Operating Instructions
2-in-1 Corded | Cordless Phone
Model No. KX-TGB850
KX-TGB852
KX-TG2153SK
Model shown is KX-TGB850.
Before initial use, see “Getting Started” on
page 8.
®
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them for future reference.
Consulte “Guía Rápida Española”, página 37.
For assistance, visit our Web site: http://shop.panasonic.com/support for customers in the U.S.A.
Please register your product: http://shop.panasonic.com/support
2
For assistance, please visit http://shop.panasonic.com/support
Answering System
Answering system ....................................29
Turning the answering system on/off ........29
Greeting message ....................................29
Listening to messages ..............................30
Useful Information
Voicemail service ......................................33
Wall mounting ...........................................33
Troubleshooting ........................................34
FCC and other information .......................35
Guía Rápida Española
Guía Rápida Española .............................37
Appendix
Customer services ....................................43
Limited Warranty (ONLY FOR U.S.A.) ......44
Index
Index .........................................................46
Introduction
Model composition....................................3
Accessory information
..............................3
Graphical symbols for use on equipment
and their descriptions
...............................4
Important Information
For your safety..........................................5
Important safety instructions.....................6
For best performance
...............................6
Other information
......................................7
Specications
...........................................7
Getting Started
Setting up .................................................8
Note when setting up
................................9
Controls
....................................................10
Navigating the menus
...............................12
Date and time
...........................................12
Other settings
...........................................12
Menu Map.................................................13
Making and Answering Calls
Making calls ..............................................14
Answering calls.........................................15
Useful features during a call
.....................15
Intercom, transferring calls and
conference calls........................................16
Handset locator
........................................17
Phonebook
Phonebook ...............................................18
Speed dial.................................................19
Caller ID Service
Using Caller ID service .............................21
Caller list
...................................................21
Programming
Personal settings ......................................23
Advanced settings
....................................25
Table of contents
3
For assistance, please visit http://shop.panasonic.com/support
Introduction
Model composition
Series Model No.
Base unit Handset
Part No. Part No. Quantity
KX-TGB850 series KX-TGB850 KX-TGB850 KX-TGBA85 1
KX-TGB852 KX-TGB850 KX-TGBA85 2
KX-TG2153SK KX-TGB850 KX-TGBA85 3
Accessory information
Supplied accessories
No. Accessory item/Part number
Quantity
KX-TGB850 KX-TGB852 KX-TG2153SK
1
AC adaptor/PNWYAB810S00 2 3 4
2
Telephone line cord/PNJA1186Z 1 1 1
3
Desk stand
*1
/PNWYAB850B01 1 1 1
4
Corded handset/PNWYAB850B00 1 1 1
5
Corded handset cord/ PQJA212V 1 1 1
6
Rechargeable batteries
*2
2 4 6
7
Handset cover
*3
/PNWYAB810S01 1 2 3
8
Charger/PNWYAB810S02 1 2 3
*1
The desk stand comes attached to the base unit.
*2
See below for replacement battery information.
*3
The handset cover comes attached to the handset.
1
2
3
4
5 6 7 8
Additional/replacement accessories
Please contact your nearest Panasonic dealer for sales information (page 43).
Accessory item Model number/Specification
Rechargeable
batteries
HHR-4DPA*
1
● To order, please visit http://shop.panasonic.com/support
Battery type:
– Nickel metal hydride (Ni-MH)
– 2 x AAA (R03) size for each handset
*1
Replacement batteries may have a different capacity from that of the supplied batteries.
4
For assistance, please visit http://shop.panasonic.com/support
Introduction
Other information
● Design and specications are subject to change without notice.
● The illustrations in these instructions may vary slightly from the actual product.
Expanding your phone system
You can expand your phone system by
registering optional handsets (4 max.)
to a single base unit.
● Optional handsets may be a different
color from that of the supplied handsets.
● To order, please visit
http://shop.panasonic.com/support
Graphical symbols for use on equipment and their
descriptions
Symbol Explanation Symbol Explanation
Alternating current (A.C.)
Class II equipment (equipment in
which protection against electric
shock relies on Double Insulation or
Reinforced Insulation)
Direct current (D.C.) “ON” (power)
Protective earth “OFF” (power)
Protective bonding earth Stand-by (power)
Caution: risk caused by
visible radiation
“ON”/“OFF” (power; push-push)
For indoor use only Caution, risk of electric shock
Handset (optional): KX-TGBA85
5
For assistance, please visit http://shop.panasonic.com/support
Important Information
Operating safeguards
● Unplug the product from power outlets before
cleaning. Do not use liquid or aerosol cleaners.
● Do not disassemble the product.
● Do not spill liquids (detergents, cleansers,
etc.) onto the telephone line cord plug, or
allow it to become wet at all. This may cause
a re. If the telephone line cord plug becomes
wet, immediately pull it from the telephone
wall jack, and do not use.
● Do not place the corded or cordless handset in
the base unit when battery cover is removed.
Medical
● Consult the manufacturer of any personal
medical devices, such as pacemakers or
hearing aids, to determine if they are adequately
shielded from external RF (radio frequency)
energy. (The product operates in the frequency
range of 1.92 GHz to 1.93 GHz, and the RF
transmission power is 115 mW (max.).)
● Do not use the product in health care facilities
if any regulations posted in the area instruct
you not to do so. Hospitals or health care
facilities may be using equipment that could
be sensitive to external RF energy.
CAUTION
Installation and location
● Never install telephone wiring during an
electrical storm.
● Never install telephone line jacks in wet
locations unless the jack is specically
designed for wet locations.
● Never touch uninsulated telephone wires or
terminals unless the telephone line has been
disconnected at the network interface.
● Use caution when installing or modifying
telephone lines.
● The AC adaptor is used as the main
disconnect device. Ensure that the AC outlet
is installed near the product and is easily
accessible.
● The product is only use for mounting at
heights ≤ 2 m.
For your safety
To prevent severe injury and loss of life/property,
read this section carefully before using the
product to ensure proper and safe operation of
your product.
WARNING
Power connection
● Use only the power source marked on
the product.
● Do not overload power outlets and extension
cords. This can result in the risk of re or
electric shock.
● Completely insert the AC adaptor/power plug
into the power outlet. Failure to do so may
cause electric shock and/or excessive heat
resulting in a re.
● Regularly remove any dust, etc. from the
AC adaptor/power plug by pulling it from the
power outlet, then wiping with a dry cloth.
Accumulated dust may cause an insulation
defect from moisture, etc. resulting in a re.
● Unplug the product from power outlets if it
emits smoke, an abnormal smell, or makes an
unusual noise. These conditions can cause
re or electric shock. Conrm that smoke has
stopped emitting and contact us at
http://shop.panasonic.com/support
● Unplug from power outlets and never touch
the inside of the product if its casing has been
broken open.
● Never touch the plug with wet hands. Danger
of electric shock exists.
Installation
● To prevent the risk of re or electrical shock,
do not expose the product to rain or any type
of moisture.
● Do not place or use this product near
automatically controlled devices such as
automatic doors and re alarms. Radio
waves emitted from this product may cause
such devices to malfunction resulting in an
accident.
● Do not allow the AC adaptor or telephone line
cord to be excessively pulled, bent or placed
under heavy objects.
6
For assistance, please visit http://shop.panasonic.com/support
Important Information
Attention:
A nickel metal hydride battery that is recyclable
powers the product you have purchased. Please
call 1-800-8-BATTERY (1-800-822-8837) for
information on how to recycle this battery.
Important safety
instructions
When using your product, basic safety
precautions should always be followed to reduce
the risk of re, electric shock, and injury to
persons, including the following:
1. Do not use this product near water for
example, near a bathtub, washbowl, kitchen
sink, or laundry tub, in a wet basement or
near a swimming pool.
2. Avoid using a telephone (other than a
cordless type) during an electrical storm.
There may be a remote risk of electric shock
from lightning.
3. Do not use the telephone to report a gas leak
in the vicinity of the leak.
4. Use only the power cord and batteries
indicated in this manual. Do not dispose of
batteries in a re. They may explode. Check
with local codes for possible special disposal
instructions.
SAVE THESE INSTRUCTIONS
For best performance
Base unit location/avoiding noise
The base unit and other compatible Panasonic
units use radio waves to communicate with each
other.
● For maximum coverage and noise-free
communications, place your base unit:
– at a convenient, high, and central location
with no obstructions between the handset and
base unit in an indoor environment.
– away from electronic appliances such as
TVs, radios, personal computers, wireless
devices, or other phones.
Note:
● This height is not guaranteed for product
reliability.
● To prevent serious injuries due to the
product unexpectedly falling, the product
must be installed at a height of 1.5 m or lower.
● This product is unable to make calls when:
– the handset batteries need recharging
or have failed.
– there is a power failure.
Battery
● We recommend using the batteries noted on
page 3. USE ONLY rechargeable Ni-MH
batteries AAA (R03) size.
● Do not mix old and new batteries.
● Do not open or damage the batteries.
Released electrolyte from the batteries is
corrosive and may cause burns or injury to the
eyes or skin. The electrolyte is toxic and may
be harmful if swallowed.
● Exercise care when handling the batteries.
Do not allow conductive materials such as
rings, bracelets, or keys to touch the batteries,
otherwise a short circuit may cause the
batteries and/or the conductive material to
overheat and cause burns.
● Charge the batteries provided with or
identied for use with this product only,
in accordance with the instructions and
limitations specied in this manual.
● Only use a compatible charger to charge the
batteries. Do not tamper with the charger.
Failure to follow these instructions may cause
the batteries to swell or explode.
● Avoid the use in the following conditions
– High or low extreme temperatures during
use, storage or transportation.
– Replacement of a battery with an incorrect
type that can defeat a safeguard.
– Disposal of a battery into re or a hot oven,
or mechanically crushing or cutting of a battery,
that can result in an explosion.
– Extremely high temperature and/or extremely
low air pressure that can result in an explosion
or the leakage of ammable liquid or gas.
7
For assistance, please visit http://shop.panasonic.com/support
Important Information
Notice for product disposal,
transfer, or return
● This product can store your private/
condential information. To protect your
privacy/condentiality, we recommend that
you erase information such as phonebook or
caller list entries from the memory before you
dispose of, transfer, or return the product.
Notice
Specification
● Frequency range:
1.92 GHz to 1.93 GHz
● RF transmission power:
115 mW (max.)
● Power source:
100–240 V AC, 50/60 Hz
● Power consumption
Base unit:
Standby: 0.81 W
Maximum: 1.97 W
Charger:
Standby: 0.03 W
Maximum: 0.9 W
● Operating conditions:
0°C – 40°C (32°F – 104°F), 20% – 80%
relative air humidity (dry)
– facing away from radio frequency
transmitters, such as external antennas of
mobile phone cell stations. (Avoid putting the
base unit on a bay window or near a window.)
● Coverage and voice quality depends on the
local environmental conditions.
