V6
Model No.:Epower-336
USER MANUAL
Thanks for choosing VTOMAN V6 smart car jump starter. Please read the user manual
carefully before use and keep it for further reference.
A. CONFIGURATIONS
1.
2.
3.
4.
5.
6.
7.
8.
Power switch
Electricity indicator
Type-C Input port
5V/9V/12V Quick-charge output
5V/2.4A output
LED Flashlight (Strong, Strobe, SOS)
12V Jumper cable interface
Compass
- 01 -
1
2
3
4
6
7
8
5
Type-c Input Port
B
B. ELECTRICITY INDICATORS
Press the power switch, the indicators will show electricity as follows:
During charging, the blinking light indicates how much electricity has been charged.
And all lights will go off when it is fully charged.
C.INSTRUCTIONS
Steps To Recharge The Unit
1. Connect the wall charger with the unit.
2. Plug the wall charger into your universal output socket (100-240V).
Indicators
V6 Electricity
0
0%
1
25%
2
50%
3
75%
4
100%
- 02 -
12V Jumper Cable Interface
Smart Jumper Cable
Steps To Jump Start Vehicles (12V Only)
1.
2.
3.
Plug the blue end into the jumper cable interface of the unit
and make sure the safety indicator is off.
Connect the clamps to vehicle battery. Red clamp to
positive polarity (+), black clamp to negative polarity(-).
Operate according to the state of the safety indicator.
Steps To Charge Your Electronics
1.
2.
3.
Connect the type-a end to the quick-charge port of the unit.
Connect the other end to your electronics.
Press the power button, the unit will automatically detect the battery interior and
delivery at the most suitable current, which is faster and safer.
4.
5.
Turn the vehicle ignition switch to START position.
Remove the jumper cable after the vehicle being started.
- 03 -
The indicator is steady green:
Connection is right and it’s
ready for jumping start.
The indicator flashes in green :
The vehicle battery is at low
voltage, you need to press the
"BOOST" button and wait until
the green light becomes
steady, then start your car
within 30 seconds.
The indicator is steady red and
there is buzzing:
The positive and negative poles
are reversed. Please reconnect
and wait until the indicator turns to
steady green
The indicator does not light, and
there is no buzzing:
The vehicle battery may be totally
dead, please make sure the
connection is right, after that,
press the “BOOST” button and
wait until the indicator become
steady green, then go to start your
car within 30 seconds.
Steps To Switch Light Modes
Press and hold the switch button for 3 seconds to turn on the lighting mode, and then
each time you press it more, you can switch to flash, SOS, and finally turn it off.
D. PACKAGE CONTENT
E. SPECIFICATIONS
Unit size: 6.69*3.25*1.34 inches
Unit weight: 0.99lb / 435g
Battery capacity: 37Wh
Output: 5V/9V/12V Quick-charge; 5V/2.4A, 12V Jumper cable interface
Input: 5V/3A Type-C input
Full charge time: 4~5 hours
Starting current: 300A (3S)
Peak current: 1500A
Operating temp: -20°C ~ 60°C / (-4 °F~140°F）
No.
①
②
③
Name
Host
Jumper Cable
Type-C USB Cable
Quantity
1
1
1
No.
④
Name
User Manual
Storage Bag
Quantity
1
1
- 04 -
F.Q&A
1.
2.
3.
4.
5.
6.
G.TROUBLESHOOTING
H. TOXIC AND HAZARDOUS SUBSTANCES ILLUSTRATION
Case
The V6 does not
respond after
pressing the power button
Cause
The circuits is cut off by
self-protection because
of its low voltage or overheat.
Solution
Recharge the unit until at least 3 lights
are lit, or let it cool down for 10 minutes
until the temperature is below 55°C
before you can use it again.
Toxic And Hazardous Substances Or Elements
Pb
O
Hg
O
Cd
O
Cr（Vi）
O
PBB
O
PBDE
O
O: The content of this hazardous substance in all homogeneous materials
of the component is below the limit requirements specified in
the 2002/95/EC (Rohs) standard.
- 05 -
Q: How to turn off the jump starter ?
A: The product has a smart detection function. Once there is no load, or the
electronic product is fully charged, it will automatically shut down and save the
power to avoid loss.
Q: How long does it take to fully recharge the V6?
A: Approx 4~5 hours.
Q: How many times can this V6 charge a phone ?
A: Depending on the battery capacity of the cell phone. Taking iPhone8 as an
example, it can be filled 6 times in a row.
Q: How many times can V6 start cars after a full charge ?
A: Approx 20 times.
Q: What’s the service life of V6 ?
A: In normal use, it can work for 2~3 years.
Q: How long can it keep charged while not using ?
