NOT allergic
to any of the ingredients. For more information on allergies, please visit the Food Standards
Agency’s website at: www.food.gov.uk
Weights & Measures
Metric Imperial US cups
250ml 8 floz 1 cup
180ml 6 fl oz 3/4 cup
150ml 5 floz 2/3 cup
120ml 4 floz 1/2 cup
75ml 2 1/2 floz 1/3 cup
60ml 2 floz 1/4 cup
30ml 1 floz 1/8 cup
15ml 1/2 floz 1 tablespoon
Imperial Metric
1/2 oz 15g
1 oz 30g
2 oz 60g
3 oz 90g
4 oz 110g
5 oz 140g
6 oz 170g
7 oz 200g
8 oz 225g
9 oz 255g
10 oz 280g
11 oz 310g
12 oz 340g
13 oz 370g
14 oz 400g
15 oz 425g
1 lb 450g
Fillings:
Savoury:
• Ham, Cheese and Tomato
• Tuna Melt - Tuna, Mayonnaise and
Cheese
• Roast Pork and Apple Sauce
• Turkey, Stuffing and Cranberry
• Cheese, Beans and Sausage
• BLT - Bacon, Lettuce and Tomato
• Brie, Cranberry Sauce and Rocket
Sweet:
• Chocolate Spread and Banana
• Toffee and Apple
• Cherry Pie Filling
• Apple and Blackcurrant
• Apple and Sultanas
9
Ingredients
4 slices of bread
6 slices of prosciutto
55g fresh mozzarella
(approximately 2 to 3 slices per
sandwich)
Ingredients
4 slices of bread
Smoked salmon
Cream cheese
Prosciutto and Fresh Mozzarella
Makes 2 sandwiches
Smoked Salmon and Cream Cheese
Makes 2 sandwiches
Method
1. Plug in your Sandwich Maker to preheat.
2. Place two slices of bread on your work surface and butter
them.
3. Turn the bread butter side down and evenly place the
prosciutto and mozzarella slices on to the bread.
4. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
5. Once the sandwich maker has preheated, place the
sandwiches in the heated plates and close the lid.
6. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
7. Cut the sandwiches along the perforated edges and
serve.
Method
1. Plug in your Sandwich Maker to preheat.
2. Place two slices of bread on your work surface and butter
them.
3. Turn the bread butter side down and evenly spread the
cream cheese and place the smoked salmon on to the
bread.
4. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
5. Once the sandwich maker has preheated, place the
sandwiches in the heated plates and close the lid.
6. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
7. Cut the sandwiches along the perforated edges and
serve.
10
Ingredients
4 slices of bread
4-6 slices of Cheddar cheese
(or your favourite cheese)
Traditional Grilled Cheese
Makes 2 sandwiches
Method
1. Plug in your Sandwich Maker to preheat.
2. Place two slices of bread on your work surface and butter
them.
3. Turn the bread butter side down and add the slices of
cheese.
4. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
5. Once the sandwich maker has preheated, place the
sandwiches in the heated plates and close the lid.
6. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
7. Cut the sandwiches along the perforated edges and
serve.
Ingredients
4 slices of bread
1 tomato, sliced
4 bacon strips
2 thick slices of cheese
Breakfast Sandwich
Makes 2 sandwiches
Method
1. Pre-cook your bacon.
2. Plug in your Sandwich Maker to preheat.
3. Place two slices of bread on your work surface and butter
them.
4. Turn the bread butter side down and place the cooked
bacon, tomato slices and cheese inside.
5. Butter the remaining two slices of bread and place on
top, butter side up, creating your sandwich.
6. Once the sandwich maker has preheated, place the
sandwiches in the heated plates and close the lid.
7. Toast for approximately 5 minutes, or until the bread is
evenly toasted.
8. Cut the sandwiches along the perforated edges and
serve.
11
Your Own Recipes:
0120.V11220.V1
thank you!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to
the place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
YEAR
GUARANTEE
