POWERSHRED

HS-1010

Please read these instructions before use.

Do not discard: keep for future reference.

IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!

• Keepawayfromchildrenandpets.Keephandsawayfrom

paperentry.Alwayssettoofforunplugwhennotinuse.

• Keepforeignobjects–gloves,jewelry,clothing,hair,

etc.–awayfromshredderopenings.Ifobjectenterstop

opening,switchtoReverse(R)tobackoutobject.

• Neveruseaerosolproducts,petroleumbasedlubricantsor

otherflammableproductsonornearshredder.Donotuse

cannedaironshredder.

• Donotuseifdamagedordefective.Donotdisassemble

shredder.Donotplacenearoroverheatsourceorwater.

• ThisshredderhasaDisconnectPowerSwitch(C)inthedoor.Thedoor

mustbeclosedtooperateshredder.Incaseofemergency,opendoor.

Thisactionwillstopshredderimmediately.

• Avoidtouchingexposedcuttingbladesundershredderhead.

• Shreddermustbepluggedintoaproperlygroundedwalloutletor

socketofthevoltageandamperagedesignatedonthelabel.The

groundedoutletorsocketmustbeinstalledneartheequipmentand

easilyaccessible.Energyconverters,transformers,orextensioncords

shouldnotbeusedwiththisproduct.

• Donotoperatethemachinewithoutthesafetyflapclosed(A).

Willshred:Paperonly

Willnotshred:Adhesivelabels,continuousformpaper,transparencies,

newspaper,junkmail,creditcards,CD/DVDs,staples,paperclips,

cardboard,laminates,filefolders,X-raysorplasticotherthannotedabove

Papershredsize:

HighSecurityMicro-Cut....(Din6)1/32in.x3/16in.(0.8mmx5.0mm)

Maximum:

Sheetsperpass.................................................................................10*

Paperentrywidth...........................................................12in.(305mm)

*8.5in.x11in.,20lb.,(75g)paperat120V,60Hz,15Amps;heavier

paper,humidityorotherthanratedvoltagemayreducecapacity.

Recommendedmaximumdailyusagerates:5,000sheetsperday.10

sheetsperpass.

* In order to perform at capacity, shredder must be plugged into

a dedicated 20Amp, 120V outlet and auto oil system must

be engaged.

H.ControlPanelandLEDs

  1.ON/OFF



 2.Reverse

  3.Binfull

  4.Dooropen

  5.SafetyFlapOpen



 6.Lowoil



 7.Autooilcomplete

A.SafetyFlap

B.Paperentry

C.Disconnectswitch(opendoor)

D.Door

E.Basket-paper(inside)

F. Casters

G.Seesafetyinstructions

ENGLISH

ModelHS-1010

KEY

INDICATOR LIGHTS

CAPABILITIES

ADVANCED PRODUCT FEATURES

Stopsautomatically

whendooris

opened.Symbols

flashalternately

Stopsautomatically

whenbinisfull.

Emptybagwhen

bagfullindicator

lightsup

Stopsautomatically

iftoomuch

paperisinserted.

Automaticreverse

ifpaperjams

Stopsautomatically

ifsafetyflapis

opened.Symbols

flashalternately

Overloadprotection.

Machinestopstocool

down-approx.10-15

minutes.Symbols

flashalternately

Cuttingshaftsare

automaticallyoiled

Oilbottleisempty

Sleep Mode

Energysavingfeatureshutsdown

theshredderafter1hourofinactivity

Auto Oil™

Lubricatesthecuttersautomaticallytoenhance

performanceandextendshredderlife

SHREDDER SET-UP

OILING SET-UP

PAPER

Ensureaccess

toadedicated

20Amp,120V

outlet

BASIC SET-UP BASIC SHREDDING OPERATION

Pluginandmake

suredoorisclosed

Press( )ONto

activate

Whenfinished

shreddingsetto

( )OFF

Feedpaper

straightintopaper

entryandrelease

Donothingand

shredderwillgo

automaticallyto

sleepmodeafter

1hour

Makesuresafety

flapissecurely

inplace

•Emptywastebasketwhenbinfullindicatorlightsup.

•Shredderwon’trunifthedoorisopen,orbinneedstobeemptied.

•Maintenanceisanimportantpartofprotectingyourinvestment.Don’tforgettopurchaseouroil(3505801)andshredderbags(3604101).