A: The circuit design of the V6 is very scientific. It doesn’t matter if it is not used for
6-12 months, but in order to extend the service life, it is recommended to charge it
every three months.
I.PRECAUTIONS
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
11.
12.
13.
14.
15.
16.
17.
Please be cautious when using.
Please read the instructions carefully before use.
The product can only be used for starting 12V vehicles. It is prohibited to use it on
equipment such as aircrafts and ships.
Please do not use it if the clamp or the unit has any damage.
Prohibit using it as a car battery.
Prohibit using it as a car battery charger.
Please remove the unit from your car battery in time after cranking your car
successfully.
Please use the equipped jumper cables and other accessories come with it only.
Please make sure that the blue end of the jumper cable is fully inserted into the
jumper cable interface, otherwise, the blue end may melt.
Before use, make sure all battery connectors are clean and the clamps are
connected right. If the battery poles are dirty or corrosive, the start-up performance
of the product will be reduced.
Please do not use more than 3 times in a row. Or it can be overheated and
damaged. It’s better to let it cool down for 2 minutes after using 3 times in a row.
Please remove the product from the car battery within 30s after use, or it may
cause damage.
Do not connect the positive and negative terminals together when the power is on.
Please make sure that at least 3 lights are lit before use.
Please keep this product away from children.
Do not play it as a toy.
Do not wet the product.
Do not immerse the product in water.
Do not operate the product in an explosive atmosphere like the presence of
flammable liquids, gases or dust.
Do not remodel or disassemble the product. Only professional technicians are
allowed to repair.
Do not expose the product to extreme heat or fire.
To avoid the risk of short-circuiting caused by metals falling into the hole, please
remove your jewelries such as rings, bracelets and necklaces before using the
product.
Do not drop the product. If the product is impacted or damaged, it must be tested
by a qualified battery technician.
Do not place the product in an environment where the temperature exceeds 70°C.
Please charge at room temperature not exceeding 60°C.
18.
19.
20.
21.
22.
23.
24.
25.
- 06 -
Please use the charger delivered with the power pack to charge it only.
Do not start cars while charging the unit.
If the host leaks, please immediately recycle it with proper equipment.
Under extreme conditions, battery leakage may occur. If the liquid comes out of
the product, it cannot be handled directly by hand. In the case of skin contact,
wash immediately with soap and water. If the liquid comes in contact with your
eyes, rinse your eyes with cold tap water for at least 10 minutes and seek medical
attention immediately.
Lithium-ion battery-based products should be disposed in accordance with local
regulations at the end of their life.
Please be cautious when using.
Please read the instructions carefully before use.
The product can only be used for starting 12V vehicles. It is prohibited to use it on
equipment such as aircrafts and ships.
Please do not use it if the clamp or the unit has any damage.
Prohibit using it as a car battery.
Prohibit using it as a car battery charger.
Please remove the unit from your car battery in time after cranking your car
successfully.
Please use the equipped jumper cables and other accessories come with it only.
Please make sure that the blue end of the jumper cable is fully inserted into the
jumper cable interface, otherwise, the blue end may melt.
Before use, make sure all battery connectors are clean and the clamps are
connected right. If the battery poles are dirty or corrosive, the start-up performance
of the product will be reduced.
Please do not use more than 3 times in a row. Or it can be overheated and
damaged. It’s better to let it cool down for 2 minutes after using 3 times in a row.
Please remove the product from the car battery within 30s after use, or it may
cause damage.
Do not connect the positive and negative terminals together when the power is on.
Please make sure that at least 3 lights are lit before use.
Please keep this product away from children.
Do not play it as a toy.
Do not wet the product.
Do not immerse the product in water.
Do not operate the product in an explosive atmosphere like the presence of
flammable liquids, gases or dust.
Do not remodel or disassemble the product. Only professional technicians are
allowed to repair.
Do not expose the product to extreme heat or fire.
To avoid the risk of short-circuiting caused by metals falling into the hole, please
remove your jewelries such as rings, bracelets and necklaces before using the
product.
Do not drop the product. If the product is impacted or damaged, it must be tested
by a qualified battery technician.
Do not place the product in an environment where the temperature exceeds 70°C.
Please charge at room temperature not exceeding 60°C.
Please use the charger delivered with the power pack to charge it only.
Do not start cars while charging the unit.
If the host leaks, please immediately recycle it with proper equipment.
Under extreme conditions, battery leakage may occur. If the liquid comes out of
the product, it cannot be handled directly by hand. In the case of skin contact,
wash immediately with soap and water. If the liquid comes in contact with your
eyes, rinse your eyes with cold tap water for at least 10 minutes and seek medical
attention immediately.
Lithium-ion battery-based products should be disposed in accordance with local
regulations at the end of their life.
26.
27.
28.
29.
30.
- 07 -