● If the reception for a base unit location is not
satisfactory, move the base unit to another
location for better reception.
Environment
● Keep the product away from electrical noise
generating devices, such as uorescent lamps
and motors.
● The product should be kept free from excessive
smoke, dust, high temperature, and vibration.
● The product should not be exposed to direct
sunlight.
● Do not place heavy objects on top of the product.
● When you leave the product unused for a long
period of time, unplug the product from the
power outlet.
● The product should be kept away from heat
sources such as heating devices, cooking
appliances, etc. It should not be placed in
rooms where the temperature is less than 0°C
(32°F) or greater than 40°C (104 °F). Damp
basements should also be avoided.
● The maximum calling distance may be
shortened when the product is used in the
following places: Near obstacles such as hills,
tunnels, underground, near metal objects
such as wire fences, etc.
● Operating the product near electrical
appliances may cause interference. Move
away from the electrical appliances.
Routine care
● Wipe the outer surface of the product with
a soft moist cloth.
● Do not use benzine, thinner, or any abrasive
powder.
Other information
● The applied nameplate is located at the bottom
or rear of the product.
● CAUTION: Risk of explosion if battery is
replaced by an incorrect type. Dispose of
used batteries according to the instructions.
8
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Charger
1 Connect the AC adaptor to the unit by
pressing the plug rmly.
2 Fasten the cord by hooking it.
3 Connect the AC adaptor to the power outlet.
Note:
Use only the supplied AC adaptor
MN0063-L060040.
Battery installation
1 Press down at
1
.
2 Slide the handset cover
2
.
3 Insert the batteries, then close the handset
cover.
● USE ONLY rechargeable Ni-MH batteries AAA
(R03) size (
A
).
● Do NOT use alkaline/manganese/Ni-Cd
batteries.
● Conrm correct polarities.
Setting up
Connections
Base unit
1 Connect the AC adaptor to the unit by
pressing the plug rmly.
2 Connect the telephone line cord to the unit
until you hear a click.
3 Fasten the AC adaptor cord and the telephone
line cord by hooking it.
4 Connect the AC adaptor to the power outlet.
5 Connect the telephone line cord to the
single-line telephone jack (RJ11C) until
you hear a click.
6 A DSL/ADSL lter (not supplied) is required if
you have a DSL/ADSL service.
7 Connect the corded handset cord to the corded
handset and the base unit until you hear a click.
Note:
Use only the supplied AC adaptor
MN0063-L060040.
1
2
A
+
–
+
–
7
7
5
6
4
SERIAL NO.
LINE
USE SPECIFIED ADAPTOR
ONLY
6V DC
DESK STAND
12
3
33
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
1
2
3
Hook
Hook
9
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Note for battery installation
● Use the supplied rechargeable batteries.
For replacement, we recommend using the
rechargeable batteries noted on page 3 and 6.
Note for battery charging
● It is normal for the handset to feel warm
during charging.
● Clean the charge contacts of the handset
and charger with a soft and dry cloth once a
month. Before cleaning the unit, disconnect
from power outlets and any telephone line
cords. Clean more often if the unit is exposed
to grease, dust, or high humidity.
Battery level
Icon Battery level
Battery is fully charged
Battery is partially charged
Battery is running low
Battery is almost fully discharged
Ni-MH battery performance
(supplied batteries)
Operation Operating time
In continuous use 14 hours max.
Not in use (standby) 200 hours max.
Note:
● Actual battery performance depends on usage
and ambient environment.
Battery charging
Charge for at least 7 hours.
When the handset needs charging, the display
shows “Low battery” and there is a warning
beep every 2 minutes during a call, recharge the
handset before using it again. When charging,
will scroll on the display.
Note when setting up
Note for connections
● The AC adaptor must remain connected at
all times. (It is normal for the adaptor to feel
warm during use.)
● The AC adaptor should be connected to a
vertically oriented or oor-mounted AC outlet.
Do not connect the AC adaptor to a horizontally
oriented AC outlet that faces the oor, such as
an AC outlet installed on a ceiling or under a
table, as the weight of the adaptor may cause it
to become disconnected.
Power failure
The base unit will work as a standard telephone
using power from the telephone line, so you can
make and answer outside calls with the corded
handset. However, this operation may not work
properly depending on area or telephone line’s
condition. The base unit speakerphone and the
cordless handset will not function during a power
failure.
CALL BLOCK
10
For assistance, please visit http://shop.panasonic.com/support
Getting Started
CALL BLOCK
Menu
Redial
1 Receiver
2 Call block
Short cut to call block menu, page 25.
3 Intercom
Press to make intercom call and transfer calls to
the base unit or another handset.
4 Talk/Speakerphone
Press to make and receive calls.
During a call, press to turn speakerphone on
and off.
5 Dial keypad/Speed dial buttons 1 to 9
Press and hold to dial the stored entry, page 20.
6
/Pulse to Tone dialing
Dial a star, page 19.
During a call, press to switch from pulse dialing to
tone dialing, page 15.
7 Display
See page 12 for an overview of the display icons.
8 Flash
Press to use with switchboard/PBX services and
some network services.
9 Off
Press to end a call.
10
/Change case/Pause
Dial a
.
Press and hold to change the case from Abc to
abc or ABC mode when entering or editing
letters, page 18.
Press and hold to enter a pause when pre-dialing
or storing numbers, page 15.
11 Microphone
12 Charge contacts
A Soft keys
By pressing a soft key, you can select the feature
shown directly above it on the display.
B Navigator key
– LuR
P: View the phonebook list.
– LdR
CID (Caller ID): View the caller list.
– LuR
or
LdR
: Scroll through various lists
or items.
– Volume
(
LuR
or
Ld
R
)
: Adjust the receiver or
speaker volume while talking.
– LuR
or
LdR
: Move the cursor to edit a
number or name.
Controls
Handset
7
2
A
B
3
4
5
1
A
8
9
11
12
10
6
11
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Menu
Redial
13
Call list
Press to enter the caller list, page 21.
14
SP-PHONE (Speakerphone)
SP-PHONE indicator
Press to make and receive calls.
15
/Change case/Pause
Dial a
.
Press and hold to change the case from Abc to
abc or ABC mode when entering or editing letters,
page 18.
Press and hold to enter a pause when pre-dialing
or storing numbers, page 15.
16
Exit/Stop
Press to go back to standby mode.
Press to stop playback message, page 30.
17
Play
Play/Message indicator
Press to play the message, page 30.
A
Soft keys
By pressing a soft key, you can select the feature
shown directly above it on the display.
B
Navigator key
L
u
R
or
L
d
R
: Scroll through various lists or items.
LuR
or
LdR
: Adjust the receiver or speaker volume
while talking.
LuR
or
LdR
,
L R
or
L R
: Move the cursor
to edit a number or name.
L R
or
L R
: Repeat/skip messages
during playback
Base unit
1
Corded handset
2
Receiver
3
4
Phonebook
View the phonebook list, page 18.
5
Call block
Short cut to call block menu, page 25.
6
Erase/Flash
Press to delete currently playing message, page 30.
Press to use with switchboard/PBX services and
some network services
7
Answer On/Off
Answer On/Off Indicator
Press to turn on/off the answering system.
8
Microphone
9
Speaker
10
Dial keypad
Speed dial buttons 1 to 9
Press and hold to dial the stored entry, page 20.
11
/Pulse to Tone dialing
Dial a star, page 19.
During a call, press to switch from pulse dialing to
tone dialing, page 15.
12
Locator/Intercom
Use to locate a misplaced handset.
Press to make intercom call and transfer calls to
the handset.
1 2 A 4 5A
8 9 10 12 13 16B14
6 7
1711 15
3
8
Display
See page 12 for an overview of the display icons.
12
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Display icons
Item Meaning
*
1
Indicates a received call
*
1
Indicates an outgoing call
Flashes to indicate a new missed
call and when viewing a new
missed call in the caller list
Steady when viewing a missed
call in the caller list
*
1,
*
2
Indicates a blocked number
*
1
Flashes when reveiving an
incoming call
Steady when the phone is off
hook
*
1
Speakerphone is activated
Ringer volume is off
*
3
Flashes to indicate new voicemail
messages received
Steady when the entry has been
viewed in the caller list
Flashes when recording a new
message
Steady when answering system
is on
*
1
Silent mode is on
*
1
Out of base unit range
*
1
Range status: The more bars
visible, the closer the handset is
to the base unit.
*
1
Alarm is on
*
1
Handset only.
*
2
Caller ID subscribers only.
*
3
Voice mail subscribers only.
Navigating the menus
The phone has an easy to use menu system.
Each menu has a list of options, which can be
seen on the menu map on page 13.
When the handset and base unit are in standby:
4
L
Menu
R
to open the main menu.
5
LsR
: available options.
6
L
OK
R
to select an option.
7 To return to the previous menu level, press
L
Back
R
.
8 To exit the menu and return to standby,
press
L
OFF
R
on the handset or
L
EXIT/STOP
R
on the base unit.
Note:
If no buttons are pressed for 30 seconds,
the handset and base unit returns to standby
automatically.
Date and time
Handset
1
L
Menu
R
,
L
d
R
“Personal set”,
press
L
OK
R
.
2
L
d
R
“Date & time”.
3
L
OK
R
to select.
4 Enter the current month, date, and year using
the keypad (e.g.
L
0
R L
7
R
L
1
R
L
2
R
L
2
R
L
0
R
for
July 12, 2020), press
L
OK
R
to conrm.
5 Enter the current time using the keypad
(e.g.
L
0
R
L
9
R
L
3
R
L
0
R
for 09:30), then press
LsR
to select “AM” or “PM” and press
L
OK
R
to
save.
Other settings
Dial mode
If you cannot make calls, change this setting
according to your telephone line service. The
default setting is “Tone”, to change this setting,
see page 26.
“Tone”: For tone dial service.
“Pulse”: For rotary/pulse dial service.
13
For assistance, please visit http://shop.panasonic.com/support
Getting Started
Handset
Phonebook - View
- Add new
- Edit
- Delete
*1
- Delete all
*1
Personal set - Sounds
- Ring volume
- Ring tones
- Silent mode
- Key tone
- Docking tone
- Battery tone
- Handset name
- Date & time
- Language
- Auto answer
- Auto hang-up
Alarm
- Off
- On once
- On daily
Advanced set
- Call block
- Unknown call
- Block list
- Block mode
- Block number
- Area code
- Flash time
- Dial mode
- Auto clock
- Change PIN
- Register
- Deregister
*2
- Reset
Answ. machine
- On/off
- Play all
- Record memo
- Delete all
- Outgoing msg.
- Record also
- Answer only
- Ring count
- Remote access
- TAM language
Menu Map
Base unit
Phonebook - View
- Add new
- Edit
- Delete
*1
- Delete all
*1
Personal set - Sounds
- Ring volume
- Key tone
- Language
Advanced set
- Call block
- Unknown call
- Block list
- Block mode
- Block number
- Area code
- Flash time
- Dial mode
- Auto clock
- Change PIN
- Deregister
*2
- Reset
Answ. machine
- On/off
- Play all
- Record memo
- Delete all
- Outgoing msg.
