NEC MultiSync® EA Series
High-performance, LED-backlit LCD displays ideal for corporate environments
B D " | " | " UHD D
• 1.0mm or smaller ultra narrow bezels let you focus on your work and are ideal for multiple monitor configurations
• USB Type-C port* gives flexibility to connect to multiple platforms (EA242WU, EA242F, EA272F, EA271Q, EA271U)
• USB Type-C input* charges a mobile device while showing video and using USB (EA242WU, EA242F, EA272F, EA271Q, EA271U)
• Includes NEC’s own ControlSync** technology to allow users to easily control multiple NEC’s displays.
• Four-way ergonomic stand boasts pivot, tilt, swivel and height adjustment maximize your viewing comfort
• Touch-sensitive OSD® controls are integrated into the bezel, making display adjustments easier than ever
• Integrated USB hub easily connects you to your peripherals
• DisplayPort 1.2 out for convenient multi-monitor connectivity (EA242WU, EA242F, EA272F, EA271Q)
• ENERGY STAR® compliance reduces electrical costs and lowers total cost of ownership
With its 4
th
& 5
th
generation MultiSync EA Series, NEC has developed
monitor solutions that push the boundaries of what you’ve come to
know as business-class screen performance. The EA Series deliver a
completely redesigned chassis with a host of enhanced features, advanced
technologies, future-proof connectivity and environmentally friendly
benefits. All models utilize IPS LCD panels, which boast the best possible
color accuracy and minimal viewing angle shift.
Every model features LED backlights, enabling a thin and light design.
Other green features include ECO Mode™, a carbon footprint meter and
an ambient light sensor, which automatically adjusts the brightness to the
optimal setting depending on ambient lighting, screen content or both,
conserving power up to 87% compared to typical energy consumption. In
addition, the human sensor detects user activity in front of the monitor and
reduces display power up to 95% with inactivity.
The ground breaking ControlSync™* technology allows users to control
up to six select MultiSync EA Series units in a multi-monitor configuration.
Upon establishing one unit as the master, you will be able to simultaneously
control many performance attributes of the multi-monitor setup through the
master monitor.
*EA242WU not supported
EA Series Desktops
23" EA231WU
24” EA241F
24” EA242F
24" EA242WU
27" EA271F
27” EA272F
27" EA271Q
27" EA271U
*select models
**EA242WU not supported
Highlights
Reimagine your desktop
computing experience.
Smart Sensing Technologies
Smart sensing technology includes ambient light and human
sensors, which considerably reduce power consumption by
automatically detecting your work conditions and adjusting to
the proper display brightness or entering Power Saving Mode.
MultiSync EA Series Features
IT-Friendly Features
Customize Setting allows both users and IT administrators to set and restore preferred
settings with just one touch, contributing to a free-seating business environment.
The optional NaViSet™ Administrator 2.0 software offers an intuitive graphical interface,
allowing for easy adjustment of display settings via mouse and keyboard. NaViSet
Administrator provides all the advanced control to remotely located IT professionals.
Comprehensive Input Panel
DisplayPort, USB-Type C*, HDMI, DVI-D* and 15-pin VGA*, as well as USB hubs connect you
to the latest peripherals and future-proofs your investment.
*Select models
Power-saving Features
Include ECO Mode™, a carbon footprint meter and an ambient light sensor, which
automatically adjusts the brightness to the optimal setting depending on ambient lighting,
screen content or both, conserving power up to 87% compared to typical energy consumption.
In addition, the human sensor detects user activity in front of the
monitor and reduces display power up to 95% with inactivity.
Multiple Monitor Technologies
The ground breaking ControlSync™* technology allows users to control up to six select
MultiSync EA Series units in a multi-monitor configuration. Upon establishing one unit as the
master, you will be able to simultaneously control many performance attributes of the multi-
monitor setup through the master monitor. ControlSync enables multi-monitor setups of up
to six monitors and controls up to 26 settings.
*Select models
Adjustable for Every Workspace
Four-way ergonomic stand boasts pivot, tilt, swivel and height adjustment up to 130mm to
maximize your viewing comfort. In addition, Space-saving multimedia speakers are hidden
to maintain the monitor’s aesthetic appeal (headphone jack also included).
