48" Induction Range
AMC48IN
aga-ranges.com • 800-223-3900
Oven Features
Cooktop Features
A
D
C
B
E
AMC48IN-BLK
Gloss Black
AMC48IN-MBL
Matte Black
AMC48IN-WHT
White
AMC48IN-IVY
Ivory
AMC48IN-SS
Stainless Steel
AMC48IN-SKY
Midnight Sky
• Over 6 cubic feet of oven space amongst 3 separate ovens
maximize space and reduce energy consumption
• One extra-large 7-Mode Multi-Function™ Oven (left oven) tailored
to your cooking needs with Defrost, Convection, Convection
Broiling, Fan Assist Bake, Conventional, Browning and Base Heat
• A second extra-large true European convection oven (right oven)
• Each large oven has 5 rack positions; the range comes with 4
heavy duty steel racks and one telescoping steel rack for a total of
5 oven racks
• Powerful dual-element Broiler with an 8-pass, 2,300 watt broiler –
ready to cook in just 5 minutes
• Glide Out Broiler System™ with Full Broil and Half Broil mode
to provide complete coverage with adjustable heights and
extendable gliding tray spacious enough to cook six 6-oz steaks
at once
• 9 eye-catching Hi-Fi Style Controls deliver precise power to each
burner and oven with stereo-like grace
• Spacious storage drawer with rubber mat to protect and store
your cookware
• EasyClean™ Technology with black enamel interior
• Extra-large ceramic glass induction cooktop with 5 induction
burners
• Induction cooktop makes use of 90% of the available heat
compared to just 55% with that of a gas burner
• Built-in pan recognition sensors automatically turn the burner o
when not in use saving energy and increasing safety while the
child lock feature protects little hands
• Ecient induction cooking surface with the following features:
• Each zone oers a boost in power
• Residual heat indicator
• 9 power settings giving instant response
• Automatic heat up per zone
• Low temperature and simmering setting
• Overheat detection
• Child safety lock
• Generous cooking space with three 7" dia.,
one 6" dia. and one 10" dia. defined pan areas
A: 1,850 watts with 3,000 watt Boost: 7" dia.
B: 1,400 watts with 2,200 watt Boost: 6" dia.
C: 2,300 watts with 3,700 watt Boost: 10" dia.
D: 1,850 watts with 3,000 watt Boost: 7" dia.
E: 1,850 watts with 3,000 watt Boost: 7" dia.
2
48" Induction Range
AMC48IN
aga-ranges.com • 800-223-3900
ArtNo.110-0040 - 110 Mercury min spacings
0 0 0 0 0
0
140
100
180
220
0
100
140
180
220
0
1
33
22
1
0
1
3
/
16
”
30 mm
min
1
3
/
16
”
30 mm
min
31 ½”
800 mm
min
1219 mm
48
36
1
⁄
8
”
(918 mm) min
37
13
⁄
64
”
(945 mm) max
0
100
140
180
220
0
100
140
180
220
0
1
33
22
1
0
(*check rangehood instructions for actual dimensions)
16
5
/
32
” (410 mm)
minimum
48” (1219 mm) minimum
ArtNo.110-0040 - 110 Mercury min spacings
0 0 0 0 0
0
140
100
180
220
0
100
140
180
220
0
1
33
22
1
0
1
3
/
16
”
30 mm
min
1
3
/
16
”
30 mm
min
31 ½”
800 mm
min
1219 mm
48
36
1
⁄
8
”
(918 mm) min
37
13
⁄
64
”
(945 mm) max
0
100
140
180
220
0
100
140
180
220
0
1
33
22
1
0
(*check rangehood instructions for actual dimensions)
16
5
/
32
” (410 mm)
minimum
48” (1219 mm) minimum
General Properties
Oven Capacity 6 cu. ft.
Cooking Mode
Main Cavity – Right side
Convection Bake
2.8 cu. ft.
(17” W x 14” D x 14 ½” H*)
Cooking Mode
Second Cavity – Left side
Multi-function Oven with
7 Cooking Modes
2.8 cu. ft.
(17" W x 14" D x 14 ½" H*)
Cooking Mode
Third Cavity – Broiler
Dual-element with 8-pass 2,300W
0 .5 cu. ft.
Cleaning Type EasyClean™ Enamel
Controls Knobs on fascia
Oven Performance
Main Cavity – Right side 2,500W
Second Cavity – Left side 2,500W
Third Cavity - Broiler 2,300W
Broiler Type 8 Pass Radiant Heat
Cooktop Performance
Cooktop Dimensions 43" W x 21
1
/
2
" D
Number of Zones 5
Power of Front Left Zone: 6” dia. 1,400 watts with 2,200 watt Boost
Power of Back Left Zone: 7” dia. 1,850 watts with 3,000 watt Boost
Power of Center Zone: 10” dia. 2,300 watts with 3,700 watt Boost
Power of Front Right Zone: 7” dia. 1,850 watts with 3,000 watt Boost
Power of Back Right Zone: 7” dia. 1,850 watts with 3,000 watt Boost
Electrical Details
Circuit Breaker (A) 50A
Volts (V) 240V
Frequency (Hz) 60Hz
Plug Type 4 Wire
Power Cord Length 48"
Dimensions & Weights
Appliance Dimensions 47
9
/
16
" W x 28
7
/
16
" D x 36
1
/
8
" H
Depth with Door Open 46
1
/
8
"
Weight 357 lbs.
Shipping Weight 390 lbs.
Package Dimensions 49
1
/
4
" W x 31" D x 46
1
/
2
" H
Accessories Included
1 Enameled broiler pan
1 Broiler pan insert
1 Storage drawer mat
Warranty
1 Year Warranty, Entire Appliance, Parts and Labor
26
1
/
8
(663 mm)
27
3
/
8
(695 mm)
28
7
/
16
(723 mm)
46
5
/
16
(1177 mm)
*Usable Space