- Record also
- Answer only
- Ring count
- Remote access
- TAM language
*1
Only available if a phonebook entry is stored.
*2
This feature is not available for single handset
model.
14
For assistance, please visit http://shop.panasonic.com/support
Making and Answering Calls
Using the speakerphone
1 During a conversation with the corded
handset, press
L
SP-PHONE
R
to turn on the
speakerphone.
● You can place the corded handset on the
cradle.
● Speak into the base unit microphone.
● Speak alternately with the other party.
2 When you nish talking, press
L
SP-PHONE
R
.
Note:
● For best performance, use the speakerphone
in a quiet environment.
● To switch to the receiver, lift the corded
handset.
Making a call using the redial list
The last 10 phone numbers dialed are stored in
the redial list (each 24 digits max.).
1
L
Redial
R
.
2
LsR
: Select the desired entry.
3 Lift the corded handset or press
L
SP-PHONE
R
.
Deleting an entry or all entries in the redial list
1
L
Redial
R
.
2
LsR
: Select the desired entry, press
L
OK
R
.
3 d
4
5
Adjusting the receiver or speaker
volume
Handset / Base unit
LsR
repeatedly while talking.
Pause (for PBX/long distance
service users)
A pause is sometimes required when making
calls using a PBX or long distance service. When
storing a calling card access number and/or PIN in
the phonebook, a pause is also needed.
Example: If you need to dial the line access
number “9” when making outside calls with
a PBX:
Making calls
Using the handset
1 Lift the handset and dial the phone number.
2
● To correct a digit, press
L
Clear
R
.
TALK/SP-PHONE
R
.
3 When you nish talking, press
L
OFF
R
or place
the handset on the charger.
Note:
● While talking, you can switch between the
receiver and the speakerphone by pressing
L
TALK/SP-PHONE
R
.
● In step 1, you can store the dialed phone
number to the phonebook by pressing
L
Save
R
.
Auto hang-up: You can end a call simply by
placing the handset on the charger (page 24).
Making a call using the redial list
The last 10 phone numbers dialed are stored in
the redial list in each unit (each 24 digits max.).
1
L
Redial
R
.
2
LsR
: Select the desired entry.
3
L
TALK/SP-PHONE
R
.
Deleting an entry or all entries in the redial list
1
2
3
4
5
Using the base unit
1 Dial the phone number.
● To correct a digit, press
L
Clear
R
.
2 Lift the corded handset.
3 When you nish talking, place the corded
handset on the cradle.
Note:
You can also dial the phone number after lifting
the corded handset.
● To make the call using the speakerphone,
press
L
TALK/SP-PHONE
R
.
L
Redial
R
.
L
L
sR
: Select the desired entry, press
L
OK
R
.
L
OK
R
,
L
d
R
“
Delete
” or “
Delete all
”.
L
OK
R
to conrm or
L
Back
R
to cancel.
L
OK
R
. “
Confirm?
”.
L
OK
R
,
L
d
R
“
Delete
” or “
Delete all
”.
L
OK
R
to conrm or
L
Back
R
to cancel.
L
OK
R
. “
Confirm?
”.
15
For assistance, please visit http://shop.panasonic.com/support
Making and Answering Calls
Useful features during a call
Mute
Handset / Base unit
1
L
Mute
R
during a call.“
Mute on”.
2 To return to the call, press
L
Mute
R
.
Flash
Handset / Base unit
Pressing
L
FLASH
R
on the handset or
L
ERASE/
FLASH
R
on the base unit allows you to use
the special features of your host PBX such as
transferring an extension call, or accessing
optional telephone services.
Note:
● To change the flash time, see page 26.
For call waiting or Call Waiting
Caller ID service users
To use call waiting or Call Waiting Caller ID, you
must rst subscribe with your phone service
provider.
This feature allows you to receive calls while you
are already talking on the phone. If you receive
a call while on the phone, you will hear a call
waiting tone.
If you subscribe to both Caller ID and Call
Waiting with Caller ID services, the 2nd caller’s
information is displayed on the handset that is in
use after you hear the call waiting tone.
Handset / Base unit
1 Press
L
FLASH
R
on the handset or
L
ERASE/FLASH
R
on the base unit to answer
the 2nd call.
2 To switch between calls, press
L
FLASH
R
on the handset or
L
ERASE/FLASH
R
on the
base unit.
Temporary tone dialing
(for rotary/pulse service users)
Press
L R
before entering access numbers which
require tone dialing.
Handset
1
L9R
press and hold L R. “P” (Pause) will
be displayed.
2 Dial the phone number.
L
TALK/SP-
PHONE
R
.
Base unit
1
L9R
press and hold L R. “P” (Pause) will
be displayed.
2 Dial the phone number.
3 Lift the corded handset.
Note for handset and base unit:
● A 3.5 second pause is inserted each time you
press and hold
L R (Pause).
Answering calls
Using the handset
1 Lift the handset and press
L
TALK/SP-PHONE
R
when the unit rings.
2 When you nish talking, press
L
OFF
R
or place
the handset on the charger.
Auto answer: You can answer calls simply by
lifting the handset off the charger. You do not
need to press
L
TALK/SP-PHONE
R
. To turn this
feature on, see page 24.
Temporary ringer off: You can turn the ringer off
temporarily by pressing
L
Silent
R
(right soft key).
Using the base unit
When a call is being received, the SP-PHONE
indicator ashes.
1 Lift the corded handset or press
L
SP-PHONE
R
when the unit rings.
2 When you nish talking, place the
corded handset on the cradle. When the
speakerphone is used, press
L
SP-PHONE
R
.
Temporary ringer off: You can turn the ringer off
temporarily by pressing
L
Silent
R
(right soft key).
Adjusting the ringer volume
Handset / Base unit
LsR
repeatedly to select the desired volume while
ringing.
Handset / Base unit
16
For assistance, please visit http://shop.panasonic.com/support
Making and Answering Calls
Receiving an intercom call
Handset
When an intercom call is received, base unit or
the handset number that is calling is displayed.
1
L
TALK/SP-PHONE
R
to answer the call.
Base unit
When an intercom call is received, the handset
number that is calling is displayed.
1 Lift the corded handset to answer the call.
Transferring calls
Outside calls can be transferred or a conference
call with an outside party can be made:
– between handsets
– between a handset and the base unit
During an outside call:
Handset
1 If only one handset is registered to the base
unit, press
L
INTERCOM
R
and the base unit
rings automatically.
2 If 2 or more handsets are registered to the
base unit, press
L
INTERCOM
R
L
d
R
to
select the handset / base unit that is to be
called, press
L
OK
R
.
3 When the other handset or base unit answers,
press
L
OFF
R
to complete the transfer.
Base unit
1 If only one handset is registered to the base
unit, press
L
LOCATOR/INTERCOM
R
and the
handset rings automatically.
2 If 2 or more handsets are registered to the
base unit, press
L
LOCATOR/INTERCOM
R
L
d
R
to select the handset that is to be
called, press
L
OK
R
.
3 When the handset answers, place the corded
handset on the cradle to complete the
transfer.
Note:
If there is no answer from the other handset /
base unit, press
L
INTERCOM
R
on the handset
or
L
LOCATOR/INTERCOM
R
on the base unit
to return to the outside caller. The outside call
resumes automatically after 60 seconds if there is
no answer.
Handset equalizer
This feature claries the voice of the person
you are talking to, producing a more natural-
sounding voice that is easier to hear and
understand.
You can choose from
“Treble”
,
“Alto”
or
“Bass”
.
1 Press
L
Options
R
while talking.
2
L
d
R
“Equalizer”
, press
L
OK
R
.
3
LsR
Select the desired setting, press
L
OK
R
.
Note:
● Depending on the condition and quality
of your telephone line, this feature may
emphasise exixting line noise.
● If it becomes difcult to hear, you can change
the setting.
● This feature is not available while using the
speakerphone.
Intercom, transferring calls
and conference calls
Making an intercom call
Intercom calls can be made:
– between handsets
– between a handset and the base unit
Handset
1 If only one handset is registered to the base
unit, press
L
INTERCOM
R
and the base unit
rings automatically.
2 If 2 or more handsets are registered to the
base unit, press
L
INTERCOM
R
L
d
R
to
select the handset / base unit that is to be
called, press
L
OK
R
.
Base unit
1 If only one handset is registered to the
base unit, press LOCATOR/INTERCOM
R
,
the handset rings automatically.
Lift the corded handset if needed.
2 If 2 or more handsets are registered to the
base unit, press LOCATOR/INTERCOM ,
d
to select the handset that is to be
called, press
L
OK
R
.
Lift the corded handset if needed.
L
L R
L
R
17
For assistance, please visit http://shop.panasonic.com/support
Making and Answering Calls
3-way conference call
To hold a 3-way conference call between 2
intercom callers and 1 outside caller.
During an outside call:
Handset
1 If only one handset is registered to the base
unit, press
L
INTERCOM
R
and the base unit
rings automatically.
2 If 2 or more handsets are registered to the
base unit, press
L
INTERCOM
R
L
d
R
to
select the handset / base unit that is to be
called, press
L
OK
R
.
3 Once the other handset or base unit answers,
press
L
Conf
R
to join all 3 callers.
Base unit
1 If only one handset is registered to the base
unit, press
L
LOCATOR/INTERCOM
R
and the
handset rings automatically.
2 If 2 or more handsets are registered to the
base unit, press
L
LOCATOR/INTERCOM
R
L
d
R
to the handset that is to be called and
press
L
OK
R
.
3 When the handset answers, press
L
Conf
R
to
join all 3 callers.
Handset locator
The handset locator can be used to alert a
handset user that they are wanted or locate
a missing handset. Locator calls cannot be
answered by a handset.
1
L
LOCATOR/INTERCOM
R
on the base unit.
2
L
d
R
“Locate all”
, press
L
OK
R
.
3 To stop the ringing,
L
LOCATOR/INTERCOM
R
or press any button on the handset.
18
For assistance, please visit http://shop.panasonic.com/support
Phonebook
Storing a redial list number to the
phonebook
Handset / Base unit
1
L
Redial
R
.
2
LsR
: Select the desired entry, press
L
OK
R
.
3
L
OK
R
. “Save number”.
4
L
OK
R
. “Enter name”.
5 Enter the name, press
L
OK
R
. The number is
displayed.
6 Edit the number if necessary, then press
L
OK
R
.
The number is stored.
Storing caller information to the
phonebook
Handset / Base unit
Handset:
L
d
R
CID.
Base unit:
L
CALL LIST
R
.
2
LsR
: Select the desired entry.
3
L
Options
R
,
L
d
R
“Save number”.
4
L
OK
R
.
5 Enter the name if necessary, then press
L
OK
R
.
The number is displayed.
6 Edit the number if necessary, then press
L
OK
R
.
