thank you for choosing JBL. For over 50 years, JBL has
been involved in every aspect of musical and film recording and
reproduction, from live performances to monitoring the recordings
you play in your home, car or office.
We’re confident that the JBL loudspeakers you have
chosen will provide every note of enjoyment that you expected and
that when you think about purchasing additional audio equipment
for your home, car or office, you will once again choose JBL.
Please take a moment to complete the enclosed profile card. It
enables us to keep you posted on our latest advancements, and
helps us to better understand our customers and to build products
that meet their needs and expectations.
JBL Consumer Products
Media System2000 – 230V OM 7/20/98 11:44 AM Page 2
Declaration of Conformity
We, JBL Europe A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the products described
in this owner’s manual are in compliance with technical
standards:
EN 55 013/6.1990
EN 55 020/6.1988
EN 55 022/6.1993
EN 60 065/1994
EN 60 555-2-3/1987/88
Steen Michaelsen
JBL Europe A/S
Birkerød. DENMARK. 10/97
Media System2000 – 230V OM 7/20/98 11:44 AM Page 3
1. Placement
VOLUME TREBLE BASS
VOLUME TREBLE BASS
V
O
LU
M
E T
R
E
B
LE
B
A
S
S
For optimum performance
and stereo imaging, slightly
angle the speakers toward
the listening position.
The subwoofer can be
placed on the desktop or
on the floor.
Media System2000 – 230V OM 7/20/98 11:44 AM Page 4
2. Connections2. Connections
Computer Sound Card
or Portable CD Player
Secondary Speaker
Line Out
Speaker
Subwoofer
In
In
Main Speaker
Audio
Remote
Volume
Remote
Volume
Speaker
InR L Out
Out
AC Cord
Media System2000 – 230V OM 7/20/98 11:44 AM Page 5
Auto turn-on/turn-off
The Media System2000
features an automatic
turn-on/turn-off feature.
They will turn off when the
source equipment (comput-
er or CD player) has no
sound output for approxi-
mately fifteen minutes and
immediately turn back on
when
a signal is present.
3. Operation
Volume:
To raise the volume level,
rotate the
volume
knob
clockwise.
To lower the volume level,
rotate the
volume
knob
counterclockwise.
Treble:
To raise the treble level,
rotate the
treble
knob
clockwise.
To lower the treble level,
rotate the
treble
knob
counterclockwise.
Bass:
To raise the bass level,
rotate the
bass
knob
clockwise.
To lower the bass level,
rotate the
bass
knob
counterclockwise.
Volume Treble Bass
Volume Treble Bass
Volume Treble Bass
Volume Treble Bass
Volume Treble Bass
Volume Treble Bass
Multiposition directional
adjustment
The satellites incorporate a
multiposition directional
adjustment that allows you
to tilt the speakers toward
the listening area. This
allows you to position the
speakers for ideal sound
reproduction and imaging.
Media System2000 – 230V OM 7/20/98 11:44 AM Page 6
4. Specifications
Maximum Amplifier Output:
15 watts/channel @ 1% THD
Frequency Response:
70Hz – 20kHz
Input Sensitivity: 3V maximum
Input Impedance: 10k ohms
Signal Input Jack:
Stereo mini-connector (1/8")
Subwoofer Output Jack:
Stereo mini-connector (1/8")
Dimensions (H x W x D):
7-5/8 x 3 x 7-7/8"
194 x 76 x 200mm
Weight:
2 lbs/0.9 kg – main
1.5 lbs./0.7 kg – secondary
Maximum Amplifier Output:
35 watts @ 1% THD
Frequency Response:
50Hz – 120Hz
Input Sensitivity: 3V maximum
Input Impedance: 10k ohms
Signal Input Jack:
Stereo mini-connector (1/8")
Subwoofer Output Jack:
Stereo mini-connector (1/8")
Dimensions (H x W x D):
9-5/8 x 5-1/4 x 10-3/4"
244 x 133 x 273mm
Weight:
2.6 lbs/1.2 kg
Satellites
Subwoofer
Media System2000 – 230V OM 7/20/98 11:44 AM Page 7
JBL Consumer Products
80 Crossways Park West, Woodbury, NY 11797
8500 Balboa Boulevard, Northridge, CA 91329
©
1997 JBL, Incorporated. JBL is a registered trademark of JBL, Incorporated.
Printed 10/97 Part No. MEDSYS2000OM230V
