User Manual Tripp Lite OMNIVSX650 36 pages

UPS Systems

Models:

OMNIVSX450D, OMNIVSX450, OMNIVSX650D, OMNIVSX650

(Series Numbers: AG-87DD, AG-02FA, AG-87DF, AG-02FB)

Important Safety Instructions ................. 2

Quick Installation ...................................3

Basic Operation .....................................4

UPS On/Off ..........................................4

LED Indicators .....................................4

Features ................................................5

UPS Features ......................................5

Battery Replacement ............................6

Storage and Service ..............................6

Regulatory Compliance ..........................7

Español..................................................8

Français ............................................... 15

Русский ..............................................22

Deutsch ...............................................29

Owner’s Manual

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

Loading ...

Specifications

Brand: Tripp Lite

Model: OMNIVSX650

Category: Tools - Home Improvement

Nominal Input Voltage(s) Supported: 230V AC

Nominal Voltage Details: 230V nominal output in battery mode

Frequency Compatibility: 50 / 60 Hz

Frequency Compatibility Details: Automatic frequency selection

Output Voltage Regulation (Line Mode): 230V (±9.5%)

Output Voltage Regulation (Battery Mode): ±10%

Included Output Power Cables: Includes 2 C13 to C14 power cables

Output AC Waveform (Battery Mode): PWM sine wave

Nominal Output Voltage(s) Supported: 220V; 230V; 240V

Battery Type: Valve Regulated Lead Acid (VRLA)

DC System Voltage (VDC): 12

Battery Recharge Rate (Included Batteries): 8 hours from 10% to 90%

Battery Replacement Description: See manual for battery replacement information

UPS Power Module Dimensions (hwd, in.): 5.6 x 4 x 11.8

UPS Power Module Weight (kg): 4.81

UPS Power Module Weight (lbs.): 10.6

Low Voltage Transfer to Battery Power (Setpoint): 170

High Voltage Transfer to Battery Power (Setpoint): 280

UPS Input Connection Type: C14 inlet

Product Compliance: RoHS; CE (Europe); UKCA

Output Capacity (VA): 650

Output Capacity (kVA): 0.65

Output Capacity (Watts): 360

Output Capacity (kW): 0.36

Primary UPS Depth (mm): 300

Primary UPS Height (mm): 142

Primary UPS Width (mm): 102

Shipping Dimensions (hwd / in.): 8.70 x 5.60 x 13.60

Unit Weight (lbs.): 10.600

Runtime Full Load (min.): 1 min. (360W)

Runtime Half Load (min.): 6 min. (180W)

UPS AC Suppression Response Time: Instantaneous

EMI / RFI AC Noise Suppression: Yes

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Storage Temperature Range: 5° to 122°F (-15° to 45°C)

Relative Humidity: Up to 90%, non-condensing

AC Mode Efficiency Rating (100% Load): 95%

Operating Elevation (m): 0-2000m

Transfer Time: 6 milliseconds

UPS Housing Material: PVC

Tripp Lite OMNIVSX650 Line Interactive UPS, C13 Outlets (4) - 230V, 650VA, 360W, Ultra-Compact Design

Owner's Manual