The number is stored.
Viewing or dialing an entry
Handset / Base unit
1 Proceed with the operation for your unit.
Handset:
L
u
R
P.
Base unit:
LPR
.
Phonebook
The phonebook can store up to 70 names and
numbers. Names can be up to 16 characters and
numbers up to 24 digits.
Storing a name and number
When subscribed to Caller ID, to display the
name of the caller instead of the number, save
the full telephone number including the area code
to the phonebook.
Multiple entries can be stored with the same
name. However, to prevent unnecessary
duplicated entries, the number can be stored only
once.
Handset / Base unit
1
L
Menu
R
. “Phonebook”.
2
L
OK
R
,
L
d
R
“Add new”.
3
L
OK
R
. “Enter name”.
4 Enter the name, press
L
OK
R
. “Enter number”
is displayed.
5 Enter the number, press
L
OK
R
. The entry is
saved.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Entering names and writing tips
Handset / Base unit
Use the keypad letters to enter names, e.g. to
store Tom:
L8R
once to enter T.
L6R
three times to enter o.
L6R
once to enter m.
To change the text from lower to upper case,
press and hold
L
.
Clear
R
to delete the last character or digit.
LsR
: Move between characters/digits.
L0R
to insert a space.
R
L
1 Proceed with the operation for your unit.
Note:
See ‘Entering names and writing tips’ on
page 18.
7 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Note:
See ‘Entering names and writing tips’ on
page 18.
7 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
19
For assistance, please visit http://shop.panasonic.com/support
Phonebook
Chain dial
Base unit
This feature allows you to dial phone numbers
in the phonebook while you are on a call. This
feature can be used, for example, to dial a
calling card access number or bank account PIN
that you have stored in the phonebook, without
having to dial manually.
1 During an outside call, press
L
P
R
.
2
LsR
: Select the required entry.
3 Press
L
OK
R
2 times.
Note:
When storing a calling card access number and
your PIN in the phonebook as one phonebook
entry, press and hold
L R to add pauses after the
number and PIN as necessary (page 15).
If you have rotary/pulse service, you need
to press
L R
before pressing
L
P
R
in step 1 to
change the dialing mode temporarily to tone.
When adding entries to the phonebook, we
recommend adding
L R
to the beginning of phone
numbers you wish to chain dial.
Speed dial
You can assign 1 phone number to each of the
dial keys (1 to 9) in the handset and base unit.
The speed dial name can be up to 14 characters
and the speed dial number can be up to 24 digits.
If a number is stored in the phonebook, it cannot
be stored as a speed dial number.
3 Proceed with the operation for your unit.
Handset:
L
TALK/SP-PHONE
R
to dial or
L
OFF
R
to return to standby.
Base unit: Lift the corded handset or
L
EXIT/
STOP
R
to return to standby.
Note:
When the list is displayed, to view detailed, press
L
View
R
. To return to the list, press
L
Back
R
.
Editing a name and number
Handset / Base unit
1
L
Menu
R
. “Phonebook”.
2
L
OK
R
,
L
d
R
“Edit”, press
L
OK
R
.
3
LsR
: To select the entry that needs to be edited,
or search alphabetically, press
L
OK
R
.
4
L
Clear
R
to delete the name if required, then
enter the new name, press
L
OK
R
. The existing
number is displayed.
5
L
Clear
R
to delete the number if required, then
enter the new number, press
L
OK
R
. The entry
is saved.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Deleting an entry
Handset / Base unit
1
L
Menu
R
. “Phonebook”.
2
L
OK
R
,
L
d
R
“Delete”, press
L
OK
R
.
3
LsR
: To select the entry that needs to be
deleted, or search alphabetically, press
L
OK
R
.
4 The display shows “Confirm?”.
5
L
OK
R
to conrm or
L
Back
R
to cancel.
Deleting all entries
Handset / Base unit
1
L
Menu
R
. “Phonebook”.
2
L
OK
R
,
L
d
R
“Delete all”, press
L
OK
R
.
3 The display shows “Confirm?”.
4
L
OK
R
to conrm or
L
Back
R
to cancel.
5 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
2
LsR
: Select the required entry.
OR
Enter the rst letter of the name to search
alphabetically. The rst name that starts with
this letter or the nearest letter in the alphabet
will be displayed.
LsR
: Select the required entry.
20
For assistance, please visit http://shop.panasonic.com/support
Phonebook
Note:
● An entry stored in the phonebook can not be
stored as a speed dial number.
● If you want to delete the speed dial number,
follow “Deleting an entry” on page 19.
Dial a speed dial number
Handset / Base unit
1 Press and hold the relevant key until the
number is displayed and dialed.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Storing phone numbers to
speed dial keys
Handset / Base unit
1
2
d
3
Menu
R
. “Phonebook”.
L
OK , “Edit”, press
L
OK
R
.
L R L R
L
sR
: To select the key you want to store the
number, press
L
OK
R
.
4 Enter the name, press
L
OK
R
.
5 Enter the number, press
L
OK
R
.
21
For assistance, please visit http://shop.panasonic.com/support
Caller ID Service
Area code
Phone numbers stored automatically in the caller
list will include area codes. If you do not want to
dial the area code when making calls from the
caller list, you can store the area code which you
want the unit to delete automatically. The area
code must be 3-digit long.
Handset / Base unit
1
L
MENU
R
,
L
d
R
“Advanced set”, press
L
OK
R
.
2
L
d
R
“Area code”
, press
L
OK
R
.
3 Enter the 3-digit area code, press
L
OK
R
to conrm.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Caller list
Make sure the unit’s date and time setting is
correct, page 24.
Viewing the caller list
Handset / Base unit
1 Proceed with the operation for your unit.
Handset:
L
d
R
CID to open the caller list.
Base unit:
L
CALL LIST
R
to open the caller list.
● If there are no calls in the list, the display
shows “List empty”.
2
LsR
: To the required entry.
3
L
Options
R
, “View”, press
L
OK
R
.
4 The display shows the date and time of the
call.
Note:
disappears after viewing all missed call.
Dialing an entry in the caller list
Handset / Base unit
1 Proceed with the operation for your unit.
Handset:
L
d
R
CID to open the caller list.
Base unit:
L
CALL LIST
R
to open the caller list.
2
LsR
: To the required entry.
3 Proceed with the operation for your unit.
Handset:
L
TALK/SP-PHONE
R
.
Base unit: Lift the corded handset or press
L
SP-PHONE
R
.
Using Caller ID service
IMPORTANT
● This unit is Caller ID compatible. To use Caller
ID features, you must subscribe to a Caller ID
service. Contact your phone service provider
for details.
Caller ID features
When an outside call is being received, the
caller’s phone number is displayed. Caller
information for the last 50 callers is logged in the
caller list from the most recent call to the oldest.
● If the unit cannot receive caller information,
the following is displayed:
-
“Unknown”
: The caller dials from an area
which does not provide a Caller ID service.
-
“Private”
: The caller requests not to send
caller information.
● If the unit is connected to a PBX system,
caller information may not be properly
received. Contact your PBX supplier.
Missed calls
If a call is not answered, the unit treats it as a
missed call. The display ashes
. This lets you
know if you should view the calls list to see who
called while you were away.
Phonebook name display
When caller information is received and it matches
a phone number stored in the phonebook, the
stored name in the phonebook is displayed and
logged in the caller list.
To ensure that the caller’s name is displayed,
make sure the full telephone number, including
the area code is stored in the phonebook.
22
For assistance, please visit http://shop.panasonic.com/support
Caller ID Service
Editing a caller’s phone
number
You can edit a phone number in the caller list by
removing its area code and/or the long distance
code “1”.
Handset / Base unit
1 Proceed with the operation for your unit.
Handset:
L
d
R
CID to open the caller list
Base unit:
L
CALL LIST
R
to open the caller list.
2
LsR
: To the required entry.
3
L
Options
R
, “View”, press
L
OK
R
.
4 Press L R repeatedly until the number number
is shown in the desired format.
5 Proceed with the operation for your unit.
Handset:
L
TALK/SP-PHONE
R
.
Base unit: Lift the corded handset.
Deleting an entry
Handset / Base unit
1 Proceed with the operation for your unit.
Handset:
L
d
R
CID to open the caller list.
Base unit:
L
CALL LIST
R
to open the caller list.
2
LsR
: To the required entry.
3
L
Options
R
,
L
d
R
“Delete”.
4
L
5
L
OK
R
. “Confirm?”.
OK
R
to con
rm or
L
Back
R
to cancel.
Deleting the entire caller list
Handset / Base unit
1 Proceed with the operation for your unit.
Handset:
L
d
R
CID to open the caller list.
Base unit:
L
CALL LIST
R
to open the caller list.
2
L
Options
R
, d “Delete all”.
3
L
L
R
OK
R
.
“Confirm?
”.
4
L
OK
R
to conrm or
L
Back
R
to cancel.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
23
For assistance, please visit http://shop.panasonic.com/support
Programming
Personal settings
Sounds
Ringer volume
The ring volume can be set to different volume
levels. Choose from 5 volume levels or Off.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3 “Ring volume”, press
L
OK
R
.
4
LsR
: Select the volume (1 - 5 or “Off”), press
L
OK
R
.
5 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Note:
When the phone is ringing, adjust the ringer
volume by pressing
LsR
.
Ringer melody
Different ringer melodies of the handset can be
set. Choose from 10 different ringer melodies.
While scrolling a sample ring will be heard for
each melody.
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3
L
d
R
“Ring tones”, press
L
OK
R
.
4
LsR
: Select the ring tone (1 - 10), press
L
OK
R
to save.
5
L
OFF
R
to return to standby.
Note:
The preset melodies in this product are used with
permission of ©2015 Copyrights Vision Inc.
Silent mode
Silent mode can be set for a designated time
period. Once activated when you receive an
incoming call the handset will not ring.
IMPORTANT
We recommend turning the base unit ringer off
(page 15) in addition to turning the silent mode
on.
While silent mode is activated, you cannot hear
operating and notication tones of the handset.
■Turning silent mode on /off
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3
L
d
R
“Silent mode”, press
L
OK
R
.
4 “On/off”, press
L
OK
R
.
5
LsR
: Select “On” or “Off”, press
L
OK
R
.
6
L
OFF
R
to return to standby.
■Changing the start and end time
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3
L
d
R
“Silent mode”, press
L
OK
R
.
4
L
d
R
“Start & end”, press
L
OK
R
.
5 Enter the start time using the keypad
L
0
R L
2
R
L
3
R L
0
R
for 2:30), then press
LsR
to select “AM”
or “PM” and press
L
OK
R
.
Enter the end time using the keypad (e.g.
L
0
R
L
3
R
L
3
R
L
0
R
for 3:30), then press
LsR
to select
“AM” or “PM” and press
L
OK
R
to save.
6
L
OFF
R
to return to standby.
Key tones
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3
L
d
R
“Key tone”, press
L
OK
R
.