Go to Support Section at www.fellowes.com or see back page of manual for useful telephone numbers.

LIMPIEZA DE LOS SENSORES INFRARROJOS DE INICIO AUTOMÁTICO

Eliminates frustrating jams by preventing overloads.

Removelid

fromoilbottle

Putoiltubeintooil

bottleandscrew

stopperon

Placeoilbottle

intooilholderon

sideifcabinet

Closedoor.Plug

intosocket-outlet

Oilpumpstarts

automaticallyon

firstuse.TostopOil

Indicator(

)from

blinkingred,press

ON( )after15

seconds

Afterchangingoil

bottle,pressReverse

(R)untilOilIndicator

(

)nolonger

blinksred

5 6 7 84321

Hookoil

bottleholder

intosideof

cabinet

Removeoilbottle

holderfrom

cabinet

SHEET CAPACITY GAUGE

PAPER JAM

TROUBLESHOOTING AND PREVENTIVE MAINTENANCE

SLEEP MODE

CLEANING AUTO-START INFARED SENSORS

Electronicallymeasurespaperthicknesstoprevent

paperjams:

UptoRED:Toomanysheetshavebeen

inserted.Automaticreverseofpaper.

UptoYELLOW:Maximumsheetcapacity.

UptoGREEN:Normalsheetcapacity

duringshreddingprocess.

Insleepmode

Togetoutofsleep

pressON( )

insertpaper

WHEN IN SLEEP MODE

SettoOff( )andemptybin.Replacebinandfollowthebelow

procedures.

Stopsautomatically

iftoomuchpaper

isinserted.

Automaticreverse

ifpaperjams

Gentlypulluncut

paperfrom

paperentry.

Machinerunsfor

ashorttimein

reverse.Repeatif

necessary

ShredOneSheet

Paperdetectionsensorsaredesignedformaintenancefreeoperation.However,on

rareoccasionsthesensorsmaybecomeblockedbypaperdustcausingthemotorto

runevenifthereisnopaperpresent(Note:twopaperdetectionsensorsarelocatedinthecenter

ofthepaperentry).

Turnoffand

unplugshredder

LocateAuto-start

infaredsensor

Cleanany

contaminationfrom

thepapersensors

Usethin,long-handled

brushtocleansensors.

Makesurebrushis

cleananddry

TO CLEAN THE SENSORS

1 3

4 5

1 3

Quality Office Products Since 1917

POWERSHRED

HS-1010

Australia +1-800-33-11-77

Canada +1-800-665-4339

Europe 00-800-1810-1810

Mexico +1-800-234-1185

United States +1-800-955-0959

Questions or Concerns?

www.fellowes.com

Troubleshooting

Registration

Manuals

Customer Service & Support

Troubleshooting

Replacement parts

General questions

LimitedWarranty: Fellowes,Inc. (“Fellowes”)warrants thepartsofthemachine to

befreeofdefectsinmaterialandworkmanshipandprovidesserviceandsupportfor

1year fromthe dateofpurchasebythe originalconsumer. Felloweswarrants the

cuttingbladesofthemachineto befreefromdefectsinmaterialand workmanship

for1yearfromthedateofpurchasebytheoriginalconsumer.Ifanypartisfoundto

bedefectiveduringthewarrantyperiod,yoursoleandexclusiveremedywillberepair

orreplacement,atFellowes’optionandexpense,ofthedefectivepart.Thiswarranty

does not apply in cases of abuse, mishandling, or unauthorized repair. The user is

responsibleforanyadditionalcostsincurredbyFellowesinservicingthepapershredder

outsideofthecountrywheretheshredderisinitiallysold.ANYIMPLIEDWARRANTY,

INCLUDINGTHATOFMERCHANTABILITYORFITNESSFORAPARTICULARPURPOSE,IS

HEREBYLIMITEDINDURATIONTOTHEAPPROPRIATEWARRANTYPERIOD SETFORTH

ABOVE.InnoeventshallFellowesbeliableforanyconsequentialorincidentaldamages

attributabletothisproduct.Thiswarrantygivesyouspecificlegalrights.Theduration,

terms, and conditions of this warrantyare valid worldwide,except where different

limitations,restrictions,orconditionsmayberequiredbylocallaw.Formoredetailsor

toobtainserviceunderthiswarranty,pleasecontactusoryourdealer.

WARRANTY