USB-C Connectivity*
USB Type-C helps optimize connectivity and declutter the workspace by replacing video,
audio, power, and USB cabling with just a single cable to connect and charge a notebook,
tablet PC, or mobile device with the display. (EA242WU, EA242F, EA272F, EA271Q, EA271U)
*Select models
* Ships with EA242WU and EA242F only
** EA242WU - No ControlSync Support, Spectraview limited support - DDC/CI only, Does not ship with USB or ControlSync cables
MODEL EA231WU EA241F EA242F EA242WU**
DISPLAY
Panel Technology IPS IPS IPS IPS
Backlight Type W-LED W-LED W-LED LED
Viewable Image Size 22.5" 23.8" 23.8" 24.1”
Aspect Ratio 16:10 16:9 16:9 16:10
Native Resolution 1920 x 1200 1920 x 1080 1920 x 1080 1920 x 1200
Pixel Pitch 0.254mm 0.275mm 0.275mm 0.27mm
Pixels Per Inch
(at native resolution)
100 93 93 94
Brightness (typical) 250cd/m² 250cd/m² 250cd/m² 300cd/m²
Contrast Ratio (typical) 1000:1 1000:1 1000:1 1000:1
Color Gamut
Adobe RGB
Coverage/Size
72.9% / 75.5% 73.6% / 75.3% 73.6% / 75.3% 77.0% / 79.3%
NTSC Coverage/Size 69.5% / 72.1% 69.5% / 72.0% 69.5% / 72.0% 72%
sRGB Coverage/Size 94.3% / 101.8% 95.1% / 101.6% 95.1% / 101.6% 100%
Viewing Angle (typical)
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
Response Time (typical) 5 5 6 6
Displayable Colors More than 16.7 million More than 16.7 million More than 16.7 million More than 16.7 million
Synchronization Range
Horizontal (Analog/Digital) 31.5-75 KHz 31.5-75 KHz 31.5-83 KHz 31.5-77.0 KHz
Vertical 50-60 Hz 50-75 Hz 50-75 Hz 50-60 Hz
Input Signal
Video Analog RGB 0.7 Vp-p/75 Ohms Analog RGB 0.7 Vp-p/75 Ohms
Digital HDMI/DisplayPort, USB Type-C
~31.5 - ~83.0kHz Horizontal Frequency,
~50Hz - ~75Hz Vertical Frequency, ~25MHz
- ~165MHz Dot Clock Fequency
Displayport/USB-C - Digital RGB
HDMI - Digital RGB/YUC
Sync
Separate Sync: TTL Level (Positive/Negative) - Composite Sync: TTL Level (Positive/Negative) - Composite Sync on Green: (0.3Vp-p
negative 0.7Vp-p positive)
Input Connectors DisplayPort, HDMI, DVI-D, VGA 15-pin D-sub DisplayPort, HDMI, DVI-D, VGA 15-pin D-sub
DisplayPort, HDMI, VGA 15-pin D-sub, USB
Type-C
DisplayPort, HDMI, USB Type-C
Output Connectors DisplayPort DisplayPort 1.2 (SST / MST)
USB
Hub USB 3.1, 1 up / 3 down USB 3.1, 1 up / 3 down USB 3.1, 1 up / 3 down USB 3.1, 1 up / 2 down
Power Delivery USB-C 65W USB-C 65W
POWER
CONSUMPTION
On (typical) 15W 15W 19W 19W
Power Savings Mode (typical) 0.29W 0.29W 0.3W 0.3W
PHYSICAL
SPECIFICATIONS
Dimensions
(WxHxD)
With stand
19.6 x 13.3-19.2 x 9.8 in. /
498.9 x 337.2-487.2 x 250 mm
21.2 x 13.3-19.2 x 9.8 in. /
537.7 x 336.6-486.6 x 250mm
21.2 x 13.2-19.1 x 9.8 in. /
537.7 x 336.2-486.2 x 250mm
20.9 x 14.4-20.3 x 9.8 in. /
531.5 x 365.3-515.3 x 250.0mm
Without stand
19.6 x 12.6 x 1.8 in. / 498.9 x 319.7 x
45.6 mm
21.2 x 12.6 x 1.8 in. / 537.7 x 319.1 x
45.6mm
21.2 x 12.6 x 1.8 in. / 537.7 x 319.1 x
46.6mm
20.9 x 13.7 x 1.9 in. /
531.5 x 347.8 x 47.6mm
Net Weight
With stand 13.0 lbs. / 5.9 kg 13.4 lbs. / 6.1 kg 15.4 lbs. / 7.0 kg 14.8 lbs. / 6.7 kg
Without stand 7.5 lbs. / 3.4 kg 7.9 lbs. / 3.6 kg 9.9 lbs. / 4.5 kg 9.3 lbs. / 4.2 kg
VESA Hole Configuration 100 x 100mm 100 x 100mm 100 x 100mm 100 x 100mm
ENVIRONMENTAL
CONDITIONS
Operating Temperature 41-95°F / 5-35°C 41-95°F / 5-35°C 41-95°F / 5-35°C 41-95°F / 5-35°C