4
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
5 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Docking tone
When you replace the handset in the base unit,
you will hear a double beep. You can switch this
beep on or off.
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3
L
d
R
“Docking tone”, press
L
OK
R
.
24
For assistance, please visit http://shop.panasonic.com/support
Programming
Language
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2
L
d
R
“Language”, press
L
OK
R
.
3
LsR
: Select the preferred language, press
L
OK
R
to save.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Languages available are English, Spanish
and French.
Auto answer
The phone is set to answer calls by lifting the
handset off the charger. This feature can be
switched off so that calls can only be answered
by pressing
L
TALK/SP-PHONE
R
.
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2
L
d
R
“Auto answer”, press
L
OK
R
.
3
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
4
L
OFF
R
to return to standby.
Auto hang-up
The phone is set to end calls by pressing
L
OFF
R
.
This feature can be switched on so that calls can
be ended by placing the handset on the charger.
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2
L
d
R
“Auto hang-up”, press
L
OK
R
.
3
L
d
R
: Select “On” or “Off”, press
L
OK
R
to
conrm.
4
L
OFF
R
to return to standby.
Alarm
Handset
1
L
Menu
R
,
L
d
R
“Alarm”, press
L
OK
R
.
2
LsR
: Select “Off”, “On once” or “On daily”,
press
L
OK
R
.
3 If you select “On once” or “On daily”, enter
the time using the keypad (e.g.
L
0
R L
2
R L
3
R
L
0
R
for 2:30), then press
LsR
to select “AM” or
“PM” and press
L
OK
R
to save.
4
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
5
L
OFF
R
to return to standby.
Battery tone
When your batteries are running low on charge,
you will hear a beep. You can switch this beep
on or off.
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2 “Sounds”, press
L
OK
R
.
3
L
d
R
“Battery tone”, press
L
OK
R
.
4
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
5
L
OFF
R
to return to standby.
Handset name
A personalized name can be set for each handset
to easily distinguish between them. A name can
be up to 14 characters.
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2
L
d
R
“Handset name”, press
L
OK
R
.
3 Enter the new handset name, press
L
OK
R
to
save.
To delete the current name or if a mistake is
made, press
L
Clear
R
to delete the last character
or digit.
4
L
OFF
R
to return to standby.
Note:
See ‘Entering names and writing tips’, page 18.
Date and time
Handset
1
L
Menu
R
,
L
d
R
“Personal set”, press
L
OK
R
.
2
L
d
R
“Date & time”, press
L
OK
R
.
3 Enter the current month, date, and year using
the keypad (e.g.
L
0
R L
7
R
L
1
R
L
2
R
L
2
R
L
0
R
for
July 12, 2020), press
L
OK
R
to conrm.
4 Enter the current time using the keypad
(e.g.
L
0
R
L
9
R
L
3
R
L
0
R
for 9:30), then press
LsR
to select “AM” or “PM” and press
L
OK
R
to save.
5
L
OFF
R
to return to standby.
25
For assistance, please visit http://shop.panasonic.com/support
Programming
s
4 Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Switching call block on/off
Handset / Base unit
2
L
d
R
“Block list”, press
L
OK
R
.
3 “Block mode”, press
L
OK
R
.
4
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
5 Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Setting a number to be blocked
You can store up to 50 phone numbers in the call
block list.
To activate this feature, you must turn the block
mode on (page 25).
Handset / Base unit
■Adding call blocked number from the
caller list
1 Proceed with the operation for your unit.
Handset:
L
d
R
CID to open the caller list.
Base unit:
L
CALL LIST
R
to open the caller list.
2
LsR
: To the required entry.
L
Options
R
.
3
L
d
R
: “Block number”, press
L
OK
R
2 times.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
■Adding call blocked number manually
2
L
d
R
3
L
d
R
“Block list”, press
L
OK
R
.
“Block number”, press
L
OK
R
.
4
LsR
: to the next available slot, press
L
OK
R
.
4
L
OFF
R
to return to standby.
Once the alarm is set to on, the
icon is
displayed. When the alarm goes on the icon
ashes. Press any dial key to stop the sound.
If set to “On once” then the alarm will turn off
automatically after it sounds. If the alarm is set to
“On daily” the alarm will sound at that time every
day, to turn the alarm off select “Off” in the menu.
Advanced settings
Call block
This feature allows the unit to block calls from
specied phone numbers that you do not want to
answer such as junk calls (Caller ID subscribers
only).
When a call is received, the unit does not ring
while the caller is being identied.
If the caller’s phone number matches an entry in
the block list, the unit emits no sound to the caller
and “Blocked caller” is displayed for about 7
seconds, then disconnects the call.
To disconnect the current call and add a
phone number to the call block list
You can press the
L
CALL BLOCK
R
button in the
following situations to disconnect the current call
and add a phone number to the call block list:
– when an incoming call is being received
– when an incoming call is being received by
the answering system
– when talking on an outside call
Once a phone number has been added to the
call block list, the unit will block calls from that
phone number in the future.
Handset / Base unit
1 Press
L
CALL BLOCK
R
under the situations
shown above.
● The call block number is stored in the call
block list and “Blocked caller” is displayed
for about 7 seconds, then the call is
disconnected.
Switching unknown call block on/off
Handset / Base unit
5 Enter the number or pre ix you want to block.
Press
L
OK
R
to con irm.
6 Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Note:
When you store a phone number in the block
list, you will need to store the full number
including the area code for the number to be
blocked.
If you want to change/delete the block list
number, follow the first 3 steps in “Adding call
blocked number manually” above, and then
1
L
CALL BLOCK
R
.
2 “Unknown call”, press
L
OK
R
.
3
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
1
L
CALL BLOCK
R
.
1
L
CALL BLOCK
R
.
26
For assistance, please visit http://shop.panasonic.com/support
Programming
Change PIN
Some functions are protected by a 4-digit PIN
code which must be entered if the settings are
changed. The default PIN is 0000. The PIN can
be changed to a preferred number.
When entering a PIN, the digits are shown as
****.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Advanced set”, press
L
OK
R
.
2
L
d
R
“Change PIN”, press
L
OK
R
.
3 If the PIN is already changed from default
setting, enter the current 4-digit PIN, press
L
OK
R
.
4 Enter a new 4-digit PIN, press
L
OK
R
.
5 Re-enter the new PIN, press
L
OK
R
to save.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
IMPORTANT
If the PIN code is changed, please keep a record
of the new number.
Registering a handset
Note:
Handset batteries must be fully charged before
registration. Hold the handset close to the base
unit during the registration process.
Handsets that were supplied with the base unit
are already pre-registered.
On the base unit:
1 Press and hold
L
LOCATOR/INTERCOM
R
for 5 seconds. The base unit will remain in
registration mode for 120 seconds.
On the handset:
2 If the handset is not registered to a base
unit: “Register your Handset”, press
L
OK
R
.
“Press locator Key for 5 sec”, press
L
OK
R
and then enter the 4-digit PIN code (default =
0000),
L
OK
R
.
3 If the handset is already registered to a base
unit, press
L
Menu
R
,
L
d
R
“Advanced set”,
press
L
OK
R
.
L
d
R
“Register”, press
L
OK
R
.
4 “Press locator key for 5 sec”, press
L
OK
R
.
5 Enter the 4-digit PIN code (default = 0000),
press
L
OK
R
.
A beep will be heard if the registration is
successful. The handset is automatically
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Advanced set”, press
L
OK
R
.
2
L
d
R
“Flash time”, press
L
OK
R
.
3
LsR
: Select “80ms”, “90ms”, “100ms”,
“110ms”, “160ms”, “200ms”, “250ms”,
“300ms”, “400ms”, “600ms”, “700ms”
or “900ms”, press
L
OK
R
to save.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Dial mode
Your phone is set to tone dialing. You should
only need to change this if connected to a PBX/
switchboard which requires pulse dialing.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Advanced set”,
L
OK
R
.
2
L
d
R
“Dial mode”,
L
OK
R
.
3
LsR
: Select “Tone” or “Pulse”,
L
OK
R
.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Auto clock
If you have subscribed to Caller ID Service,
the date and time will be set on your base unit
whenever a call is received. This feature can be
set to On or Off.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Advanced set”, press
L
OK
R
.
2
L
d
R
“Auto clock”, press
L
OK
R
.
3
LsR
: Select “On” or “Off”, press
L
OK
R
to save.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Flash time
This setting is useful to access certain network
and PBX/switchboard services. The default ash
time is suitable for your country and network
operator. It is unlikely that you should need to
change this setting unless advised to do so.
press to the slot where the number is stored,
press . To delete the number, press
, either press to delete, or enter a
new number and press .
LsR
L
OK
R
L
CLEAR
R
L
OK
R
L
OK
R
27
For assistance, please visit http://shop.panasonic.com/support
Programming
Default settings by reset
Phonebook Unchanged
Speed dial Unchanged
Ring volume (Handset) 5
Ring volume (Base unit) 5
Ring tones
*1
1
Silent mode (End time)
*1
08:00AM
Key tone On
Docking tone
*1
On
Battery tone
*1
On
Handset name
*1
Unchanged
Date & time Unchanged
Language English
Auto answer
*1
Off
Auto hang-up On
Alarm
*1
Off
Call block (Unknown call) Off
Call block (Block mode) Off
Call block (Block number) Unchanged
Area code Empty
Flash time 700ms
Dial mode Tone
Auto clock Unchanged
Change PIN 0000
Caller list Unchanged
Redial list Unchanged
Receiver/speaker volume
(Handset)
3
Receiver/speaker volume
(Base unit)
3
Handset equalizer
*1
Alto
Answering system On
Answer mode Record also
Greeting message Use default
assigned an available handset number. Use this
number when making internal calls.
Note:
If registration is not successful the rst time,
please repeat the process again in case the base
unit registration period ran out of time. If the base
unit is not found after about 120 seconds, the
handset returns to standby. Try registering again.
De-registering a handset
A handset can cancel other handsets registered
to the same base unit. This allows the handset to
end its wireless connection with the system.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Advanced set”, press
L
OK
R
.
2
L
d
R
“Deregister”, press
L
OK
R
.
3 Enter the 4-digit PIN code (default = 0000),
press
L
OK
R
.
4
L
d
R
to select the handset that needs to be
de-registered, press
L
OK
R
. A conrmation
beep will be heard and the display will return
to standby.
Restore default settings
The phone can be restored to its default (original)
settings. All the handsets that are registered to
the base unit will be retained.
IMPORTANT
Current handset and base unit settings will be
reset. Some contents will be retained even if you
reset the phone setting. See “Default setting by
reset” for details.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Advanced set”, press
L
OK
R
.
2
L
d
R
“Reset”, press
L
OK
R
.
3 The display shows “Confirm?”.
4 Proceed with the operation for your unit.
Handset:
L
OK
R
to conrm or
L
OFF
R
to return to
standby.
Base unit:
L
OK
R
to conrm or
L
EXIT/STOP
R
to return to standby.
The phone will restart automatically.
Silent mode
*1
Off
Silent mode (Start time)
*1
08:00PM
28
For assistance, please visit http://shop.panasonic.com/support
Programming
Recording message Unchanged
Ring count 4 rings
Remote access Deactivate
Security code
0000
*1
Handset only
TAM language English
29
For assistance, please visit http://shop.panasonic.com/support
Answering System
Answering system
The answering system can answer and record
calls for you when you are unavailable to answer
the phone.
You can also set the unit to play a greeting
message but not to record caller messages
by selecting “Answer only” after setting the
answering system “On”.
IMPORTANT
Make sure the unit’s date and time setting is
correct (page 24).
Memory capacity (including your
greeting message)
The total recording capacity is about 25 minutes.
A maximum of 59 messages can be recorded.
Note:
When message memory becomes full:
– “Memory full!” is shown on the handset
and base unit display.
– The total number of new messages are not
displayed even if the answering system is
turned on.
– The unit automatically switches to “Answer
only” mode even if you selected “Record
also”
.
Turning the answering
system on/off
The answering system is preset to on.
Using the base unit keys
Press
L
ANSWER ON/OFF
R
to turn on/off the
answering system.
Via the menu
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2 “On/off”, press
L
OK
R
.
3
LsR
: Select “On” or “Off”, press
L
OK
R
.
If On is selected,
LsR
“Record also” or
“Answer only”, press
L
OK
R
.
Note for base unit and handset:
When the answering system is turned on:
– the ANSWER ON/OFF indicator on the base
unit lights up.
– is displayed.
Call screening
Base unit
While a caller is leaving a message, you can
listen to the call through the base unit’s speaker.
To adjust the volume, press
L
u
R
or
L
d
R
repeatedly.
You can answer a call by:
– lifting the corded handset from the base unit
– pressing L
TALK/SP-PHONE
R on the handset.
Note:
You can also adjust the volume by pressing
L
u
R
or
L
d
R
in standby.
Greeting message
When the unit answers a call, a greeting
message is played to callers.
You can use either:
– your own greeting message
– a pre-recorded greeting message
Recording your greeting message
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2
L
d
R
“Outgoing msg.”, press
L
OK
R
.
3
LsR
: Select “Record also” or “Answer only”,
press
L
OK
R
.
4
L
d
R
“Record”, press
L
OK
R
.
5 Once you hear the beep say your message
into the handset / base unit microphone, press
L
Save
R
to end recording. The greeting will be
played back.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
30
For assistance, please visit http://shop.panasonic.com/support
Answering System
Listening to messages
Note:
● “Missed call” is still shown even after you have
listened to messages. To remove this message,
see “Viewing the caller list” on page 21.
Using the base unit keys
When new messages have been recorded:
– Play/Message indicator on the base unit
ashes.
– ashes with the total number of new
messages.
Press
L
PLAY
R
.
● If new messages have been recorded, the
base unit plays back new messages.
● If there are no new messages, the base unit
plays back all messages.
Operating the answering system during
playback
Key Operation
L
u
R
or
L
d
R
Adjust the speaker volume
L
b
R
Play previous message
L
f
R
Skip message
L
EXIT/STOP
R
Stop playback
L
ERASE/FLASH
R
Delete currently playing
message
Via the menu
When new messages have been recorded,
ashes on the display.
Handset / Base unit
To listen to new messages:
L
Listen
R
*
*If you stop the playback operation halfway,
L
Listen
R
disappears from the standby display even when
there are new messages which are not played.
To listen to all messages:
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
L
d
R
“Play all”, press
L
OK
R
.
Using a pre-recorded greeting message
The unit provides 2 pre-recorded greeting
messages:
– If you erase or do not record your own
greeting message, the unit plays a pre-
recorded greeting asking callers to leave a
message.
– If the greeting is set to “Answer only”,
callers’ messages are not recorded and the
unit plays a different pre-recorded greeting
message asking callers to call again.
Resetting to a pre-recorded greeting message
If you change into a pre-recorded greeting
message once you record your own greeting
message, your own recorded greeting message
is erased.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”,
press
L
OK
R
.
2
L
d
R
“Outgoing msg.”, press
L
OK
R
.
3
LsR
: Select “Record also” or “Answer only”,
press
L
OK
R
.
4
L
d
R
“Use default”, press
L
OK
R
.
5 “Confirm?”, press
L
OK
R
.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Playing back the greeting message
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”,
press
L
OK
R
.
2
L
d
R
“Outgoing msg.”, press
L
OK
R
.
3
LsR
: Select “Record also” or “Answer only”,
press
L
OK
R
.
4 “Play”, press
L
OK
R
.
5 The current greeting will play back.
6 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
31
For assistance, please visit http://shop.panasonic.com/support
Answering System
Ring count
Select the duration of rings before your answer
machine picks up the call. Choose from 3-8 rings
or Toll saver.
When set to Toll saver, if you have new
messages your phone answers after 3 rings.
If there are no new messages it will answer
after 5 rings. So you have the option to hang up,
saving the time and cost of a call.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2
L
d
R
“Ring count”, press
L
OK
R
. It will display
the current setting.
3
LsR
: Select the number of rings required and
press
L
OK
R
to save.
Remote access
You can operate your answering machine from
any DTMF phone by calling your product and
entering a 4-digit security code.
Dial your telephone number. When you hear your
outgoing message, press
L R
.
Enter your 4-digit security code (default setting
0000) you will hear a conrmation beep. Use the
keypad to operate the answering machine.
Key Operation
1 Play new messages
2 Play all messages
3 Delete currently playing
message
4 Skip back to previous message
5 Answer on/off
6 Skip forward to next message
8 Play the greeting message
9 Record the greeting message
0 Play remote access menu
Note:
If you want to listen the same message again,
press 4, then press 6.
Note for handset:
All new messages will automatically play back
via the loudspeaker then, press
L
TALK/SP-PHONE
R
for private playback. The
display shows the number of new messages
and the date and time the messages were left. If
there are no new messages, all stored messages
are played.
During playback
L
Options
R
LsR
: to change the options.
L
OK
R
Options Operation
Repeat Repeat message
Next Skip message
Previous Play previous message
Delete Delete currently playing
message
Deleting all old messages
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2
L
d
R
“Delete all”, press
L
OK
R
.
Recording a memo message
You can record memo messages for other
users which can be played back just like normal
messages.
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2
L
d
R
“Record memo”, press
L
OK
R
.
After the tone record your memo by speaking
into the microphone, press
L
Save
R
to end
recording. The message will be played back.
3
L
OK
R
to stop playback or
L
Delete
R
to delete.
3 “Confirm?”, press
L
OK
R
.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
Handset / Base unit
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
32
For assistance, please visit http://shop.panasonic.com/support
Answering System
Remote access on/off and change
remote security code
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2
L
d
R
“Remote access”, press
L
OK
R
.
3
LsR
: Select “Activate”, “Deactivate” or
“Security code”, press
L
OK
R
.
4 If you select “Security code”, enter the old
code and press
L
OK
R
when the security code
is already changed from default setting.
5 Enter the new code and press
L
OK
R
.
6 Re-enter the new code. Press
L
OK
R
.
Turning on the answering system
remotely
1 Dial your phone number from a touch-tone
phone.
2 Let the phone ring 15 times.
● The message is heard.
3 Enter
L R
and your remote security code
within 7 seconds after the message.
● You can either hang up, or begin remote
operation (page 31).
TAM language
Handset / Base unit
1
L
Menu
R
,
L
d
R
“Answ. machine”, press
L
OK
R
.
2
L
d
R
“TAM language”, press
L
OK
R
.
3
LsR
: Select the language you require.
Press
L
OK
R
.
Languages available are English or Spanish.
7 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
4 Proceed with the operation for your unit.
Handset:
L
OFF
R
to return to standby.
Base unit:
L
EXIT/STOP
R
to return to standby.
33
For assistance, please visit http://shop.panasonic.com/support
Useful Information
2 Mount the unit on a wall then slide down to
secure in place.
● This product is compliant with the following
wall phone plate size.
A
83 mm (3 ¼ inches)
Fit the slots of the unit onto the wall
phone plate.
To temporarily set the handset down during a
conversation, place it as shown here.
Charger
1 Drive the screws (not supplied) into the wall.
Mount the unit on a wall then slide down to
secure in place.
Voicemail service
In addition to your unit’s answering system
you may also have voicemail service from
your phone service provider. Voicemail is an
answering service that may be offered by your
phone service provider. This service can also
record calls when you are unavailable to answer
the phone or when your line is busy. Messages
are recorded on the phone company system and
not on the unit’s answering system.
● To use the voicemail service rather than
the unit’s answering system, turn off
the answering system (page 29).
If you have unit’s answering system set to on and
also the voicemail enabled, the system with least
amount of rings will record the message
rst.
Example:
If the unit’s answering system is set to 4 rings
(page 31) and the voicemail answering system
provided by your phone company is set to 6 rings
(call your service provider), the unit’s answering
system will record the incoming call rst.
When you have new messages,
is displayed
if message indication service is available. Please
contact your phone service provider for details of
this service.
To listen to your voicemail messages, you have
to dial your voicemail access number manually.
If still remains on the display even after you have
listened to new messages, while in the calls list
press and holding
5
for 2 seconds will delete all
voicemail messages.
Wall mounting
Note:
● Make sure that the wall and the xing method are
strong enough to support the weight of the unit.
Base unit
1 Remove the desk stand from the base unit.
1
2
3
25.4 mm (1 inch)
SERIAL NO.
LINE
USE SPECIFIED ADAPTOR
ONLY
6V DC
PUSH
PUSH
A
34
For assistance, please visit http://shop.panasonic.com/support
Useful Information
No Caller Display
● You must subscribe to Caller ID service.
Contact your phone service provider for
details.
● The caller may have withheld their number.
● The record cannot be found in the phonebook.
Check that the correct name/number is stored
in the phonebook, with the full area code.
I have forgotten my PIN!
● Restore the phone to its default settings, see
page 27.
Cannot register a handset to the base
unit
● Up to a maximum of 4 handsets can be
registered to the base unit. De-register a
handset in order to register a new one, see
page 27.
● Check that correct PIN code (default = 0000)
has been entered.
● Check that the handset and base unit are at
least one metre away from other electrical
equipment to avoid interference when
registering.
Handset does not ring
● The handset ringer volume may be set to Off,
see page 23.
Base unit does not ring
● The base unit ringer volume may be set to
Off, see page 23.
Noise interference on my phone or on
other electrical equipment nearby
● Place the phone at least one metre away from
electrical appliances or any metal obstructions
to avoid any risk of interference.
Answering machine will not record new
messages
● Is the recording memory full? Play and delete
messages.
● Is the greeting message set to “Answer
only”? Change the greeting message to
“Record also”.
Troubleshooting
No dial tone
● Use only the telephone line cord supplied.
● Check that the telephone line cord is
connected properly.
● Check that the mains power is connected
properly.