Operating Humidity 20-80% 20-80% 20-80% 20-80%
Operating Altitude 16404 ft. / 5000m 16404 ft. / 5000m 16404 ft. / 5000m 16404 ft. / 5000m
Storage Temperature 14-140°F / -10-60°C 14-140°F / -10-60°C 14-140°F / -10-60°C 14-140°F / -10-60°C
Storage Humidity 10-85% 10-85% 10-85% 10-85%
Storage Altitude 40,000 ft. / 12,192m 40,000 ft. / 12,192m 40,000 ft. / 12,192m 40,000 ft. / 12,192m
ENVIRONMENTAL
COMPLIANCE
ENERGY STAR 7.0 7.0 8.0 8.0
RoHS Yes Yes Yes Ye s
ADDITIONAL FEATURES
Tilt, Swivel, Pivot, Height-adjustable stand, ControlSync, Customize Setting, Integrated speakers, 3-port USB 3.1 hub, LED backlit, Auto brightness with ambient light sensor, Human
sensor, SpectraView Compatible, ECO Mode, Carbon footprint meter, Resettable cost meter, Ultra-narrow bezel, Carrying handle, Rapid Response, Ambix, XtraView, Hot Key, Touch OSD
controls, OSD Lock Out, Cable management, Dynamic Visual Mode (Standard, Text, Movie, Gaming, Photo, Dynamic), NaViSet software, VESA mount, HDCP, DDC/CI, No Touch Auto
Adjust, Plug and Play (VESA DDC2B), VESA DPMS power management, AccuColor color control, Digital smoothing, Digital controls, ISO 9241-307 Class I, DICOM SIM
SHIPS WITH Setup sheet, User manual, Power cord, DisplayPort cable, USB cable, ControlSync cable, USB-C cable*
Setup sheet, User manual, Power cord,
DisplayPort cable, USB-C cable
LIMITED WARRANTY 3 years
* Ships with EA272F, EA271Q and EA271U only
4-way adjustable stand
Ambient and human
sensors
Comprehensive input panel
(select models)
EA242WU
Touch-sensitive OSD controls
Thin, lightweight design with
integrated speakers
USB 3.0 hub
(select models)
MODEL EA271F EA272F EA271Q EA271U
DISPLAY
Panel Technology IPS IPS PLS IPS
Backlight Type W-LED W-LED W-LED W-LED
Viewable Image Size 27" 27" 27" 27"
Aspect Ratio 16:9 16:9 16:9 16:9
Native Resolution 1920 x 1080 1920 x 1080 2560 x 1440 3840 x 2160
Pixel Pitch 0.31mm 0.31mm 0.23mm 0.16mm
"Pixels Per Inch
(at native resolution)"
82 82 109 163
Brightness (typical) 250cd/m² 250cd/m² 350cd/m² 350cd/m²
Contrast Ratio (typical) 1000:1 1000:1 1000:1 1000:1
Color
Gamut
Adobe RGB
Coverage/Size
73.6% / 75.3% 78.3% / 83.2% 78.1% / 81.6%
NTSC Coverage/Size 69.5% / 72.1% 69.5% / 72.0% 74.6% / 79.5% 75.1% / 78.0%
sRGB Coverage/Size 95.0% / 101.8% 95.1% / 101.6% 100.0% / 112.2% 100.0% / 110.1%
Viewing Angle (typical)
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
178° Vert., 178° Hor.
(89U/89D/89L/89R) @ CR>10
178° Vert., 178° Hor.
89U/89D/89L/89R) @ CR>10
Response Time (typical) 6 6 6 5
Displayable Colors More than 16.7 million More than 16.7 million More than 16.7 million 1.07 billion
Synchronization Range
Horizontal (Analog/Digital) 31.5-83 KHz 31.5-83 KHz 31.5-83 KHz 31.5-83 KHz
Vertical 56-75 Hz 56-75 Hz 56.0 Hz - 75.0 Hz 30.0 Hz - 75.0 Hz
Input Signal
Video
Digital HDMI/DisplayPort, USB C ~31.5 -
~83.0kHz Horizontal Frequency, ~50Hz
- ~75Hz Vertical Frequency, ~25MHz -
~165MHz Dot Clock Fequency
Digital HDMI/DisplayPort, USB Type-C
~31.5 - ~83.0kHz Horizontal Frequency,
~50Hz - ~75Hz Vertical Frequency, ~25MHz
- ~165MHz Dot Clock Fequency
Digital HDMI/DisplayPort, USB Type-C
~31.5 - ~83.0kHz Horizontal Frequency,
~50Hz - ~75Hz Vertical Frequency, ~25MHz