No display
● Check that the batteries are inserted correctly
and fully charged. Use only approved
rechargeable batteries supplied.
● Reset the unit by removing the batteries
and disconnecting the mains power. Wait for
around 15 seconds before connecting it again.
Allow up to one minute for the handset and
base unit to synchronize.
LCD and key backlight does not light up
during operation
● Battery charge is low. Fully charge the
batteries.
icon is not displayed
● Handset is out of range. Move closer to the
base unit.
● Check that the mains power is connected
properly.
icon is not scrolling during charge
● Adjust the handset slightly on the charger.
● Clean the charge contacts with a dry cloth.
● Check that the charger power is connected
properly.
● The battery is full. When the handset is fully
charged, icon will appear steadily on the
display.
35
For assistance, please visit http://shop.panasonic.com/support
Useful Information
network, the telephone company will notify you
in advance that temporary discontinuance of
service may be required. But if advance notice
isn’t practical, the telephone company will notify
the customer as soon as possible. Also, you will
be advised of your right to le a complaint with
the FCC if you believe it is necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operation of
the equipment. If this happens the telephone
company will provide advance notice in order for
you to make necessary modications to maintain
uninterrupted service.
If trouble is experienced with this equipment, for
repair or warranty information, please contact
a Factory Service Center or other Authorized
Servicer. If the equipment is causing harm to the
telephone network, the telephone company may
request that you disconnect the equipment until
the problem is resolved.
Connection to party line service is subject to state
tariffs. Contact the state public utility commission,
public service commission or corporation
commission for information.
If your home has specially wired alarm equipment
connected to the telephone line, ensure the
installation of this equipment does not disable
your alarm equipment. If you have questions
about what will disable alarm equipment, consult
your telephone company or a qualied installer.
This equipment is hearing aid compatible as
dened by the FCC in 47 CFR Section 68.316.
When you hold the phone to your ear, noise
might be heard in your Hearing Aid. Some
Hearing Aids are not adequately shielded from
external RF (radio frequency) energy. If noise
occurs, use an optional headset accessory or
the speakerphone option (if applicable) when
using this phone. Consult with your audiologist or
Hearing Aid manufacturer about the availability of
Hearing Aids which provide adequate shielding to
RF energy commonly emitted by digital devices.
WHEN PROGRAMMING EMERGENCY
NUMBERS AND(OR) MAKING TEST CALLS TO
EMERGENCY NUMBERS:
1 Remain on the line and briey explain to the
dispatcher the reason for the call.
2 Perform such activities in the off-peak hours,
such as early morning or late evenings.
Liquid damage
Liquid or other form of moisture has
entered the handset/base unit
● Disconnect the AC adaptor and telephone
line cord from the base unit. Remove the
batteries from the handset and leave to dry
for at least 3 days. After the handset/ base
unit are completely dry, reconnect the AC
adaptor and telephone line cord. Insert the
batteries and charge fully before use. If
the unit does not work properly, contact an
authorized service center.
Caution:
● To avoid permanent damage, do not
use a microwave oven to speed up the
drying process.
FCC and other information
This equipment complies with Part 68 of the FCC
rules and the requirements adopted by the ACTA.
On the bottom of this equipment is a label that
contains, among other information, a product
identier in the format US:ACJ----------.
● Registration No.............(found on the bottom
of the unit)
● Ringer Equivalence No. (REN).......0.9A
A plug and jack used to connect this equipment
to the premises wiring and telephone network
must comply with the applicable FCC Part 68
rules and requirements adopted by the ACTA.
A compliant telephone cord and modular plug is
provided with the product. It is designed to be
connected to a compatible modular jack that is
also compliant.
The REN is used to determine the number of
devices that may be connected to a telephone
line. Excessive RENs on a telephone line may
result in the devices not ringing in response to
an incoming call. In most but not all areas, the
sum of RENs should not exceed ve (5.0). To
be certain of the number of devices that may be
connected to a line, as determined by the total
RENs, contact the local telephone company. For
products approved after July 23, 2001, the REN
for the product is part of the product identier that
has the format US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a decimal
point (e.g., 03 is a REN of 0.3).
If this equipment causes harm to the telephone
36
For assistance, please visit http://shop.panasonic.com/support
Useful Information
FCC RF Exposure Warning:
● This product complies with FCC radiation
exposure limits set forth for an uncontrolled
environment.
● To comply with FCC RF exposure
requirements, the base unit must be installed
and operated 20 cm (8 inches) or more
between the product and all person’s body.
● This product may not be collocated or
operated in conjunction with any other
antenna or transmitter.
● For body-worn operation, the handset
must be used only with a non-metallic
accessory. Use of other accessories may not
ensure compliance with FCC RF exposure
requirements.
Notice:
● FCC ID can be found inside the battery
compartment or on the bottom of the units.
3 This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Privacy of communications may not be ensured
when using this phone.
CAUTION:
Any changes or modications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate this
device.
NOTE:
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
the instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
– Consult the dealer or an experienced radio/TV
technician for help.
Some cordless telephones operate at
frequencies that may cause interference to
nearby TVs and VCRs. To minimize or prevent
such interference, the base unit of the cordless
telephone should not be placed near or on top
of a TV or VCR. If interference is experienced,
move the cordless telephone further away from
the TV or VCR.This will often reduce or eliminate
interference.
37
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Guía rápida
Conexiones
Unidad base
1 Conecte el adaptador de corriente alterna a la unidad
presionándolo rmemente.
2
Conecte el cable de la línea telefónica a la unidad hasta
que escuche un clic.
3
Enganche el cable del adaptador de corriente alterna y el
cable de la línea telefónica para jarlos.
4
Conecte el adaptador de corriente a la toma de corriente.
5 Conecte el cable de la línea telefónica a la
toma de una sola línea telefónica (RJ11C) hasta que
escuche un clic.
6
Se requiere un ltro DSL/ADSL (no incluido)
si dispone de este tipo de servicio.
7
Conecte el cable del auricular alámbrico a este
y a la unidad base hasta que escuche un clic.
Nota:
Use solo el adaptador de corriente MN0063-L060040
que se incluye.
7
7
5
6
4
SERIAL NO.
LINE
USE SPECIFIED ADAPTOR
ONLY
6V DC
DESK STAND
12
3
33
Cargador
1 Conecte el adaptador de corriente alterna a la
unidad presionándolo rmemente.
2 Enganche el cable para jarlo.
3 Conecte el adaptador de corriente a la toma de
corriente.
Nota:
Use solo el adaptador de corriente MN0063-L060040
que se incluye.
Gancho
USE SPECIFIED AC ADAPTOR
ONLY
6 V DC
1
2
3
Gancho
38
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Instalación y carga de la batería
Cargue durante al menos 7 horas.
1 Presione
1
hacia abajo.
2 Deslice la tapa del auricular
2
.
3 Inserte las baterías y, a continuación, cierre
la tapa del auricular.
Cuando el auricular necesite carga, la pantalla
mostrará el mensaje “Batería baja” y se emitirá un
pitido de advertencia cada 2 minutos durante una llamada.
Recargue el auricular antes de usarlo nuevamente.
Cuando se esté cargando el dispositivo, se mostrará el
icono
con sus barras en movimiento.
Nota:
● UTILICE SOLO baterías recargables de Ni-MH
tamaño AAA (R03) (
A
).
● NO utilice baterías alcalinas, de manganeso
ni de Ni-Cd.
● Conrme que las polaridades estén correctas.
● Cambie el idioma de la pantalla.
1
2
A
+
–
+
–
CALL BLOCK
39
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Sugerencias de operación
Teclas de función
Al oprimir una tecla de función, puede seleccionar la función que aparece directamente encima de ella en la
pantalla.
Tecla navegadora
Auricular:
–
L
u
R
P
: Ver la lista del directorio telefónico.
–
L
d
R
CID (
Identificador de llamada ) : Ver la lista de llamadas.
–
L
u
R o L
d
R : Navegar por diversas listas o elementos.
– VOLUME (Volumen:
L
u
R o L
d
R ): Ajustar el volumen del receptor o el altavoz mientras habla.
–
L
u
R o L
d
R : Mover el cursor para editar un número o nombre.
Unidad base:
–
L
u
R o L
d
R : Navegar por diversas listas o elementos.
–
L
u
R o L
d
R : Ajustar el volumen del receptor o el altavoz mientras habla.
–
L
u
R o L
d
R, L R o L R : Mover el cursor para editar un número o nombre.
–
L R o L R : Repetir u omitir el mensaje durante la reproducción.
Auricular: Unidad base:
Cómo navegar por los menús
1
L
Menú
R
para abrir el menú principal.
2
LsR
: Opciones disponibles.
3
L
OK
R
para seleccionar una opción.
4 Para volver al nivel de menú anterior, oprima
L
Atrás
R
.
5 Para salir del menú y regresar a espera, oprima
L
OFF
R
en el auricular o
L
EXIT/STOP
R
en la unidad base.
Idioma mostrado en pantalla (Auricular/Unidad base) (predeterminado: “English”)
1
L
Menu
R
,
L
d
R
“Personal set” (Ajuste personal),
L
OK
R
.
2
L
d
R
“Language” (Idioma),
L
OK
R
.
3
LsR
: Seleccione el idioma de su preferencia,
L
OK
R
.
Menú
Remarc
L
u
R
L
u
R
L
u
R
L
u
R
L R
L R
CALL BLOCK
Menu
Redial
Menú Remarc
40
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Fecha y hora (Auricular)
1
L
Menú
R
,
L
d
R
“Ajuste personal”,
L
OK
R
.
2
L
d
R
“Fecha y hora”,
L
OK
R
.
3 Introduzca la fecha con el teclado (p. ej.
L
0
R L
7
R L
1
R L
2
R L
2
R L
0
R
para el 12 de julio de 2020),
L
OK
R
.
4 Introduzca la hora con el teclado (p. ej.
L
0
R L
9
R L
3
R L
0
R
para las 9:30),
LsR
para seleccionar “AM” o “PM”,
L
OK
R
.
Modo de marcación (Auricular/Unidad base) (predeterminado: “Tono”)
1
L
Menú
R
,
L
d
R
“Ajuste avanz.”,
L
OK
R
.
2
L
d
R
“Modo marcac”,
L
OK
R
.
3
LsR
: Seleccione “Tono” o “Pulso”,
L
OK
R
.
Operaciones básicas
Cómo hacer y contestar llamadas (Auricular)
Para hacer llamadas Levante el auricular, marque el número telefónico,
L
TALK/SP-PHONE
R
.
Para contestar llamadas Levante el auricular,
L
TALK/SP-PHONE
R
.
Para colgar
L
OFF
R
Para ajustar el volumen del receptor o del
altavoz
Oprima
LsR
repetidamente mientras habla.
Cómo hacer una llamada usando la lista de
remarcación
L
Remarc
R
,
LsR
: Seleccione la entrada deseada,
L
TALK/SP-PHONE
R
.
Cómo hacer y contestar llamadas (Unidad base)
Para hacer llamadas Marque el número telefónico. Levante el auricular alámbrico u
oprima
L
SP-PHONE
R
.
Para contestar llamadas Levante el auricular alámbrico u oprima
L
SP-PHONE
R
.
Para colgar Coloque el auricular alámbrico en la base. Cuando utilice el
altavoz, oprima
L
SP-PHONE
R
.
Para ajustar el volumen del receptor o del
altavoz
Oprima
LsR
repetidamente mientras habla.
Cómo hacer una llamada usando la lista de
remarcación
L
Remarc
R
,
LsR
: Seleccione la entrada deseada, levante el auricu-
lar alámbrico.
Para ajustar el volumen del timbre (Auricular/Unidad base)
Para ajustar el volumen del timbre Oprima
LsR
repetidamente para seleccionar el volumen deseado
mientras suena.
Directorio telefónico (Auricular/Unidad base)
Para añadir entradas 1
L
Menú
R
. “Directorio”.
2
L
OK
R
,
L
d
R
“Agregar nueva”.
3
L
OK
R
. “Introd. nombre”.
4 Introduzca el nombre,
L
OK
R
. Se muestra “Introd. nombre”.
5 Introduzca el número,
L
OK
R
.
41
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Directorio telefónico (Auricular/Unidad base)
Para hacer llamadas 1 Continúe operando su unidad.
Auricular:
L
u
R
P
Unidad base:
LPR
2
LsR
: Seleccione la entrada deseada.
O
Introduzca la primera letra del nombre para realizar una
búsqueda en orden alfabético. Se mostrará el primer
nombre que comience con dicha letra o con la letra más
cercana del alfabeto.
LsR
: Seleccione la entrada deseada.
3 Continúe operando su unidad.
Auricular:
L
TALK/SP-PHONE
R
.
Unidad base: Levante el auricular alámbrico.
Contestador de llamadas (Unidad base)
Contestador encendido/apagado Oprima
L
ANSWER ON/OFF
R
para encender y apagar el
contestador de llamadas.
Para escuchar mensajes
L
PLAY
R
Sistema contestador de llamadas (Auricular)
Para escuchar mensajes Para escuchar mensajes nuevos:
L
Escucha
R
Para escuchar todos los mensajes:
L
Menú
R
,
L
d
R
“Contestador”,
L
OK
R
.
L
d
R
“Reproducir todo”,
L
OK
R
.
42
Para obtener ayuda, visite http://shop.panasonic.com/support (solo en inglés)
Guía Rápida Española
Preguntas frecuentes
Preguntas Causa y solución
¿Por qué no se muestra
?
● El auricular está demasiado lejos de la unidad base.
Acérquelo.
● El adaptador para corriente de la unidad base no está
conectado correctamente. Conecte de nuevo el adaptador
para corriente a la unidad base.
● El auricular no está registrado en la unidad base. Regístrelo.
En la unidad base:
1 Mantenga oprimido
L
LOCATOR/INTERCOM
R
durante 5
segundos. La unidad base permanecerá en el modo de
registro durante 120 segundos.
En el auricular:
2 Si el auricular no está registrado en una unidad base:
“Registrar su Auricular”, oprima
L
OK
R
. “Presione loclzdr.
Durante 5 seg.”, oprima
L
OK
R
e introduzca el código PIN de
4 dígitos (predeterminado = 0000).
L
OK
R
.
3 Si el auricular ya está registrado en una unidad base,
oprima
L
Menú
R
,
L
d
R
“Ajuste avanz.”, oprima
L
OK
R
L
d
R
“Registrar”, oprima
L
OK
R
.
4 “Presione loclzdr. Durante 5 seg.”, oprima
L
OK
R
.
5 Introduzca el código PIN de 4 dígitos (predeterminado =
0000), oprima
L
OK
R
.
¿Cómo se incrementa el nivel de volumen
del auricular?
● Oprima repetidamente la tecla de volumen
L
u
R
mientras
habla.
¿Por qué hay ruido o
se corta la conversación?
● Trate de reubicar la unidad base de forma que se minimice
la distancia al auricular.
● Si ocurre el mismo problema incluso cuando el auricular
está junto a la unidad base,
visite: http://shop.panasonic.com/support
¿Es posible añadir otro auricular accesorio
a mi unidad base?
● Sí, puede añadir hasta 4 auriculares (incluyendo los que se
venden con su unidad base) a una sola unidad base.
● Para adquirir auriculares accesorios adicionales
(KX-TGBA85),
visite: http://shop.panasonic.com/support
Los usuarios de TTY (usuarios con impedimentos auditivos
o del habla)
pueden llamar al 1-877-833-8855.
¿Es posible mantener cargando las baterías
todo el tiempo?
● Puede dejar el auricular en el cargador el tiempo que lo
desee. Esto no daña las baterías.
¿Cómo se contestan las llamadas en espera
(2a llamada)?
● Oprima
L
FLASH
R
en el auricular o
L
ERASE/FLASH
R
en la
unidad base cuando escuche el tono de llamada en espera.
43
For assistance, please visit http://shop.panasonic.com/support
Appendix
Customer services
Accessories!
hp://shop.panasonic.com/support
Customer Services Directory
Shop
for all your Panasonic gear
Go to
Get everything you need to get the most out of
your Panasonic products
Accessories & Parts for your Camera, Phone, A/V
products, TV, Computers & Networking, Personal
Care, Home Appliances, Headphones, Baeries,
Backup Chargers & more…
For Product Informaon, Operang Assistance,
Parts, Owner’s Manuals, Dealer and Service info
go to
hp://shop.panasonic.com/support
For the hearing or speech impaired TTY: 1- 877-833-8855
As of June 2015
44
For assistance, please visit http://shop.panasonic.com/support
Appendix
Limited Warranty Coverage (For USA Only)
Labor
One (1) Year
Parts
One (1) Year
To submit a new repair request and for quick repair status visit our Web Site at
http://shop.panasonic.com/support
Panasonic Products Limited Warranty
Online Repair Request
Mail-In Service--Online Repair Request
If your product does not work properly because of a defect in materials or workmanship,
Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length
of the period indicated on the chart below, which starts with the date of original purchase
(“warranty period”), at its option either (a) repair your product with new or refurbished parts,
(b) replace it with a new or a refurbished equivalent value product, or (c) refund your
purchase price. The decision to repair, replace or refund will be made by the warrantor.
During the “Labor” warranty period there will be no charge for labor. During the “Parts”
warranty period, there will be no charge for parts. This Limited Warranty excludes both
parts and labor for non-rechargeable batteries, antennas, and cosmetic parts (cabinet).
This warranty only applies to products purchased and serviced in the United States.
This warranty is extended only to the original purchaser of a new product which was
not sold “as is”.
Telephon
e
When shipping the unit, carefully pack, include all supplied accessories listed in the
Owner’s Manual, and send it prepaid, adequately insured and packed well in a carton box.
When shipping Lithium Ion batteries please visit our Web Site at
http://shop.panasonic.com/support as Panasonic is committed to providing the most up to
date information. Include a letter detailing the complaint, a return address and provide a
daytime phone number where you can be reached. A valid registered receipt is required
under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER WILL
BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING
DATE OF PURCHASE, AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL
BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF
OF PURCHASE.
Product or Part Name
Limited Warranty (ONLY FOR U.S.A)
45
For assistance, please visit http://shop.panasonic.com/support
Appendix
Limited Warranty Limits and Exclusions
(As examples, this excludes damages for lost time, travel to and from the servicer,
loss of or damage to media or images, data or other memory or recorded content.
The items listed are not exclusive, but for illustration only.)
This warranty ONLY COVERS failures due to defects in materials or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which
are caused by products not supplied by the warrantor, or failures which result from
accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or other business
or rental use of the product, or service by anyone other than a Factory Service Center
or other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY.
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF
MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY,
ARE YOUR RESPONSIBILITY.
Some states do not allow the exclusion or limitation of incidental or consequential damages,
or limitations on how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state. If a problem with this product develops during or after the warranty period,
you may contact your dealer or Service Center. If the problem is not handled to your
satisfaction, then write to:
Panasonic Corporation of North America
Consumer Affairs Department 8th FI.
Two Riverfront Plaza
Newark NJ 07102-5490
As of January 2020
46
Index
D Date and time: 12, 24
Default settings: 27
De-registering a handset: 27
Dial mode: 12, 26
Display icons: 12
Docking tone: 23
During a power failure: 9
F Flash: 15
Flash time: 26
H Handset
Controls: 10
Equalizer: 16
Locator: 17
Name: 24
Handset speakerphone: 14
I Intercom: 16
K Key tones: 23
L Language: 24
M Making calls: 14
Menu Map: 13
Mute: 15
N Navigating the menus: 12
P Pause: 14
Phonebook: 18
PIN code: 26
Power failure: 9
R Redial
Deleting a number or the entire list: 14
Making a call: 14
Storing a number to the phonebook: 18
Registering a handset: 26
Restore default settings: 27
Ringer melody: 23
Ringer volume: 23
Rotary/pulse service: 15
S Silent mode: 23
Speed dial: 19
SP-PHONE (Speakerphone): 14
Specications: 7
T Temporary tone dialing: 15
Transferring calls: 16
Troubleshooting: 34
Index
A Alarm: 24
Answering calls: 15
Answering system
Call screening: 29
Deleting all messages: 31
Greeting message: 29
Listening to messages: 30
Memory capacity: 29
On/off: 29
Recording a memo message: 31
Remote access 31
Ring count: 31
Security code: 32
TAM language: 32
Auto answer: 24
Auto clock: 26
Auto hang-up: 24
B Base unit speakerphone: 14
Base unit controls: 11
Battery
Battery level: 9
Caution: 6
Charging: 9
Installation: 8
Note for battery charging: 9
Note for battery installation: 9
Performance: 9
Tone: 24
Type: 3
C Call block: 25
Caller ID: 21
Call waiting: 15
Call Waiting Caller ID: 15
Conference call: 17
Connections
Base unit: 8
Charger: 8
Note: 9
47
Index
TTY: 43
V Voicemail: 33
W Wall mounting: 33
© Panasonic Corporation 2020
Printed in China
PNQE1138ZA SS0120MU0
1 Reconnect AC adaptor to the base unit.
2 Check if telephone line cord is connected.
3 Use rechargeable Ni-MH batteries.
(Alkaline/Manganese/Ni-Cd batteries CANNOT be used.)
4 Read troubleshooting page in the Operating Instructions.
Visit our Web site: http://shop.panasonic.com/support
L
FAQ and troubleshooting hints are available.
If your product is not working properly. . .
IMPORTANT!
Two Riverfront Plaza, Newark, NJ 07102-5490
For your future reference
We recommend keeping a record of the following information to assist with any repair under warranty.
Serial No. Date of purchase
(found on the bottom of the base unit)
Name and address of dealer
Attach your purchase receipt here.