- ~165MHz Dot Clock Fequency
Digital HDMI/DisplayPort, USB Type-C
~31.5 - ~83.0kHz Horizontal Frequency,
~50Hz - ~75Hz Vertical Frequency, ~25MHz
- ~165MHz Dot Clock Fequency
Sync
Separate Sync: TTL Level (Positive/Negative) - Composite Sync: TTL Level
(Positive/Negative) - Composite Sync on Green: (0.3Vp-p negative 0.7Vp-p positive)
Input Connectors DisplayPort, HDMI, VGA 15-pin D-sub
DisplayPort, HDMI, VGA 15-pin D-sub, USB
Type-C
DisplayPort, HDMI, VGA 15-pin D-sub, USB
Type-C
DisplayPort, HDMI, VGA 15-pin D-sub, USB
Type-C
Output Connectors DisplayPort DisplayPort 1.2 (SST / MST)
USB
Hub USB 3.1, 1 up / 3 down USB 3.1, 1 up / 3 down USB 3.1 and USB-C, 1 up / 3 down USB 3.1 and USB-C, 1 up / 3 down
Power Delivery USB-C 65W USB-C 60W USB-C 60W
POWER
CONSUMPTION
On (typical) 17W 19W 31W 38W
Power Savings Mode (typical) 0.27W 0.3W 0.29W 0.29W
PHYSICAL
SPECIFICATIONS
Dimensions
(WxHxD)
With stand
24.0 x 14.9 - 20.8 x 9.8 in. /
610.2 x 377.3 - 527.3 x 250 mm
24.0 x 14.9 - 20.8 x 9.8 in. /
610.2 x 376.9 - 526.9 x 250 mm
24.1 x 14.9 - 20.8 x 9.8 in. /
611.8 x 378.0 - 528.0 x 250.0 mm
24.1 x 14.9 - 20.8 x 9.8 in. /
611.8 x 378.0 - 528.0 x 250.0 mm
Without stand
24.0 x 14.2 x 1.8 in. / 610.2 x 359.8 x
45.6 mm
24.0 x 14.2 x 1.8 in. / 610.2 x 359.8 x
46.6 mm
24.1 x 14.2 x 2.6 in. / 611.8 x 361.9 x
67.2 mm
24.1 x 14.2 x 2.6 in. / 611.8 x 361.9 x
67.2 mm
Net Weight
With stand 16.8 lbs. / 7.6 kg 20.3 lbs. / 9.2 kg 20.9 lbs. / 9.5 kg 20.9 lbs. / 9.5 kg
Without stand 11.0 lbs. / 5.0 kg 12.8 lbs. / 5.8 kg 13.5 lbs. / 6.1 kg 13.4 lbs. / 6.1 kg
VESA Hole Configuration 100 x 100mm 100 x 100mm 100 x 100 mm 100 x 100 mm
ENVIRONMENTAL
CONDITIONS
Operating Temperature 41-95°F / 5-35°C 41-95°F / 5-35°C 41-95°F / 5-35°C 41-95°F / 5-35°C
Operating Humidity 20-80% 20-80% 20-80% 20-80%
Operating Altitude 6563 ft. / 2000m 16404 ft. / 5000m 16,404 ft. / 5000m 16,404 ft. / 5000m
Storage Temperature 14-140°F / -10-60°C 14-140°F / -10-60°C 14-140°F / -10-60°C 14-140°F / -10-60°C
Storage Humidity 10-85% 10-85% 10-85% 10-85%
Storage Altitude 40,000 ft. / 12,192m 40,000 ft. / 12,192m 40,000 ft. / 12,192m 40,000 ft. / 12,192m
ENVIRONMENTAL
COMPLIANCE
ENERGY STAR 7.0 8.0 7.0 8.0
TCO 7.0 8.0 7.0 7.0
RoHS Yes Yes Yes Ye s
ADDITIONAL FEATURES
SpectraView
II
Compatible, ControlSync, Customize Setting, Integrated speakers, 3-port USB hub, LED backlit, Auto brightness with ambient light sensor, Human sensor, ECO Mode,
Carbon footprint meter, Resettable cost meter, Ultra-narrow bezel, Tilt, Swivel, Dual Direction Pivot, Height-adjustable stand, Rapid Response, Ambix, XtraView, Hot Key, OSD Lock
Out, Cable management, Dynamic Visual Mode, NaViSet software, VESA mount, HDCP, DDC/CI, No Touch Auto Adjust, Plug and Play (VESA DDC2B), VESA DPMS power manage-
ment, AccuColor color control, Digital controls, ISO 9241-307 Class I
SHIPS WITH Setup sheet, User manual, Power cord, DisplayPort cable, USB cable, ControlSync cable, USB-C cable*
LIMITED WARRANTY 3 years
All other brand or product names are trademarks or registered trademarks of their respective holders.
Product specifications subject to change.
©2022 Sharp NEC Display Solutions of America, Inc. | All rights reserved.
Rev. 09.07.2022
Sharp NEC Display Solutions of America
www.sharpnecdisplays.us
